体感互动展示系统 使用说明书
互动投影系统使用说明
1安装1.1运行环境要求推荐硬件配置如下CPU: Intel Pentium D 925内存: 1024M显卡: NVIDIA GeForce 8500GT硬盘: 160G视频采集卡：支持WDM驱动模拟摄像机：CCD传感器，BNC输出，加装可见光截止红外光通过滤光片760nm - 850nm 投影机：物理分辨率800x600以上，1000流明以上操作系统Windows XP / Vista / 7 32位1.2安装直接运行安装程序按提示安装完成软件需要.Net Framework 2.0 支持，如果你的电脑上没装，需要安装光盘里dotnetfx.exe 2 注册使用USB锁无需注册运行互动投影系统软件，主界面如下：进入菜单[帮助]->[注册]用户码是软件自动生成的，请把用户码发送给我，我会给你发送注册码将得到的注册码输入文本框，点注册，会提示注册成功。
3. 设置互动引擎进入菜单[互动引擎]->[设置]请按以下步骤对互动引擎进行设置：1.窗口上面实时显示当前摄像机采集画面，将摄像机对准投影画面使整个投影画面包含在摄像机画面中，拖动①②③④把4个十字准心分别对准投影画面的四个顶点。
2.设置水平翻转与垂直翻转可以翻转摄像机的画面，在摄像机画面反了的时候可以设置3.平滑与降噪是指对采集的摄像机图像作平滑与降噪处理以防产生干扰点，这两个参数通常不需要改动4.灵敏度越高动作越容易被识别，同时也越容易产生干扰，通常在70-90间调节。
5.上面的步骤设置好了后可以点击测试，这样可以立即测试引擎是否能正常工作。
点击后会出现全屏的黑画面，你可以在画面上做动作，相应的位置会出现白色的点，按Esc可以退出测试。
4运行互动模块4.1常规运行这里把互动效果内容称为互动模块，软件里自带了两个很炫的模块，池塘和秋叶。
在运行互动模块之前，我们要先启动互动引擎，不然是无法互动的。
点击菜单[互动引擎]->[启动]双击要运行的互动模块，这时你可以直接与投影画面互动。
桌面体感摄像头登记台用户手册说明书
Desktop Body Camera Dock StationUser ManualDesktop Body Camera Dock Station User ManualTABLE OF CONTENTSChapter 1 Introduction (7)1.1 Introduction (7)1.2 Key Features (7)1.3 Packing List (7)Chapter 2 Panels Description (8)2.1 Top View (8)2.2 Dock Station Cradle (9)2.3 Front Panel (10)2.4 Rear Panel (11)Chapter 3 Basic Operation (12)3.1 Start Up Dock Station (12)3.2 Activate Dock Station Software (12)3.3 Access Dock Station via Web Browser (13)Chapter 4 Department and Officer Management (15)4.1 Add Department (15)4.2 Police Officer Management (15)Chapter 5 Data Collection (17)5.1 Set Data Saving Path (17)5.1.1 For Dock Station Software User (17)5.1.2 For User Accesses Dock Station via Web Browser (17)5.2 Configure Collection Format (18)5.2.1 For Dock Station Software User (18)5.2.2 For User Accesses Dock Station via Web Browser (19)5.3 Collect Data (19)Chapter 6 Maintenance (21)6.1 Exception (21)6.2 Log Search (21)Chapter 7 Collected Data Management (22)7.1 Search Data (22)7.2 Play Data (22)7.3 Lock Data (22)7.4 File Management (22)Chapter 8 Data Backup (23)8.1 Auto Backup (23)8.2 Manual Backup (23)8.3 Restore Database (23)Chapter 9 Other Settings (25)9.1 Basic Settings (25)9.2 Edit Dock Station Software Password (25)9.2.1 Edit via Dock Station Software (25)9.2.2 Edit via Web Browser (26)9.3 Edit Web Accessing Password via Web Browser (26)User ManualCOPYRIGHT ©2017 Hangzhou Hikvision Digital Technology Co., Ltd.ALL RIGHTS RESERVED.Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.About this ManualThis Manual is applicable to Desktop Body Camera Dock Station.The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the company website(/en/).Please use this user manual under the guidance of professionals.Trademarks Acknowledgementand other Hikvision’s trademarks and logos are the properties of Hikvision in various jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.Legal DisclaimerTO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAU LTS AND ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.Regulatory InformationFCC InformationPlease take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to ope rate the equipment.FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.FCC ConditionsThis device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:1. This device may not cause harmful interference.2. This device must accept any interference received, including interference that may cause undesired operation.EU Conformity StatementThis product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the applicable harmonized European standards listed under the EMC Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: .2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: Industry Canada ICES-003 ComplianceThis device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.Applicable ModelsThis manual is applicable to DS-MH4172I.Symbol ConventionsThe symbols that may be found in this document are defined as follows.Symbol DescriptionProvides additional information to emphasize or supplementimportant points of the main text.Indicates a potentially hazardous situation, which if not avoided,could result in equipment damage, data loss, performancedegradation, or unexpected results.Indicates a hazard with a high level of risk, which if not avoided, willresult in death or serious injury.Safety Instructions●Proper configuration of all passwords and other security settings is the responsibility of theinstaller and/or end-user.●In the use of the product, you must be in strict compliance with the electrical safetyregulations of the nation and region. Please refer to technical specifications for detailedinformation.●Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited PowerSource with 100 to 240 VAC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information.●Please make sure that the plug is firmly connected to the power socket.●If smoke, odor or noise rise from the device, turn off the power at once and unplug the powercable, and then please contact the service center.Preventive and Cautionary TipsBefore connecting and operating your device, please be advised of the following tips:●Ensure unit is installed in a well-ventilated, dust-free environment.●Unit is designed for indoor use only.●Keep all liquids away from the device.●Ensure environmental conditions meet factory specifications.●Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result ofdropping it may cause damage to the sensitive electronics within the unit.●Use the device in conjunction with an UPS if possible.●Power down the unit before connecting and disconnecting accessories and peripherals.Chapter 1 Introduction1.1 IntroductionDesktop body camera dock station (hereinafter referred to as the dock station) provides you a simplified way to access and back up law-enforcement data in Hikvision body camera.1.2 Key Features●Automatically copy data in connected body camera.●Charge connected body camera.●Simultaneously collect data for up to 8 body cameras. Collection priority is configurable.●Save collected data in dock station HDD.●Accessible via web browser.1.3 Packing ListYou are recommended to check the objects in the package. Please contact us if anything is damaged or lost.Chapter 2 Panels Description 2.1 Top View122.2 Dock Station CradlePurpose:Cradle is designed to charge Hikvision body camera and collect data.Table 2-2DescriptionNo. Name Description1 Charge indicator ●Solid red: Battery placed in cradle is being charged.●Solid green: Battery placed in cradle is fully charged.2 Power indicator Solid green: Cradle power supply is connected.3 Mini USB interface ●Connect cradle with dock station.●Charge cradle.2.3 Front Panel 125432.4 Rear Panel12345678910Chapter 3 Basic Operation3.1 Start Up Dock StationStep 1Connect a VGA/HDMI display.Step 2Plug in power supply into a power socket.Step 3Turn on power switch.Step 4Enter dock station power-on user name and password and press Enter.●Default user name: Administrator●Default password: 12345The default password (12345) for the Admin account is for first-time log-in purposes only. You must change this default password to better protect against security risks, such as the unauthorized access by others to the product that may prevent the product from functioning properly and/or lead to other undesirable consequences.For your privacy, we strongly recommend changing the password to something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.3.2 Activate Dock Station SoftwarePurpose:For the first-time access, you need to activate the dock station software by setting a password. Step 1Run dock station software (body camera station).Step 2Enter the same password in Password and Confirm Password text fields.The password can only contain the digit and digit number cannot exceeds 20.Step 3Click OK.Figure 3-1Set Password3.3 Access Dock Station via Web BrowserPurpose:You can manage dock station after accessing via web browser installed in dock station or in personal computer that in the same network segment with your dock station.Step 1Open web browser, enter the IP address of the dock station and press Enter.●To visit dock station via web browser installed in dock station, use IP address 127.0.0.1.●To visit dock station via web browser installed in personal computer in the same networksegment with your dock station, use dock station IP address.●Supported web browser: Internet Explorer 8 to 11 and Chrome.Step 2Log into the dock station.●If the dock station has not been activated, activate it before login.You can only activate dock station after log into it via web browser installed in dock station.1)Set the password for the admin user account.2)Click Activation.If the dock station is already activated, enter the user name and password in the login interface, and click Login.Chapter 4 Department and Officer ManagementPurpose:After adding officer information, you can view officer information when collecting body camera data. Add department information first and then add police officer information.4.1 Add DepartmentStep 1Go to Department Management page in web browser.Step 2Click Add.Step 3Enter Department Name, Department No., and Remark.Step 4Optionally, select Parent Department if necessary.Step 5Click OK.Figure 4-1Add Department4.2 Police Officer ManagementStep 1Go to Police Officer Management page in web browser.Step 2Click Add.Step 3Enter Name, Officer No., and Device No.Device No.: The serial No. of body camera.Step 4Select Gender and Department.Step 5Optionally, enter Mobile Phone and Remark if necessary.Step 6Click OK.Chapter 5 Data Collection5.1 Set Data Saving Path5.1.1 For Dock Station Software UserPurpose:Set the saving path for collected data and data clear strategy.Step 1Go to Settings > Disk in dock station software.Step 2Configure following parameters.●Path: Select local disks for collected data.●When Free Space Under and Clean Up: When the free space of selected local disks is smallerthan the value of When Free Space Under, dock station will clear the earliest files to release a space which is specified in Clean Up.●Delete Original Data: Delete the data in body camera after it has been collected by dockstation.Step 3Click Save.5.1.2 For User Accesses Dock Station via Web BrowserStep 1Go to System Configuration > Disk Management in dock station webpage.●Root Saving Directory: Select local disks for collected data.●Free Space and Min. Space to Clean Up: When the free space of selected local disks is smallerthan the value of Free Space, dock station will clear the earliest files to release a space which is specified in Min. Space to Clean Up.●Delete Original Data: Delete the data in body camera after it has been collected by dockstation.Step 2Click Save.5.2 Configure Collection Format5.2.1 For Dock Station Software UserPurpose:Dock station will only collect the files of specified format. Follow the steps to view, modify, or delete format.Step 1Go to Settings > Basic > Collection Format.Step 2Add or delete format for video, audio, and picture.Step 3Click Save.Figure 5-3Collection Format5.2.2 For User Accesses Dock Station via Web BrowserStep 1Go to System Configuration > Dock Station Parameter.Step 2Add or delete format for video, audio, and picture.Step 3Click Save.5.3 Collect DataPurpose:After body camera is connected, dock station will automatically copy data from body camera and save them in specified HDD.Step 1Run dock station software and go to Home page to view data collection formation.Step 2Turn on body camera.Step 3Connect the body camera USB interface to a USB cable of dock station or a cradle. And then dock station will automatically collect data in the body camera.●Priority on: Click it to set the data collection of the body camera as the first priority. Datacollection of other body cameras will be stopped till the first priority data collection finished.The feature is only available for one body camera at a time. If no body camera has turned on the function, dock station will collect data from all body cameras simultaneously.●Free: The capacity of uncollected data.●Total: The total capacity of data to collect.●Green bar: Show the collection progress.●Collected data will be saved in folder: Data saving disk > StationData folder> device No. folder.Chapter 6 Maintenance6.1 ExceptionWhen network is abnormal or HDD capacity is insufficient, alarm message will appear and audible warning will be triggered.●Alarm message: Pop up alarm message in lower-right corner. Alarm message appears afterHDD capacity or network recovers to normal.●Audible warning: Device will send out audible warning. You can turn off audible warning. Refer to Logs tab for detailed alarm information.6.2 Log SearchPurpose:Operations of dock station software are recorded in the log. Search and view logs to get knowledge of dock station processes, information, etc.Step 1Go to Logs interface.Step 2Set search conditions, including Date and Event Type.Step 3Click Search.Chapter 7 Collected Data ManagementPurpose:In Local Files tab, you can search and manage the successfully collected videos, audios, pictures, etc.7.1 Search DataStep 1Go to Local Files interface.Step 2Set search conditions.Step 3Click Search.7.2 Play DataStep 1Search data to play. For details, refer to 7.1 Search Data.Step 2Click of a file to play it.7.3 Lock DataPurpose:You can lock collected data to prevent it from being deleted or modified.Step 1Search the data to lock. For details, refer to 7.1 Search Data.Step 2Check the data to lock.Step 3Click . Data lock status is shown in Unlock Status column.7.4 File ManagementPurpose:You can search files and lock files.Step 1Go to File Management page.Step 2Set search conditions.Step 3Click Search. The files meet the search conditions will be listed.Step 4Optionally, click of a file to lock it to prevent it being modified or overwritten.Chapter 8 Data BackupPurpose:When dock station software is abnormal or is re-installed, you can restore database.8.1 Auto BackupStep 1Go to Settings > Data.Step 2Enable Auto-back.Step 3Set Auto-back Interval.Step 4Enter Backup to Keep value.Backup to Keep: The upper limit of number of database backup file. Once exceeds the number, the earliest database backup file will be replaced by the new one.Step 5Click Save. Go to installation root directory of dock station software >BodyCamaraStationBackup folder to view the database backup file.8.2 Manual BackupStep 1Go to Settings > Data.Step 2Click Manual Backup. Go to upper level folder of dock station software installation path > BodyCamaraStationBackup folder to view the database backup file.8.3 Restore DatabasePurpose:When dock station database is damaged or lost, you can restore database.Step 1Go to Settings > Data.Step 2Click Restore Backup and select the database backup file to restore.Chapter 9 Other Settings9.1 Basic SettingsStep 1Go to Settings > Basic.Step 2Configure parameters as needed.●Station No.: Number of the dock station.●Logo: Modify the logo shown in the top-left corner. The logo format must be PNG and logopixel must be 60 × 42.●Station Name: Modify the name shown in the top-left corner.●Launch at Startup: Run dock station software when dock station starts up.Step 3Click Save.9.2 Edit Dock Station Software PasswordPurpose:Modify the password of docks station software.9.2.1 Edit via Dock Station SoftwareStep 1Go to Settings > Basic.Step 2Enter Current Password.Step 3Enter the same password in New Password and Confirm Password.Step 4Click Save.9.2.2 Edit via Web BrowserStep 1Go to System Configuration > User Management> Management Password.Step 2Enter Current Password.Step 3Enter the same password in New Password and Confirm.Step 4Click Save.Management Password9.3 Edit Web Accessing Password via Web Browser Purpose:Modify the web accessing password of dock station.Step 1Go to System Configuration > User Management> User Password.Step 2Enter Current Password.Step 3Enter the same password in New Password and Confirm.Step 4Click Save.0100001071205UD08161B-B。
体感互动展示系统 使用说明书
【睿云互动】体感互动展示平台使用操作说明书
体感手势互动操作
软件使用操作简单易行，一共有六个操作手势，只需站在屏幕前方，随心所欲，画面任由操作者掌控；以下是操作的六个手势：
本软件结合了客户的需求提供了一个暂停的手势，不管你在开会或者想锁定画面仔细欣赏，一个暂停的手势能够防止受自己或者他人其他动作影响，让体验者控制自如。
后台管理操作
后台结构介绍：
用户通过后台内容管理可将互动界面对应的展示模块进行自定义操作，包括：增加、删除、修改功能，同时每个模块都可以增加视频、图片，背景音乐，背景图片等。
后台管理的主界面，系统为管理员提供了多套模板选择操作，操作简洁方便；
首页模板：旋转木马与企业墙
内页模板：滑动门、渐变擦除、折叠翻页、错位拉链、百叶窗、蒙太奇、反转同心圆、淡入淡出、随机棋盘格、棋盘格、高低栅栏、立方体旋转等切换特效。
后台操作的具体步骤
第一步操作要“新建项目”，如下
设置分辨率：本软件有多种常分辨率选项，请选择与你使用显示设备适合的分辨率选项。
设置控制权限获取方式：有“双臂展开伸平”和“距离近的控制”两种权限获取方式，根据需要选择其中一个，点击确定。
第二步是设置模块与为模块设置宣传图片，如下图
选择首页模板
编辑模块标题
编辑模块切换效果
以下是设置后的模块效果：
第三步接着对模块内容进行“编辑”，最后“打包生成”就完成了操作。
添加每个模块图片内容
添加模块视频内容
添加模块背景音乐
添加背景图片
“打包生成”就完成了操作
睿云互动体感互动展示平台说明书4008-445-168。
基于体感交互技术的多人龙舟运动虚拟交互展示系统设计
- 18 -高 新 技 术体育运动一直以来都扮演着重要的社会和文化角色，同时也是人们互动、锻炼和娱乐的方式。
其中，龙舟运动作为一项历史悠久的传统体育活动，具有丰富的内涵[1]。
由于现代生活节奏加快，许多人无法亲身参与精彩的体育赛事。
虚拟现实（VR ）和体感交互技术飞速进步，为大众提供了亲身模拟体验龙舟运动的机会。
该文设计了一种基于体感交互技术的多人龙舟运动虚拟交互展示系统，该系统将传统的龙舟运动带入数字时代，使更多人可以享受其乐趣。
该系统使不同地区的龙舟爱好者使用虚拟现实头盔和手柄模拟划桨动作，通过虚拟龙舟赛事体验龙舟竞技精神。
1 系统总框架设计基于体感交互技术的多人龙舟运动虚拟交互展示系统总框架如图1所示。
由图1可知，基于体感交互技术的多人龙舟运动虚拟交互展示系统包括硬件设计、软件设计2个部分。
其中，硬件设计中采用Oculus Rift S 系列的虚拟现实头盔让参与者进入虚拟龙舟运动环境，为其提供视觉沉浸感；采用HTC Vive Controller 系列的体感控制器模拟桨的划动动作，使参与者与虚拟环境进行互动；采用Oculus Rift 内置传感器实时跟踪参与者的运动状态。
软件设计包括虚拟环境建模模块、用户界面和交互模块、多人在线模块以及训练模块4个部分。
虚拟环境建模模块通过实时三维建模技术将真实的龙舟赛道、自然景观、龙舟以及其他物体精确地还原到虚拟环境中；用户界面和交互模块根据虚拟建模模块建设的赛道分成不同的模式供参赛者选择，同时参赛者通过控制体感控制器进行虚拟龙舟运动；多人在线模块通过网络连接为不同地点的多名参与者提供互动和竞技的机会；训练模块为新手提供教程，解释龙舟赛事的规则和技巧。
以上硬件、软件的相互配合，可以为参与者提供全面的虚拟龙舟运动体验。
2 虚拟环境建模模块在基于体感交互技术的多人龙舟运动虚拟交互展示系统中，虚拟环境建模模块起到关键作用，其通过实时三基于体感交互技术的多人龙舟运动虚拟交互展示系统设计郭晓民 庄学伟（泉州经贸职业技术学院，福建 泉州 362000）摘 要：龙舟运动是一项传统的体育项目，虚拟交互展示系统可以强化参与者的互动体验，提高龙舟运动的普及度和吸引力。
互动数字展示策划书3篇
互动数字展示策划书3篇篇一《互动数字展示策划书》一、项目背景随着科技的不断发展，互动数字展示技术在各个领域的应用越来越广泛。
为了打造一个具有创新性和吸引力的互动数字展示项目，提升用户体验和展示效果，特制定本策划书。
二、项目目标1. 打造一个引人入胜的互动数字展示空间，吸引观众的注意力和参与度。
2. 以生动有趣的方式展示相关内容，提高信息传达的效果。
3. 提升品牌形象和知名度。
三、展示内容根据具体需求和主题确定展示内容，例如：1. 产品展示，包括特点、优势、应用场景等。
2. 企业发展历程、成就和愿景。
3. 特定主题的相关信息、数据和案例。
四、互动方式设计1. 触摸互动：设置触摸屏幕，让观众可以通过触摸操作获取更多信息。
2. 体感互动：利用体感设备，实现观众身体动作与展示内容的互动。
3. 虚拟漫游：创建虚拟场景，观众可自由漫游并探索。
4. 互动游戏：设计有趣的互动游戏，增加趣味性和参与度。
五、技术方案1. 显示设备：选择高清显示屏、投影仪等。
2. 互动设备：如触摸传感器、体感设备等。
3. 内容制作软件：用于制作展示内容。
4. 数据处理和传输系统：确保数据的稳定传输和处理。
六、展示布局1. 合理规划展示区域，划分不同功能区。
2. 设计流畅的参观路线，引导观众有序参观。
3. 注意空间利用和视觉效果，营造舒适的参观环境。
七、项目实施计划1. 确定项目时间表，包括设计、制作、安装调试等阶段。
2. 明确各阶段的责任人与任务分工。
3. 建立有效的沟通机制，确保项目顺利进行。
八、预算安排1. 列出各项费用的明细，包括设备采购、内容制作、施工安装等。
2. 根据预算合理安排资源，确保项目质量和进度。
九、效果评估1. 设立评估指标，如观众参与度、满意度等。
2. 在项目运行期间定期进行评估和反馈。
3. 根据评估结果进行改进和优化。
十、后续维护1. 制定设备维护计划，确保设备正常运行。
2. 定期更新展示内容，保持新鲜感和吸引力。
人机交互、体感互动技术
交互技术
人机交互技术，英文名称Human-Computer Interaction Techniques。 是指通过计算机输入、输出设备，以有效的方式实现人与计算机对话的技术。
人机交互技术
1、机器通过输 出或显示设备给人提 供大量有关信息及提 示请示等。
2、人通过输入 设备给机器输入有关 信息回答问题或机器 给出的提示请示等。
交互技术
人机交互技术是未来计算机用户界面设计中的重要内容之一，也许在不 远的将来人们可以通过电极将神经信号与电子信号互相联系，达到人脑与电 脑互相沟通的技术。可以预见，电脑甚至可以在未来成为一种媒介，到达人 脑与人脑意识之间的交流，即通常听说的心灵感应。
现在
未来
瘫痪病人用大脑控制机器臂喝啤酒
脑机互联网实现“心灵感应”
人机交互界面
输入
输出
输出指的是 由机械或设备发 出来的通知，如 故障、警告、操 作说明提示等。
人机交互界面
人机交互与人机界面的关系
人机交互
人机交互界面
人机交互是指人与机器的交互，
人机界面是指用户与含有计算机
本质上是人与计算机的交互。或者从 的机器系统之间的通信媒体或手段，
更广泛的角度理解：人机交互是指人 是人机双向信息交互的支持软件和硬
姿势（Gesture) ：主要利用 数据手套、数据服装等装置， 对手和身体的运动进行跟踪， 完成自然的人机交互。
交互技术——非精确交互技术
头部跟踪（HeadTracking）： 主要利用电磁、超声波等方法， 通过对头部的运动进行定位交 互。
视觉跟踪（Eye-Tracking）： 对眼睛运动过程进行定位的交 互方式。 （非精确交互技术视频）
交互技术
人机交互技术
《多媒体智慧展厅系统设计方案》
《多媒体智慧展厅系统设计方案》一、系统概述多媒体智慧展厅系统是一个集展示、互动、传播为一体的综合性平台。
它以数字化的内容为核心，通过多媒体设备的展示和互动手段的应用，将信息以更加直观、生动的形式呈现给参观者。
该系统具备智能化的控制和管理功能，能够实现对展厅设备、展示内容和参观流程的高效管理和优化。
二、系统组成1、多媒体展示设备（1）大屏幕显示系统：包括 LED 显示屏、拼接屏等，用于展示高清视频、图片和文字等内容。
（2）投影系统：如正投、背投等，可营造出沉浸式的展示环境。
（3）触摸一体机：提供互动操作界面，方便参观者获取信息和参与互动。
2、互动体验设备（1）虚拟现实（VR）和增强现实（AR）设备：为参观者带来身临其境的体验。
（2）互动游戏设备：增加参观的趣味性和参与度。
3、智能控制系统（1）中央控制系统：对展厅内的多媒体设备、灯光、音响等进行集中控制和管理。
（2）传感器系统：感知参观者的行为和位置，实现自动化的展示和互动。
4、内容管理系统（1）内容创作工具：用于制作和编辑展示内容，如视频、动画、图文等。
（2）内容存储和分发系统：确保内容的安全存储和快速分发到各个展示设备。
三、系统功能1、展示功能（1）多样化的内容展示：支持图片、视频、音频、动画等多种媒体形式的展示。
（2）分屏展示和联动展示：可以同时展示多个内容，并实现不同屏幕之间的联动效果。
2、互动功能（1）触摸互动：参观者通过触摸屏幕进行操作和选择。
（3）社交互动：支持参观者之间的互动交流和分享。
3、智能控制功能（1）设备自动化控制：根据预设的规则和场景，自动控制设备的开关、亮度、音量等。
（2）内容智能推送：根据参观者的兴趣和行为，推送相关的展示内容。
4、数据分析功能（1）参观者行为分析：统计参观者的停留时间、互动次数、参观路径等数据，为优化展示内容和布局提供依据。
（2）设备运行数据分析：监测设备的运行状态和故障信息，及时进行维护和管理。
四、展厅布局设计1、主题分区根据展示的主题和内容，将展厅划分为不同的区域，如历史文化区、科技创新区、产品展示区等。
互动投影系统使用详细讲解
互动投影安装说明文档一、安装方式互动投影有多种安装方式，具体选用那种方式是需要根据场地环境与硬件设备来选择的。
下列图表演示了一些安装方式。
顶装方式地面安装方式地面安装方式适合于大尺寸地面互动，对天花板的距离有要求，一般在三米以上。
如果投影面积不够，可能需要给投影机加装短焦镜头。
也可以选择一些短焦投影机。
如明基TS819ST,明基MX816ST等。
地面可以是浅色的木地板、瓷砖，或者是水泥地都可以成像，不能是高反光，需要是单一纯色。
●墙面正投安装方式墙面安装方式比较节省空间，适合正面操作。
●墙面背投安装方式●桌面安装方式二、硬件1、电脑主机电脑主机一般推荐双核处理器，可以给图像分析处理更快的支持。
显卡推荐 Nvidia 系列的中高端显卡，为了充分利用 DirectX 3D加速功能。
如果节省成本，可以不需要液晶显示器，直接输出在投影机上。
（注意，某些效果专门为 Nvidia Geforce 系列显卡写的，所以ATI显卡与一些集成显卡，有些效果将无法工作，请注意配置Nvidia Geforce系列的3D显卡）推荐配置：CPU Intel i3 或更高内存 4G 硬盘 500G 显卡 Nvidia 9600GT 以上2、投影机投影机一般推荐3000流明的，当然根据室内情况，如果较暗可以选择低流明的投影机。
如果周围光线太强需要更高流明的投影机。
3、投影机到显示器的连接线这里一般是VGA线，不过不同的显卡出来的接口可能是VGA或者是DVI，这时需要转接头。
一般VGA线信号支持50米安装距离，太长需要中继器。
VGA连接线:VGA 到DVI转接头:投影机的安装需要吊架，这个需专业人员安装。
4、摄像机：提供12V DC 的电源给摄像机供电。
镜头：采用2.8-12mm手动调焦（提供），支持视角在30-80度，一般情况下使用。
5、采集卡(提供)采集卡为USB连接方式,用来连接摄像机的，插好后,按说明书安装驱动即可，安装好后可以查看设备管理器查看是否安装成功。
L-12互动展示台使用说明书
体感互动展示系统 规格说明
体感互动展示系统规格说明硬件规格
标准版软件介绍：
体感互动展示系统标准版支持两层级UI界面，支持PNG、JPG等图片文件格式及各种常用的显示分辨率。
首层 UI 界面使用“旋转木马”式特效，如下图 1 和图2所示。
该特效使用“下一页”和“上一页”的手势在不同图片之间切换，然后使用“进入下一层”的手势进入中心下方图片所代表的第二层内容。
在首层
UI界面中，用户可定制背景、图片的数目。
图1：“旋转木马”效果一
图2：“旋转木马”效果二
第二层UI界面可使用多达12种不同的图片变换效果：滑动门、渐变擦除、折叠翻页、错位拉链、百叶窗、蒙太奇、反转同心圆、淡入淡出、随机棋盘格、棋盘格、高低栅栏、立方体旋转。
在第二层内容中，使用“下一页”和“上一页” 的手势在不同图片之间切换，然后使用“回上一层”的手势回到首层UI界面。
在第二层内容中，用户可定制图片的数目。
在每一层UI界面都可以使用“暂停”手势使体感互动展示系统进入暂停状态，此时系统对使用者的动作不做任何响应。
当系统处于“暂停”状态时，可以使用“恢复”手势使系统恢复对使用者的动作进行响应。
手势说明：
睿云互动咨询热线：400-8445-168。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
【睿云互动】体感互动展示平台使用操作说明书
体感手势互动操作
软件使用操作简单易行，一共有六个操作手势，只需站在屏幕前方，随心所欲，画面任由操作者掌控；以下是操作的六个手势：
本软件结合了客户的需求提供了一个暂停的手势，不管你在开会或者想锁定画面仔细欣赏，一个暂停的手势能够防止受自己或者他人其他动作影响，让体验者控制自如。
后台管理操作
后台结构介绍：
用户通过后台内容管理可将互动界面对应的展示模块进行自定义操作，包括：增加、删除、修改功能，同时每个模块都可以增加视频、图片，背景音乐，背景图片等。
后台管理的主界面，系统为管理员提供了多套模板选择操作，操作简洁方便；
首页模板：旋转木马与企业墙
内页模板：滑动门、渐变擦除、折叠翻页、错位拉链、百叶窗、蒙太奇、反转同心圆、淡入淡出、随机棋盘格、棋盘格、高低栅栏、立方体旋转等切换特效。
后台操作的具体步骤
第一步操作要“新建项目”，如下
设置分辨率：本软件有多种常分辨率选项，请选择与你使用显示设备适合的分辨率选项。
设置控制权限获取方式：有“双臂展开伸平”和“距离近的控制”两种权限获取方式，根据需要选择其中一个，点击确定。
第二步是设置模块与为模块设置宣传图片，如下图
选择首页模板
编辑模块标题
编辑模块切换效果
以下是设置后的模块效果：
第三步接着对模块内容进行“编辑”，最后“打包生成”就完成了操作。
添加每个模块图片内容
添加模块视频内容
添加模块背景音乐
添加背景图片
“打包生成”就完成了操作
睿云互动体感互动展示平台说明书4008-445-168。
