六层框架结构图书馆毕业设计

【内容摘要】：本设计主要进行了结构方案中横向框架③轴框架的抗震设计。在确定框架布局之后，先进行了层间荷载代表值的计算，接着利用顶点位移法求出自震周期，进而按底部剪力法计算水平地震荷载作用下大小，进而求出在水平荷载作用下结构内力（弯矩、剪力、轴力）。接着计算竖向荷载（恒载、活荷载以及雪荷载）作用下的结构内力，结合EXCEL软件进行验算，并找出最不利的一组或几组内力组合。选取最安全的结果计算配筋并绘图。此外还进行了结构方案中的室内楼梯的设计（完成了平台板、梯段板、平台梁等构件的内力和配筋计算及施工图绘制）、楼盖的设计（完成了板的配筋和梁的配筋）、基础的设计等。【关键词】：框架结构结构计算抗震设计

【Abstract】:The purpose of the design is to do the anti-seismic design in the longitudinal frames of axis③.When the directions of the frames is determined, firstly the weight of each floor is calculated. Then the vibrate cycle is calculated by utilizing the peak-displacement method, then making the amount of the horizontal seismic force can be got by way of the bottom-shear force method. Then seismic force can be assigned according to the shearing stiffness of the frames of the different axis. Then the internal force (bending moment, shearing force, axial force & snow force) in the structure under the horizontal loads can be easily calculated. After the determination of the internal force under the dead and live loads, the combination of internal force can be made by using the Excel software, whose purpose is to find one or several sets of the most adverse internal force of the wall limbs and the coterminous girders, which will be the basis of protracting the reinforcing drawings of the components. The design of the stairs is also be approached by calculating the internal force and reinforcing such components as landing slab, step board and landing girder whose shop drawings are completed. The design of floors lab, foundation and “#”-floorslab is also be completed in the end.

【Keywords】: frames structures, structural design, anti-seismic design.

目录

1.中英文内容摘要 (1)

2.设计任务书 (1)

2.1工程概况 (1)

2.2地质、水文及气象资料 (1)

2.3施工技术条件及建筑材料供应 (1)

2.4设计内容及要求 (1)

2.4.1建筑设计部分 (1)

2.4.2结构设计部分 (2)

3.前言 (3)

4.工程概况 (4)

4.1工程概况 (4)

4.2柱网布置 (4)

4.3框架结构承重方案的选择 (4)

4.4框架结构的计算简图 (5)

4.5初估梁柱截面尺寸 (6)

4.5.1梁截面尺寸初选 (6)

4.5.2柱截面尺寸初选 (6)

5.框架侧移刚度的计算 (7)

i的计算 (8)

5.1横梁线刚度

b

i的计算 (8)

5.2纵梁线刚度

b

i的计算 (8)

5.3柱线刚度

c

5.4各层横向侧移刚度计算（D值法） (8)

6.重力荷载代表值的计算 (10)

6.1楼屋面永久荷载标准值 (10)

6.2屋面及楼面可变荷载标准值 (11)

6.3墙、门、窗重力荷载计算 (11)

6.4梁、柱计算 (11)

6.4.1梁柱平面布置图 (11)

6.4.2梁、柱重力荷载计算 (11)

6.5各质点重力荷载代表值计算 (13)

7.横向水平荷载作用下框架结构的内力和侧移计算 (18)

7.1横向自振周期的计算 (18)

7.2水平地震作用及楼层地震剪力的计算 (19)

7.3多遇水平地震作用下的位移验算 (20)

7.4水平地震作用下框架内力计算 (21)

8.竖向荷载作用下框架结构的内力计算 (26)

8.1计算单元确定 (26)

8.2荷载计算 (26)

8.2.1恒载作用 (26)

8.2.2活载作用 (28)

8.3内力计算 (29)

9.横向框架内力组合 (36)

9.1结构抗震等级 (36)
