金工实习英文讲义-线切割
金工实习报告总结线切割
一、实习背景线切割是一种常用的金属加工方法,通过高压电火花放电,使工件表面产生微小切割,从而实现金属材料的切割。
在本次金工实习中,我有幸学习了线切割技术,了解了其原理和操作方法。
二、实习目的1. 掌握线切割的基本原理和操作方法;2. 培养动手能力和实际操作技能;3. 了解线切割在机械加工中的应用。
三、实习内容1. 线切割原理线切割是利用高压电火花放电,使工件表面产生微小切割的一种加工方法。
放电过程中,电极丝和工件之间产生电弧,电弧热量使工件表面熔化,熔化物质被电极丝带走,从而实现切割。
2. 线切割设备线切割设备主要由电源、控制系统、伺服电机、线切割机床等组成。
其中,伺服电机负责电极丝的进给运动,控制系统负责整个线切割过程的控制。
3. 线切割操作(1)装夹工件:将工件放置在线切割机床的工作台上,用卡具固定。
(2)设置参数:根据工件材料、形状和尺寸,设置合适的切割速度、放电电流、进给速度等参数。
(3)编程:编写线切割程序,将工件轮廓信息输入控制系统。
(4)启动线切割:按下启动按钮,控制系统开始执行线切割程序。
(5)观察和调整:在切割过程中,观察切割效果,根据实际情况调整参数。
4. 线切割应用线切割广泛应用于模具加工、航空航天、电子电器等行业。
其主要优点包括:(1)加工精度高,可达0.01mm;(2)可加工复杂形状的工件;(3)加工速度快,生产效率高;(4)可加工多种金属材料。
四、实习心得1. 通过本次实习,我对线切割技术有了较为全面的了解,掌握了线切割的基本原理和操作方法。
2. 实践过程中,我深刻体会到理论知识的重要性。
在设置参数和编程时,需要充分了解工件材料、形状和尺寸等信息,才能保证线切割质量。
3. 线切割操作过程中,安全意识至关重要。
在操作线切割设备时,要严格遵守操作规程,防止意外事故发生。
4. 线切割技术在实际生产中具有广泛的应用,为我国制造业的发展做出了重要贡献。
五、总结本次金工实习使我受益匪浅,不仅掌握了线切割技术,还提高了自己的动手能力和实际操作技能。
《金工实习A》教学大纲(试行)
《金工实习A》教学大纲(试行)一、课程基本信息开课单位现代工程训练中心课程代码GE09039课程名称金工实习A英文名称Metalworking practice A课程性质必修学分2总学时64先修课程工程制图、工程材料开课学期夏季适应专业近机近电类专业、2+X项目制训练中基础训练部分二、课程描述中文:金工实习A是一门涵盖机械、电气、控制、管理等多学科集成的具有多层次、多模块、柔性化的实践性技术基础课,是近机械类有关专业教学计划中重要的实践教学环节之一。
本课程以实践教学为主,安排学生进行独立操作,并辅以专题讲授。
学生通过工程基本训练,获取先进的、系统的、视野宽阔的大工程知识背景,建立典型的制造业生产过程概念,培养工程素质、工程实践能力和创新能力。
为后续课程的学习和今后的工作奠定基础。
英文:Metalworking practice A, as one of the most important practical teaching part in teaching plan of near-mechanical-related majors, is a multi-level, multi-module and flexible practical basic course covering various subjects, including mechanical, electrical, control and management. This course is mainly based on practical teaching toarrange students to do operations independently, and specialized lectures would be supplemented as assistance when necessary. Through the basic training of engineering, students can obtain advanced, systematic, and broaden knowledge background of engineering, establish concept of typical manufacturing process, develop their engineering quality, practical ability, and creativity. The course can lay the foundation for students’further study and future work.课程内容(一)课程教学目标1、了解现代机械制造的一般过程。
金工实习英文讲义-磨工
Mechanical Engineering TrainingGrindingName:Student NO.:Date:1. Introduction to GrindingGrinding is an abrasive machining process that uses a grinding wheel as the cutting tool.A wide variety of machines are used for grinding:(1) Hand-cranked knife-sharpening stones (grindstones)(2) Handheld power tools such as angle grinders and die grinders(3) Various kinds of expensive industrial machine tools called grinding machines(4) Bench grinders often found in residential garages and basementsGrinding practice is a large and diverse area of manufacturing and toolmaking. It can produce very fine finishes and very accurate dimensions; yet in mass production contexts it can also rough out large volumes of metal quite rapidly. It is usually better suited to the machining of very hard materials than is "regular" machining (that is, cutting larger chips with cutting tools such as tool bits or milling cutters), and until recent decades it was the only practical way to machine such materials as hardened steels. Compared to "regular" machining, it is usually better suited to taking very shallow cuts, such as reducing a shaft’s d iameter by half a thousandth of an inch or 12.7 μm.Grinding is a subset of cutting, as grinding is a true metal-cutting process. Each grain of abrasive functions as a microscopic single-point cutting edge, and shears a tiny chip that is analogous to what would conventionally be called a "cut" chip (turning, milling, drilling, tapping, etc.). However, among people who work in the machining fields, the term cutting is often understood to refer to the macroscopic cutting operations, and grinding is often mentally categorized as a "separate" process. This is why the terms are usually used in contradistinction in shop-floor practice, even though, strictly speaking, grinding is a subset of cutting.In this training course, considering the availability of required equipment in the training center, we will focus on the training of metal casting methods.2. Types of Grinding ProcessSelecting which of the following grinding operations to be used is determined by the size, shape, features and the desired production rate.Surface GrindingSurface grinding uses a rotating abrasive wheel to remove material, creating a flat surface. The tolerances that are normally achieved with grinding are ± 2 × 10−4 inches for grinding a flat material, and ± 3 × 10−4 inches for a parallel surface (in metric units: 5 μm for flat material and 8 μm for parallel surface).The surface grinder is composed of an abrasive wheel, a workholding device known as a chuck, either electromagnetic or vacuum, and a reciprocating table.Typical workpiece materials include cast iron and steel. These two materials do not tend to clog the grinding wheel while being processed. Other materials are aluminum, stainless steel, brass and some plastics. The photo of a surface grinding machine is shown in Figure 1. The machine you are going to use in this training course is the surface grinding machine. You will learn about the working principles of the machine and manipulate the machine to grind a workpiece according to a technical drawing.Figure 1 Surface grinding machineCylindrical GrindingCylindrical grinding (also called center-type grinding) is used to grind the cylindrical surfaces and shoulders of the workpiece. The workpiece is mounted on centers and rotated by a devise known as a drive dog or center driver. The abrasive wheel and the workpiece are rotated by separate motors and at different speeds. The table can be adjusted to produce tapers. The wheel head can be swiveled.The five types of cylindrical grinding are: outside diameter (OD) grinding, inside diameter (ID) grinding, plunge grinding, creep feed grinding, and centerless grinding.A cylindrical grinder has a grinding (abrasive) wheel, two centers that hold the workpiece, and a chuck, grinding dog, or other mechanism to drive the work. Most cylindrical grinding machines include a swivel to allow for the forming of tapered pieces. The wheel and workpiece move parallel to one another in both the radial and longitudinal directions. The abrasive wheel can have many shapes. Standard disk shaped wheels can be used to create a tapered or straight workpiece geometry while formed wheels are used to create a shaped workpiece. The process using a formed wheel creates less vibration than using a regular disk shaped wheel.Tolerances for cylindrical grinding are held within five ten-thousandths of an inch (+/- 0.0005) (metric: +/- 13 um) for diameter and one ten-thousandth of an inch (+/- 0.0001) (metric: 2.5 um) for roundness. Precision work can reach tolerances as high as fifty millionths of an inch (+/- 0.00005) (metric: 1.3 um) for diameter and ten millionths (+/- 0.00001) (metric: 0.25 um) for roundness. Surface finishes can range from 2 to 125 micro-inches (metric: 50 nm to 3 um), with typical finishes ranging from 8-32 micro-inches. (metric: 0.2 um to 0.8 um)Figure 2 shows a cylindrical grinding machine.Figure 2 Cylindrical grinding machine3. Working Principle of the Surface Grinding MachineFigure 3 Structure of a surface grinding machineAs can be seen in Figure 3, the surface grinding machine consists of a table with a fixture to guide and hold the work piece, and a power-driven grinding wheel spinning at the required speed. The speed is determined by the wheel’s diameter and manufacturer’s rating. The grinding wheel can travel across a fixed work piece, or the work piece can be moved while the grind wheel stays in a fixed position. The work piece is usually firmlyfixed on the table through electromagnetic power to make sure it won’t move under the rotatory force of the grinding wheel. So when we say the work piece moves, we actually mean the table that fixes the work piece moves.Fine control of the grinding head or table position is possible using a vernier calibrated hand wheel. From Figure 3, we can see there are three hand wheels, in which the Longitudinal Feed Hand Wheel controls the longitudinal movement of the table, the Cross Feed Hand Wheel controls the horizontal movement of the table while the Vertical Feed Hand Wheel controls the vertical movement of the grinding head. With the hand wheels, we can precisely control the amount of material to be removed and finally meet the technical requirement.Figure 4 The grinding processAs can be seen form Figure 4, the Grinding machine removes material from the surface of the workpiece by abrasion, which can generate substantial amounts of heat. To cool the work piece so that it does not overheat and go outside its tolerance, grinding machines incorporate a coolant. The coolant also benefits the machinist as the heat generated may cause burns. During the grinding process, the coolant is continuously supplied to the grinding wheel where it contacts the workpiece to remove the heat.4. Grinding WheelA grinding wheel is an expendable wheel that is composed of an abrasive compound used for various grinding (abrasive cutting) and abrasive machining operations. The wheels are generally made from a matrix of coarse particles pressed and bonded together to form a solid, circular shape. Various profiles and cross sections are available depending on the intended usage for the wheel. They may also be made from a solid steel or aluminum disc with particles bonded to the surface. Figure 5 shows the photo of a grinding wheel that is used in the surface grinding machine.Figure 5 Grinding wheelThe manufacture of these wheels is a precise and tightly controlled process, due not only to the inherent safety risks of a spinning disc, but also the composition and uniformity required to prevent that disc from exploding due to the high stresses produced on rotation.Common materials for manufacturing grinding wheels include: Aluminum Oxide, Silicon Carbide, Ceramic, Diamond and Cubic Boron Nitride. Grinding wheels with diamond or Cubic Boron Nitride (CBN) grains are called super-abrasives. Grinding wheels with Aluminum Oxide (corundum), Silicon Carbide or Ceramic grains are called conventional abrasives.5. Use of the MicrometerIn the training practice, you are supposed to grind the workpiece according to a technical drawing where size and tolerance of the finished workpiece are specified. Your finished workpiece must conform to all the specifications in the technical drawing. Therefore, in order to check if the workpiece is qualified, you have to learn about the use of the micrometer.A micrometer, sometimes known as a micrometer screw gauge, is a device incorporating a calibrated screw widely used for precise measurement of components in mechanical engineering and machining as well as most mechanical trades. Micrometers are usually, but not always, in the form of calipers (opposing ends joined by a frame), which is why micrometer caliper is another common name. The spindle is a very accurately machined screw and the object to be measured is placed between the spindle and the anvil. The spindle is moved by turning the ratchet knob or thimble until the object to be measured is lightly touched by both the spindle and the anvil. Figure 6 shows a micrometer.Figure 6 The micrometerBut how to read the micrometer? Let us see an example in Figure 7.Figure 7 Micrometer thimble reading 5.78mmThe spindle of an ordinary metric micrometer has 2 threads per millimeter, and thus one complete revolution moves the spindle through a distance of 0.5 millimeter. The longitudinal line on the frame is graduated with 1 millimeter divisions and 0.5 millimeter subdivisions. The thimble has 50 graduations, each being 0.01 millimeter (one-hundredth of a millimeter). Thus, the reading is given by the number of millimeter divisions visible on the scale of the sleeve plus the particular division on the thimble which coincides with the axial line on the sleeve.Suppose that the thimble were screwed out so that graduation 5, and one additional 0.5 subdivision were visible (as shown in Figure 7), and that graduation 28 on the thimble coincided with the axial line on the sleeve. The reading then would be 5.00 + 0.5 + 0.28 = 5.78 mm.6. Training PracticeIn this training course, you are supposed to grind the workpiece according to a technical drawing. The drawing will be given to you in class, so before you start working, first read the drawing carefully and make sure you have understood all the specifications on the drawing. Then following the guidance of the teacher, you can manipulate the grinding machine. When you have finished, use the micrometer to check if the workpiece meets the specifications, if not, you have to repeat the process until the specifications are all met.7. Safety Rules(1) The grinding wheel rotates in a very high speed, so do not try to use your hands totouch the wheel or workpiece when the machine is running.(2) Sparks may occur when the grinding machine is working, so you shall stay awayfrom the end of the machine to avoid being burnt.(3) After the workpiece is finished, do not try to pick it up with bare hand. Gloves areneeded in case you get your fingers injured by the heat from the workpiece.。
《金工实习》课程教学大纲
《金工实习》课程教学大纲课程名称:金工实习课程代码:ELEA1036英文名称:Metalworking Practice课程性质:大类基础课程学分/学时:1.5学分/2周开课学期:第3学期适用专业:电气工程及其自动化、热能与动力工程专业、建筑环境与设备工程专业、测控技术与仪器专业、电子信息工程专业、通信工程专业等先修课程:无后续课程:企业生产实习、自动化综合实践、毕业设计开课单位:工程训练中心课程负责人:谢志余大纲执笔人:周新弘大纲审核人:余雷一、课程性质和教学目标(在人才培养中的地位与性质及主要内容,指明学生需掌握知识与能力及其应达到的水平)课程性质:金工实习(工程训练)是一门实践性的技术基础课程,是非机械类有关专业教学计划中重要的实践教学环节之一。
本课程应安排学生进行独立操作,并辅以专题讲授。
学生通过实习获得机械制造的基本知识,建立机械制造生产过程的概念;在培养一定操作技能的基础上增强学生的工程实践能力;在劳动观点、创新意识、理论联系实际的科学作风等基本素质方面受到培养和锻炼;为了解制造领域的工程文化、学习后续课程和今后的工作打下一定的实践基础。
教学目标:修本课程前,学生应具备一定的读图、识图、制图能力。
以便使学生在实习过程中,能根据图纸,独立完成加工制做任务。
机械制造工程训练与工程材料、机械制造基础、机械设计等课程有着深刻的联系,须统筹考虑课程之间的衔接和配合。
机械制造工程训练以实践教学为主,学生应能进行独立的基本实践操作,在训练过程中要有机结合基本工艺理论知识和实践,在保证贯彻教学基本要求的前提下,尽可能结合生产进行,培养学生创造、创新能力。
本课程的具体教学目标如下:1.了解机械制造工艺知识。
了解机械制造的一般过程和基本的概念;学习机械制造基本工艺知识,对简单零件初步具有选择加工方法和进行工艺分析的能力;了解所用主要设备的工作原理、典型结构及主要工夹量具的使用;了解新工艺、新技术在机械制造中的应用;掌握机械制造有关安全操作技术;2.接受基本工程素质教育。
金加工英语学习概述
Aabrasion n. 磨料,研磨材料,磨蚀剂, a. 磨损的,磨蚀的aalign n. 找中(心),找正,对中,对准,找平,调直,校直,调整,调准angle milling cutter n. 角铣刀angular grinding n. 斜面磨削,斜磨法angular milling n. 斜面铣削angular plunge grinding n. 斜向切入磨削angular turning n. 斜面车削arbour n. 刀杆,心轴,柄轴,轴,辊轴attachment n. 附件,附件机构,联结,固接,联结法automatic bar machine n. 棒料自动车床automatic boring machine n. 自动镗床automatic copying lathe n. 自动仿形车床automatic double-head milling machine n. 自动双轴铣床automatic lathe n. 自动车床automatic turret lathe n. 自动转塔车床Bbelt grinding machine n. 砂带磨床bench lathe n. 台式车床bevel n. 斜角,斜面,倾斜,斜切,斜角规,万能角尺,圆锥的,倾斜的,斜边,伞齿轮,锥齿轮bborehole n. 镗孔,镗出的孔,钻眼boring n. 镗孔,钻孔,穿孔boring fixture n. 镗孔夹具boring machine n. 镗床boring tool n. 镗刀boring, drilling and milling machine n. 镗铣床broaching machine n.拉床,铰孔机,剥孔机broaching tool n. 拉刀broad finishing tool n. 宽刃精切刀,宽刃精车刀,宽刃光切刀CCalibrate vt. 校准[正],刻度,分度,检查[验],定标,标定,使标准化,使符合标准cam contour grinder n. 凸轮仿形磨床carbide tip n. 硬质合金刀片carbide turning tool n. 硬质合金车刀carbide-tipped tool n. 硬质合金刀具cast iron machining n. 铸铁加工,铸铁切削加工centerless cylindrical grinder n. 无心外圆磨床ceramic cutting tool n. 金属陶瓷刀具chamfer n.;vt. 倒角,倒棱chamfered cutting edge n. 倒角刀刃champing fixture n. 快换夹具champing jaw n. 快换卡爪chaser n. 螺纹梳刀,梳刀盘,板牙chatter vi.;n. 振动,振荡,震颤,刀振cherry n.;a. 樱桃,鲜红的,樱桃木制的chip n. 切屑,铁屑,刀片,刀头,片,薄片,芯片,chip breaker groove radius n. 断屑槽底半径,卷屑槽底半径chip clearance n. 切屑间隙chip cross-sectional area n. 切屑横截面面积chip curl n. 螺旋形切屑chip flow n. 切屑流chip formation n. 切屑形成chip removing process n. 去毛刺加工chip variable n. 切屑变量chuck n. 卡盘,夹盘,卡头,[电磁]吸盘,vt. 固定,装卡,夹紧,卡住chucker n. 卡盘车床,卡角车床circular drillling machine n. 圆工作台钻床contour milling n. 成形铣削,外形铣削,等高走刀曲面仿形法convex milling attachment n. 凸面铣削附件convex turning attachment n. 中凸车削附件,凸面车削附件coolant lubricant n. 冷却润滑剂coolant lubricant emulsion n. 冷却润滑乳液[剂]copy n. 样板,仿形,靠模工作法,拷贝复制品,v. 复制,模仿,抄录copy grinding n. 仿形磨床copy-mill n. 仿形铣copying turret lathe n. 仿形转塔车床corner n. 角,弯[管]头,弯管counterbore n. 埋头孔,沉孔,锥口孔,平底扩孔钻,平底锪钻, n.;vt. 扩孔,锪孔,镗孔,镗阶梯孔crankshaft grinding machine n. 曲轴磨床crankshaft turning lathe n. 曲轴车床creep feed grinding n. 缓进给磨削cross milling n. 横向铣削curly chip n. 卷状切屑,螺旋形切屑,切屑螺旋cut v.;n. 切削[割],口,片,断,断开,削减,减少,断面,剖面,相交,凹槽cut off n. 切断[开,去],关闭,停车,停止,断开装置,断流器,挡板,截止,截流cut teeeth n. 铣齿cut-off grinding n. 砂轮截断,砂轮切割cutter n. 刀具,切削工具,截断器,切断器,切断机cutting n. 切削,切片,切割,切屑,金属屑,截槽cutting edge profile n. 切削刃轮廓[外形,断面],切削刃角度cutting force n. 切削力cutting lip n. 切削刃,刀刃,钻唇,钻刃cutting operation n. 切削加工,切削操作,切削作业cutting rate n. 切削效率,切削速率cutting tool n. 刀具,切削工具,刃具cycle n. 周期,周,循环,一个操作过程,轮转,自行车cylindrical grinder n. 外圆磨床Ddeep-hole drilling n.深孔钻削deep-hole milling n. 深孔铣削design n. 设计,计算,计划,方案,设计书,图纸die-sinking n. 凹模dimension n. 尺寸,尺度,维度,量纲,因次direction of the feed motion n. 进给方向,进刀方向discontinuous chip n. 间断切屑distance n. 距离,间隔[隙],长度,vt. 隔开Eedge point n. 刀口,刀刃efficiency n. 效率,效能,性能,功率,产量,实力,经济性,有[功,实]效end mill n. 立铣刀external grinding n. 外圆磨削Fface n. 表面,外观,工作面,表盘,屏,幕v. 面向,朝向,表面加工,把表面弄平face grinding machine n. 平面磨床face milling machine n. 端面磨床feed force n. 进给力feed motion n. 进给运动fine adjustment n. 精调,细调,微调fGgap n. 间隔,间隙,距离,范围,区间,缺口,开口火花隙,vt. 使产生裂缝vi. 豁开gear cutting machine n. 齿轮加工机床,切齿机gear generating grinder n. 磨齿机gear hob n. 齿轮滚刀grinding cutter n. 磨具grinding force n. 磨削力grinding machine n. 磨床grinding wheel diameter n. 砂轮直径grinding wheel width n. 砂轮宽度groove n. 槽,切口,排屑槽,空心槽,坡口,vt. 切[开,铣]槽groove milling n.铣槽Hheadstock spindle n. 床头箱主轴,主轴箱主轴,头架轴helical tooth system n. 螺旋齿轮传动装置high precision lathe n. 高精度车床high-speed n. 高速high-speed machining n. 高速加工hob n. 齿轮滚刀,滚刀,螺旋铣刀,v. 滚铣,滚齿,滚削Iinclination n.倾斜,斜度,倾角,斜角[坡],弯曲,偏[差,角]转increment n. 增量,增加,增[大]长indexing table automatic n. 自动分度工作台infeed grinding n. 切入式磨削installation n. 装置,设备,台,站,安装,设置internal grinding n. 内圆磨削involute hob n. 渐开线滚刀Jjig boring machine n. 坐标镗床Kkeyway cutting n. 键槽切削加工knurling tool n. 滚花刀具,压花刀具,滚花刀Llaedscrew machine n. 丝杠加工机床lap grinding n. 研磨lapping n. 研磨,抛光,精研,搭接,擦准lathe dog n. 车床轧头,卡箍,鸡心夹头,离心夹头,制动爪,车床挡块lathe tool n. 车刀level n. 水平,水准,水平线,水平仪,水准仪,电平,能级,程度,强度,a. 水平的,相等的,均匀的,平稳的loading time n. 装载料时间,荷重时间,充填时间,充气时间lock n. 锁,栓,闸,闭锁装置,锁型,同步,牵引,v. 闭锁,关闭,卡住,固定,定位,制动刹住longitudinal grinding n. 纵磨low capacity machine n. 小功率机床[机器]Mmachine axis n. 机床中心线machine table n. 机床工作台machine tool n. 机床,工作母机machining (or cutting) variable n. 加工(或切削)变量machining cycle n. 加工循环machining of metals n. 金属切削加工,金属加工NNose n. 鼻子,端,前端,凸头,刀尖,机头,突出部分,伸出部分number of revolutions n. 转数numerical control n. 数字控制numerically controlled lathe n. 数控车床Ooblique grinding n. 斜切式磨床operating cycle n. 工作循环operation n. 运转,操作,控制,工作,作业,运算,计算operational instruction n. 操作说明书,操作说明operational safety n. 操作安全性,使用可靠性oscillating type abrasive cutting machine n. 摆动式砂轮切割机oscillation n. 振动,振荡,摆动,颤振,振幅out-cut milling n. 切口铣削oxide ceramics n. 氧化物陶瓷oxide-ceramic cutting tool n. 陶瓷刀具Pperipheral grinding n. 圆周磨削peripheral speed n. 圆周速度,周速,边缘速度perpendicular a. 垂直的,正交的,成直角的n. 垂直,正交,竖直,垂线,垂直面profile n. 轮廓,形面,剖面,侧面图,分布图。
金工实习英文讲义-焊接
Mechanical Engineering TrainingWeldingName:Student NO.:Date:1. Introduction to WeldingWelding is a fabrication or sculptural process that joins materials, usually metals or thermoplastics, by causing coalescence. This is often done by melting the workpieces and adding a filler material to form a pool of molten material (the weld pool) that cools to become a strong joint, with pressure sometimes used in conjunction with heat, or by itself, to produce the weld. This is in contrast with soldering and brazing, which involve melting a lower-melting-point material between the workpieces to form a bond between them, without melting the work pieces.2. Types of Welding MethodsSome of the best known welding methods include:Shielded metal arc welding (SMAW) - also known as "stick welding", uses an electrode that has flux, the protectant for the puddle, around it. The electrode holder holds the electrode as it slowly melts away. Slag protects the weld puddle from atmospheric contamination. And this will be the focus of this training course.Gas tungsten arc welding (GTAW) - also known as TIG (tungsten, inert gas), uses a non-consumable tungsten electrode to produce the weld. The weld area is protected from atmospheric contamination by an inert shielding gas such as Argon or Helium.Gas metal arc welding (GMAW) - commonly termed MIG (metal, inert gas), uses a wire feeding gun that feeds wire at an adjustable speed and flows an argon-based shielding gas or a mix of argon and carbon dioxide (CO2) over the weld puddle to protect it from atmospheric contamination.Flux-cored arc welding (FCAW)- almost identical to MIG welding except it uses a special tubular wire filled with flux; it can be used with or without shielding gas, depending on the filler.Submerged arc welding (SAW) - uses an automatically fed consumable electrode and a blanket of granular fusible flux. The molten weld and the arc zone are protected from atmospheric contamination by being "submerged" under the flux blanket.Electroslag welding (ESW) - a highly productive, single pass welding process for thicker materials between 1 inch (25 mm) and 12 inches (300 mm) in a vertical or close to vertical position.3. The Shielded Metal Arc Welding ProcessShielded metal arc welding (SMAW) is one of the most common types of arc welding is; it is also known as manual metal arc welding (MMA) or stick welding. Electric current is used to strike an arc between the base material and consumable electrode rod, which is made of filler material (typically steel) and is covered with a coating flow that protects the weld area from oxidation and contamination by producing carbon dioxide (CO2) gas during the welding process. The electrode core itself acts as filler material, making a separate filler unnecessary.As can be seen from Figure 1, when the electrode rod contacts the base material, an arc will be stricken, which generates so much heat that the rod fuses. The coating flow on the external side of the rod will then produce CO2 to protect the weld area, while the fusedelectrode core will become the weld metal to put the base materials together. And the weld metal will be covered with a layer of solidified slag, which should be removed with a hammer when it cools down.1. Coating Flow2.Rod3.Shield Gas4.Fusion5.Base Material6. Weld Metal7.Solidified SlagFigure 1 The SMAW processThe process is versatile and can be performed with relatively inexpensive equipment, making it well suited to shop jobs and field work. An operator can become reasonably proficient with a modest amount of training and can achieve mastery with experience. Weld times are rather slow, since the consumable electrodes must be frequently replaced and because slag, the residue from the flux, must be chipped away after welding. Furthermore, the process is generally limited to welding ferrous materials, though special electrodes have made possible the welding of cast iron, nickel, aluminum, copper, and other metals.Figure 2 A worker carrying out the SMAW processFigure 2 shows a worker carrying out the SMAW process. We can see that he is wearing a helmet, a pair of thick gloves and a protection suit. And these will also be what you are supposed to be wearing when you are taking the training practice. During the process, there will be very strong lights that may make you feel dizzy and lose your sight for a while if you watch the light directly. So the helmet is used to protect your eyes from the strong light. Also, there will be quite a lot of sparks, the protection suit and gloves will protect you from being burnt.4. Training PracticeIn this training course, you are supposed to use SMAW to weld two separate iron plates together. First the teacher will give you a demonstration, you should watch carefully and pay attention to the details. Then each student will have to take the welding practice. Your scores will be given according to the quality of the weld joint.5. Safety Rules(1) Do remember to wear the helmet, gloves and the protection suit before you startwelding.(2) Keep the helmet always on when welding, do not use your eyes to look at thelights directly.(3) There is electricity in both the rod and the workbench, so do not use your barehand to touch either of them.(4) Do not point the rod to others or sway the rod around in case you or other peopleget hurt.。
金工实习英文讲义-激光切割
Mechanical Engineering TrainingLaser CuttingName:Student NO.:Date:1. Introduction to Laser CuttingLaser cutting is a technology that uses a laser to cut materials, and is typically used for industrial manufacturing applications, but is also starting to be used by schools, small businesses, and hobbyists. Laser cutting works by directing the output of a high-power laser most commonly through optics. The laser optics and CNC (computer numerical control) are used to direct the material or the laser beam generated. A typical commercial laser for cutting materials would involve a motion control system to follow a CNC or G-code of the pattern to be cut onto the material. The focused laser beam directed at the material, which then either melts, burns, vaporizes away, or is blown away by a jet of gas, leaving an edge with a high-quality surface finish. Industrial laser cutters are used to cut flat-sheet material as well as structural and piping materials.In 1965, the first production laser cutting machine was used to drill holes in diamond dies. This machine was made by the Western Electric Engineering Research Center. In 1967, the British pioneered laser-assisted oxygen jet cutting for metals. In the early 1970s, this technology was put into production to cut titanium for aerospace applications. At the same time CO2 lasers were adapted to cut non-metals, such as textiles, because, at the time, CO2 lasers were not powerful enough to overcome the thermal conductivity of metals.2. Working Principle of Laser Cutting ProcessFigure 1 Structure of a laser cutterFigure 1 shows the structure of a laser cutter. Inside the cutter, generation of the laser beam involves stimulating a lasing material by electrical discharges or lamps within a closed container. As the lasing material is stimulated, the beam is reflected internally bymeans of a partial mirror, until it achieves sufficient energy to escape as a stream of monochromatic coherent light. Mirrors or fiber optics are typically used to direct the coherent light to a lens, which focuses the light at the work zone. The narrowest part of the focused beam is generally less than 0.0125 inches (0.32 mm) in diameter. Depending upon material thickness, kerf widths as small as 0.004 inches (0.10 mm) are possible. In order to be able to start cutting from somewhere else than the edge, a pierce is done before every cut. Piercing usually involves a high-power pulsed laser beam which slowly makes a hole in the material, taking around 5–15 seconds for 0.5-inch-thick (13 mm) stainless steel, for example.The movement of the cutter is controlled by a CNC device through G-code commands. The G-code can be manually programmed or be automatically generated with certain CAM (Computer Aided Manufacturing) software. In this training course, you are supposed to use a software called CAXA to design a drawing yourself, generate the G-code for the drawing and import the G-code to the laser cutting machine to cut the drawing on a wood sheet.3. Advantages of Laser CuttingAdvantages of laser cutting over mechanical cutting include easier workholding and reduced contamination of workpiece (since there is no cutting edge which can become contaminated by the material or contaminate the material). Precision may be better, since the laser beam does not wear during the process. There is also a reduced chance of warping the material that is being cut, as laser systems have a small heat-affected zone. Some materials are also very difficult or impossible to cut by more traditional means.4. Types of Lasers Used in Laser CuttingThere are three main types of lasers used in laser cutting. The CO2 laser is suited for cutting, boring, and engraving. The neodymium (Nd) and neodymium yttrium-aluminium-garnet (Nd-YAG) lasers are identical in style and differ only in application. Nd is used for boring and where high energy but low repetition are required. The Nd-YAG laser is used where very high power is needed and for boring and engraving. Both CO2 and Nd/ Nd-YAG lasers can be used for welding.5. Laser Cutting MethodsThere are many different methods in cutting using lasers, with different types used to cut different material. Some of the methods are vaporization, melt and blow, melt blow and burn, thermal stress cracking, scribing, cold cutting and burning stabilized laser cutting. Vaporization cuttingIn vaporization cutting the focused beam heats the surface of the material to boiling point and generates a keyhole. The keyhole leads to a sudden increase in absorptivity quickly deepening the hole. As the hole deepens and the material boils, vapor generated erodes the molten walls blowing ejecta out and further enlarging the hole. Non melting material such as wood, carbon and thermoset plastics are usually cut by this method. Melt and blowMelt and blow or fusion cutting uses high-pressure gas to blow molten material fromthe cutting area, greatly decreasing the power requirement. First the material is heated to melting point then a gas jet blows the molten material out of the kerf avoiding the need to raise the temperature of the material any further. Materials cut with this process are usually metals.Thermal stress crackingBrittle materials are particularly sensitive to thermal fracture, a feature exploited in thermal stress cracking. A beam is focused on the surface causing localized heating and thermal expansion. This results in a crack that can then be guided by moving the beam. The crack can be moved in order of m/s. It is usually used in cutting of glass.Stealth dicing of silicon wafersThe separation of microelectronic chips as prepared in semiconductor device fabrication from silicon wafers may be performed by the so-called stealth dicing process, which operates with a pulsed Nd:YAG laser, the wavelength of which (1064 nm) is well adopted to the electronic band gap of silicon (1.11 eV or 1117 nm). gReactive cuttingAlso called "burning stabilized laser gas cutting", "flame cutting". Reactive cutting is like oxygen torch cutting but with a laser beam as the ignition source. Mostly used for cutting carbon steel in thicknesses over 1 mm. This process can be used to cut very thick steel plates with relatively little laser power.6. Training PracticesIn this training course, you are supposed to use a software called CAXA to design a drawing yourself, generate the G-code for the drawing and import the G-code to the laser cutting machine to cut the drawing on a wood sheet.The computer room is on the third floor of the training center, where you can use the software. The software is in Chinese, but don’t worry, the teacher and TA there will tell you how to use the functions in English. Once you have completed your drawing, you will have to upload it on the server so that you can download it on the computer where the laser cutting machine is. After the training, you can take the finished workpiece away as a souvenir.7. Safety RulesOne thing you have to pay attention to in this training course is that, do not put any part of your body in the laser cutting machine when it is still working. The powerful laser may burn the skin and cause injury.。
Lesson 27 metal-cutting process 金属切削加工 机械专业专业英语教学
Lesson 27 metal-cutting process 金属切削加工
A plane containing the directions of the primary motion and the feed motion is defined as the working plane(工作 平面), since it contains the motions responsible for the cutting action.
Lesson 27 metal-cutting process 金属切削加工
Feed The feed motion f is provided to the tool or the workpiece and, when added to the primary motion, leads to a repeated or continuous chip removal and the creation of the desired machined surface. The motion may proceed by steps or continuously. The feed speed vf is defined as the instantaneous velocity of the feed motion relative to the workpiece (at a selected point on the cutting edge).
Lesson 27 metal-cutting process 金属切削加工
Metal-cutting processes are extensively used in the manufacturing industry. They are characterized by the fact that the size of the original workpiece is sufficiently large that the final geometry can be circumscribed(外接)by it, and that the unwanted material is removed as chips, particles, and so on. The chips(去屑)are a necessary means(必要手段)to obtain the desired tolerances, and surfaces. The amount of scrap may vary from a few percent to 70%~80% of the volume of the original work material.
金工实习实验报告线切割
金工实习实验报告——线切割一、实习目的1. 了解线切割机床的结构及工作原理,掌握线切割加工的基本操作方法。
2. 学会使用线切割机床进行零件加工,提高动手能力和实际操作技能。
3. 掌握线切割加工工艺参数的选择,提高加工质量和效率。
二、实习内容1. 线切割机床的结构及工作原理2. 线切割加工的基本操作方法3. 线切割加工工艺参数的选择4. 线切割加工实践三、实习过程1. 线切割机床的结构及工作原理线切割机床主要由控制系统、机床本体、切割线、工件和夹具等部分组成。
线切割机床的工作原理是利用高压水泵将细丝(切割线)喷射到工件表面,通过改变切割线与工件表面的相对位置,实现对工件的切割加工。
2. 线切割加工的基本操作方法(1)准备工作:打开线切割机床,检查各部分是否正常,确认电源、水源、气源是否畅通。
(2)装夹工件:将工件装夹在夹具上,保证工件位置准确。
(3)调整切割参数:根据工件材料、厚度等参数,选择合适的线径、切割速度、电流等参数。
(4)开始切割:启动机床,让切割线与工件表面接触,进行切割加工。
(5)加工过程中注意事项:随时关注切割情况,防止切割线断裂、断丝等情况发生。
如发现异常,立即停机处理。
(6)结束切割:达到所需切割尺寸后,停止机床,取出工件。
3. 线切割加工工艺参数的选择线切割加工工艺参数的选择主要包括线径、切割速度、电流等。
线径的选择取决于工件材料和厚度,切割速度和电流的选择则会影响切割质量和效率。
一般来说,线径越大,切割速度越慢,电流越大,切割质量越好。
但也要注意,线径过大、切割速度过慢、电流过大会导致切割效率降低,反之则可能导致切割质量不佳。
4. 线切割加工实践根据实习要求,选择合适的线切割机床和工艺参数,进行实际操作。
以加工一个矩形工件为例,首先进行准备工作,然后装夹工件,调整切割参数,开始切割,期间注意观察切割情况,防止异常发生。
最后结束切割,取出工件。
四、实习总结通过线切割实习,我对线切割机床的结构及工作原理有了更深入的了解,掌握了线切割加工的基本操作方法,学会了选择合适的工艺参数。
金工实习报告关于线切割
一、实习背景线切割是一种高精度、高效率的金属加工方法,广泛应用于模具制造、精密零件加工等领域。
为了深入了解线切割工艺,提高自身的实践能力,我参加了本次金工实习,通过实际操作,掌握线切割的基本原理、操作方法及注意事项。
二、实习过程1. 线切割机床的认识实习开始,我们先对线切割机床进行了详细的了解。
线切割机床主要由机床本体、脉冲电源、数控装置、工作台、夹具、电极丝等组成。
机床本体采用框架结构,稳定性好;脉冲电源产生高压脉冲电流,使电极丝与工件之间产生电火花,实现切割;数控装置接受输入的编程指令,控制机床的运动。
2. 线切割工艺原理线切割加工是利用细金属丝(如钼丝)作为电极,在脉冲电源的作用下,电极丝与工件之间产生电火花,使工件被切割。
电极丝在数控装置的控制下,按照预定的轨迹运动,从而实现对工件的切割。
3. 线切割操作方法(1)电极丝的准备:根据工件材料、尺寸和形状,选择合适的电极丝,并对其进行清洗、润滑处理。
(2)工件装夹:将工件固定在工作台上,确保工件与电极丝之间的距离适中。
(3)编程:根据工件图纸,编写数控程序,输入数控装置。
(4)启动机床:开启脉冲电源和数控装置,开始线切割加工。
(5)观察与调整:在加工过程中,密切观察工件表面和电极丝状态,根据实际情况调整加工参数。
4. 注意事项(1)确保安全:操作线切割机床时,要严格遵守安全操作规程,佩戴防护眼镜和绝缘手套。
(2)电极丝的选择:根据工件材料、尺寸和形状,选择合适的电极丝,以确保加工质量。
(3)编程精度:编程时,要确保程序准确无误,避免出现错误。
(4)加工参数的调整:根据工件尺寸精度要求,合理调整加工参数,如脉冲宽度、脉冲间隔等。
三、实习收获通过本次金工实习,我对线切割工艺有了更深入的了解,掌握了线切割机床的操作方法及注意事项。
以下是我在实习过程中的收获:1. 提高了实践能力:通过实际操作,将理论知识与实际生产相结合,提高了自身的实践能力。
2. 增强了团队协作意识:在实习过程中,与同学们互相学习、互相帮助,增强了团队协作意识。
金工实习实训报告线切割
金工实习实训报告——线切割一、实习背景与目的随着我国制造业的快速发展,线切割技术在机械加工领域中的应用日益广泛。
为了提高我国机械专业人才的实践操作能力,强化理论知识与实际操作的相结合,我国高校纷纷将线切割技术纳入金工实习课程。
本次实习报告旨在通过对线切割设备的操作与实践,使学生对线切割技术有更深入的了解,提高学生的动手能力与工程实践能力。
二、实习内容与过程1. 实习前的准备在实习开始前,我们参加了线切割安全培训,了解了线切割设备的基本原理、操作规程及安全注意事项。
同时,我们还学习了线切割工艺参数的选择、工件装夹、编程等方面的知识。
2. 实习过程实习过程中,我们分为若干小组,每组分配一台线切割设备。
在指导老师的带领下,我们逐步学习了线切割设备的操作。
首先,我们对工件进行装夹,确保工件在切割过程中保持稳定。
然后,根据工件的形状和尺寸,我们选择了合适的线切割工艺参数,包括切割速度、电流、脉冲宽度等。
接下来,我们通过线切割编程软件编写加工程序,并对程序进行调试。
最后,我们启动设备,进行线切割加工。
3. 实习成果通过实习,我们成功完成了多个线切割加工任务,包括不同形状和尺寸的工件。
在操作过程中,我们掌握了线切割设备的基本操作方法,了解了线切割工艺参数对切割效果的影响。
同时,我们学会了如何处理线切割过程中遇到的问题,如断丝、加工精度不达标等。
三、实习收获与反思1. 收获(1)掌握了线切割设备的基本操作方法;(2)了解了线切割工艺参数的选择方法及影响因素;(3)学会了如何处理线切割过程中的问题;(4)提高了动手能力与工程实践能力。
2. 反思(1)实习过程中,我们对线切割设备的安全注意事项掌握不够到位,需要在今后的工作中加强安全意识;(2)在编程与调试加工程序时,我们出现了一些失误,需要提高自己的编程与调试能力;(3)实习时间较短,我们对线切割技术的理解还有待加深,需要继续学习与实践。
四、总结通过本次线切割实习,我们不仅掌握了线切割设备的基本操作方法,还对线切割工艺有了更深入的了解。
金工实习报告关于线切割
一、实习背景线切割技术是一种重要的金属加工方法,具有加工精度高、表面质量好、生产效率高等优点,广泛应用于模具制造、航空航天、汽车制造等领域。
为了深入了解线切割技术,提高自己的实践能力,我在大学期间参加了金工实习,重点学习了线切割工艺。
二、实习目的1. 掌握线切割的基本原理和操作方法;2. 熟悉线切割设备的使用和维护;3. 培养实际操作能力和团队协作精神;4. 提高自己的动手能力和创新能力。
三、实习过程1. 线切割原理及设备线切割技术是利用高压脉冲电流使金属丝在工件表面产生电火花,使工件材料迅速熔化、气化,从而实现金属材料的切割。
线切割设备主要由脉冲电源、伺服控制系统、工作台、金属丝等部分组成。
2. 线切割工艺(1)加工前的准备工作:首先,根据工件图纸确定切割路径,然后选择合适的金属丝和切割参数。
金属丝的选择要根据工件材料的性质和切割速度来决定。
切割参数包括脉冲宽度、脉冲间隔、切割速度等。
(2)装夹工件:将工件放置在工作台上,调整工件位置,使其与金属丝保持适当的距离。
装夹工件时要注意工件定位精度,确保切割质量。
(3)编程与调试:根据切割路径编写控制程序,输入到线切割设备中。
调试程序时,要确保程序正确,并根据实际情况调整切割参数。
(4)切割过程:启动线切割设备,进行切割。
在切割过程中,要注意观察切割效果,及时调整切割参数,确保切割质量。
(5)切割后的处理:切割完成后,清理工件表面残留的金属丝和氧化物,对工件进行清洗和检验。
3. 实际操作在实习过程中,我亲自操作了线切割设备,按照工艺要求完成了多个工件的切割。
在操作过程中,我学会了如何调整切割参数、如何排除故障、如何提高切割质量等。
四、实习体会1. 线切割技术具有很高的实用价值,能够满足多种加工需求。
2. 线切割工艺对操作人员的技能要求较高,需要掌握一定的理论知识和技术水平。
3. 实习过程中,我深刻体会到团队协作的重要性。
只有大家齐心协力,才能顺利完成实习任务。
金刚石线多线切割英文演讲稿
3.Key Points in Designing The Machine(Structure)
1.Stiffness of the basic parts should be enough to resist distortion. For example, the frame of the workroom is designed as a box. This shape can strength the stiffness, so that it can endure bigger load.
3.Key Points in Designing The Machine(Structure)
3.The moving parts in the workroom should be cooled down. In the part of the picture, there are many cooling circulation loops. Cool water can get through these loops.
4.Conclusion
1.Designing this machine is a process during which we must learn constantly. The complete machine is divided into three parts, so one of us is in charge of one parts. Must works have been done to coordinate. A lot of knowledges in special fields are strange to us, such as wire cut. It is not a traditional processing. 2.We must be patient enough. The conception model of the machine has been modified more than ten times from Augest 2011 to May 2012.
数控英文课件Unit 18 Wire-Cut EDM (1)
A direct current of low voltage and high amperage is delivered to the electrode at the rate of approximately 20,000 hertz (Hz).
这些电脉冲能量转变成电火花,通过电极和工件 之间的电介液放电。
在此句中,which引导的定语从句修饰sparks.句中, between the electrode and the workpiece和through the diee heat is created in the localized area of the spark impact; the metal melts and a small particle of molten metal is expelled from the workpiece. The dielectric fluid, which is constantly being circulated, carries away the eroded particles of metal and also helps in dissipating the heat caused by the spark.
工业中用到的电火花加工机床有两种类型:立 式主轴电火花加工机床和线切割电火花加工机床。 由于线切割电火花加工通常要进行数控编程来加工 复杂形状,此处将详细介绍这种类型。
Wire-cut EDM
The wire-cut EDM is a discharge machine which uses NC movement to produce the desired contour or shape on a part .It does not require a specialshaped electrode; instead, it uses a continuous traveling wire under tension as the electrode.
线切割使用方法流程
线切割使用方法流程Line cutting, also known as wire cutting or wire EDM, is a manufacturing process that uses a thin, electrically-charged wire to cut through metal. The process is precise and can produce intricate shapes with tight tolerances. 线切割,也称为线切割或线切割电火花加工,是一种利用薄的、带电的金属线切割金属的制造过程。
这个过程很精确,可以生产形状复杂、公差严格的零件。
The first step in the wire cutting process is to create a CAD model of the part to be cut. This model is then used to program the wire cutting machine to make the required cuts. 线切割的第一步是制作要切割的零件的CAD模型。
然后使用这个模型对线切割机进行程序编程,以实现所需的切割。
Once the machine is programmed, a spool of wire is threaded through the workpiece and connected to a power supply. As the wire is energized, it generates a spark that rapidly and precisely cuts through the metal. 一旦机器编程完成,就会通过工件中穿过一卷线,将它连接到电源。
当线得到激发时,它会产生一个火花,迅速而精确地切割金属。
One of the advantages of wire cutting is its ability to cut extremely hard materials, such as tungsten carbide, and create intricate shapes with tight tolerances. This makes it an ideal method for producing tooling components, extrusion dies, and other precision parts. 线切割的优点之一是它能够切割极硬的材料,如钨钢,以及制造具有严格公差的复杂形状。
