接线端子冲压模具设计

XX学院

毕业设计（论文）

题目接线端子冲压模具设计

姓名学号

系部

专业

指导教师职称教授

2015-04-06

摘要

在这次设计中根据所给题目的要求，首先对冲压件进行了分析，分析该零件的尺寸精度得出用一般精度的模具即可满足零件精度的要求，再从零件的形状、尺寸标注及生产批量等情况看，选择加工方案。由于模具工业的重要性,模具成型工艺在各个工业部门得到了广泛的应用,使得模具行业的产值已经大大超过机床刀具工业的产值.这一情况充分说明在国民经济蓬勃发展的过程中,在各个工业发达国家对世界市场进行激烈的争夺中,越多越多地采用模具来进行生产,模具工业明显地成为技术经济和国力发展的关键.

因此,要使国民经济各个部门获得高速发展,加速实现社会主义四个现代化,就必须尽快将模具工业搞上去,使模具生产形成一个独立的工业部门,从而充分发挥模具工业在国民经济中的关键的作用. 本设计接线端子零件冲压模具，凸凹模安装在模具下模座上。倒装复合模废料清理无须二次清理，操作方便安全，生产效率较高。设计上主要是对凸模、凹模的设计，其中主要是其工作部分的尺寸设计，以保证制件的精度和质量要求。

关键词：模具冲裁件凸模凹模

ABSTRACT

In this design according to the requirements of the topic, firstly, stamping parts are analyzed, the dimensional accuracy of the parts of the analysis that the general accuracy of the mould can meet the requirements of precision parts, from the shape, dimension and mass production situation, selection and processing scheme. Due to the importance of the mold industry, mold forming technology has been widely used in various industrial sectors, so that the mold industry output value has been greatly exceeded the machine tool industry output value. This fully explained in the process of national economy vigorous development, in the fierce competition for each industrial developed countries on the world market, more and more using mold for production, key technology and national economic development has become the mold industry obviously.

Therefore, to make each department of national economic high speed development, accelerate the realization of the four modernizations of socialism, we must mold industrial make up as soon as possible, so that the mold production formed an independent industrial sector, so as to give full play to the key role of mold industry in the national economy. The design of bending plate stamping bracket parts of the die, punch and die installed in the mould of the lower mould seat. Flip composite modulus waste disposal, without two clean, convenient and safe operation, high production efficiency. The design process of compound die and bending die compound die is similar, the bending die structure is more complex. The design is mainly the design of the punch, concave die and punch and die, which is mainly designed dimension of the part of the work, to ensure the precision and quality requirements.

Keywords: mould,blank piece;punch;dies

目录

第一章工件分析 (1)

第一节材料的工艺分析 (1)

第二节材料选择 (3)

第三节工件结构形状 (3)

第四节尺寸精度 (3)

第二章冲裁工艺方案的确定 (5)

第三章模具总体设计 (6)

第一节模具类型的选择 (6)

第二节操作与定位方式 (6)

第三节卸料、出件方式 (6)

第四节确定送料方式 (7)

第五节确定导向方式 (7)

第四章模具工艺参数确定 (8)

第一节排样设计与计算 (8)

第二节搭边值的确定 (8)

第三节进距与条料宽度计算 (9)

第四节材料利用率的计算 (12)

第五章计算冲压力与压力机的初选 (12)

的计算 (13)

第一节冲裁力F

p

的计算 (13)

第二节卸料力F

q1

的计算 (14)

第三节顶件力F

q2

第四节总的冲压力F的计算 (14)

第五节压力机的初选 (14)

第六章模具压力中心的确定 (15)

第七章冲裁模间隙的确定 (16)

第一节冲裁间隙Z (16)

第二节冲裁间隙分析 (16)
