快捷键

3A, *3DARRAY
3DO, *3DORBIT
3F, *3DFACE
3P, *3DPOL Y
A, *ARC
AC, *BACTION
ADC, *ADCENTER
AA, *AREA
AL, *ALIGN
AP, *APPLOAD
AR, *ARRAY
-AR, *-ARRAY
ATT, *ATTDEF
-ATT, *-ATTDEF
ATE, *ATTEDIT
-ATE, *-ATTEDIT
ATTE, *-ATTEDIT
B, *BLOCK
-B, *-BLOCK
BC, *BCLOSE
BE, *BEDIT
BH, *HATCH
BO, *BOUNDARY
-BO, *-BOUNDARY
BR, *BREAK
BS, *BSA VE
C, *CIRCLE
CH, *PROPERTIES
-CH, *CHANGE
CHA, *CHAMFER
CHK, *CHECKSTANDARDS CLI, *COMMANDLINE COL, *COLOR COLOUR, *COLOR
CO, *COPY
CP, *COPY
CT, *CTABLESTYLE
D, *DIMSTYLE
DAL, *DIMALIGNED DAN, *DIMANGULAR DAR, *DIMARC
JOG, *DIMJOGGED
DBA, *DIMBASELINE DBC, *DBCONNECT DC, *ADCENTER
DCE, *DIMCENTER DCENTER, *ADCENTER
DCO, *DIMCONTINUE DDA, *DIMDISASSOCIATE DDI, *DIMDIAMETER DED, *DIMEDIT
DI, *DIST
DIV, *DIVIDE
DJO, *DIMJOGGED
DLI, *DIMLINEAR
DO, *DONUT
DOR, *DIMORDINATE DOV, *DIMOVERRIDE
DR, *DRAWORDER
DRA, *DIMRADIUS
DRE, *DIMREASSOCIATE DRM, *DRAWINGRECOVERY DS, *DSETTINGS
DST, *DIMSTYLE
DT, *TEXT
DV, *DVIEW
E, *ERASE
ED, *DDEDIT
EL, *ELLIPSE
EX, *EXTEND
EXIT, *QUIT
EXP, *EXPORT
EXT, *EXTRUDE
F, *FILLET
FI, *FILTER
G, *GROUP
-G, *-GROUP
GD, *GRADIENT
GR, *DDGRIPS
H, *HATCH
-H, *-HATCH
HE, *HATCHEDIT
HI, *HIDE
I, *INSERT
-I, *-INSERT
IAD, *IMAGEADJUST
IAT, *IMAGEATTACH
ICL, *IMAGECLIP
IM, *IMAGE
-IM, *-IMAGE
IMP, *IMPORT
IN, *INTERSECT
INF, *INTERFERE
IO, *INSERTOBJ
J, *JOIN
L, *LINE
LA, *LAYER
-LA, *-LAYER
LE, *QLEADER
LEN, *LENGTHEN
LI, *LIST LINEWEIGHT, *LWEIGHT
LO, *-LAYOUT
LS, *LIST
LT, *LINETYPE
-LT, *-LINETYPE LTYPE, *LINETYPE
-LTYPE, *-LINETYPE
LTS, *LTSCALE
LW, *LWEIGHT
M, *MOVE
MA, *MATCHPROP ME, *MEASURE
MI, *MIRROR
ML, *MLINE
MO, *PROPERTIES MS, *MSPACE
MSM, *MARKUP
MT, *MTEXT
MV, *MVIEW
O, *OFFSET
OP, *OPTIONS ORBIT, *3DORBIT
OS, *OSNAP
-OS, *-OSNAP
P, *PAN
-P, *-PAN
PA, *PASTESPEC PARAM, *BPARAMETER PARTIALOPEN, *-PARTIALOPEN PE, *PEDIT
PL, *PLINE PO, *POINT
POL, *POL YGON
PR, *PROPERTIES PRCLOSE, *PROPERTIESCLOSE PROPS, *PROPERTIES PRE, *PREVIEW
PRINT, *PLOT
PS, *PSPACE
PTW, *PUBLISHTOWEB PU, *PURGE
-PU, *-PURGE
QC, *QUICKCALC
R, *REDRAW
RA, *REDRAW ALL
RE, *REGEN
REA, *REGENALL
REC, *RECTANG
REG, *REGION
REN, *RENAME
-REN, *-RENAME
REV, *REVOLVE
RO, *ROTA TE
RPR, *RPREF
RR, *RENDER
S, *STRETCH
SC, *SCALE
SCR, *SCRIPT
SE, *DSETTINGS
SEC, *SECTION
SET, *SETV AR
SHA, *SHADEMODE
SL, *SLICE
SN, *SNAP
SO, *SOLID
SP, *SPELL
SPL, *SPLINE
SPE, *SPLINEDIT
SSM, *SHEETSET
ST, *STYLE
STA, *STANDARDS
SU, *SUBTRACT
T, *MTEXT
-T, *-MTEXT
TA, *TABLET
TB, *TABLE
TH, *THICKNESS
TI, *TILEMODE
TO, *TOOLBAR TOL, *TOLERANCE TOR, *TORUS
TP, *TOOLPALETTES TR, *TRIM
TS, *TABLESTYLE UC, *UCSMAN
UN, *UNITS
-UN, *-UNITS
UNI, *UNION
V, *VIEW
-V, *-VIEW
VP, *DDVPOINT
-VP, *VPOINT
VS, *BVSTA TE
W, *WBLOCK
-W, *-WBLOCK
WE, *WEDGE
X, *EXPLODE
XA, *XATTACH
XB, *XBIND
-XB, *-XBIND
XC, *XCLIP
XL, *XLINE
XR, *XREF
-XR, *-XREF
Z, *ZOOM
A V, *DSVIEWER CP, *COPY
DIMALI, *DIMALIGNED DIMANG, *DIMANGULAR DIMBASE, *DIMBASELINE DIMCONT, *DIMCONTINUE DIMDIA, *DIMDIAMETER DIMED, *DIMEDIT DIMTED, *DIMTEDIT DIMLIN, *DIMLINEAR DIMORD, *DIMORDINA TE DIMRAD, *DIMRADIUS DIMSTY, *DIMSTYLE DIMOVER, *DIMOVERRIDE LEAD, *LEADER
TM, *TILEMODE
AAD, *DBCONNECT AEX, *DBCONNECT ALI, *DBCONNECT ASQ, *DBCONNECT ARO, *DBCONNECT ASE, *DBCONNECT DDA TTDEF, *ATTDEF
DDA TTEXT, *ATTEXT DDCHPROP, *PROPERTIES DDCOLOR, *COLOR DDLMODES, *LAYER DDLTYPE, *LINETYPE DDMODIFY, *PROPERTIES DDOSNAP, *OSNAP DDUCS, *UCS
Alt+S, 图层状态管理器
….
《PKPM 快捷键》
'Q ' 'Quit ' '退出程序'
'QU ' 'Quit ' '退出程序'
'QUI ' 'Quit ' '退出程序'
'EXIT ' 'Quit ' '退出程序'
'DI ' 'InqPP ' '点点距离'
'DIL ' 'InqPL ' '点线距离'
'DIF ' 'InqPF ' '点面距离'
'LEN ' 'Length ' '线段长度'
'E ' 'Erase ' '删除图素'
'M ' 'DragMove ' '图素拖动'
'RO ' 'Rotate ' '图素旋转'
'MI ' 'Mirror ' '图素镜像'
'CP ' 'DragCopy ' '拖动复制'
'AR ' 'MoveCopy ' '平移复制'
'ARR ' 'RotaCopy ' '旋转复制'
'S ' 'DragEndM ' '端点拖动'
'BR ' 'Break ' '图素截断'
'TR ' 'Trim ' '图素修剪'
'EX ' 'Extend ' '图素延伸'
'F ' 'Fillet ' '直线圆角'
'O ' 'Offset ' '偏移复制'
'U ' 'UnDo ' 'UNDO '
'SN ' 'GridSnap ' '点网捕捉F3' 'TO ' 'ToolBarS ' '工具开关'
'DV ' 'ZoomRota ' '观察角度'
'V ' 'ViewSet ' '设观察点'
'HI ' 'HideDisp ' '消隐显示'
'HIDE ' 'HideDisp ' '消隐显示'
'SHADE ' 'HideDisp ' '消隐显示'
'R ' 'Redraw ' '重新显示F5' 'ZE ' 'ZoomExt ' '充满显示F6' 'ZOOME ' 'ZoomExt ' '充满显示F6'
'Z2X ' 'Zoom2X ' '放大一倍F7' 'ZX2 ' 'ZoomX2 ' '缩小一半F8'
'RA ' 'ZoomAll ' '显示全图Ctrl+F6' 'ZW ' 'ZoomWin ' '窗口放大Ctrl+ W'
'ZX ' 'ZoomX ' '比例缩放'
'ZD ' 'ZoomPIP ' '局部放大'
'ZM ' 'ZoomPan ' '平移显示Ctrl+ M'
'ZP ' 'ZoomPrv ' '恢复显示Ctrl+F5' 'REA ' 'RedraWin ' '各窗刷新Ctrl+ R' 'PO ' 'Point ' ' 点'
'L ' 'Line ' '两点直线'
'PL ' 'PolyLine ' '折线'
'POL ' 'PolyLine ' '折线'
'REC ' 'Rectangl ' '矩形'
'A ' 'Arc ' '圆弧'
'C ' 'Circle ' '圆环'
'CH ' 'Change ' '图素修改'
'1 ' '1VPort ' '设一视窗'
'2 ' '2VPorts ' '设二视窗'
'3 ' '3VPorts ' '设三视窗'
'4 ' '4VPorts ' '设四视窗'
'P ' 'Point ' '节点'
'L ' 'Line ' '两点直线'
'PA ' 'Parallel ' '平行直线'
'ND ' 'NodeDel ' '删除节点'
'GD ' 'GridDel ' '删除网格'
'CDF ' 'ColmDef ' '柱定义'
'BDF ' 'BeamDef ' '主梁定义'
'WDF ' 'WallDef ' '墙定义'
'WNDF ' 'WnDrDef ' '洞口定义' 'CD ' 'ColmDel ' '删除柱'
'BD ' 'BeamDel ' '删除主梁'
'WD ' 'WallDel ' '删除墙'
'WND ' 'WnDrDel ' '删除洞口'
'FLD ' 'FloorDel ' '删标准层'
'FLIN ' 'FloorIns ' '插标准层'
'EDBF ' 'EditBFlr ' '层间编辑'
'LDDF ' 'LoadDef ' '荷载定义'
'LDIN ' 'LoadIns ' '荷载插入'
'LDD ' 'LoadDel ' '荷载删除'
'EndOfFile' 'EndOfFile' 'EndOfFile'
TSSD AutoCAD 简化命令
3A, *3DARRAY
3DO, *3DORBIT
3F, *3DFACE
3P, *3DPOL Y AR, *ARRAY ADC, *ADCENTER AD, *ID
AE, *AREA
AL, *ALIGN AP, *APERTURE ATP, *ATTDISP
A T, *DDA TTE
-AT, *ATTEDIT ATT, *DDA TTDEF -ATT, *ATTDEF
A V, *DSVIEWER BR, *BREAK BH, *BHATCH BL, *BMAKE
-BL, *BLOCK BO, *BOUNDARY -BO, *-BOUNDARY C, *COPY
CC, *CHAMFER CH, *DDCHPROP -CH, *CHANGE CO, *DDCOLOR CR, *CIRCLE DIM, *DIM
DD, *DDEDIT DDV, *DDVPOINT DIST, *DIST
DIV, *DIVIDE DO, *DONUT DST, *DIMSTYLE DT, *DTEXT DV, *DVIEW DDIM, *DDIM DXI, *DXFIN DXO, *DXFOUT E, *ERASE
EL, *ELEV
ELL, *ELLIPSE EN, *END
EP, *EXPLODE EX, *EXTEND F, *FILLET
FF, *FILL
FI, *FILTER GROUP, *GROUP GR, *DDGRIPS
-GR, *GRID
HI, *HIDE
HA TCHEDIT, *HATCHEDI HT, *HATCH
I, *DDINSERT
-I, *INSERT
IM, *IMAGE
-IM, *-IMAGE
L, *LINE
LA, *LAYER
-LA, *-LAYER LE, *LEADER LEN, *LENGTHEN LI, *LIST
LS, *LTSCALE LT, *LINETYPE
-LT, *-LINETYPE LTS, *LTSCALE M, *MOVE
A, *MATCHPROP ME, *MEASURE MI, *MIRROR ML, *MLINE MO, *DDMODIFY MN, *MENU MS, *MSPACE MT, *MTEXT
-MT, *-MTEXT MV, *MVIEW
N, *NEW
O, *OFFSET OP, *OPEN
OS, *OSNAP
-OS, *-OSNAP
P, *PAN
-P, *-PAN
PA, *PASTESPEC PB, *PICKBOX PE, *PEDIT
PG, *POL YGON REI, *REINIT
PL, *PLINE
PN, *PLAN
PO, *POINT
POL, *POL YGON PR, *PREFERENCES PRE, *PREVIEW PRINT, *PLOT
PS, *PSPACE
PT, *PLOT
PU, *PURGE
QT, *QUIT
R, *REDRAW RA, *REDRAWALL RD, *REDO
RE, *RENAME
-RE, *RENAME REC, *RECTANGLE REG, *REGION REV, *REVOLVE RG, *REGEN RGA, *REGENALL RM, *DDRMODES RO, *ROTA TE RPR, *RPREF
RR, *RENDER
S, *STRETCH SC, *SCALE SCR, *SCRIPT
SD, *SHADE
SE, *DDSELECT
-SE, *SELECT SET, *SETVAR
SL, *SLICE
SN, *SNAP
SO, *SOLID
SP, *SPLFRAME SPL, *SPLINE SPE, *SPLINEDIT QS, *QSAVE SSA, *SA VEAS ST, *STYLE
SV, *SAVE
SU, *SUBTRACT TR, *TRIM
TAB, *TABLET TE, *TEXT
TH, *THICKNESS TI, *TILEMODE TO, *TOOLBAR TOL, *TOLERANCE TOR, *TORUS TA, *TRACE UC, *DDUCS UCP, *DDUCSP UN, *DDUNITS
-UN, *UNITS UNI, *UNION
UI, *UCSICON V, *DDVPOINT -V, *VPOINT
VI, *DDVIEW
-VI, *VIEW
VS, *VSLIDE WB, *WBLOCK WE, *WEDGE
X, *EXPLODE XA, *XATTACH XBIND, *XBIND
-XBIND, *-XBIND XC, *XCLIP
XL, *XLINE
XR, *XREF
-XR, *-XREF
ZX, *ZOOM
;; TSSD 简化命令
TS, *TSSDSET HTK, *HZHTK TZML, *TZHML ;;外部接口
TCH, *TZHJK GS, *GSHJK PM, *PMJK PZX, *PMZHX
PZZ, *PMZHZ PLG, *PMLQ PGJ, *PMGJ PCC, *PMCHC PWZ, *PMWZ PBH, *PMBH
;;轴网
JZ, *JXZHW HZ, *YHZHW TZ, *TJZHX DZ, *DGZHX SZ, *SHCHZHX ZJ, *ZHXJC
XZ, *XCHZHX BZ, *ZHWBZH DB, *DZHBH ZBJ, *ZHHBJ YX, *ZHHYX ZWP, *ZHHWP QWP, *QXWP DH, *DHKG ZBL, *ZHWXBXSH ;;柱子
CFZ, *CHFZH CYZ, *CHYZH ZCC, *ZHCHCBZH ZYW, *ZHYWBZH ZJZ, *ZHJZHBZH DZB, *DZHBZH SZH, *SHCHZHZ YZH, *YDZH ZTS, *ZHTSH ZKX, *ZHKX
JX, *JXCHL ZXS, *ZHXSHBH ZXB, *ZHXBXSH ;;梁
ZXL, *ZHXBL ZL, *HZHXL FZL, *FZHLX
L YW, *L YWBZH LJZ, *LJZHBZH LBL, *LXBL
CL, *CSHXL GLK, *GBLK LPY, *LXPY XLX, *JXCHL LLJ, *LJLX QCL, *XCHLX
L YD, *LXYD LXXB, *LXXB LXS, *LXSHBH LXB, *LXBXSH ;;剪力墙
ZXQ, *ZHXBQ ZQ, *HZHXQ FZQ, *FZHQX QJC, *QXJC QHF, *JCHF GQK, *GBQK QPY, *QXPY QTC, *QXTCH CQ, *CSHXQ QYD, *QXYD QBZ, *QXPMBZH QKD, *QSHKD SDK, *SHCHDK YDK, *DKYD FZD, *FZHDK DBK, *DKBK DDK, *DKDCBK QFK, *QDFK ;;板
BSZ, *BBSHZH BYZ, *BYZHB FBH, *FJBH BKD, *LBKD ;;基础
HTJ, *HZHTJ ZXX, *ZHXXBJ BJC, *BDLZHJ JJC, *JCHJC BCT, *CHTBZH QXZ, *QXBZH ZJB, *CZHJB TJZ, *ZHSHTJ SHZ, *SHCHZH ;;构件计算
LXL, *LXLJS JZL, *JZLJS JXB, *JXBJS JC, *JCHJS CT, *CHTJS SLT, *LTJS MJ, *MJJS LJM, *LJM FHZ, *FHGJZH QZ, *QZHJM LTP, *LTPM LTT, *LTXT LTB, *LTB BYT, *BSHYT CTT, *ZHJCHT ZZJ, *ZHXZHJ BKZ, *BKZHJ JTZ, *JTZHJ WLTJ, *WLTJ YLTJ, *YLTJ WJTJ, *WJTJ WJZJ, *WJZHJ DSJ, *DLSHJ ZSJ, *ZHXSHJ ;;钢筋
SG, *REINSET GJH, *GJBZ ZHJ, *ZDZHJ RZ, *RYZHJ FJ, *ZDFJ RF, *RYFJ DF, *DKFJ HJ, *TSHHRYJ DJ, *HDGJ ZGJ, *HZGJ GJW, *HGJW YXG, *YXGUJ GJ, *GJ
LJ, *LJ
SJ, *SXGJ FDJ, *FJDJ FQJ, *FJGJ ;;钢筋工具
JYG, *GJJYG JXG, *GJJXG JZG, *GJJZHG SS, *SHWG BDJ, *GBGJDJ YG, *YGDD XG, *XGDD PJD, *PLNEA PJDX, *PLNED PYJ, *PYGJ DPY, *DDPY LJJ, *LJGJ
JLT, *GJLT SZJ, *ZHJSHS SGJ, *GJSHS CGJ, *GJCHXB ;;尺寸
XB, *XXBZH DQB, *DQBZH PYB, *PXBZH BKH, *LKQH BLZ, *LQZHB ZDB, *ZHDBZH BJD, *JDBZH BHC, *HCHBZH BBJ, *BJBZH DMD, *BZHDK DM, *BZHHB CD, *CHDCHL DX, *KDQQ DY, *XCHQQ GZ, *GCHCZH BWZ, *CHCBWZ ZFZ, *WZFZH BYS, *WZYS ;;文字
SZX, *TEXTSET DSR, *DHSHR T, *DHBJ XFZ, *XFZH FY, *ZHYWDZH SWZ, *WZSHR BJ, *TYBJ ZPX, *WZPX CK, *CK
TWZ, *CHZHTH TGJ, *THGJZHJ CCD, *CHZCHD SCD, *SHCHJCHK ZWZ, *WZZHK FWZ, *ZHKHF
;;文字工具
HTH, *FHTH ZCZ, *LJCHZ LWZ, *LJWZ
WZ2, *QPWZ
WZ1, *SHPWZ CWZ, *CHFZCH DWZ, *WZDD SFZ, *WZSF XWZ, *WZQX WZZ, *WZXZH GSB, *GGSHB GXB, *GGXB SHF, *SHBHF XHF, *XBHF TYZ, *TYZG
;;表格
ZHB, *ZHZBG DEX, *READEXCEL BJB, *BJBG
GN, *GNWZ XXH, *XXH
JQZ, *WZJQZH JHZ, *WZJHZH HZB, *SHCHZHB ;;钢结构详图
HXG, *XGHZH HLS, *LSHHZH BHF, *HFHZH
;;实体工具
BBL, *BBL
GXK, *GBXK LXD, *LJXD
LC, *LXFZH
JD, *JXDH
XCX, *XCHCHX XST, *XCHSHT DJD, *JDDD CJD, *JDJC CTX, *TXJC BXS, *XSHBH XBL, *XBXSH ;;其它工具
PGP, *TPDG KJ, *TSCT SXT, *SYSET STC, *LAYERSET CX, *XCXSH CG, *XCGB TDS, *QTDS GTC, *TCHGS ZKG, *ZKG TYH, *TXYH TK, *TKGL
;;常用符号
LDM, *LDMH BHBJ, *BHBJ PF, *PFBZH TPF, *PFTD YC, *YCHBZH SY, *SYFH
LF, *LJFH
PD, *PDX
PP, *PMPQ
JP, *PDFH
BG, *BGHZH BBG, *BGBJ DC, *DCFH TM, *TXMCH HMJ, *MJHZH ZB, *BZBD ZBZ, *ZHBZH HJT, *HJT。
