51单片机蜂鸣器播放音乐代码
51单片机蜂鸣器播放音乐代码
/*生日快乐歌曲*/#include <>#define uint unsigned int#define uchar unsigned charsbit beep = P1^5;uchar code SONG_TONE[]={212,212,190,212,159,169,212,212,190,212,142,159, 212,212,106,126,159,169,190,119,119,126,159,142,159,0};uchar code SONG_LONG[]={9,3,12,12,12,24,9,3,12,12,12,24,9,3,12,12,12,12,12,9,3,12,12,12,24,0};//延时void DelayMS(uint x){uchar t;while(x--) for(t=0;t<120;t++);}void PlayMusic(){uint i=0,j,k;while(SONG_LONG[i]!=0||SONG_TONE[i]!=0){ //播放各个音符，SONG_LONG 为拍子长度for(j=0;j<SONG_LONG[i]*20;j++){beep=~beep;//SONG_TONE 延时表决定了每个音符的频率for(k=0;k<SONG_TONE[i]/3;k++);}DelayMS(10);i++;}}void main(){beep=0;while(1){PlayMusic(); //播放生日快乐DelayMS(500); //播放完后暂停一段时间}}两只蝴蝶：#include <> // 这是单片机音乐代码生成器生成的代码#define uchar unsigned charsbit beepIO=P1^5; // 输出为可以修改成其它 IO 口uchar m,n;uchar code T[49][2]={{0,0},{0xF8,0x8B},{0xF8,0xF2},{0xF9,0x5B},{0xF9,0xB7},{0xFA,0x14},{0xFA,0x66},{0xFA,0 xB9},{0xFB,0x03},{0xFB,0x4A},{0xFB,0x8F},{0xFB,0xCF},{0xFC,0x0B},{0xFC,0x43},{0xFC,0x78},{0xFC,0xAB},{0xFC,0xDB},{0xFD,0x08},{0xFD,0x33},{0xFD,0 x5B},{0xFD,0x81},{0xFD,0xA5},{0xFD,0xC7},{0xFD,0xE7},{0xFE,0x05},{0xFE,0x21},{0xFE,0x3C},{0xFE,0x55},{0xFE,0x6D},{0xFE,0x84},{0xFE,0x99},{0xFE,0 xAD},{0xFE,0xC0},{0xFE,0x02},{0xFE,0xE3},{0xFE,0xF3},{0xFF,0x02},{0xFF,0x10},{0xFF,0x1D},{0xFF,0x2A},{0xFF,0x36},{0xFF,0x42},{0xFF,0x4C},{0xFF,0 x56},{0xFF,0x60},{0xFF,0x69},{0xFF,0x71},{0xFF,0x79},{0xFF,0x81}};uchar code music[][2]={{0,4},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8}, {21,4},{23,4},{21,4},{19,4},{16,4},{19,4},{14,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,24},{16,4},{19,4},{21,8}, {21,4},{23,4},{21,4},{19,4},{16,4},{19,4},{21,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8}, {21,4},{23,4},{21,4},{19,4},{16,4},{19,4},{14,24},{23,4},{26,4},{26,16},{26,4},{28,4},{26,4},{23,24},{21,4},{23,4},{21,8},{21,4}, {23,4},{21,4},{19,4},{16,4},{16,2},{19,2},{19,24},{0,20},{26,4},{26,4},{28,4},{31,4},{30,4},{30,4},{28,4},{23,4},{21,4},{21,4},{23,16},{ 0,4},{23,4},{23,4},{26,4},{28,8},{28,12},{16,4},{23,4},{21,4},{21,24},{23,4},{26,4},{26,4},{23,4},{26,8},{0,4},{31,8},{30,4},{28,4},{30,4},{2 3,8},{0,4},{28,4},{28,4},{30,4},{28,4},{26,4},{23,4},{21,8},{23,4},{21,4},{23,4 },{26,16},{0xFF,0xFF}};void delay(uchar p){uchar i,j;for(;p>0;p--)for(i=181;i>0;i--)for(j=181;j>0;j--);}void pause(){uchar i,j;for(i=150;i>0;i--)for(j=150;j>0;j--);}void T0_int() interrupt 1{beepIO=!beepIO;TH0=T[m][0]; TL0=T[m][1];}void main()uchar i=0;TMOD=0x01; EA=1; ET0=1;while(1){m=music[i][0];n=music[i][1];if(m==0x00){TR0=0;delay(n);i++;}else if(m==0xFF){TR0=0;delay(30);i=0;}else if(m==music[i+1][0]){TR0=1;delay(n);TR0=0;pause();i++;}else{TR0=1;delay(n);i++;}}}祝你平安：#include ""unsigned char Count;sbit _Speak =P1^5 ;unsigned char code SONG[] ={ //祝你平安0x26,0x20,0x20,0x20,0x20,0x20,0x26,0x10,0x20,0x10,0x20,0x80,0x26,0x20,0x30,0x20 ,0x30,0x20,0x39,0x10,0x30,0x10,0x30,0x80,0x26,0x20,0x20,0x20,0x20,0x20,0x1c,0x20 ,0x20,0x80,0x2b,0x20,0x26,0x20,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x80,0x26,0x20 ,0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x60,0x40,0x10,0x39,0x10,0x26,0x20 ,0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x80,0x26,0x20,0x2b,0x10,0x2b,0x10 ,0x2b,0x20,0x30,0x10,0x39,0x10,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x20 ,0x20,0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x18,0x20,0x18,0x20,0x26,0x20 ,0x20,0x20,0x20,0x40,0x26,0x20,0x2b,0x20,0x30,0x20,0x30,0x20,0x1c,0x20,0x20,0x20 ,0x20,0x80,0x1c,0x20,0x1c,0x20,0x1c,0x20,0x30,0x20,0x30,0x60,0x39,0x10,0x30,0x10 ,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x10,0x26,0x10,0x26,0x10,0x2b,0x10,0x2b,0x80 ,0x18,0x20,0x18,0x20,0x26,0x20,0x20,0x20,0x20,0x60,0x26,0x10,0x2b,0x20,0x30,0x20 ,0x30,0x20,0x1c,0x20,0x20,0x20,0x20,0x80,0x26,0x20,0x30,0x10,0x30,0x10,0x30,0x200x39,0x20,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x10,0x40,0x10,0x20,0x10 ,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x00};void Time0_Init(){TMOD = 0x01;IE = 0x82;TH0 = 0xD8;TL0 = 0xEF; //12MZ晶振，10ms}void Time0_Int() interrupt 1{TH0 = 0xD8;TL0 = 0xEF;Count++; //长度加1}/*-------------------------------------------------功能:1MS延时子程序-------------------------------------------------*/void Delay_xMs(unsigned int x){unsigned int i,j;for( i =0;i < x;i++ ){for( j =0;j<3;j++ );}}void Play_Song(unsigned char i){unsigned char Temp1,Temp2;unsigned int Addr;Count = 0; //中断计数器清0Addr = i * 217;while(1){Temp1 = SONG[Addr++];if ( Temp1 == 0xFF ) //休止符{TR0 = 0;Delay_xMs(100);}else if ( Temp1 == 0x00 ) //歌曲结束符{return;}else{Temp2 = SONG[Addr++];TR0 = 1;while(1){_Speak = ~_Speak;Delay_xMs(Temp1);if ( Temp2 == Count ){Count = 0;break;}}}}}/*-------------------------------------------------功能:主程序-------------------------------------------------*/ void main(){Time0_Init(); //定时器0中断初始化while(1){Play_Song(0); //播放}}。
51单片机蜂鸣器播放音乐代码(生日快乐 两只蝴蝶 祝你平安)精编版
/*生日快乐歌曲*/#include <reg51.h>#define uint unsigned int#define uchar unsigned charsbit beep = P1^5;uchar code SONG_TONE[]={212,212,190,212,159,169,212,212,190,212,142,159, 212,212,106,126,159,169,190,119,119,126,159,142,159,0};uchar code SONG_LONG[]={9,3,12,12,12,24,9,3,12,12,12,24,9,3,12,12,12,12,12,9,3,12,12,12,24,0};//延时void DelayMS(uint x){uchar t;while(x--) for(t=0;t<120;t++);}void PlayMusic(){uint i=0,j,k;while(SONG_LONG[i]!=0||SONG_TONE[i]!=0){ //播放各个音符，SONG_LONG 为拍子长度for(j=0;j<SONG_LONG[i]*20;j++){beep=~beep;//SONG_TONE 延时表决定了每个音符的频率for(k=0;k<SONG_TONE[i]/3;k++);}DelayMS(10);i++;}}void main(){beep=0;while(1){PlayMusic(); //播放生日快乐DelayMS(500); //播放完后暂停一段时间}}两只蝴蝶：#include <reg51.h> // 这是单片机音乐代码生成器生成的代码#define uchar unsigned charsbit beepIO=P1^5; // 输出为P1.5 可以修改成其它IO 口uchar m,n;uchar code T[49][2]={{0,0},{0xF8,0x8B},{0xF8,0xF2},{0xF9,0x5B},{0xF9,0xB7},{0xFA,0x14},{0xFA,0x66},{0xFA,0xB9},{0xFB,0x03 },{0xFB,0x4A},{0xFB,0x8F},{0xFB,0xCF},{0xFC,0x0B},{0xFC,0x43},{0xFC,0x78},{0xFC,0xAB},{0xFC,0xDB},{0xFD,0x08},{0xFD,0x33},{0xFD,0x5B},{0xFD,0x8 1},{0xFD,0xA5},{0xFD,0xC7},{0xFD,0xE7},{0xFE,0x05},{0xFE,0x21},{0xFE,0x3C},{0xFE,0x55},{0xFE,0x6D},{0xFE,0x84},{0xFE,0x99},{0xFE,0xAD},{0xFE,0xC0 },{0xFE,0x02},{0xFE,0xE3},{0xFE,0xF3},{0xFF,0x02},{0xFF,0x10},{0xFF,0x1D},{0xFF,0x2A},{0xFF,0x36},{0xFF,0x42},{0xFF,0x4C},{0xFF,0x56},{0xFF,0x60},{ 0xFF,0x69},{0xFF,0x71},{0xFF,0x79},{0xFF,0x81}};uchar code music[][2]={{0,4},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8},{21,4},{23,4},{21,4},{19 ,4},{16,4},{19,4},{14,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,24},{16,4},{19,4},{21,8},{21,4},{23,4},{21,4},{19 ,4},{16,4},{19,4},{21,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8},{21,4},{23,4},{21,4},{19 ,4},{16,4},{19,4},{14,24},{23,4},{26,4},{26,16},{26,4},{28,4},{26,4},{23,24},{21,4},{23,4},{21,8},{21,4},{23,4},{21,4},{19,4},{16 ,4},{16,2},{19,2},{19,24},{0,20},{26,4},{26,4},{28,4},{31,4},{30,4},{30,4},{28,4},{23,4},{21,4},{21,4},{23,16},{0,4},{23,4},{23,4},{26,4} ,{28,8},{28,12},{16,4},{23,4},{21,4},{21,24},{23,4},{26,4},{26,4},{23,4},{26,8},{0,4},{31,8},{30,4},{28,4},{30,4},{23,8},{0,4},{28,4},{28,4},{ 30,4},{28,4},{26,4},{23,4},{21,8},{23,4},{21,4},{23,4},{26,16},{0xFF,0xFF}};void delay(uchar p){uchar i,j;for(;p>0;p--)for(i=181;i>0;i--)for(j=181;j>0;j--);}void pause(){uchar i,j;for(i=150;i>0;i--)for(j=150;j>0;j--);}void T0_int() interrupt 1beepIO=!beepIO;TH0=T[m][0]; TL0=T[m][1];}void main(){uchar i=0;TMOD=0x01; EA=1; ET0=1;while(1){m=music[i][0];n=music[i][1];if(m==0x00){TR0=0;delay(n);i++;}else if(m==0xFF){TR0=0;delay(30);i=0;}else if(m==music[i+1][0]){TR0=1;delay(n);TR0=0;pause();i++;}else{TR0=1;delay(n);i++;}}}祝你平安：#include "reg52.h"unsigned char Count;sbit _Speak =P1^5 ;unsigned char code SONG[] ={ //祝你平安0x26,0x20,0x20,0x20,0x20,0x20,0x26,0x10,0x20,0x10,0x20,0x80,0x26,0x20,0x30,0x20, 0x30,0x20,0x39,0x10,0x30,0x10,0x30,0x80,0x26,0x20,0x20,0x20,0x20,0x20,0x1c,0x20, 0x20,0x80,0x2b,0x20,0x26,0x20,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x80,0x26,0x20, 0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x60,0x40,0x10,0x39,0x10,0x26,0x20, 0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x80,0x26,0x20,0x2b,0x10,0x2b,0x10, 0x2b,0x20,0x30,0x10,0x39,0x10,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x20, 0x20,0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x18,0x20,0x18,0x20,0x26,0x20, 0x20,0x20,0x20,0x40,0x26,0x20,0x2b,0x20,0x30,0x20,0x30,0x20,0x1c,0x20,0x20,0x20, 0x20,0x80,0x1c,0x20,0x1c,0x20,0x1c,0x20,0x30,0x20,0x30,0x60,0x39,0x10,0x30,0x10, 0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x10,0x26,0x10,0x26,0x10,0x2b,0x10,0x2b,0x80, 0x18,0x20,0x18,0x20,0x26,0x20,0x20,0x20,0x20,0x60,0x26,0x10,0x2b,0x20,0x30,0x20, 0x30,0x20,0x1c,0x20,0x20,0x20,0x20,0x80,0x26,0x20,0x30,0x10,0x30,0x10,0x30,0x20, 0x39,0x20,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x10,0x40,0x10,0x20,0x10, 0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x00};void Time0_Init(){TMOD = 0x01;IE = 0x82;TH0 = 0xD8;TL0 = 0xEF; //12MZ晶振，10ms}void Time0_Int() interrupt 1{TH0 = 0xD8;TL0 = 0xEF;Count++; //长度加1}/*-------------------------------------------------功能:1MS延时子程序-------------------------------------------------*/ void Delay_xMs(unsigned int x){unsigned int i,j;for( i =0;i < x;i++ ){for( j =0;j<3;j++ );}}void Play_Song(unsigned char i){unsigned char Temp1,Temp2;unsigned int Addr;Count = 0; //中断计数器清0Addr = i * 217;while(1){Temp1 = SONG[Addr++];if ( Temp1 == 0xFF ) //休止符{TR0 = 0;Delay_xMs(100);}else if ( Temp1 == 0x00 ) //歌曲结束符{return;}else{Temp2 = SONG[Addr++];TR0 = 1;while(1){_Speak = ~_Speak;Delay_xMs(Temp1);if ( Temp2 == Count ){Count = 0;break;}}}}}/*------------------------------------------------- 功能:主程序-------------------------------------------------*/ void main(){Time0_Init(); //定时器0中断初始化while(1){Play_Song(0); //播放}}。
51单片机蜂鸣器播放单音节音乐
0xFD,0x23,0x7F, 0xFC,0xAC,0x7F, 0xFD,0x23,0xFF, 0xFC,0x44,0xFF,
// 1_ 3_ 2 .5
0xFC,0x44,0x7F, 0xFD,0x23,0x7F, 0xFC,0xAC,0xFF, 0xFA,0x68,0xFF,
{
for (i =0; i < 363; i++)
{;}
}
}
*名称：Init()
*功能：设置计数器0工作方式,16位计数,溢出中断方式
**********************************************************************************/
void Init()
{
TMOD = 0x01; //定时器0处于计时方式,16位
*名称：Count1(void) interrupt 1
*功能：设置计时器0溢出中断,每中断一次改变P2_3引脚电平
*********************************************************************************/
void Count1(void) interrupt 1
void main()
{
uchar time;
Init();
TH0 = high;
TL0 = low;
while (1)
{
if (music[ptr] != 0xFF && music[ptr] != 0x00)//判断是否是正常音符
{
TR0 = 0;
P2_3 = 1;
蜂鸣器音乐工具
蜂鸣器音乐工具 IMB standardization office【IMB 5AB- IMBK 08- IMB 2C】
51单片机蜂鸣器音乐简谱转换工具－输入简谱就能自动生成音乐程序的工具Music Encode?
2013-12-07 14:29:35|?分类： |?标签： |举报 |字号大中小订阅
相信您在作蜂鸣器发声实验时肯定为复杂的频率与音调之间的转换而伤脑筋，这里向大家介绍一款工具可以大大简化转换操作，只需要输入简谱就能自动生成音乐播放程序代码。
以下此程序的主界面：
程序范例可以点主界面上的“关于”按钮后就能找到，但是代码也不全，需要加入对音乐程序的调用代码，其它范例里也写的很清楚了，只需要调用Play函数就行了，其调用格式如下：
Play(乐曲名,调号,升降八度,演奏速度);
经过实践，此函数的的后三个参数分别设为0,2和350时演奏出的音乐比较符合“原味”，下面给出本站的入门型51实验板结合此工具作的音乐程序：
.；第二个数字是0123之一，代表低音、中音、高音、超高音；第三个数字是时间长度，以半拍为单位。
乐曲数据表的结尾是三个0。
程序如下：
#include <>
sbit speaker = P1^7;
unsigned char timer0h, timer0l, time;
.；第二个数字是0123之一，代表低音、中音、高音、超高音；第三个数字是半拍的个数，代表时间长度。
当三个数字都是0，就代表乐曲数据表的结尾。
51单片机用蜂鸣器演奏卡农
DB 15H,20H,12H,20H
DB 12H,20H,13H,20H
DB 18H,20H,19H,20H
DB 1CH,20H,20H,20H
DB 24H,20H,26H,20H
DB 2BH,20H,24H,20H
DB 26H,20H,2BH,20H
MOV IE,#82H ;EA,ET0
MUSIC0:
NOP
MOV DPTR,#DAT ;表头地址送DPTR
MOV 20H,#00H ;中断计数器清0
MOV B,#00H ;表序号清0
MUSIC1:
NOP
CLR A
DB 10H,10H,13H,20H
DB 18H,10H,15H,10H
DB 13H,20H,15H,10H
DB 18H,10H,15H,10H
DB 19H,10H,18H,10H
DB 15H,10H,13H,10H
DB 15H,10H,18H,10H
DB 19H,10H,18H,20H
DB 20H,10H,1CH,10H
DB 19H,10H,18H,10H
DB 15H,10H,13H,10H
DB 12H,10H,13H,20H
DB 18H,10H,15H,10H
DB 13H,20H,26H,10H
DB 24H,10H,20H,10H
DB 1CH,10H,20H,10H
MOV A,B
MOVC A,@A+DPTR ;取节拍代码送R7
MOV R7,A
SETB TR0 ;启动计数
MUSIC2:
单片机蜂鸣器音乐
单片机蜂鸣器音乐单片机在我们的生活中无处不在，它被广泛地应用在各种电子产品中，为我们的生活带来了便利。
今天，我要向大家介绍的是一种基于单片机的蜂鸣器音乐播放器。
一、硬件部分1、单片机：我们选用的是AT89C51单片机，它具有低功耗、高性能的特点，非常适合用于音乐播放器。
2、蜂鸣器：蜂鸣器是用来发出声音的，我们将其连接在单片机的输出口上。
3、存储芯片：为了能够播放存储在芯片中的音乐，我们需要将音乐以某种格式存储在芯片中。
常用的存储芯片有EEPROM和Flash芯片。
4、按键：为了能够选择播放不同的音乐，我们需要添加一个按键。
二、软件部分1、音乐编码：我们需要将音乐转换成二进制编码，这样才能被单片机读取并播放。
常用的音乐编码格式有MIDI、WAV等。
2、音乐播放：当按下按键时，单片机读取存储芯片中的音乐数据，并通过蜂鸣器播放。
3、音乐选择：通过按键可以选择不同的音乐进行播放。
4、音量控制：我们可以通过编程来控制蜂鸣器的音量大小。
三、调试与测试1、硬件调试：检查连接是否正确，确保没有短路或断路的情况。
2、软件调试：将程序下载到单片机中进行调试，确保能够正常播放音乐。
3、综合测试：将所有硬件和软件都连接起来进行测试，确保能够正常工作。
四、总结与展望通过本次实验，我们成功地制作了一个基于单片机的蜂鸣器音乐播放器。
它具有简单、实用的特点，可以用来播放存储在芯片中的音乐。
未来，我们可以进一步扩展其功能，例如添加更多的按键来选择不同的音乐、添加显示屏来显示歌曲名称等。
我们也可以将其应用到其他领域，例如智能家居、智能安防等。
单片机蜂鸣器唱歌程序在许多应用中，单片机蜂鸣器经常被用来发出声音或音乐。
下面是一个使用单片机蜂鸣器唱歌的程序示例。
我们需要确定单片机和蜂鸣器的连接方式。
通常，单片机具有一个内置的蜂鸣器输出引脚，可以将蜂鸣器连接到这个引脚上。
在以下的示例中，我们将假设单片机具有一个内置蜂鸣器输出引脚，并将其连接到P1.0端口上。
蜂鸣器音乐工具
51单片机蜂鸣器音乐简谱转换工具－输入简谱就能自动生成音乐程序的工具Music Encode??2013-12-07 14:29:35|??分类：51单片机编程|??标签：|举报|字号大中小?订阅相信您在作蜂鸣器发声实验时肯定为复杂的频率与音调之间的转换而伤脑筋，这里向大家介绍一款工具可以大大简化转换操作，只需要输入简谱就能自动生成音乐播放程序代码。
以下此程序的主界面：程序范例可以点主界面上的“关于”按钮后就能找到，但是代码也不全，需要加入对音乐程序的调用代码，其它范例里也写的很清楚了，只需要调用Play函数就行了，其调用格式如下：Play(乐曲名,调号,升降八度,演奏速度);经过实践，此函数的的后三个参数分别设为0,2和350时演奏出的音乐比较符合“原味”，下面给出本站的入门型51实验板结合此工具作的音乐程序：//51单片机播放音乐库文件/**************************************************************************SOUND PLAY FOR 51MCUCOPYRIGHT (c) 2005 BY JJJ.-- ALL RIGHTS RESERVED --File Name: SoundPlay.hAuthor: Jiang Jian JunCreated: 2005/5/16Modified: NORevision: 1.0*******************************************************************************//*说明**************************************************************************曲谱存贮格式unsigned char code MusicName{音高，音长，音高，音长...., 0,0}; 末尾:0,0 表示结束(Important)音高由三位数字组成：个位是表示1~7 这七个音符十位是表示音符所在的音区:1-低音，2-中音，3-高音;百位表示这个音符是否要升半音: 0-不升，1-升半音。
51单片机蜂鸣器代码理解
51单片机蜂鸣器代码理解1.引言1.1 概述概述：蜂鸣器是一种广泛应用于电子设备中的声音输出装置，它通过控制某个频率的电信号使蜂鸣器发出特定的声音。
而51单片机，则是一种常见的单片机芯片，具有广泛的应用领域。
本文将主要探讨51单片机蜂鸣器的代码理解和应用。
通过对其基本原理的概述以及相关代码的解析，希望读者能够深入理解51单片机蜂鸣器的工作原理和实现方式。
在第二部分中，我们将介绍单片机蜂鸣器的基本原理。
包括如何通过单片机控制蜂鸣器的电信号频率和时长，从而实现不同的声音效果。
接着，在第二点中，我们将详细解析51单片机蜂鸣器的代码。
通过对代码的分析，读者可以了解到如何使用51单片机的引脚功能和定时器功能来控制蜂鸣器。
最后，在结论部分，我们将对所述内容进行总结，并展望51单片机蜂鸣器在未来的应用前景。
蜂鸣器作为一种重要的声音输出装置，具有广泛的应用前景，可以应用于报警系统、提醒装置等领域。
通过本文的阅读，读者将能够全面了解51单片机蜂鸣器的工作原理和代码实现方式，为相关领域的应用开发提供参考和指导。
让我们开始探索吧！1.2 文章结构文章结构的部分主要介绍了本文的组织和分类方式，以帮助读者更好地理解文章的内容和思路。
本文按照以下结构进行组织：1. 引言部分：介绍了文章的概述、结构和目的。
通过引言部分，读者可以初步了解到本文的内容和主题，并对文章的结构和目的有一个整体的认识。
2. 正文部分：主要分为两个小节，分别是"单片机蜂鸣器的基本原理"和"51单片机蜂鸣器代码解析"。
2.1 单片机蜂鸣器的基本原理：该部分将详细介绍单片机蜂鸣器的基本工作原理，包括蜂鸣器的构成和工作原理，以及单片机如何控制蜂鸣器发出指定的声音。
2.2 51单片机蜂鸣器代码解析：该部分将对51单片机蜂鸣器的代码进行解析，包括如何初始化引脚、设置定时器和中断等相关代码。
通过对代码的逐行解析和说明，读者可以更加深入地理解代码的功能和实现原理。
基于51单片机两种音乐编码的比较及用法
基于51单⽚机两种⾳乐编码的⽐较及⽤法基于51单⽚机的两种⾳乐编码⽅法的⽐较及⽤法（建议对这⽅⾯有兴趣的朋友们要先看懂了解⾳乐简谱，包括⾼⾳、中⾳、低⾳，节拍、延时，及各个⾳调的频率，⽹上有很多资料）1⽅法：⽤51单⽚机⾳乐编码器软件（Music encode）输出⼗六进制数表⽰：曲谱存贮格式unsigned char code MusicName{⾳⾼，⾳长，⾳⾼，⾳长...., 0,0}; 末尾:0,0 表⽰结束(Important) （其实软件“关于”⾥的源代码有使⽤⽅法的介绍）⾳⾼由三位数字组成：个位是表⽰1~7 这七个⾳符⼗位是表⽰⾳符所在的⾳区:1-低⾳，2-中⾳，3-⾼⾳;百位表⽰这个⾳符是否要升半⾳: 0-不升，1-升半⾳。
⾳长最多由三位数字组成：个位表⽰⾳符的时值，其对应关系是：|数值(n): |0 |1 |2 |3 | 4 | 5 | 6|⼏分⾳符: |1 |2 |4 |8 |16 |32 |64 ⾳符=2^n⼗位表⽰⾳符的演奏效果(0-2): 0-普通，1-连⾳，2-顿⾳百位是符点位: 0-⽆符点，1-有符点2⽅法：编码为⼗六进制（⾼四位表⽰⾳调编码，低四位表⽰节拍编码）（各⾳调频率及初值计算定时器初值⽹上有,在此不叙说）do re mi fa so la si分别编码为1~7，重⾳do编为8,重⾳re编为9，停顿编为0。
如0x24,表⽰低⾳LA、1拍。
以此类推表4.4简谱对应的简谱码、T值、节拍数简谱发⾳简谱码T值节拍码节拍数5 低⾳SO 1 64260 1 1/4拍6 低⾳LA 2 64400 2 2/4拍7 低⾳TI 3 64524 3 3/4拍1 中⾳DO 4 64580 4 1拍2 中⾳RE 5 64684 5 1⼜1/4拍3 中⾳MI 6 64777 6 1⼜1/2拍4 中⾳FA 7 64820 8 2拍5 中⾳SO 8 64898 A 2⼜1/2拍6 中⾳LA 9 64968 C 3拍7 中⾳TI A 65030 F 3⼜3/4拍3 ⾼⾳MI D 651574 ⾼⾳FA E 651785 ⾼⾳SO F 65217总结：通过两种⽅法仿真⽐较，这两种⽅法各有优劣，⽅法1⽤Music encode编码简单不需要对简谱有深⼊了解但蜂鸣器发⾳不理想，⽤⽅法2编码需要看懂简谱及要知道各⾳调节拍所对应的编码号但蜂鸣器⽐较动听，柔和（后⾯附有两种⽅法的仿真代码和原理图）（想要Music encode软件的朋友可以留下邮箱，我发给你们，⽹上也有的）⽅法1代码：//51单⽚机播放⾳乐库⽂件/**************************************************************************SOUND PLAY FOR 51MCUCOPYRIGHT (c) 2005 BY JJJ.-- ALL RIGHTS RESERVED --File Name: SoundPlay.hAuthor: Jiang Jian JunCreated: 2005/5/16Modified: NORevision: 1.0******************************************************************************* //*说明**************************************************************************曲谱存贮格式unsigned char code MusicName{⾳⾼，⾳长，⾳⾼，⾳长...., 0,0}; 末尾:0,0 表⽰结束(Important)⾳⾼由三位数字组成：个位是表⽰1~7 这七个⾳符⼗位是表⽰⾳符所在的⾳区:1-低⾳，2-中⾳，3-⾼⾳;百位表⽰这个⾳符是否要升半⾳: 0-不升，1-升半⾳。
51单片机蜂鸣器播放音乐代码
/*生日快乐歌曲*/#include <>#define uint unsigned int#define uchar unsigned charsbit beep = P1^5;uchar code SONG_TONE[]={212,212,190,212,159,169,212,212,190,212,142,159, 212,212,106,126,159,169,190,119,119,126,159,142,159,0};uchar code SONG_LONG[]={9,3,12,12,12,24,9,3,12,12,12,24,9,3,12,12,12,12,12,9,3,12,12,12,24,0};//延时!void DelayMS(uint x){uchar t;while(x--) for(t=0;t<120;t++);}void PlayMusic(){uint i=0,j,k;while(SONG_LONG[i]!=0||SONG_TONE[i]!=0){ //播放各个音符，SONG_LONG 为拍子长度%for(j=0;j<SONG_LONG[i]*20;j++){beep=~beep;//SONG_TONE 延时表决定了每个音符的频率for(k=0;k<SONG_TONE[i]/3;k++);}DelayMS(10);i++;}}~void main(){beep=0;while(1){PlayMusic(); //播放生日快乐DelayMS(500); //播放完后暂停一段时间}}两只蝴蝶：%#include <> // 这是单片机音乐代码生成器生成的代码#define uchar unsigned charsbit beepIO=P1^5; // 输出为可以修改成其它IO 口uchar m,n;uchar code T[49][2]={{0,0},{0xF8,0x8B},{0xF8,0xF2},{0xF9,0x5B},{0xF9,0xB7},{0xFA,0x14},{0xFA,0x66},{0xFA,0xB9},{0xFB,0x03 },{0xFB,0x4A},{0xFB,0x8F},{0xFB,0xCF},{0xFC,0x0B},{0xFC,0x43},{0xFC,0x78},{0xFC,0xAB},{0xFC,0xDB},{0xFD,0x08},{0xFD,0x33},{0xFD,0x5B},{0xFD,0x8 1},{0xFD,0xA5},{0xFD,0xC7},{0xFD,0xE7},{0xFE,0x05},{0xFE,0x21},{0xFE,0x3C},{0xFE,0x55},{0xFE,0x6D},{0xFE,0x84},{0xFE,0x99},{0xFE,0xAD},{0xFE,0xC0 },{0xFE,0x02},{0xFE,0xE3},{0xFE,0xF3},{0xFF,0x02},{0xFF,0x10},{0xFF,0x1D},{0xFF,0x2A},{0xFF,0x36},{0xFF,0x42},{0xFF,0x4C},{0xFF,0x56},{0xFF,0x60},{ 0xFF,0x69},{0xFF,0x71},{0xFF,0x79},{0xFF,0x81}};~uchar code music[][2]={{0,4},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8},{21,4},{23,4},{21,4},{19 ,4},{16,4},{19,4},{14,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,24},{16,4},{19,4},{21,8},{21,4},{23,4},{21,4},{19 ,4},{16,4},{19,4},{21,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8},{21,4},{23,4},{21,4},{19 ,4},{16,4},{19,4},{14,24},{23,4},{26,4},{26,16},{26,4},{28,4},{26,4},{23,24},{21,4},{23,4},{21,8},{21,4},{23,4},{21,4},{19,4},{16 ,4},{16,2},{19,2},{19,24},{0,20},{26,4},{26,4},{28,4},{31,4},{30,4},{30,4},{28,4},{23,4},{21,4},{21,4},{23,16},{0,4},{23,4},{23,4},{26,4} ,{28,8},{28,12},{16,4},{23,4},{21,4},{21,24},{23,4},{26,4},{26,4},{23,4},{26,8},{0,4},{31,8},{30,4},{28,4},{30,4},{23,8},{0,4},{28,4},{28,4},{ 30,4},{28,4},{26,4},{23,4},{21,8},{23,4},{21,4},{23,4},{26,16},{0xFF,0xFF}};void delay(uchar p){.uchar i,j;for(;p>0;p--)for(i=181;i>0;i--)for(j=181;j>0;j--);}void pause(){uchar i,j;for(i=150;i>0;i--)for(j=150;j>0;j--);/}void T0_int() interrupt 1{beepIO=!beepIO;TH0=T[m][0]; TL0=T[m][1];}void main(){uchar i=0;TMOD=0x01; EA=1; ET0=1;、while(1){m=music[i][0];n=music[i][1];if(m==0x00){TR0=0;delay(n);i++;}else if(m==0xFF){TR0=0;delay(30);i=0;}else if(m==music[i+1][0]){TR0=1;delay(n);TR0=0;pause();i++;}else.{TR0=1;delay(n);i++;}}}祝你平安：#include ""unsigned char Count;sbit _Speak =P1^5 ;unsigned char code SONG[] ={ //祝你平安0x26,0x20,0x20,0x20,0x20,0x20,0x26,0x10,0x20,0x10,0x20,0x80,0x26,0x20,0x30,0x20, 0x30,0x20,0x39,0x10,0x30,0x10,0x30,0x80,0x26,0x20,0x20,0x20,0x20,0x20,0x1c,0x20, %0x20,0x80,0x2b,0x20,0x26,0x20,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x80,0x26,0x20, 0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x60,0x40,0x10,0x39,0x10,0x26,0x20, 0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x80,0x26,0x20,0x2b,0x10,0x2b,0x10, 0x2b,0x20,0x30,0x10,0x39,0x10,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x20, 0x20,0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x18,0x20,0x18,0x20,0x26,0x20, 0x20,0x20,0x20,0x40,0x26,0x20,0x2b,0x20,0x30,0x20,0x30,0x20,0x1c,0x20,0x20,0x20, 0x20,0x80,0x1c,0x20,0x1c,0x20,0x1c,0x20,0x30,0x20,0x30,0x60,0x39,0x10,0x30,0x10, 0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x10,0x26,0x10,0x26,0x10,0x2b,0x10,0x2b,0x80, 0x18,0x20,0x18,0x20,0x26,0x20,0x20,0x20,0x20,0x60,0x26,0x10,0x2b,0x20,0x30,0x20, 0x30,0x20,0x1c,0x20,0x20,0x20,0x20,0x80,0x26,0x20,0x30,0x10,0x30,0x10,0x30,0x20,￥0x39,0x20,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x10,0x40,0x10,0x20,0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x00}; void Time0_Init(){TMOD = 0x01;IE = 0x82;TH0 = 0xD8;TL0 = 0xEF; //12MZ晶振，10ms}void Time0_Int() interrupt 1({TH0 = 0xD8;TL0 = 0xEF;Count++; //长度加1}/*-------------------------------------------------功能:1MS延时子程序-------------------------------------------------*/void Delay_xMs(unsigned int x){）unsigned int i,j;for( i =0;i < x;i++ ){for( j =0;j<3;j++ );}}void Play_Song(unsigned char i){unsigned char Temp1,Temp2;unsigned int Addr;!Count = 0; //中断计数器清0Addr = i * 217;while(1){Temp1 = SONG[Addr++];if ( Temp1 == 0xFF ) //休止符{TR0 = 0;Delay_xMs(100);}:else if ( Temp1 == 0x00 ) //歌曲结束符{return;}else{Temp2 = SONG[Addr++];TR0 = 1;while(1){._Speak = ~_Speak;Delay_xMs(Temp1);if ( Temp2 == Count ){Count = 0;break;}}}}}/*-------------------------------------------------功能:主程序-------------------------------------------------*/ void main(){Time0_Init(); //定时器0中断初始化while(1){Play_Song(0); //播放}}。
51单片机实现蜂鸣器警车、救护车、消防车声
/*-----------------------------------------------
名称：喇叭
论坛：
编写：shifang
日期：2009.5
修改：无
内容：模救护车发声
------------------------------------------------*/
{
while(t--)
{
//大致延时1mS
DelayUs2x(245);
DelayUs2x(245);
}
}/*------------------------------------------------
定时器中断子程序
------------------------------------------------*/
main()
{
unsigned char i;
Init_Timer0(); //初始化定时器
while(1)
{ቤተ መጻሕፍቲ ባይዱ
frq=0;
for(i=0;i<60;i++)//播放1s左右一种频率
{
DelayMs(10);
}
frq=100;
for(i=0;i<60;i++)//播放1s左右另外一种频率
{
DelayMs(10);
//TH0=0x00;//给定初值
//TL0=0x00;
EA=1; //总中断打开
ET0=1; //定时器中断打开
TR0=1; //定时器开关打开
}
/*------------------------------------------------
主函数
51单片机蜂鸣器播放音乐代码
/*生日快乐歌曲*/#include <>#define uint unsigned int#define uchar unsigned charsbit beep = P1^5;uchar code SONG_TONE[]={212,212,190,212,159,169,212,212,190,212,142,159, 212,212,106,126,159,169,190,119,119,126,159,142,159,0};uchar code SONG_LONG[]={9,3,12,12,12,24,9,3,12,12,12,24,9,3,12,12,12,12,12,9,3,12,12,12,24,0};//延时void DelayMS(uint x){uchar t;while(x--) for(t=0;t<120;t++);}void PlayMusic(){uint i=0,j,k;while(SONG_LONG[i]!=0||SONG_TONE[i]!=0){ //播放各个音符，SONG_LONG 为拍子长度for(j=0;j<SONG_LONG[i]*20;j++){beep=~beep;//SONG_TONE 延时表决定了每个音符的频率for(k=0;k<SONG_TONE[i]/3;k++);}DelayMS(10);i++;}}void main(){beep=0;while(1){PlayMusic(); //播放生日快乐DelayMS(500); //播放完后暂停一段时间}}两只蝴蝶：#include <> // 这是单片机音乐代码生成器生成的代码#define uchar unsigned charsbit beepIO=P1^5; // 输出为可以修改成其它 IO 口uchar m,n;uchar code T[49][2]={{0,0},{0xF8,0x8B},{0xF8,0xF2},{0xF9,0x5B},{0xF9,0xB7},{0xFA,0x14},{0xFA,0x66},{0x FA,0xB9},{0xFB,0x03},{0xFB,0x4A},{0xFB,0x8F},{0xFB,0xCF},{0xFC,0x0B}, {0xFC,0x43},{0xFC,0x78},{0xFC,0xAB},{0xFC,0xDB},{0xFD,0x08},{0xFD,0x33},{0x FD,0x5B},{0xFD,0x81},{0xFD,0xA5},{0xFD,0xC7},{0xFD,0xE7},{0xFE,0x05}, {0xFE,0x21},{0xFE,0x3C},{0xFE,0x55},{0xFE,0x6D},{0xFE,0x84},{0xFE,0x99},{0x FE,0xAD},{0xFE,0xC0},{0xFE,0x02},{0xFE,0xE3},{0xFE,0xF3},{0xFF,0x02}, {0xFF,0x10},{0xFF,0x1D},{0xFF,0x2A},{0xFF,0x36},{0xFF,0x42},{0xFF,0x4C},{0x FF,0x56},{0xFF,0x60},{0xFF,0x69},{0xFF,0x71},{0xFF,0x79},{0xFF,0x81} };uchar code music[][2]={{0,4},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21 ,8},{21,4},{23,4},{21,4},{19,4},{16,4},{19,4},{14,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,24},{16,4},{19,4},{21 ,8},{21,4},{23,4},{21,4},{19,4},{16,4},{19,4},{21,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21 ,8},{21,4},{23,4},{21,4},{19,4},{16,4},{19,4},{14,24},{23,4},{26,4},{26,16},{26,4},{28,4},{26,4},{23,24},{21,4},{23,4},{21,8},{21 ,4},{23,4},{21,4},{19,4},{16,4},{16,2},{19,2},{19,24},{0,20},{26,4},{26,4},{28,4},{31,4},{30,4},{30,4},{28,4},{23,4},{21,4},{21,4},{23,1 6},{0,4},{23,4},{23,4},{26,4},{28,8},{28,12},{16,4},{23,4},{21,4}, {21,24},{23,4},{26,4},{26,4},{23,4},{26,8},{0,4},{31,8},{30,4},{28,4},{30,4 },{23,8},{0,4},{28,4},{28,4},{30,4},{28,4},{26,4},{23,4},{21,8},{23,4},{21,4},{ 23,4},{26,16},{0xFF,0xFF}};void delay(uchar p){uchar i,j;for(;p>0;p--)for(i=181;i>0;i--)for(j=181;j>0;j--);}void pause(){uchar i,j;for(i=150;i>0;i--)for(j=150;j>0;j--);}void T0_int() interrupt 1{beepIO=!beepIO;TH0=T[m][0]; TL0=T[m][1];}void main(){uchar i=0;TMOD=0x01; EA=1; ET0=1;while(1){m=music[i][0];n=music[i][1];if(m==0x00){TR0=0;delay(n);i++;}else if(m==0xFF){TR0=0;delay(30);i=0;}else if(m==music[i+1][0]){TR0=1;delay(n);TR0=0;pause();i++;}else{TR0=1;delay(n);i++;}}}祝你平安：#include ""unsigned char Count;sbit _Speak =P1^5 ;unsigned char code SONG[] ={ //祝你平安0x26,0x20,0x20,0x20,0x20,0x20,0x26,0x10,0x20,0x10,0x20,0x80,0x26,0x20,0x30, 0x20,0x30,0x20,0x39,0x10,0x30,0x10,0x30,0x80,0x26,0x20,0x20,0x20,0x20,0x20,0x1c, 0x20,0x20,0x80,0x2b,0x20,0x26,0x20,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x80,0x26, 0x20,0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x60,0x40,0x10,0x39,0x10,0x26, 0x20,0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x80,0x26,0x20,0x2b,0x10,0x2b, 0x10,0x2b,0x20,0x30,0x10,0x39,0x10,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40, 0x20,0x20,0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x18,0x20,0x18,0x20,0x26, 0x20,0x20,0x20,0x20,0x40,0x26,0x20,0x2b,0x20,0x30,0x20,0x30,0x20,0x1c,0x20,0x20, 0x20,0x20,0x80,0x1c,0x20,0x1c,0x20,0x1c,0x20,0x30,0x20,0x30,0x60,0x39,0x10,0x30, 0x10,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x10,0x26,0x10,0x26,0x10,0x2b,0x10,0x2b, 0x80,0x18,0x20,0x18,0x20,0x26,0x20,0x20,0x20,0x20,0x60,0x26,0x10,0x2b,0x20,0x30, 0x20,0x30,0x20,0x1c,0x20,0x20,0x20,0x20,0x80,0x26,0x20,0x30,0x10,0x30,0x10,0x30,0x20,0x39,0x20,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x10,0x40,0x10,0x20, 0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x00};void Time0_Init(){TMOD = 0x01;IE = 0x82;TH0 = 0xD8;TL0 = 0xEF; //12MZ晶振，10ms}void Time0_Int() interrupt 1{TH0 = 0xD8;TL0 = 0xEF;Count++; //长度加1}/*-------------------------------------------------功能:1MS延时子程序-------------------------------------------------*/void Delay_xMs(unsigned int x){unsigned int i,j;for( i =0;i < x;i++ ){for( j =0;j<3;j++ );}}void Play_Song(unsigned char i){unsigned char Temp1,Temp2;unsigned int Addr;Count = 0; //中断计数器清0Addr = i * 217;while(1){Temp1 = SONG[Addr++];if ( Temp1 == 0xFF ) //休止符{TR0 = 0;Delay_xMs(100);}else if ( Temp1 == 0x00 ) //歌曲结束符{return;}else{Temp2 = SONG[Addr++];TR0 = 1;while(1){_Speak = ~_Speak;Delay_xMs(Temp1);if ( Temp2 == Count ){Count = 0;break;}}}}}/*-------------------------------------------------功能:主程序-------------------------------------------------*/ void main(){Time0_Init(); //定时器0中断初始化while(1){Play_Song(0); //播放}}。
单片机蜂鸣器播放音乐代码生日快乐两只蝴蝶祝你平安
单片机蜂鸣器播放音乐代码生日快乐两只蝴蝶祝你平安/*生日快乐歌曲*/#include<reg51.h>#defineuintunsignedint#defineucharunsignedcharsbitbeep=P1^5;ucharcodeSONG_TONE[]={212,212,190,212,159,169,212,212,190,212,142,159,212,212,106,126,159,169,190,119,119,126,159,142,159,0};ucharcodeSONG_LONG[]={9,3,12,12,12,24,9,3,12,12,12,24,9,3,12,12,12,12,12,9,3,12,12,12,24,0};//延时voidDelayMS(uintx){uchart;while(x--)for(t=0;t<120;t++);}voidPlayMusic(){uinti=0,j,k;while(SONG_LONG[i]!=0||SONG_TONE[i]!=0){//播放各个音符，SONG_LONG为拍子长度for(j=0;j<SONG_LONG[i]*20;j++){beep=~beep;//SONG_TONE延时表决定了每个音符的频率for(k=0;k<SONG_TONE[i]/3;k++);}DelayMS(10);i++;}}voidmain(){beep=0;while(1){PlayMusic();//播放生日快乐DelayMS(500);//播放完后暂停一段时间}}两只蝴蝶：#include<reg51.h>//这是单片机音乐代码生成器生成的代码#defineucharunsignedcharsbitbeepIO=P1^5;//输出为P1.5可以修改成其它IO口ucharcodeT[49][2]={{0,0},{0xF8,0x8B},{0xF8,0xF2},{0xF9,0x5B},{0xF9,0xB7},{0xFA,0x14},{0xFA,0x66},{0xFA,0xB9},{ 0xFB,0x03},{0xFB,0x4A},{0xFB,0x8F},{0xFB,0xCF},{0xFC,0x0B},{0xFC,0x43},{0xFC,0x78},{0xFC,0xAB},{0xFC,0xDB},{0xFD,0x08},{0xFD,0x33},{0xFD,0x5B},{ 0xFD,0x81},{0xFD,0xA5},{0xFD,0xC7},{0xFD,0xE7},{0xFE,0x05},{0xFE,0x21},{0xFE,0x3C},{0xFE,0x55},{0xFE,0x6D},{0xFE,0x84},{0xFE,0x99},{0xFE,0xAD},{ 0xFE,0xC0},{0xFE,0x02},{0xFE,0xE3},{0xFE,0xF3},{0xFF,0x02},{0xFF,0x10},{0xFF,0x1D},{0xFF,0x2A},{0xFF,0x36},{0xFF,0x42},{0xFF,0x4C},{0xFF,0x56},{ 0xFF,0x60},{0xFF,0x69},{0xFF,0x71},{0xFF,0x79},{0xFF,0x81}};ucharcodemusic[][2]={{0,4},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8},{21,4} ,{23,4},{21,4},{19,4},{16,4},{19,4},{14,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,24},{16,4},{19,4},{21,8},{21,4} ,{23,4},{21,4},{19,4},{16,4},{19,4},{21,24},{23,4},{21,4},{23,16},{23,4},{21,4},{23,4},{21,4},{19,16},{16,4},{19,4},{21,8},{21,4} ,{23,4},{21,4},{19,4},{16,4},{19,4},{14,24},{23,4},{26,4},{26,16},{26,4},{28,4},{26,4},{23,24},{21,4},{23,4},{21,8},{21,4},{23,4} ,{21,4},{19,4},{16,4},{16,2},{19,2},{19,24},{0,20},{26,4},{26,4},{28,4},{31,4},{30,4},{30,4},{28,4},{23,4},{21,4},{21,4},{23,16},{0,4},{ 23,4},{23,4},{26,4},{28,8},{28,12},{16,4},{23,4},{21,4},{21,24},{23,4},{26,4},{26,4},{23,4},{26,8},{0,4},{31,8},{30,4},{28,4},{30,4},{23,8},{ 0,4},{28,4},{28,4},{30,4},{28,4},{26,4},{23,4},{21,8},{23,4},{21,4},{23,4},{26,16}, {0xFF,0xFF}};voiddelay(ucharp){uchari,j;for(;p>0;p--)for(i=181;i>0;i--)for(j=181;j>0;j--);}voidpause(){uchari,j;for(i=150;i>0;i--)for(j=150;j>0;j--);}voidT0_int()interrupt1{beepIO=!beepIO;TH0=T[m][0];TL0=T[m][1];}voidmain(){uchari=0;while(1){m=music[i][0];n=music[i][1];if(m==0x00){TR0=0;delay(n);i++;}elseif(m==0xFF){TR0=0;delay(30);i=0;}elseif(m==music[i+1][0]){TR0=1;delay(n);TR0=0;pause();i++;}else{TR0=1;delay(n);i++;}}}祝你平安：#include"reg52.h"unsignedcharCount;sbit_Speak=P1^5;unsignedcharcodeSONG[]={//祝你平安0x26,0x20,0x20,0x20,0x20,0x20,0x26,0x10,0x20,0x10,0x20,0x80,0x26,0x20,0x30,0x20, 0x30,0x20,0x39,0x10,0x30,0x10,0x30,0x80,0x26,0x20,0x20,0x20,0x20,0x20,0x1c,0x20, 0x20,0x80,0x2b,0x20,0x26,0x20,0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x80,0x26,0x20, 0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x60,0x40,0x10,0x39,0x10,0x26,0x20, 0x30,0x20,0x30,0x20,0x39,0x10,0x26,0x10,0x26,0x80,0x26,0x20,0x2b,0x10,0x2b,0x10, 0x2b,0x20,0x30,0x10,0x39,0x10,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x20, 0x20,0x10,0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x18,0x20,0x18,0x20,0x26,0x20, 0x20,0x20,0x20,0x40,0x26,0x20,0x2b,0x20,0x30,0x20,0x30,0x20,0x1c,0x20,0x20,0x20, 0x20,0x80,0x1c,0x20,0x1c,0x20,0x1c,0x20,0x30,0x20,0x30,0x60,0x39,0x10,0x30,0x10, 0x20,0x20,0x2b,0x10,0x26,0x10,0x2b,0x10,0x26,0x10,0x26,0x10,0x2b,0x10,0x2b,0x80, 0x18,0x20,0x18,0x20,0x26,0x20,0x20,0x20,0x20,0x60,0x26,0x10,0x2b,0x20,0x30,0x20, 0x30,0x20,0x1c,0x20,0x20,0x20,0x20,0x80,0x26,0x20,0x30,0x10,0x30,0x10,0x30,0x20, 0x39,0x20,0x26,0x10,0x2b,0x10,0x2b,0x20,0x2b,0x40,0x40,0x10,0x40,0x10,0x20,0x10, 0x20,0x10,0x2b,0x10,0x26,0x30,0x30,0x80,0x00};voidTime0_Init(){TMOD=0x01;IE=0x82;TH0=0xD8;TL0=0xEF;//12MZ晶振，10ms}voidTime0_Int()interrupt1{TH0=0xD8;TL0=0xEF;Count++;//长度加1}功能:1MS延时子程序-------------------------------------------------*/ voidDelay_xMs(unsignedintx){unsignedinti,j;for(i=0;i<x;i++){for(j=0;j<3;j++);}}voidPlay_Song(unsignedchari){unsignedcharTemp1,Temp2;unsignedintAddr;Count=0;//中断计数器清0Addr=i*217;while(1){Temp1=SONG[Addr++];if(Temp1==0xFF)//休止符{TR0=0;Delay_xMs(100);}elseif(Temp1==0x00)//歌曲结束符{return;}else{Temp2=SONG[Addr++];TR0=1;while(1){_Speak=~_Speak;Delay_xMs(Temp1);if(Temp2==Count){Count=0;break;}}}}}功能:主程序-------------------------------------------------*/ voidmain(){Time0_Init();//定时器0中断初始化while(1){Play_Song(0);//播放}}。
基于51单片机蜂鸣器发声的-C语言程序
本例使用延时函数实精品文档按键发音/* 名称：按键发音说明：按下不同的按键会是SOUNDE 发出不同频率的声音。
现不同频率的声音输出，以后也可使用定时器*/#include<reg51.h>#define uchar unsigned char#define uint unsigned intsbit BEEP=P3A 7;sbit K 仁 P1A4;sbit K2=P1A5;sbit K3=P1A6;sbit K4=P1A7;// 延时void DelayMS(uint x){uchar t;while(x--) for(t=0;t<120;t++);}// 按周期 t 发音void Play(uchar t){uchar i;for(i=0;i<100;i++){BEEP=~BEEP;DelayMS(t);}BEEP=0;}void main(){P1=0xff;BEEP=0;while(1){if(K1==0) Play(1);if(K2==0) Play(2);if(K3==0) Play(3);if(K4==0) Play(4);}}精品文档播放音乐/* 名称：播放音乐说明：程序运行时播放生日快乐歌， 未使用定时器中断，所有频率完全用延时 实现*/#include<reg51.h>#define uchar unsigned char#define uint unsigned intsbit BEEP=P3A7;// 生日快乐歌的音符频率表，不同频率由不同的延时来决定uchar code SONG_TONE[]={212,212,190,212,159,169,212,212,190,212,142,159,212,212,106,126,159, 169,190,119,119,126,159,142,159,0};// 生日快乐歌节拍表，节拍决定每个音符的演奏长短uchar code SONG_LONG[]= {9,3,12,12,12,24,9,3,12,12,12,24,9,3,12,12,12,12,12,9,3,12,12,12,24,0};// 延时void DelayMS(uint x){uchar t;while(x--) for(t=0;t<120;t++);}// 播放函数void PlayMusic(){ uint i=0,j,k; while(SONG_LONG[i]!=0||SONG_TONE[i]!=0){ //播放各个音符，SONG_LON为拍子长度for(j=0;j<SONG_LONG[i]*20;j++){BEEP=~BEEP;〃SONG_TON延时表决定了每个音符的频率for(k=0;k<SONG_TONE[i]/3;k++);} DelayMS(10);i++;}}void main(){BEEP=0;while(1){PlayMusic(); // 播放生日快乐DelayMS(500); // 播放完后暂停一段时间}精品文档。
51单片机音乐播放器程序
51单片机音乐播放器程序#include //包含51单片机寄存器定义的头文件sbit sound=P3^6; //将sound位定义为P3.6unsigned int C; //储存定时器的定时常数//以下是C调低音的音频宏定义#define l_dao 262 //将"l_dao"宏定义为低音"1"的频率262Hz #define l_re 286 //将"l_re"宏定义为低音"2"的频率286Hz#define l_mi 311 //将"l_mi"宏定义为低音"3"的频率311Hz#define l_fa 349 //将"l_fa"宏定义为低音"4"的频率349Hz#define l_sao 392 //将"l_sao"宏定义为低音"5"的频率392Hz#define l_la 440 //将"l_a"宏定义为低音"6"的频率440Hz#define l_xi 494 //将"l_xi"宏定义为低音"7"的频率494Hz//以下是C调中音的音频宏定义#define dao 523 //将"dao"宏定义为中音"1"的频率523Hz#define re 587 //将"re"宏定义为中音"2"的频率587Hz#define mi 659 //将"mi"宏定义为中音"3"的频率659Hz#define fa 698 //将"fa"宏定义为中音"4"的频率698Hz#define sao 784 //将"sao"宏定义为中音"5"的频率784Hz#define la 880 //将"la"宏定义为中音"6"的频率880Hz#define xi 987 //将"xi"宏定义为中音"7"的频率523H//以下是C调高音的音频宏定义#define h_dao 1046 //将"h_dao"宏定义为高音"1"的频率1046Hz #define h_re 1174 //将"h_re"宏定义为高音"2"的频率1174Hz#define h_mi 1318 //将"h_mi"宏定义为高音"3"的频率1318Hz #define h_fa 1396 //将"h_fa"宏定义为高音"4"的频率1396Hz #define h_sao 1567 //将"h_sao"宏定义为高音"5"的频率1567Hz #define h_la 1760 //将"h_la"宏定义为高音"6"的频率1760Hz#define h_xi 1975 //将"h_xi"宏定义为高音"7"的频率1975Hz /*******************************************函数功能：1个延时单位，延时300ms******************************************/void delay(){unsigned char i,j;for(i=0;i<300;i++)for(j=0;j<300;j++);}/*******************************************函数功能：主函数******************************************/void main(void){unsigned char i,j;//以下是《知足》的一段简谱unsignedint code f[]={ dao,l_xi,dao ,sao,sao,dao,l_xi,dao,mi,dao,l_xi,dao,l_sao,mi,re,l_la,l_xi,dao,re,dao,l_xi,dao,sao,sao,la,xi,la,mi,la,xi,h_dao,sao,mi,mi,fa,mi,l_la,re,dao,dao,l_xi,dao,sao,sao,dao,l_xi,dao,mi,dao,l_xi,dao,l_sao,mi,re,l_la,l_xi,dao,re,dao,l_xi,dao,sao,sao,la,xi,h_dao,sao,la,xi,h_dao,sao,mi,mi,fa,mi,l_sao,re, dao,l_sao,h_dao,xi, la,fa,re, re,l_sao,xi,la,sao,re,dao,dao,re,mi,fa,fa,la,sao,mi,re,mi,fa,fa,sao,dao,h_dao,xi, la,fa,xi,h_dao,h_re, sao,h_re,xi,h_dao,la,xi,h_dao,h_re,sao,0xff}; //以0xff作为音符的结束标志//以下是简谱中每个音符的节拍//"4"对应4个延时单位，"2"对应2个延时单位，"1"对应1个延时单位unsigned char code JP[ ]={2,1,1,2,2,2,1,1,4,2,1,1,2,2,1,1,1,1,4,2,1,1,2,1,1,2,1,1,4,2,1,1,2,1,1,1,1,1,1,4,2,1,1,2,2,2,1,1,4,2,1,1,2,2,1,1,1,1,4,2,1,1,2,2,2,1,1,4,2,1,1,2,1,1,1,1,1,1,1,1,1,1,2,1,1,1,1,1,1,2,1,1,2,1,1,2,1,1,2,1,1,1,1,1,1,2,2,1,1,2,2,1,1,3,1/2,1/2,3,1/2,1/2,3,1,4,};EA=1; //开总中断ET0=1; //定时器T0中断允许TMOD=0x00; // 使用定时器T0的模式1（13位计数器）while(1) //无限循环{i=0; //从第1个音符f[0]开始播放while(f[i]!=0xff) //只要没有读到结束标志就继续播放{C=460830/f[i];TH0=(8192-C)/32; //可证明这是13位计数器TH0高8位的赋初值方法TL0=(8192-C)%32; //可证明这是13位计数器TL0低5位的赋初值方法TR0=1; //启动定时器T0for(j=0;j<="">delay(); //延时1个节拍单位TR0=0; //关闭定时器T0i++; //播放下一个音符}}}/*********************************************************** 函数功能：定时器T0的中断服务子程序，使P3.7引脚输出音频的方波************************************************************/ void Time0(void ) interrupt 1 using 1{sound=!sound; //将P3.7引脚输出电平取反，形成方波TH0=(8192-C)/32; //可证明这是13位计数器TH0高8位的赋初值方法TL0=(8192-C)%32; //可证明这是13位计数器TL0低5位的赋初值方法}。
