一步法硅烷交联电力电缆
One Step Method Silone XL Cable
●一步法硅烷交联电缆。
One step method Silone XL Insulated Cable
●一步法硅烷交联防水、防白蚁、防鼠、防紫外线电力电缆。
One step method silane XL insulated Water-proof termite-proof, rat-proof ultraviolet-resistant Power Cable.
●一步法硅烷交联低烟无卤A类阻燃、耐火电力电缆。
One step method saline low-smoke non-halogen type A flame-resistance fire-proof power cable.
●一步法硅烷交联乙丙橡胶绝缘电力电缆。
One step method silane cross-linked ethylene-alkene polymer insulated power cable.
●欧美国家已经明令禁止使用PVC绝缘电缆，一步法硅烷交联电缆是极好的替代产品。
The PVC insulated cable has prohibited in European-American countries, the one-step method silane cable is the excellent substitute.
●提高了导体工作温度和短路时的温度。
Increasing the working temperature of conductor and the temperature in short-circuit.
●减小了绝缘耗损，提高了介电强度。
Decreasing the loss of insulation and increasing dielectric strength.
●燃烧时释放物无毒、无卤、无腐蚀。
The releasing substances in combustion are nontoxic, no halogen, no corrosive.
●拥有一大批一步法硅烷交联专利产品。
Owing a great number of patent products of one step method silane XL cables.
●获得湖北省高新技术企业认定证书。
Being awarded Hubei Province high-tech enterprise certificate.
■设计特点Design features
1.一步法硅烷电缆与PVC塑力缆的比较：
The comparison between one step method silane cable and PVC cable:
2. 一步法交联与二步法交联的比较：
The comparison between one step method and two step method XL cable:
一步法硅烷交联与辐照交联的比较：
The comparison between one step method silane cable and irradiation XL cable:
1.电缆绝缘厚度及导体20℃是直流电阻如下表
The following table shows the thickness of cable insulation and the DC resistance of conductor in 20℃.
2.电缆参考外径及重量见下表
注：1.一步法硅烷交联聚乙烯绝缘电力电缆0.6/1KV的结构尺寸、结构重量及载流量与0.6/1KV交联聚乙烯绝缘电力电缆相同。
2.一步法硅烷交联聚乙烯绝缘电力电缆
3.6/6KV以上的结构尺寸、结构重量及载流量与干法交联聚乙烯绝缘电力电缆相同。
Note: 1. The structural size and weight as well as carrying capacity of 0.6/1KV single stage process saline cross linking polyethylene insulation power cable is same 0.6/1KV as cross linking polyethylene insulation power cable.
2.The structural size and weight as well as carrying capacity of over
3.6/6KV single stage process saline cross linking polyethylene insulation power cable is same as dry process cross linking polyethylene insulation power cable.
