3M 6011低温快速固化单组份环氧胶技术资料

低温快速热固化单组份环氧胶6011 （临时临时））

***** 2012年9月

产品简介

3M TM 6011是3M 公司开发的一种单组份，低温快速热固化的改性环氧树脂胶粘剂。能

在较低温度、极短的时间内，在多种不同类型的材料之间形成极佳的粘接力。产品工作

性能优良，具有较高的储存稳定性。

典型应用

本产品可以很好地满足低温固化制程，粘接热敏感性元器件，比如记忆卡、CCD/CMOS 、

LED 透镜等器件。

产品参数1

性能

单位 典型数值 参考测试条件 粘度，23℃*

cP 14000**，可调节 60℃ 8 - 10 分钟 固化条件

90℃ 1.5 - 2 分钟 烘箱， 温度越高，所需固化时间越短 固化后硬度

邵氏D 78 60℃ 6’或90℃ 1’30”固化 13 PC/ABS 和打磨铝片 粘接强度

MPa 18 打磨铝片和打磨铝片 工作寿命，23℃

小时 24 适用期，23℃

天 14 储存期，-20℃

月 6 外观 黑色或白色半粘稠液体

* Brookfield

** 1mPa.s=1cPoise

1 产品参数为测试典型数值，不作为产品标准范围

注意：粘接部位可能需要加热一定的时间才能达到固化的温度。固化条件会因不同的装置

而不同。实际固化温度和时间，需要客户根据自己的具体应用来选择。

产品产品储存条件储存条件储存条件和保质期和保质期

除非标签上另有特别注明，本产品的理想贮存条件是在-20ºC 下将未开口的产品密封冷

藏在干燥的地方。

为避免污染原装胶粘剂，不得将任何用过的胶粘剂倒回原包装内。

储存期限：自生产之日起6个月。

3M一级代理商

苏州专新2013.05.29

注意事项

1. 请在室温下使用，防止高温；

2. 产品从仓库中取出后，避免立即开封，应先在室温下放置大概2个小时使其回温到

室温后再开封使用（回温时间与包装大小及环境气氛有关）

3.

使用时避免直接接触，应使用手套等保护设备；若接触到皮肤，应立即洗涤；

4. 充分保障工作场所的换气。

Important Notice 3M MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED

WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. User is responsible for

determining whether the 3M product is fit for a particular purpose and suitable for user’s method of application. Please

remember that many factors can affect the use and performance of a 3M product in a particular application. The

materials to be bonded with the product, the surface preparation of those materials, the product selected for use, the

conditions in which the product is used, and the time and environmental conditions in which the product is expected to

perform are among the many factors that can affect the use and performance of a 3M product. Given the variety of

factors that can affect the use and performance of a 3M product, some of which are uniquely within the user’s

knowledge and

control, it is essential that the user evaluate the 3M product to determine whether it is fit for a particular purpose and

suitable for the user’s method of application.

Limitation of Remedies and Liability

If the 3M product is proved to be defective, The exclusive remedy, at 3M’S option, shall be to refund the purchase

price of or to repair or rplace the defective 3M product. 3M shall not otherwise be liable for loss or damages, whether

direct, indirect, special, incidental, or consequential, regardless of the legal theory asserted, including, but not limited

to, contract, negligence, warranty, or strict liability.

This product was manufactured under a 3M quality system registered to ISO 9002 standards.

3

3M Maxdo, Xingyi Road 8

Shanghai, PRC. 3M一级代理商

苏州专新

2013.05.29
