UL3239硅橡胶绝缘耐高电压电线(150℃)

UL3239 Silicone Rubber High Voltage Resistance Wire

性能/Properties:

z Rated Temperature: 150.

℃ Highest Instantaneous Temperature: 200℃. Lowest temperature: -50℃

额定耐温: 150,

℃短时最高使用环境温度: 200℃,最低使用环境温度: -50℃。

z Rated Voltage in D.C.: 50KV, 40KV, 30KV, 20KV, 10KV, 6KV and 3KV. Suitable in varies external condition 最高耐直流电压: 50KV、40KV、30KV、20KV、10KV、6KV、3KV。适应于不同条件下使用。

z Solid and Stranded Conductor: 28~14AWG(0.08~2.08mm2)Tin-coated copper

导体使用镀锡铜28~14AWG(0.08~2.08mm2)的单支线或多支绞线。

z Different Color Options for Silicone Rubber Insulation: Red, Black, Blue, Grey, Yellow, Brown, Green, Orange, White, Translucent 绝缘采用硅橡胶,颜色有:红、黑、蓝、灰、黄、棕、绿、橙、白、半透明等。

符合欧盟RoHS环保指令要求。RoHS Compliant

z High voltage lead wire for electronic appliances and other equipment such as screen display, microwave oven, and automation etc.

电子电器及其它器械的高电压导线(如显示器、微波炉、灯具、汽车等的高电压连接线)。

镀锡铜导体

Tin-Coated Copper 硅橡胶绝缘

Silicone Rubber Insulation

E204798 ul 3239 18AWG 20KV-DC 150℃ FENG TAI ELECTRONIC -ROHS-

UL3239硅橡胶绝缘耐高压电线技术参数表

UL Style 3239 Silicone Rubber High V oltage Resistance Wire Specification 50KV 耐电压40KV 耐电压30KV 耐电压20KV 耐电压10KV

绝缘厚度Insul Thk. mm

电线

外径

Overall

Dia.

mm

绝缘

厚度

Insul

Thk.

mm

电线

外径

Overall

Dia.

mm

绝缘

厚度

Insul

Thk.

mm

电线

外径

Overall

Dia.

mm

绝缘

厚度

Insul

Thk.

mm

电线

外径

Overall

Dia.

mm

绝缘

厚度

Insul

Thk.

mm

2.88 2.33

2.92 2.36

2.98 2.42 1.82 1.42

3.80

3.00 2.45 1.86 1.46

3.30 2.70 2.30

6.85 5.95 5.10 4.20 3.70 3.00 2.60

3.80

1.35

z Allowable Tolerance for Wire Overall Diameter: ±6%

z电线外径允差±6%;

z Double Insulation Layer for 30KV, 40KV and 50KV HV Wire. Single Insulation is optional upon requested.

z30KV、40KV、50KV电线一般为双绝缘层,也可制作单绝缘;

z Single Insulation Layer for 3KV ~ 20KV HV Wire. Double Insulation is optional upon request.

z3KV~20KV电线一般为单层绝缘,10KV、20KV电线也可按客户要求制作双层绝缘。
