海康威视民用产品介绍
海康威视 3000C 产品配置 指导手册
3000C产品配置指导手册版权所有©杭州海康威视数字技术股份有限公司2019。
保留一切权利。
本手册的任何部分，包括文字、图片、图形等均归属于杭州海康威视数字技术股份有限公司或其子公司（以下简称“本公司”或“海康威视”）。
未经书面许可，任何单位和个人不得以任何方式摘录、复制、翻译、修改本手册的全部或部分。
除非另有约定，本公司不对本手册提供任何明示或默示的声明或保证。
关于本手册本手册描述的产品仅供中国大陆地区销售和使用。
本手册作为指导使用。
手册中所提供照片、图形、图表和插图等，仅用于解释和说明目的，与具体产品可能存在差异，请以实物为准。
因产品版本升级或其他需要，本公司可能对本手册进行更新，如您需要最新版手册，请您登录公司官网查阅（）。
海康威视建议您在专业人员的指导下使用本手册。
商标声明为海康威视的注册商标。
本手册涉及的其他商标由其所有人各自拥有。
责任声明●在法律允许的最大范围内，本手册所描述的产品（含其硬件、软件、固件等）均“按照现状”提供，可能存在瑕疵、错误或故障，本公司不提供任何形式的明示或默示保证，包括但不限于适销性、质量满意度、适合特定目的、不侵犯第三方权利等保证；亦不对使用本手册或使用本公司产品导致的任何特殊、附带、偶然或间接的损害进行赔偿，包括但不限于商业利润损失、数据或文档丢失产生的损失。
●若您将产品接入互联网需自担风险，包括但不限于产品可能遭受网络攻击、黑客攻击、病毒感染等，本公司不对因此造成的产品工作异常、信息泄露等问题承担责任，但本公司将及时为您提供产品相关技术支持。
●使用本产品时，请您严格遵循适用的法律。
若本产品被用于侵犯第三方权利或其他不当用途，本公司概不承担任何责任。
●如本手册内容与适用的法律相冲突，则以法律规定为准。
前言本节内容的目的是确保用户通过本手册能够正确使用产品，以避免操作中的危险或财产损失。
在使用此产品之前，请认真阅读产品手册并妥善保存以备日后参考。
符号约定对于文档中出现的符号，说明如下所示。
海康威视产品手册第六版
网络硬盘录像机海康威视的网络硬盘录像机是结合IT领域多项最新技术（如视音频压缩/解压缩、大容量硬盘记录/检索、TCP/IP网络等技术），专为安全技术防范领域设计的数字监控产品。
它同时具备数字视音频录像机（DVR）和数字视音频服务器（DVS）的特性，既可本地独立工作，也可联网组成一个强大的安全监控网，广泛用于银行、电力、公安、司法、交通、电信、小区、工矿、企业、水利设施等各领域、各部门的安全防范。
DS-8000系列命名规则主要性能与功能压缩处理●压缩代码具有自主知识产权，压缩比高，清晰度好，编码性能稳定可靠；●独立硬件压缩，DSP功耗低，更适合长时间稳定运行；●每路视频参数独立可调；●可动态调整编码参数；●支持定码率、变码率、变帧率；●帧结构可选；●可设定视频图像质量，也可设定视频图像的压缩码流，以获得满意的回放的图像质量和码流大小；●视频和音频信号压缩后生成复合码流，也可生成单一H.264视频流；●复合码流回放时视频和音频保持同步；●支持双码流技术；●支持JPEG标准的D1或CIF格式图片压缩、存储、网络传输；●支持水印（WaterMark）技术，防止图像被修改，保证录像资料真实有效。
本地录像●一台设备最多可支持八个硬盘的连接，每个硬盘的容量可达2000GB；●录像模式：定时录像、手动录像、移动侦测录像、报警录像、命令触发录像、移动侦测录像&报警录像、移动侦测录像| 报警录像；●文件切换时不丢帧；●硬盘文件系统为FAT32，与Windows文件系统一致；●硬盘上文件可以选择循环记录和非循环记录；●文件记录无碎片，系统可长时间保持稳定运行；●硬盘内录像资料不可被删除；●本地硬盘SMART支持；●非工作硬盘休眠机制；●通过USB设备、IDE CDRW、SATA设备进行文件备份或本地码流剪辑；●可外接盘库等第三方存储设备。
本地监控●音视频实时预览、画面分割、手动切换与自动轮巡；●OSD叠加，时间、位置及格式可调，通道名叠加，叠加位置可调；●本地监视器通道录像状态、报警状态显示；●多区域遮盖处理，遮盖区域的大小及位置可设置；●镜头遮挡报警处理，遮挡报警区域的大小、位置可调，灵敏度可选；●多级别、多区域的移动侦测处理；●视频丢失报警；●非法访问、IP冲突、网线断等异常事件报警；●报警输入/输出的布防与撤防、报警联动；●本地监视器上的多路回放，支持快放、慢放、暂停、单帧等回放模式，按时间回放时定位准确；●PTZ控制，支持众多解码器类型，支持预置点、巡航、轨迹的设置与调用；●多种操作方式：前面板按键操作、遥控器操作、RS-485键盘操作（设备级联）、网络键盘操作；●本地日志（支持操作、报警、异常类型）记录、查询及上传；●用户权限定制。
海康威视二代IP视频门禁系统产品介绍说明书
REAL SECURITY, REALLY CONVENIENTSECOND GENERATION IP VIDEO INTERCOM SYSTEMWITH HIKVISION AS YOUR PARTNER,YOU WILL STAND ON A SOLID FOUNDATION.Hikvision is a world leading provider of security products and solutions. Featuring an extensive and highly skilled R&D workforce, Hikvision manufactures a full suite of comprehensive products and solutions for a broad range of vertical markets. In addition to the security industry, Hikvision extends its reach to smart home tech, industrial automation, and automotive electronics industries to achieve its long-term vision. Hikvision products also provide powerful business intelligence for end users, which can enable more efficient operations and greater commercial success. The outstanding capabilities and performance of Hikvision in the security and video surveillance industries have been recognized by leading analyst firms and global awards.INDUSTRY PIONEERHikvision IP Series Video Intercom enjoys the largest global market share in the market, with more than 10,000,000 devices are being used worldwide. With a R & D team of more than 1,000 engineers, we are making continuous efforts to deliver more delicate products for our customers.EXCELLENT IMAGE QUALITY• 2 MP Fisheye camera with WDR and excellent nightvisionEASY TO USE• Convenient control via mobile app• Gate access control and elevator control for apartments• Driveway access control and door control for villas• Abundant functions for any scenario: PIN / duresspassword / message / do not disturb mode / multipleringtone options / and moreFLEXIBLE COMBINATIONS• Readily expandable with various modules• Various installation frames to better fit in with anyenvironmentELEGANT & USEFUL DESIGNS• Elegeant designs• Reddot award winning indoor stationCCTV INTEGRATION• Management from the all-in-one client• Video recording to DVR / NVR• View IP camera feed from indoor stationsHIGHLIGHTSOF THE IP VIDEO INTERCOM SYSTEMMODULAR DOOR STATIONMain Module Indicator Module Card Reader Module Main unit without button Display Module Touch & Display ModuleNametag Module Nametag module Modular Outdoor Station (Customizable)Modular Outdoor Station with Stainless steel (Customized )Keypad Module Keypad module INFO Module Main unitStandard PoE Backlight function Supports 16 Languages Extensive Modularity Angle and WDR Bigger Nametag Control Sleek Designs Hikvision’s modular intercom products excel at convenient installation and flexible expansion capabilities. The complete package features a main module with several extension modules ranging from the traditional nametag and keypad module to card readers and indicator modules, providing an abundance of functionality to customers.2-Wire Version (selected models)Stainless Steel 304material)INDOOR STATIONUltra Series Indoor Station7-inchUltra Series Indoor Station10-inch Pro Series Indoor Station7-inch32 GB SD CardLink with Alarm SensorsTouch Screenwith 1024 * 600 Resolution3rd Party Apps (only Androidmodels)Standard PoEUser-friendly InterfaceHikvision’s new all-in-one indoor station, a tablet device that can converge and controlsecurity systems. With simple slides and taps, it helps monitor and manage intercom. Alarm,access control and video security systems., with dashboards for all-in-one management,easy operations on touch screen and flexible access to third-party apps, this all-in-one indoorstation brings convenience and security in one place.2-Wire Version(selected models)Ultra series android tablet7 inchUltra series android tablet10 inchPro series indoor station7 inchApartmentUltra Series Indoor Station (7-inch)• IPS Touch screen• Live view for IP camera • Automatic image capture for missed call • Standard PoE Apartment Ultra series android tablet 10 inch • 10-inch IPS touch screen • Android version 10• Standard PoE • Built-in Hik-connect for all-in-one management • Easy integration with Android application • Wi-Fi supportedSide Entrance Main Module + Card Reader + Keypad • Fisheye camera • Night vision • Unlock door by password or card • Record video to CCTV system • One touch call Mobile App and indoor stations Elevator Master Elevator Controller Control up to 128 floors Main Entrance Network CameraMain Entrance Main Module + Nametag • Fisheye camera • Night vision • Record vide to CCTV system • One touch call Mobile App and indoor stations Main Entrance Secure Module (optional)• communicates with main door unit and electronic lock • keep door closed even when main module is damaged • supports tampering alarmAPARTMENT SOLUTIONThe apartment solution supports up to an amazing 500 indoor stations, with communication available among all of them. Multiple door stations can be installed for one building and residents can unlock them using card or password. Integration with an elevator control system makes the entire system even more secure. Hikvision’s IP Video Intercom Apartment Solution is a top choice for intercom and security system in buildings.System Capacity16 Modular Door Stations + 500 Indoor StationsKitchenUltra Series Indoor Station (7-inch) Living RoomAll-in-one indoor station (10-inch)Living RoomNetwork Video Recorder• Records video from all camerasand door stations• Triggered by event such asaccess control or motion• HDMI output to TVPerimeterNetwork CameraDoorDoor Main Module + Card Reader• Fisheye camera• Night vision•Unlock door by card• Record video to CCTV system• One touch call Mobile App and indoorstationsMain EntranceSecure Module (optional)• Communicates with maindoor unit and electroniclock• Keep door closed even whenmain module is damaged• Supports tampering alarmVILLA SOLUTIONThe villa solution provides thoughtful, useful functions for every member of the home. Userscan call multiple indoor stations at the same time and unlock a door at any of the indoorstations. They can also receive all call information and unlock doors remotely and convenientlyusing the app on a mobile device.The fisheye camera on the door station renders images clearly both day and night. With therecord-to-NVR function, users can check on what’s happening at their doorstep. To makethis system even better, integrate it with Hikvision’s CCTV system, allowing indoor stations todisplay any IP camera installed around your house. Security and convenience come together inthis IP Video Intercom Villa Solution.System Capacity16 Modular Door Stations +1 Main Indoor Station +10 Indoor ExtensionsDS-KH6320Y-WTE2DS-KH6320Y-WTE2DS-KH6320Y-WTE2DS-KAD706YDS-KD8003Y-IME2DS-KAW60-2NTUP2 wirePower lineHIK-CONNECT• Cruise through daily operations with the mobile Hik-Connect App• Talk to visitors, receive calls, play back videos, & unlock doorsremotely from anywhere, at any time2-Way Audio Live-StreamingLive view streamingCall History& EventsRelay controlScan and Downloadthe Hik-Connect AppPro series modular door stationDS-KD8003-IME1(B)Main Unit2 MP fisheye camera IR supplementIP6512V DC or standard PoE Power supply for locksDS-KD-BK Blank ModuleIP65DS-KD-DIS Display Module 3.5-inch LCDIP65Backlight functionDS-KD-KP/S Keypad Module Stainless steel IP65, IK07Backlight functionBind spot designDS-KD-EEM Card Reader Module125 KHz IP65Backlight functionDS-KD8003-IME1(B)/S Main Unit Stainless steel IR supplementIP6512VDC or Standard PoE Power supply for locksDS-KD-TDMTouch Screen Display ModuleIP65, IK083-in-1 module In-screen card reader Self-defined modesDS-KD-KP Keypad ModuleIP65Backlight function Blind spot designDS-KD-MMIFARE 1 Card Reader Module13.56 MHz IP65Backlight functionDS-KD-KK Nametag Module With 6 call buttonsIP65Backlight functionDS-KD-IN Indicator ModuleIP65Backlight functionNEWNEWUPDATEUPDATEUPDATEDS-KD-INFO Information module IP65125 KHz IP65Backlight functionDS-KD-KP/Black Keypad Module Black color versionIP 65,IK07Backlight function Bind spot designDS-KD8003-IME1(B)/NS Main unit without buttonstainless steel IR SupplementIP6512 VDC or standard POE Power supply for locksDS-KD-ACF2Dual Modules Accessories Used for flush mounting Aviation aluminumDS-KD-ACF3/S Three Module Accessories Used for flush mountingStainless steelDS-KD-ACF2/Black/EU Three Module Accessories Used for flush mountingStainless steel Black colorDS-KD-ACF2/S Dual Module Accessories Used for flush mountingStainless steelDS-KD-ACF2/Black/EU Dual Module Accessories Used for flush mountingStainless steel Black colorDS-KD-ACF3Three Modules Accessories Used for flush mounting Aviation aluminumDS-KD-ACW3Three Modules Accessories Used for surface mountingAviation aluminumDS-KD-ACW2 Dual Modules Accessories Used for surface mountingAviation aluminumInstallation Frames Surface mountInstallation Frames flush mountNEW NEW NEWDS-KD-ACW1Single Module Accessories Used for surface mountingAviation aluminumDS-KD-ACF1/S Single Module Accessories Used for flush mountingStainless steelDS-KD-ACF1/Black/EU Single Module Accessories Used for flush mountingStainless steel Black colorDS-KD-ACF1Single Module Accessories Used for flush mounting Aviation aluminumDS-KD-ACW2/S Dual Module Accessories Used for surface mountingStainless steelDS-KD-ACW3/S Three Module Accessories Used for surface mountingStainless steelDS-KD-ACW1/S SingleModule Accessories Used for surface mountingStainless steelIndoor StationUltra series indoor stationPro series indoor stationDS-KH9310-WTE1(B)7-inch IPS touch screen Android version 10Standard PoEBuilt-in Hik-connect for all-in-onemanagementEasy integration with Android applicationWi-Fi supportedDS-KH6320-TE17-inch LCD touch screenStandard PoE Mobile APP supportedDS-KH8350-TE17-inch LCD touch screenStandard PoE Mobile APP supportedDS-KH8350-WTE17-inch LCD touch screenStandard PoE Mobile APP supported Wi-Fi supportedDS-KH8520-WTE110-inch LCD touch screenStandard PoE Mobile APP supported Wi-Fi supportedDS-KH9510-WTE1(B)10-inch IPS touch screen Android version 10Standard PoEBuilt-in Hik-connect for all-in-onemanagementEasy integration with Android applicationWi-Fi supportedDS-KH6320-WTE17-inch LCD touch screenStandard PoE Mobile APP supported Wi-Fi supportedDS-KH6350-WTE17-inch LCD touch screenStandard PoE Mobile APP supportedWi-Fi supportedNEWNEWNEWPro Series 2 Wire modular door stationDS-KD8003Y-IME2/S Main Unit Stainless steel IR supplementIP65Power supply for locks 2-Wire InterfaceDS-KAD706Y-SAggregation Distributor6 Two-Wire Interface for connectionDin rail mounting, 24VDCDS-KAD706YDistributor6 Two-Wire Interface for connection andpower supplySupport up to 15 level cascadingDin rail mounting, 24VDCDS-KD8003Y-IME2/NS Main Unit Stainless steel No bell button IR supplementIP65Power supply for locks 2-Wire InterfaceDS-KH6320Y-WTE27-inch LCD touch screen2-Wire Interface Mobile APP supported Wi-Fi supportedDS-KAW60-2NPower AdapterPower supply for DS-KAD706 & DS-KAD706-SOutput: 24 VDC, 60W Din rail mountingUpdated 2-Wires SeriesPlease note: the updated Intercom solution (Y-Models) can only operate in combination with new Y-Model power distributor.DS-KD8003Y-IME2 Main Unit2 MP fisheye camera IR supplementIP65Power supply for locks2-Wire InterfaceUPDATEUPDATEUPDATEUPDATEUPDATEDS-K7P06Exit buttonOpen electric locks by pushing buttonstainless steel panel, metal button, metal bottom case Current Rating: 3A@36VDC Max Output Contact: NO/NC/COM ContactDS-KABH6320-TTable bracketfor KH6320/8520 series indoorstationDS-KA01-ZX-21Modular Demo Case Indoor Stations DS-KH9310-WTE1(B) DS-KH6350-WTE1 Modular door station DS-KD8003-IME1(B)/SDS-KD-TDM DS-KD-KP/S KD-ACF3/S Separate modules DS-KD8003-IME1(B)DS-KD-KP DS-KD-IN DS-KD-M DS-KD-KK DS-KD-DIS DS-KD-KK/S Installation frames DS-KD-ACW1/ACW2/ACF3DS-KABH8350-T Table bracketfor KH8350 series indoorstationDS-K2M061Secure moduleCommunicates with Door station via RS-485 to execute the commands from the terminal including open door, close door,normally.Collects the door signal, the exit button signal and the tamper-proof signal and send them to the door station.Supports tampering alarm Supports indicators to show thecommunication status.DS-KABH9510-TTable bracketfor KH9510 series indoor stationAdditional AccessoryNEWTRANSMISSION DISTANCETransmission distance when using PoE door station solution with shielded CAT5/CAT6/CAT7 cable is 100 meter between network switch and each component. For 2-Wire system please refer to following tables:Dual Modules Flush MountingThree Modules Flush MountingDual Modules Surface MountingThree Modules Surface MountingDIMENSIONAL REFERENCE FOR INSTALLATIONSingle Module Flush MountingSingle Module Surface MountingREMARKSREAL SECURITY, REALLY CONVENIENT SECOND GENERATIONIP VIDEO INTERCOM SYSTEMHikvision HeadquartersNo.555 Qianmo Road 310052 Hangzhou ChinaT +86 571 88075998*******************Hikvision EuropeDirk Storklaan 32132 PX Hoofddorp The Netherlands T +31 23 5542770*********************Hikvision France6 rue Paul Cézanne,93360 Neuilly-Plaisance FranceT +33 (0)1 85330450*********************Hikvision ItalyVia Abruzzo 12Z.I. San Giacomo31029 Vittorio Veneto TV ItalyT +39 0438 6902*********************Hikvision PolandThe Park, Office Building A Krakowiaków 5002-255 Warsaw, Poland T +48 22 4600150*********************Hikvision SpainCalle de Almazara 928760 Tres Cantos Madrid, Spain T +34 91 7371655*********************Hikvision CzechVyskočilova 1410/1140 00 Praha 4 – Michle Czech Republic T +42 29 6182640*********************Hikvision GermanyFlughafenstr. 2163263 Neu-Isenburg Zeppelinheim, Germany T +49 69 401507290************************08/2022@HikvisionEurope @HikvisionEurope HIKVISION EuropeCheck out our selection tool。
海康产品体系介绍
7系列经济型 8系列通用型 9系列项目型
7系列经济型 8系列通用型 9系列项目型
61系列 65系列 66系列 67系列
编码卡 解码卡
多样化的编码产品形态
9系列(2U)
DVR/NVR/ HDVR
8系列(2U)
DVR/NVR/ HDVR
7系列(1.5U)
DVR/NVR/ HDVR
7系列(1U)
DVR/NVR/ HDVR
民用安防市场
小微 企业
家庭
个人
民用安防产品分类
民用安防产品
网络摄像机
硬盘录像机
视频盒子
视频7
C1
D1
R1
PC客户端
C2
N1
手机APP
C3
C4
多样化的民用安防产品形态
C1
C2
C3
C4
D1/N1
R1
视频7
“视频7”是海康威视针对家庭和小微企业用户推出的一款视频服务类门户
实时视频点播
历史录像查看
事件消息提醒
推出时间 2004 2006 2010 2002 2009 2004 2006 2002 2009 2007 2010 2011 2011 2012
软件产品体系
系列型号 iVMS-4000/4200
iVMS-4100 iVMS-4500 iVMS-6000 iVMS-5000 iVMS-7000/7200 iVMS-8100 iVMS-8200/9500 iVMS-8300 iVMS-8400 iVMS-8600 iVMS-8700 iVMS-8800
前端产品分类
前端产品
模拟摄像机
网络摄像机
球机
一体机
智能交通 摄像机
海康威视摄像机宣传
智能分析功能
海康威视摄像机具备多种智能分 析功能，如人脸识别、行为分析、 异常检测等，可自动识别异常情 况，及时发出警报，提高治安响
应速度。
城市监控网络
海康威视摄像机在城市各个角落 部署，构建起全方位、无死角的 监控网络，有效预防和打击犯罪
行为，提升城市居民安全感。
智慧交通
交通监控与管理
海康威视摄像机在智慧交通领域应用广泛，通过实时监控道路交 通状况，有效缓解交通拥堵，提高道路通行效率。
智能识别技术
人脸识别
海康威视摄像机支持人脸 识别功能，能够快速准确 地识别出人员身份，提高 安全防范能力。
行为识别
通过智能识别技术，海康 威视摄像机能够自动识别 出异常行为，如入侵、徘 徊等，及时发出警报。
车辆识别
海康威视摄像机具备车辆 识别功能，能够自动识别 出车牌号码、车型等信息， 方便管理。
应用拓展
智能交通
海康威视将积极拓展在智能交通领域的应用，提供高清、智能的 交通监控解决方案，助力城市交通管理。
智能安防
借助人脸识别、行为识别等技术，海康威视摄像机将广泛应用于 社区、校园等场所，提升安防水平。
智慧城市
海康威视将结合物联网、云计算等技术，为智慧城市建设提供全 面的监控解决方案，助力城市管理。
智能门禁系统
海康威视摄像机可配合智能门禁系统使用，实现 校园出入管理、考勤管理等功能，提高校园管理 效率。
远程教育支持
海康威视摄像机还可用于远程教育，通过高清视 频传输，让师生远程交流、在线授课成为可能。
智慧工地
工地安全监控
01
海康威视摄像机在智慧工地中主要用于工地安全监控，实时监
测施工现场的安全状况。
具备多种存储安全措施，如数据加密、 备份等，确保视频资料的安全性。
海康威视体温检测解决方案产品介绍说明书
HikvisionTemperature Screening Solution Flexible Product Choice for a Multitude of ScenariosHikvision Temperature Screening Solution, with multiple product types andwide range of applications, is designed for the detection of skin-surfacetemperatures so as to achieve rapid and safe preliminary screening inpublic areas with high efficiency in a multitude of scenarios.ThermographicCamerasMinMoe TerminalsMetal Detector DoorDeepinMind NVRs36.5˚ C36.7˚ C36.3˚ CSolution OverviewThermographic Handheld Camera Thermographic Bullet Camera OPERATION TIPS· Install the devices in a windless indoor environment · Set up a specific temperature measurement zone· Double-check with a thermometer upon detection of elevated skin-surface temperaturesGroup Screeningwith High EfficiencyTemperature Screening on PatrolTemperature Screening & Mask DetectionAnytime, Anywhere,Just One ClickGroupTemperature ScreeningIntuitive DemonstrationTemperature Screening with Access ControlDoor Control Wall-mountedto control the doorSupports simultaneous temperature screening of multiple people, greatly enhancing efficiencystatusTemperature Screening with Fast DeploymentThermographic Bullet/Turret CameraMetal Detector DoorThermographic Handheld CameraProduct ShowcaseDS-2TD2617B-3/6PADS-2TD1217B-3/6PAThermographic Bullet CameraThermographic Turret Camera· Thermal resolution: 160 × 120· Thermal lens: 3 mm / 6 mm · Optical: 2688 × 1520· Optical lens: 4 mm / 8 mm · Bi-spectrum image fusion· Accuracy: ±0.5°C (±0.3°C with blackbody)· Measurement range: 30-45°C · Supports audio alarms· Working temperature: 10-35°C· AI human detection, false alarms reduction · Simultaneous temperature screening for multiple people· Thermal resolution: 160 × 120· Thermal lens: 3 mm / 6 mm · Optical: 2688 × 1520· Optical lens: 4 mm / 8 mm · Bi-spectrum image fusion· Accuracy: ±0.5°C (±0.3°C with blackbody)· Measurement range: 30-45°C · Supports audio alarms· Working temperature: 10-35°C· AI human detection, false alarms reduction · Simultaneous temperature screening for multiple people*Hikvision’s Temperature Screening Thermographic Cameras are designed for the detection of skin-surface temperatures so as to achieve rapid preliminary screening in public areas. Actual core body temperatures should be further confirmed using clinical measurement devices. Under any circumstances, it is highly recommended to use Hikvision’s Thermographic Cameras in accordance with local laws and regulations.DS-2TP21B-6AVF/WThermographic Handheld Camera· Thermal resolution: 160 × 120· Optical resolution: 640 × 480· Measurement range: 30-45°C · Touch screen · Accuracy: ±0.5°C· Bi-spectrum image fusion · Supports Wi-Fi· Supports audio alarms· Automatic screenshots & uploadingDS-2TE127-G4ABlackbody Calibrator· Temperature resolution: 0.1°C · Accuracy: ±0.1°C· Temperature stability: ±0.1°C/h · Effective emissivity: 0.97±0.02· Operating temperature: 0-30°CDS-2TD2636B-15/P DS-2TD2636B-13/P DS-2TD2637B-10/PThermographic Bullet Camera· Thermal resolution: 384 × 288· Thermal lens: 15 mm / 13 mm / 10 mm · Optical: 2688 × 1520· Optical lens: 6 mm / 6 mm / 4 mm· Accuracy: ±0.5°C (±0.3°C with blackbody)· Measurement range: 30-45°C · Working temperature: 10-35°C· AI human detection, false alarms reduction · Simultaneous temperature screening for multiple peopleThermographic CamerasDS-D5024FN (23.8”) DS-D5032QE (31.5”)DS-D5024FC (23.8”)DS-D5043QE(43”)DS-5032FC-A (31.5”)DS-D5043UC(43”)· 1080p, HDMI/VGA input, view angle: 178°/178°, plastic casing, VESA, base bracket included, 24/7 operation · 1080p, HDMI/VGA input, with built-in speaker, plastic casing, VESA, base bracket included, 24/7 operationMonitors HikCentral Professional· Flexible, scalable, reliableand powerful central surveillance system· Supports live view, play back, access control, alarm management, personnel identification, temperature data storage, abnormal temperature trend analysis, etc.· The customized HikCentral Professional version supports thermographic products, DeepinMind NVRs and face recognition terminalsiDS-7716(/32)NXI-I4/(16P)/X(B)(T)iDS-9616(/32)NXI-I8/X(B)(T)· Up to 16 channels of face picture comparison· 32-library capacity with up to 100,000 face pictures in total DS-3E0105P-E(B)DS-3E0109P-E(C)PoE Switches· L2, Unmanaged, 10/100M RJ45 PoE ports, 1 10/100M RJ45 uplink port, 802.3af/at, PoE power budget. 300 m long distance transmission, 6 KV surge protectionDeepinMind NVRssMinMoe TerminalISD-SMG318LT-F· 18 independent detection zones · 7-inch LCD touch screen· Thermal resolution: 160 × 120· Temperature measurement accuracy: ±0.5°C · Temperature measurement range: 30-45°C · Bi-spectrum image fusion· In accordance with the international safety standard, friendly to pregnant woman, people with cardiac pacemaker, etc.Metal Detector DoorDS-KC001Monitoring TabletDS-K1T671TM-3XFMinMoe Wall-Mounting Touch-free Temperature Screening Terminal· LCD touch screen· Thermographic technology, temperature range: 30-45°C , accuracy: ±0.5°C · Temperature screening of forehead· Authentification distance: 0.5 m – 1.5 m, height: 1.2 m – 1.9 m· Temperature screening with visional results and audio prompt· 7“ Touch-Screen Android Tablet · Display resolution: 1024 × 600· Wi-Fi 802.11b/g/n· Remote temperature screening & records checking, real-time preview· Centralized data management, max to 100,000 records· Abnormal temperature alarm· Remote access control & video intercom。
海康威视视频监控显示产品介绍
支持超高清分辨率接入
智能领航 数据未来
支持多种分辨率
DVI双链路支持 4088*4088 超高清分辨率
支持虚拟LED
智能领航 数据未来
支持虚拟LED，LED字体、大小、背景颜色及位置可调。
热 烈 欢 迎 X欢X欢市迎迎领张领导导X莅莅X临临、指指李导导X X 等 领 导 莅 临 指 导
支持解码功能
输出板：SDI ( 8/16） 、BNC ( 32） 、 HDMI ( 8/4） 、DVI ( 8/4） 、VGA ( 8/4）
模拟、SDI板卡均自带485控制接口，无需增加码分板
主机箱功能扩展
智能领航 数据未来
• 全型号机箱配备LED屏 • 实时显示机箱运行状态 • 电源插座后置
主推产品-B20
主推产品-B20
智能领航 数据未来
DS-B20-S14-(D)A DS-B20-S10-(D)A DS-B20-S07-A DS-B20-S05-A DS-B20-S03-A
14、10、7、5、3槽位可选，14、10可搭配双主控
板卡介绍
智能领航 数据未来
输入板：SDI（16/8）、BNC （32） 、高线（32） 、HDMI （8） 、DVI ( 8） 、VGA ( 8/4） 、 光纤（16） 、YPbPr （8）
500点位以内推荐： DELL PowerEdge R720四核 内存16G
信息发布屏
智能领航 数据未来
屏幕大小：19、22、32、42、46、55、65、70、84、98 面板类型：横屏、竖屏 安装方式：落地式、壁挂式
交互形式：C/S架构、B/S架构、触摸交互（可定制） 操作系统：安卓、windows、嵌入式
智能领航 数据未来
海康威视4MP网络红外速度球机摄像头产品介绍说明书
DS-2DE4415IW-DE(T5)4MP 15× IR Network Speed DomeHikvision DS-2DE4415IW-DE(T5) 4MP 15× Network IR Speed Dome adopts 1/2.8" progressive scan CMOS chip. With the 15× optical zoom lens, the camera offers more details over expansive areas.This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, roads, railways, airports, squares, parks, scenic spots, and venues, etc. Empowered by deep learning algorithms, Hikvision AcuSense technology brings human and vehicle targets classification alarms to front- and back-end devices. The system focuses on human and vehicle targets, vastly improving alarm efficiency and effectiveness.⏹Focuses on human and vehicle targets classification based on deep learning⏹Support face capture. Up to 5 faces captured at the same time⏹1/2.8" Progressive Scan CMOS⏹High quality imaging with 4 MP resolution⏹Excellent low-light performance withpowered-by-DarkFighter technology⏹15× optical zoom and 16× digital zoom provide close up views over expansive areas⏹Expansive night view with up to 100 m IR distance⏹Support H.265+/H.265 video compression⏹DORIThe DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or objects within its field of view. It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015.DORI Detect Observe Recognize IdentifyDefinition25 px/m63 px/m125 px/m250 px/m Distance(Tele)1320.0 m (4330.7 ft)523.8 m (1718.5 ft)264.0 m (866.1 ft)132.0 m (433.1 ft)⏹SpecificationCameraImage Sensor 1/2.8" progressive scan CMOSMin. Illumination Color: 0.005Lux @ (F1.6, AGC ON); B/W: 0.001Lux @ (F1.6, AGC ON), 0 Lux with IR Shutter Speed 1/1 s to 1/30000 sSlow Shutter YesDay & Night IR cut filterZoom 15x optical, 16x digitalMax. Resolution 2560 × 1440LensFocus Auto, semi-auto, manualFocal Length 5 mm to 75 mmZoom Speed Approx. 2.3 sFOV Horizontal field of view: 55° to 4° (wide-tele), Vertical field of view: 33° to 2.2° (wide-tele), Diagonal field of view: 61.5° to 4.6° (wide-tele)Aperture Max. F1.6IlluminatorSupplement Light Type IRSupplement Light Range IR Distance: up to 100 mPTZMovement Range (Pan) 360°Movement Range (Tilt) -15° to 90° (auto flip)Pan Speed Pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s Tilt Speed Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s Proportional Pan YesPresets 300Patrol Scan 8 patrols, up to 32 presets for each patrolPattern Scan 4 pattern scansPower-off Memory YesPark Action Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan3D Positioning Yes PTZ Status Display Yes Preset Freezing YesScheduled Task Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux outputVideoMain Stream 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)Sub-Stream 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)Third Stream 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)Video Compression Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEGThird stream: H.265/H.264/MJPEGVideo Bit Rate 32 kbps to 16384 kbpsH.264 Type Baseline profile/Main profile/High profileH.265 Type Main profileScalable Video Coding (SVC) H.264 and H.265 encodingRegion of Interest (ROI) 8 fixed regions for each streamAudioAudio Compression G.711/G.722.1/G.726/MP2L2/PCMAudio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2) Audio Sampling Rate 8 kHz/16 kHz/32 kHz/48 kHzEnvironment Noise Filtering YesNetworkNetwork Storage NAS (NFS, SMB/CIFS), auto network replenishment (ANR)Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, Websocket, WebsocketsAPI Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUPSimultaneous Live View Up to 20 channelsUser/Host Up to 32 users, 3 user levels: administrator, operator, and user Smooth Streaming YesSecurity Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)Client iVMS-4200, HikCentral Pro, Hik-Connect Web Browser Chrome 57.0+, Firefox 52.0+, Safari 11+, IE11 ImageImage Parameters Switch YesDay/Night Switch Day, Night, Auto, ScheduleImage Enhancement BLC, HLC, 3D DNRWide Dynamic Range (WDR) 120 dBDefog Digital defogImage Stabilization EISRegional Exposure YesRegional Focus YesImage Settings Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browserPrivacy Mask 24 programmable polygon privacy masks, mask color or mosaic configurable SNR > 52 dBInterfaceEthernet Interface 1 RJ45 10M/100M self-adaptive Ethernet portOn-board Storage Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB Alarm 1 input, 1 outputAudio 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%;1 output (line out), line level, output impedance: 600 ΩReset YesEventBasic Event Motion detection, video tampering alarm, exception, alarm input and outputSmart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detectionAlarm Linkage Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)Deep Learning FunctionFace Capture Detects up to 5 faces simultaneously.Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the facePerimeter Protection Line crossing, intrusion, region entrance, region exitingSupport alarm triggering by specified target types (human and vehicle)GeneralDemist YesPower 12 VDC, max. 18 W, including max. 1.6 W for heater and 9 W for IR; PoE (802.3at)Operating Condition -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) Material ADC12Dimension Ø 164.5 mm × 290 mm (Ø 6.48" × 11.42")Weight Approx. 2 kg (4.41 lb)ApprovalEMC FCC SDoC (47 CFR Part 15, Subpart B);CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);RCM (AS/NZS CISPR 32: 2015);IC VoC (ICES-003: Issue 6, 2019);KC (KN 32: 2015, KN 35: 2015)Safety UL (UL 62368-1);CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2017);BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);LOA (SANS IEC60950-1)Environment CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)ProtectionIP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage transient protection⏹Typical ApplicationHikvision products are classified into three levels according to their anti-corrosion performance. Refer to the following description to choose for your using environment.This model has NO SPECIFIC PROTECTION.LevelDescriptionTop-level protectionHikvision products at this level are equipped for use in areas where professional anti-corrosion protection is a must. Typical application scenarios include coastlines, docks, chemical plants, and more.Moderate protectionHikvision products at this level are equipped for use in areas with moderate anti-corrosion demands. Typical application scenarios include coastal areas about 2 kilometers (1.24 miles) away from coastlines, as well as areas affected by acid rain.No specific protectionHikvision products at this level are equipped for use in areas where no specific anti-corrosion protection is needed.⏹Dimension⏹Available Model DS-2DE4415IW-DE(T5)⏹Accessory⏹IncludedDS-1618ZJ⏹OptionalDS-1602ZJ DS-1673ZJ DS-1671ZJ-SDM9 DS-1604ZJ-corner DS-1604ZJDS-1604ZJ-pole DS-1682ZJ DS-1604ZJ-BOX-CORNERDS-1681ZJ DS-1661ZJDS-1667ZJ DS-1005KI DS-1619ZJ DS-1660ZJ DS-1662ZJDS-1663ZJ DS-1604ZJ-BOX-POLEDS-1604ZJ-box DS-1100KI。
海康威视PanoVu系列网络摄像头产品介绍说明书
Panoramic Solutions for Vast Coverage Applications Hikvision PanoVu™ Series Network CamerasEffectively monitoring large areas such as public plazas, arenas, stadiums, parking lots, and busy traffic intersections poses various challenges. For large coverage areas, security personnel need to see more with just one camera — not just a panoramic image, but zoomed-in, detailed views as well.Traditionally, coverage for 360-degree panoramic video application required the installation of four cameras or a fisheye camera. Now, one Hikvision PanoVu flexible camera can replace four standard cameras. In addition, it provides ease of installation and costs savings using a single mounting with one Ethernet cable.PanoVu: One Camera forPanoramic Wide Area Coverage • Four camera setup• Complex installation & configuration • Single camera with four channels •Motorized zoom for details •Easy installation and configuration •Save on installation costs •All-in-one solution BEFORE WITH HIKVISION PANOVUWhile fisheye cameras can cover 360 degrees without dead zones, it is difficult to see details at their edge. Hikvision’s PanoVu panoramic solution provides users with a comprehensive 180- or 360-degree coverage, and forensic details.Hikvision designed the PanoVu 180-degree and the 360-degree Panoramic with PTZ Series all-in-onecameras to capture excellent panorama views and close-up details. Multiple sensors capture panoramicimages rendering 180-degree or 360-degree panoramic imaging with real-time ultra-HD resolution. Theintegrated design and high-speed pan-tilt-zoom action grants the user swift positioning over expansiveareas with the power to bring sharp details into focus. At the same time, the PanoVu series cameras utilizeHikvision’s ultra-low light DarkFighter technology, for color images in poorly lit environments.The PanoVu product family features high definition panoramic view cameras up to 32 MP . It also providessupplemental IR and panoramic lighting for clear images in extremely dark environments, and anamazing wide-tilt angle. In addition, because panoramic cameras demand more bandwidth and storagethan conventional cameras, Hikvision designed the PanoVu cameras to use H.265+ video compressiontechnology, for efficient video transmission and storage.The PanoVu Mini Series are compact size cameras with budget-friendly pricing, combined with ease ofinstallation and use. The Mini series includes market-proven features of other PanoVu lines, including highedge definition, low image distortion, and powerful PTZ functions. They are used in a wide range of indoorand outdoor applications.• Low resolution• Less detail in the edge• Can’t zoom in for details • Higher resolution • Detail in the edge • Image stitching76mm (3 inch)183mm(7.2 inch)243mm (9.5 inch)(10.6 inch)Indoor PanoVu miniOutdoor PanoVu miniNew PanoVu Additions:PanoVu Dual-Directional cameras are new to the Hikvision PanoVu productfamily. They feature two multi-megapixel cameras in a compact housingwith budget-friendly pricing. One Hikvision dual-directional camera canreplace two standard cameras. Applications include coverage of a hallwayor retail application, such as monitoring POS terminals, or use of one lens tomonitor the entrance and the other for the exit.Hikvision’s PanoVu panoramic multi-sensor cameras are easy to install, require a single installation using one Ethernet cable, and can provide coverage equal to four standard cameras.Cameras are available in several options, including 180-degree or 360-degree fields of view in 8 MP, or 32 MP resolution choices, and in flexible, mini, and dual-directional series.PanoVu FamilyPanoramic 180°/360°Image Stitched Flexible PanoVu MiniDual-Directional 161mm(6.5 inch)67mm(2.7 inch)Panoramic 180°/360° IR• Features four sensors running high frame rate• Full 180-degree view stitched together• Up to 32 MP resolution, popular uses are parking lots, entrances, or other “no dead zone” applications • 40x optical zoom PTZ for large PanoVuFlexible Series IR• Four individual sensors with a motorized 2.8 mm - 12 mm auto focus lens• Track design that allows four individual sensor gimbals to be independently placed• Popular uses include hallway intersections, providing a 270-degree view at abuilding corner, or any application that requires 360-degree coverage• Recess mount and smaller form factor are availablePanoVu Mini IR• Three sensors running high frame rate and one PTZ for detailed views • Compact sizes and budget-friendly pricing• Suitable for retail, office, and school applicationsDual-Directional Series IR• Dual-lens design to capture two separate wide angle views• Suitable for hallways, parking lots, and retail applicationsWith an all-in-one design, a single product enables front-end splicing, panoramic views, and precise details. Moreover, it delivers both panorama and every detail through full shot (180-degree or 360-degree) and close-up views (no additional server needed).Our easy-to-install dome camera saves time using one cable and a power supply. Characterized by flexibility and ease of operation, it provides a full range of options in the user interface such as ultra-high resolution panoramic views. It also captures the details dynamically in real-time and zoom in by simply clicking on an image.Innovative Technology,Simple Installation+==+===Combining several built-in horizontal cameras with PTZ, one PanoVu camera captures 360-degree or 180-degree panoramic views and detailed, high resolution close-up images with up to 36x optical zoom.Hikvision employs front-end image stitching technology in its unique, all-in-one PanoVu Series Cameras to deliver 180- and 360-degree panoramas without additional servers. The rendered panorama has no visible edges between the stitched images. Images maintain brightness and white balance, perfectly blended for a great user experience—so no graphical flaws hinder detailed imaging in the video.Certain Hikvision PanoVu camera models use DarkFighter ultra-low light technology to render color images in low light environments down to 0.005 lux, in 180- or 360-degree panoramic mode or PTZ.Supplemental lighting significantly enhances image quality in extremely dark environments. Traditional panoramic cameras have difficulty merging supplemental light with lens angle. Hikvision’s advanced PanoVu cameras overcome this challenge using wide-angle supplemental lighting to perfectly matching the lens angle and display vivid images.Panoramic Views and Detailed ImagesDarkFighter Ultra-Low Light Technology and Supplemental Lighting360 OVERVIEW + PTZPanoVu Series Cameras also feature Hikvision’s H.265+ video compression technology, reducing bandwidth and storage requirements by an average of 70 percent or more while maintaining consistent resolution, frame rates, and detail. It’s an efficient way to manage super high resolution video footage.With smart event and multi-target tracking algorithms, select PanoVu Cameras feature a wide range of smart functions in panoramic mode, including intrusion detection, line crossing detection, and region entrance and exit detection. Hikvision PanoVu cameras can send alarm signals linked to the PTZ for tracking, greatly improving security efficiency.Smart Codec – H.265+ Optimized CompressionSmart FeaturesWith intelligent and powerful features, the PanoVu Series Cameras can be used for vast coverage areas. The PanoVu Panoramic 180 or 360 series are ideal for monitoring large areas that typically would require multiple cameras such as airports, transit stations, gymnasiums, scenic ports, and public squares. Fixed lens cameras cover narrow fields of view with great details, but don’t take in the whole scene. Single-sensor fisheye cameras provide panoramic views at affordable prices, but are unable to get more detail at greater distances.Traditional multi-sensor panoramic cameras cover a wide field of view, but users need to manually arrange the images from different sensors in order to see a panorama. The overall user experience suffers from overlaps that duplicate images, gaps where coverage is missing, and tilted imaging that looks unrealistic to the human eye. Panoramic cameras with image stitching capability help to avoid dead zones and provide a panoramic full view of the scene. With the added PTZ, areas of interest can be focused and zoomed on to see important details.The PanoVu Flexible series cameras give you the ability to monitor from four independent views for up to 270-degrees of the scene. Without the need for multiple cameras, network connection requirements and installation costs are reduced. With zoom in capability and ability to monitor 270-degrees, this series is great for monitoring intersections, parking lots, lobbies, and building corners. ApplicationsCityGymAirport Squares Harbour Building Corner Intersection Parking LotLobbiesPanoVu Mini series feature a compact design that fits well in public areas and is cost-effective. This series works well for offices, classrooms, lobbies, and retail stores. The mini series provides a 270-degree view with fully adjustable settings to get just the view desired.The PanoVu Dual-Directional sensor series delivers two views from a single camera and fits perfectly for hallways, walkways, a wide range of businesses. It also supports monitoring of cashier stations for retailers of all sizes to monitor the POS terminal and the customer simultaneously.Retail StoresOfficesClassroomsCashier StationsHallway WalkwaySpecificationsPanoramic 180° SeriesDS-2CD6924F-IS8 MP (4×2 MP Stitched or Separate)Color: 0.007 @ ƒ/1.8B/W:0 with IRPanoramic 180°/360° with PTZ SeriesOutdoor 16MP 180° Panoramic withPTZ cameraPanoramic 180° SeriesDS-2PT5326IZ-DE DS-2PT3326IZ-DE38 MP (4×2 MP)8 MP (4×2 MP)Fixed Sensors: Color: 0.005 @ ƒ/1.6 PTZ: Color: 0.005 @ ƒ/1.6Fixed Sensors: Color: 0.05 @ ƒ/2.0 PTZ: Color: 0.05 @ ƒ/2.0Fixed: 4 mmPTZ: 5 to 50 mm (10x)PTZ: 2.8 to 12 mm (4x) 80.7°×3 / 43.5°128.5°×3 / 75.7°Flexible SeriesFlexible Series cont’dDS-2CD6D54G1-IZS DS-2CD6D54G1-ZS/RC16 MP (4×4 MP)16 MP (4×4 MP)Color: 0.0125 lux @ (F1.9, AGC ON); B/W: 0.0025 lux @ (F1.9, AGC ON) 0 lux with IR Color: 0.0125 lux @ (F1.9, AGC ON); B/W: 0.0025 lux @ (F1.9, AGC ON)Four 2.8 to 8 mm Four 2.8 to 8 mm49° to 100°, / 36.4° to 72°Dual-Directional SeriesHikvision USA Inc. 18639 Railroad Street City of Industry, CA 91748Hikvision Canada Inc.4848 Levy StreetSaint-Laurent, Quebec H4R 2P1Contact InformationToll-Free: +1 866-200-6690 (U.S. and Canada)Phone: +1 909-895-0400Email:***********************Connect with us:©2020 Hikvision USA Inc. and Hikvision Canada Inc. All rights reserved. Hikvision is a registered trademark of Hikvision Digital Technology Co., Ltd. in the US, Canada and other countries. All other trademarks, service marks, and product or service names are trademarks or registered trademarks of their respective owners. Product specifications and availability are subject to change without Notice.Disclaimer: Hikvision USA Inc. products depicted herein are not FDA approved medical devices and are not intended for use in the diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or prevention of disease. When configured correctly, the Hikvision products discussed herein can identify elevated human skin-surface temperature relative to a sample population. Hikvision’s Thermographic Cameras are designed for immediate detection and preliminary screening of elevated skin-surface temperature in high-traffic areas. When measuring core body temperature, please verify through the use of clinical measurement devices and/or by consulting a medical professional. Hikvision’s Thermographic Cameras must be used in accordance with local laws and regulations.100720HK。
海康威视DS-2DE2402IW-DE3 W 4MP 2× 网络红外 Wi-Fi PTZ 摄像头说明
Hikvision DS-2DE2402IW-DE3/W 4MP 2× Network IR Wi-Fi PTZ Camera adopts 1/2.8" progressive scan CMOS chip. With the 2× optical zoom lens, the camera offers more details in the indoor environments.This series of cameras feature a wide range of functions, including intrusion detection, line crossing detection, audio exception detection, motion detection, and video tampering detection, benefitting users with great improvement on security efficiency.Key Features•1/2.8" progressive scan CMOS•Up to 2560 × 1440 resolution•Min. illumination:Color: 0.05 Lux @(F2.0, AGC ON)B/W: 0.005 Lux @(F2.0, AGC ON)0 Lux with IR•2× optical zoom, 16× digital zoom •Digital WDR, 3D DNR, HLC, BLC, Smart IR •Up to 20 m IR distance•12 VDC &PoE (802.3af, class3) •Support Wi-Fi•Support H.265+/H.265•Built-in microphone with 1 audio input and 1audio outputCamera Module 4MP 2× Network IR PTZ Camera Image Sensor 1/2.8" progressive scan CMOSMin. Illumination Color: 0.05 Lux @(F2.0, AGC ON) B/W: 0.005 Lux @(F2.0, AGC ON) 0 Lux with IRWhite Balance Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/FluorescentLamp/Sodium LampAGC Auto/ManualShutter Time 1/1 s to 1/30,000 sDay & Night IR Cut FilterDigital Zoom 2×Privacy Mask 8 programmable privacy masksFocus Mode Auto/Semi-automatic/ManualDigital WDR YesLensFocal Length 2.8 mm to 6 mm, 2× optical zoomZoom Speed Approx. 2 s (optical lens, wide-tele)FOV Horizontal field of view: 96° to 46° (wide-tele) Vertical field of view: 51° to 26° (wide-tele) Diagonal field of view: 112° to 55° (wide-tele)Working Distance 10 mm to 1500 mm (wide-tele)Aperture Range F1.8 to F2.5IRIR Distance Up to 20 mIR Intensity Automatically adjusted, depending on the zoom ratioPTZMovement Range (Pan) 350°Pan Speed Configurable, from 0.1°/s to 60°/sPreset Speed: 60°/sMovement Range (Tilt) From 0° to 90°Tilt Speed Configurable, from 0.1°/s to 50°/sPreset Speed: 50°/sProportional Zoom YesPresets 300Patrol Scan 8 patrols, up to 32 presets for each patrolPower-off Memory YesPark Action Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan PTZ Position Display YesPreset Freezing YesScheduled Task Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/PanoramaScan/Dome Reboot/Dome Adjust/Aux OutputCompression StandardVideo Compression Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264/MJPEGThird Stream: H.265/H.264/MJPEGH.264 Type Baseline Profile/Main Profile/High Profile H.264+ YesH.265 Type Main ProfileH.265+ YesVideo Bitrate 32 Kbps to 16384 KbpsSmart FeatureBasic Event Detection Motion Detection, Video Tampering DetectionSmart Event Detection Intrusion Detection, Line Crossing Detection, Audio Exception DetectionROI encoding Main stream, sub-stream and third stream respectively support two fixed areas. ImageMax. Resolution 2560 × 1440Main Stream 50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)Sub-Stream 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)Third Stream 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) Image Enhancement HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional FocusSVC YesNetworkNetwork Storage Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NFS, SMB/CIFS), ANRAlarm Linkage Alarm actions, such as Memory Card Video Record, Trigger Recording, NotifySurveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.Protocols IPv4/IPv6, HTTP, HTTPS, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP,RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, BonjourAPI ONVIF (Profile S, Profile G, Profile T), ISAPI, SDKSimultaneous Live View Up to 20 channelsUser/Host Up to 32 users.3 levels: Administrator, Operator and UserSecurity Measures User authentication (ID and PW), Host authentication (MAC address); HTTPSencryption; IP address filteringClient iVMS-4200, iVMS-4500, iVMS-5200, Hik-ConnectWeb Browser IE 8 to 11, Chrome 31.0+, Firefox 30.0+, Edge 16.16299+Wi-Fi YesInterfaceAlarm Input 1-ch alarm inputAlarm Output 1-ch alarm outputAudio Input 1-ch audio inputAudio Output 1-ch audio outputNetwork Interface 1 RJ45 10 M/100 M Ethernet Interface;PoE (802.3af, class3)GeneralPower12 VDC, 0.75 A and PoE (802.3af), 36 to 57 VDC, 0.35 A, Class3Max.: 9 W, including max. 3W for IRWorking Environment Working Temperature: -10°C to 50°C (14°F to 122°F)Working Humidity: ≤ 90%Protection Level 4000V Lightning Protection, Surge Protection and Voltage Transient Protection Material ADC12 PC PC+ABS SUS304 POMDimensions Φ 125 mm × 136.7 mm (Φ 4.92" × 5.38")Weight Approx. 0.65 kg (1.43 lb)DORIThe DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or objects within its field of view.DORI Detect Observe Recognize Identify Definition 25 px/m 63 px/m 125 px/m 250 px/m Distance (Tele)120.0 m (393.7 ft)47.6 m (156.2 ft)24.0 m (78.7 ft)12.0 m (39.4 ft)Order ModelDS-2DE2402IW-DE3/W, 12 VDC & PoE (802.3af, class3)DimensionsΦ 125136.7Unit: mmAccessoryOptional:DS-1294ZJ Wall MountMSA-C1500IC12.0-18P-USMSA-C1500IC12.0-18P-GB MSA-C1500IC12.0-18P-JPPower adapterLAS60-57CN-RJ45 Hi-PoE midspanDS-1100KI Network KeyboardDS-1005KI USB Joy-stick05060020200228。
海康民用安防服务介绍(小卫士、视频7)
2013.3
海康威视民用安防服务 --
平台简介：
“视频7”是海康威视针对家庭和企业用户推出的一款视频服务类产品。 通过“视频7”的视频服务，您可以轻松查看公寓、别墅、商铺、工厂、 办公室等场所的实时视频、历史录像；通过“视频7”的报警服务，可以即使 接收您关注产所的异常信息，第一时间采取安全防护措施。
CS-C1-11PFR\WPFR CS-C1-10F\WF
产品特点：
输出1280×960 实时图像 Micro SD/ SDHC卡(32G) 本地存储 ICR红外滤片式自劢切换 支持PIR人体侦测功能 无线声光报警，无线收发 无线门磁、无线遥控钥匙 、无线遥控布撤防 麦克风扬声器，双向音频 一体式支架，安装方便
高清视频采集, 报警联劢
高清视频采集, 报警联劢
家庭高清智能安防系统设计
别墅
紧急按钮
红外幕帘
紧急事件,报警求救
入侵防盗
红外对射
红外对射
入侵防盗
入侵防盗
半球高清网 络摄像机
门磁
筒型高清网 络摄像机
高清视频采集 门窗入侵防盗 高清视频采集
多功能报警 高清网络摄 像机
高清视频采集, 报警联劢
家庭高清智能安防功能设计
-- 主要功能
视频画面分享：
只要您愿意，通过“视频7” 您可以随时随地分享生活中的 精彩画面。
视频7平台架构
家庭高清智能安防系统设计
公寓
多功能报警 高清网络摄 像机 门磁
高清视频采集, 报警联劢
紧急按钮
紧急事件,报警求救
门窗入侵防盗
多功能报警 高清网络摄 像机
多功能报警 高清网络摄 像机
海康威视HM-TD5537T-15 W热成像、光成像双谱网络小型定位系统产品介绍说明书
HM-TD5537T-15/WThermographic Thermal & Optical Bi-spectrum Network MINI Positioning SystemHIKMICRO HM-TD5537T-15/W Thermographic Thermal & Optical Bi-spectrum Network MINI Positioning System equipped with built-in GPU which supports intelligent behavior analysis algorithm, can realize high-precision VCA detection and real-time alarm. It is applied to fire-prevention purposes in scenes such as transformer substation, recycling center, gas station, and factory. The pre-alarm system helps you discover unexpected events immediately and protects your property.Key Feature●Behavior analysis function, based on deep learning algorithm: line crossing, intrusion, region entrance & exit●Temperature exception alarm for fire prevention●Fire detection algorithm●384 × 288 resolution 17 μm, VOx UFPA, NETD ≤ 35 mK (25°C, F# = 1.0)●Image processing technology: Liner, histogram, and self-adaptive thermal AGC mode, DDE, 3D DNR●High quality detector with 10 years guaranteeSpecificationThermal ModuleImage Sensor Vanadium Oxide Uncooled Focal Plane ArraysResolution 384 × 288Pixel Pitch 17 μmSpectral Range 8 μm to 14 μmNETD ≤ 35 mK (25°C, F# = 1.0)Focal Length 15 mmIFOV 1.13 mradAperture F1.0Field of View 24.55° × 18.54° (H × V)Min. Focusing Distance 0.5 mDigital Zoom × 2, × 4, × 8Optical ModuleImage Sensor 1/2.8" Progressive Scan CMOSResolution 2688 × 1520, 4 MPMin. Illumination Color: 0.05 Lux @ (F1.6, AGC ON), B/W: 0.01 Lux @ (F1.6, AGC ON)Field of View 58.4° × 33.8° (H × V) to 2.14° × 1.2° (H × V)Focal Length 4.8 mm to 153 mm, 32 ×Aperture (Range) F1.2 to F4.4Focus Mode Semi-auto, manualDigital Zoom × 2, × 4, × 8, × 16Shutter Speed 1 s to 1/100,000 sWDR 120 dBOptical Defog YesImage EffectPicture in Picture Display partial image of thermal channel on the full screen of optical channel Target Coloration Yes. Supported in white hot and black hot mode.PTZMovement Range Pan: 360° Continuous Rotate; Tilt: From -90° to +90° (auto flip)Pan Speed Configurable, From 0.5°/s to 90°/sTilt Speed Configurable, From 0.5°/s to 40°/sProportional Zoom YesPresets 300Patrol Scan 8 patrols; Up to 32 presets per patrolPower Off Memory YesPark Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan PT Status Turn On/Turn OffScheduled Task Preset/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux OutputIlluminatorIR Distance Up to 30 mIR Intensity and Angle Automatically adjustedSmart FunctionVCA 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), 10 scenes and 8 VCA rules for each scene.Temperature Measurement 3 temperature measurement rule types, 273 presets as scene, 21 rules of each scene (10 points, 10 areas, and 1 line)Temperature Range -20°C to 550°C (-4°F to 1022°F) Temperature Accuracy Max. (± 2°C, ± 2%)Fire Detection Dynamic fire and smoke detection, up to 10 fire points and 10 smoke points detectable.Video and AudioMain Stream Optical channel50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720)60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 960, 1280 × 720)Thermal channel50 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 512, 384 × 288)Sub-stream Optical channel50 Hz: 25fps (704 × 576, 352 × 288)60 Hz: 30 fps (704 × 576, 352 × 288) Thermal channel50 fps (704 × 576, 640 × 512, 384 × 288)Video Compression Main stream: H.265+/H.265/H.264+/ H.264 Sub-stream: H.265/H.264/MJPEGAudio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC/PCM NetworkProtocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoENetwork Storage MicroSD/SDHC/SDXC card (up to 128 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)API ISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T)Simultaneous Live View Up to 20 channelsUser/Host level Up to 32 users. 3 levels: administrator, operator, userSecurity User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filteringClient iVMS-4200, Hik-ConnectWeb Browser Live view (plug-in allowed): Internet Explorer 11 Live view (plug-in free): Chrome 57.0 +, Firefox 52.0 + Local service: Chrome 57.0 +, Firefox 52.0 +InterfaceAlarm Input 2-ch inputs (0 to 5 VDC)Alarm Output 2-ch relay outputs, alarm response actions configurableAlarm Action Preset/patrol scan/SD card record/relay output/smart capture/FTP upload/email linkageAudio Input 1 Audio Output 1Communication Interface 1, RJ45 10 M/100 M self-adaptive Ethernet interface. 1, RS-485 interfaceGeneralMenu Language 32 languagesEnglish, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)Power Supply 24 VDC Power Consumption 20 WWorking Temperature/Humidity -40°C to 70°C (-40°F to 158°F) 90% or lessWiper YesProtection Level IP67 StandardTVS 6000V lightning protection, surge protection, voltage transient protectionDimensions 321 mm × 194 mm × 153 mm(12.64" × 7.64" × 6.02") Weight Approx. 4.8 kg (10.582 lb)DRI Range Table* The table is only for reference and the performance may vary according to different environment.* The optimal detection, recognition, and identification distances are calculated according to Johnson’s Criteria.Detection Range: In order to distinguish an object from the background, the object must be covered by 1.5 or more pixels. Recognition Range: In order to classify the object (animal, human, vehicle, etc.), the object must be covered by 6 or more pixels.Identification Range: In order to identify the object and describe it in details, the object must be covered by 12 or more pixels..Detection Range (Vehicles: 1.4 × 4.0 m) Detection Range (Humans: 1.8 × 0.5 m) Recognition Range (Vehicles: 1.4 × 4.0 m) Recognition Range (Humans: 1.8 × 0.5 m) Identification Range (Vehicles: 1.4 × 4.0 m) Identification Range (Humans: 1.8 × 0.5 m) 1353 m441 m338 m110 m169 m55 mSmart Function Table* The table is only for reference and the performance may vary according to different environment.VCA Range(Vehicles: 1.4 × 4.0 m) VCA Range (Humans: 1.8 × 0.5 m) Temperature Measurement (Object: 2 × 2 m) Temperature Measurement (Object: 1 × 1 m) Fire Detection (Object: 2 × 2 m) Fire Detection (Object: 1 × 1 m) 450 m150 m 353 m 176 m882 m441 mAvailable Model HM-TD5537T-15/WDimensionCOMPLIANCE NOTICE: The thermal series products might be subject to export controls in various countries or regions, including without limitation, the United States, European Union, United Kingdom and/or other member countries of the Wassenaar Arrangement. Please consult your professional legal or compliance expert or local government authorities for any necessary export license requirements if you intend to transfer, export, re-export the thermal series products between different countries.。
海康威视智能分析产品介绍
车辆信息结构化系统iVMS-6200E-VI
平安城市建设中的重点项目，为大量的案件提供了重要的线索 由于有良好的补光和拍摄角度，是视频图像结构化技术发展的桥头堡
车辆卡口图片二次结构化服务器 让现有卡口系统具有最新的结构化应用技术
卡口图片
最新结构 化数据
用于传统车辆卡口图片的二次结构 化，解决现有系统中卡口摄像机上 结构化能力不足的问题。
人脸静态检索产品iVMS-6200E-FS
人脸检索功能
人脸查重功能
推荐使用场景
各级机关业务处、刑侦大队、治安大队等应用 各级派出所应用 户政管理应用 各级监狱、看守所、戒毒所应用
其他人员管理部门应用
视频检索产品iVMS-6200E-Ｓ
视频检索
周界行为分 析
数据结构化
事件检索
原始录像数据
视频结构化数据库
推荐使用场景
公安刑侦 部门
交警部门
其他行业涉 及到刑侦
用户
车辆检索系统iVMS-6200E-VR
车辆检索系统，是指使用者通过搜索图像文本或者视觉特征，在系统中通过 类似信息的比对，获取到真正实际需求的图像信息的一种智能搜索方法。
嫌疑人修改、 更换车牌
车脸检索 快速检索
输入样例图片
应用于刑侦 破案场景
功能图示
用于传统车辆卡口图片的二次结构化，解决现有系统中卡口摄像机上结 构化能力不足的问题。
系统特点
车牌识别：支持包括民用车牌、警用车牌、军用车牌、武警车牌、2002式号牌的号码识别 ，支持识别黑、白、蓝、黄、绿五种车牌颜色。
车型：支持客车，大货车，轿车，面包车，小货车，SUV，中型客车7中车型的识别 车身颜色：支持红、黄、绿、青、蓝、紫、粉、棕、白、灰及黑11种车身颜色识别 品牌（重点）：支持227种机动车车辆品牌下2040种车辆子品牌的识别 安全带：支持主驾驶未系安全带检测 遮阳板：支持主、副驾驶遮阳板打开检测 无车牌：支持无车牌车辆的品牌识别 每天处理150W张300W卡口图片的全功能识别 每天处理300W张300W卡口图片的品牌识别
海康威视后端设备产品介绍材料
后端产品手册2009.12.06目录DS-9000系列 (1)产品简介 (1)订货型号 (1)主要特性 (1)功能与性能 (2)物理接口 (4)典型应用 (5)技术规格表 (6)DS-9100系列 (8)产品简介 (8)订货型号 (8)主要特性 (8)功能与性能 (9)物理接口 (11)典型应用 (12)技术规格表 (13)DS-8100系列 (14)主要特性 (14)功能与性能 (14)典型应用 (16)DS-8100HF-S (18)产品简介 (18)订货型号 (18)特别说明 (18)物理接口 (18)技术规格表 (20)DS-8100HE-S (21)产品简介 (21)订货型号 (21)特别说明 (21)物理接口 (21)技术规格表 (23)DS-8100HC-S (24)产品简介 (24)订货型号 (24)特别说明 (24)物理接口 (24)技术规格表 (26)DS-8100HS-S (27)订货型号 (27)特别说明 (27)物理接口 (27)技术规格表 (29)DS-8100HL-S (30)产品简介 (30)订货型号 (30)特别说明 (30)物理接口 (30)技术规格表 (32)DS-7100系列 (33)DS-7100H-S (33)产品简介 (33)订货型号 (33)特别说明 (33)主要特性 (33)功能与性能 (34)物理接口 (36)典型应用 (37)技术规格表 (38)DS-7200系列（6467平台） (39)主要特性 (39)功能与性能 (39)典型应用 (41)DS-7208HV-S (42)产品简介 (42)订货型号 (42)特别说明 (42)物理接口 (42)技术规格表 (44)DS-7216HV-S (45)产品简介 (45)订货型号 (45)特别说明 (45)物理接口 (45)技术规格表 (47)DS-8000系列 (48)功能与性能 (48)典型应用 (50)DS-8000HF-S (51)产品简介 (51)订货型号 (51)特别说明 (51)技术规格表 (54)DS-8000HT-S (55)产品简介 (55)订货型号 (55)特别说明 (55)物理接口 (55)技术规格表 (57)DS-8000HE-S (58)产品简介 (58)订货型号 (58)特别说明 (58)物理接口 (58)技术规格表 (60)DS-8000HE-SL (61)产品简介 (61)订货型号 (61)特别说明 (61)物理接口 (61)技术规格表 (63)DS-8000HC-S (64)产品简介 (64)订货型号 (64)特别说明 (64)物理接口 (64)技术规格表 (66)DS-8000HC-SL (67)产品简介 (67)订货型号 (67)特别说明 (67)物理接口 (67)技术规格表 (69)DS-8000HS-S (70)产品简介 (70)订货型号 (70)特别说明 (70)物理接口 (70)技术规格表 (72)DS-8000HS-ST (73)产品简介 (73)订货型号 (73)特别说明 (73)物理接口 (73)技术规格表 (75)DS-7000系列 (76)DS-7000H-S (76)产品简介 (76)订货型号 (76)特别说明 (76)物理接口 (76)技术规格表 (79)DS-7200系列（6446平台） (80)DS-7204H-S (80)产品简介 (80)订货型号 (80)特别说明 (80)物理接口 (80)技术规格表 (81)DS-7208H-S (82)产品简介 (82)订货型号 (82)特别说明 (82)物理接口 (82)技术规格表 (83)DS-9000系列产品简介DS-9000系列网络硬盘录像机是海康威视自主研发的新一代混合型网络硬盘录像机它融合了多项专利技术，采用了多项IT高新技术，如视频编解码技术、嵌入式系统技术、存储技术、网络技术和智能技术等。
海康威视 NVR5.0 用户手册说明书
网络数字录像机(NVR )用户手册-1-前言注意事项:欢迎您使用本公司网络数字录像机(NVR)产品，为保障你安全稳定的使用，请务必仔细阅读本使用手册，下面是关于产品的正确使用方法以及预防危险、防止财产受到损失等内容，使用时请务必遵守。
1.安装环境：请在0℃-50℃的温度环境下放置和使用本产品；设备安装与使用时应水平放置，尽量避免倾斜或倒置；避免放置或安装在高温、潮湿、有灰尘或煤烟的场所。
设备不应遭受水滴或水溅，设备上不应放置诸如花瓶一类的装满液体的物品，勿将其他设备放置于本产品上面。
为保证设备的正常散热，在设备中设计装有散热风扇，应尽量将设备安装在通风良好的环境；录像机安装时，其后部应距离其它设备或墙壁6CM 以上，便于散热；在多雷地区使用时，请安装避雷装置，以避免雷击引起的主机故障或硬件烧坏。
2.注意事项：不要用湿手或潮湿的物品接触电源开关与网络数字录像机，以免触电；安装完主机一定确保主机以及机箱接地，以避免视频、音频信号受到干扰，以及避免网络数字录像机被静电损坏；请确保网络数字录像机供电电源电压的稳定，尽量使用电压值稳定，波纹干扰较小的电源输入，不要采用直接断开总开关的方式关闭网络数字录像机； 勿将液体或金属溅落在录像机上，以免造成机器内部短路或失火；设备不包括硬盘，在使用前需正确安装硬盘，否则将不能进行录放像操作； 主板上的灰尘在受潮后会引起短路，为了使网络数字录像机能长期正常工作，应该定期用刷子对主板、接插件、机箱及机箱风扇等进行除尘；网络数字录像机关机时，不要直接关闭电源开关，应使用面板上的关机按钮，使网络数字录像机自动关掉电源，以免损坏硬盘；主机系统支持硬盘的格式化功能，如果硬盘已经使用过，请注意是否为FAT32格式的，本嵌入式网络数字录像机只支持FAT32格式，否则将有出错的隐患，； 请勿带电打开机器；为保证录像数据的完整性，发现坏硬盘请及时进行更换（日志中有关于磁盘错误的记录）。
海康威视B11产品介绍
DS-6408-B11DH （单业务板）
4HDMI 路视频输入，4DVI 视频输入 1 个 DB15 接口（电平：2.0Vp-p，阻抗：1kΩ ）
DS-6404-B11S (单业务板)
DS-6408-B11S (单业务板)
4/8 路视频输入，4/8 路 SDI 环通输出，SDI 接口 无音频输入 支持 HD-SDI 标准接入，支持标准 1080P@25fps 等分辨率接入
（DS-6516-B11：1 个 DB26 接口；DS-6532-B11：2 个 DB26 接口）
4/8 路视频输入，VGA 接口 支持视频分辨率为：1280*1024@60HZ;1024*768@60HZ 1 个 DB15 接口 （电平：2.0Vp-p，阻抗：1kΩ ）
4/8 路视频输入，RGB 接口 支持视频分辨率为：1280*1024@60HZ;1024*768@60HZ 1 个 DB26 接口 （电平：2.0Vp-p，阻抗：1kΩ ）
网络视频输入
编码标准：H.264/MPEG4 传输协议：TCP/UDP/MULTCAST/RTP/RTSP 可接入设备类型：网络摄像机，DVR，DVS 分辨率支持： 1920*1080@25fps,1600*1200@25fps,1920*1080@30fps, 1600*1200@30fps 向下兼容
<250W（3 槽位满配）
0℃--＋50℃
0℃--＋50℃
0℃--＋50℃
10％--90％
10％--90％
10％--90％
19 英寸标准 12U 机箱 19 英寸标准 7U 机箱
19 英寸标准 4U 机箱
482.6mm（宽）× 482.6mm（宽）×432mm 482.6mm（宽）×432mm（深）
海康威视产品展示手册说明书
Smart Meeting
Interactive Display
Easy projection, convenient sharing and flexible comment contributes for a more efficient meeting.
Easy Projection
Working Area
Access Control
Authorising Access
With a Hikvision access control system, you can assign permissions for room entry - preventing illegal break-ins, with real-time notifications of unauthorised access attempts. Because the access system can be linked to a camera, you can view video footage of the incident for full situation management.
HikCentral Professional ACS License
MinMoe Access Control Terminal
Flexible Deployment - Supports wall mounting and floor standing with mounting pole. Visualised Temperature Screening - 7-inch touch screen. Thermographic Technology - Measures forehead temperature upon face detection. High Accuracy of Temperature Screening Temperature range 30°C to 45°C*. Mask Detection - Supports face mask wearing alerts and compulsory mask wearing alerts. Temperature screening with mask.
海康威视监控产品介绍
功能特性
·支持即时回放功能，在预览画面下对指定通道的当前录像进行回放，并且不影响其他通道预览； ·支持最大16路同步回放及多路同步倒放； ·支持标签定义、查询、回放录像文件； ·支持重要录像文件加锁保护功能； ·支持硬盘配额和硬盘盘组两种存储模式，可对不同通道分配不同的录像保存容量或周期； ·支持16个SATA接口，1个eSATA盘库，可用于录像和备份； ·支持RAID0、RAID1、RAID5、RAID6和RAID10； ·双千兆网卡，支持多址设定等应用； ·支持GB28181协议、Ehome协议接入平台； ·支持网络检测（网络流量监控、网络抓包、网络通畅）功能。
安防全系列产品 视频采集、传输存储、中心解析、大数据、报警、移动交通、显示控制、
可视对讲与智能锁、门禁与人员通道、热成像、智慧消防等各产品线
新业务板块/New Business
智慧存储、海康微影、慧影科技等其他拓展业务
汽车电子 车用电子产品及软件，智能车载信息系统
机器人业务 无人机、机器视觉组件、工厂自动化产线配套设备、机器视觉与
物联网数据管理……
互联网业务 视频云平台、民用安防服务、视频社交分享……
公司概览
以上为截止2018年12月31日数据
重大项目
G20
北京奥运会
APEC
上海世博会
中国国家大剧院
英国伦敦邱园
丹麦奥尔堡海港
德国科隆东亚艺术博物馆
南非国家电网
产品介绍
前端视频采集-高清红外枪机
主要特性 最高分辨率可达2560 × 1440@25fps,在该分辨率下可输出实时图像 支持低码率、低延时、ROI感兴趣区域增强编码,支持smart265编码 码流平滑设置，适应不同场景下对图像质量、流畅性的不同要求 高效阵列红外灯,使用寿命长,照射距离最远可达30米(I3)/50米(I5)/80米(I8),支持smart IR，防止夜间红外过曝 ICR红外滤片式自动切换,实现真正的日夜监控,支持日夜两套参数独立配置 支持3D数字降噪，支持120dB真宽动态,支持双码流,支持手机监控 支持走廊模式,背光补偿,自动电子快门功能,适应不同监控环境,功能齐全:心跳,镜像等 支持智能报警：越界侦测,区域入侵侦测,支持智能后检索，配合NVR支持事件的二次检索分析 支持萤石云平台接入,支持Email、FTP、NTP服务器测试,支持HTTPS等安全认证，支持创建证书 支持用户登录锁定机制，及密码复杂度提示 符合IP67级防尘防水设计,可靠性高 应用场景 适用于道路、仓库、地下停车场、酒吧、管道、园区等光线较暗或无光照环境且要求高清画质的场所。
