欧洲最新能效标准CFL Specification V5 August 2005

lamp Specification Version 5 – August 2005

BLANK SHEET

BLANK SHEET

Diagrammatic representation of lamps covered by this specification

EST Lamp Specification V5 August 2005 Page 5 of 51

EST Lamp Specification V5 August 2005 Page 6 of 51

Record of amendments to the EST Lamp Specification

BLANK SHEET

EST Specification

Version 5

Part 1

General items applicable to all

lamp types

1.1 Introduction

This Energy Saving Trust (“Trust”) lamp specification supersedes all previous specifications issued by the Trust. (The only exceptions will be for products still undergoing life assessment to the superseded edition at the time of publication of this document).

这一节能灯规格取代以往所有Trust所发行的。（唯一的例外是所评估的产品处于编辑发布这份文件之时）

1.2 Lamp Groups covered by this Specification

The previous introductory items summarise the categories of lamps covered by this specification. All lamps approved by the Trust shall comply with relevant European CENELEC Standards and all additional requirements as detailed in this specification which are relevant to the lamp type(s). 以往介绍的项目概述了本规格所涵盖灯具。所有经Trust通过的灯应遵守相关欧洲SENELEC标准及一切额外的要求，详见本规格相关灯型。

1.3 Lamp definitions

Group 1 Compact Fluorescent Lamps - Electronic Self- Ballasted Compact Fluorescent Lamps (CFLs) utilising B22d, B15d, E27 or E14 caps, or any other suitable cap types which are specified in EN 60061-1, or which are in the final stages of European standardisation for inclusion in EN 60061-1. These lamp types shall comply with European Standards EN 60968 for safety and EN 60969 for performance, five classes of CFLs are specified: -

自带电子镇流器的CFLs使用B22d, B15d, E27或E14灯头，或其他适用的类型，依据EN 60061-1，或其最终确立的欧洲标准版本。这些灯型的安全指标应遵照欧洲标准EN 60968，性能标准应根据EN 60969，特别是5种等级的CFLs. Class S - which meet the energy labelling requirements for Class A of the European Directive 98/11/EC. 等级S---标签要求符合欧洲指令98/11/EC的等级A.

Class L– which meet the energy labelling requirements for Class B of the European Directive 98/11/EC. Additionally they shall also meet the energy labelling requirements of at least 85% of the minimum Class A requirements of Directive 98/11/EC.

等级L---标签要求符合欧洲指令98/11/EC的等级B.另外要求标签应至少85%符合欧洲指令98/11/EC的等级A

Class P – which are used for decorative effect lighting and which meet the energy labelling requirements for Class B of the European Directive 98/11/EC. Additionally they shall also meet the energy labelling requirements of at least 45% of the minimum Class A requirements of Directive 98/11/EC等级P---用于装饰灯及标签要求符合欧洲指令98/11/EC的等级B.另外要求标签应至少45%符合欧洲指令98/11/EC的等级A

Class R – A compact fluorescent arc tube controlled by electronic ballasting, the combination being mounted into a reflector housing intended to fit into conventional filament reflector lamp luminaires or the like and exhibit a significantly lower energy consumption than the filament reflector lamp that it may claim to replace. 电子镇流管控CF弧光管组合陆续进入reflector housing，旨在纳入常规的filament reflector lamp luminaires或the like，相比较要被更换的filament reflector lamp，它大大降低了能耗。

Class T– Two part CFLs, comprising a light source (lamp) complying with Group 2 (see below) which is operated by separate electronic control gear contained in an ‘adaptor’ utilising bayonet or Edison screw caps (complying with EN 60061-1, EN 60598, EN 60929, EN 61347-2-3), both lamp and adaptor being supplied as a single entity at the point of sale. Replacement lamps must be readily available for purchase as separate items. (These lamp types will be assessed as Class S, L, P or R as appropriate)CFLs两部分,包括光源(灯)符合第2组(见下文)，其被使用bayonet或Edison螺丝帽的适配器的电子控制齿轮所操控(遵守EN 60061-1, EN 60598, EN 60929, EN 61347-2-3)，灯和适配器在销售点作为整体配套供应. 对于那些作为独立购买的产品，灯具更换必须是可行的。 (这些灯型将根据适宜的等级S, L, P 或R而被评级)

Group 2 Single capped fluorescent - Lamps which comply with European Standards EN 61199 for safety and EN 60901 for performance. These lamps require separate electronic ballasts, usually provided in a suitable luminaire or with an adaptor as in the case of Class T.

灯的安全标准依照欧洲标准EN 61199，性能标准遵循EN 60901。这些灯要求单独的电子镇流器，提供常规灯具或等级T的适配器。
