产品规格书品名：Smart dust微尘传感器型号：S7
（V1.2）
广州勒夫迈智能科技有限公司研发中心
目录
1.S7Smart Dust产品概述 (3)
1.1S7Smart Dust微尘传感器在吸尘器和扫地机器人产品的应用效益 (3)
1.2S7Smart Dust微尘传感器的产品特性 (3)
1.3应用领域 (4)
1.4基本特性 (4)
1.5接口定义 (5)
1.6应用电路 (6)
1.7数据传输 (7)
2.产品尺寸图 (7)
3.安装示意图 (8)
安装注意事项： (8)
附录1--S7Smart Dust微尘传感器UART数据说明 (9)
1.S7Smart Dust产品概述
S7Smart Dust微尘传感器产品利用光学的对射原理，可以精准地检测出经过吸尘器的手柄或延长杆管道、扫地机器人、抽油烟机、粒子检测仪器等设备的通风管道中的粒子数量和浓度数据。
1.1S7Smart Dust微尘传感器在吸尘器和扫地机器人产品的应用效益
◆设备的吸尘洁净效果和地面，地毯，床单等的洁净度，通过传感器输出数据和LED颜色显示直观地呈现给使用者；
◆设备根据传感器数据智能控制马达的转速，达到静音节能省电和延长马达寿命；
1.2S7Smart Dust微尘传感器的产品特性
◆产品为宽电压供电电压范围：12V--30V，可以直接用驱动马达的PWM 信号线为其供电;
◆产品采用发射和接收对射分离结构，具有体积小，便于用户在各种复杂的结构中灵活安装使用：接收主机L34*W30*H8.5mm,发射端L15*W7*H6.5;
◆运动测量精度高，风速12m/s时最小检测粒径10um;
◆测量灵敏度高，响应时间小于0.3s;
◆测量范围宽：0-999与0--9999两种选项量程;
◆功耗低：工作电流小于30mA，休眠电流小于0.5mA.
◆输出接口含有3PIN组成的7种颜色的颗粒浓度LED驱动电平，可以外接LED指示灯；
◆数据颗粒浓度输出接口：PWM,UART可以实时地为吸尘器、扫地机器人等设备提供准确的微尘浓度数据。
1.3应用领域
●吸尘器
●扫地机器人
●抽油烟机
●智能检测仪
1.4基本特性
传感器参数
参数指标单位
微尘测量范围≥5微米（μm）微尘质量浓度有效量程0~3000mg/m2
微尘质量浓度分辨率1mg/m2
单次响应时间≤0.3秒（s）
供电电源驱动马达的方波电压(12-30V)伏特（V）
工作电流≤30毫安（mA）待机电流≤0.5毫安（m A）数据接口电平L<0.8@3.3H>2.7@3.3伏特（V）
工作温度范围-10℃～+65℃（无结露）摄氏度（℃）工作湿度范围0~98%（非凝结）
储存温度范围-20℃～+80℃（无结露）摄氏度（℃）平均无故障时间≥5年（Y）
接口方式： 1.25mm*13P连接器
输出方式UART&PWM
接收主板尺寸34×30×8.5(传感器主体)毫米（mm）
＜注意点＞
●本产品原则上仅适用于上述应用领域，用作其他用途时，需要用户自行验证。
●本产品请尽量远离高频高压发生源，以避免因高频高压造成的干扰。
●无规则的剧烈震动会造成本产品测量误差增大。
●外界光会造成本产品的测量误差增大，因此安装于设备时，应尽量避免外
界光的射入。
1.5接口定义
PIN13PIN1
PIN1VCC外部电源输入
PIN2GND电源地
PIN3SET 设置管脚/TTL电平@3.3V，高电平或悬空为正常工作状态，低电平为休眠状态
PIN4RX串口接收管脚/TTL电平@3.3V
PIN5TX串口发送管脚/TTL电平@3.3V
PIN6RESET模块复位信号/TTL电平@3.3V，低复位
PIN7预留
PIN8PWM脉宽调制信号输出
PIN9GND电源地
PIN10VDD输出电源正3.3VDC负载20mA Max@25VDC输入PIN11R三基色LED-R驱动输出
PIN12G三基色LED-G驱动输出
PIN13Y三基色LED-Y驱动输出
1.6应用电路
电路设计应注意:
1.S7输出接口的数据通讯和控制管脚均需要3.3V作为高电平。
（主板MCU为5V
供电，需要在通讯线（RXD、TXD）和控制线（SET、RESET）上加入电平转换芯片或电路）
2.SET和RESET内部有上拉电阻，如果不使用，则应悬空。
3.PIN7为程序内部调试用，应用电路中应使其悬空。
4.传感器VDD输出电压+3.3VDC，负载电流20mA Max。
5.R\G\Y驱动输出需要连接外围转换电路实现，如：图1电路仅作参考。
图1
1.7数据传输
UART输出
传感器采用标准全双工UART串口通信，波特率为9600bps，在应用过程中，只需接收微尘浓度数据，传感器默认状态下为持续工作，串口数据解码后得到微尘浓度值，单位为mg/m²。
详细的串口通信格式及数据解码参见《附录1》。
PWM输出
传感器通过PWM口输出PWM信号，该PWM周期为1S，按低电平宽度计算微尘浓度值。
低脉冲时间与微尘浓度的关系：1ms=1mg/m²。
例如低电平宽度为100ms，则对应灰尘浓度为100mg/m²。
PWM浓度输出范围为5mg/m²～800 mg/m²。
2.产品尺寸图
单位：mm.发射管部分
接收部分
3.安装示意图
安装注意事项：
●发射管与传感器主体通过线材连接；
● 安装发射管和接收管时，应采取减振措施，尽量避免振动；●应保证发射管与接收管之间呈现180°；●发射管与接收管的距离应小于等于60mm；
附录1--S7Smart Dust 微尘传感器UART 数据说明
1.UART 参数：
默认波特率：9600bps 位数：8Bit 校验位：无停止位：1位
2.主机通讯协议格式特征字节1特征字节2指令字节状态字节1状态字节
2
校验字节1校验字节20x420x4D
CMD
DATAH DATAL LRCH LRCL
3.指令及特征字节定义CMD DATAH DATAL
说明
0xE2X X
被动式读数0xE1X 00H-被动式01H-主动式状态切换0xE4
X
00H-待机模式01H-正常模式
待机控制
4.指令应答：
0xE2:应答32字节，同采样数据类型协议。
5.校验字生成
从特征字开始所有字节累加和。
发射管部分
180°对射
安装管道部分
接收部分
180°对射
连接线
6.采样数据类型总长度：32字节
起始符10x42（固定）
起始符20x4D（固定）
帧长度高八位……帧长度=2x13+2(数据+校验位)
帧长度低八位……
数据1高八位……数据1表示等效螨虫粒径颗粒物个数
(识别率≥90%)
数据1低八位……
数据2高八位……数据2表示PM20浓度
mg/m²
数据2低八位……
数据3高八位……数据3表示PM30浓度
mg/m²
数据3低八位……
数据4高八位……数据4表示PM50浓度
mg/m²
数据4低八位……
数据5高八位……数据5表示微尘总浓度
mg/m²
数据5低八位……
数据6高八位……保留
数据6低八位……
数据7高八位……保留
数据7低八位……
数据8高八位……保留
数据8低八位……
数据9高八位……保留
数据9低八位……
数据10高八位……保留
数据10低八位……
数据11高八位……保留
数据11低八位……
数据12高八位……保留
数据12低八位……
数据13高八位……版本号
数据13低八位……错误代码
数据和校验高八位……校验码=起始符1+起始符2+……..+数据13低
八位
数据和校验低八位……
注：用户一般取数据5的高低八位为最终的微尘总浓度。
