道路交通工程专业外文翻译外文文献英文文献

合集下载

公路通行能力外文翻译文献

公路通行能力外文翻译文献(文档含中英文对照即英文原文和中文翻译)Highway Capacity And Levels of Service Capacity DefinedA generalized definition of capacity is: The capacity of any element of the highway system is the maximum number of vehicles which has a reasonable expectation of passing over that section (in either one or both directions) during a given time period under prevailing roadway and trafficconditions. A sampling of capacities for modern highway elements is as follows:Capacity in PassengerFacilityCars Freeways and expressways away from ramps and2000 weaving sections, per lane per hourTwo-Lane highways, total in both directions, per2000hourThree-lane highways, total in each direction, per2000hourTwelve-foot lane at signalized intersection, per hour1800of green signal time(no interference and idealprogression)In treating capacity，TRB Circular 212 divides freeways into components: basic freeway segments and those in the zone of influence of weaving areas and ramp junctions. Capacities of expressways，multilane highways，and two- and three-lane facilities also have the two components: basic and those in the zone of influence of intersections. Each of these is treated separately below.Speed-Volume-Capacity Relationships for BasicFreeway and Multilane Highway SegmentsA knowledge of the relationships among speed，volume，and capacity is basic to understanding the place of capacity in highway design and operation. Figurel3.1，which gives such a relationship for a single freeway or expressway lane, is used for illustrative purposes.If a lone vehicle travels along a traffic lane，the driver is free to proceed at the design speed. This situation is represented at the beginning of the appropriate curve at the upper left of Fig. 13.1. But as the number of vehicles in the lane increases, the driver's freedom to select speed is restricted. This restriction brings a progressive reduction in speed. For example，many observations have shown that，for a highway designed for 70 mph (113km/h)，when volume reaches 1900 passenger cars per hour，traffic is slowed to about 43 mph (69km/h). If volume increases further, the relatively stable normal-flow condition usually found at lower volumes is subject to breakdown. This zone of instability is shown by the shaded area on the right side of Fig. 13. 1. One possible consequence is that traffic flow will stabilize at about 2000 vehicles per hour at a velocity of 30 to 40 mph (48 to 64km/h) as shown by the curved solid line on Fig. 13. 1. Often，however , the quality of flow deteriorates and a substantial drop in velocity occurs; in extreme cases vehicles may come to a full stop. In this case the volume of flow quickly decreases as traffic proceeds under a condition known as …forced flow.‟ V olumes under forced flow are shown by the dashed curve at the bottom of Fig. 13. 1. Reading from that curve，it can be seenthat if the speed falls to 20 mph (32km/h)，the rate of flow will drop to 1700 vehicles per hour; at 10 mph （16km/h) the flow rate is only 1000;and,of course，if vehicles stop，the rate of flow is 0. The result of this reduction in flow rate is that following vehicles all must slow or stop，and the rate of flow falls to the levels shown. Even in those cases where the congestion lasts but a few seconds, additional vehicles are affected after the congestion at the original location has disappeared. A …shock wave’develops which moves along the traffic lane in the direction opposite to that of vehicle travel. Such waves have been observed several miles from the scene of the original point of congestion，with vehicles slowing or stopping and then resuming speed for no apparent reason whatsoever.Effects of the imposition of speed limits of 60, 50, and 40 mph are suggested by the dotted lines on Fig. 13. 1. A 55-mph (88km/h) curve could also be drawn midway between the 60 and 50 mph dotted curves to reflect the effects of the federally imposed 55-mph limit, but this is conjectural since the level of enforcement varies so widely.Vehicle spacing，or its reciprocal, traffic density, probably have the greatest effect on capacity since it generates the driver's feeling of freedom or constraint more than any other factor. Studies of drivers as they follow other vehicles indicate that the time required to reach a potential collision point，rather than vehicle separation，seems to control behavior. However，this time varies widely among drivers and situations. Field observations have recordedheadways (time between vehicles) ranging from 0. 5 to 2 sec, with an average of about 1. 5s.Thus，the calculated capacity of a traffic lane based on this 1. 5 s average, regardless of speed，will be 2400 vehicles per hour. But even under the best of conditions, occasional gaps in the traffic stream can be expected，so that such high flows are not common. Rather, as noted，they are nearer to 2000 passenger cars per hour.The ‘Level of Service’ ConceptAs indicated in the discussion of the relationships of speed, volume or density, and vehicle spacing, operating speed goes down and driver restrictions become greater as traffic volume increase. …Level of service‟ is commonly accepted as a measure of the restrictive effects of increased volume. Each segment of roadway can be rated at an appropriate level，A to F inclusive，to reflect its condition at the given demand or service volume. Level A represents almost ideal conditions; Level E is at capacity; Level F indicates forced flow.The two best measures for level of service for uninterrupted flow conditions are operating or travel speed and the radio of volume to capacity达到最大限度的广播，called the v/c ratio. For two- and three-lane roads sight distance is also important.Abbreviated descriptions of operating conditions for the various levels of service are as follows:Level A—Free flow; speed controlled by driver's desire，speed limits, orphysical roadway conditions.Level B—Stable flow; operating speeds beginning to be restricted; little or no restrictions on maneuverability from other vehicles.Level C—Stable flow; speeds and maneuverability more closely restricted.Level D—Approaches unstable flow; tolerable speeds can be maintained but temporary restrictions to flow cause substantial drops in speed. Little freedom to maneuver，comfort and convenience low.Level E—V olumes near capacity; speed typically in neighborhood of 30 mph (48km/h); flow unstable; stoppages of momentary duration. Ability to maneuver severely limited.Level F—Forced flow，low-operating speeds，volumes below capacity; queues formed.A third measure of level of service suggested in TRB Circular 212 is traffic density. This is，for a traffic lane，the average number of vehicles occupying a mile (1. 6km) of lane at a given instant. To illustrate，if the average speed is 50 mph，a vehicle is in a given mile for 72 s. If the lane carrying 800 vehicles per hour，average density is then 16 vehicles per mile ;spacing is 330 ft (100m)，center to center. The advantage of the density approach is that the various levels of service can be measured or portrayed in photographs.From: Clarkson H. Oglesby and R. Gary Hicks “Highwayengineering”, 1982公路通行能力和服务水平通行能力的定义道路通行能力的广义定义是：在繁忙的道路和交通条件下公路系统任何元素的通行能力是对在指定的时间通过一断面（一个或两个方向）的最大数量的车辆有一个合理的预期。

交通毕业设计外文及翻译（最终五篇）

交通毕业设计外文及翻译（最终五篇）第一篇：交通毕业设计外文及翻译Synchro在交通控制与设计中的应用在城市的较小的区域内，可以对区域内的所有交叉口进行控制;在城市较大的区域，可以对区域进行分区分级控制。

分区的结果往往使面控制成为一个由几条线控制组成的分级集中控制系统，这时，可认为各线控制是面控制中的一个单元；有时分区的结果是成为一个点，线，面控制的综合性分级控制系统。

现在对城市道路进行区域协调控制就是将其划分为多级多个信号控制子区，对信号子区进行协调控制，优化管理控制信号子区，然后对整个道路进行区域协调控制，达到整个城市道路优化的目的。

把城市道路划分为多个信号控制子区，也就是进行城市道路干线交叉口交通信号协调控制，把城市划分为多个主路控制，再把主路上各个交叉口进行联动控制，同时，对单个交叉口信号控制优化的同时需要考虑主路上下游各个交叉口的联动控制。

主路上的各个交叉口按照设计的信号配时方案进行运行，使车辆进入城市主干道交叉口时，不至经常遇到红灯，称为城市主干道交叉口信号协调控制，称为“绿波”信号控制。

城市单点交叉口作为城市交通网络中的重要组成部分，作为城市道路交通问题的关键点。

对城市单点交叉口，评价标准的参考指标：交叉口的通行能力、进口道的饱和度、道路交叉口进口道停车延误、交叉口进口道停车次数、进口道排队长度和汽车的油耗等。

交叉口定时信号控制配时方法在不断的改进之中，国内外大部分学者认为从不同的评价指标出发，可以采用不同的种优化算法寻求其它更合理的配时方法。

平面交叉口按交通管制方式可以分为全无控制交叉口、主路优先控制交叉口、信号灯控制交叉口、环形交叉口等几种类型。

主路优先控制交叉口，是在次路上设停车让行或减速让行标志，指令次路车辆必须停车或减速让主路车辆优先通行的一种交通管制方式。

交叉口是道路网中通行能力的“瓶颈”和交通事故的“黑点”。

国内外城市中的交通堵塞主要发上在交叉口，造成车辆中断，事故增多，延误严重。

道路条件交通安全英文文献翻译

Vision Zero – Implementing a policy for traffic safety The scope of this paper is to outline, in a general way, the safety philosophy inherent in present road- and street design, trace the origin of this philosophy, and to present the principles for a new design of streets and roads. It will be argued that deficiencies in the present road design philosophy are the main cause of the global road safety crisis, clearly indicating its man-made nature. A brief description is made of the decision process leading to the establishment of Vision Zero as Sweden’s Traffic Safety Policy in 1997.Following an analysis of the problem, suggestions are made for finding solutions. The solutions are based on some of the principles in Vision Zero. They include a new basic mechanism for creating error-tolerance in the road system, and new design principles for road- and street design.The tradition of “blaming the victim” is hereby questioned and focus is put on the need for professionals to act based on these new standards. During the last 10 years the fatalities in Sweden have dropped from approximately 550/year to 450/year. Roads redesigned with median barriers have an 80% reduction in fatalities. Streets with 30 km/h design speed show similar results. This indicates that measures derived from Vision Zero strategy are effective but that large scale implementation has not yet been done.1. The processThe Swedish Road Administration (SRA) had an overall responsibility for Road Traffic Safety in Sweden since 1993. This responsibility was further clarified by the Government in 1996. Sweden has very small Ministries (number of personnel). As a consequence Administrations like the SRA often have semi-political tasks like development of policies and targets. Decisions on policy, long term targets and overall budgets are made by the Government or the Parliament but development is made in the Administration.Following the elections in the autumn 1994 Sweden got a new Minister for Transportation. The Minister declared that traffic safety would be one of her priorities. A dialog was started between the Minister’s Staff and the SRA on how the Minister could make traffic safety a prioritized subject.In the spring of 1994 the SRA together with the major stakeholders for traffic safety had presented a short term program for action for theyears of 1994–2000. It had the character of continuing earlier work but with more emphasis on cooperation between key actors and focus on results. Directly after this program was launched the SRA started to develop some basic ideas for a long term strategy for traffic safety. It had been recognised for some time that the contemporary traffic safety paradigm had some problems (Johansson, 1991). Part of this problem was a lack of expected benefits of many measures, something that was recognised by among others Gerald Wilde (best described in Wilde, 2001). A comprehensive overview can be found in OECD (1990).The new safety paradigm, Vision Zero is built around the basic idea that even if not all crashes or collisions can be avoided, all severe injuries can, in principle, be avoided. The basic idea was to build a “safe system” where all predicted crashes and collisions had tolerable health losses. The Minister and her Staff recognised that it was possible to work with the ideas behind Vision Zero in a political setting and quickly adopted the basic ideas, developed a text (translated in Belin et al., 1997), and took it to the Parliament in 1997, where it was accepted by all political parties (Tingvall, 1998). Since then, the Parliament has repeated this decision on a number of occasions. The notion of “Vision Zero” has become synonymous with the concept of “high political ambitions” in a number of other areas as well. The Government in 2008 took a decision on a Vision Zero for suicide. Much of the political debate on Vision Zero between 1995 and the Parliament’s decision in 1997 was concentrated on the question”How many fatalities can we accept” At this time Sweden had around 500 fatalities in road traffic per year. Comparisons where made with the safety level for other transport modes, (clearly a zero fatality goal), occupational safety (about 50 fatalities annually), electricity (about five fatalities annually). From this political analysis it was concluded that a zero fatality target was the only justifiable target for road traffic.During the same time period SRA and its network concentrated work on developing strategies for radically lowering fatality risks in road traffic, typically aiming at reducing fatality risks with a factor 10. Examples follow later in this paper.2. Vision ZeroIn 1997 the Swedish Parliament passed a bill on Traffic Safety where it was stated that:“Vision Zero means that eventually no one will be killed orseriously injured within the r oad transport system.”Vision Zero does not presume that all accidents that result in personal property damage or in less serious injuries must be eliminated. These occurrences are not considered to be an essential element in the road traffic safety problem even if they can entail large costs for the State, county councils, municipalities and individuals. Rather, focus shall be placed on those incidents that lead to a person being killed or seriously injured. Vision Zero also proposes an ethical approach to the health problems associated with road traffic:“It can never be ethically acceptable that people are killed or seriously injured when moving within the road transport system.”Vision Zero is said to be a long-term goal for the design and functioning of the road transport system. What is important is to realise that the Vision Zero approach will alter the aim of the work on road traffic safety; ., from attempting to reduce the number of accidents to the formulation of an explicit goal: to eliminate the risk of chronic health impairment caused by a traffic accident. This new approach will also alter the question from “what can we do” to “what must we do”Vision Zero presumes a new division of responsibility for road traffic safety within the road transport system. The responsibility for road traffic safety should be introduced along the following lines.1. The designers of the system are always ultimately responsible for the design, operations and use of the road transport system and are thereby responsible for the level of safety within the entire system.2. Road users are responsible for following the rules for using the road transport system set by the system designers.3. If road users fail to obey these rules due to a lack of knowledge, acceptance or ability, or if injuries do occur, the system designers are required to take the necessary further steps to counteract people being killed and seriously injured.Taking the Vision Zero approach means that paying attention to human life and health is an absolute requirement in the design and functioning of the road transport system. This implies that road traffic safety issues, in similarity to environmental issues, must be clearly integrated in all the processes that affect road traffic safety in the road transport system and be based on the following:“The level of violence that the human body can tolerate without being killed or seriously injured shall be the basic parameter in the designof the road transport system.”It is upon this principle that the future society with safe road traffic can develop: through designing and constructing roads, vehicles and transport services so that the level of violence that can be tolerated by the human being is not exceeded; and through the effective contribution of different support systems such as rules and regulations, education, information, surveillance, rescue services, care and rehabilitation. With this as the basis, there will be a positive demand for new and effective solutions that can contribute to a road transport system where human needs, prerequisites and demands are in focus.“It is true, that 95% of all crashes or collisions depend on human error, but according to Vision Zero philosophy, 95% of the solutions are in changing roads, streets or vehicles.”Some simple examples follow:(1) Drivers in Sweden used to have a 92% seat-belt wearing rate. Good but not good enough. EuroNCaP1 established a protocol for seat-belt reminders a couple of years ago having the effect that 70% of new cars sold in Sweden 2005 had seat-belt reminders. The drivers of these cars have a seat-belt wearing rate of 99%. Hence, the problem of seat-belt wearing will gradually be solved at a very low cost.(2) Alcohol: All over the world alcohol and traffic is a big problem, even if improvements can be made with strict legislation and enforcement. By demonstrating a demand for safe transport primarily by professional transporters a demand for “proven sober” transports has risen. In Sweden about 50% of all school buses have alcohol interlocks (a device that checks if the driver is sober). A new generation of Alco locks are coming on the market (at least four competitors in Europe/USA) reducing price and improving performance.In this way a car that reminds you to use your seat-belt, and checks your breath for alcohol, or otherwise checks your performance, and assists you to be a better, safer driver. Different aspects of the Vision Zero philosophy can be found in (Tingvall et al., 1996, 1997; Tingvall, 1998, 2007; Belin et al., 1997).3. Traditional road design philosophyThe traditional road-oriented safety philosophy has as its starting point the ‘‘accident”. Accident statistics are normally based on police reports made up on traffic accidents known to the police. These statistics have been used by road authorities world-wide for describing and analysing the road safety problem associated with roads and roaddesign. It is important to notice that the conceptsof traffic accidents and (bad) road safety are not synonymous. Many accidents could be an indicator of (bad) safety, but if the accidents do not lead to personal injuries they are not. Road safety is a ‘loss of health’ problem. A crash or accident without loss of health is no safety problem, only a cost. But the thesis put forward in this paper is another, namely that by choosing the ‘‘accident” perspective, you get a safety philosophy that at its best reduces accidents, not necessarily personal injuries. And, as all modern definitions of the traffic safety problem define it as a health problem (health loss) the accident perspective misses the target.Accident analysis shows typically that 90–95% of all accidents are caused by road users. Society’s most fundamental response to accident prevention has been rules and regulations for road user behaviour. The purpose of traffic legislation is mainly to simplify the tasks for road users, making the risk of accident lower. In many cases this works as intended. But if focus is shifted to the effect of the traffic regulation on health loss, the pattern is less clear. Examples could be, for instance, traffic lights and pedestrian crossings. Installing traffic lights typically results in fewer crashes, but more severe injuries. Pedestrian crossings generally do not lead to a safer crossing for pedestrians; they facilitate crossing a street but provide no safety in themselves.When it comes to road- and street design the dominant safety strategy overall has been to increase space for drivers and vehicles. That is, wider lanes, wider roads, straighter roads, larger crossings etc. The reasoning behind this is straightforward and logical; if drivers run off the road, make the road a little bit wider so there is room for manoeuvring the vehicle back into the lane and keeping the vehicle on the road; if drivers run off the road in bends, try making the road a little bit straighter thereby avoiding accidents in bends. This strategy has had some success in reducing the number of accidents, but even the effect on the accident risk has been questioned (Hauer, 1999). The strategy to create space for evasive action has not been successful in reducing fatalities and other severe injuries. In fact, everything else considered, this strategy increases fatalities and other health losses. A wide, strait road has more fatalities than a narrow road with many curves if everything else is the same. The reason is simple: the most predominant effect of creating more space is an increase in driving speed, which means higher levels of kinetic energy in crashes. Higher energy levels lead to more severe health losses,all other things being equal. This increase in speed has two reasons; first road administrations normally set a higher speed limit on roads that are wide and straight because they are said to have a higher safety standard, and drivers tend to drive faster anyway on these roads.This safety philosophy to build wide, straight roads and streets is one of the main contributions to the present global road safety crisis. The result is an increase, by one or two factors of 10, in the risks of severe personal injury or fatality, compared to the Vision Zero design philosophy described later in this paper. No other design parameter has an impact of this magnitude. As an example Swedish 2-lane highways with a speed limit of 110 km/h had one of the most severe injury pattern recorded ever; out of three persons injured on these roads, one was killed. Relatively new Chinese highways produce more than 1 killed/km/year. The main difference between the Swedish rural roads and the Chinese highways is that the latter have a large quantity of vulnerable road users, who are ‘‘separated” from motorised vehicles only by the“wideness” of the roads and traffic regulations . pedestrian crossings. It has been shown on the Swedish roads mentioned in the example that the fatalities can be reduced by 85–90% by applying mid- and side barriers. The Chinese highways mentioned above could, at least in principle, be rebuilt reducing fatalities with up to 99%.A note must be made on motorisation and its effect on overall safety in a country. Sweden has approximately cars/inhabitant whereas China is only in its beginning as a motorised country with cars/inhabitant. The World Bank has noted that the number of persons killed in a country turns from an increasing trend to a decreasing trend when the GNP/capita reaches approximately 8000 US$ (Kopits and Kropper, 2003). A hypothesis based on this data could be that the change in composition of traffic, that is, the mixture of protected/unprotected road users reaches a critical limit at that stage of economic development. That is, the separation between vehicles and unprotected road users reaches a certain level which has an overall good effect on road safety. It should also be noted that this separation in (most) societies is spontaneous and not engineered. It is a function of more and more people becoming motorised (car or bus) and the number of vulnerable road users decreasing, especially on rural roads. The challenge in a developing country is of course to engineer this separation at an early stage of motorisation.4. Design principles in Vision ZeroThe human tolerance for biomechanical forces is in this perspective the starting point for the design of a safe traffic system. This tolerance is a given factor –it cannot be affected to any significant extent. For instance if cars hits pedestrians at 25–30 km/h most of them survive. However, if the cars instead do 50 km/h, most pedestrians will die.The trick from an engineering point of view is to design and construct a traffic system where this human tolerance is not exceeded. Whereas the general strategy for safe road design from the accident perspective was to increase space for drivers and vehicles, the corresponding strategy from a Vision Zero perspective is to manage kinetic energy in crashes and collisions. It is kinetic energy that kills and injures the road user –not the accident. By managing the crash in terms of the energy that is transferred to the human body, an error tolerance can be built into the traffic system. In fact, an error tolerance was also the intention behind the idea to give drivers space in the traditional safety paradigm. Space would give room for evasive manoeuvres thus avoiding the accident; the problem was that it never worked the way it was intended.The management of kinetic energy in crashes and collisions can be broken down to the following principle for road and street design; “Integration and Separation”: kinetic energy is managed by integrating compatible traffic elements and by separating incompatible ones. Here are some boundary values:1. Vulnerable road users should not be exposed to motorised vehicles at speeds exceeding 30 km/h.2. If 1. cannot be satisfied then separate or reduce the vehicle speed to 30 km/h.3. Car occupants should not be exposed to other motorised vehicles at speeds exceeding 50 km/h in 090crossings.4. If 3. cannot be satisfied then separate, or reduce the angle, or reduce the speed to 50 km/h.5. Car occupants should not be exposed to oncoming traffic (other vehicles of approximately same weight) at speeds exceeding 70 km/h or 50 km/h if oncoming vehicles are of considerably different weight.6. If 5. cannot be satisfied then separate, homogenise weights or reduce speeds to 70 (50) km/h.7. Car occupants should not be exposed to the road side at speeds exceeding 70 km/h, or 50 km/h if the road side contains trees or other narrow objects .8. If 7. cannot be satisfied separate or reduce speed to 70 (50) km/h.视觉零——道路交通安全的一项实施政策本文的范畴是一个提纲，一般来说，道路安全理念本来就存在于现在道路和道路设计中。

交通工程专业外文翻译外文文献英文文献

土木工程学院交通工程专业中英文翻译Road Design专业：交通工程英文原文The Basics of a Good RoadWe have known how to build good roads for a long time. Archaeologists have found ancient Egyptian roadsthat carried blocks to the pyramids in 4600 BCE. Later,the Romans built an extensive road system, using the same principles we use today. Some of these roads are still in service.If you follow the basic concepts of road building, you will create a road that will last. The ten commandments of a good road are:（1）Get water away from the road（2）Build on a firm foundation（3）Use the best materials（4）Compact all layers properly（5）Design for traffic loads and volumes（6）Design for maintenance（7）Pave only when ready（8）Build from the bottom up（9）Protect your investment（10）Keep good records1．Get water away from the roadWe can’t overemphasize the importance of good drainage.Engineers estimate that at least 90% of a road’s problems can be related to excess water or to poor waterdrainage. Too much water in any layer of a road’sstructure can weaken that la yer, leading to failure.In the surface layer, water can cause cracks and potholes. In lower layers it undermines support, causing cracks and potholes. A common sign of water in an asphalt road surface is alligator cracking — an interconnected pattern of cracks forming small irregular shaped pieces that look like alligator skin. Edge cracking, frost heaves, and spring breakup of pavements also point to moistureproblems.To prevent these problems remember that water:• flows downhill• needs to flow somepla ce• is a problem if it is not flowingEffective drainage systems divert, drain and dispose of water. To do this they use interceptor ditches and slopes,road crowns, and ditch and culvert systems.Divert —Interceptor ditches, located between the road and higher ground along the road, keep the water from reaching the roadway. These ditches must slope so they carry water away from the road.Drain —Creating a crown in the road so it is higher along the centerline than at the edges encourages water to flow off the road. Typically a paved crown should be 1⁄4" higher than the shoulder for each foot of width from the centerline to the edge. For gravel surfaces the crown should be 1⁄2" higher per foot of width. For this flow path to work, the road surface must be relatively water tight. Road shoulders also must be sloped away from the road to continue carrying the flow away. Superelevations (banking) at the outside of curves will also help drainthe road surface.Dispose —A ditch and culvert system carries water away from the road structure. Ditches should be at least one foot lower than the bottom of the gravel road layer that drains the roadway. They must be kept clean and must be sloped to move water into natural drainage. If water stays in the ditches it can seep back into the road structure and undermine its strength. Ditches should also be protected from erosion by planting grass, or installing rock and other erosion control measures. Erosion can damage shoulders and ditches, clog culverts, undermine roadbeds, and contaminate nearby streams and lakes. Evaluate your ditch and culvert system twice a year to ensure that it works. In the fall, clean out leaves and branches that can block flow. In spring, check for and remove silts from plowing and any dead plant material left from the fall.2．Build on a firm foundationA road is only as good as its foundation. A highway wears out from the top down but falls apart from the bottom. The road base must carry the entire structure and the traffic that uses it.To make a firm foundation you may need to stabilize the roadbed with chemical stabilizers, large stone called breaker run, or geotextile fabric. When you run into conditions where you suspect that the native soil is unstable, work with an engineer to investigate the situation and design an appropriate solution.3．Use the best materialsWith all road materials you “pay now or pay later.” Inferior materials may require extensive maintenance throughout the road’s life. They may also force you to replace the road prematurely.Crushed aggregate is the best material for the base course. The sharp angles of thecrushed material interlock when they are compacted. This supports the pavement and traffic by transmitting the load from particle to particle. By contrast, rounded particles act like ballbearings, moving under loads.Angular particles are more stable than rounded particles.Asphalt and concrete pavement materials must be of the highest quality, designed for the conditions, obtained from established firms, and tested to ensure it meets specifications.4．Compact all layersIn general, the more densely a material is compacted, the stronger it is. Compaction also shrinks or eliminates open spaces (voids) between particles. This means that less water can enter the structure. Water in soil can weaken the structure or lead to frost heaves. This is especially important for unsurfaced (gravel) roads. Use gravel which has a mix of sizes (well-graded aggregate) so smaller particles can fill the voids between larger ones. Goodcompaction of asphalt pavement lengthens its life.5．Design for traffic loads and volumesDesign for the highest anticipated load the road will carry. A road that has been designed only for cars will not stand up to trucks. One truck with 9 tons on a single rear axle does as much damage to a road as nearly 10,000 cars.Rural roads may carry log trucks, milk trucks, fire department pumper trucks, or construction equipment. If you don’t know what specific loads the road will carry, a good rule of thumb is to design for the largest piece of highway maintenance equipment that will be used on the road.A well-constructed and maintained asphalt road should last 20 years without major repairs or reconstruction. In designing a road, use traffic counts that project numbers and sizes of vehicles 20 years into the future. These are only projections, at best, but they will allow you to plan for traffic loadings through a road’s life.6．Design for maintenanceWithout maintenance a road will rapidly deteriorate and fail. Design your roads so they can be easily maintained. This means:• adequate ditches that can be cleaned regularly• culverts that are marked for easy locating in the spring• enough space for snow after it is plowed off the road• proper cross slopes for safet y, maintenance and to avoid snow drifts• roadsides that are planted or treated to prevent erosion• roadsides that can be mowed safelyA rule of thumb for adequate road width is to make it wide enough for a snowplow to pass another vehicle without leaving the travelled way.Mark culverts with a post so they can be located easily.7．Pave only when readyIt is not necessary to pave all your roads immediately. There is nothing wrong with a well-built and wellmaintained gravel road if traffic loads and volume do not require a paved surface. Three hundred vehicles per day is the recommended minimum to justify paving.Don’t assume that laying down asphalt will fix a gravel road that is failing. Before you pave, make sure you have an adequate crushed stone base that drains well and is properly compacted. The recommended minimum depth of crushed stone base is 10" depending on subgrade soils. A road paved only when it is ready will far outperform one that is constructed too quickly.8．Ê Build from the bottom upThis commandment may seem obvious, but it means that you shouldn’t top dress or resurface a road if the problem is in an underlying layer. Before you do any road improvement, locate the cause of any surface problems. Choose an improvement technique that will address the problem. This may mean recycling or removing all road materials down to the native soil and rebuilding everything. Doing any work that doesn’t solve the problem is a waste of money and effort.9．Ê Protect your investmentThe road system can be your municipality’s biggest investment. Just as a home needs painting or a new roof, a road must be maintained. Wisconsin’s severe climate requires more road maintenance than in milder places. Do these important maintenance activities: Surface —grade, shape, patch, seal cracks, control dust, remove snow and iceDrainage —clean and repair ditches and culverts; remove all excess materialRoadside —cut brush, trim trees and roadside plantings, control erosionTraffic service —clean and repair or replace signsDesign roads with adequate ditches so they can be maintained with a motor grader. Clean and grade ditches to maintain proper pitch and peak efficiency. After grading, remove all excess material from the shoulder.10．Keep good recordsYour maintenance will be more efficient with good records. Knowing the road’s construction, life, and repair history makes it much easier to plan and budget its future repairs. Records can also help you evaluate the effectiveness of the repair methods and materials you used.Good record keeping starts with an inventory of the system. It should include the history and surface condition of the roadway, identify and evaluate culverts and bridges, note ditch conditions, shoulders, signs, and such structures as retaining walls and guardrails.Update your inventory each year or when you repair or change a road section. A formal pavement management system can help use these records and plan and budget road improvements.ResourcesThe Basics of a Good Road#17649, UW-Madison, 15 min. videotape. Presents the Ten Commandments of a Good Road. Videotapes are loaned free through County Extension offices.Asphalt PASER Manual(39 pp), Concrete PASER Manual (48 pp), Gravel PASER Manual (32 pp). These booklets contain extensive photos and descriptions of road surfacesto help you understand types of distress conditions and their causes. A simple procedure for rating the condition helps you manage your pavements and plan repairs.Roadware, a computer program which stores and reports pavement condition information. Developed by the Transportation Information Center and enhanced by the Wisconsin Department of Transportation, it uses the PASER rating system to provide five-year cost budgets and roadway repair/reconstruction priority lists.Wisconsin Transportation Bulletin factsheets, available from the Transportation Information Center (T.I.C.).Road Drainage, No. 4. Describes drainage for roadways, shoulders, ditches, and culverts.Gravel Roads, No. 5. Discusses the characteristics of a gravel road and how to maintain one.Using Salt and Sand for Winter Road Maintenance,No. 6. Basic information and practical tips on how to use de-icing chemicals and sand.Culverts—Proper Use and Installation, No. 15. Selecting and sizing culverts, designing, installing and maintaining them.Geotextiles in Road Construction/Maintenance andErosion Control, No. 16. Definitions and common applications of geotextiles on roadways and for erosion control.T.I.C. workshops are offered at locations around the state.Crossroads,an 8-page quarterly newsletter published by the T.I.C. carries helpful articles, workshop information, and resource lists. For more information on any of these materials, contact the T.I.C. at 800/442-4615.中文译文一个良好的公路的基础长久以来我们已经掌握了如何铺设好一条道路的方法，考古学家发现在4600年古埃及使用建造金字塔的石块铺设道路，后来，罗马人使用同样的方法建立了一个庞大的道路系统，这种方法一直沿用到今天。

道路路桥工程中英文对照外文翻译文献

道路路桥工程中英文对照外文翻译文献Asphalt Mixtures: ns。

Theory。

and Principles1.nsXXX industry。

XXX。

The most common n of asphalt is in the n of XXX "flexible" XXX them from those made with Portland cement。

XXX2.XXXXXX the use of aggregates。

XXX。

sand。

or gravel。

and a binder。

XXX for the pavement。

XXX。

The quality of the asphalt XXX to the performance of the pavement。

as it must be able to XXX。

3.PrinciplesXXX。

with each layer XXX layers typically include a subgrade。

a sub-base。

a base course。

and a surface course。

The subgrade is the natural soil or rock upon which the pavement is built。

while the sub-base and base courses provide nal support for the pavement。

The surface course is the layer that comes into direct contact with traffic and is XXX。

In n。

the use of XXX.The n of flexible pavement can be subdivided into high and low types。

交通安全外文翻译文献中英文

外文文献翻译(含：英文原文及中文译文)英文原文POSSIBILITIES AND LIMITA TIONS OF ACCIDENT ANALYSISS.OppeAbstraetAccident statistics, especially collected at a national level are particularly useful for the description, monitoring and prognosis of accident developments, the detection of positive and negative safety developments, the definition of safety targets and the (product) evaluation of long term and large scale safety measures. The application of accident analysis is strongly limited for problem analysis, prospective and retrospective safety analysis on newly developed traffic systems or safety measures, as well as for (process) evaluation of special short term and small scale safety measures. There is an urgent need for the analysis of accidents in real time, in combination with background behavioural research. Automatic incident detection, combined with video recording of accidents may soon result in financially acceptable research. This type of research may eventually lead to a better understanding of the concept of risk in traffic and to well-established theories.Keyword: Consequences; purposes; describe; Limitations; concerned; Accident Analysis; possibilities1. Introduction.This paper is primarily based on personal experience concerning traffic safety, safety research and the role of accidents analysis in this research. These experiences resulted in rather philosophical opinions as well as more practical viewpoints on research methodology and statistical analysis. A number of these findings are published already elsewhere.From this lack of direct observation of accidents, a number of methodological problems arise, leading to continuous discussions about the interpretation of findings that cannot be tested directly. For a fruitful discussion of these methodological problems it is very informative to look at a real accident on video. It then turns out that most of the relevant information used to explain the accident will be missing in the accident record. In-depth studies also cannot recollect all the data that is necessary in order to test hypotheses about the occurrence of the accident. For a particular car-car accident, that was recorded on video at an urban intersection in the Netherlands, between a car coming from a minor road, colliding with a car on the major road, the following questions could be asked: Why did the driver of the car coming from the minor road, suddenly accelerate after coming almost to a stop and hit the side of the car from the left at the main road? Why was the approaching car not noticed? Was it because the driver was preoccupied with the two cars coming from the right and the gap before them that offered him thepossibility to cross? Did he look left before, but was his view possibly blocked by the green van parked at the corner? Certainly the traffic situation was not complicated. At the moment of the accident there were no bicyclists or pedestrians present to distract his attention at the regularly overcrowded intersection. The parked green van disappeared within five minutes, the two other cars that may have been important left without a trace. It is hardly possible to observe traffic behavior under the most relevant condition of an accident occurring, because accidents are very rare events, given the large number of trips. Given the new video equipment and the recent developments in automatic incident and accident detection, it becomes more and more realistic to collect such data at not too high costs. Additional to this type of data that is most essential for a good understanding of the risk increasing factors in traffic, it also important to look at normal traffic behavior as a reference base. The question about the possibilities and limitations of accident analysis is not lightly answered. We cannot speak unambiguously about accident analysis. Accident analysis covers a whole range of activities, each originating from a different background and based on different sources of information: national data banks, additional information from other sources, especially collected accident data, behavioral background data etc. To answer the question about the possibilities and limitations, we first have to look at the cycle of activities in the area of traffic safety. Some ofthese activities are mainly concerned with the safety management of the traffic system; some others are primarily research activities.The following steps should be distinguished:- detection of new or remaining safety problems;- description of the problem and its main characteristics;- the analysis of the problem, its causes and suggestions for improvement;- selection and implementation of safety measures;- evaluation of measures taken.Although this cycle can be carried out by the same person or group of persons, the problem has a different (political/managerial or scientific) background at each stage. We will describe the phases in which accident analysis is used. It is important to make this distinction. Many fruitless discussions about the method of analysis result from ignoring this distinction. Politicians, or road managers are not primarily interested in individual accidents. From their perspective accidents are often treated equally, because the total outcome is much more important than the whole chain of events leading to each individual accident. Therefore, each accident counts as one and they add up all together to a final safety result.Researchers are much more interested in the chain of events leading to an individual accident. They want to get detailed information abouteach accident, to detect its causes and the relevant conditions. The politician wants only those details that direct his actions. At the highest level this is the decrease in the total number of accidents. The main source of information is the national database and its statistical treatment. For him, accident analysis is looking at (subgroups of) accident numbers and their statistical fluctuations. This is the main stream of accident analysis as applied in the area of traffic safety. Therefore, we will first describe these aspects of accidents.2. The nature of accidents and their statistical characteristics.The basic notion is that accidents, whatever there cause, appear according to a chance process. Two simple assumptions are usually made to describe this process for (traffic) accidents:- the probability of an accident to occur is independent from the occurrence of previous accidents;-the occurrence of accidents is homogeneous in time.If these two assumptions hold, then accidents are Poisson distributed. The first assumption does not meet much criticism. Accidents are rare events and therefore not easily influenced by previous accidents. In some cases where there is a direct causal chain (e.g. , when a number of cars run into each other) the series of accidents may be regarded as one complicated accident with many cars involved.The assumption does not apply to casualties. Casualties are often related to the same accident andtherefore the independency assumption does not hold. The second assumption seems less obvious at first sight. The occurrence of accidents through time or on different locations are not equally likely. However, the assumption need not hold over long time periods. It is a rather theoretical assumption in its nature. If it holds for short periods of time, then it also holds for long periods, because the sum of Poisson distributed variables, even if their Poisson rates are different, is also Poisson distributed. The Poisson rate for the sum of these periods is then equal to the sum of the Poisson rates for these parts.The assumption that really counts for a comparison of (composite) situations, is whether two outcomes from an aggregation of situations in time and/or space, have a comparable mix of basic situations. E.g. , the comparison of the number of accidents on one particular day of the year, as compared to another day (the next day, or the same day of the next week etc.). If the conditions are assumed to be the same (same duration, same mix of traffic and situations, same weather conditions etc.) then the resulting numbers of accidents are the outcomes of the same Poisson process. This assumption can be tested by estimating the rate parameter on the basis of the two observed values (the estimate being the average of the two values). Probability theory can be used to compute the likelihood of the equality assumption, given the two observations and their mean.This statistical procedure is rather powerful. The Poisson assumptionis investigated many times and turns out to be supported by a vast body of empirical evidence. It has been applied in numerous situations to find out whether differences in observed numbers of accidents suggest real differences in safety. The main purpose of this procedure is to detect differences in safety. This may be a difference over time, or between different places or between different conditions. Such differences may guide the process of improvement. Because the main concern is to reduce the number of accidents, such an analysis may lead to the most promising areas for treatment. A necessary condition for the application of such a test is, that the numbers of accidents to be compared are large enough to show existing differences. In many local cases an application is not possible. Accident black-spot analysis is often hindered by this limitation, e.g., if such a test is applied to find out whether the number of accidents at a particular location is higher than average. The procedure described can also be used if the accidents are classified according to a number of characteristics to find promising safety targets. Not only with aggregation, but also with disaggregation the Poisson assumption holds, and the accident numbers can be tested against each other on the basis of the Poisson assumptions. Such a test is rather cumbersome, because for each particular case, i.e. for each different Poisson parameter, the probabilities for all possible outcomes must be computed to apply the test. In practice, this is not necessary when the numbers are large. Then the Poissondistribution can be approximated by a Normal distribution, with mean and variance equal to the Poisson parameter. Once the mean value and the variance of a Normal distribution are given, all tests can be rephrased in terms of the standard Normal distribution with zero mean and variance one. No computations are necessary any more, but test statistics can be drawn from tables.3. The use of accident statistics for traffic safety policy.The testing procedure described has its merits for those types of analysis that are based on the assumptions mentioned. The best example of such an application is the monitoring of safety for a country or region over a year, using the total number of accidents (eventually of a particular type, such as fatal accidents), in order to compare this number with the outcome of the year before. If sequences of accidents are given over several years, then trends in the developments can be detected and accident numbers predicted for following years. Once such a trend is established, then the value for the next year or years can be predicted, together with its error bounds. Deviations from a given trend can also be tested afterwards, and new actions planned. The most famous one is carried out by Smeed 1949. We will discuss this type of accident analysis in more detail later.(1). The application of the Chi-square test for interaction is generalised to higher order classifications. Foldvary and Lane (1974), inmeasuring the effect of compulsory wearing of seat belts, were among the first who applied the partitioning of the total Chi-square in values for the higher order interactions of four-way tables.(2). Tests are not restricted to overall effects, but Chi-square values can be decomposed regarding sub-hypotheses within the model. Also in the two-way table, the total Chisquare can be decomposed into interaction effects of part tables. The advantage of 1. and 2. over previous situations is, that large numbers of Chi-square tests on many interrelated (sub)tables and corresponding Chi-squares were replaced by one analysis with an exact portioning of one Chi-square.(3). More attention is put to parameter estimation. E.g., the partitioning of the Chi-square made it possible to test for linear or quadratic restraints on the row-parameters or for discontinuities in trends.(4). The unit of analysis is generalised from counts to weighted counts. This is especially advantageous for road safety analyses, where corrections for period of time, number of road users, number of locations or number of vehicle kilometres is often necessary. The last option is not found in many statistical packages. Andersen 1977 gives an example for road safety analysis in a two-way table. A computer programme WPM, developed for this type of analysis of multi-way tables, is available at SWOV (see: De Leeuw and Oppe 1976). The accident analysis at this level is not explanatory. It tries to detect safety problems that need specialattention. The basic information needed consists of accident numbers, to describe the total amount of unsafety, and exposure data to calculate risks and to find situations or (groups of) road users with a high level of risk. 4. Accident analysis for research purposes.Traffic safety research is concerned with the occurrence of accidents and their consequences. Therefore, one might say that the object of research is the accident. The researcher’s interest however is less focused at this final outcome itself, but much more at the process that results (or does not result) in accidents. Therefore, it is better to regard the critical event in traffic as his object of study. One of the major problems in the study of the traffic process that results in accidents is, that the actual occurrence is hardly ever observed by the researcher.Investigating a traffic accident, he will try to reconstruct the event from indirect sources such as the information given by the road users involved, or by eye-witnesses, about the circumstances, the characteristics of the vehicles, the road and the drivers. As such this is not unique in science, there are more examples of an indirect study of the object of research. However, a second difficulty is, that the object of research cannot be evoked. Systematic research by means of controlled experiments is only possible for aspects of the problem, not for the problem itself. The combination of indirect observation and lack of systematic control make it very difficult for the investigator to detectwhich factors, under what circumstances cause an accident. Although the researcher is primarily interested in the process leading to accidents, he has almost exclusively information about the consequences, the product of it, the accident. Furthermore, the context of accidents is complicated. Generally speaking, the following aspects can be distinguished: - Given the state of the traffic system, traffic volume and composition, the manoeuvres of the road users, their speeds, the weather conditions, the condition of the road, the vehicles, the road users and their interactions, accidents can or cannot be prevented.- Given an accident, also depending on a large number of factors, such as the speed and mass of vehicles, the collision angle, the protection of road users and their vulnerability, the location of impact etc., injuries are more or less severe or the material damage is more or less substantial. Although these aspects cannot be studied independently, from a theoretical point of view it has advantages to distinguish the number of situations in traffic that are potentially dangerous, from the probability of having an accident given such a potentially dangerous situation and also from the resulting outcome, given a particular accident.This conceptual framework is the general basis for the formulation of risk regarding the decisions of individual road users as well as the decisions of controllers at higher levels. In the mathematical formulation of risk we need an explicit description of our probability space, consistingof the elementary events (the situations) that may result in accidents, the probability for each type of event to end up in an accident, and finally the particular outcome, the loss, given that type of accident.A different approach is to look at combinations of accident characteristics, to find critical factors. This type of analysis may be carried out at the total group of accidents or at subgroups. The accident itself may be the unit of research, but also a road, a road location, a road design (e.g. a roundabout) etc.中文译文交通事故分析的可能性和局限性S.Oppe摘要交通事故的统计数字, 尤其国家一级的数据对监控和预测事故的发展, 积极或消极检测事故的发展, 以及对定义安全目标和评估工业安全特别有益。

道路桥梁专业中英文对照---毕业设计论文外文文献翻译

附录一英文翻译原文AUTOMATIC DEFLECTION AND TEMPERATURE MONITORING OFA BALANCED CANTILEVER CONCRETE BRIDGEby Olivier BURDET, Ph.D.Swiss Federal Institute of Technology, Lausanne, SwitzerlandInstitute of Reinforced and Prestressed Concrete SUMMARYThere is a need for reliable monitoring systems to follow the evolution of the behavior of structures over time.Deflections and rotations are values that reflect the overall structure behavior. This paper presents an innovative approach to the measurement of long-term deformations of bridges by use of inclinometers. High precision electronic inclinometers can be used to follow effectively long-term rotations without disruption of the traffic. In addition to their accuracy, these instruments have proven to be sufficiently stable over time and reliable for field conditions. The Mentue bridges are twin 565 m long box-girder post-tensioned concrete highway bridges under construction in Switzerland. The bridges are built by the balanced cantilever method over a deep valley. The piers are 100 m high and the main span is 150 m. A centralized data acquisition system was installed in one bridge during its construction in 1997. Every minute, the system records the rotation and temperature at a number of measuring points. The simultaneous measurement of rotations and concrete temperature at several locations gives a clear idea of the movements induced by thermal conditions. The system will be used in combination with a hydrostatic leveling setup to follow the long-term behavior of the bridge. Preliminary results show that the system performs reliably and that the accuracy of the sensors is excellent.Comparison of the evolution of rotations and temperature indicate that the structure responds to changes in air temperature rather quickly.1.BACKGROUNDAll over the world, the number of structures in service keeps increasing. With the development of traffic and the increased dependence on reliable transportation, it is becoming more and more necessary to foresee and anticipate the deterioration of structures. In particular,for structures that are part of major transportation systems, rehabilitation works need to be carefully planned in order to minimize disruptions of traffic. Automatic monitoring of structures is thus rapidly developing.Long-term monitoring of bridges is an important part of this overall effort to attempt to minimize both the impact and the cost of maintenance and rehabilitation work of major structures. By knowing the rate of deterioration of a given structure, the engineer is able to anticipate and adequately define the timing of required interventions. Conversely, interventions can be delayed until the condition of the structure requires them, without reducing the overall safety of the structure.The paper presents an innovative approach to the measurement of long-term bridge deformations. The use of high precision inclinometers permits an effective, accurate and unobtrusive following of the long-term rotations. The measurements can be performed under traffic conditions. Simultaneous measurement of the temperature at several locations gives a clear idea of the movements induced by thermal conditions and those induced by creep and shrinkage. The system presented is operational since August 1997 in the Mentue bridge, currently under construction in Switzerland. The structure has a main span of 150 m and piers 100 m high.2. LONG-TERM MONITORING OF BRIDGESAs part of its research and service activities within the Swiss Federal Institute of Technology in Lausanne (EPFL), IBAP - Reinforced and Prestressed Concrete has been involved in the monitoring of long-time deformations of bridges and other structures for over twenty-five years [1, 2, 3, 4]. In the past, IBAP has developed a system for the measurement of long-term deformations using hydrostatic leveling [5, 6]. This system has been in successful service in ten bridges in Switzerland for approximately ten years [5,7]. The system is robust, reliable and sufficiently accurate, but it requires human intervention for each measurement, and is not well suited for automatic data acquisition. One additional disadvantage of this system is that it is only easily applicable to box girder bridges with an accessible box.Occasional continuous measurements over periods of 24 hours have shown that the amplitude of daily movements is significant, usually amounting to several millimeters over a couple of hours. This is exemplified in figure 1, where measurements of the twin Lutrive bridges, taken over a period of several years before and after they were strengthened by post-tensioning, areshown along with measurements performed over a period of 24 hours. The scatter observed in the data is primarily caused by thermal effects on the bridges. In the case of these box-girder bridges built by the balanced cantilever method, with a main span of 143.5 m, the amplitude of deformations on a sunny day is of the same order of magnitude than the long term deformation over several years.Instantaneous measurements, as those made by hydrostatic leveling, are not necessarily representative of the mean position of the bridge. This occurs because the position of the bridge at the time of the measurement is influenced by the temperature history over the past several hours and days. Even if every care was taken to perform the measurements early in the morning and at the same period every year, it took a relatively long time before it was realized that the retrofit performed on the Lutrive bridges in 1988 by additional post-tensioning [3, 7,11] had not had the same effect on both of them.Figure 1: Long-term deflections of the Lutrive bridges, compared to deflections measured in a 24-hour period Automatic data acquisition, allowing frequent measurements to be performed at an acceptable cost, is thus highly desirable. A study of possible solutions including laser-based leveling, fiber optics sensors and GPS-positioning was performed, with the conclusion that, provided that their long-term stability can be demonstrated, current types of electronic inclinometers are suitable for automatic measurements of rotations in existing bridges [8].3. MENTUE BRIDGESThe Mentue bridges are twin box-girder bridges that will carry the future A1 motorway from Lausanne to Bern. Each bridge, similar in design, has an overall length of approximately 565 m, and a width of 13.46 m, designed to carry two lanes of traffic and an emergency lane. The bridges cross a deep valley with steep sides (fig. 2). The balanced cantilever design results from a bridge competition. The 100 m high concrete piers were built using climbing formwork, after which the construction of the balanced cantilever started (fig. 3).4. INCLINOMETERSStarting in 1995, IBAP initiated a research project with the goal of investigating the feasibility of a measurement system using inclinometers. Preliminary results indicated that inclinometers offer several advantages for the automatic monitoring of structures. Table 1 summarizes the main properties of the inclinometers selected for this study.One interesting property of measuring a structure’s rotations, is that, for a given ratio of maximum deflection to span length, the maximum rotation is essentially independent from its static system [8]. Since maximal allowable values of about 1/1,000 for long-term deflections under permanent loads are generally accepted values worldwide, developments made for box-girder bridges with long spans, as is the case for this research, are applicable to other bridges, for instance bridges with shorter spans and other types of cross-sections. This is significant because of the need to monitor smaller spans which constitute the majority of all bridges.The selected inclinometers are of type Wyler Zerotronic ±1°[9]. Their accuracy is 1 microradian (μrad), which corresponds to a rotation of one millimeter per kilometer, a very small value. For an intermediate span of a continuous beam with a constant depth, a mid-span deflection of 1/20,000 would induce a maximum rotation of about 150 μrad, or 0.15 milliradians (mrad).One potential problem with electronic instruments is that their measurements may drift overtime. To quantify and control this problem, a mechanical device was designed allowing the inclinometers to be precisely rotated of 180° in an horizontal plane (fig. 4). The drift of each inclinometer can be very simply obtained by comparing the values obtained in the initial and rotated position with previously obtained values. So far, it has been observed that the type of inclinometer used in this project is not very sensitive to drifting.5. INSTRUMENTATION OF THE MENTUE BRIDGESBecause a number of bridges built by the balanced cantilever method have shown an unsatisfactory behavior in service [2, 7,10], it was decided to carefully monitor the evolution of the deformations of the Mentue bridges. These bridges were designed taking into consideration recent recommendations for the choice of the amount of posttensioning [7,10,13]. Monitoring starting during the construction in 1997 and will be pursued after the bridges are opened to traffic in 2001. Deflection monitoring includes topographic leveling by the highway authorities, an hydrostatic leveling system over the entire length of both bridges and a network of inclinometers in the main span of the North bridge. Data collection iscoordinated by the engineer of record, to facilitate comparison of measured values. The information gained from these observations will be used to further enhance the design criteria for that type of bridge, especially with regard to the amount of post-tensioning [7, 10, 11, 12, 13].The automatic monitoring system is driven by a data acquisition program that gathers and stores the data. This system is able to control various types of sensors simultaneously, at the present time inclinometers and thermal sensors. The computer program driving all the instrumentation offers a flexible framework, allowing the later addition of new sensors or data acquisition systems. The use of the development environment LabView [14] allowed to leverage the large user base in the field of laboratory instrumentation and data analysis. The data acquisition system runs on a rather modest computer, with an Intel 486/66 Mhz processor, 16 MB of memory and a 500 MB hard disk, running Windows NT. All sensor data are gathered once per minute and stored in compressed form on the hard disk. The system is located in the box-girder on top of pier 3 (fig. 5). It can withstand severe weather conditions and will restart itself automatically after a power outage, which happened frequently during construction.6. SENSORSFigure 5(a) shows the location of the inclinometers in the main span of the North bridge. The sensors are placed at the axis of the supports (①an d⑤), at 1/4 and 3/4 (③an d④) of the span and at 1/8 of the span for②. In the cross section, the sensors are located on the North web, at a height corresponding to the center of gravity of the section (fig.5a). The sensors are all connected by a single RS-485 cable to the central data acquisition system located in the vicinity of inclinometer ①. Monitoring of the bridge started already during its construction. Inclinometers①,②and③were installed before the span was completed. The resulting measurement were difficult to interpret, however, because of the wide variations of angles induced by the various stages of this particular method of construction.The deflected shape will be determined by integrating the measured rotations along the length of the bridge (fig.5b). Although this integration is in principle straightforward, it has been shown [8, 16] that the type of loading and possible measurement errors need to be carefully taken into account.Thermal sensors were embedded in concrete so that temperature effects could be taken into account for the adjustment of the geometry of the formwork for subsequent casts. Figure 6 shows the layout of thermal sensors in the main span. The measurement sections are located at the same sections than the inclinometers (fig. 5). All sensors were placed in the formwork before concreting and were operational as soon as the formwork was removed, which was required for the needs of the construction. In each section, seven of the nine thermal sensor (indicated in solid black in fig. 6) are now automatically measured by the central data acquisition system.7. RESULTSFigure 7 shows the results of inclinometry measurements performed from the end ofSeptember to the third week of November 1997. All inclinometers performed well during that period. Occasional interruptions of measurement, as observed for example in early October are due to interruption of power to the system during construction operations. The overall symmetry of results from inclinometers seem to indicate that the instruments drift is not significant for that time period. The maximum amplitude of bridge deflection during the observed period, estimated on the basis of the inclinometers results, is around 40 mm. More accurate values will be computed when the method of determination ofdeflections will have been further calibrated with other measurements. Several periods of increase, respectively decrease, of deflections over several days can be observed in the graph. This further illustrates the need for continuous deformation monitoring to account for such effects. The measurement period was .busy. in terms of construction, and included the following operations: the final concrete pours in that span, horizontal jacking of the bridge to compensate some pier eccentricities, as well as the stressing of the continuity post-tensioning, and the de-tensioning of the guy cables (fig. 3). As a consequence, the interpretation of these measurements is quite difficult. It is expected that further measurements, made after the completion of the bridge, will be simpler to interpret.Figure 8 shows a detail of the measurements made in November, while figure.9 shows temperature measurements at the top and bottom of the section at mid-span made during that same period. It is clear that the measured deflections correspond to changes in the temperature. The temperature at the bottom of the section follows closely variations of the air temperature(measured in the shade near the north web of the girder). On the other hand, the temperature at the top of the cross section is less subject to rapid variations. This may be due to the high elevation of the bridge above ground, and also to the fact that, during the measuring period, there was little direct sunshine on the deck. The temperature gradient between top and bottom of the cross section has a direct relationship with short-term variations. It does not, however, appear to be related to the general tendency to decrease in rotations observed in fig. 8.8. FUTURE DEVELOPMENTSFuture developments will include algorithms to reconstruct deflections from measured rotations. To enhance the accuracy of the reconstruction of deflections, a 3D finite element model of the entire structure is in preparation [15]. This model will be used to identify the influence on rotations of various phenomena, such as creep of the piers and girder, differential settlements, horizontal and vertical temperature gradients or traffic loads.Much work will be devoted to the interpretation of the data gathered in the Mentue bridge. The final part of the research project work will focus on two aspects: understanding the very complex behavior of the structure, and determining the most important parameters, to allow a simple and effective monitoring of the bridges deflections.Finally, the research report will propose guidelines for determination of deflections from measured rotations and practical recommendations for the implementation of measurement systems using inclinometers. It is expected that within the coming year new sites will be equipped with inclinometers. Experiences made by using inclinometers to measure deflections during loading tests [16, 17] have shown that the method is very flexible and competitive with other high-tech methods.As an extension to the current research project, an innovative system for the measurement of bridge joint movement is being developed. This system integrates easily with the existing monitoring system, because it also uses inclinometers, although from a slightly different type.9. CONCLUSIONSAn innovative measurement system for deformations of structures using high precision inclinometers has been developed. This system combines a high accuracy with a relatively simple implementation. Preliminary results are very encouraging and indicate that the use of inclinometers to monitor bridge deformations is a feasible and offers advantages. The system is reliable, does not obstruct construction work or traffic and is very easily installed. Simultaneous temperature measurements have confirmed the importance of temperature variations on the behavior of structural concrete bridges.10. REFERENCES[1] ANDREY D., Maintenance des ouvrages d’art: méthodologie de surveillance, PhD Dissertation Nr 679, EPFL, Lausanne, Switzerland, 1987.[2] BURDET O., Load Testing and Monitoring of Swiss Bridges, CEB Information Bulletin Nr 219, Safety and Performance Concepts, Lausanne, Switzerland, 1993.[3] BURDET O., Critères pour le choix de la quantitéde précontrainte découlant de l.observation de ponts existants, CUST-COS 96, Clermont-Ferrand, France, 1996.[4] HASSAN M., BURDET O., FAVRE R., Combination of Ultrasonic Measurements and Load Tests in Bridge Evaluation, 5th International Conference on Structural Faults and Repair, Edinburgh, Scotland, UK, 1993.[5] FAVRE R., CHARIF H., MARKEY I., Observation à long terme de la déformation des ponts, Mandat de Recherche de l’OFR 86/88, Final Report, EPFL, Lausanne, Switzerland, 1990.[6] FAVRE R., MARKEY I., Long-term Monitoring of Bridge Deformation, NATO Research Workshop, Bridge Evaluation, Repair and Rehabilitation, NATO ASI series E: vol. 187, pp. 85-100, Baltimore, USA, 1990.[7] FAVRE R., BURDET O. et al., Enseignements tirés d’essais de charge et d’observations à long terme pour l’évaluation des ponts et le choix de la précontrainte, OFR Report, 83/90, Zürich, Switzerland, 1995.[8] DAVERIO R., Mesures des déformations des ponts par un système d’inclinométrie,Rapport de maîtrise EPFL-IBAP, Lausanne, Switzerland, 1995.[9] WYLER AG., Technical specifications for Zerotronic Inclinometers, Winterthur, Switzerland, 1996.[10] FAVRE R., MARKEY I., Generalization of the Load Balancing Method, 12th FIP Congress, Prestressed Concrete in Switzerland, pp. 32-37, Washington, USA, 1994.[11] FAVRE R., BURDET O., CHARIF H., Critères pour le choix d’une précontrainte: application au cas d’un renforcement, "Colloque International Gestion des Ouvrages d’Art: Quelle Stratégie pour Maintenir et Adapter le Patrimoine, pp. 197-208, Paris, France, 1994. [12] FAVRE R., BURDET O., Wahl einer geeigneten Vorspannung, Beton- und Stahlbetonbau, Beton- und Stahlbetonbau, 92/3, 67, Germany, 1997.[13] FAVRE R., BURDET O., Choix d’une quantité appropriée de précontrain te, SIA D0 129, Zürich, Switzerland, 1996.[14] NATIONAL INSTRUMENTS, LabView User.s Manual, Austin, USA, 1996.[15] BOUBERGUIG A., ROSSIER S., FAVRE R. et al, Calcul non linéaire du béton arméet précontraint, Revue Français du Génie Civil, vol. 1 n° 3, Hermes, Paris, France, 1997. [16] FEST E., Système de mesure par inclinométrie: développement d’un algorithme de calcul des flèches, Mémoire de maîtrise de DEA, Lausanne / Paris, Switzerland / France, 1997.[17] PERREGAUX N. et al., Vertical Displacement of Bridges using the SOFO System: a Fiber Optic Monitoring Method for Structures, 12th ASCE Engineering Mechanics Conference, San Diego, USA, to be published,1998.译文平衡悬臂施工混凝土桥挠度和温度的自动监测作者Olivier BURDET博士瑞士联邦理工学院，洛桑，瑞士钢筋和预应力混凝土研究所概要：我们想要跟踪结构行为随时间的演化，需要一种可靠的监测系统。

道路与桥梁工程中英文对照外文翻译文献

中英文对照外文翻译(文档含英文原文和中文翻译)Bridge research in EuropeA brief outline is given of the development of the European Union, together with the research platform in Europe. The special case of post-tensioned bridges in the UK is discussed. In order to illustrate the type of European research being undertaken, an example is given from the University of Edinburgh portfolio: relating to the identification of voids in post-tensioned concrete bridges using digital impulse radar.IntroductionThe challenge in any research arena is to harness the findings of different research groups to identify a coherent mass of data, which enables research and practice to be better focused. A particular challenge exists with respect to Europe where language barriers are inevitably very significant. The European Community was formed in the 1960s based upon a political will within continental Europe to avoid the European civil wars, which developed into World War 2 from 1939 to 1945. The strong political motivation formed the original community of which Britain was not a member. Many of the continental countries saw Britain’s interest as being purelyeconomic. The 1970s saw Britain joining what was then the European Economic Community (EEC) and the 1990s has seen the widening of the community to a European Union, EU, with certain political goals together with the objective of a common European currency.Notwithstanding these financial and political developments, civil engineering and bridge engineering in particular have found great difficulty in forming any kind of common thread. Indeed the educational systems for University training are quite different between Britain and the European continental countries. The formation of the EU funding schemes —e.g. Socrates, Brite Euram and other programs have helped significantly. The Socrates scheme is based upon the exchange of students between Universities in different member states. The Brite Euram scheme has involved technical research grants given to consortia of academics and industrial partners within a number of the states— a Brite Euram bid would normally be led by an industrialist.In terms of dissemination of knowledge, two quite different strands appear to have emerged. The UK and the USA have concentrated primarily upon disseminating basic research in refereed journal publications: ASCE, ICE and other journals. Whereas the continental Europeans have frequently disseminated basic research at conferences where the circulation of the proceedings is restricted.Additionally, language barriers have proved to be very difficult to break down. In countries where English is a strong second language there has been enthusiastic participation in international conferences based within continental Europe —e.g. Germany, Italy, Belgium, The Netherlands and Switzerland. However, countries where English is not a strong second language have been hesitant participants }—e.g. France.European researchExamples of research relating to bridges in Europe can be divided into three types of structure:Masonry arch bridgesBritain has the largest stock of masonry arch bridges. In certain regions of the UK up to 60% of the road bridges are historic stone masonry arch bridges originally constructed for horse drawn traffic. This is less common in other parts of Europe as many of these bridges were destroyed during World War 2.Concrete bridgesA large stock of concrete bridges was constructed during the 1950s, 1960s and 1970s. At the time, these structures were seen as maintenance free. Europe also has a large number of post-tensioned concrete bridges with steel tendon ducts preventing radar inspection. This is a particular problem in France and the UK.Steel bridgesSteel bridges went out of fashion in the UK due to their need for maintenance as perceived in the 1960s and 1970s. However, they have been used for long span and rail bridges, and they are now returning to fashion for motorway widening schemes in the UK.Research activity in EuropeIt gives an indication certain areas of expertise and work being undertaken in Europe, but is by no means exhaustive.In order to illustrate the type of European research being undertaken, an example is given from the University of Edinburgh portfolio. The example relates to the identification of voids in post-tensioned concrete bridges, using digital impulse radar.Post-tensioned concrete rail bridge analysisOve Arup and Partners carried out an inspection and assessment of the superstructure of a 160 m long post-tensioned, segmental railway bridge in Manchester to determine its load-carrying capacity prior to a transfer of ownership, for use in the Metrolink light rail system..Particular attention was paid to the integrity of its post-tensioned steel elements. Physical inspection, non-destructive radar testing and other exploratory methods were used to investigate for possible weaknesses in the bridge.Since the sudden collapse of Ynys-y-Gwas Bridge in Wales, UK in 1985, there has been concern about the long-term integrity of segmental, post-tensioned concrete bridges which may b e prone to ‘brittle’ failure without warning. The corrosion protection of the post-tensioned steel cables, where they pass through joints between the segments, has been identified as a major factor affecting the long-term durability and consequent strength of this type of bridge. The identification of voids in grouted tendon ducts at vulnerable positions is recognized as an important step in the detection of such corrosion.Description of bridgeGeneral arrangementBesses o’ th’ Barn Bridge is a 160 m long, three span, segmental, post-tensionedconcrete railway bridge built in 1969. The main span of 90 m crosses over both the M62 motorway and A665 Bury to Prestwick Road. Minimum headroom is 5.18 m from the A665 and the M62 is cleared by approx 12.5 m.The superstructure consists of a central hollow trapezoidal concrete box section 6.7 m high and 4 m wide. The majority of the south and central spans are constructed using 1.27 m long pre-cast concrete trapezoidal box units, post-tensioned together. This box section supports the in site concrete transverse cantilever slabs at bottom flange level, which carry the rail tracks and ballast.The center and south span sections are of post-tensioned construction. These post-tensioned sections have five types of pre-stressing:1. Longitudinal tendons in grouted ducts within the top and bottom flanges.2. Longitudinal internal draped tendons located alongside the webs. These are deflected at internal diaphragm positions and are encased in in site concrete.3. Longitudinal macalloy bars in the transverse cantilever slabs in the central span .4. Vertical macalloy bars in the 229 mm wide webs to enhance shear capacity.5. Transverse macalloy bars through the bottom flange to support the transverse cantilever slabs.Segmental constructionThe pre-cast segmental system of construction used for the south and center span sections was an alternative method proposed by the contractor. Current thinking suggests that such a form of construction can lead to ‘brittle’ failure of the ent ire structure without warning due to corrosion of tendons across a construction joint，The original design concept had been for in site concrete construction.Inspection and assessmentInspectionInspection work was undertaken in a number of phases and was linked with the testing required for the structure. The initial inspections recorded a number of visible problems including:Defective waterproofing on the exposed surface of the top flange.Water trapped in the internal space of the hollow box with depths up to 300 mm.Various drainage problems at joints and abutments.Longitudinal cracking of the exposed soffit of the central span.Longitudinal cracking on sides of the top flange of the pre-stressed sections.Widespread sapling on some in site concrete surfaces with exposed rusting reinforcement.AssessmentThe subject of an earlier paper, the objectives of the assessment were:Estimate the present load-carrying capacity.Identify any structural deficiencies in the original design.Determine reasons for existing problems identified by the inspection.Conclusion to the inspection and assessmentFollowing the inspection and the analytical assessment one major element of doubt still existed. This concerned the condition of the embedded pre-stressing wires, strands, cables or bars. For the purpose of structural analysis these elements、had been assumed to be sound. However, due to the very high forces involved,、a risk to the structure, caused by corrosion to these primary elements, was identified.The initial recommendations which completed the first phase of the assessment were:1. Carry out detailed material testing to determine the condition of hidden structural elements, in particularthe grouted post-tensioned steel cables.2. Conduct concrete durability tests.3. Undertake repairs to defective waterproofing and surface defects in concrete.Testing proceduresNon-destructi v e radar testingDuring the first phase investigation at a joint between pre-cast deck segments the observation of a void in a post-tensioned cable duct gave rise to serious concern about corrosion and the integrity of the pre-stress. However, the extent of this problem was extremely difficult to determine. The bridge contains 93 joints with an average of 24 cables passing through each joint, i.e. there were approx. 2200 positions where investigations could be carried out. A typical section through such a joint is that the 24 draped tendons within the spine did not give rise to concern because these were protected by in site concrete poured without joints after the cables had been stressed.As it was clearly impractical to consider physically exposing all tendon/joint intersections, radar was used to investigate a large numbers of tendons and hence locate duct voids within a modest timescale. It was fortunate that the corrugated steel ducts around the tendons were discontinuous through the joints which allowed theradar to detect the tendons and voids. The problem, however, was still highly complex due to the high density of other steel elements which could interfere with the radar signals and the fact that the area of interest was at most 102 mm wide and embedded between 150 mm and 800 mm deep in thick concrete slabs.Trial radar investigations.Three companies were invited to visit the bridge and conduct a trial investigation. One company decided not to proceed. The remaining two were given 2 weeks to mobilize, test and report. Their results were then compared with physical explorations.To make the comparisons, observation holes were drilled vertically downwards into the ducts at a selection of 10 locations which included several where voids were predicted and several where the ducts were predicted to be fully grouted. A 25-mm diameter hole was required in order to facilitate use of the chosen horoscope. The results from the University of Edinburgh yielded an accuracy of around 60%.Main radar sur v ey, horoscope verification of v oids.Having completed a radar survey of the total structure, a baroscopic was then used to investigate all predicted voids and in more than 60% of cases this gave a clear confirmation of the radar findings. In several other cases some evidence of honeycombing in the in site stitch concrete above the duct was found.When viewing voids through the baroscopic, however, it proved impossible to determine their actual size or how far they extended along the tendon ducts although they only appeared to occupy less than the top 25% of the duct diameter. Most of these voids, in fact, were smaller than the diameter of the flexible baroscopic being used (approximately 9 mm) and were seen between the horizontal top surface of the grout and the curved upper limit of the duct. In a very few cases the tops of the pre-stressing strands were visible above the grout but no sign of any trapped water was seen. It was not possible, using the baroscopic, to see whether those cables were corroded.Digital radar testingThe test method involved exciting the joints using radio frequency radar antenna: 1 GHz, 900 MHz and 500 MHz. The highest frequency gives the highest resolution but has shallow depth penetration in the concrete. The lowest frequency gives the greatest depth penetration but yields lower resolution.The data collected on the radar sweeps were recorded on a GSSI SIR System 10.This system involves radar pulsing and recording. The data from the antenna is transformed from an analogue signal to a digital signal using a 16-bit analogue digital converter giving a very high resolution for subsequent data processing. The data is displayed on site on a high-resolution color monitor. Following visual inspection it is then stored digitally on a 2.3-gigabyte tape for subsequent analysis and signal processing. The tape first of all records a ‘header’ noting the digital radar settings together with the trace number prior to recording the actual data. When the data is played back, one is able to clearly identify all the relevant settings —making for accurate and reliable data reproduction.At particular locations along the traces, the trace was marked using a marker switch on the recording unit or the antenna.All the digital records were subsequently downloaded at the University’s NDT laboratory on to a micro-computer.（The raw data prior to processing consumed 35 megabytes of digital data.）Post-processing was undertaken using sophisticated signal processing software. Techniques available for the analysis include changing the color transform and changing the scales from linear to a skewed distribution in order to highlight、突出certain features. Also, the color transforms could be changed to highlight phase changes. In addition to these color transform facilities, sophisticated horizontal and vertical filtering procedures are available. Using a large screen monitor it is possible to display in split screens the raw data and the transformed processed data. Thus one is able to get an accurate indication of the processing which has taken place. The computer screen displays the time domain calibrations of the reflected signals on the vertical axis.A further facility of the software was the ability to display the individual radar pulses as time domain wiggle plots. This was a particularly valuable feature when looking at individual records in the vicinity of the tendons.Interpretation of findingsA full analysis of findings is given elsewhere, Essentially the digitized radar plots were transformed to color line scans and where double phase shifts were identified in the joints, then voiding was diagnosed.Conclusions1. An outline of the bridge research platform in Europe is given.2. The use of impulse radar has contributed considerably to the level of confidence in the assessment of the Besses o’ th’ Barn Rail Bridge.3. The radar investigations revealed extensive voiding within the post-tensioned cable ducts. However, no sign of corrosion on the stressing wires had been found except for the very first investigation.欧洲桥梁研究欧洲联盟共同的研究平台诞生于欧洲联盟。

交通工程专业外文翻译外文文献

Automotive safety systems and technology research and analysis Abstract: auto parts of good and bad will directly affect the safety of the carare directly related to the peoples life safety and security in wealth. This articlemainly from the cars active safety technology and passive safety technology twoaspects elaborated the importance of car parts and how to improve the safety ofthe car. Key words: automobile active safety technology passive safety technology As traffic tools of the modernization and absolute number increase sharplytraffic accidents are also increasing. Car accident has become severe global socialissues. Undoubtedly advanced auto safety facilities are the driving safetyindispensable safeguard. So we should start from technology to research anddevelopment of high performance high s

公路线形设计外文文献翻译英文参考

外文文献翻译(含：英文原文及中文译文)文献出处：Y Hassan. Geometric Design of Highways[J] Advances in Transportation Studies, 2016, 6(1):31-41.英文原文Geometric Design of HighwaysY HassanA. Alignment DesignThe alignment of a road is shown on the plane view and is a series of straight lines called tangents connected by circular curves. In modern practice it is common to interpose transition or spiral curves between tangents and circular curves.The line shape should be continuous, sudden changes from flat line to small radius curve or sudden change of long line end connected to small radius curve should be avoided, otherwise a traffic accident may occur. Similarly, arcs with different radii end-to-end (complex curves) or short straight lines between two arcs with different radii are bad lines unless an easing curve is inserted between arcs. The long, smooth curve is always a good line because it is beautifully lined and will not be abandoned in the future. However, it is not ideal that the two-way road line shape is composed entirely of curves, because some drivers always hesitate to pass through curved road segments. The long and slow curve is used in thesmaller corners. If you use a short curve, you will see "kinks." In addition, the design of the flat and vertical sections of the line should be considered comprehensively and should not be only one. No matter which, for example, when the starting point of the flat curve is near the vertex of the vertical curve, serious traffic accidents will occur.V ehicles driving on curved sections are subjected to centrifugal force, and they need a force of the same magnitude in the opposite direction due to the height and lateral friction to offset it. From the viewpoint of highway design, the high or horizontal friction cannot exceed a certain value. The maximum, these control values for a certain design speed may limit the curvature of the curve. In general, the curvature of a circular curve is represented by its radius. For the linear design, the curvature is often described by the curvature, ie, the central angle corresponding to the 100-foot curve, which is inversely proportional to the radius of the curve.A normal road arch is set in a straight section of the road, and the curve section is set to a super high, and an excessively gradual road section must be set between the normal section and the super high section. The usual practice is to maintain the design elevation of each midline of the road unchanged. By raising the outer edge and lowering the inner edge to form a super high, for the line shape where the straight line is directly connected with the circle curve, the super high should never start on the straight line before reaching the curve. At the other end of the curve at acertain distance to reach all the ultra-high.If the vehicle is driving at a high speed on a restricted section of road, such as a straight line connected with a small radius circle curve, driving will be extremely uncomfortable. When the car enters the curve section, the super high starts and the vehicle tilts inward, but the passenger must maintain the body because it is not subjected to centrifugal force at this time. When the car reaches the curve section, centrifugal force suddenly occurs, forcing passengers to make further posture adjustments. When the car leaves the curve, the above process is just the opposite. After inserting the relaxation curve, the radius gradually transitions from infinity to a certain fixed value on the circle curve, the centrifugal force gradually increases, and ultra-high levels are carefully set along the relaxation curve, and the centrifugal force is gradually increased, thereby avoiding driving bumps.The easement curve has been used on railways for many years, but it has recently been applied on highways. This is understandable. The train must follow a precise orbit, and the uncomfortable feeling mentioned above can only be eliminated after the ease curve is used. However, the driver of a car can change the lateral position on the road at will, and he can provide a relaxation curve for himself by making a roundabout curve. But doing this in one lane (sometimes in other lanes) is very dangerous. A well-designed relaxation curve makes the above roundaboutnessunnecessary. Multi-cluster safety is a measure, and roads are widely used as transition curves.For a circular curve with the same radius, adding an easing curve at the end will change the relative positions of the curve and the straight line. Therefore, whether or not to use an easing curve should be determined before final alignment survey. The starting point of the general curve is labeled PC or BC and the end point is labeled PT or EC. For curves with transition curves, the usual marker configurations are: TC, SC, CS, and ST.For two-way roads, the road width should be increased at sharp bends. This is mainly based on the following factors: 1. The driver is afraid to get out of the edge of the road. 2. Due to the difference in the driving trajectory of the front and rear wheels of the vehicle, the effective lateral width of the vehicle increases; 3. The width of the front of the vehicle that is inclined relative to the centerline of the road. For roads that are 24 feet wide, the added width is negligible. Only if the design speed is 30 mil / h and the curvature is up to 2 ft. However, for narrow roads, widening is very important even on smooth curve sections. The recommended widening values and widened designs are shown in ". Highway linear design."B. Longitudinal slope lineThe vertical alignment of the highway and its impact on the safety andeconomy of vehicle operation constitute one of the most important elements in highway design. V ertical lines consist of straight lines and vertical parabolas or circular lines called vertical slope lines. When a grade line rises gradually from a horizontal line, it is called an uphill, and vice versa, it is called a downhill slope. In the analysis of slope and slope control, designers usually have to study the effect of changes in slope on the midline profile. In determining the slope, the ideal situation is the balance of excavation and filling, and there is no large amount of borrowers and abandoned parties. All the earth moving is carried down as far as possible and the distance is not long. The slope should change with the terrain and be consistent with the direction of ascent and descent of the existing drainage system. In the mountains, the slopes should be balanced to minimize the total cost. In the plain or grassland areas, the slope is approximately parallel to the surface, but higher than the surface at a sufficient height to facilitate drainage of the surface. If necessary, winds can be used to remove surface snow. If the road is approaching or running along a river, the current height of the slope is determined by the expected flood level. In any case, the gentle slope should be set at the excavation section compared to the short vertical section connecting the short vertical curve due to the upslope downslope, and the section from the downslope upslope should be set at the fill. Road section. Such a good linear design can often avoid the formation of a mound or depressionopposite to the current landscape. Other considerations are much more important when determining the vertical slope line than when filling the balance. Study and make more detailed adjustments to advanced issues. In general, the slope of the design that is consistent with the existing conditions is better, which can avoid some unnecessary costs.In slope analysis and control, the impact of slope on motor vehicle operating costs is one of the most important considerations. As the slope increases, the fuel consumption will obviously increase and the speed will slow down. A more economical solution can balance the annual increase in the annual cost of reducing the slope and increasing the annual cost of running the vehicle without increasing the slope. The exact solution to this problem depends on the understanding of traffic flow and traffic type, which can only be known through traffic investigations.In different states, where the maximum longitudinal gradient is also very different, AASHTO recommends that the maximum longitudinal slope be selected based on the time and terrain. The current design has a maximum longitudinal gradient of 5% at a design speed of 70 mil / h. At a design speed of 30 mil / h, the maximum longitudinal slope is generally 7% - 12% depending on the topography.When using longer sustained climbs, the slope length cannot exceed the critical slope length when no slow-moving vehicle is provided. The critical slope length can vary from 1700 ft in 3% grade to 500 ft in 8%grade. The slope of the continuous long slope must be less than the maximum slope of any end surface of the highway. Usually the long continuous single slope is disconnected and the lower part is designed as a steep slope, while approaching the top of the slope allows the slope to decrease. At the same time, it is necessary to avoid obstruction of the view due to the inclination of the longitudinal section.The maximum longitudinal gradient of the highway is 9%. Only when the drainage of the road is a problem, if the water must be drained to the side ditch or the drainage ditch, the minimum gradient criterion is of importance. In this case, AASHTO recommends a minimum gradient of0.35%.C. sight distanceIn order to ensure the safety of driving, the road must be designed to have a sufficient distance in front of the driver's line of sight, so that they can avoid obstacles other than the obstacles, or safely overtake. The line-of-sight is the length of the road visible to the driver of the vehicle. Two meanings: "parking distance" or "non-passing sight distance" or "overtaking sight distance."No matter what happens, reasonable design requires the driver to see this danger outside a certain distance, and brake the car before hitting it. In addition, it is not safe to think that the vehicle can avoid danger by leaving the driving lane. Because this can cause the vehicle to lose controlor to collide with another car.The parking distance is composed of two parts: The first part is the distance that the driver takes before the driver finds an obstacle and brakes. In this detection and reaction phase, the vehicle travels at its initial speed; the second part is the driver’s Part of the pa rking distance depends on the speed of the vehicle and the driver's visual time and braking time. The second part of the parking distance depends on the speed, the brakes, the tires, the conditions of the road surface, and the line shape and slope of the road.Otherwise, the capacity of the highway will be reduced, and the accident will increase, because the irritable driver would risk a collision and overtake the vehicle if he cannot safely overtake the vehicle. The minimum distance in front of which the driver can safely be seen is called the overtaking distance.When making a decision on whether to pass or not, the driver must compare the visibility distance ahead and the distance required to complete the overtaking movement. The factors that influence him to make a decision are the degree of caution in driving and the acceleration performance of the vehicle. Due to the significant differences between humans, the overtaking behavior, which is mainly determined by human judgments and actions rather than the mechanical theorem, varies greatly from driver to driver. In order to establish the line-of-sight value forovertaking, engineers observed many drivers’ overtaking behavior. Between 1938 and 1941, a basic survey was established to establish a standard of over- sight distance. Assume that the operating conditions are as follows:1. It is driven at a uniform speed by the overtaking vehicle.2. Overtaking When entering the overtaking area, decelerate after being overtaken.3. When arriving at the overtaking area, the driver needs to observe the passing area for a short time and start overtaking.4. In the face of the opposite vehicle, the overtaking is completed in a delayed start-up and a hurried turn. In the overtaking process, overtaking accelerates in the overtaking lane and the average speed is 10 mil / h faster than being overtaken.5. When overtaking returns to its original lane, there must be a safe distance between it and the opposite vehicle on the other lane.The sum of the above five items is the over sight distance.中文译文公路线形设计作者：Y HassanA. 平面设计道路的线形反映在平面图上是由一系列的直线和与直线相连的圆曲线构成的。

道路交通安全毕业论文中英文资料外文翻

Vision Zero –Implementing a policy for traffic safetyRoger JohanssonRoad Safety Division Swedish Road Administration Roda Vagen 1 78187 BorlangeSwedenKeywords：Vision Zero Road Safety ImplementationAbstractThe scope of this paper is to outline in a general way the safety philosophy inherentin present road—and street design trace the he present road design philosophy are the main cause of the global road safetycrisis clearly indicating in Vision Zero。

They include a newbasic mechanism for creating error—tolerance in the road system and new designprinciples for road—and street design。

The tradition of “blaming the victim" is hereby questioned and focus is put on theneed for professionals to act based on these new standards。

During the last 10 yearsthe fatalities in Sweden have dropped from approximately 550/year to 450/year。

二级公路毕业设计外文文献

外文资料及翻译Effects of Design Features on Rigid Pavement PerformanceThe performance of rigid pavements is affected by a variety of design features, including slab thickness, base type, joint spacing, reinforcement, joint orientation, load trans fer, dowel bar coatings, longitudinal joint design, joint sealant, tied concrete shoulders ,and subdrainage . A study was made by ERES Consultants, Inc. under FHWA contract on the effects of these features on rigid pavement performance . Ninety-five pavemen tsections located in four major climatic regions were thoroughly evaluated . The following conclusions, which provide some revealing insights into pavement performance, are abstracted from the report (Smith et al., 1990a).Slab Thickness The effect of slab thickness on pavement performance was significant.It was found that increasing slab thickness reduced transverse and longitudinal cracking in all cases. This effect was much more pronounced for thinner slabs than fo rthicker slabs . It was not possible to compare the performance of the thinner slabs and the thicker slabs directly, because the thick slabs were all constructed directly on th esubgrade and the thinner slabs were all constructed on a base course .Increasing the thickness of slab did not appear to reduce joint spalling or join tfaulting . Thick slabs placed directly on the subgrade, especially in wet climates an dexposed to heavy traffic, faulted as much as thin slabs constructed on a base course .Base Type Base types, including base/slab interface friction, base stiffness, base erodibility, and base permeability, seemed to have a great effect on the performance of jointed concrete pavements . The major performance indicators, which were affected by variations in base type, were transverse and longitudinal cracking, joint spalling, and faulting .The worst performing base type, consisted of the cement-treated or soil cement bases, which tended to exhibit excessive pumping, faulting, and cracking. This is most likely due to the impervious nature of the base, which traps moisture and yet can brea- k down and contribute to the movement of fines beneath the slab .The use of lean concrete bases generally produced poor performance . Large curl -ing and warping stresses have been associated with slabs constructed over lean concrete bases. These stresses result in considerable transverse and longitudinal cracking of the slab . The poor performance of these bases can also be attributed to a bathtub design, in which moisture is trapped within the pavement cross section .Dense-graded asphalt-treated base courses ranged in performance from very poor to good. The fact that these types of bases were often constructed as a bathtub design contributed to their poor performance . This improper design often resulted in severe cracking, faulting, and pumping.The construction of thicker slabs directly on the subgrade with no base resulted In a pavement that performed marginally. These pavements were especially susceptible to faulting, even under low traffic levels.Pavements constructed over aggregate bases had varied performance, but were generally in the fair to very good category. In general, the more open-graded the aggregate,the better the performance . An advantage of aggregate bases is that they contribute the least to the high curling and warping stresses in the slab . Even though aggregate bases are not open-graded, they are more permeable and have a lower friction factor than stabilized bases .The best bases in terms of pavement performance were the permeable bases . Typical base courses have permeabilities ranging from 0 to less than 1 ft/day (0 .3 m/day) ; good permeable bases have permeabilities up to 1000 ft/day (305 m/day) . Specific areas of concern were the high corner deflections and the low load transfer exhibited by the permeable bases . These can affect their long-term performance, so the use of dowel bars might be required . An unexpected benefit of using permeable bases was the reduction in "D" cracking on pavements susceptible to this type of distress .Slab Length For JPCP, the length of slabs investigated ranged from 7 .75 to 30 ft(2.4to9.1m). It was found that reducing the slab length decreased both the magnitude of the joint faulting and the amount of transverse cracking. On pavements with random joint spacings, slabs with joint spacings greater than 18 ft (5.5 m) experienced more transverse cracking than did the shorter slabs .For JRCP, the length of slabs investigated ranged from 21 to 78 ft (6 .4 to 23 .9 m) .Generally, shorter joint spacings performed better, as measured by the deteriorated transverse cracks, joint faulting, and joint spalling . However, several JRCP with long joint spacings performed quite well . In particular, the long jointed pavements in New Jersey, which were constructed with expansion joints, displayed excellent performance .An examination of the stiffness of foundation was made through the use of the radius of relative stiffness, f . Generally speaking, when the ratio L/E, where L is the length of slab, was greater than 5, transverse cracking occurred more frequently . Thisfactor was further examined for different base types . It was found that stiffer base courses required shorter joint spacings to reduce or eliminate transverse cracking .Reinforcement The amount of steel reinforcement appeared to have an effect in controlling the amount of deteriorated transverse cracking . Pavement sections with less than 0.1% reinforcing steel often displayed significant deteriorated transverse cracking.A minimum of 0 .1% reinforcing steel is therefore recommended, with larger amounts required for more severe climate and longer slabs.Joint Orientation Conventional wisdom has it that skewed joints prevent the application of two wheel loads to the joint at the same time and thus can reduce load-associated distresses . The results from the limited sample size in this study were ambiguous, but all of the nondoweled sections with skewed joints had a lower PSR than similar designs with perpendicular joints . The available data provide no definite conclusions on the effectiveness of skewing transverse joints for nondoweled slabs . Skewed joints are not believed to provide any benefit to doweled slabs.Load Transfer Dowel bars were found to be effective in reducing the amount of joint faulting when compared with nondoweled sections of comparable designs. The diameter of dowels had an effect on performance, because larger diameter bars provided better load transfer and control of faulting under heavy traffic than did smaller dowels.It appeared that a minimum dowel diameter of 1 .25 in . (32 mm) was necessary to provide good performance .Nondoweled JPCP slabs generally developed significant faulting, regardless of pavement design or climate . This effect was somewhat mitigated by the use of permeable bases. However, the sections in this group had a much lower number of accumulated ESAL, so no definite conclusions can be drawn yet .Dowel Bar Coatings Corrosion-resistant coatings are needed to protect dowels from the adverse effects of moisture and deicing chemicals .While most of the sections in this study did not contain corrosion-resistant dowel bars, those that did generally exhibited enhanced performance. Very little deteriorated transverse cracking was identified on these sections. In fact, one section in New Jersey with stainless steel-clad dowel bars was performing satisfactorily after 36 years of service .Longitudinal Joint Design The longitudinal joint design was found to be a critical design element.Both inadequate forming techniques and insufficient depths of joint can contribute to the development of longitudinal cracking . There was evidence of the ad vantage of sawing the joints over the use of inserts . The depth of longitudinal joints is generally recommended to be one-third of the actual, notdesigned, slab thickness, but might have to be greater when stabilized bases are used .Joint Sealant Joint sealing appeared to have a beneficial effect on performance . This was particularly true in harsh climates with excessive amounts of moisture . Preformed compression sealants were shown to perform well for more than 15 years under heavy traffic.Except where "D" cracking occurred, pavement sections containing preformed sealants generally exhibited little joint spalling and were in good overall conditions.Rubberized asphalt joint sealants showed good performance for 5 to 7 years.Tied Concrete Shoulders It is generally believed that tied concrete shoulders can reduce edge stresses and corner deflections by providing more lateral supports to the mainline pavement, thus improving pavement performance . Surprisingly, this study showed that, although tied concrete shoulders performed better than asphalt shoulders,many of the tied shoulders were not designed properly and actually contributed to poor performance of the mainline pavement . The tiebars were spaced too far apart ,sometimes at a spacing of 40 in.(1016 mm), and were not strategically located near slab corners to provide adequate support . In some cases, tied concrete shoulders were constructed over a stabilized dense-graded base in a bathtub design, resulting in the poor performance of mainline pavement.Subdrainage The provision of positive subdrainage, either in the form of longitudinal edge drains or the combination of a drainage layer and edge drains, generally reduced the amount of faulting and spalling related to "D" cracking . With few exceptions, the load-associated distresses, especially faulting and transverse cracking, decreased as the drainage characteristics improved . The overall pavement performance can be improved by using an open-graded base or restricting the percentage of fines . A filter layer must be placed below the permeable base, and regular maintenance of the outlets must be provided .译文结构特点对刚性路面性能的影响刚性路面的性能受种种结构特点的影响，如板厚、基层类型、接缝间距、钢筋用量、接风方向、荷载传递、传力杆涂层、纵缝设计、接缝填封料、有拉杆混凝土道肩和地下排水等。

道路交通工程专业外文翻译外文文献英文文献

土木工程学院交通工程专业中英文翻译Road Design专业：交通工程英文原文The Basics of a Good RoadWe have known how to build good roads for a long time. Archaeologists have found ancient Egyptian roadsthat carried blocks to the pyramids in 4600 BCE. Later,the Romans built an extensive road system, using the same principles we use today. Some of these roads arestill in service.If you follow the basic concepts of road building, you will create a road that will last. The ten commandments of a good road are:（1）Get water away from the road（2）Build on a firm foundation（3）Use the best materials（4）Compact all layers properly（5）Design for traffic loads and volumes（6）Design for maintenance（7）Pave only when ready（8）Build from the bottom up（9）Protect your investment（10）Keep good records1．Get water away from the roadWe can’t overemphasize the importance of good drainage.Engineers estimate that at least 90% of a road’s problems can be related to excess water or to poor waterdrainage. Too much water in any laye r of a road’sstructure can weaken that layer, leading to failure.In the surface layer, water can cause cracks and potholes. In lower layers it undermines support, causing cracks and potholes. A common sign of water in an asphalt road surface is alligator cracking — an interconnected pattern of cracks forming small irregular shaped pieces that look like alligator skin. Edge cracking, frost heaves, and spring breakup of pavements also point to moisture problems.To prevent these problems remember that water:• flows downhill• needs to flow someplace• is a problem if it is not flowingEffective drainage systems divert, drain and dispose of water. To do this they use interceptor ditches and slopes,road crowns, and ditch and culvert systems.Divert —Interceptor ditches, located between the road and higher ground along the road, keep the water from reaching the roadway. These ditches must slope so they carry water away from the road.Drain —Creating a crown in the road so it is higher along the centerline than at the edges encourages water to flow off the road. Typically a paved crown should be 1⁄4" higher than the shoulder for each foot of width from the centerline to the edge. For gravel surfaces the crownshould be 1⁄2" higher per foot of width. For this flow path to work, the road surface must be relatively water tight. Road shoulders also must be sloped away from the road to continue carrying the flow away. Superelevations (banking) at the outside of curves will also help drainthe road surface.Dispose —A ditch and culvert system carries water away from the road structure. Ditches should be at least one foot lower than the bottom of the gravel road layer that drains the roadway. They must be kept clean and must be sloped to move water into natural drainage. If water stays in the ditches it can seep back into the road structure and undermine its strength. Ditches should also be protected from erosion by planting grass, or installing rock and other erosion control measures. Erosion can damage shoulders and ditches, clog culverts, undermine roadbeds, and contaminate nearby streams and lakes. Evaluate your ditch and culvert system twice a year to ensure that it works. In the fall, clean out leaves and branches that can block flow. In spring, check for and remove silts from plowing and any dead plant material left from the fall.2．Build on a firm foundationA road is only as good as its foundation. A highway wears out from the top down but falls apart from the bottom. The road base must carry the entire structure and the traffic that uses it.To make a firm foundation you may need to stabilize the roadbed with chemical stabilizers, large stone called breaker run, or geotextile fabric. When you run into conditions where you suspect that the native soil is unstable, work with an engineer to investigate the situation and design an appropriate solution.3．Use the best materialsWith all road materials you “pay now or pay later.” Inferior materials may require extensive maintenance throughout the road’s life. They may also force you to replace the road prematurely.Crushed aggregate is the best material for the base course. The sharp angles of thecrushed material interlock when they are compacted. This supports the pavement and traffic by transmitting the load from particle to particle. By contrast, rounded particles act like ballbearings, moving under loads.Angular particles are more stable than rounded particles.Asphalt and concrete pavement materials must be of the highest quality, designed forthe conditions, obtained from established firms, and tested to ensure it meets specifications.4．Compact all layersIn general, the more densely a material is compacted, the stronger it is. Compaction also shrinks or eliminates open spaces (voids) between particles. This means that less water can enter the structure. Water in soil can weaken the structure or lead to frost heaves. This is especially important for unsurfaced (gravel) roads. Use gravel which has a mix of sizes (well-graded aggregate) so smaller particles can fill the voids between larger ones. Goodcompaction of asphalt pavement lengthens its life.5．Design for traffic loads and volumesDesign for the highest anticipated load the road will carry. A road that has been designed only for cars will not stand up to trucks. One truck with 9 tons on a single rear axle does as much damage to a road as nearly 10,000 cars.Rural roads may carry log trucks, milk trucks, fire department pumper trucks, or construction equipment. If you don’t know what specific loads the road w ill carry, a good rule of thumb is to design for the largest piece of highway maintenance equipment that will be used on the road.A well-constructed and maintained asphalt road should last 20 years without major repairs or reconstruction. In designing a road, use traffic counts that project numbers and sizes of vehicles 20 years into the future. These are only projections, at best, but they will allow you to plan for traffic loadings through a road’s life.6．Design for maintenanceWithout maintenance a road will rapidly deteriorate and fail. Design your roads so they can be easily maintained. This means:• adequate ditches that can be cleaned regularly• culverts that are marked for easy locating in the spring• enough space for snow after it is plowed off the road• proper cross slopes for safety, maintenance and to avoid snow drifts• roadsi des that are planted or treated to prevent erosion• roadsides that can be mowed safelyA rule of thumb for adequate road width is to make it wide enough for a snowplow to pass another vehicle without leaving the travelled way.Mark culverts with a post so they can be located easily.7．Pave only when readyIt is not necessary to pave all your roads immediately. There is nothing wrong with a well-built and wellmaintained gravel road if traffic loads and volume do not require a paved surface. Three hundred vehicles per day is the recommended minimum to justify paving.Don’t assume that laying down asphalt will fix a gravel road that is failing. Before youpave, make sure you have an adequate crushed stone base that drains well and is properly compacted. The recommended minimum depth of crushed stone base is 10" depending on subgrade soils. A road paved only when it is ready will far outperform one that is constructed too quickly.8．Ê Build from the bottom upThis commandment may seem obvious, but it means that you shouldn’t top dress or resurface a road if the problem is in an underlying layer. Before you do any road improvement, locate the cause of any surface problems. Choose an improvement technique that will address the problem. This may mean recycling or removing all road materials down to the native soil and rebuilding everything. Doing any work that doesn’t solve the problem is a waste of money and effort.9．Ê Protec t your investmentThe road system can be your municipality’s biggest investment. Just as a home needs painting or a new roof, a road must be maintained. Wisconsin’s severe climate requires more road maintenance than in milder places. Do these important maintenance activities: Surface —grade, shape, patch, seal cracks, control dust, remove snow and iceDrainage —clean and repair ditches and culverts; remove all excess materialRoadside —cut brush, trim trees and roadside plantings, control erosionTraffic service —clean and repair or replace signsDesign roads with adequate ditches so they can be maintained with a motor grader. Clean and grade ditches to maintain proper pitch and peak efficiency. After grading, remove all excess material from the shoulder.10．Keep good recordsYour maintenance will be more efficient with good records. Knowing the road’s construction, life, and repair history makes it much easier to plan and budget its future repairs. Records can also help you evaluate the effectiveness of the repair methods and materials you used.Good record keeping starts with an inventory of the system. It should include the history and surface condition of the roadway, identify and evaluate culverts and bridges, note ditch conditions, shoulders, signs, and such structures as retaining walls and guardrails.Update your inventory each year or when you repair or change a road section. A formal pavement management system can help use these records and plan and budget road improvements.ResourcesThe Basics of a Good Road#17649, UW-Madison, 15 min. videotape. Presentsthe Ten Commandments of a Good Road. Videotapes are loaned free through County Extension offices.Asphalt PASER Manual(39 pp), Concrete PASER Manual (48 pp), Gravel PASERManual (32 pp). These booklets contain extensive photos and descriptions of road surfaces to help you understand types of distress conditions and their causes. A simple procedure for rating the condition helps you manage your pavements and plan repairs.Roadware, a computer program which stores and reports pavement conditioninformation. Developed by the Transportation Information Center and enhanced by the Wisconsin Department of Transportation, it uses the PASER rating system to providefive-year cost budgets and roadway repair/reconstruction priority lists.Wisconsin Transportation Bulletin factsheets, available from the Transportation Information Center (T.I.C.).Road Drainage, No. 4. Describes drainage for roadways, shoulders, ditches, and culverts.Gravel Roads, No. 5. Discusses the characteristics of a gravel road and how to maintain one.Using Salt and Sand for Winter Road Maintenance,No. 6. Basic information and practical tips on how to use de-icing chemicals and sand.Culverts—Proper Use and Installation, No. 15. Selecting and sizing culverts, designing, installing and maintaining them.Geotextiles in Road Construction/Maintenance andErosion Control, No. 16. Definitions and common applications of geotextiles onroadways and for erosion control.T.I.C. workshops are offered at locations around the state.Crossroads,an 8-page quarterly newsletter published by the T.I.C. carries helpfularticles, workshop information, and resource lists. For more information on any of these materials, contact the T.I.C. at 800/442-4615.中文译文一个良好的公路的基础长久以来我们已经掌握了如何铺设好一条道路的方法，考古学家发现在4600年古埃及使用建造金字塔的石块铺设道路，后来，罗马人使用同样的方法建立了一个庞大的道路系统，这种方法一直沿用到今天。

公路路面毕业论文中英文资料外文翻译文献

公路路面中英文资料外文翻译文献PavementHighway pavements are divided into two main categories: rigitand flexible.The wearing surfaceof a rigid pavement is usually constructed of Portland cement concrete such that it acts like a beam over any irregularities in the underlying supporting material.The wearing surface of flexible pavements, on the other hand, is usually constructed of bituminous material such that they remain in contact with the underlying material even when minor irregularities occur.Flexible pavements usually consist of a bituminous surface underlaid with a layer of granular material and a layer of a suitable mixture of coarse and fine materials.Coarse aggregatesFine aggregatesTraffic loads are transferred by the wearing surface to the underlying supporting materials through the interlocking of aggregates, the frictionaleffect of the granular materials, and the cohesion of the fine materials.Flexible pavements are further divided into three subgroups: high type, intermediate type, and low type. High-type pavements have wearing surfaces that adequately support the expected traffic load without visible distress due to fatigue and are not susceptible to weather conditions.Intermediate-type pavements have wearing surfaces that range from surface treated to those with qualities just below that of high-type pavements. Low-type pavements are used mainly for low-cost roads and have wearing surfaces that range from untreated to loose natural materials to surface-treated earth.The components of a flexible pavement include the subgradeor preparedroadbed, the subbase, basecourse, and the surface course (Fig.11.1).✹Upper surface courseMiddle surface courseLower surface courseThe performance of the pavement depends on the satisfactory performance of each component, which requires proper evaluation of the properties of each component separately.✹The subgrade is usually the natural material located along the horizontal alignment of the pavement and serves as the foundation of the pavement structure.✹The subgrademay also consist of a layer of selected borrow materials, well compacted to prescribedspecifications.✹Compacting plantCompaction deviceCompactnessIt may be necessary to treat the subgrade material to achieve certain strength properties required for the type of pavement being constructed.Located immediately above the subgrade, the subbase component consists of a superior quality to that which generally is used for subgrade construction. The requirements for subbase materials are usually given in terms of the gradation, plastic characteristics, and strength. When the quality of the subgrade material meets the requirements of the subbase material, the subbase component may be omitted.In cases where suitable subbase material is not readily available ,the available material can be treated with other materials to achieve the necessary properties. This process of treating soils to improve their engineering properties is know as stabilization.✹The base course lies immediately above the subbase. It is placed immediately above the subgrade if a subbase course is not used.✹This course usually consists of granular materials such as crushed stone, crushed or uncrushed.The specifications for base course materials usually include stricter requirements than those for subbase materials, particularly with respect to their plasticity, gradation, and strength.Materials that do not have the required properties can be used as base materials if they are properly stabilized with Portland cement, asphalt, or lime .In some cases, high-quality base course materials may also be treated with asphalt or Portland cement to improve the stiffness characteristics of heavy-duty pavementsThe surface course is the upper course of the road pavement and is constructed immediately above the base course. The surface course in flexible pavement usually consists of a mixture of mineral aggregates and asphaltic materials.It should be capable of withstanding high tire pressures, resisting the abrasive forces due to traffic, providing a skid-resistant driving surface, and preventing thepenetration of surface water into the underlying layers.✹The thickness of the wearing surface can vary from 3 in. to more than 6 in.（inch，英寸，2.54cm）, depending on the expected traffic on the pavement.It was shown that the quality of the surface course of a flexible pavement depends on the mix design of the asphalt concrete used.✹Rigid highway pavements usually are constructed to carry heavy traffic loads, although they have been used for residential and local roads. Properly designed and constructed rigid pavements have long service lives and usually are less expensive to maintain than the flexible pavements.✹The Portland cement concrete commonly used for rigid pavements consists of Portland cement, coarse aggregate, fine aggregate, and water. Steel reinforcing rods may or may not be used, depending on the type of pavement being constructed.Rigid highway pavements be divided into three general type: plain concrete pavements, simply reinforced concrete pavements, and continuously reinforced concrete pavement. The definition of each pavement type is related to the amount of reinforcement used.Plain concrete pavement has no temperature steel or dowels for load transfer. However, steel tie bars are often used to provide a hingeeffect at longitudinal joints and to prevent the opening of these joints. Plain concrete pavements are used mainly on low-volume highways or when cement-stabilized soils are used as subbase.✹Joints are placed at relatively shorter distances (10 to 20 ft) than with the other types of concrete pavements to reduce the amount of cracking.In some case, the transverse joints of plain concrete pavements are skewed about 4 to 5 ft in plan, such that only one wheel of a vehicle passes through the joint at a time. This helps to provide a smoother ride.Simply reinforced concrete pavements have dowels for the transfer of traffic loads across joints, with these joints spaced at larger distances, ranging from 30 to 100 ft. Temperature steel is used throughout the slab, with the amount dependent on the length of the slab. Tie bars are also commonly used in longitudinal joints.h/2 h/25~10cm 填缝料横向施工缝构造Continuously reinforced concrete pavements have no transverse joints, except construction joints or expansion joints when they are necessary at specific positions, such as at bridges.These pavements have a relatively high percentage of steel, with the minimum usually at 0.6 percent of the cross section of the slab. They also contain tie bars across the longitudinal joints.Bituminous Surface CoursesThe bituminous surface course has to provide resistance to the effects of repeated loading by tyres and to the effects of the environment.✹ In addition, it must offer adequate skid resistance in wet weather as well ascomfortable vehicle ride. It must also be resistant to rutting and to cracking.✹ It is also desirable that surface course is impermeable, except in the case ofporous asphalt.Hot rolled asphalt (HRA) is a gapgraded material with less coarse aggregate. In fact it is essentially a bitumen/fine aggregate/filler mortar into which some coarse aggregate is placed.The mechanical propertiesare dominated by those of the mortar. This material has been extensively used as the wearing course on major road in the UK, though its use has recently declined as new materials have been introduced.✹ It provides a durablelayer with good resistance to cracking and one which isrelatively easy to compact. The coarse aggregate content is low (typically 30%) which results in the compacted mixture having a smooth surface. Accordingly, the skid resistance is inadequate and precoated chippings are rolled into the surface at the time of laying to correct this deficiency.In Scotland, HRA wearing course remains the preferred wearing course on trunk roads including motorway but ， since 1999 thin surfacings have been the preferred option in England and Wales. Since 1999 in Northern Ireland, HRA wearing course and thin surfacings are the preferred permitted options.Porous asphalt (PA) is a uniformly graded material which is designed to provide平缝加拉杆型large air voids so that water can drain to the verges within the layer thickness. If the wearing course is to be effective, the basecourse below must be waterproof and the PA must have the ability to retain its open textured properties with time.Thick binder films are required to resist water damage and ageing of the binder. In use, this material minimizes vehicle spray, provides a quiet ride and lower rolling resistance to traffic than dense mixtures.✹It is often specified for environmental reasons but stone mastic asphalt (SMA) and special thin surfacings are generally favoured in current UK practice.There have been high profile instances where a PA wearing course has failed early in its life. The Highways Agency does not recommend the use of a PA at traffic levels above 6000 commercial vehicles per day.✹Asphaltic concrete and dense bitumen macadam (DBM) are continuously graded mixtures similar in principle to the DBMs used in roadbases and basecourses but with smaller maximum particle sizes. Asphaltic concrete tends to have a slightlydenser grading and is used for road surfaces throughout the world with the excepting of the UK.✹It is more difficult to meet UK skid resistance Standards with DBMs than HRA, SMA or PA. This problem can be resolves by providing a separate surface treatment but doing so generally makes DBM economically unattractive.✹Stone mastic asphalt (SMA) material was pioneeredin Germany and Scandinavia and is now widely used in the UK. SMA has a coarse, aggregrate skeleton, like PA, but the voids are filled with a fine aggregate/filler /bitumen mortar.✹In mixtures using penetration grade bitumen , fibres are added to hold the bitumen within the mixture (to prevent “binder drainage”).Bitumen✹oil bitumen( earth oil)✹natural bitumen✹TarWhere a polymer modified bitumen is used, there is generally no need for fibres. SMA is a gap-graded material with good resistance to rutting and high durability. modified bitumen✹SBS✹SBR✹PE\EV A✹It differs from HRA in that the mortar is designed to just fill the voids in the coarse aggregate whereas, in HRA, coarse aggregate is introduced into the mortar and does not provide a continous stone matrix. The higher stone content HRAs ,however, are rather similar to SMA but are not wide used as wearing courses in the UK, being preferred for roadbase and basecourse construction.A variety of thin and what were called ultra thin surfacings (nowadays, the tendency is to use the term ‘thin surfacings’ for both thin and ultra thin surfacings )have been introduced in recent years, principally as a result of development work concentrated in France.These materials vary in their detailed constituents but usually have an aggregate grading similar to SMA and often incorporate a polymer modified bitumen.They may be used over a high stiffness roadbase and basecourse or used for resurfacing of existing pavements. For heavy duty pavements (i .e those designed to have a useful life of forty years), the maintenance philosophy is one of minimum lane occupancy, which only allows time for replacement of the wearing course to these ‘long life’ pavement structures. The new generation of thin s urfacings allows this to be conveniently achieved.The various generic mixture types described above can be compared with respect to their mechanical properties and durability characteristics by reference to Fig.12.1. This shows, in principle, how low stone content HRA, asphaltic concrete, SMA and PA mixtures mobilize resistance to loading by traffic.Asphaltic concrete (Fig.12.1a)) presents something of a compromise when well designed, since the dense aggregate grading can offer good resistance to the shear stresses which cause rutting, while an adequate binder content will provide reasonable resistance to the tensile stresses which cause cracking.In general, the role of the aggregate dominates. DBMs tend to have less dense gradings and properties which, therefore, tend towards good rutting resistance and away from good crack resistance.HRA (Fig.12.1b)) offers particularly good resistance to cracking through the binder rich mortar between the coarse aggregate particles. This also provides good durability but the lack of coarse aggregate content inhibits resistance to rutting.SMA and PA are shown in the same diagram ( Fig.c)) to emphasis the dominant role the coarse aggregate. In both case, well coated stone is used. In PA, the void space remains available for drainage of water, whilst in SMA, the space is occupied by a fine aggregate/ filler/ bitumen/ fibre mortar.Both materials offer good rutting resistance through the coarse aggregate content. The tensile strength of PA is low whilst that of SMA is probably adequate but little mechanical testing data have been reported to date.Drainage for Road and Airports✹Provision of adequate drainage is important factor in the location and geometric design of road and airports. Drainage facilities on any highway, street and airport should adequately provide for the flow of water away from the surface of the pavement to properly designed channels.Inadequate drainage will eventually result in serious damage to the structure.✹In addition, traffic may be slowed by accumulated water on the pavement, and accidents may occur as a result of hydroplaning and loss of visibility from splash and spray. The importance of adequate drainage is recognized in the amount of highway construction dollars allocated to drainage facilities. About25 percent of highway construction dollars are spent for erosion control anddrainage structures, such as culverts, bridges, channels, and ditches.✹Highway Drainage Structures✹One of the main concerns of the highway engineer is to provide an adequate size structure, such that the waterway opening is sufficiently large to discharge the expected flow of water.Inadequately sized structures can result in water impounding, which may lead to failure of the adjacent sections of the highway due to embankments being submerged in water for long periods.✹The two general categories of drainage structures are major and minor. Major structures are those with clear spans greater than 20 feet, whereas minor structures are those with clear spans of 20 feet or less .✹Major structures are usually large bridges, although multiple-span culverts may also be included in this class. Minor structures include small bridges and culverts.Emphasis is placed on selecting the span and vertical clearancerequirements for major structures. The bridge deck should be located above the high water mark .The clearance above the high water mark depends on whether the waterway is navigable ✹If the waterway is navigable, the clearance above the high water mark should allow the largest ship using the channel to pass underneath the bridge without colliding with the bridge deck. The clearance height, type, and spacing of piers also depend on the probability of ice jams and the extentto which floating logs and debris appear on the waterway during high water.✹An examination of the banks on either side of the waterway will indicate the location of the high water mark, since this is usually associated with signs of erosion and debris deposits. Local residents, who have lived near and observed the waterway during flood stages over a number of years, can also give reliable information on the location of the high water mark. Stream gauges that have been installed in the waterway for many years can also provide data that can be used to locate the high water mark.Minor structures, consisting of short-span bridges and culverts, are the predominant type of drainage structures on highways. Although openings for these structures are not designed to be adequate for the worst flood conditions, they should be large enough to accommodate the flow conditions that might occur during the normal life expectancy of the structure.✹Provision should also be made for preventing clogging of the structure due to floating debris and large boulders rolling from the banks of steep channels.✹Culverts are made of different materials and in different shapes. Materials used to construct culverts include concrete（reinforced and unreinforced）, corrugated steel, and corrugatedaluminum. Other materials may also be used to line the interiorof the culvert to prevent corrosion and abrasionor to reduce hydraulic resistance. For example, asphaltic concrete may be used to line corrugated metal culverts. The different shapes normally used in culvert construction include circular, rectangular (box), elliptical, pipe arch, metal box, and arch.✹The drainage problem is increased in these areas primarily for two reasons: the impervious nature of the area creates a very high runoff; and there is little room for natural water courses. It is often necessary to collect the entire storm water into a system of pipes and transmit it over considerable distances before it can be loosed again as surface runoff. This collection and transmission further increase the problem, since all of the water must be collected with virtually no pending, thus eliminating any natural storage; and through increased velocity the peak runoffs are reached more quickly.Also, the shorter times of peaks cause the system to be more sensitive to short-duration,high intensive rainfall.Storm sewers,like culverts and bridges,are designed for storms of various intensity-return-period relationships, depending uponthe economy and amount of ponding that can be tolerated.✹Airport Drainage✹The problem of providing proper drainage facilities for airports is similar in many ways to that of highways and streets. However, because of the large and relatively flat surface involved, the varying soil conditions, the absence of natural water courses and possible side ditches, and the greater concentration of discharge at the terminus of the construction area, some phases of the problem are more complex. For the average airport the over-all area to be drained is relatively large and an extensive drainage system is required. The magnitude of such a system makes it even more imperative that sound engineering principles based on all of the best available data be used to ensure the most economical design.Overdesigning of facilities results in excessive money investment with no return, and underdesigning can result in conditions hazardous to the air traffic using the airport. In order to ensure surfaces that are smooth, firm, stable, and reasonably free from flooding, it is necessary to provide a system which will do several things.It must collect and remove the surface water from the airport surfaces; intercept and remove surface water flowing toward the airport from adjacent areas; collect and remove any excessive subsurface water beneath the surface of the airport facilities and in many cases lower the ground-water table; and provide protection against erosion of the sloping areas.路面公路的路面被分为两类：刚性的和柔性的。

交通工程外文文献

INLAND SHIPPING TRAFFIC PLANNINGBASED ON REAL TIME MODELLING.1Luk Knapen∗Bart De Munck∗Frank Gevaerts∗∗fks BVBA Stationstraat108,3570ALKEN(Belgium)Abstract:Inland shipping traﬃc on a canal segmented by locks and crossed bydrawbridges is controlled using real time traﬃc modelling.Ship position calculationis based on passage point notiﬁcation.Operated locks and bridges have beenmodelled by using hierarchical parallelﬁnite state machines.Actual traﬃc stateis continuously monitored as a basis for traﬃc state forecast which is calculatedas a resource allocation problem.Keywords:Traﬃc Control,Traﬃc Modelling,Discrete Event Systems,Estimation1.INTRODUCTIONTraﬃc on the Brussels-Scheldt canal consists ofseagoing and inland vessels.The canal has twolocks and is crossed by eight drawbridges/liftbridges.Most of the bridges serve regular road transportand can be opened on demand by the ships traﬃc;two of them are operated by the NMBS(belgianrailway company)based on time tables.The downstream end of the canal consists of theWintam lock and gives access to the tidal riverScheldt.Therefor,seagoing ships can leave thecanal only within speciﬁc timeslots.The respon-sible authority W&Z(Waterwegen en Zeekanaal)operates the VSZ software to manage traﬃc ontheir network(including the BS-canal).The VSZtraﬃc(forecast)model is presented in this article.2.GOALS AND CONSTRAINTSShort term forecast main goals are:(1)to minimize traﬃc jam,to minimize thetravel time and to optimize energy consump-tion by guiding the traﬃc•As soon as a skipper requests access to the fairway,a traﬃc schedule(VaarSchema)is deﬁned using the speciﬁc ship or convoy char-acteristics,the speciﬁed route,the ETD and traﬃc model.The traﬃc schedule mentions travel distances,times and ETA values for passage points(mainly located near bridges and locks).•The monitored area(network of canals)is subdivided in a set of zones corresponding to mariphone coverage areas.Each of the zones is managed by a single operator in the control room.An operator keeps in touch with the skippers in her/his allocated zone and is responsible for conveying information about travel schedule changes to the ship.•Operators register alerts with speciﬁc mo-ments in time relative to the ETA for speciﬁc locations in a travel schedule.VSZ issues notiﬁcation messages to the appropriate op-erator when the relevant event occurs.•Whenever a new travel schedule is entered in the system,the entire model gets recal-culated to produce a new forecast.This can induce changes in forecasts for previously calculated travel schedules due to bottle neck situations at locks,bridges and fairway segments where ships cannot overtake each other nor pass traﬃc from the opposite di-rection.If the diﬀerence between the current and previously communicated travel schedule exceeds a predeﬁned limit,the operator is asked to communicate the new situation to the monitored ships.Statistics based forecast•Long term forecasts are based on statistics because insuﬃcient data about the actual traﬃc are available which makes forecast results unrealistic.•The user selects the route and speciﬁes values for some statistical dimensions(parameters for stochastics):ship category/class,type of day time of day(ETD),load,...•ETA for relevant locations on the route are calculated using stochastics based on statisti-cal data gathered while monitoring the actual traﬃc state.4.MODELS4.1Fairway Network ModelThe fairway is modelled as a general graph.•Every edge in the graph has constant nautical characteristics(cross section):edge lengths rougly are in the range50...1000[m].•The possibility for ships to fare and to pass and overtake each other,is calculated us-ing the CEMT Ship Size classiﬁcation based rules taking into account the vessel’s draught. Locks and drawbridges(liftbridges)have been modelled as Hierarchical Parallel Finite State Ma-chines(HP-Fsm).•Each one of the HP-Fsm has an associated object describing speciﬁc physical parameters (height,width,transition cost,...).•Each associated object has a speciﬁc set of (boolean)availability indicators that directly map to the user’s application domain(ex.Lock door unavailable due to service).The set of availability indicators deﬁnes a set of operating modes.Operating modes determine the actual HP-Fsm behaviour by making some states or transitions infeasible.•Deﬁnitions for HP-Fsm,associated object parameters and operating modes have been speciﬁed in XML documents which makes VSZ highly conﬁgurable.Resources have been subdivided in S-Resources and T-Resources:•S-Resources or State Resources:in order for ships to pass,the resource needs to be in a speciﬁc state during the entire passage period.Vessels are not allowed to pass under moving constructions.•T-Resources or Transition Resources:in or-der for ships to pass,they need to participate in a sequence of state transitions(i.e.a lock is transiting from the lower to the upper state).4.2Traﬃc Models and Travel SchedulesVSZ keeps track of several versions of the traﬃc model:•Actual Traﬃc Model:contains a travel sched-ule for each vessel/convoy in the system.This schedule is updated for each passage notiﬁcation and thus holds the most recent information about the travel schedules.•Planned Traﬃc Model:whenever a RIS-operator starts a planning session,the Actual Traﬃc Model is cloned.The RIS operator can force vessels to move in groups,allocate vessels to lock and bridge operations andﬁx operations to a speciﬁc moment in time.The RIS-operator thus has her/his private model to inﬂuence and simulate the traﬃc for the near future(typically4...8hours).During the interactive planning operations, this model is not updated by external event notiﬁcations(because that would interfere with the planner’s work).The RIS-operator however can,at any moment in time,expose the model to the queued external events soFig.1.Hierarchical Parallel FSM for the Zemst3-doorset lockthat the Planned Traﬃc Model gets compat-ible with the real world.The RIS-operator then can push the updated planning to the Actual State Model in order to make it available to the traﬃc coordina-tors who are monitoring the vessels in their zones.The most important tool for the RIS-operator is the Traﬃc Diagram showing the vessels dis-placement against time in the upper part and the bridge/lock operations schedule in the lower part. Each vessel or convoy has following associated travel schedules(1)Actual:the schedule that is part of theActual Traﬃc Model;this one is kept up to date by adding new schedules and by accepting passage notiﬁcations(2)Planned:the schedule that is part of thePlanned Traﬃc Model;this one is manipu-lated by the RIS-operator and updated by passage notiﬁcations(only on explicit opera-tor demand)(3)Communicated:the schedule that has beenfrozen by a traﬃc coordinator when the in-formation has been conveyed to the skipper.This one is used as a reference to decide whether or not the diﬀerence with the Actual schedule is worth to be communicated to the monitored vessel.5.MODEL CALCULATIONThe models are evaluated as resource allocation problems:bridges,locks and fairway network components are considered to be scarce resources and need to be allocated to vessels/convoys in order to allow them to perform their schedule.The model is subject to a set of constraints:(1)Vessel priority:according to the Scheep-vaartReglement(rules governing the traﬃc on the canal)vessels get assigned a pri-ority that depends on the vessel type and the travel direction(upstream,downstream).Fig.3.System Structure Overview showing diﬀer-entiators causing operator alarm notiﬁcations The VSZ algorithms extend the oﬃcial pri-ority to construct a total order over the set of traﬃc schedules.Traﬃc schedules are added to the model being calculated in priority order and a lower priority schedule cannot inﬂuence a higher one(this is a basic algo-rithmic requirement to guaranteeﬁnite cal-culation times).(2)Speed and acceleration limits:each ves-sel/convoy has its minimum and maximum speed and acceleration speciﬁed(3)Railway bridges:the schedules for thosebridges are externally speciﬁed constraints (4)Tidal wave:the tidal wave on the riverScheldt allows seagoing vessels to leave the Wintam lock only within speciﬁc time slots relative to the tidal wave top(5)Maximal bridge open time:bridges servingcar transport crossing the canal can remain open(unavailable for the crossing transport)Fig.2.Traﬃc diagram showing distance against time(upper part)and operations schedule(lower part)only during a speciﬁed maximum period of time(6)Delay required for bridge and lock operations(7)Lock capacity:Locks have a maximal capac-ity determined by their dimensions.A lock ﬁlling optimizer is used to get as much ves-sels as possible participating in any speciﬁc operation(8)Network Components(NWC)have aﬁnitecapacity determined by their cross section characteristics(determining the ability to overtake and to cross traﬃc in the opposite direction)Each traﬃc schedule is calculated as follows: (1)the sequence of required NWC is determined(from the planned route)(2)the entry time at theﬁrst NWC is the userspeciﬁed ETD(3)the earliest exit time for a ship on an NWC iscalculated taking into account all constraints mentioned above(4)when the exit time for an NWC N0is nota suitable entry time for N0’s successor andN0is a regular fairway NWC,a new attempt is made at a lower speed(within the speciﬁed constraints)(5)the algorithm is a recursive one;eventually,the ETD may need to be modiﬁed toﬁnd asolution(in traﬃc saturation conditions) Crossing a fairway NWC is computed as follows: (1)Ship speed is piecewise linear over everyspeciﬁc NWC,thus distance is piecewisequadratic.This characteristic is not limit-ing for the applicability of the model sincethe essential characteristics are the average,entry and exit speed not the actual speeddistribution.(2)The original NWC are subdivided in40[m]long parts in order to simplify the model.This way,the algorithm can assume that aship either occupies the entire NWC or doesnot occupy it at all.This has a signiﬁcant ef-fect on the complexity of crossing/overtakingcalculations.Non-fairway SResources operated on demand(bridges), the cheapest state that fulﬁls all conditionsfor the vessels/convoys to pass is selected. (2)The optimal path in the state transitiondiagram for the corresponding FSM,start-ing in the state that holds before the ves-sels/convoys arrive to the selected state,isFig.4.Result of a simulation run with 50ships/convoys.determined.The state transition is scheduled at the latest moment that allows the transi-tion to complete on time.(3)The selected state is kept only for the timerequired;ﬁnally the SResource NWC handling :(1)Tstate where it is ableto accept the selected set of vessels/convoys.Then a suitable ﬁnal state is determined.(4)The optimal path through the state tran-sition network needs to contain the initial ,via and ﬁnal states.Finding the optimal path in a parallel state machine involves ex-tremely large search spaces.Since the con-stituting HP-FSM’s inﬂuence each other,no wave front algorithm was found to solve the problem.It is possible to write down the state transition matrix but that is very large (but sparse)too.The problem was solved by determining the conditional sensitivity for the HP-Fsm :that is the set of triggers that have any eﬀect in a particular state.The search space then is traversed by con-secutively applying each trigger in the con-ditional sensitivity set for each state.This is done in a recursive process so that eventually each feasible sequence of triggers is applied.As soon as a feasible path is found,an upper limit for the cost is known and the search space can be cut (to limit its size).Although several similar techniques have been applied to speed up calculations,this algorithm takes tens of seconds to complete,which is too much in practical situations.A (persistent)solution caching facility has been introduced to solve this problem.(5)The required state transition sequence isscheduled at the latest moment that allows the initial-via subsequence to complete on time so that the lock is in a suitable state when the vessels/convoys arrive.6.DATA USEDThe project reuses existing data as far as possible in order to integrate it eﬃciently in the NVZ business operations.(1)Network topology,geometry and nautical char-acteristics are taken from the GIS database deployed at NVZ.(2)Train schedules are acquired from NMBS (ina ﬁrst phase,printed on paper).(3)Tidal tables are acquired from the DienstMaritieme Toegang as MsExcel sheets.(4)The REMARCC hull database is used as themaster source of information but data are cached in local databases in order to survive network breakdowns.7.RESEARCH PERFORMEDThe VSZ model calculates the estimated position for each vessel for the set of passage points on the route.Physical and legal upper and lower bound speed limits and acceleration/decelerations limits are taken into account.The problem solution on a single fairway segment without any boundary conditions is a trivial one.Research in the VSZ concentrated on issues ofﬁnding solutions fullﬁll-ing all nautical boundary conditions induced by drawbridges and lock schedules and actual traﬃc. The problem solution starts as an initial condition problem where vessel position and velocity at future times have to be determined(in order to approximate the skipper’s actual behaviour).The route is subdivided in segments having constant nautical characteristics:this subdivision changes with time due to drawbridge and lock schedules and since the mere vessel presence changes the nautical characteristics of fairway segments.The algorithm toﬁnd the speed distribution along the route is a recursive one that considers each subproblem to be solved as an initial boundary condition problem.In order to guarantee conver-gence,the algorithm is organised to deliver partial solution trials thatﬁnish after any previously tried solution(total ordering in time domain).The convergence of the speed distribution algo-rithm and the performance of the HP-FSM opti-mal pathﬁnder have been major components of research.8.RELATED WORK8.1WABISThe VSZ project tries to realize objectives sim-ilar to those addressed by the WABIS system (Matheja et al.,2001).Main diﬀerences areVSZ has to operate without a real time ship position notiﬁcation system like the GPS/GPRS based system in WABIS but is required to rely on passage notiﬁcations only to keep track of actual ship positions.VSZ does not provide a ship based workstation for ECDIS based visualisationVSZ uses a fairway model that is similar to the WABIS one but models locks and drawbridges by means of Hierarchical Parallel FSM.An optimal path from source to target state is searched for. Estimated operation times are deduced from de-lays associated with state transitions.Each passage notiﬁcation causes recalculation of the entire model.Each calculation involvesﬁnding state transition sequences(paths)in the HP-FSM either opti-mised for minimal duration or for minimal water consumption.In contrast to WABIS,VSZ uses a single model instead of separate models for macro (ETA predictions)and micro scales(advise con-cerning passing,navigation in narrow and one-way sections,lock optimisation).8.2Train Traﬃc Control ResearchBengt Sandblad et al.studied the user inter-face problem from a cognitive point of view. (Andersson et al.,1997)lists the problem condi-tions(goal,model,observability,controllability) but does not provide or suggest any solution. (Sandblad et al.,2002)shows that the problems faced in railway control are similar to the one addressed by VSZ.The authors propose a con-tinuous re-planning system based on information exchanded over telephone and radio communica-tion.The proposed GUI is equivalent to the traﬃc diagram used in VSZ and has been evaluated in laboratory.However,VSZ already implements the continous re-planning paradigm for the traﬃc model too.Furthermore,the inland shipping case diﬀers from the railway one because skippers are independent parties not subject to a predeﬁned schedule and because lock and(most)drawbridge operations are performed on demand(not subject to a given schedule).REFERENCESAndersson,Arne W.,Ingemar Frej,Anders Gideon,Peter Hellstrm and Bengt Sand-blad(1997).A systems analysis approach to modelling train traﬃc control.Proceedings of the WCRR,16-19November1997,Florence, Italy.C,673–679.Matheja, A., C.Zimmermann,rnould, M.Bernard and M.Miska(2001).Wabis-an information an operating system for inland waterways.Proceedings of Second European Inland Waterway Navigation Conference,Bu-dapest.Sandblad,Bengt,Arne W Andersson,Jan Bystrm and Arvid Kauppi(2002).New control strate-gies and user interfaces for train traﬃc con-trol.Proceedings of Comprail2002,Limnos, Grekland,juni2002.。

道路路桥工程中英文对照外文翻译文献

道路路桥工程中英文对照外文翻译文献中英文资料中英文资料外文翻译(文档含英文原文和中文翻译)原文：Asphalt Mixtures-Applications。

Theory and Principles1.ApplicationsXXX is the most common of its applications。

however。

and the onethat will be XXX.XXX “flexible” is used to distinguish these pavements from those made with Portland cement,which are classified as rigid pavements。

that is。

XXX it provides they key to the design approach which must be used XXX.XXX XXX down into high and low types,the type usually XXX product is used。

The low typesof pavement are made with the cutback。

or emulsion。

XXX type may have several names。

However。

XXX is similar for most low-type pavements and XXX mix。

forming the pavement.The high type of asphalt XXX中英文资料XXX grade.中英文资料Fig.·1 A modern XXX.Fig.·2 Asphalt con crete at the San Francisco XXX.They are used when high wheel loads and high volumes of traffic occur and are。

公路通行能力外文翻译文献

道路工程(路桥)毕业设计外文文献翻译

外文文献翻译原文：Asphalt Mixtures-Applications, Theory and Principles1 . ApplicationsAsphalt materials find wide usage in the construction industry. The use of asphalt as a cementing agent in pavements is the most common of its applications, however, and the one that will be consid ered here.Asphalt products are used to produce flexibl e pavements for highways and airports. The term “fl exible” is used to distinguish these pavements from those made with Portland cement, which are classified as rigid pavements, that is, having beam strength. This distinction is important because it provid es they key to the design approach which must be used for successful flexibl e pavement structures.The flexibl e pavement classification may be further broken d own into high and l ow types, the type usually depending on whether a solid or liquid asphalt product is used. The l ow types of pavement are mad e with the cutback, or emulsion, liquid products and are very widely used throughout this country. Descriptive terminology has been devel oped in various sections of the country to the extent that one pavement type may have several names. However, the general process foll owed in construction is similar for most l ow-type pavements and can be described as one in which the aggregate and the asphalt product are usually applied to the roadbed separately and there mixed or all owed to mix, forming the pavement.The high type of asphalt pavements is made with asphalt cements of some sel ected penetration grad e.Fig. ·1 A modern asphalt concrete highway. Should er striping is used as a safely feature.Fig. ·2 Asphalt concrete at the San Francisco International Airport.They are used when high wheel l oads and high volumes of traffic occur and are, therefore, often designed for a particular installation.2 . Theory of asphalt concrete mix designHigh types of flexible pavement are constructed by combining an asphalt cement, often in the penetration grad e of 85 to 100, with aggregates that are usually divided into three groups, based on size. The three groups are coarse aggregates, fine aggregates, and mineral filler. These will be discussed in d etail in later chapter.Each of the constituent parts mentioned has a particular function in the asphalt mixture, and mix proportioning or d esign is the process of ensuring that no function is negl ected. Before these individual functions are examined, however, the criteria for pavement success and failure should be consid ered so that d esign objectives can be established.A successful fl exible pavement must have several particular properties. First, it must be stable, that is to resistant to permanent displacement under l oad. Deformation of an asphalt pavement can occur in three ways, two unsatisfactory and one desirable. Plastic d eformationof a pavement failure and which is to be avoid ed if possible. Compressive deformation of the pavement results in a dimensional change in the pavement, and with this change come a l oss of resiliency and usually a d egree of roughness. This deformation is less serious than the one just described, but it, too, leads to pavement failure. The desirabl e type of deformation is an elastic one, which actually is beneficial to flexibl e pavements and is necessary to their long life.The pavement should be durable and should offer protection to the subgrade. Asphalt cement is not impervious to the effects of weathering, and so the design must minimize weather susceptibility. A durable pavement that does not crack or ravel will probably also protect the roadbed. It must be remembered that fl exible pavements transmit l oads to the subgrad e without significant bridging action, and so a dry firm base is absolutely essential.Rapidly moving vehicl es d epend on the tire-pavement friction factor for control and safety. The texture of the pavement surfaces must be such that an adequate skid resistance is developed or unsafe conditions result. The design procedure should be used to sel ect the asphalt material and aggregates combination which provid es a skid resistant roadway.Design procedures which yield paving mixtures embodying all these properties are not available. Sound pavements are constructed where materials and methods are selected by using time-tested tests and specifications and engineering judgments al ong with a so-call ed design method.The final requirement for any pavement is one of economy. Economy, again, cannot be measured directly, since true economy only begins with construction cost and is not fully determinable until the full useful life of the pavement has been record ed. If, however, the requirements for a stable, durable, and safe pavement are met with a reasonable safety factor, then the best interests of economy have probably been served as well.With these requirements in mind, the functions of the constituent parts can be examined with consideration give to how each part contributes to now-established objectives or requirements. The functions of the aggregates is to carry the l oad imposed on the pavement, and this is accomplished by frictional resistance and interl ocking between the individual pieces of aggregates. The carrying capacity of the asphalt pavement is, then, related to the surface texture (particularly that of the fine aggregate) and the density, or “compactness,”, of the aggregates. Surface texture varies with different aggregates, and while a rough surfacetexture is desired, this may not be available in some l ocalities. Dense mixtures are obtained by using aggregates that are either naturally or artificially “well grad ed”. This means that the fine aggregate serves to fill the voids in the coarser aggregates. In addition to affecting density and therefore strength characteristics, the grading also influences workability. When an excess of coarse aggregate is used, the mix becomes harsh and hard to work. When an excess of mineral filler is used, the mixes become gummy and difficult to manage.The asphalt cement in the fl exibl e pavement is used to bind the aggregate particl es together and to waterproof the pavements. Obtaining the proper asphalt content is extremely important and bears a significant influence on all the items marking a successful pavement. A chief objective of all the design methods which have been devel oped is to arrive at the best asphalt content for a particular combination of aggregates.3 . Mix design principl esCertain fundamental principles underlie the design procedures that have been developed. Before these procedures can be properly studied or applied, some consid eration of these principles is necessary.Asphalt pavements are composed of aggregates, asphalt cement, and voids. Consid ering the aggregate alone, all the space between particles is void space. The volume of aggregate voids depends on grading and can vary widely. When the asphalt cement is ad ded, a portion of these aggregate voids is fill ed and a final air-void volume is retained. The retention of thisair-void volume is very important to the characteristics of the mixture. The term air-void volume is used, since these voids are weightless and are usually expressed as a percentage of the total volume of the compacted mixture.An asphalt pavement carries the applied load by particl e friction and interlock. If the particl es are pushed apart for any reason , then the pavement stability is d estroyed. This factor indicates that certainly no more asphalt shoul d be ad ded than the aggregate voids can readily hold. However ,asphalt cement is susceptible to volume change and the pavement is subject to further compaction under use. If the pavement has no air voids when placed, or if it loses them under traffic, then the expanding asphalt will overfl ow in a condition known as bleeding. The l oss of asphalt cement through bl eeding weakens the pavement and also reduces surface friction, making the roadway hazard ous.Fig. ·3 Cross section of an asphalt concrete pavement showing the aggregate framework bound together by asphalt cement.The need for a minimum air-void volume (usually 2 or 3 per cent ) has been established. In addition, a maximum air-void volume of 5 to 7 per cent shoul d not be exceed. An excess of air voids promotes raveling of the pavement and also permits water to enter and speed up the deteriorating processes. Also, in the presence of excess air the asphalt cement hard ens and ages with an accompanying loss of durability and resiliency.The air-void volume of the mix is determined by the d egree of compaction as well as by the asphalt content. For a given asphalt content, a lightly compacted mix will have a large voids volume and a l ower d ensity and a greater strength will result. In the laboratory, the compaction is controlled by using a specified hammer and regulating the number of bl ows and the energy per blow. In the fiel d, the compaction and the air voids are more difficult to control and tests must be made no specimens taken from the compacted pavement to cheek on the d egree of compaction being obtained. Traffic further compact the pavement, andall owance must be mad e for this in the design. A systematic checking of the pavement over an extend ed period is needed to given factual information for a particular mix. A change in density of several per cent is not unusual, however.Asphalt content has been discussed in connection with various facets of the ix design problem. It is a very important factor in the mix design and has a bearing an all the characteristics ld a successful pavement: stability, skid resistance, durability, and economy. As has been mentioned, the various design procedures are intended to provid e a means for selecting the asphalt content . These tests will be consid ered in detail in a future chapter ,butthe relationship between asphalt content and the measurable properties of stability, unit weight, and air voids will be discussed here.Fig.4 Variations in stability, unit weight, and air-void content with asphalt cement content.If the gradation and type of aggregate, the degree of compaction, and the type of asphalt cement are controll ed, then the strength varies in a predictable manner. The strength will increase up to some optimum asphalt content and then decrease with further additions. The pattern of strength variation will be different when the other mix factors are changed, and so only a typical pattern can be predicted prior to actual testing.Unit weight varies in the same manner as strength when all other variabl e are controll ed. It will reach some peak value at an asphalt content near that determined from the strength curve and then fall off with further additions.As already mentioned, the air-void volume will vary with asphalt content. However, the manner of variation is different in that increased asphalt content will d ecrease air-void volume to some minimum value which is approached asymptotically. With still greater additions of asphalt material the particles of aggregate are only pushed apart and no change occurs in air-void volume.In summary, certain principles involving aggregate gradation, air-void volume, asphalt content, and compaction mist be understood before proceeding to actual mix d esign. The proper design based on these principl es will result in sound pavements. If these principles are overl ooked, the pavement may fail by one or more of the recognized modes of failure: shoving, rutting, corrugating, becoming slick when the max is too ‘rich’; raveling, cracking, having low durability whe n the mix is too ‘l ean’.It should be again emphasized that the strength of flexible is, more accurately, a stabilityand d oes not indicate any ability to bridge weak points in the subgrade by beam strength. No asphalt mixture can be successful unless it rests on top of a properly designed and constructed base structure. This fact, that the surface is no better than the base, must be continually in the minds of those concerned with any aspect of fl exible pavement work.译文：沥青混合料的应用、理论和原则1、应用沥青材料如今在建筑行业广泛使用。

公路建设外文翻译文献

公路建设外文翻译文献(文档含中英文对照即英文原文和中文翻译)PavementHighway pavements are divided into two main categories: rigitand flexible.The wearing surfaceof a rigid pavement is usually constructed of Portland cement concrete such that it acts like a beam over any irregularities in the underlying supporting material.The wearing surface of flexible pavements, on the other hand, is usually constructed of bituminous material such that they remain in contact with the underlying material even when minor irregularities occur.Flexible pavements usually consist of a bituminous surface underlaid with a layer of granular material and a layer of a suitable mixture of coarse and fine materials.Coarse aggregatesFine aggregatesTraffic loads are transferred by the wearing surface to the underlying supporting materials through the interlocking of aggregates, the frictionaleffect of the granular materials, and the cohesion of the fine materials.Flexible pavements are further divided into three subgroups: high type, intermediate type, and low type. High-type pavements have wearing surfaces that adequately support the expected traffic load without visible distress due to fatigue and are not susceptible to weather conditions.Intermediate-type pavements have wearing surfaces that range from surface treated to those with qualities just below that of high-type pavements. Low-type pavements are used mainly for low-cost roads and have wearing surfaces that range from untreated to loose natural materials to surface-treated earth.✹The components of a flexible pavement include the subgradeor prepared roadbed, the subbase, basecourse, and the surface course (Fig.11.1).✹Upper surface courseMiddle surface courseLower surface courseThe performance of the pavement depends on the satisfactory performance of each component, which requires proper evaluation of the properties of each component separately.✹The subgrade is usually the natural material located along the horizontal alignment of the pavement and serves as the foundation of the pavement structure.✹The subgrademay also consist of a layer of selected borrow materials, well compacted to prescribedspecifications.✹Compacting plantCompaction deviceCompactnessIt may be necessary to treat the subgrade material to achieve certain strength properties required for the type of pavement being constructed.Located immediately above the subgrade, the subbase component consists of a superior quality to that which generally is used for subgrade construction. The requirements for subbase materials are usually given in terms of the gradation, plastic characteristics, and strength. When the quality of the subgrade material meets the requirements of the subbase material, the subbase component may be omitted.In cases where suitable subbase material is not readily available ,the available material can be treated with other materials to achieve the necessary properties. This process of treating soils to improve their engineering properties is know as stabilization.✹The base course lies immediately above the subbase. It is placed immediately above the subgrade if a subbase course is not used.✹This course usually consists of granular materials such as crushed stone, crushed or uncrushed.The specifications for base course materials usually include stricter requirements than those for subbase materials, particularly with respect to their plasticity, gradation, and strength.Materials that do not have the required properties can be used as base materials if they are properly stabilized with Portland cement, asphalt, or lime .In some cases, high-quality base course materials may also be treated with asphalt or Portland cement to improve the stiffness characteristics of heavy-duty pavementsThe surface course is the upper course of the road pavement and is constructed immediately above the base course. The surface course in flexible pavement usually consists of a mixture of mineral aggregates and asphaltic materials.It should be capable of withstanding high tire pressures, resisting the abrasive forces due to traffic, providing a skid-resistant driving surface, and preventing the penetration of surface water into the underlying layers.✹The thickness of the wearing surface can vary from 3 in. to more than 6 in.（inch，英寸，2.54cm）, depending on the expected traffic on the pavement.It was shown that the quality of the surface course of a flexible pavement depends on the mix design of the asphalt concrete used.✹Rigid highway pavements usually are constructed to carry heavy traffic loads, although they have been used for residential and local roads. Properly designed and constructed rigid pavements have long service lives and usually are less expensive to maintain than the flexible pavements.✹The Portland cement concrete commonly used for rigid pavements consists of Portland cement, coarse aggregate, fine aggregate, and water. Steel reinforcing rods may or may not be used, depending on the type of pavement being constructed.Rigid highway pavements be divided into three general type: plain concrete pavements, simply reinforced concrete pavements, and continuously reinforced concrete pavement. The definition of each pavement type is related to the amount of reinforcement used.Plain concrete pavement has no temperature steel or dowels for load transfer.However, steel tie bars are often used to provide a hingeeffect at longitudinal joints and to prevent the opening of these joints. Plain concrete pavements are used mainly on low-volume highways or when cement-stabilized soils are used as subbase.Joints are placed at relatively shorter distances (10 to 20 ft) than with the other types of concrete pavements to reduce the amount of cracking.In some case, the transverse joints of plain concrete pavements are skewed about 4 to 5 ft in plan, such that only one wheel of a vehicle passes through the joint at a time. This helps to provide a smoother ride.Simply reinforced concrete pavements have dowels for the transfer of traffic loads across joints, with these joints spaced at larger distances, ranging from 30 to 100 ft. Temperature steel is used throughout the slab, with the amount dependent on the length of the slab. Tie bars are also commonly used in longitudinal joints.Continuously reinforced concrete pavements have no transverse joints, except construction joints or expansion joints when they are necessary at specific positions, such as at bridges.These pavements have a relatively high percentage of steel, with the minimum usually at 0.6 percent of the cross section of the slab. They also contain tie bars across the longitudinal joints.h/2h/25~10cm填缝料横向施工缝构造填缝料平缝加拉杆型Bituminous Surface CoursesThe bituminous surface course has to provide resistance to the effects of repeated loading by tyres and to the effects of the environment.✹In addition, it must offer adequate skid resistance in wet weather as well as comfortable vehicle ride. It must also be resistant to rutting and to cracking.✹It is also desirable that surface course is impermeable, except in the case of porous asphalt.Hot rolled asphalt (HRA) is a gapgraded material with less coarse aggregate. In fact it is essentially a bitumen/fine aggregate/filler mortar into which some coarse aggregate is placed.The mechanical propertiesare dominated by those of the mortar. This material has been extensively used as the wearing course on major road in the UK, though its use has recently declined as new materials have been introduced.✹It provides a durablelayer with good resistance to cracking and one which is relatively easy to compact. The coarse aggregate content is low (typically 30%) which results in the compacted mixture having a smooth surface. Accordingly, the skid resistance is inadequate and precoated chippings are rolled into the surface at the time of laying to correct this deficiency.In Scotland, HRA wearing course remains the preferred wearing course on trunk roads including motorway but，since 1999 thin surfacings have been the preferred option in England and Wales. Since 1999 in Northern Ireland, HRA wearing course and thin surfacings are the preferred permitted options.Porous asphalt (PA) is a uniformly graded material which is designed to provide large air voids so that water can drain to the verges within the layer thickness. If the wearing course is to be effective, the basecourse below must be waterproof and the PA must have the ability to retain its open textured properties with time.Thick binder films are required to resist water damage and ageing of the binder. In use, this material minimizes vehicle spray, provides a quiet ride and lower rolling resistance to traffic than dense mixtures.✹It is often specified for environmental reasons but stone mastic asphalt (SMA) and special thin surfacings are generally favoured in current UK practice.There have been high profile instances where a PA wearing course has failed early in its life. The Highways Agency does not recommend the use of a PA at traffic levels above 6000 commercial vehicles per day.✹Asphaltic concrete and dense bitumen macadam (DBM) are continuously graded mixtures similar in principle to the DBMs used in roadbases and basecourses but with smaller maximum particle sizes. Asphaltic concrete tends to have a slightlydenser grading and is used for road surfaces throughout the world with the excepting of the UK.✹It is more difficult to meet UK skid resistance Standards with DBMs than HRA, SMA or PA. This problem can be resolves by providing a separate surface treatment but doing so generally makes DBM economically unattractive.✹Stone mastic asphalt (SMA) material was pioneeredin Germany and Scandinavia and is now widely used in the UK. SMA has a coarse, aggregrate skeleton, like PA, but the voids are filled with a fine aggregate/filler /bitumen mortar.✹In mixtures using penetration grade bitumen , fibres are added to hold the bitumen within the mixture (to prevent “binder drainage”).Bitumen✹oil bitumen( earth oil)✹natural bitumen✹TarWhere a polymer modified bitumen is used, there is generally no need for fibres. SMA is a gap-graded material with good resistance to rutting and high durability. modified bitumen✹SBS✹SBR✹PE\EV A✹It differs from HRA in that the mortar is designed to just fill the voids in the coarse aggregate whereas, in HRA, coarse aggregate is introduced into the mortar and does not provide a continous stone matrix. The higher stone content HRAs ,however, are rather similar to SMA but are not wide used as wearing courses in the UK, being preferred for roadbase and basecourse construction.A variety of thin and what were called ultra thin surfacings (nowadays, the tendency is to use the term …thin surfacings‟ for both thin and ultra thin surfac ings ) have been introduced in recent years, principally as a result of development work concentrated in France.These materials vary in their detailed constituents but usually have an aggregate grading similar to SMA and often incorporate a polymer modified bitumen.They may be used over a high stiffness roadbase and basecourse or used for resurfacing of existing pavements. For heavy duty pavements (i .e those designed to have a useful life of forty years), the maintenance philosophy is one of minimum lane occupancy, which only allows time for replacement of the wearing course to these …long life‟ pavement structures. The new generation of thin surfacings allows this to be conveniently achieved.The various generic mixture types described above can be compared with respect to their mechanical properties and durability characteristics by reference to Fig.12.1. This shows, in principle, how low stone content HRA, asphaltic concrete, SMA and PA mixtures mobilize resistance to loading by traffic.Asphaltic concrete (Fig.12.1a)) presents something of a compromise when well designed, since the dense aggregate grading can offer good resistance to the shear stresses which cause rutting, while an adequate binder content will provide reasonable resistance to the tensile stresses which cause cracking.In general, the role of the aggregate dominates. DBMs tend to have less dense gradings and properties which, therefore, tend towards good rutting resistance andaway from good crack resistance.HRA (Fig.12.1b)) offers particularly good resistance to cracking through the binder rich mortar between the coarse aggregate particles. This also provides good durability but the lack of coarse aggregate content inhibits resistance to rutting.SMA and PA are shown in the same diagram ( Fig.c)) to emphasis the dominant role the coarse aggregate. In both case, well coated stone is used. In PA, the void space remains available for drainage of water, whilst in SMA, the space is occupied by a fine aggregate/ filler/ bitumen/ fibre mortar.Both materials offer good rutting resistance through the coarse aggregate content. The tensile strength of PA is low whilst that of SMA is probably adequate but little mechanical testing data have been reported to date.Drainage for Road and Airports✹Provision of adequate drainage is important factor in the location and geometric design of road and airports. Drainage facilities on any highway, street and airport should adequately provide for the flow of water away from the surface of the pavement to properly designed channels.Inadequate drainage will eventually result in serious damage to the structure.✹In addition, traffic may be slowed by accumulated water on the pavement, and accidents may occur as a result of hydroplaning and loss of visibility from splash and spray. The importance of adequate drainage is recognized in the amount of highway construction dollars allocated to drainage facilities. About25 percent of highway construction dollars are spent for erosion control anddrainage structures, such as culverts, bridges, channels, and ditches.✹Highway Drainage Structures✹One of the main concerns of the highway engineer is to provide an adequate size structure, such that the waterway opening is sufficiently large to discharge the expected flow of water.Inadequately sized structures can result in water impounding, which may lead to failure of the adjacent sections of the highway due to embankments being submerged in water for long periods.✹The two general categories of drainage structures are major and minor. Major structures are those with clear spans greater than 20 feet, whereas minor structures are those with clear spans of 20 feet or less .✹Major structures are usually large bridges, although multiple-span culverts may also be included in this class. Minor structures include small bridges and culverts.Emphasis is placed on selecting the span and vertical clearancerequirements for major structures. The bridge deck should be located above the high water mark .The clearance above the high water mark depends on whether the waterway is navigable ✹If the waterway is navigable, the clearance above the high water mark should allow the largest ship using the channel to pass underneath the bridge without colliding with the bridge deck. The clearance height, type, and spacing of piers also depend on the probability of ice jams and the extentto which floating logs and debris appear on the waterway during high water.✹An examination of the banks on either side of the waterway will indicate the location of the high water mark, since this is usually associated with signs of erosion and debris deposits. Local residents, who have lived near and observed the waterway during flood stages over a number of years, can also give reliable information on the location of the high water mark. Stream gauges that have been installed in the waterway for many years can also provide data that can be used to locate the high water mark.Minor structures, consisting of short-span bridges and culverts, are the predominant type of drainage structures on highways. Although openings for these structures are not designed to be adequate for the worst flood conditions, they shouldbe large enough to accommodate the flow conditions that might occur during the normal life expectancy of the structure.✹Provision should also be made for preventing clogging of the structure due to floating debris and large boulders rolling from the banks of steep channels.✹Culverts are made of different materials and in different shapes. Materials used to construct culverts include concrete（reinforced and unreinforced）, corrugated steel, and corrugatedaluminum. Other materials may also be used to line the interiorof the culvert to prevent corrosion and abrasionor to reduce hydraulic resistance. For example, asphaltic concrete may be used to line corrugated metal culverts. The different shapes normally used in culvert construction include circular, rectangular (box), elliptical, pipe arch, metal box, and arch.✹The drainage problem is increased in these areas primarily for two reasons: the impervious nature of the area creates a very high runoff; and there is little room for natural water courses. It is often necessary to collect the entire storm water into a system of pipes and transmit it over considerable distances before it can be loosed again as surface runoff. This collection and transmission further increase the problem, since all of the water must be collected with virtually no pending, thus eliminating any natural storage; and through increased velocity the peak runoffs are reached more quickly.Also, the shorter times of peaks cause the system to be more sensitive to short-duration,high intensive rainfall.Storm sewers,like culverts and bridges,are designed for storms of various intensity-return-period relationships, depending upon the economy and amount of ponding that can be tolerated.✹Airport Drainage✹The problem of providing proper drainage facilities for airports is similar in many ways to that of highways and streets. However, because of the large and relatively flat surface involved, the varying soil conditions, the absence of natural water courses and possible side ditches, and the greater concentration of discharge at the terminus of the construction area, some phases of the problem are more complex. For the average airport the over-all area to be drained is relatively large and an extensive drainage system is required. The magnitude of such a system makes it even more imperative that sound engineering principles based on all of the best available data be used to ensure the most economical design.Overdesigning of facilities results in excessive money investment with no return, and underdesigning can result in conditions hazardous to the air traffic using the airport. In order to ensure surfaces that are smooth, firm, stable, and reasonably free from flooding, it is necessary to provide a system which will do several things.It must collect and remove the surface water from the airport surfaces; intercept and remove surface water flowing toward the airport from adjacent areas; collect and remove any excessive subsurface water beneath the surface of the airport facilities and in many cases lower the ground-water table; and provide protection against erosion of the sloping areas.路面公路的路面被分为两类：刚性的和柔性的。

交通建设项目工程专业外文翻译外文文献英文文献.doc

土木工程学院交通工程专业中英文翻译Road Design专业：交通工程英文原文The Basics of a Good RoadWe have known how to build good roads for a long time. Archaeologists have found ancient Egyptian roadsthat carried blocks to the pyramids in 4600 BCE. Later,the Romans built an extensive road system, using the same principles we use today. Some of these roads are still in service.If you follow the basic concepts of road building, you will create a road that will last. The ten commandments of a good road are:（1）Get water away from the road（2）Build on a firm foundation（3）Use the best materials（4）Compact all layers properly（5）Design for traffic loads and volumes（6）Design for maintenance（7）Pave only when ready（8）Build from the bottom up（9）Protect your investment（10）Keep good records1．Get water away from the roadWe can’t overemphasize the importance of good drainage.Engineers estimate that at least 90% of a road’s problems can be related to excess water or to poor waterdrainage. Too much water in any laye r of a road’sstructure can weaken that layer, leading to failure.In the surface layer, water can cause cracks and potholes. In lower layers it undermines support, causing cracks and potholes. A common sign of water in an asphalt road surface is alligator cracking — an interconnected pattern of cracks forming small irregular shaped pieces that look like alligator skin. Edge cracking, frost heaves, and spring breakup of pavements also point to moisture problems.To prevent these problems remember that water:• flows downhill• needs to flow someplace• is a problem if it is not flowingEffective drainage systems divert, drain and dispose of water. To do this they use interceptor ditches and slopes,road crowns, and ditch and culvert systems.Divert —Interceptor ditches, located between the road and higher ground along the road, keep the water from reaching the roadway. These ditches must slope so they carry water away from the road.Drain —Creating a crown in the road so it is higher along the centerline than at the edges encourages water to flow off the road. Typically a paved crown should be 1⁄4" higher than the shoulder for each foot of width from the centerline to the edge. For gravel surfaces the crown should be 1⁄2" higher per foot of width. For this flow path to work, the road surface must be relativelywater tight. Road shoulders also must be sloped away from the road to continue carrying the flow away. Superelevations (banking) at the outside of curves will also help drainthe road surface.Dispose —A ditch and culvert system carries water away from the road structure. Ditches should be at least one foot lower than the bottom of the gravel road layer that drains the roadway. They must be kept clean and must be sloped to move water into natural drainage. If water stays in the ditches it can seep back into the road structure and undermine its strength. Ditches should also be protected from erosion by planting grass, or installing rock and other erosion control measures. Erosion can damage shoulders and ditches, clog culverts, undermine roadbeds, and contaminate nearby streams and lakes. Evaluate your ditch and culvert system twice a year to ensure that it works. In the fall, clean out leaves and branches that can block flow. In spring, check for and remove silts from plowing and any dead plant material left from the fall.2．Build on a firm foundationA road is only as good as its foundation. A highway wears out from the top down but falls apart from the bottom. The road base must carry the entire structure and the traffic that uses it.To make a firm foundation you may need to stabilize the roadbed with chemical stabilizers, large stone called breaker run, or geotextile fabric. When you run into conditions where you suspect that the native soil is unstable, work with an engineer to investigate the situation and design an appropriate solution.3．Use the best materialsWith all road materials you “pay now or pay later.” Inferior materials may require extensive maintenance throughout the road’s life. They may also force you to replace the road prematurely.Crushed aggregate is the best material for the base course. The sharp angles of thecrushed material interlock when they are compacted. This supports the pavement and traffic by transmitting the load from particle to particle. By contrast, rounded particles act like ballbearings, moving under loads.Angular particles are more stable than rounded particles.Asphalt and concrete pavement materials must be of the highest quality, designed for the conditions, obtained from established firms, and tested to ensure it meets specifications. 4．Compact all layersIn general, the more densely a material is compacted, the stronger it is. Compaction also shrinks or eliminates open spaces (voids) between particles. This means that less water can enter the structure. Water in soil can weaken the structure or lead to frost heaves. This is especially important for unsurfaced (gravel) roads. Use gravel which has a mix of sizes (well-graded aggregate) so smaller particles can fill the voids between larger ones. Goodcompaction of asphalt pavement lengthens its life.5．Design for traffic loads and volumesDesign for the highest anticipated load the road will carry. A road that has been designed only for cars will not stand up to trucks. One truck with 9 tons on a single rear axle does as much damage to a road as nearly 10,000 cars.Rural roads may carry log trucks, milk trucks, fire department pumper trucks, or construction equipment. If you don’t know what specific loads the road will carry, a good rule of thumb is to design for the largest piece of highway maintenance equipment that will be used on the road.A well-constructed and maintained asphalt road should last 20 years without major repairs orreconstruction. In designing a road, use traffic counts that project numbers and sizes of vehicles 20 years into the future. These are only projections, at best, but they will allow you to plan for traffic loadings through a road’s life.6．Design for maintenanceWithout maintenance a road will rapidly deteriorate and fail. Design your roads so they can be easily maintained. This means:• adequate ditches that can be cleaned regularly• culverts that are marked for easy locating in the spring• enough space for snow after it is plowed off the road• proper cross slopes for safety, maintenance and to avoid snow drifts• roadsi des that are planted or treated to prevent erosion• roadsides that can be mowed safelyA rule of thumb for adequate road width is to make it wide enough for a snowplow to pass another vehicle without leaving the travelled way.Mark culverts with a post so they can be located easily.7．Pave only when readyIt is not necessary to pave all your roads immediately. There is nothing wrong with a well-built and wellmaintained gravel road if traffic loads and volume do not require a paved surface. Three hundred vehicles per day is the recommended minimum to justify paving.Don’t assume that laying down asphalt will fix a gravel road that is failing. Before you pave, make sure you have an adequate crushed stone base that drains well and is properly compacted. The recommended minimum depth of crushed stone base is 10" depending on subgrade soils. A road paved only when it is ready will far outperform one that is constructed too quickly.8．Ê Build from the bottom upThis commandment may seem obvious, but it means that you shouldn’t top dress or resurface a road if the problem is in an underlying layer. Before you do any road improvement, locate the cause of any surface problems. Choose an improvement technique that will address the problem. This may mean recycling or removing all road materials down to the native soil and rebuilding everything. Doing any work that doesn’t solve the problem is a waste of money and effort.9．Ê Protect your investmentThe road system can be your municipality’s biggest investment. Just as a home needs painting or a new roof, a road must be maintained. Wisconsin’s severe climate requires more road maintenance than in milder places. Do these important maintenance activities: Surface —grade, shape, patch, seal cracks, control dust, remove snow and iceDrainage —clean and repair ditches and culverts; remove all excess materialRoadside —cut brush, trim trees and roadside plantings, control erosionTraffic service —clean and repair or replace signsDesign roads with adequate ditches so they can be maintained with a motor grader. Clean and grade ditches to maintain proper pitch and peak efficiency. After grading, remove all excess material from the shoulder.10．Keep good recordsYour maintenance will be more efficient with good records. Knowing the road’s construction, life, and repair history makes it much easier to plan and budget its future repairs. Records can also help you evaluate the effectiveness of the repair methods and materials you used.Good record keeping starts with an inventory of the system. It should include the history and surface condition of the roadway, identify and evaluate culverts and bridges, note ditch conditions, shoulders, signs, and such structures as retaining walls and guardrails.Update your inventory each year or when you repair or change a road section. A formal pavement management system can help use these records and plan and budget road improvements.ResourcesThe Basics of a Good Road#17649, UW-Madison, 15 min. videotape. Presents the Ten Commandments of a Good Road. Videotapes are loaned free through County Extension offices.Asphalt PASER Manual(39 pp), Concrete PASER Manual (48 pp), Gravel PASER Manual (32 pp). These booklets contain extensive photos and descriptions of road surfacesto help you understand types of distress conditions and their causes. A simple procedure for rating the condition helps you manage your pavements and plan repairs.Roadware, a computer program which stores and reports pavement condition information. Developed by the Transportation Information Center and enhanced by the Wisconsin Department of Transportation, it uses the PASER rating system to provide five-year cost budgets and roadway repair/reconstruction priority lists.Wisconsin Transportation Bulletin factsheets, available from the Transportation Information Center (T.I.C.).Road Drainage, No. 4. Describes drainage for roadways, shoulders, ditches, and culverts.Gravel Roads, No. 5. Discusses the characteristics of a gravel road and how to maintain one.Using Salt and Sand for Winter Road Maintenance,No. 6. Basic information and practical tips on how to use de-icing chemicals and sand.Culverts—Proper Use and Installation, No. 15. Selecting and sizing culverts, designing, installing and maintaining them.Geotextiles in Road Construction/Maintenance andErosion Control, No. 16. Definitions and common applications of geotextiles on roadways and for erosion control.T.I.C. workshops are offered at locations around the state.Crossroads,an 8-page quarterly newsletter published by the T.I.C. carries helpful articles, workshop information, and resource lists. For more information on any of these materials, contact the T.I.C. at 800/442-4615.中文译文一个良好的公路的基础长久以来我们已经掌握了如何铺设好一条道路的方法，考古学家发现在4600年古埃及使用建造金字塔的石块铺设道路，后来，罗马人使用同样的方法建立了一个庞大的道路系统，这种方法一直沿用到今天。
