编译原理课程设计-LR分析器总控程序的实现

合肥工业大学计算机与信息学院课程设计课程：编译原理专业班级：计算机科学与技术09-2班学号：姓名：一：设计题目题目： LR分析器总控程序的实现设计内容及要求：对P.101中的文法，按图5.5LR分析表构造LR分析器。

要求程序按P.102例5.7那样，对于输入串i*i+i，输出LR分析器的工作过程。

改进：可以自行输入输入串，能按重新按钮重新开始，外加了一个计时器。

二：设计目的进一步了解了LR分析器的整个工作过程，将LR分析器以图形界面的形式展现了出来，有利加深了对LR分析过程的掌握。

三：实验原理本程序是用windows编的，大体的思想是这样的：通过建立一个符号栈，状态栈，输入栈（结构体类型定义的）分别用来存放符号，状态，输入串，将LR 分析表构造成为一个二维数组table[13][9]，其中0--11表示状态结点，21－－26表示规约标号，-1表示error（出错），12表示acc（接受），在acation函数里面通过i等于多少来判断到底是规约还是移进。

在Main_OnCommand（）函数中通过switch....case..来判断每次及下一步所要执行的操作。

运行的时候，首先要输入一个以#结尾的输入串，然后单击开始——>下一步.....,如果规约成功，则弹出一个规约成功的对话框，否则弹出一个规约失败的对话框。

当然在运行的过程中如果出现什么差错，都可以单击重新开始按钮重新输入输入串重新开始。

四：实验代码#include "stdAfx.h"#include <windows.h>#include <windowsx.h>#include "resource.h"#include "MainDlg.h"char *str2[6]={"E->E+T","E->T","T->T*F","T->F","F->(E)","F->i"};int flag=0;#define MAX 20typedef struct{int stack1[MAX];int top1;}status;typedef struct{char stack2[MAX];int top2;}symbol_instr;char index_char[9]={'i','+','*','(',')','#','E','T','F'};//为二维数数组的纵坐标//LR分析表//0--11表示状态结点，21－－26表示规约标号，//-1表示error（出错），12表示acc（接受）int table[13][9] = {{ 5,-1,-1, 4,-1,-1, 1, 2, 3},\{-1, 6,-1,-1,-1,12,-1,-1,-1},\{-1,22, 7,-1,22,22,-1,-1,-1},\{-1,24,24,-1,24,24,-1,-1,-1},\{ 5,-1,-1, 4,-1,-1, 8, 2, 3},\{-1,26,26,-1,26,26,-1,-1,-1},\{ 5,-1,-1, 4,-1,-1,-1, 9, 3},\{ 5,-1,-1, 4,-1,-1,-1,-1,10},\{-1, 6,-1,-1,11,-1,-1,-1,-1},\{-1,21, 7,-1,21,21,-1,-1,-1},\{-1,23,23,-1,23,23,-1,-1,-1},\{-1,25,25,-1,25,25,-1,-1,-1}};//规约规则struct rule{char x;int y;}r[6]={{'E',3},{'E',1},{'T',3},{'T',1},{'F',3},{'F',1}}; //后面的代表A—>@中@的长度BOOL WINAPI Main_Proc(HWND hWnd, UINT uMsg, WPARAM wParam, LPARAM lParam) {switch(uMsg){HANDLE_MSG(hWnd, WM_INITDIALOG, Main_OnInitDialog);HANDLE_MSG(hWnd, WM_COMMAND, Main_OnCommand);HANDLE_MSG(hWnd,WM_CLOSE, Main_OnClose);}return FALSE;}void init_stack1(HWND hwnd,status *p){if( !p)MessageBox(hwnd,TEXT("出错"),TEXT("警告"),MB_OK|MB_ICONHAND);p->top1 = -1;}void push1(HWND hwnd,status *&p,int x){if(p->top1 < MAX-1){p->top1++;p->stack1[p->top1] = x;}else MessageBox(hwnd,TEXT("出错"),TEXT("警告"),MB_OK|MB_ICONHAND);}int pop1(HWND hwnd,status *p){int x;if(p->top1 != 0){x = p->stack1[p->top1];p->top1--;return x;}else{MessageBox(hwnd,TEXT("状态栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n状态栈1空!\n");return 0;}}void out_stack(HWND hwnd,status *p){if(p->top1 <0)MessageBox(NULL,TEXT("状态栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n状态栈3空!\n");int i;TCHAR str[256];for(i=0;i<=p->top1;i++)wsprintf(&str[i],"%d",p->stack1[i]);SetDlgItemText(hwnd,IDC_EDIT1,str);}int get_top1(HWND hwnd,status *p){int x;if(p->top1 != -1){x = p->stack1[p->top1];return x;}else{MessageBox(hwnd,TEXT("状态栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n状态栈2空!\n");return 0;}}void init_stack2(HWND hwnd,symbol_instr *p){if( !p)MessageBox(hwnd,TEXT("出错"),TEXT("警告"),MB_OK|MB_ICONHAND);p->top2= -1;}void push2(HWND hwnd,symbol_instr *p,char x){if(p->top2 < MAX-1){p->top2++;p->stack2[p->top2] = x;p->stack2[p->top2+1]='\0';}else MessageBox(hwnd,TEXT("出错"),TEXT("警告"),MB_OK|MB_ICONHAND);}char pop2(HWND hwnd,symbol_instr *p){char x;if(p->top2 != -1){x = p->stack2[p->top2];p->top2--;p->stack2[p->top2+1]='\0';return x;}else{MessageBox(hwnd,TEXT("符号栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n符号栈1空!\n");return 0;}}void out_stack1(HWND hwnd,symbol_instr *p){if(p->top2 <0)MessageBox(hwnd,TEXT("符号栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n状态栈3空!\n");SetDlgItemText(hwnd,IDC_EDIT2,p->stack2);}void out_stack2(HWND hwnd,symbol_instr *p){if(p->top2 <0)MessageBox(hwnd,TEXT("符号栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n状态栈3空!\n");SetDlgItemText(hwnd,IDC_EDIT3,p->stack2);}char get_top2(HWND hwnd,symbol_instr *p){char x;if(p->top2 != -1){x = p->stack2[p->top2];return x;}else{MessageBox(hwnd,TEXT("符号栈为空"),TEXT("警告"),MB_OK|MB_ICONHAND);//printf("\n符号栈2空!\n");return 0;}}void print(HWND hwnd,status *status_p,symbol_instr *symbol_p,symbol_instr *instr_p){out_stack(hwnd,status_p); //输出状态栈的内容out_stack1(hwnd,symbol_p); //输出符号栈的内容out_stack2(hwnd,instr_p); //输出输入串}int get_index_char(char i){for(int j=0;j<9;j++){if(index_char[j] == i)return j;}return -1;}int goto_char(HWND hwnd,status *status_p,symbol_instr *instr_p){char x;int y,z;x = get_top2(hwnd,instr_p); //输入栈的内容y = get_top1(hwnd,status_p); //状态栈栈顶内容z = get_index_char(x); //得到i，*等相当于二维数组return table[y][z];}void action(HWND hwnd,status *status_p,symbol_instr *symbol_p,symbol_instr *instr_p){int i,j,x;char a;i = goto_char(hwnd,status_p,instr_p);//规约出错if(i == -1)MessageBox(hwnd,TEXT("规约出错!"),TEXT("结束"),MB_OK|MB_ICONEXCLAMATION);//规约成功if(i == 12){MessageBox(hwnd,TEXT("规约成功!"),TEXT("结束"),MB_OK|MB_ICONEXCLAMATION);flag=1;}//移进动作if(i>=0 && i<=11){push1(hwnd,status_p,i);a = pop2(hwnd,instr_p);push2(hwnd,symbol_p,a);print(hwnd,status_p,symbol_p,instr_p);}//规约动作if(i>=21 && i<=26){x = r[i-21].y;for(j=0;j<x;j++){pop1(hwnd,status_p);pop2(hwnd,symbol_p);}push2(hwnd,instr_p,r[i-21].x);SetDlgItemText(hwnd,IDC_EDIT4,str2[i-21]);}}void CALLBACK TimerProc(HWND hwnd,UINT message,UINT iTimerID,DWORD dwTime) {SYSTEMTIME stLocal;TCHAR buf[256];GetLocalTime(&stLocal);wsprintf(buf,"%d年%d月%d 日%d:%d:%d",stLocal.wYear,stLocal.wMonth,stLocal.wDay,stLocal.wHour,stLocal.wM inute,stLocal.wSecond);SetDlgItemText(hwnd,IDC_EDIT5,buf);}BOOL Main_OnInitDialog(HWND hwnd, HWND hwndFocus, LPARAM lParam){SetTimer(hwnd,0,1000,TimerProc);return TRUE;}status *status_p=new status;symbol_instr *symbol_p=new symbol_instr;symbol_instr *instr_p=new symbol_instr ;void Main_OnCommand(HWND hwnd, int id, HWND hwndCtl, UINT codeNotify){switch(id){case IDC_BUTTON1:{init_stack1(hwnd,status_p); //初始化各栈init_stack2(hwnd,symbol_p);init_stack2(hwnd,instr_p);//压进栈初始元素push1(hwnd,status_p,0);push2(hwnd,symbol_p,'#');char x;TCHAR msg[256];GetDlgItemText(hwnd,IDC_EDIT3,msg,sizeof(msg));unsigned int i;for(i=0;i < strlen(msg);i++)push2(hwnd,symbol_p,msg[i]);//然后由符号栈弹出，压进输入栈while( symbol_p->top2 != 0){x = pop2(hwnd,symbol_p);push2(hwnd,instr_p,x);}print(hwnd,status_p,symbol_p,instr_p);//打印初始分析表*/ }break;case IDC_BUTTON2:{action(hwnd,status_p,symbol_p,instr_p);}break;case IDC_BUTTON3:{SetDlgItemText(hwnd,IDC_EDIT1,TEXT(""));SetDlgItemText(hwnd,IDC_EDIT2,TEXT(""));SetDlgItemText(hwnd,IDC_EDIT3,TEXT(""));SetDlgItemText(hwnd,IDC_EDIT4,TEXT(""));}break;default:break;}}void Main_OnClose(HWND hwnd){EndDialog(hwnd, 0);}四：实验结果（1）当输入i*i+i#时最终弹出规约成功的对话框：（2）当输入ii*i#时，最终会弹出规约出错的对话框如下：。
