WATER INFORMATION(超声波水表说明书)
超声波液体流量计简明使用手册
Panametrics公司TransPort®PT878手持式超声波液体流量计简明使用手册概述1.以Panametrics公司提供的TransPort®PT878英文手册为准，中文简明手册仅供参考。
2.超声波时差法流量计通过使用一对传感器，每个传感器通过流体发射和接收超声波信号。
当流体流动时，顺流方向信号的传播时间短于逆流方向，这个时间差正比于流体流速。
TransPort®PT878流量计测量这个时间差，结合设置的管径参数来计算流体的流速。
3.TransPort®PT878采用管外夹装式传感器，安装简便，无需破管与接触介质。
4.TransPort®PT878采用了受专利保护的声信号编码技术，从而极大提高了信噪比,这使得TransPort®PT878不仅适用于绝大多数的纯净液体应用，也为众多包含气泡、液滴或夹带固体颗粒等传统时差法原理无法测量的两相流体提供精确、无漂的测量。
PT878新特点♦可方便地按照您想看的格式显示您想看的数据∙超大液晶显示屏▫电致背景发光▫分块显示屏可显示1到4个参数∙支持多种语言♦为恶劣的工业操作条件设计，不受地域限制∙潜水型，防护等级IP67∙配有橡胶护罩和内置支架，可保护仪表电子部分♦可方便地记录超过100,000点以上的数据，无需杂乱的电缆就可将其下载至您的PC机∙红外通讯♦易于设置与操作∙可调的手带，携带方便∙下拉式菜单与软式按键让设置瞬间完成♦FLASH闪存∙不需更换EPROMs就可通过红外通讯口升级PT878的软件程序传感器安装和测量管路要求1.考虑到管路中流体可能存在的固体颗粒和气泡的分布，传感器应水平安装。
2.管路内流体需满管。
3.选择测量管路时应该避免选用流体自上向下流动的竖直管线。
4.传感器安装位置应远离弯头，变径，阀门，节流装置，安装点直管段的要求至少要满足前10D后5D（D为管线直径）。
5.为保证超声波发射和接收稳定，管线表面应该平整光滑，传感器表面和管径接触部不允许含有空气，必须涂抹耦合剂。
超声波水表使用说明
超声波水表使用说明第一部分：引言超声波水表是一种应用超声波技术进行水量测量的智能仪表。
相比传统的机械水表，超声波水表具有精确度高、反应速度快、维护方便等优点。
本文将详细介绍超声波水表的使用方法和注意事项。
第二部分：超声波水表的安装超声波水表的安装需要遵循以下步骤：1. 清除安装位置的杂物和污垢，并确保安装位置平整稳固。
2. 将超声波水表与水管连接，确保连接处无漏水现象。
3. 打开水源，检查水表是否正常工作。
第三部分：超声波水表的使用方法超声波水表的使用方法如下：1. 用干净的布擦拭超声波水表的外壳，确保表面干净无尘。
2. 打开水龙头，水流经过超声波水表时，水表将开始工作并进行测量。
3. 超声波水表会自动记录水流量，并在表面显示当前的用水量。
4. 可以通过按键或旋转盘来切换显示模式，例如显示总用水量、流速等。
第四部分：注意事项在使用超声波水表时，需要注意以下事项：1. 避免超声波水表长时间暴露在阳光直射下，以防止温度过高影响其正常工作。
2. 定期清洁超声波水表，以防止灰尘和污垢堆积影响测量精度。
3. 如发现超声波水表异常，如显示不正常或测量值异常等情况，应及时联系专业人员进行检修或更换。
4. 注意超声波水表的防水性能，避免水流进入内部造成损坏。
第五部分：总结超声波水表是一种高精度、快速响应的水表，使用方法简单，但仍需注意安装和使用过程中的细节。
合理使用超声波水表可以提高水资源的利用效率，减少浪费，为环境保护和节能做出贡献。
超声波水表的使用说明包括安装、使用方法和注意事项等方面。
通过正确的安装和使用，我们可以充分利用超声波水表的优势，实现对水资源的有效管理和节约使用。
希望本文对超声波水表的使用者有所帮助。
