DMOSApplication NoteAN-D15 The following outline explains how to read and use SupertexMOSFET data sheets. The approach is simple and care hasbeen taken to avoid getting lost in a maze of technical jargon.The VN3205 data sheet was chosen as an example because ithas the largest choice of packages. The product nomenclatureshown applies only to Supertex proprietary products.Advanced DMOS TechnologyThis enhancement-mode (normally-off) DMOS FET transistorsutilize a vertical DMOS structure and Supertex’s well-provensilicon-gate manufacturing process. This combination producesdevices with the power handling capabilities of bipolar transistorsand with the high input impedance and negative temperaturecoefficient inherent in MOS devices. Characteristic of all MOSstructures, these devices are free from thermal runaway andthermally-induced secondary breakdown.Supertex vertical DMOS FETs are ideally suited to a wide rangeof switching and amplifying applications where high breakdownvoltage, high input impedance, low input capacitance, and fastswitching speed are desired.Maximum resistance from drain tosource when device is fully turned onDrain to source breakdown voltage& drain to gate breakdown voltageMinimum drain current whendevice is fully turned onUnderstanding MOSFET DataBV DSS/R DS(ON)I D(ON)BV DGS(max)(min)SOT-89TO-92Quad P-DIP DIE50V0.3Ω 3.0A VN3205N8VN3205N3VN3205N6VN3205NDOrder Number / PackageOrdering InformationThis section outlines main features of the productN-Channel Enhancement-ModeVertical DMOS FETsDevice StructureV:Vertical DMOS (discretes & quads)D:Vertical Depletion-Mode DMOSdiscretesT:Low threshold vertical DMOSdiscretesL:Lateral DMOS discretesType of Channel•N-Channel, or•P-ChannelDesignSupertex Family numberVN3205Drain-to-Source Breakdown Voltagedivided by 10.05:50V11/12/01Supertex Inc. does not recommend the use of its products in life support applications and will not knowingly sell its products for use in such applications unless it receives an adequate "products liabilityPackage Options•All Supertex devices can be stored and operated satisfactorily within these junction temperature (T J ) limits.•Appropriate derating factors from curves and change in parameters due to reduced/elevated temperatures have to be considered when temperature is not 25°C.•Operation at T J below maximum limit can enhance operating life.V GS•Most Supertex FETs are rated for ±20V•± voltage handling capability allows quick turn off by reversing bias.•External protection should be used when there is a possibility of exceeding this rating. Stress exceeding ±20V will result in gate insulation degradation and eventual failure.Maximum allowable temperature at leads while soldering,1.6mm away from case for 10 seconds.Absolute Maximum RatingsDrain-to Source Voltage BV DSS Drain-to-GateBV DGS Gate-to-Source Voltage±20VOperating and Storage Temperature -55°C to +150°CSoldering Temperature300°CRatings given in product summary.Extreme conditions a device can be subjected to electrically and thermally. Stress in excess of these ratings will usually cause permanent damage.Thermal CharacteristicsDevice characteristics affecting limits of heat produced and removed from device. Die size, R DS(ON) and packaging type are the main factors determining these thermal limitations.The following DC parameters are 100% tested with 300µS, 2% duty cycle pulsed at 25°C, BV DSS , V GS(TH), I DSS , I D(ON) & R DS(ON).•∆V GS(TH) and ∆R DS(ON) are guaranteed by design ie., when device is functional for other DC parameters, these two parameters will not deviate from published values.•Since a representative sample is adequate to assure consistency of specs, A.C.parameters are sample tested on a lot/batch basis.•High temperature testing on sample basis when requested with hi-rel processing.•Refer to section 3 “power MOS structures” for test circuits used for measurement.∆R DS(ON)•Positive temperature coefficient.•Enhances stability due to current sharing during parallel operation.R DS(ON)•Drain to source resistance measured when device is partially turned on at V GS = 4.5V, and fully turned on at V GS = 10V.•Designers should use maximum values for worst case condition.•When better turn on characteristics (ie., low R DS(ON)) is required for logic level inputs, Supertex’s low threshold TN & TP devices may be used.•Typical value of R DS(ON) can be calculated at various V GS conditions by using output characteristics or saturation characteristics family of curves (I D vs. V DS ).•R DS(ON) increases with higher drain currents. R DS(ON) curve has a slight slope for low values of I D , but rises rapidly for high values.I D(ON)•Defined as the minimum drain current when device is turned on.•Supertex measures I D(ON) min. at V GS = 10V.Although Supertex specifies a typical value of I D(ON), the designer should use minimum value as the worst case.BV DSS•Please see product summary (part I)•Positive temperature coefficient. See curve BV DSS vs. T J .V GS(TH)•Voltage required from gate to source to turn on device to certain I D current value given in “condition” column.•I D measurement condition is low for small die and higher for larger die.∆V GS(TH)•Threshold voltage reduces whentemperature increases and vice versa.•Value at temperature other than 25 °C can be determined by V GS(TH)(normalized) vs. T J curve.I GSS•Since the gate is insulated from the rest of device by a silicon dioxide insulating layer, this parameter depends on thick-ness/integrity of layer and size of device.•Measured at maximum permissible voltage from gate to source: ±20V.•Values of this parameter are often tens/hundreds of times less than published maximum value. Electrical screening is done at 100nA since test equipmentfunctions slowly at lower values, which is not practical for mass production. Con-sult factory for screening lower values.I DSS•This is the leakage current from drain to source when device is fully turned off.•Measured by applying maximumpermissible voltage between drain and source (BV DSS ) and gate shorted to source (V GS = 0)•Special electrical screening possible at lower values since max. published values are higher to achieve practical testing speeds.Symbol ParameterMin TypMaxUnit Conditions BV DSS Drain-to-Source Breakdown Voltage 50V V GS = 0V, I D = 10mA V GS(th)Gate Threshold Voltage0.82.4V V GS = V DS , I D = 10mA ∆V GS(th)Change in V GS(th) with Temperature -4.3-5.5mV/°C V GS = V DS , I D = 10mA I GSS Gate Body Leakage1.0100nA V GS = ±20V, V DS = 0V I DSSZero Gate Voltage Drain Current10µA V GS = 0V, V DS = Max Rating 1mA V GS = 0V, V DS = 0.8 Max Rating T A = 125°CI D(ON)ON-State Drain Current3.014A V GS = 10V, V DS = 5V R DS(ON)TO-92 and P-DIP 0.45ΩV GS = 4.5V, I D = 1.5A SOT-890.45ΩV GS = 4.5V, I D = 0.75A TO-92 and P-DIP 0.3ΩV GS = 10V, I D = 3A SOT-890.3ΩV GS = 10V, I D = 1.5A ∆R DS(ON)Change in R DS(ON) with Temperature 0.85 1.2%/°C V GS = 10V, I D = 3A G FS Forward Transconductance 1.01.5V DS = 25V, I D = 2A C ISS Input Capacitance220300C OSS Common Source Output Capacitance 70120pFV GS = 0V, V DS = 25V C RSS Reverse Transfer Capacitance 2030 f = 1 MHzt d(ON)Turn-ON Delay Time 10t rRise Time15nst d(OFF)Turn-OFF Delay Time 25t f Fall Time25V SD Diode Forward Voltage Drop 1.6V V GS = 0V, I SD = 1.5A t rrReverse Recovery Time300nsV GS = 0V, I SD = 1AElectrical Characteristics (@ 25°C unless otherwise specified)ΩV DD = 25V I D = 2AR GEN = 10ΩSwitching Characteristics (continued)t d(OFF)•The sequence of events now begins to reverse. C ISS discharges through R GEN . The rise of V DS is initially slowed by increase of output capacitance.t RR•The reverse recovery time is the time needed for the carriergradient, formed during forward biasing, to be depleted when the biasing is reversed.•An external fast recovery diode may be connected from drain to source to improve recovery time.V SD•This is the forward voltage drop of the parasitic diode between drain and source.•Diode my be used as a commutator in H bridge configurationsor in a synchronous rectifier mode. Excessive fly back voltages may be clamped by this diode in a totem pole configuration.t f•V DS rises as the load resistor charges the output capacitance.t r•When C ISS is driven to a voltage exceeding V GS(TH), conduction from drain source begins. G FS increases causing increase in C ISS due to “Miller Effect” Charge requirements to Region II increase considerably. Gain stabilizes in Region III and “Miller Effect” is nullified, resulting in a linear change in V GS for increase in Q G .Symbol ParameterMin TypMaxUnit Conditions BV DSS Drain-to-Source Breakdown Voltage 50V V GS = 0V, I D = 10mA V GS(th)Gate Threshold Voltage0.82.4V V GS = V DS , I D = 10mA ∆V GS(th)Change in V GS(th) with Temperature -4.3-5.5mV/°C V GS = V DS , I D = 10mA I GSS Gate Body Leakage1.0100nA V GS = ±20V, V DS = 0V I DSSZero Gate Voltage Drain Current10µA V GS = 0V, V DS = Max Rating 1mA V GS = 0V, V DS = 0.8 Max Rating T A = 125°CI D(ON)ON-State Drain Current3.014A V GS = 10V, V DS = 5V R DS(ON)TO-92 and P-DIP 0.45ΩV GS = 4.5V, I D = 1.5A SOT-890.45ΩV GS = 4.5V, I D = 0.75A TO-92 and P-DIP 0.3ΩV GS = 10V, I D = 3A SOT-890.3ΩV GS = 10V, I D = 1.5A ∆R DS(ON)Change in R DS(ON) with Temperature 0.85 1.2%/°C V GS = 10V, I D = 3A G FS Forward Transconductance 1.01.5V DS = 25V, I D = 2A C ISS Input Capacitance220300C OSS Common Source Output Capacitance 70120pFV GS = 0V, V DS = 25V C RSS Reverse Transfer Capacitance 2030 f = 1 MHzt d(ON)Turn-ON Delay Time 10t rRise Time15nst d(OFF)Turn-OFF Delay Time 25t f Fall Time25V SD Diode Forward Voltage Drop 1.6V V GS = 0V, I SD = 1.5A t rrReverse Recovery Time300nsV GS = 0V, I SD = 1AElectrical Characteristics (@ 25°C unless otherwise specified)ΩV DD = 25V I D = 2AR GEN = 10Ω1235 Bordeaux Drive, Sunnyvale, CA 9408911/12/01。
