Marine Growth Preventing System
RDDJ
RDDJ Marine Growth Preventing System
船舶或平台海水冷却系统管路中有海生物的附着和生长。The marine growth adhere to the seawater pipelines and grow in it.
随着时间的累积，海生物会造成管路管径缩小，甚至堵塞。
With the accumulation of time ， the marine growth will reduce the diameter of piping, and results in blockage.
目前最常用的防海生物装置主要有2种： 即电解海水防污装置和电解铜、铝（铁）防污防腐装置。
At present, there is two main type of MGPS that be mostly commonly used: Electrolysis of Seawater Anti-fouling System & Electrolysis of Copper and Aluminum ( Iron) Anode Anti-fouling and Anti-corrosion System.
RDDJ-100 Electrolysis of Copper and Aluminum ( Iron) Anode Anti-fouling and
Anti-corrosion System 组成：恒电流控制箱、防海生物阳极、防腐蚀阳极、接线盒。
Constitute ： Control panel / Anti-fouling anode / Anti-corrosion anode / Junction box.
恒电流控制箱 Control panel
接线盒 Junction box
防腐蚀阳极
Anti-corrosion anode
防海生物阳极
Anti-fouling anode
阳极通电进行电解后，产生防海生物离子和防腐蚀离子，形成电解液。
The anode is electrified to create electro-analysis and produce anti-fouling ion or anti-corrosion ion, they form
electro-analysis liquid.
电解液由海水泵抽出，分布到海水冷却管系中，达到既防止海生物附着又防止管系腐蚀的目的。
Electro-analysis liquid are sent to cooling seawater piping by seawater pump to prevent
RDDJ-100 Electrolysis of Copper and Aluminum ( Iron) Anode Anti-fouling and
Anti-corrosion System
输入电压：AC110V/220V,50Hz/60Hz 输出电压：最大DC12V 输出电流：每路0~8A,可调
Control panel has following functions:Input voltage: AC110V/220V,50Hz/60Hz Output voltage: Max DC12V
Output current: 0~8A/channel(adjustable)
电源控制箱/
Control Panel
设置setup
电流
current
电压 voltage
消声
silence
中/英
Chinese/English
RDDJ -200 Electrolysis of Seawater Anti-fouling System
组成：控制箱 、电解槽、海水泵，喷管组件，流量指示板。
Constitute ： Control panel 、Electrolyzer 、Seawater pump 、 Injection nozzle set 、 Flow indicating plate 。
控制箱 Control panel
电解槽
Anti-corrosion anode
通过电解海水，产生次氯酸钠溶液。
Energize the seawater for electrolysis to
form Sodium hypochlorite solution
次氯酸钠溶液通过海水泵添加到冷却海水中，以抑制
海生物对管道和设备的污损。
Send the solution to the cooling seawater piping by seawater pump to prevent marine growth from the pipeline as well as prevent corrosion damagement for pipeline.
海水泵
流量指示板
Flow indicating plate
喷管组件
Injection nozzle set
RDDJ Marine Growth Preventing System
适用范围：Application ：
2.电解铜、铝（铁）防污防腐装置:结构简单，安装方便且成本低，主要用于管道海水处理量＜500m ³/h时。Electrolysis of Copper and Aluminum ( Iron) Anode Anti-fouling and Anti-corrosion System: simple structure, convenient installation and low cost sea , mainly used for pipe water flow less than 500 m³/h.
1.电解海水防污装置:操作和维修方便，对海水无污染，主要用于管道海水流量＞500m ³/h时。
Electrolysis of Seawater Anti-fouling System: convenient operation and maintenance , no pollution to the sea , mainly used for pipe water flow over 500 m³/h
。
