多通道VLF频段连续测量记录仪
多导电生理记录仪
多导电生理记录仪多导电生理记录仪,又称为多通道生理记录仪(Multi-channel physiological recording system),是一种用于测量和记录生物体内多种生理信号的仪器。
它能够同时接收多个生理信号通道的输入,将电信号转化为数字信号,并通过计算机进行数据存储和分析。
多导电生理记录仪通常具有多个输入通道,用于接收来自不同生理传感器的信号。
常见的传感器包括心电图(Electrocardiogram, ECG)、脑电图(Electroencephalogram, EEG)、肌电图(Electromyogram, EMG)、皮肤电反应(Galvanic Skin Response, GSR)、眼动图(Electrooculogram, EOG)等。
这些传感器通过电极或传感器贴片与体表接触,将生物电信号转化为电信号,再经过信号调理电路放大和滤波后,传输到多导电生理记录仪中。
多导电生理记录仪的核心部分是信号转换模块和数字信号处理模块。
信号转换模块负责将输入的模拟信号转换为数字信号,通常采用模数转换器(Analog-to-Digital Converter, ADC)完成。
通过设置不同的增益、采样率和分辨率,可以对输入信号进行精确地采集和测量。
数字信号处理模块则负责对转换后的信号进行数字滤波、放大、去噪等处理,以提高信号质量和准确性。
多导电生理记录仪使用计算机来实现数据的存储、分析和显示。
通过将记录仪与计算机连接,可以将采集到的生理信号传输到计算机的硬盘上进行存储,并通过相应的软件进行数据处理和分析。
这些软件通常具有信号处理、波形显示、事件标记、频谱分析、特征提取等功能,能够帮助研究人员对生理数据进行有针对性的分析和研究。
多导电生理记录仪在临床医学、科学研究和生物反馈等领域都有广泛的应用。
在临床医学中,它可以用于心电图监测、睡眠障碍检测、脑电图诊断等。
在科学研究中,它可以用于神经科学研究、生理学研究、运动学研究等。
多通道信号分析仪
多通道信号分析仪多通道信号分析仪(multi-channel signal analyzer)是一种用于采集、处理和分析多个通道信号的设备。
它可以同时测量和分析不同通道的信号,以便深入研究信号的特征和行为。
多通道信号分析仪广泛应用于工业自动化、通信、医疗、音频视频等领域。
多通道信号分析仪的基本原理是通过多个通道同步采样不同的信号,并将其送入数字信号处理单元进行处理和分析。
它通常包括多个输入通道、ADC(模数转换器)、DSP(数字信号处理器)和相关的软件界面。
输入通道可以是模拟信号或数字信号,ADC负责将这些信号转换为数字形式,DSP进行数字信号处理和分析,软件界面提供直观的操作界面,方便用户进行参数设置和结果显示。
1.高度集成:多通道信号分析仪将多个功能集成在一个设备中,提供了方便的操作和使用体验。
2.高速采样:多通道信号分析仪通常具备高速采样能力,可以准确捕捉快速变化的信号。
3.传感器互联:多通道信号分析仪可以与各种传感器互连,实时监测多个信号源。
4.数据可视化:多通道信号分析仪可以将采集到的信号以图表、波形、频谱等形式进行可视化展示,方便用户直观地了解信号的特征。
5.高度灵活:多通道信号分析仪可以进行实时分析和离线分析,用户可以根据需要选择不同的分析方法和参数。
1.音频视频分析:多通道信号分析仪在音频和视频领域可以用于分析音频信号、视频信号的频谱、波形、噪声等参数,可以用于音频视频设备的开发、测试和调试。
2.医学监测:多通道信号分析仪可以用于医学监测领域,例如心电图、脑电图、血氧饱和度等信号的采集和分析,有助于医生准确诊断病情。
3.通信系统测试:多通道信号分析仪可以用于通信系统的测试和优化,例如无线通信系统的信号检测、调幅度、频谱分析等,帮助保证通信系统的正常运行。
4.工业自动化:多通道信号分析仪可以用于工业自动化系统的故障检测、过程优化等,通过对多个传感器信号的实时监测和分析,提高工业生产的效率和质量。
维萨拉 VaiNet 环境监测系统说明书
应用说明www.vaisala.c nVaiNet AP10 网络接入点成熟的无线环境监测技术维萨拉 viewLinc 监测系统利用基于射频技术的维萨拉 VaiNet 无线设备对环境条件进行无线跟踪。
通过线性调频扩频 (CSS)* 信号调制,VaiNet 提供稳定的通信,在长距离范围内以及严酷、复杂和闭塞的条件下依旧可靠。
长距离无线通信避免了使用中继器来提高信号强度。
VaiNet 的无线数据记录仪以及接入点已经进行了预编程,以便于可以相互定位并建立通信。
更少的设备和配置让安装更加简单,因此,即使是之前缺乏或者没有设置联网监测系统经验的用户也能部署它。
VaiNet RFL100 无线电频率数据记录仪维萨拉 VaiNet 无线技术使用 sub-GHz 频率在环境监测应用中实现更好的信号传播。
大多数配备无线设备的工业监测系统都采用某种冗余方式防止数据记录仪网络中出现单点故障。
VaiNet 通过在多个网络接入点之间分配信号负载形成冗余。
接入点和数据记录仪之间的无线信号强度决定了最佳数据传输路径。
接入点利用以太网供电 (PoE),从而减少布线,并且可以轻松连接到 UPS*。
如果没有 PoE,则安装时提供单独的电源。
此外,大多数RFL100 型号都是完全无线的,由电池供电,可确保系统在停电期间继续监测。
如果无线网络掉线,每个记录仪可以保留长达 30 天的数据,并且,如果以太网局域网出现故障,接入点将进行额外的数据存储。
一旦网络恢复,数据记录仪和接入点就会自动将历史数据回填到监测系统软件,以确保历史记录不间断。
由于其他频率已得到广泛使用,sub-GHz 无线技术有很多优点。
VaiNet 在繁重的 2.4 GHz 频段外部进行通信,信号不易受到干扰。
sub-GHz 无线通信的另一个优点是低频信号,这意味着信号传播距离更长,穿透力更好。
工业环境和仓库环境中典型的障碍(水泥砌块墙、金属货架、重型设备、液体产品、铝箔包装)更容易被低频信号穿透。
多通道数据采集器-用户手册说明书
SensorHub多通道数据采集器用户手册版本:V3.0目录1.产品介绍 (5)2.设备快速使用流程 (7)设备连接SenseCAP云平台 (7)设备连接第三方的传感器和服务器 (8)3.组装设备 (9)设备包装清单(SensorHub) (9)设备接口介绍 (10)安装SIM卡 (10)安装天线 (11)连接传感器 (12)连接电源线 (12)4.配置设备连接到SenseCAP云平台 (13)绑定设备 (13)4.1.1注册账号 (13)4.1.2下载手机App (13)4.1.3绑定设备和传感器 (13)设备上电开机 (14)登录云平台查看数据和状态 (15)云平台使用说明 (15)API使用说明 (16)5.配置设备连接到第三方服务器 (17)准备工具 (17)5.1.1上位机配置软件 (17)5.1.2串口线连接和驱动安装 (18)配置工具功能介绍 (18)通用设置 (19)5.3.1设备编码(EUI)和上报周期修改 (21)5.3.2MQTT服务器配置 (22)5.3.3GPS配置 (24)5.3.4APN配置 (24)5.3.5读写操作和清空配置 (24)6.添加自定义传感器 (25)传感器标准及分类 (26)6.1.1用户自定义传感器 (26)6.1.2内建支持传感器 (26)用户自定义传感器示例:添加土壤温湿度传感器 (27)6.2.1准备 (27)6.2.2配置传感器基本信息 (27)6.2.3配置测量值信息 (29)6.2.4传感器测试 (31)6.2.5确认数据上传服务器 (32)在SenseCAP云平台添加自定义测量值和传感器 (36)6.3.1添加测量类型 (36)6.3.2添加传感器类型ID (37)7.故障排除和日志解析 (39)常见异常诊断 (39)7.1.1通道状态异常 (39)7.1.2在测试传感器时,报错:No sensor found. Is the sensor connected (39)7.1.3在测试传感器时,报错:[ERROR] rs485 err code: XX XX (39)日志解析 (41)8.设备安装和使用注意事项 (46)内置电池低温环境使用注意事项(必看) (46)传感器航空插头线序 (46)安装示例-数据采集器 (47)安装示例-太阳能板 (49)1.产品介绍SenseCAP是一套工业级传感网络系统,实现低功耗的环境物理量数据采集,包含可靠易用的硬件产品和软件平台服务。
8多导生理记录仪招标参数
8多导生理记录仪招标参数8多导生理记录仪是一种用于测量人体生理信号的设备,它可以同时记录多个导联的生理信号,包括心电图(ECG)、脑电图(EEG)、肌电图(EMG)和呼吸信号等。
以下是针对8多导生理记录仪的一些招标参数的详细描述。
1.通道数:这是一个非常关键的参数,决定了记录仪能同时记录多少个导联的生理信号。
因此,8多导生理记录仪应该至少具备8个通道,以支持同时记录8个导联的生理信号。
2.生理信号种类:8多导生理记录仪应该能够同时记录多种不同类型的生理信号,包括心电图、脑电图、肌电图和呼吸信号等。
这些信号种类应该在设备中有对应的接口和信号处理功能。
3.采样率:采样率指的是记录仪每秒采样的次数,用来刻画信号的时域分辨率。
要求生理记录仪的采样率足够高,以确保信号被准确地记录下来。
对于8多导记录仪,采样率应该不低于1kHz,以满足对高频组分的采样要求。
4.动态范围:动态范围表示记录仪可以准确地测量的最大和最小信号幅度的差值。
较大的动态范围有助于避免信号被过量放大或过量压缩,从而保证信号的准确性。
对于多导生理记录仪,动态范围应该在±10mV至±20mV之间。
5.噪声水平:噪声水平是指在测量信号过程中,记录仪本身引入的杂音水平。
较低的噪声水平有助于提高信号的质量和准确性。
对于8多导生理记录仪,噪声水平应该在0.5µV至1µV以内。
6.联接方式:生理记录仪应该支持多种不同类型的传感器联接方式,包括干接触式和湿接触式。
这样可以提供更多的选择和适应不同类型的患者和应用场景。
7.存储容量:生理记录仪应该具备足够的存储容量,能够长时间记录并存储大量的生理信号数据。
一般来说,8多导生理记录仪的存储容量应该在100GB至500GB之间。
8.数据传输和导出:生理记录仪应该支持多种数据传输和导出方式,包括USB接口和无线蓝牙传输等。
这样方便用户将数据导出到计算机或其他设备进行进一步的分析和处理。
多道生理记录仪技术参数
3
脉冲比例
1:1——10:1
4
脉冲幅度
0V——8V
5
脉冲步长
-50、-40、-30、-20、-10、0、10、20、30、40、50
八、硬盘/DVD/存储系统
1
DVD容量
3.6-4.7G
2
存储时间
硬盘:不间断存储140小时;DVD:12小时
3
传输速度
150 M/S
九、高分辨率显示系统
1
CPU
酷睿双核
2
内存
≥2G
3
硬盘
≥500G
4
显示分辨率
1680*1050
本参数无指向性、排它性,仅为满足医院需要。
3
输入阻抗
>5MΩ
*4
灵敏度
1、2、5、10、20、50、100、200mm/mv
五、4路高精度MAP放大器
1
低通滤波
100、200、400、600、800、1200HZ
2
高通滤波
1HZ
3
灵敏度
1、2、5、10、20、50、100、200mm/mv
六、4路有创血压放大器
1
低通滤波
20、30、40Hz
多道生理记录仪技术参数
序号
项目
技术参数
一、整机
1
安全性
符合Ⅰ类,CF级医疗仪器标准
2
样式
可移动式
3
电源
220V±10%/50HZ
二、前置式68通道高精度放大器
*1
滤波
陷波50HZ,专用于支除交流电干扰
2
采样率
4.0KHZ/CH
*3
安全保护
VIOFO A129 Pro Duo 车载DVRS说明书
Copyright2022 VIOFO ltd . All Rights Reserved. The user manual is available onhttps:///en/content/42-help-and-support/CTable of Contents Product OverviewTable of ContentsStandard ItemsOptional AccessoryDashcamBluetooth ControlCPLHardwire Kit HK4Type-C DataCableWindshield StaticSticker x2Note: The USB data cable is only for connecting the camera with computer to transfer video files or upgrade firmware, not for charging the camera.*Car Charger AdapterTrim RemovalToolGPS ModuleSpare Mount Sticky PadsProduct OverviewInstallation OperationSystem SettingsReview and Control on Smartphone Bluetooth Remote Control Standard Items Optional Accessory Product DiagramInserting / Removing the Memory Card LED Indicators Buttons and Icons Display OverviewPower On / Off Loop RecordingEmergency Recording Playback Videos PC ModeFirmware Upgrade210141721222325NoticeCustomer ServiceProduct Overview Product OverviewProduct DiagramInserting / Removing the Memory CardInserting the memory cardPush the memory card into the card slot until you hear a click, with the card label facing the forward (away from the screen).1 - Menu / Power On|Off2 - Menu Up / Recording Start / Stop3 - Menu Confirm / Video Protect / Playback4 - Menu Down /Microphone Enable / Disable 5 - Wi-Fi On|Off6 - Power in / MicroSD Card Reader Mode7 - Memory Card Slot1 - Reset Button2 - Power Status Indicator3 - Recording Status Indicator4 - Microphone Status Indicator5 - Wi-Fi Status IndicatorThe microSD card is sold separately. The microSD card must have a Class-10 or UHS-I rating and the capacity is up to 256GB.64GB,128GB and 256GB microSD cards must be formatted with the FAT32 file system, either on a computer or in the camera.We recommend you buy the VIOFO brand memory card which are manufactured with top-tier MLC NAND flash, making them durable and reliable.Removing the memory cardFormatting the cardNote:Ensure that the camera is turned off / not recording, and then push the edge of the memory card with your fingernail.The card will spring out far enough to be removed.Memory card must be formatted before first use.We suggest formatting the card periodically to ensure the best performance of the camera.Note: Formatting card will erase all data permanently , please back up important data beforehand.LED IndicatorsLEDLED Status Flashing RedSolid Red OffFlashing Red Solid RedSolid Blue Off Solid Blue OffBehavior Updating FirmwarePower On Power Off Recording Not Recording Microphone Enabled Microphone DisabledWi-Fi ConnectedWi-Fi DisabledMICWi-FiRECPWRFlashing BlueWi-Fi Enabled and waiting connectingButtons and Icons2) Select a location on the windshield behind the rear-view mirror .1) Insert the clips, then slide the mount horizontally into the slot on the back of camera.3) Wipe clean the installation surface of the windscreen with a dry cloth, it must be grease free for the sticky pad to stick firmly.4) Peel the protection film off the sticky pad and camera lens.Product Overview InstallationDisplay Overview1440P3000:00:00Recording Mode Wi-Fi StatusRecording Time Video Resolution Recording Status GPS Status Emergency Lock Microphone SD CardConnecting to PowerPlug the USB power adapter into your vehicle’s 12V / 24V female power socket. Insert the USB cable male port into the camera's mount USB port.Installation Installation5) Fix the dashcam on the selected location.Installation 1. Do not install / mount the camera in a location that interferes with the driver’s visibility and safety.2. Install / mount the camera close to the rearview mirror so that both sides of the scene being recorded are equally covered by the camera’s FOV (field of view).3. To ensure a clear view on rainy days, the lens should be positioned within the windshield wiper’s sweeping range.4. Do not install / mount the camera on or near airbag panels.5. Installation / mounting location should not be a ected by sun control film (window tint). There should not be any other electronic equipment close to the camera for optimal performance.Note:Do not install / mount the camera or cables near an airbag panel or within the airbag’s working range. The manufacturer is not liable for any injury or death caused by deployment of the airbag.TipsEmergency RecordingAutomatic emergency recordingWhen the G-sensor is activated by a collision, the current footage will be locked automatically to avoid being overwritten by loop recording.1.Loop RecordingInsert a microSD card into the camera’s card slot and automatic loop recording will begin once the camera detects power.Time frame for each video file is 1 / 2 / 3 / 5 / 10 minutes.When there is insufficient space on the microSD car, loop recording.will automatically overwrite the oldest files (one by one).Loop recording files are saved to SD card: \DCIM\Movie.1.1.2.3.2.3.4.When you start the engine, the camera will turn on and begin recording automatically.When you turn off the engine or unplug the charging cable from the power adapter, the camera will stop recording and turn off. Long press [ ] button to power on or off the camera.OperationManual emergency recordingPressing the [ ] button during a recording will lock the current file being recorded. Once locked, the file will not be overwritten by the loop recording feature.Note:Collision detection sensitivity can be adjusted in settings under the “G-sensor” option. Locked files are saved to SD card: DCIM \ Movie \ RO2.Playback VideosUnder standby mode (not recording), click once [ ] button to enter the e the arrow buttons [ ] to select the desired video and press the button [ ] to play. Press the [ ] button to exit.1.2.3.Note:The default video resolution of the dashcam is 2560 x 1440P 30fps.Operation Operation1. Connect the camera to a computer by using the included short USB cable.2. The camera will automatically turn on and "microSD Card Reader Mode" will be displayed on its LCD screen.3. The computer will detect “removable disk”.4. There will be two folders under DCIM folder: Movie (loop recording video files)Contains subfolder: Parking (Parking mode video files) RO (Protected / Locked video files) Photo (Video snapshot files)5. Copy the files needed to your computer drive.PC ModeNote:• Before using a microSD card to upgrade the firmware, formatting the card in camera is necessary to ensure stable read and write operation.• Do not unplug or power o the camera during a firmware upgrade, it may cause the camera to subsequently fail to boot.Follow the instructions on this website to upgrade the firmware: https:///en/content/42-help-and-support/Firmware UpgradePress the Menu button during video mode to access the settings.(recording need to be stopped)• Resolution: Set the video resolution of footage recorded2560 x 1600 30fps, 2560 x 1440 60fps, 2560 x 1440 30fps 2560 x 1080 60fps, 2560 x 1080 30fps, 2304 x 1296 30fps1920 x 1080 60fps, 1920 x 1080 30fps, are available for selection.• Bitrate: You can set the bitrate for video. High bitrate mayimprove the quality and smoothness of the video, especially when recording fast motion or high contrast scenes. Using high bitrate mode may decrease the amount of recording time available on your memory card. Using a low bitrate will save space and record for a longer time.• Loop Recording:• WDR:• Exposure: Adjust the value of the EV (Exposure Value) to obtain Automatically balance the lighting over bright and overdark areas.from -2.0 to + 2.0. The default is set at 0.0.• Parking Mode: There are 3 options under parking mode:① Auto event detection:The camera will automatically record for 45 seconds while a moving object is detected during parking. And it will stop recording if there are no new movements.② Time lapse recording:Time-lapse record a video at low frames at 1 / 2 / 3 / 5 / 10 fps, It keeps recording continuously without audio recorded. ③ Low bitrate recording:This mode records video continuously at low bitrate 4MB/s in mini le size with audio recorded.Note: We recommend to buy VIOFO HK4 ACC hardwire kit cable for parking mode recording.• Enter Parking Mode Timer: Parking Recording Duration.parking mode.• Parking Recording Duration: Set the Parking Recording Duration.• Parking G-sensor: The G-sensor detects significant or sudden movement (such as an impact or collision), it will trigger an event recording. We suggest setting it to High sensitivity in parking mode recording.• Parking Motion Detection: Adjust the sensitivity of the motion detection so minor motion caused by wind or rain doesn't trigger a recording while in parking mode.• Time-lapse Recording: Record video from frames captured at• Motion Detection: When this feature is activated, a recording willbegin if there is movement in front of the camera. Once the camera does not detect movement for 60 seconds, the recording will be stopped and the device will switch to detect mode. The device will record again if it will detect a new movement in front of the camera.• GPS:longer measure your speed and position nor synchronize the time/date with the atomic clock. (only available when connecting with GPS signal) Please use " Dashcam Viewer " to playback videos and to visualize your position and speed on your computer.System Settings System Settings2019• Speed Unit: Set the speed unit, kilometer per hour (KPH) or milesper hour (MPH).• G-sensor: The G-sensor measures g-shock forces. The setting from'Low’ to' High’ determines the amount of force needed to lock the le from being overwritten by loop-recording. We recommend leaving it set to 'Low’.• Date Stamp: • WiFi: Imprint the time and date on the recorded video.enable Wi-Fi quickly. We recommend choosing 5GHz Wi-Fi mode if you mobile phone support 5GHz Wi-Fi.Set it On / Off. Press the [ ] button for 3 or 5 seconds to • GPS Info Stamp: Imprint the GPS information on the recordedvideo.• Camera Model Stamp: Imprint the camera model on the recorded video.• Record Audio: Turn the microphone ON / OFF. This can be alsoactivated by pressing the [ ] button while the camera is recording.• Screen Saver: Turn the screen OFF after a set time.• Boot Delay: The camera will boot seconds later when powered on. • LED: Turn the LED light ON / OFF.• Date / Time: System date / time setting.• Time Zone: Set the current time zone for GPS time and datecalibration.Note: the time zone must be manually adjusted for daylight savings.• Language: Display language setting (English, Traditional Chinese, French, etc).• Beep Sound: • Voice Notification:• Frequency: Frequency adjustment setting to minimize Turn on / o the voice noti cation.Turn all noti cation sounds ON/OFF.ickeringand banding in recorded video.• Image Rotation: Turn the screen upside down. • Image Mirror:Reverse the image from left to right .• Format: The operation will delete all data on the Micro SD card.Note: Once you format the Micro SD card, all information will bedeleted and cannot be restored. Make sure you back up all important files before proceeding.• Format Warning: Set the number of days between formatwarnings.• Default Setting: Restore camera to factory defaults.• Car Number: Imprint a customized set of 11 digits to the recordedvideo. Useful to add license plates or identifying features.• Custom Text Stamp: Imprint the customize text on the recordedvideo.• Firmware Version: Current firmware version check..System SettingsSystem SettingsConnecting the camera to a smartphone• Search "VIOFO" on Google play store on an Android device or Apple app store on an iOS device, or scan below code to download the APP.• Download and install VIOFO APP.• Run VIOFO APP.• Turn on the Wi-Fi in the menu or long press the [ ] button. • On VIOFO app, follow app instruction to connect with camera.a smartphone. Features include full camera control, live preview, playback and video recording. With Wi-Fi enabled, the camera can be only controlled by VIOFO app.Turn on the Wi-Fi in the menu or long press the [ ] button.When the Wi-Fi is on, a Wi-Fi status icon and the password appear on the camera LCD screen.Bluetooth Remote Control2122With the Bluetooth remote control (optional ) mounted in a convenient location on your dashboard, you can safely protect important videos from being overwritten, without needing to take your eyes off the road. When you press the bluetooth remote, the camera will lock the current video file and take a video snapshot.Bluetooth Remote ControlPairing with dash camera• Power on the camera.• Press and hold the video lock button on remote control for 3 seconds to pair with camera.• If get paired successfully, the LED indicator of the remote turns blue.GET IT ONGoogle PlayDownload on theApp StoreFCC StatementThis equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment oand on, the user is encouraged to try to correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna.• Increase the separation between the equipment and receiver.• Connect the equipment into an outlet on a circuit di erent from that to which the receiver is connected.• Consult the dealer or an experienced radio / TV technician for help.Notice23Caution:Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference.(2) this device must accept any interference received, including interference that may cause undesired operation.Shenzhen VIOFO Technology Co.,Ltd, declares that this Radio Frequency peripheral is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.Notice24Customer Service 25Customer Service26VIOFO also have Product Registration Program to help customers extend warranty by 6 months.Visit and register your new product to extend the warranty from 12 months to 18 months.How to Contact Us ?Submit a ticket at Live chat box at *****************/viofo.world +86 755 8526 8909 (CN)Mon-Fri 9am-6pmProduct Registration ProgramYour Opinion MattersVideo SharingIf you have any thoughts on how we can do even better, connect with us today at *****************.Share videos caught on VIOFO camera with us. Let’s enjoy your new found together! Gain a chance to get a mysterious gift at *******************.Thanks for choosing VIOFO!From the date of purchase on, all products are warranted for 12 months and all accessories are warranted for 3 months. VIOFO offers lifetime technical support for all our users. We are committed to making sure that you are 100% satisfied with our products and services.。
地震电磁卫星观测物理量简介
地震电磁卫星观测物理量简介欧阳新艳【摘要】地震引发电离层扰动反映在某些特定的物理量上已经得到人们的共识, 但其中哪些量反映的特征最明显, 最有利于提取地震电离层异常仍然不明确, 需要进一步的深入研究. 本文介绍了法国的DEMETER、乌克兰的SICH-1M、意大利的ESPERIA及俄罗斯的COMPASS-2等几个主要地震电磁卫星的观测物理量, 以资参考.【期刊名称】《国际地震动态》【年(卷),期】2007(000)008【总页数】5页(P54-58)【关键词】地震电磁卫星;观测物理量;电离层扰动【作者】欧阳新艳【作者单位】中国地震局地震预测研究所,北京,100036【正文语种】中文【中图分类】P318.6引言由地震活动引起的电离层与磁层扰动研究开始于1964年阿拉斯加地震。
之后,利用卫星观测数据研究地震引发的电离层效应越来越广泛。
卫星观测到的地震电离层扰动现象主要有:电磁辐射、等离子体参数变化及高能粒子沉降等。
近年来,已有很多文章报道过卫星飞过震中附近区域记录到电磁辐射异常及电离层参数扰动等现象。
观测到此类扰动现象的卫星有: Alouette(1964)、 OGO-6(1969)、ISIS-2 (1971)、 GEOS-1 and 2(1978)、 Intercosmos-19(1979)、 Aureol-3(1981)、 DE-2(1981)、 Intercosmos-Bulgaria-1300(1982)、 Cosmos-1809(1987)、 Intercosmos-24(1989)等等。
而各个卫星观测到的具体的物理量都不同,实际应用中达到的效果也不尽相同。
本文介绍了目前几个主要地震卫星的观测物理量,这些卫星将是未来科学家们进行地震电离层效应研究的主要数据来源。
1 地震电磁卫星观测物理量1.1 法国DEMETER卫星法国DEMETER(Detection of Electro-Magnetic Emissions Transmitted from Earthquake Regions)卫星,于2004年6月29日成功发射,极轨椭圆轨道、倾角98.3°、高度710 km,自2005年12月中旬轨道降至660 km。
维萨拉 viewLinc 监测系统与数据记录仪说明书
维萨拉 viewLinc 监测系统连接选项www.vaisala.c n 1VaiNet 远距离无线监测特点▪本地显示和警报状态▪提供外部探头▪电池供电▪参数包括:温度、湿度、模拟和触点输入▪壳体 NEMA 评级:IP65Wi-Fi 数据记录仪2标准 Wi-Fi 适配器3电池供电无线数据记录仪 802.11 b 或 g操作系统)操作系统)可选固定或远程探头(相对湿度和温度)多端口以太网56以太网供电 vNet PoE4viewLinc Windows 操作系统)仪、viewLinc Windows 操作系统)冰箱87System components:Trending-time trends and w of controlled nitoring of s via a single l points can be dashboard end data.Protectionbe retained ach logger.ckfill to the server ures gap free data.lerts for out-of-ns are sent viaPC, buzzer, lights, ponders. Alerts knowledged using a mobileortingn be created on y run reports ly generated and according to aMS scales easily o measurement n 1,000, and is and multi-countryAccessto be installed onwww.vaisala.c n扫描代码获取更多信息。
MR1200系列便携式多通道波形监视记录仪用户说明书排版V1.0210 260(2)第二版
本手册是北京博电新力电力系统仪器有限公司的出版物。
任何形式的复制均需征得北京博电新力电力系统仪器有限公司的同意。
本手册只代表出版时的技术动态。
手册中的产品信息、说明以及所有技术数据均不具有合同约束力。
博电新力电力系统仪器有限公司保留随时对技术、配置进行修改而不另行通知的权利。
博电新力电力系统仪器有限公司对本手册中可能发生的错误不承担责任。
注意事项:当输入36V 以上电压时,注意安全防止触电事故的发生。
当输入大电流时,注意人身及被测设备安全。
记录仪为精密电子设备,请注意防水防潮。
装置工作异常时,请及时与厂家联系,请勿自行维修。
目录第一章概述 (4)第二章装置特点 (5)第三章技术指标 (6)第四章接口说明 (8)第五章操作说明 (10)5.1 波形监视、录波功能 (10)5.1.1 开始监视功能 (11)5.1.2 开始录波功能 (12)5.1.3 停止监视/录波功能 (13)5.1.4 选择设置文件 (14)5.1.5 录波设置 (15)5.1.6 监视设置 (28)5.2 数据分析功能 (32)5.2.1 谐波分析功能 (32)5.2.2 矢量分析功能 (34)5.2.3 对称分析功能 (36)5.3 文件保存及文件管理功能 (39)5.3.1 文件保存 (40)5.3.2 文件管理 (41)5.4 校准功能 (43)5.4.1 校准零值操作 (43)5.4.2校准增益操作 (45)5.5 波形及参数的显示设置 (46)5.5.1 在记录仪上电后或者监视过程中设置波形及参数的显示 (47)5.5.2 在监视停止后或者打开文件后设置波形及参数的显示 (47)5.6 波形操作 (50)第一章概述电力系统便携式故障记录仪是用于记录和分析电力系统发生故障前后相关电参数的变化过程及继电保护动作行为的装置,利用其在故障前后一段时间记录的系统运行数据可以很方便地查出原因,便携式故障记录仪作为电力系统的“黑匣子”以其便于携带、功能强大、可应用于多种场合等优点已在实际中广泛应用。
LV 5381 多路SDI监视器说明书
概要特点LV 5381MULTI SDI MONITORLV5381可以输入4路高标清(HD/SD)SDI信号并同时显示。
适合应用在摄像机工位监看光圈波形和摄像机彩色校准。
主要应对多台(1-4台)摄像机的校准和监视的使用要求,实现了可以重叠和并列显示视频信号波形,矢量波形,图像。
并且标准配备了嵌入音频电平表显示,传输误码监测和告警功能,直观监测色域错误的5条(5 Bar)功能。
除了多路信号同时显示之外,也可以将不同监看模式组合显示。
4路信号同时监看功能8.4英寸TFT-LCD液晶显示屏,最多可以显示4路SDI信号(同样的格式)。
采用的LCD液晶屏是XGA清晰度(1024×768像素)高彩色显示屏幕,也可以当做图像监视器使用。
充分的显示模式图像质量管理无法缺少的波形、矢量显示开始,可以实现图像,音频电平表,5BAR,传输误码、色域误码监测功能。
CINELITE Ⅱ・CINELITE ADVANCE标配使用CINELITE功能可轻松地处理图像显示上任意点的电平。
便于对使用基准点的几台摄像机调整增益。
使用CINEZONE功能可一目了然地确认图像上的整体亮度分布。
甚至运用CINELITE ADVANCE功能可以在在视频信号波形显示和矢量波形中联动显示图像中选择的位置电平和彩色相位。
多种显示模式多路SDI信号4画面显示之外,各种显示模式可以实现单画面显示,或分割4个画面显示多种模式。
单画面显示时视频信号波形,图像显示,音频电平表可以选择缩图的显示方式。
视频信号波形显示YCbCr,RGB,伪模拟复合信号显示。
波形扩大显示和行扫描波形显示功能等。
矢量波形显示4路SDI信号同时分屏显示或重叠显示。
各SDI信号波形用不同的颜色显示,便于监视。
准备了75%,100%刻度。
OP70遥控接口(出厂选件)通过遥控接口可以调用预设的显示模式5381SER01双链路信号选件可以同时监看两组双链路信号5381SER02音频李沙育选件实现SDI信号嵌入音频的李沙育显示功能5381SER03数据状态显示选件数据状态,数据分析,错误记录,相位差测试LR2751-I 双联机架适配器LC2129盲板显示预设功能可以记忆30个不同的个性显示和参数设置,并灵活简单调用。
东莞联仪多路温度记录仪 SH-8X 8 路 SH-16X 16 路 SH-24X 24 路 SH-3
使用说明书多路温度记录仪SH-8X 8路SH-16X 16路SH-24X 24路SH-32X 32路SH-32X 40路SH-32X 48路SH-32X 56路SH-32X 64路东莞市联仪仪器仪表有限公司Dongguan Lianyi Instrument Co., Ltd.电话:0769-******** 33213581前言感谢您选购本公司的产品,为保证用户能正确使用本产品,请在使用前认真阅读本产品说明书.并对照检查本说明书的装箱清单确认产品和附件.若有不符合请联系本公司或代理商.注意事项1.本说明书内容与仪器配套使用,因版本升级等内容有更改时,恕不另行通知.2.本说明书内容经确认无误,已用最简单的方式来表达用户对说明书的易懂性编写.如发现有不正确或说明不清晰时,请与本公司或代理商联系.3.版本:V1.1警告为了你的人身安全和能正确使用本仪器,请务必遵守本说明书要求进行操作和测量.并严格注意以下安全规定.1.电源与接地保护,本产品工作电源为AC220V供电,打开电源前应确保供电是否与额定电压匹配,并确保电源已接保护地线,以防电击,本仪器外壳已接到电源插座地线端.2.请勿在有爆炸性的环境下操作,以免发生爆炸造成人身伤害.3.请不要自行打开仪器外壳,仪器内部某些地方具有高压电,防止发生触电.4.不允许在带电的情况下插拔接线端子,以免发生触电.5.如果是因为违反安全规定需产生的仪器损坏,本公司不承担任务责任.1.概述本多路温度采集器采用32位高速CPU进行数据处理,采用5寸工业显示屏,支持K J T 型热电偶输入,多种显示方式,使用者能更加直观读取各参数,仪器具有完善的功能、性能优越和操作简单的特点,能满足生产、实验室和研发测量的需求。
广泛应用于照明电器、电动工具、家用电器、电机、电热器具医药、石油、化工、冶金、电力等行业及科研单位等领域生产企业的生产线、实验室、质检部门。
按实户需求还能订制各种测量功能,来满足更高的应用。
台湾伟林VR-18-4600010116(支持18通道),VR-06-4600010146(支持6通道)无纸记录仪产品资料-昆山布兰杰电子
1:16 MB CF 卡 3:128 MB CF 卡 X:其它规格
外壳
1:盘面式 2:桌上/手提两用型
特别选项
0:无 1:24VDC 辅助电源(6 组电源接点,可供传送器使用) 2:3 点模拟输出 3:6 点模拟输出 4:9 点模拟输出 5:盘面式附电源插头 6:盘面式附电源开关 B:黑色外壳 C:黑色外壳附 24VDC 辅助电源 X:其它规格
停止位:1 或 2 bits
3 线 RTD:2.6℃/两根导线阻抗差异的欧姆值
Ethernet 通讯模块:
2 线 RTD:2.6℃/两根导线阻抗相加的欧姆值
通讯协议:Modbus TCP/IP,10Base T
易燃电流:200nA
连接埠:AUI 与 RJ-45(可自动侦测)
共模抑制比(CMRR):120dB
红外线侦测:
常模抑制比(NMRR):55dB
侦测距离:侦测器前方 2 公尺
隔离失效电压:最少 430VAC min
工作环境与物理条件:
感知器断裂侦测:TC,RTD,mV 输入-感知器开路(断线) 工作温度:5℃ 至 50℃
4~20mA 输入-实际输入小于 1mA 时
储藏温度:-25℃至 60℃
1~5V 输入-实际输入小于 0.25V 时
组态设定画面
● 最多可观看 6 笔实时联机资料的数值图 ● 资料值以不同的颜色区分并著名通路名称,容易辨识 ● 资料值(标有通路名称与颜色)与柱状图一起显示 ● 显示目前的时间 / 日期 ● ”警报发生”与”记忆容量已满”提示
● Channel 组态设定(通路名称、修正、警报点设定…等) ● Display 显示画面设定(范围、颜色、显示模式等等) ● Tool 工具参数设定,Timer、计次与累加器(选配) ● Instrument 记录器参数设定 ● Clock 时钟设定 ● System Info 系统信息
通用型多通道高速数据采集记录仪
通用型多通道高速数据采集记录仪皮柳杨;黄莎玲;叶海福【期刊名称】《太赫兹科学与电子信息学报》【年(卷),期】2014(000)004【摘要】目前数据采集记录仪体积较大,采样频率低,记录通道少,记忆空间易受干扰而多变。
本系统以 Xilinx 的 Virtex-5系列现场可编程门阵列(FPGA)芯片XC5VLX30作为核心控制单元;采用 ADI 公司的高速 AD 进行模数转换;外围采用多片并口存储器作为存储单元,延长记录时间。
本系统能够采样16通道以上、精确度8位模拟信号,采样速率能达500 Mbps 以上,并把采样数据无线传输给上位机进行处理。
%Nowadays,-the-data-acquisition-recorder-is-featured-with-large-volume,-low-sampling-frequency,-and-less-recording-channels.-Its-memory-space-is-changeable-and-susceptible-to-interference.-The-core-control-of-this-system-is-Xilinx-Virtex-5-XC5VLX30-series-Field-Programmable-Gate-Array(FPGA)-chip.-It-adopts-the-high-speed-AD-of-ADI-Company-to-accomplish-analog-to-digital-conversion.-Peripheral-unit-employs-multiple-parallel-memories-as-storage,-which-can-extend-the-recording-time.-The-proposed-system-is-able-to-sample-more-than-16-channels-of-analog-signals-with-8-bit-precision.-The-sampling-rate-can-reach-above-500-Mbps.-And-the-sampled-data-can-be-transferred-wirelessly-to-the-PC-for-processing.【总页数】5页(P600-604)【作者】皮柳杨;黄莎玲;叶海福【作者单位】中国工程物理研究院电子工程研究所,四川绵阳 621999;中国工程物理研究院电子工程研究所,四川绵阳 621999;中国工程物理研究院电子工程研究所,四川绵阳 621999【正文语种】中文【中图分类】TN911.23;TP399【相关文献】1.基于SCSI存储设备的高速数据采集记录仪 [J], 王重阳;贾惠波2.通用型多通道高速数据采集记录仪 [J], 皮柳杨;黄莎玲;叶海福;3.通用型高速瞬态数据采集记录仪 [J],4.通用型高速瞬态数据采集记录仪 [J],5.基于ARM嵌入式高速数据采集记录仪的设计 [J], 廖奇;苗克坚;陈伯翰因版权原因,仅展示原文概要,查看原文内容请购买。
- 1、下载文档前请自行甄别文档内容的完整性,平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益,请联系客服反馈,我们会尽快为您处理(人工客服工作时间:9:00-18:30)。
HERZ TOTEM-2AMulti-Channel VLF Electromagnetic Continuous Measuring Survey InstrumentAirborne VLF data are mainly used for the in-terpretation of large scale geological features such as faults and conducting rock units, alt-hough under favourable circumstances, smaller conductors such as those due to sul-phide mineralization may be revealed. VLF data are regarded as an excellent, cost-effective complement to airborne magnetic data.The TOTEM-2A receives the magnetic com-ponent of fields radiated from VLF transmit-ters in the 15 to 25 kHz frequency range. These transmitters are located around the world for the purposes of navigation and communication with submarines. The param-eters normally measured are the change in total field and the vertical quadrature compo-nent and the total field gradient from dual sensors. The sign of the quadrature polarity is also recorded.A TOTEM-2A system includes a sensor com-prising three mutually orthogonal Air-coil or ferrite-cored coils and a pre-amplifier mount-ed on an assembly, which can be placed in-side an aerofoil (either a stinger or towed bird with 4.5 inch (114 mm) Inside diameter). A cable connects the sensor to an electronics console which provides outputs for analog and digital recorders.The TOTEM-2A employs highly unique digital and linear integrated circuits to implement the functions of crystal-controlled phase-locked loop frequency synthesizers, dual frequency heterodyne conversion and proprietary time domain sampling vector computation tech-niques.Simultaneous dual frequency operation en-sures that transmitters can be selected to provide good coupling with conductors of any orientation. The gradient mode measure-ments enhance interline contouring and de-lineation of multiple conductors.Because of its simplicity, size and ease of operation, this VLF system is an ideal add-on to existing airborne geophysical exploration systems.Air-Coil SensorOutstanding FeaturesAutomatic Measurement of two VLF Stations:The TOTEM-2A can be configured to meas-ure two VLF transmitting stations simultane-ously, which results in greatly improved data quality for two important reasons. First, the likelihood of finding conductive bodies that strike in different directions is enhanced. Secondly, responses from more than one transmitter can be correlated to verify the re-sults of each measurement, thereby resulting in better confidence in the data and thus bet-ter interpretations.TOTEM-2A VLF Nose Stinger(Photo courtesy of Tundra Airborne Surveys Ltd.) Accurate Frequency Selection:The frequency of the Line and Ortho chan-nels can be selected individually by means of three digital thumbwheel switches, in 100 Hz steps, throughout the full range of 15.0 to 24.3 kHz. Optionally through special modifi-cation the range can be extended to cover 10 to 30 kHz; however by doing so, the TOTEM-2A VLF station frequency thumbwheel set-tings will not read direct, but be indicative with an offset.Wide Signal Bandwidth:As VLF stations are located at 100 Hz incre-ments, the acceptance bandwidth around the nominal frequency is sufficient to accommo-date modulation plus some offset without causing severe modulation noise. Detects Geological Strikes in almost any direction:The TOTEM-2A has the capability to detect conductors with strikes in almost any direc-tion due to its efficiency in operation making it feasible to read two transmitted signals. Quantities Measured by theTOTEM-2A:The TOTEM-2A VLF can process simultane-ously dual frequency information from each of two spatially separated sensors, thereby permitting gradient measurement at two pri-mary field azimuths.Primary Fields:The horizontal magnetic field component Ho of the propagating field from VLF radio transmission stations is utilized by the TOTEM-2A as the source of primary excita-tion. This component continues to exist be-neath the earth’s surface as Hd, decreasing at a rate dependent on the ground conduct-ivity.Secondary Field:Conductivity variations in the horizontal plane, due to localized mineralization or other geological structure, causes a secondary field to be generated.The TOTEM-2A avoids the need for inde-pendent orientation, and amplitude or phase reference by effectively measuring the change in magnitude and the ellipticity (polar-ization) of the total field (primary plus sec-ondary).Because anomalous secondary fields are generally quite small in comparison with the primary field, these measurements equate very closely with measurement of the in-phase horizontal and quadrature vertical sec-ondary fields.The nominal 100% primary magnitude is de-termined in an anomaly free zone.To avoid interference from aircraft or bird roll, pitch and yaw, it is necessary to make field measurements with an orthogonal (xyz) array of three antennae.The three directional antennae components are designated as LINE, ORTHO and ERECT.1) LINE couples maximally with a fieldin the nominal direction of flight (in-line with flight).2) ORTHO couples maximally with afield in the nominal direction at 90º tothe direction of flight (orthogonal toflight).3) ERECT couples maximally with anominally vertical field.The field parameters which are actually com-puted by the TOTEM-2A are determined rela-tive to the principal axis signal, which may be designated as either Line or Ortho.The TOTEM-2A can process VLF signals from two primary field azimuths simultane-ously, one in each of the two principal axis channels. Parameters MeasuredTotal Field:The change in magnitude of the vector sum of the principal axis field and the in-phase components of the other two orthogonal fields. (100% primary field magnitude is con-sidered to be above the absolute magnitude of the total field established in an anomaly free zone.)Vertical Quadrature:Magnitude of that component of the Erect axis field in quadrature with the principal axis field.Horizontal Quadrature:Magnitude of that component of field, on the Line or Ortho axis orthogonal to the principal, in quadrature to the principal axis. Gradient:As the TOTEM-2A can process VLF signals from two spatially separated sensors simulta-neously, it can therefore, perform gradient measurements.Gradient is defined as the difference in mag-nitude of the total field at the lower sensorwith the total field at the upper sensor. Total field is by definition independent of sensor orientation; hence the magnitude of the gra-dient anomaly will not be modulated by rela-tive misorientation between upper and lower sensors.TOTEM-2A SPECIFICATIONSPRIMARY SOURCEMagnetic field component radi-ated from VLF radio transmitters (one or two simultaneously)PARAMETERS MEASUREDTotal field, vertical quadrature, horizontal quadrature and gradi-entFREQUENCY RANGE15 kHz to 25 kHz; front panel selectable for each channel in 100 Hz stepsExtended Range 10 to 30 kHz (Contact RMS Instruments)SENSITIVITY RANGE130 mV m to 100 mV m at 20 kHz, 3 dB down 14 kHz and 24 kHzVLF SIGNAL BANDPASS-3 dB at +80 Hz; < 4% variationat +50 HzADJACENT CHANNEL REJECTION300 to 800 Hz : 20 to 32 dB; 800 to 1500 Hz : 32 to 40 dB; > 1500 Hz : 40 dB (for < 2% noise envelope)OUT OF BAND REJECTION10 kHz to 2.5 kHz = 5 x 10-4 Am to 5 x 10 -1 Am ; < 2.5 kHz rising at 12 db octave;30 kHz to 60 kHz = 5 x 10-4 Am to 8 x 10-3 Am ; > 60 kHz rising at 6 dB octave (for no overload condition)OUTPUT FILTERTime constant 1 sec. for 0% to 50% or 10% to 90%, noise bandwidth 0.3 Hz (second order LP)INTERNAL NOISE1.3 mV m rms (ambient noise will exceed this)ELECTRIC FIELD REJECTION< 0.5% error for 20 m tow cableSFERICS FILTERReduces noise contribution of the impulse interferenceCONTROLSPower switchFrequency selector switches (Line and Ortho)Meter switch (total quad) Sferics filter switchDISPLAYSMeters (Line and Ortho) Sferics light Overload lightINPUTS Power:23 to 32 VDC; 0.5 Amps, fused Signal:Sensor upper; Sensor lowerOUTPUTSa) Total, quad, gradient, multi-plexed (line and ortho); Span: ± 1.0 Vb) Audio monitor, stereo line andortho; approx. 3 V p-pDIMENSIONS AND WEIGHT Console:480 mm x 45 mm x 340 mm 19” (1U) rack mount (19 x 1.75 x 13.4 inch.) 3.8 kg (8.3 lbs.)Sensor and Preamplifier Assembly:Air-coil: 110 mm x 490 mm (4.3 x 19.3 in.), 2.5 kg (5.5 lbs.)Optional:Ferrite: 110mm x 570 mm (4.3 x 22.4 in.), 1.5 kg (3.3 lbs.)ENVIRONMENTAL Operating temperature:Console: 0 - 50ºCPreamp/Antenna: -10 - 50ºC Storage temperature:-40 - 70ºC Relative Humidity:0 - 99% non-condensing Altitude:0 - 20,000 ft.Specifications subject to change without noticeMay 2013For additional information on these and other products, contact: Distributed By:。
