钢芯耐热铝合金成型绞线

1567
630/45 39/4.51 7/2.81 623.03 43.10 666.13 30.56 2078 150.2 156.3 161.9 0.0467 63.7 20.8
1796
630/55 36/4.76 7/3.20 640.63 56.30 696.93 31.26 2209 163.7 171.6 179.5 0.0459 65.9 20.3
2127
800/70 64/4.01 7/3.60 808.28 71.25 879.53 35.15 2791 206.9 211.9 224.0 0.0363 65.9 20.3
2127
800/100 64/3.98 19/2.60 796.23 100.9 897.13 35.63 2991 241.4 255.5 268.6 0.0369 70.2 19.5
968
240/55 20/3.92 7/3.20 241.38 56.30 297.68 20.64 1108 101.0 108.9 116.8 0.1218 80.5 17.9
984
300/15 30/3.55 7/1.67 296.94 15.33 312.27 20.88 940 66.0 68.2 70.3 0.0989 61.6 21.3
1347
400/25 33/3.89 7/2.22 392.20 27.10 419.30 24.23 1295 95.2 99.0 102.8 0.0749 63.7 20.8
1319
400/35 36/3.72 7/2.50 391.27 34.36 425.63 24.44 1349 102.5 107.3 111.8 0.0751 65.9 20.3
1123
300/70 20/4.41 7/3.60 305.49 71.25 376.74 23.23 1402 127.8 132.8 144.9 0.0962 80.5 17.9
1150
400/20 30/4.15 7/1.95 405.80 20.91 426.71 24.43 1286 90.3 93.2 96.2 0.0722 61.6 21.3
1825
630/80 39/4.56 19/2.32 636.92 80.32 717.24 31.88 2388 192.6 203.8 214.3 0.0463 70.2 19.5
1831
800/55 56/4.30 7/3.20 813.23 56.30 869.53 34.92 2690 191.4 199.5 207.2 0.0361 63.7 20.8
820
185/30 15/3.92 7/2.32 181.03 29.59 210.62 17.30 733 63.1 67.3 71.1 0.1618 73.9 18.9
808
210/25 21/3.56 7/2.22 209.03 27.10 236.13 18.27 789 65.6 69.4 73.2 0.1404 70.5 19.4
1125
300/40 21/4.27 7/2.66 300.72 38.90 339.62 21.90 1136 92.1 97.5 102.6 0.0977 70.5 19.4
1119
300/50 20/4.37 7/2.98 299.97 48.82 348.79 22.23 1210 103.3 110.1 116.5 0.0980 73.8 18.9
1321
400/50 36/3.76 7/3.07 399.73 51.82 451.55 25.26 1511 121.8 129.1 136.3 0.0736 70.5 19.4
1349
400/65 23/4.70 7/3.44 399.04 65.06 464.10 25.67 1611 135.0 144.1 153.2 0.0736 73.9 18.9
钢芯耐热铝合金成型绞线 JNRLH60X/G1A、JNRLH60X/G2A、JNRLH60X/G3A
标称 截 面
根数 / 直径
铝
钢
mm
150/20 18/3.21 7/1.85
面积
绞线
铝
钢
总和
外径
mm2
mm
145.67 18.82 164.49 15.24
单位 长度 质量
kg/ km
549
额定抗拉力 G1A G2A G3A
1096
300/20 30/3.59 7/1.95 303.67 20.91 324.58 21.32 1002 73.6 76.5 79.5 0.0968 63.7 20.8
1115
300/25 21/4.31 7/2.22 306.38 27.10 333.48 21.63 1058 82.5 86.3 90.2 0.0959 66.0 20.3
882
210/35 20/3.67 7/2.50 211.57 34.36 245.93 18.68 854 73.5 78.3 82.8 0.1386 73.8 18.9
894
210/50 20/3.65 7/2.98 209.27 48.82 258.09 19.22 961 89.6 96.4 102.7 0.1404 80.5 17.9
2123
1000/125 72/4.19 19/2.90 992.78 125.5 1118 39.80 3733 301.0 318.6 334.9 0.0296 70.1 19.5
2450
1440/120 78/4.85 19/2.80 1441 117.0 1558 46.80 4898 362.1 378.5 393.7 0.0204 65.2 20.5
1541
500/45 33/4.34 7/2.80 488.18 43.10 531.28 27.32 1688 128.3 134.3 139.9 0.0601 65.9 20.3
1530源自文库
500/65 36/4.21 7/3.44 501.14 65.06 566.20 28.30 1897 152.9 162.0 171.1 0.0586 70.5 19.4
1357
400/95 24/4.65 19/2.50 407.58 93.27 500.85 26.84 1860 171.2 184.3 196.4 0.0720 80.1 17.9
1392
500/35 33/4.38 7/2.50 497.23 34.36 531.59 27.28 1642 119.7 124.5 129.0 0.0591 63.7 20.8
kN 46.2 48.8 51.5
直流 电阻 20℃
Ω/km
弹性 模量
GPa
0.2014 70.4
线胀系 参考载流
数
量
10-6/℃
A
19.5
696
185/25 15/3.98 7/2.10 186.62 24.25 210.87 17.28 706 58.7 62.1 65.5 0.1568 70.5 19.4
3071
18
897
240/30 21/3.85 7/2.40 244.47 31.67 276.14 19.75 922 75.7 80.1 84.2 0.1201 70.5 19.4
977
240/40 20/3.90 7/2.66 238.92 38.90 276.14 19.86 964 83.0 88.5 93.5 0.1229 73.9 18.9
