常用金属封装大功率三极管参数
型号 极性 用途 V A W β／kpl 2N5684 PNP NF/S-L 80 50 300 2N5686
MJ10013 PNP Darl-L 550 10 175
MJ11015 PNP Darl-L 120 30 200 MJ11016
MJ11033 PNP Darl-L 120 50 300 MJ11032
MJ14003 PNP S-L 80 70 300 MJ14002
MJ15004 PNP S-L 140 20 250 MJ14003
MJ15023 PNP S-L 200 16 250 MJ15022
MJ15025 PNP S-L 250 16 250 MJ15024
MJ4502 PNP NF/S-L 90 30 200 2N6518
2N5686 NPN NF/S-L 80 50 300 2N5684
BDY56 NPN NF/S-L 180 15 115
BU208A NPN TV-HA 1500 5 12.5
BU326 NPN TV-SN 800 6 60
BU932R NPN Darl-L 450 15 500ns
BUS13A NPN S-L 1000 15 175
BUS14A NPN S-L 1000 30 250
BUS48A NPN NF/S-L 1000 15 175
BUX22 NPN S-L 300 40 250
BUX48A/C NPN S-L 850/1000 15 125
BUX98A/C NPN NF/S-L 450/1000 30 250
BUY71 NPN TV-HA 2200 2 40
C1325 NPN TV-HA 1500 6 8
C1413A NPN TV-HA 1500 5 50
C1875 NPN TV-HA 1500 3.5 50
C1942 NPN TV-HA 1500 3 50
C2027 NPN TV-HA 1500 5 50
C2159 NPN S-L 400 50 200
C2246 NPN S-L 450 15 100
C2443 NPN S-L 600 50 400
C2707 NPN NF/S-L 180 15 150
C2770 NPN S-L 600 100 770
C2820 NPN S-L 500 20 125
C2830 NPN S-L 500 20 200
C2928 NPN HA 1500 5 80
C2930 NPN S-L 500 30 200
C3026 NPN S-L 1700 5 50
C3058 NPN S-L 600 30 200
C3168 NPN S-L 500 20 200
C3213 NPN S-L 800 75 400
C3215S NPN S-L 1200 10 125
C3216S NPN S-L 1200 20 200
C3517 NPN S-L 1200 50 300
C3769 NPN TV-HA 1500 8 50
D1175 NPN HA 1500 5 100 intergr.D. D1279 NPN HA/S-L 1400 10 50
D641 NPN S-L 600 15 150
D650 NPN Darl-L 400 6 80
D797 NPN NF/S-L 100 30 200
D820 NPN TV-HA 1500 5 50
D821 NPN TV-HA 1500 6 50
D822 NPN TV-HA 1500 7 50
D850 NPN TV-HA 1500 3 65
D869 NPN TV-HA 1500 3.5 50 intergr.D. D870 NPN TV-HA 1500 5 50 intergr.D. D871 NPN TV-HA 1500 6 50 intergr.D. D898B NPN TV-HA 1500 3 50 intergr.D. D900B NPN TV-HA 1500 5 50 intergr.D. D905 NPN TV-HA 1400 8 50
D950 NPN TV-HA 1500 3 42 intergr.D. D951 NPN TV-HA 1500 3 65 intergr.D. MJ10009 NPN Darl-L 700 20 175
MJ10012 NPN Darl-L 400 10 175
MJ10014 NPN Darl-L 600 10 175
MJ10015 NPN Darl-L 600 50 250
MJ10016 NPN Darl-L 500 50 250
MJ10024 NPN Darl-L 750 20 200
MJ10025 NPN Darl-L 850 20 250
MJ11016 NPN Darl-L 120 30 200 MJ11015 MJ11032 NPN Darl-L 120 50 300 MJ11033 MJ12005 NPN HA/S-L 1500 8 100
MJ13333 NPN S-L 400 20 175
MJ13335 NPN S-L 500 20 175
MJ14002 NPN S-L 80 70 300 MJ14003 MJ15002 NPN S-L 140 15 200
MJ15003 NPN S-L 140 20 250 MJ15004 MJ15022 NPN S-L 200 16 250 MJ15023 MJ15024 NPN S-L 250 16 250 MJ15025 2N5685 NPN NF/S-L 60 50 300 2N5684 2N6678 NPN S-L 650 20 175
