史赛克动力系统彩页-180918
瑞典SEP B-13混合动力装甲车辆战术系统
瑞典SEP B-13混合动力装甲车辆战术系统瑞典虽然是永久中立国，不参加任何军事集团，但军工技术却令人瞩目，而且所有军种的主要武器装备，都是自行生产的。
瑞典在装甲车辆方面的成就是公认的，技术方面在全世界居领先地位，包括美国陆军新型“斯特赖克”装甲车都引进了瑞典的技术。
瑞典已经成功的研制出世界上第一种全电动模块装甲战术系统，包括轮式和履带式两种规格，将军用装甲车辆的开发，引入一个全新阶段。
瑞典SEP B-13模块装甲战术系统瑞典阿尔维斯·赫格隆公司正在发展一种先进的“多用途装甲平台”（SEP）B-13模块装甲战术系统，综合一套全电传动系统和可折卸、可互换任务模块系列组件。
主要特点是：全电传动系统真正将发动机和驱动系统分开，发动机带动发电机产生电力并同时向蓄电系统储存，通过电缆将动力传输到电动机来驱动；模块化装甲战术系统、车辆的履带式或轮式平台和乘员模块之间是独立的，可快速拆卸、可互换和可单独运输。
只要根据需要换装不同的任务模块，就能组合出不同用途装甲车辆，多达24种类型。
一、瑞典SEP发展计划瑞典SEP发展工作从1996年开始，分履带式系统和轮式系统两大类型，主要由瑞典阿尔维斯·赫格隆公司负责开发。
瑞典的全电动模块装甲车辆计划一经推出就受众多国家青睐，共同参加研制，主要有芬兰、荷兰、意大利、希腊、瑞典和土耳其等六个国家。
2000年11月，第一辆SEP-履带式示范车辆交付给瑞典国防装备局（FMV）用于评估。
到2003年，车辆已经进行各种不同的试验行程达2,000 公里。
瑞典国防装备局在2001年11月，授予阿尔维斯·赫格隆公司开发SEP-轮式型号合同。
第一辆在履带式系统基础上开发的SEP-轮式原型示范车辆。
在2003年瑞典国防装备局授予一份风险减少合同给阿尔维斯·赫格隆公司，制造第二辆SEP-履带式测试平台车辆。
2004年4月22日，瑞典阿尔维斯·郝格隆茨公司向瑞典国防装备局交付了第一辆SEP-轮式原型示范车辆。
Stryker设备产品信息
