ch9_noneferrous-有色金属双语

Al
Si
Si shape modified by Sr
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.4 Portion of the aluminum-magnesium phase diagram
PREVIOUS
Materials for mechanical Engineering
Materials for mechanical Engineering
Non-Ferrous Alloys
Prof. Liuzhang Ouyang
School of Materials Science & Engineering South china University of technology
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys 9.1.2 Al-Cu alloys
• adding Cu lowers the melting point of Al • alloy suitable for casting • Al-Cu alloys can be age hardened (see later)
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys Al-Cu phase diagram
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys Al-4wt%Cu
fine Al2Cu precipitates (age hardened)
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys Al-4wt%Cu
coarse Al2Cu (over aged)
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.3 Al-Si alloys • adding Si lowers the melting point of Al • alloy suitable for sand or die casting (high fluidity) • Al and Si have no solid solubility below the eutectic – so obtain microstructure of Si particles in an Al matrix • good corrosion resistance and good weldability • microstructure can be refined by rapid cooling to increase strength and ductility • or modify microstructure by adding Sr
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.6 Precipitation Hardening
• • An appreciable maximum solubility of one component in the other, on the order of several percent A solubility limit that rapidly decreases in concentration of the major component with temperature reduction
9.1 Aluminum Alloys 9.1.6 Age (or precipitation) hardening • method of strengthening metals • e.g. Al-Cu, 7075 Al-1.5Cu-2.5Mg-5.5Zn-0.3Mn-0.2Cr-0.5Fe-0.4Si-0.3(Zr+Ti) • Need decrease in solid solubility of an alloying element with decreasing temperature • Draw suitable phase diagram:
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.3 Al-Si phase diagram
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys 9.1.3 Sand-cast 443 aluminum alloy
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
Non-Ferrous Alloys
Metal Alloys
• Ferrous Alloys: Alloys containing more than 50wt.%Fe – Classification of Steels – Designation of Steels • Nonferrous Alloys: Alloys containing less than 50wt.%Fe – Aluminum – Copper – Magnesium – Titanium – Refractory(难熔) metals – Superalloys（超耐热合金） – Noble metals（贵金属）
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys
9.1.1 Aluminum Alloys
• • • • • • Refined by electrolytic reduction of aluminum oxide Requires a lot of electricity Easy to form and light weight Work hardens well • cast – e.g. Al-Cu, Al-Si Easy to recycle • wrought – e.g. 7000 series alloys Oxidation coating
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys
Production of aluminum in an electrolytic cell
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.3 Al-12Si-0.02Sr
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys 9.1.3 Al-12Si-0.02Sr
Chapter Outline
9.1 Aluminum Alloys 9.2 Magnesium and Beryllium Alloys 9.3 Copper Alloys 9.4 Nickel and Cobalt Alloys 9.5 Titanium Alloys 9.6 Bearing alloys
L L+α α A (a) α B A
L β α+β (b) B A
L α β B
α+β (c)
Which of the above systems can be precipitation-hardened? The answer is (c)!
OUTLINE RETURN
RETURN
PREVIOUS
NEXT
RETURN OUTLINE
Non-Ferrous Alloys
Learning objective
1. Explore the properties and applications of Cu, Al, and Ti alloys in load-bearing applications. 2. Designation of nonferrous alloy 3. Age (or precipitation) hardening热处理—时效强化（以 Al-4%Cu为例） 4. Designation of bearing alloys
PREVIOUS NEXT RETURN OUTLINE RETURN
Non-Ferrous Alloys
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
Non-Ferrous Alloys
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.5 Wrought Al alloys • wrought = rolled, extruded, forged – heat treatable – non-heat treatable • International alloy designation system (IADS) – e.g. 1XXX = Al – 7XXX = Al-Zn-Mg-(Cu) – specific example “7075”: Al-1.5Cu-2.5Mg-5.5Zn-0.3Mn-0.2Cr0.5Fe-0.4Si-0.3(Zr+Ti) • NB no universally accepted designation system for cast alloys
PREVIOUS NEXT RETURN OUTLINE RETURN
9.1 Aluminum Alloys 9.1.3 Al-wt%12Si
PREVIOUS
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys 9.1.3 Al-wt%12Si
(a) Sand-cast 443 aluminum alloy containing coarse silicon and inclusions. (b) Permanent-mold 443 alloy containing fine dendrite cells and fine silicon due to faster cooling. (c) Die-cast 443 alloy with a still finer microstructure (× 350).
NEXT
RETURN OUTLINE
RETURN
9.1 Aluminum Alloys Inclusions and precipitation in aluminum alloy
(a) FeAl3 inclusions in annealed 1100 aluminum (× 350). (b) Mg2Si precipitates in annealed 5457 aluminum alloy (× 75).
RETURN
PREVIOUS
NEXT
RETURN OUTLINE
Non-Ferrous Alloys
Non-ferrous Alloys Predate Iron
• Many non-ferrous alloys can be produced at lower temperatures than iron • Copper, brass, and bronze all predate iron alloys
Al
PREVIOUS NEXT RETURN OUTLINE
Si
RETURN
9.1 Aluminum Alloys 9.1.3 Al-12Si-0.02Sr
Eutectic composition shifted - so obtain primary silicon dendrites
