(数控模具设计)模具技术用语

模具技术用语

各種模具常用成形方式

accurate die casting 精密壓鑄powder forming 粉末成形calendaring molding 壓延成形powder metal forging 粉末鍛造

cold chamber die casting 冷式壓鑄precision forging 精密鍛造

cold forging 冷鍛press forging 沖鍛compacting molding 粉末壓出成形rocking die forging 搖動鍛造compound molding 複合成形rotary forging 迴轉鍛造compression molding 壓縮成形rotational molding 離心成形

dip mold 浸漬成形rubber molding 橡膠成形encapsulation molding 注入成形sand mold casting 砂模鑄造extrusion molding 擠出成形shell casting 殼模鑄造

foam forming 发泡成形sinter forging 燒結鍛造

forging roll 軋鍛six sides forging 六面鍛造

gravity casting 重力鑄造slush molding 凝塑成形

hollow(blow) molding 中空(吹出)成形squeeze casting 高壓鑄造

hot chamber die casting 熱室壓鑄swaging 擠鍛

hot forging 熱鍛transfer molding 轉送成形

injection molding 射出成形warm forging 溫鍛investment casting 精密鑄造matched die method 對模成形法laminating method 被覆淋膜成形low pressure casting 低壓鑄造

lost wax casting 脫蠟鑄造matched mould thermal forming 對模熱成形模

各式模具分類用語

bismuth mold 鉍鑄模landed plunger mold 有肩柱塞式模具burnishing die 擠光模landed positive mold 有肩全壓式模具button die 鑲入式圓形凹模loading shoe mold 料套式模具center-gated mold 中心澆口式模具loose detail mold 活零件模具

chill mold 冷硬用鑄模loose mold 活動式模具

clod hobbing 冷擠壓製模louvering die 百葉窗沖切模composite dies 複合模具manifold die 分歧管模具counter punch 反凸模modular mold 組合式模具

double stack mold 雙層模具multi-cavity mold 多模穴模具electroformed mold 電鑄成形模multi-gate mold 複式澆口模具expander die 擴徑模offswt bending die 雙折冷彎模具extrusion die 擠出模palletizing die 疊層模

family mold 反套製品模具plaster mold 石膏模

blank through dies 漏件式落料模porous mold 通氣性模具duplicated cavity plate 複板模positive mold 全壓式模具fantail die 扇尾形模具pressure die 壓緊模

fishtail die 魚尾形模具profile die 輪廓模

flash mold 溢料式模具progressive die 順序模

gypsum mold 石膏鑄模protable mold 手提式模具

hot-runner mold 熱流道模具prototype mold 雛形試驗模具ingot mold 鋼錠模punching die 落料模

lancing die 切口模raising(embossing) 壓花起伏成形

re-entrant mold 倒角式模具sectional die 拼合模

runless injection mold 無流道冷料模具sectional die 對合模具segment mold 組合模semi-positive mold 半全壓式模具shaper 定型模套single cavity mold 單腔模具

solid forging die 整體鍛模split forging die 拼合鍛模

split mold 雙併式模具sprueless mold 無注道殘料模具squeezing die 擠壓模stretch form die 拉伸成形模sweeping mold 平刮鑄模swing die 振動模具three plates mold 三片式模具trimming die 切邊模

unit mold 單元式模具universal mold 通用模具unscrewing mold 退扣式模具yoke type die 軛型模

模具廠常用之標準零配件

air vent vale 通氣閥anchor pin 錨梢

angular pin 角梢baffle 調節阻板angular pin 傾斜梢baffle plate 折流檔板

ball button 球塞套ball plunger 定位球塞

ball slider 球塞滑塊binder plate 壓板

blank holder 防皺壓板blanking die 落料沖頭bolster 上下模板bottom board 澆注底板bolster 墊板bottom plate 下固定板bracket 扥架bumper block 緩衝塊

buster 堵口casting ladle 澆注包casting lug 鑄耳cavity 模穴(模仁) cavity retainer plate 模穴扥板center pin 中心梢clamping block 鎖定塊coil spring 螺旋彈簧

cold punched nut 冷沖螺母cooling spiral 螺旋冷卻栓core 心型core pin 心型梢

cotter 開口梢cross 十字接頭cushion pin 緩衝梢diaphragm gate 盤形澆口

die approach 模頭料道die bed 型底

die block 塊形模體die body 鑄模座

die bush 合模襯套die button 沖模母模

die clamper 夾模器die fastener 模具固定用零件die holder 母模固定板die lip 模唇

die plate 沖模板die set 沖壓模座direct gate 直接澆口dog chuck 爪牙夾頭dowel 定位梢dowel hole 導套孔

dowel pin 合模梢dozzle 輔助澆口dowel pin 定位梢draft 拔模錐度draw bead 張力調整桿drive bearing 傳動軸承ejection pad 頂出襯墊ejector 脫模器ejector guide pin 頂出導梢ejector leader busher 頂出導梢襯套ejector pad 頂出墊ejector pin 頂出梢ejector plate 頂出板ejector rod 頂出桿ejector sleeve 頂出襯套ejector valve 頂出閥

eye bolt 環首螺栓filling core 椿入蕊

film gate 薄膜形澆口finger pin 指形梢

finish machined plate 角形模板finish machined round plate 圓形模板
