86.2%氧化亚铜的应用与混配技术一、产品特点86.2%氧化亚铜（绿亨铜师傅）由氧化亚铜原粉和高效分散助剂经国内领先的流化床气流粉碎机加工而成，其制剂细度2000目以上，悬浮率85%以上，各项技术指标达到国际先进水平。
不仅是国内企业独家登记的最高含量的铜制剂,而且已办理境外登记（喀麦隆和尼日尼亚），也是国家重点推荐的新产品和国家专利产品（专利号2011102072053）。
相比一般的铜制剂，使用本品更加安全，持效期达30天以上。
世界最高含铜量的杀菌剂！简单的化学结构：Cu-O-Cu，提供充足的杀菌活性物——铜离子。
氧化亚铜的铜含量为89%，可杀得的铜含量为65%。
铜离子的多少，决定杀菌活性和效果。
铜师傅为一价铜，可杀得是二价铜，杀菌时一价铜转化二价铜，所以铜师傅更加安全。
铜师傅是很稳定的含水系统，铜师傅的持效期更长。
铜师傅比可杀得性价比高。
作物病害由真菌、细菌或病毒三类病原体引发。
它们的生命组织中都有蛋白质，氧化亚铜释放出铜离子与真菌、细菌或病毒体内蛋白质中的-SH、 -N2H、-COOH、-OH等基团起作用，铜离子透过病原体细胞，能使蛋白质变性凝固。
导致病菌死亡。
氧化亚铜对多种病原微生物具有杀菌活性：（1）真菌类:鞭毛菌亚门、接合菌亚门、子囊菌亚门、担子菌亚门和半知菌亚门卵菌（2）细菌:球菌、杆菌和螺形菌(3)低等植物:藻类, 苔藓、地衣、附生植物和(4)低等软体动物蜗牛等。
(5)病毒；烟草花叶病毒、马铃薯病毒和黄瓜花叶病毒一药多能，兼防兼治。
对防治变异、产生抗性的病原体、疑难杂症更有突出的防治。
对果树、蔬菜、花卉、粮食等作物的常见病：炭疽病、溃疡病、霜霉病、叶斑病、锈病、疫病、枯萎病、猝倒病、疮痂病、立枯病、干腐病等都有较好的防治效果。
非选择性杀菌——杀菌广谱，理论上讲，只要用药方法正确，防治各种病害都有效。
氧化亚铜是带电的杀菌剂，氧化亚铜的微小颗粒正电，作物表面带负电荷，药剂与作物表面形成极强的电动势。
物理吸附力极强。
耐雨水冲刷，保证药剂发挥持久，可达30天，减少用药量。
非公害、无污染、与环境友好。
氧化亚铜在中国已经列为生产AA级绿色食品的农药，但是中国没有氧化亚铜的农药残留标准。
为了更好地服务中国蔬菜、果树等农产品出口基地用药。
支持基地的农产品出口工作。
配合国家及境外农药检测机构严格的检测。
公司委托国家农药质量监督检测中心做氧化亚铜的残留试验。
86.2%氧化亚铜残留试验报告结果：2011年在北京和南京两地残留试验结果86.2%氧化亚铜可湿性粉剂，用532-800倍液（1081-1621.5mg/kg)，施药3-4次，施药间隔10天，采收间隔期为7、14、21，收获葡萄中氧化亚铜的残留量0.450-9.958mg/kg)。
合理使用建议：施药量最高800倍液（1081mg/kg),最多施药3次，施药间隔期10天，安全间隔期14天）无抗药性。
抗药性产生的原因：一种农药在同一种作物上反复使用、经过一定时间后，药效就明显减退，甚至几乎无效，这种现象，就称病虫产生了抗药性。
抗药性的产生，迫使农民不得不增加药量和用药次数，这样又恰好形成了一种恶性升级现象。
而氧化亚铜可对同一防治对象长期、连续施药不用更换药物，不会产生抗药性，减少了频繁选择、变化用药的麻烦。
用量少、成本低。
制剂用量：800—2000倍液，苹果：2000—2500 倍液，同类产品400—800倍液。
一遍相当于同类杀菌剂2—3遍，至少直接降低成本30%以上。
补充铜元素。
86.2%氧化亚铜可补充铜元素，促进作物的营养生长和生殖生长，提高作物的产量和品质。
尤其在葡萄上比较明显。
二、应用与混配技术氧化亚铜的应用1、氧化亚铜具有保护和治疗双重作用，且持效期长达30天，提前施药，相当于给农作物表面“渡上”保护膜，预防各种真菌、细菌和病毒病对作物侵入。
这样减少了作物30%的用药量，达到事半功倍的效果。
易敏感期，耐药性低，防治苗期病害使用浓度不低于1500倍，1包10克铜师傅打1桶水，特别在十字花科作物苗期使用浓度不低于2000倍液（2包10克86.2%氧化亚铜打3捅水）盛花期，花落2/3，幼果期：不低于1500倍液。
2、果树的清园、开花前、芽前，高浓度施药。
不超过1000倍药液。
生长期尽量不用药，避免污染果面。
幼果期后，果面蜡质层形成， 1500倍液施药。
对铜离子敏感的作物：如桃、李、杏、柿、梅、枇杷和荸荠等，这些作物对铜离子比较敏感，不能喷雾，只能涂抹树干。
铜制剂禁止在果树花期和幼果期使用，其他时间都可以使用，冬春季稀释1000-1500倍液打干枝，防治轮纹病、腐烂病及其他真细菌性病害，套袋后可以放心的使用，防治葡萄霜霉病、柑橘溃疡病、苹果斑点落叶病防治效果突出，且持效期较长。
3、经各地的植保所和药检所关于86.2%氧化亚铜的试验结果来看，86.2%氧化亚铜不仅对葡萄霜霉病有很好的防治效果，而且对其他病害如黑豆病、白腐病都有很好的防效。
4、氧化亚铜1500--2500倍液施药，可以有效防止病害引发的各种落叶，如果营养失调和气候原因等引起的落叶现象，用氧化亚铜的同时，配合植物生长调节剂和其他物理防治方法，综合防治。
氧化亚铜的混配原则：1、可以与大部分的杀虫、杀菌剂及叶面肥使用。
根据客户的反馈和总结：氧化亚铜与市场上常见的如甲霜灵、杀毒矾、井冈霉素、多菌灵、代森锰锌（全络合态）、春雷霉素、多抗霉素、烯酰吗啉、霜脲氰、氰霜唑、银发利、中生菌素、链霉素、氟硅唑、毒死蜱、丁硫克百威、敌敌畏等大多数农药复配都比较安全，只要配药时注意二次稀释和时配时用原则就可以。
2、不能混用的有：(1)单一金属元素肥（所谓“单一元素肥”就是只含有一种元素的单剂肥，如硫酸锌、硫酸镁、硼肥、钾肥、钙肥等）(2)杀菌剂乙磷铝（别名：疫霉灵、三乙磷酸铝、霉菌灵、克菌灵、霜霉灵、疫霉净、磷酸乙酯铝）(3)福美双、福美锌系列产品；4、非络合态的代森系列产品（代森锰锌、代森联、代森锌等）5、氯溴异氰尿酸 6、恶霉灵系列产品7、展着剂和渗透剂。
混配增效的推广经验：1、氧化亚铜1500倍液和绿亨烯酰吗啉或霜脲锰锌或代森锰锌（全络合态）防治霜霉病、疫病效果非常突出。
2、氧化亚铜1500倍液和绿亨50%春雷多（春雷霉素、中生菌素、链霉素）复配防治细菌性病害效果突出。
50%春雷多还可防治炭疽病或稻瘟病。
3、氧化亚铜1500倍液和绿亨250g/L苯醚甲环唑3000倍（或50%烯酰吗啉1500倍）和中生菌素2000倍液三元混配防治黄瓜靶斑病（小黄点）有独特的优势。
4、氧化亚铜1500倍液与70%嘧霉胺1500倍防治灰霉病效果突出。
5、氧化亚铜1500倍液和氟硅唑或丙环唑混配防治白粉病、锈病或黑星病。
6、氧化亚铜1500倍液和绿亨28%多井600倍液混配防治稻曲病、纹枯病、稻瘟病。
7、氧化亚铜1500倍液和甲霜灵复配防治烟草黑茎病疫病效果明显。
8、氧化亚铜1500倍液和咪鲜胺防治炭疽病。
由于各厂家工艺不同，成分相同的非绿亨产品不能保证可以混配。
以下是可以混配的部分其他产品：52.5%抑快净水分散粒剂、72%克露可湿性粉剂、40%福星乳油、40%硫酸链霉素、206.7克/升万兴乳油、55%升势可湿性粉剂、25%使百克乳油、杜邦易保、50%翠贝水分散粒剂、50%乾程可湿性粉剂、75%猛杀生干悬浮剂、银法利687.5克/升悬浮剂、杜邦90%万灵可湿性粉剂、70%甲托、80%大生M-45等黄瓜靶斑病的防治方法：在北方保护地栽培的黄瓜，由于菜农常年重复用药，且用药量超出标准量的好几倍，各种病菌对常规药产生了很强的抗性，病害越来越很难防治，尤其黄瓜的靶斑病，普通药剂很难有效，主要原因有三：1.靶斑病是真菌和细菌混合侵染引起的，单独预防真菌或细菌很难取得很好效果；2.靶斑病对目前一般真菌性药剂产生了很强抗药性；3.以链霉素为代表的细菌性病害治疗药剂目前抗性严重，现在几乎无特效药。
目前铜制剂是治疗和预防黄瓜靶斑病的最好的药，首先铜制剂对所有的真菌细菌都有效，其次铜制剂与其它农药无交互抗性，不易产生抗性，第三铜制剂国家列为生产AA级绿色食品的农药。
但是铜制剂与其它农药不易复配，怕出现药害。
经过中国农业大学科研人员努力，绿亨化工的86.2%氧化亚铜各项技术指标已超过国家标准，只要用药方法得当，几乎不产生药害，根据科研多年的经验，86.2%氧化亚铜和苯醚甲环唑（或烯酰吗啉）与中生菌素三元复配防治黄瓜的靶斑病有独特的效果。
氧化亚铜的特殊用法：氧化亚铜使用的注意事项：1、注意二次稀释原则:先用少量水将药液调成浓稠母液，然后再稀释到所需浓度。
（1）能够保证药剂在水中分散均匀（2）有利于准确用药。
（3）可减少农药发生药害的危险。
2、对铜敏感果树如桃、李、柿等应慎用，十字花科和苹果树稀释2000倍液以上。
3、无论何种作物，作物的花期和幼果期是对铜制剂比较敏感。
铜制剂慎用。
4、高温期和高湿期慎用铜制剂，以免产生药害。
5、农药的复配问题：部分零售商指导农民随意配药，大多数并没有表现出药害，但实际上因农药和叶面肥各种相互作用，大大降低农药的药效，还有一部分复配的结果直接产生了药害，造成了不必要的损失，如何解决此问题。
（1）购买正规企业的农药产品，（2）找当地有丰富经验的农艺师指导配药（3）配药时先做小面积试验，然后大面积推广(4)复配时现配现用，不能长久搁置药液。
6、掌握用药时机：氧化亚铜用药时应选择晴朗的天气，温度不能超过35度，空气湿度不能大于85%进行施药，对作物是比较安全的。
高温高湿发生药害原因：高温高湿时作物的代谢旺盛，气孔张开，药剂容易进入植体，喷雾在叶片上的药液容易蒸发，叶面上的药液浓度过高，导致药害发生。
