沃尔沃说明书
沃尔沃I-Shift型号产品驱动模式和软件功能说明书
I-Shift drive modes and software functionsThe I-Shift gearboxʼs functions are optimized with specially adapted drive modes, which make the gearbox even more practical and economical by adapting the gearshift functional-ity to the current transport conditionsThe driving mode is selected with a button on the gear se-lector. Fuel saving functions are adjusted according to the se-lected drive mode. I-See (optional) speed limits and strategy are adjusted according to the selected drive mode.Drive modes•Economy: Focus on lowering fuel consumption, some re-duction in power. Using I-See function.•Standard: Reasonable fuel consumption without compro-mising drivability. Using I-See function.•Performance: Full power, with less focus on fuel consump-tion.•Off-road: Agility is prioritised.•Heavy duty: Optimised for drivability and comfort at high loads (Heavy Equipment Transport).Sales variantsDrive modeDRM-E I-Shift drive mode economyDRM-BE I-Shift drive mode balanced economyAMT vocation optionAVO-BAS Basic I-Shift softwareAVO-ENH Enhanced I-Shift software including construc-tion and off-road applicationsAVO-HD Enhanced I-Shift software including heavy du-ty, construction and off-road applicationsTransmission performance modeTPM-AUTR Transmission performance mode auto return TPM-MAN Transmission performance mode manual UTPM Without drive mode performance in DRM-BEAMT manual shift optionsAMSO-BAS Basic I-Shift gear shiftingAMSO-AUT I-Shift manual gear shift available in automatic mode incl kickdown functionAMT PTO functionsAPF-BAS Basic I-Shift PTO functionsAPF-ENH Enhanced I-Shift PTO functions (Auto Neu-tral/ Reverse Inhibit / Split Box Connection)FEATURES AND BENEFITS•Optimized drivability.•Reduce fuel consumption.•Reduce CO2 footprint.•Simplify selection of drive modes.FACT SHEETI-Shift drive modesI-Shift drive modes icons in instrument cluster.I-Shift drive modes and software functions● Standard, ○ Option, — Not available1Note! Choice of UTPM gives no Performance drive mode.DRM-E+AVO-BAS is designed for long haul transport to secure a good fuel economy.DRM-BE+AVO-BAS is the versatile offer for the majority of the transport segments.DRM-BE+AVO-ENH is adapted for construction operations.DRM-BE+AVO-HD is specially tailored for heavier transport operations.FACT SHEETI-Shift drive modesI-Shift software functions● Standard, ○ Option, — Not available2Only AT2612, ATO2612, ATO3112 and ATO3512.3For Volvo FH16 or for a Volvo with driven front axle.FACT SHEETI-Shift drive modesI-Shift Drive Mode Economy (DRM-E)DRM-E is optimized for fleet usage were driver influence is limited. To access I-See functionality, PVT-MAP needs to be added.This drive mode restricts the possibility to alter among the drive modes. The DRM-E will be locked in Economy mode. I-Shift Drive Mode Balanced Economy (DRM-BE)This is the base which giving ideal selection for most all ap-plications. To optimize further toward a particular vocation, DRM-BE is selected with AVO-BAS, AVO-ENH or AVO-HD. For customer usages with frequent start and stop like garbage collection, a potential to save fuel is to remove the possibility to access performance driving mode. That variant exist for DRM-BE and is called UTPM.For DRM-BE with UTPM, the performance drive mode is removed and consequently also the option with TPM-AUTR. Other options in DRM-BE with UTPM are available like AVO-ENH/AMSO-AUT/APF-ENH.Basic Vocational Functions (AVO-BAS)Allows the driver to choose between the Economy, Standard and Performance driving modes.Enhanced Performance – Bad Roads (AVO-ENH)This optional package is specially adapted to the specific con-ditions of the construction and timber transport segments. The Off-road mode includes various functions that adapt gearshifts and gear selection to poor driving surfaces and hilly gradients. It also includes functions that facilitate starting from standstill in poor driving conditions.Off-road mode is designed to minimise the number of gearshifts required. This is useful during off-road driving. It prevents wheels from spinning out when torque is increased after a gearshift, and prevents missed gearshifts, for example if the road gradient changes sharply. High engine power (high revs) is often required when driving uphill.The driver can also influence the maximum number of down shifts. This is very useful when you shift to a lower gear on a very steep uphill gradient and only want to shift once to a gear strong enough to take you all the way up. Economy, Standard, Performance and Off-road driving modes are available. Summary of the functions in the package:•Engine revs are increased as necessary to provide extra torque when starting off from standstill.•Larger margins before upshifts ensure safer driving if the gradient changes.•Gear selection is adapted to minimise the number of gearshifts and run at slightly higher revs.•Functions that make it easier to keep the same gear when the accelerator pedal position and road gradient change.•The package enables multiple downshifts. This facilitates gearshifts when driving up steep slopes.•Includes a function that speeds up clutch release and makes it easier to rock the vehicle out of trouble if it gets stuck on a soft surface.•When moving the gear lever, the driver can choose the gear that provides the highest possible engine speed. Enhanced Performance – Heavy duty (AVO-HD)AVO-HD optimizes I-Shift for heavy duty transport with high gross combination weights (>85 tonnes). Regardless of the gross combination weight, the driver can always optimize dri-vability by selecting or deactivating the Heavy Duty mode, and activating the long haul mode. The functions in the software package also offer benefits for trucks hauling multiple trailers. AVO-HD also includes AVO-ENH functions (Off-road mode)but the functions in Off-road are only active when the Heavy Duty mode is inactive.Change DirectionEnables fast change of driving direction in for instance maneuvering situations by change direction functionality. Change direction is to select reverse gear at lower vehicle speed and use the accelerator pedal to brake the vehicle and start reversing without letting the foot of the accelerator pedal. Vice versa applies, i.e. reversing the vehicle and thenFACT SHEETI-Shift drive modespush the gear selector into A/M and use accelerator pedal to come into forward driving. Pressing the accelerator pedal more makes the event of changing driving direction to occur faster. Change Direction is activated up to 30 km/h.Note! Change Direction requires AVO-ENH or AVO-HD. Terrain BrakeTerrain brake gives improved off-road agility for Volvo FH16 or for a Volvo with driven front axle.With this function, the driver controlling the vehicle better. For instance, rolling off a stone in terrain, is made in a con-trolled manor by the driver activation.Terrain brake means that the brake is applied when the ac-celerator pedal is released and consequently holds the truck in the position inhibiting free rolling. Terrain brake can be en-gaged below 4 km/h, i.e. at low speeds. Applied terrain brake force is controlled by the retarder brake lever position on the steering column.Note! Terrain Brake requires AVO-ENH or AVO-HD. Transmission Performance Mode Auto Return (TPM-AUTR)Transmission performance mode AUTR. Auto return to drive mode Economy.Enable manual switch (TPM-MAN)Transmission performance mode MAN. Enable manual switch between Economy and Performance mode.Basic Gear Selection Adjustment (AMSO-BAS) Allows the driver to adjust gear selection with the gear lever buttons during engine braking in Automatic mode (gear selec-tor position A).Enhanced Gear Selection Adjustment,incl. Kickdown (AMSO-AUT)This function allows both the automatically selected starting gear and the driving gear in Automatic mode to be adjusted by activating the plus/minus button on the gear lever.The kickdown function selects a gear for maximum acceler-ation. When the kickdown switch on the accelerator pedal is engaged, the system changes the gearshift strategy to max-imise vehicle acceleration. When suitable (e.g. depending on engine speed), this leads to a downshift.Basic PTO Functions (APF-BAS)Facilitates power take-off operation. Pre-defined splitter gear positions determine which splitter gear is used when one or two gearbox power take-offs are engaged.Because gear selection is matched to the engine speed lim-it, it is possible to set parameters for the software. The gear selection is then adapted to any engine speed limits imposed by body-builder functions.Enhanced PTO Functions (APF-ENH)Several functions that aid power take-off operation. I-Shiftʼs power take-off functions make it possible to activate the prop-erties listed below by having the software parameters adjust-ed at an authorised workshop.•Auto Neutral: On command, the driveline is disconnected from the bodybuilder control unit, regardless of the gear leverʼs position, when Auto Neutral is activated.•Reverse Inhibit: When the bodybuilder control unit is-sues the Reverse Inhibit command, the reverse gears are blocked by the transmission system.•Connection of splitter box: Allows connection of a splitter box for operation of high-capacity power take-offs. Direct gear is activated when the bodybuilder module is put in splitter box mode. It is also possible to use all high range gears. Please look into the body builder instructions. Performance ShiftGives faster, gentler shifts through intelligent utilisation of the engineʼs compression brake (VEB brakes), the vehicleʼs clutch and a special gearbox brake.Automatic selection of correct starting gear (1st – 6th gear)is included. The choice of starting gear is determined by gross vehicle weight and road gradient.Gearbox Oil Temperature MonitorContinuously shows the gearbox oil temperature in the infor-mation display.Heavy Start EngagementFor start-up with high revs in Performance mode in 1st gear,resulting in higher starting torque. This function raises the revs to facilitate heavy starts. This is useful, for instance, if the truck is stuck in soft ground.I-RollAutomatic activation and deactivation of a freewheel function in order to cut fuel consumption, which can be reduced by up to several percent. I-Roll is used when neither engine power nor engine braking is needed, for instance on flat roads. When driving with cruise control, I-Roll runs at roughly 1–3 km/h be-low the pre-set speed, which saves fuel. The longer the vehi-FACT SHEETI-Shift drive modescle drives using I-Roll, the more fuel is saved.Smart Cruise ControlInteracts with the vehicleʼs Brake Cruise and ensures that the auxiliary brakes are not activated unnecessarily. The auxiliary brakes are deactivated on downhill stretches to save fuel. This allows increased use of the freewheel function, resulting in improved fuel efficiency.Downhill Cruise ControlDownhill Cruise Control sets a maximum speed to control the vehicle speed in a down-hill.Downhill Cruise Control primarily uses the auxiliary brakes such as the Volvo Engine Brake or the retarder to make sure that the selected speed is not exceeded. Only when required, the wheel brakes are applied.The driver can still use the brake pedal to further lower the speed without deactivating the system.Launch ControlOptimizes gear selection and EBS functions when manoeu-vring at low speeds. Manoeuvring is facilitated because the EBS brakes are automatically engaged when the truck changes direction. This also ensures that the Auto Hold func-tion is activated.It is possible to drive the vehicle forward with the idle regu-lator. This saves unnecessary downshifts and makes it easier to adjust the vehicleʼs speed, for instance when driving in traf-fic queues.Enhanced Shift Strategy4By interacting with EBS 5 and ECS 6, both starting and ma-noeuvring are made easier.This brake mode maximises VEB/VEB+/retarder braking effects by automatically selecting the appropriate gear so the engine runs at high revs. This function compensates for the engine brake when changing gears in brake mode.When changing gears during engine braking, the wheel brakes are activated to compensate for braking moment. This raises braking power and provides smoother gearshifts. Interaction with the braking systems increases safety by preventing the truck from accelerating during gearshifts on steep slopes when braking mode is activated.Heavy Duty GCW Control7Optimizes gear selection for high gross combination weights(according to heavy haulage document). This function improves drivability and fuel economy in the heavy duty trans-port segment. Heavy Duty GCW Control gives the driver ac-cess to the HD (Heavy Duty) driving mode.In HD mode, 1st gear is used as the starting gear and gear selection is adapted to heavier gross combination weights. The gearshifts generally occur at higher revs. HD is activat-ed and deactivated by pressing and holding the modes button on the gear selector for about 3 seconds. The chosen driving mode remains selected when the engine is turned off. Among other things, the DRM-BE-AVO-HD function se-lects the starting gear to suit the gross combination weight, thereby saving the clutch. The entire gear range is utilised, and the gears are changed consistently at high revs to maintain torque and driving comfort.When driving with low gross combination weights or with-out a load, it is easy to deactivate the HD driving mode and return to Economy mode. After this, the driver can switch be-tween available drive modes. This ensures comfortable and fuel efficient driving.4 Full functionality requires EBS-MED.5 EBS = Disc Brakes with Electronically controlled Brake System (EBS-STD / EBS-MED)6 ECS = Electronically Controlled Suspension (SUSPL-EC).7 Available only with certain engine/gearbox combinations.Volvo Tech ToolI-Shiftʼs software packages can easily be installed and changed with the help of Volvoʼs analysis and programming tool, Volvo Tech Tool. This is done by authorised dealers and workshops,where the software packages can be further cus-tomised with optional functions and customer parameters. Customer parametersI-Shift also has many options for setting customer parame-ters that optimize the vehicleʼs driving properties in special applications and special transport segments. For instance, the starting gear can be optimized according to the transport conditions. Power take-off operation can also be customised. Customised settings and reprogramming of I-Shift are car-ried out at authorised workshops using the Volvo Tech Tool.FACT SHEETI-Shift drive modes。
沃尔沃儿童电动车说明书
沃尔沃儿童电动车说明书一、产品介绍沃尔沃儿童电动车是专为儿童设计的迷你版电动汽车，外观造型时尚可爱，颜色鲜艳。
它采用环保材料制作，符合儿童玩具安全标准，为孩子们提供安全、健康的娱乐方式。
二、产品特点1. 真实驾驶体验：沃尔沃儿童电动车配备了真实的方向盘和踏板，让孩子们能够体验到真正的驾驶乐趣，增强了他们的动手能力和协调能力。
2. 电池供电：沃尔沃儿童电动车采用可充电电池供电，无需频繁更换电池，方便实用。
3. 安全设计：车辆配备了安全带和防护围栏，有效保护孩子的安全。
此外，车辆底盘采用防滑设计，增加了行驶的稳定性。
4. 音乐娱乐：沃尔沃儿童电动车内置了多首儿童歌曲和音效，让孩子在驾驶的同时享受音乐的快乐。
5. 灯光效果：车辆装配了前后灯光和转向灯，增加了夜间行驶的安全性。
三、使用方法1. 充电：使用配套的充电器连接电源插座，然后将充电器连接至车辆上的充电接口。
充电时间约为8小时，请确保在成人的监护下进行充电操作。
2. 启动：将钥匙插入车辆上的点火开关，然后按下启动按钮即可启动车辆。
注意要确保车辆处于平稳的地面上。
3. 驾驶：在启动后，踩下踏板即可前进，松开踏板则停止。
方向盘用于控制车辆的转向，左转向左转动方向盘，右转向右转动方向盘。
4. 停车：在需要停车时，松开踏板即可停止车辆。
请确保在停车时车辆停在平稳的地面上，并拉上手刹。
四、注意事项1. 使用时请遵循交通规则，不要在拥挤的地方行驶，以免发生意外。
2. 使用前请确保车辆的电池已充满电。
3. 在使用过程中，如发现车辆出现异常情况（如异响、电池损坏等），请停止使用并及时联系售后服务中心。
4. 在长时间不使用时，请将电池取出并储存在干燥通风的地方。
5. 严禁将车辆用于除儿童游戏之外的其他用途。
6. 在使用过程中，家长应时刻监护孩子的安全，避免发生意外事故。
五、保养和维修1. 定期检查车辆的电池是否正常，如发现电池老化或损坏，请及时更换。
2. 清洁车辆时，使用湿布擦拭，切勿使用化学清洁剂。
沃尔沃汽车手册说明书
硬盘驱动器 进寻请请远..................... 旧拨
媒体播 器 - 兼容文件格式............ 旧择
通过 致U下/U分B 输入 接外部音源......... 旧只
通过 致U下/U分B 输入 接外部音源......... 旧叫
使用中 的按钮和 制或方向盘 侧的键 盘， 启动或解除*功能和 行许多ď 的
置
按č MY重台AR，显示Đ车 驾驶和 制有关的
所有 定，例如 Cit本 分且f优t本 和警 自
动风扇转
定时钟等
中 中的 制面
示仅用作示意 - 功能的
数量和按钮的 置 选定的 备和具体 场而
异 航 * - 寻AV ， 参 阅 ĕ 门 的 附 录
分优n账u账 航系统 音响和媒体 - RADI导 MEDIA TEL*，
参阅 附录的相关章节
功 能 置 - MY重 台AR ， 参 阅 销同 C致R 进 码古详远
}}
* 选配件/附件的更多信息， 查看 言
只
01重 言
口古
车 互联网 接 -
*，
参阅
古
附录
车 中的电子版 车 手
选 č角的信息符 ，获 电子 车Ľ手册
®
03B速u优tooth 免提电话 - 音量 置........ 拨拨
电话簿............................... 拨择 电话簿 - 快 搜索联系人.............. 拨择 电话簿 - 中 Č的 符表键盘........ 拨择 电话簿 - 搜索联系人.................. 拨只 语音识别............................. 拨只 语音识别的语言选 ................... 拨叫 语音识别的帮助功能................... 拨9 语音识别 - 置...................... 拨9 语音识别 - 语音指 .................. 择口 语音识别 - 快 指 .................. 择口 语音识别 - 移动电话.................. 择口 语音识别 - 收音机.................... 择古 语音识别 - 多媒体.................... 择古 联网车 ............................. 择该 车 调制解调器 *..................... 择旧
沃尔沃S60车型说明书
VOLVO S60 PRICING606060 60 The S model comes with all the features you’d expect of a Volvo, and one or two more. Beyond 16" Echo wheels and DSTC (Dynamic Stability and Traction Control),the S offers sophisticated dual-zone climate control, electric door mirrors and windows,cruise control, leather steering wheel and gear knob, and our Performance audio system with 6 speakers and CD player.The SE aims to spoil. Its luxurious interior boasts Sports seats with leather-faced upholstery – electronically adjustable for the driver. Then there’s the 9-speaker High Performance audio system with Dolby ®Pro Logic ®II Surround Sound (ii), and intuitive features, such as an automatic rain sensor and autodimming rear-view mirror. On the outside, 17" Orestes wheels and chrome inserts in the bumpers make sure your presence doesn’t go unnoticed.60 Want to make an impression? Our Sport model is the car for you. Essential features include 17" Orpheus alloy wheels, speed dependent steeringsystem, colour coordinated front and rear lower spoilers, side mouldings and rear spoiler. Inside the cabin, the equipment list includes leather sports steering wheel and gear knob. The Sports seats areupholstered in Nordborg – combining the benefits of leather and textile – while interior inlays are aluminium.SE Sport combines sporty features from the Sport model with luxury features from the SE and also includes Imola Sports leather upholstery and chronograph instrument dials, plus 18" Nebul alloy wheels.SE Lux includes all the features from the luxurious SE plus upgraded Sovereign Hide upholstery, walnut wood trim, bi-xenon headlamps and Volvo’s Dynaudio Premium sound audio system.CHOOSE YOUR VOLVO 2-3STANDARD EQUIPMENT 4OPTIONS5ACCESSORIES & UPHOLSTERY 6-7TECHNICAL SPECIFICATION 8-9CHOOSE YOUR COLOUR 10INSCRIPTION TM 11CARE BY VOLVO 13THE VOLVO S60If you’ve been searching for a stylish, sporty machine then look no further – the Volvo S60 is the definitive sports saloon. Blessed with perfectly sculpted body work and a luxurious interior, it certainly looks the part.But it’s under the bonnet where it really excels – take a look through this price list to find out about the S60’s jaw dropping performance.T5The T5 2.4 litre, turbocharged, in-line, 5 cylinder engine delivers outstanding performance – producing 260 PS and 350 Nm torque. This extremely smooth engine features variable valve timing on the exhaust side and a responsive turbocharger designed to deliver maximum torque from low and medium engine speeds. Effortless performance is combined with excellent fuel consumption and CO 2emissions.D5The D5 2.4 litre, turbocharged, in-line, 5 cylinder, common rail diesel engine delivers very low fuel consumption and CO 2emissions with excellent performance – producing 185 PS and 400 Nm torque. This extremely advanced diesel engine is made entirely of aluminium giving it a similar weight to a petrol engine.This advanced design combined with third-generation electronic common rail fuel injection, variable blade turbocharger and a diesel particulate filter makes it one of the cleanest and most advanced diesel engines available on the market. A 2.4D version with 163 PS is also available.BI-FUELAs part of Volvo’s total commitment to the environment, the S60 Bi-Fuel engine enables you to benefit from the lower cost of CNG (iii)and reduce harmful emissions to the atmosphere.2(i)Euro prices shown are calculated using an exchange rate of 1.469 Euros to the £, as published in the Financial Times on 1st March 2006. Euro prices will be subject to the prevailing exchange rate at the time of purchase. These figures are for information purposes only.(ii)Dolby and Pro Logic II Surround Sound™ are trademarks of Dolby Laboratories Licensing Corporation.(iii)Compressed Natural Gas.Rec. Retail On the Road On the Road Basic £VAT £Price £Price £Price w PETROL2.0T S £16,733.62£2,928.38£19,662.00£20,370.00129,923.532.5T S£18,810.21£3,291.79£22,102.00£22,810.00133,507.89DIESEL2.4D (163 PS) S £18,482.55£3,234.45£21,717.00£22,395.00132,898.26D5 (185 PS) S£19,214.47£3,362.53£22,577.00£23,255.00134,161.60BI-FUEL2.4 Bi-Fuel (CNG)(iii)S£18,661.28£3,265.72£21,927.00£22,560.00133,140.64Rec. Retail On the Road On the Road Basic £VAT £Price £Price £Price w PETROL2.0T Sport £18,308.09£3,203.91£21,512.00£22,220.00132,641.182.5T Sport £20,384.68£3,567.32£23,952.00£24,660.00136,225.54T5 Sport£22,159.15£3,877.85£26,037.00£26,745.00139,288.41DIESEL2.4D (163 PS) Sport £20,057.02£3,509.98£23,567.00£24,245.00135,615.91D5 (185 PS) Sport£20,788.94£3,638.06£24,427.00£25,105.00136,879.25Rec. Retail On the Road On the Road Basic £VAT £Price £Price £Price w PETROL2.0T SE £18,861.28£3,300.72£22,162.00£22,870.00133,596.032.5T SE £20,937.87£3,664.13£24,602.00£25,310.00137,180.39T5 SE£22,712.34£3,974.66£26,687.00£27,395.00140,243.26DIESEL2.4D (163 PS) SE £20,610.21£3,606.79£24,217.00£24,895.00136,570.76D5 (185 PS) SE£21,342.13£3,734.87£25,077.00£25,755.00137,834.10BI-FUEL2.4 Bi-Fuel (CNG)(iii)SE£20,788.94£3,638.06£24,427.00£25,060.00136,813.14Rec. Retail On the Road On the Road Basic £VAT £Price £Price £Price w PETROL2.0T SE Sport £20,393.19£3,568.81£23,962.00£24,670.00136,240.232.5T SE Sport £22,469.79£3,932.21£26,402.00£27,110.00139,824.59T5 SE Sport£24,159.15£4,227.85£28,387.00£29,095.00142,740.56DIESEL2.4D (163 PS) SE Sport £22,142.13£3,874.87£26,017.00£26,695.00139,214.96D5 (185 PS) SE Sport£22,874.04£4,002.96£26,877.00£27,555.00140,478.30Rec. Retail On the Road On the Road Basic £VAT £Price £Price £Price w PETROL2.0T SE Lux £20,776.17£3,635.83£24,412.00£25,120.00136,901.282.5T SE Lux £22,852.77£3,999.23£26,852.00£27,560.00140,485.64T5 SE Lux£24,627.23£4,309.77£28,937.00£29,645.00143,548.51DIESEL2.4D (163 PS) SE Lux £22,525.11£3,941.89£26,467.00£27,145.00139,876.01D5 (185 PS) SE Lux£23,257.02£4,069.98£27,327.00£28,005.00141,139.35W H E T H E R Y O U D E S I R E P U L S E -R A C I N G P E R F O R M A N C E O R O U T S T A N D I N G F U E L E C O N O M Y , Y O U R W I S H I S O U R C O M M A N D .THE VOLVOS603W I T H A L L O F T H I S A S S T A N D A R D , Y O U C A N B E S U R E Y O U ’L L B E W E L L E Q U I P P E D F O R L I F E I N Y O U R V O L V O .4THE VOLVOS60Financial Times on 1st March 2006. Euro prices will be subject to the prevailing exchange rate at time of Two Cupholders in Tunnel Console are removed when Front and Rear Ashtray, Cupholder in Tunnel Consoleare trademarks of Dolby Laboratories Licensing Corporation.Four-C Chassis cannot be combined with Load Compensating Suspension or Lowered Sport Chassis.q516"Ursa17"Orpheus17"OrpheusACCESSORIES&UPHOCHOOSEYOURPERFECTDRIVINGENVIRONMENTFORYOURVOLVO.7THE VOLVOS60UPHOLSTERYNordborg T extile/Leather SportsLight Sand (9G51)Leather-faced SportsLight Sand (9A51)OAK/ARENASovereign HideSoft Leather SportsArena (978C)Imola SportLeatherArena/Oak (918C)Imola SportLeatherArena/Off Black (917C)(i)Euro prices shown are for information only and are calculated using an exchange rate of1.469 Euros to the £, as published in the Financial Times on 1st March 2006.Euro prices will be subject to the prevailing exchange rate at the time of purchase.These figures are for information purposes only.(ii)Indicates total fitted price. At participating dealers only.(iii)VAT on Child Seats = 5%.(iv)Denotes the colour of the door panels above the Inlay Trim.(v)In combination with the Volvo Premium Sound loudspeaker system, the front doorsides are trimmed in Oak vinyl.(vi)In combination with the Volvo Premium Sound loudspeaker system, the front doorsides are trimmed in Off Black vinyl.(vii)Not for iPod shuffle.NB It is not possible to reproduce exact original shades in printed matter.Svangen T extile/Vinyl Sports(v)Oak (9280)Nordborg T extile/Leather SportsArena (9G81)Sovereign HideSoft Leather SportsLinen White (977L)OFF BLACKLeather-faced SportsOff Black (9A70)Svangen T extile/Vinyl Sports(vi)Off Black (9270)Nordborg T extile/Leather SportsOff Black (9G70)Sovereign HideSoft Leather SportsLinen White (978L)Sovereign HideSoft Leather SportsOff Black (9770)INTERIOR INLAYSWalnut WoodMesh Aluminium Grid AluminiumManganiteLeather-faced SportsOak (9A80)Leather-faced SportsArena (9A81)H NKM JDAGC OE/FW I T H A W I D E R A N G E O F E X T E R I O R C O L O U R S Y O U R V O L V O S 60 C A N R E F L E C T Y O U R P E R S O N A L T A S T E .10NB It is not possible to reproduce exact original shades in printed matter. Please ask your Volvo dealer to show you samples.THE VOLVOS60019 Black Stone 465 Cedar Green pearl 466 Barents Blue pearl 426 Silver metallic 452 Black Sapphire metallic 455 Titanium Grey pearl463 Blackcurrant pearl 479 Orinoco Blue pearl612 Passion Red613 Deep Blue467 Magic Blue pearl 614 Ice White469 Lunar Gold pearl471 Willow Green pearl477 Inscription™ Electric Silver Coarse Flake metallic478 Maple Red pearlSTARTING OFF ON THE RIGHT FOOT You might be surprised how easy and flexible financing can be. Our range of finance, service and insurance options allows you to budget around one key factor – your lifestyle.FINANCE/LEASEAs part of Volvo, Volvo Car Finance has developed a series of funding plans that will provide you withmaximum choice and flexibility when acquiring a Volvo.INSURANCEVolvo Owners Insurance is designed for Volvo drivers and because we know Volvos inside out, we can offer exactly the right tools and expertise, fitting only genuine Volvo parts by trained Volvo technicians. BecauseVolvo drivers have an excellent reputation, we can also offer extensive cover at a reasonable price.Call now for your insurance quote on 0800 238 239(i),quoting reference BROCH.MAKING LIFE EASIEROwning a Volvo should be a safe and enjoyable experience. To ensure it stays that way, we’re committed to providing you with the best in support for as long as you own one.SERVICE PROGRAMMEYour Volvo dealer has the unique know-how to tailor a service programme according to Volvo’s strict recommendations and guarantees you years of safety and driving pleasure.VOLVO ON CALLSubscribe to Volvo On Call and you’ll never be completely on your own. It's a GPS-basedcommunication system providing 24-hour access to both emergency and roadside assistance wherever you are. See the Volvo On Call brochure for more information.LOOKING AHEADYou’ll probably never find out just how good some of these services are. But should the unexpected happen, we’d like to think that you’d be even happier you chose a Volvo.ROADSIDE ASSISTANCEEvery new car comes with one year’s Volvo Assistance cover. You’ll enjoy free breakdown and recoveryassistance, anywhere in Europe, 24 hours a day. You can even extend cover for £85 for one year or £155for two years.Call Volvo Assistance on ***********.WARRANTYEvery new Volvo comes with comprehensiveprotection. Our warranty covers the first three years or 60,000 miles, whichever comes first. There’s a three year unlimited mileage warranty on thepaintwork, and either eight or twelve years against rust perforation. If a component fails due to a defect or material fault, your dealer will swiftly rectify theproblem, free of charge.THE END IS JUST THE BEGINNINGIt’s a simple idea; one point of contact for all your car ownership needs – whether it’s about finding the right finance deal or who to contact in an emergency. To get the most out of owning your Volvo, trust Care by Volvo.All ‘On The Road’ prices quoted in this price list include Volvo standard national delivery charge, inclusive of number plates at £480 and the VED (Vehicle Excise Duty) car tax effective from 1st March 2000. The ‘On The Road’ price also includes a £38 vehicle first registration fee (as set by the government), effective since 1st April 1998 (excludes Channel Islands and Isle of Man). Retail prices quoted do not include these additions.WHAT NEXT?If you’d like to find out more about the range of products and services that make up Care by Volvo, the story continues at Alternatively you can contact your nearest Volvo dealer or request relevant brochures.(i) Volvo Owners Insurance is underwritten by Royal & Sun Alliance Insurance plc No. 93792. Registered in England and Wales at St Mark’s Court, Chart Way, Horsham, West Sussex RH12 1XL. Authorised and regulated by the Financial Services Authority. For your protection telephone calls will be recorded and may be monitored.NB Some of the information in this brochure may not be correct due to product changes which may have occurred since it was printed. Before ordering, please ask your Volvo dealer for the latest information. The manufacturer reserves the right to make changes at any time, without notice, to prices, colour, materials, specifications and models.For tax free sales, including Military, Diplomat and all other Export enquiries, contact Volvo Car UK Tourist & Diplomat Sales or Volvo Car UK British Military Sales on 01707 262 388or e-mail to **************************@11THE VOLVOS6012DESIGNEDBYVOLVO.INSCRIBEDBYYOU.Volvo Inscription™ opens up awhole new colourful world of interiorsophistication for you to discover.Choose from a collection of exquisite,specially designed interiors available ina kaleidoscope of colours and put yourown personal signature on your Volvo.Once you’ve colour co-ordinated thefinest Scottish hide leather upholstery,carpets, steering wheel, panel trimsand matching textile mats, you’ll havecreated an in-car experience yoursenses won’t let you forget.To help you decide, our Design Teamhave suggested the best possiblecolour combinations for interior andexterior shown in the Designer’sRecommendations section.Inscription™. Designed by Volvo,inscribed by you.UPHOLSTERY AND INTERIOR COLOURSRoyal Blue/Off Black Inscription™ SoftLeather with Royal Blue stitching. Off Blackinterior with Granite headliner and Off BlackLuxury Floor Mats with Royal Blue piping.DESIGNER'S RECOMMENDATIONSINLAYSBlack Mesh aluminium trimEXTERIOR COLOURS019Black Stone426Silver metallic455Titanium Grey pearl466Barents Blue pearl477Inscription™ Electric Silver CoarseFlate Metallic614Ice WhiteUPHOLSTERY AND INTERIOR COLOURSLinen White Inscription™ Soft Leather withLinen White stitching. Oak interior with Arenaheadliner and Oak Luxury Floor Mats withLinen White piping.DESIGNER’S RECOMMENDATIONSINLAYSMesh aluminium trimEXTERIOR COLOURS019Black Stone454Ruby Red pearl463Blackcurrant pearl469Lunar Gold pearl471Willow Green pearl477Inscription™ Electric Silver CoarseFlate Metallic478Maple Red pearl479Orinocco Blue Pearl614Ice WhiteUPHOLSTERY AND INTERIOR COLOURSToscana Tan Inscription™ Soft Leather withToscana Tan stitching. Off Black interior withGranite headliner and Off Black Luxury FloorMats with Toscana Tan piping.DESIGNER’S RECOMMENDATIONSINLAYSBlack Mesh aluminium trimEXTERIOR COLOURS019Black Stone426Silver metallic452Black Sapphire metallic455Titanium Grey pearl477Inscription™ Electric Silver CoarseFlate MetallicUPHOLSTERY AND INTERIOR COLOURSOff Black Inscription™ Soft Leather with OffBlack stitching. Off Black interior with Graniteheadliner and Off Black Luxury Floor Matswith Off Black piping.DESIGNER’S RECOMMENDATIONSINLAYSBlack Mesh Aluminium TrimEXTERIOR COLOURS019Black Stone426Silver metallic452Black Sapphire metallic454Ruby Red pearl455Titanium Grey pearl463Blackcurrant pearl471Willow Green pearl477Inscription™ Electric Silver CoarseFlate Metallic478Maple Red pearl479Orinocco Blue Pearl612Passion RedUPHOLSTERY AND INTERIOR COLOURSVermillion Red/Off Black Inscription™ SoftLeather with Vermillion Red stitching. OffBlack interior with Granite headliner andOff Black Luxury Floor Mats with VermillionRed piping.DESIGNER'S RECOMMENDATIONSINLAYSBlack Mesh aluminium trimEXTERIOR COLOURS019Black Stone426Silver metallic452Black Sapphire metallic455Titanium Grey pearl477Inscription™ Electric Silver CoarseFlate MetallicDH7FDH8L DH7JDH7GDH7HUPHOLSTERY AND INTERIOR COLOURS Fawn Sand/Off Black Inscription™ SoftLeather with Fawn Sand stitching. Off Black interior with Granite headliner and Off Black Luxury Floor Mats with Fawn Sand piping.DESIGNER’S RECOMMENDATIONS INLAYSBlack Mesh aluminium trimEXTERIOR COLOURS 019Black Stone 426Silver metallic452Black Sapphire metallic 455Titanium Grey pearl 469Lunar Gold pearl477Inscription™ Electric Silver CoarseFlate MetallicUPHOLSTERY AND INTERIOR COLOURS Linen White Inscription™ Soft Leather with Linen White stitching. Off Black interior with Arena headliner and Off Black Luxury Floor Mats with Linen White piping.DESIGNER’S RECOMMENDATIONS INLAYSMesh aluminium trimEXTERIOR COLOURS 019Black Stone 454Ruby Red pearl 463Blackcurrant pearl 469Lunar Gold pearl 471Willow Green pearl477Inscription™ Electric Silver CoarseFlate Metallic 478Maple Red Pearl 479Orinocco Blue pearl 614Ice WhitePlease note: Some of the information in this brochure may be incorrect due to product changes which may have occurred since printing. Before ordering, please ask your Volvo dealer for the latest information. The manufacturer reserves the right to make changes at any time without notice, to prices, colours, materials, specifications and models. Please see the Inscription™brochure for further information.Black Mesh aluminium trim Inscription™ Luxury Floor Mats with Nubuck PipingRibbed Upholstery InsertsWalnut wood trimMesh aluminium trimDH7DDH7KDH7LInscription™ Sports steering wheel UPHOLSTERY AND INTERIOR COLOURS Linen White/Off Black Inscription™ SoftLeather with Linen White stitching. Off Black interior with Arena headliner and Off Black Luxury Floor Mats with Linen White piping.DESIGNER’S RECOMMENDATIONS INLAYSBlack Mesh aluminium trimEXTERIOR COLOURS 019Black Stone 426Silver metallic452Black Sapphire metallic 454Ruby Red pearl 455Titanium Grey pearl 463Blackcurrant pearl 469Lunar Gold pearl 471Willow Green pearl477Inscription™ Electric Silver CoarseFlate Metallic 612Passion Red 614Ice WhiteTHE VOLVOS6013I N S C R I P T I D E S I G N E D B Y V O L V O . I N S C R I B E D B Y Y O U .A03931。
2007年沃尔沃xc90说明书
2007年沃尔沃xc90说明书2007年沃尔沃XC90说明书引言：2007年沃尔沃XC90是一款豪华SUV，以其卓越的性能和安全性而闻名。
本文将为您介绍该车型的主要特点和功能，以及一些重要的维护和保养事项。
第一部分：车辆概述2007年沃尔沃XC90是一款七座豪华SUV，采用了现代化的设计和先进的技术。
它的外观造型时尚大气，内饰豪华舒适。
XC90配备了强大的发动机和先进的悬挂系统，为驾驶者提供卓越的驾驶体验。
第二部分：安全性能沃尔沃一直以来都注重车辆的安全性能，2007年的XC90也不例外。
该车型配备了多项安全功能，包括稳定性控制系统、制动辅助系统和侧面碰撞保护系统等。
此外，XC90还配备了多个安全气囊，以确保乘客在碰撞事故中得到最大程度的保护。
第三部分：驾驶性能2007年的XC90提供了多种动力选择，包括汽油和柴油发动机。
这些发动机都具有出色的动力输出和燃油经济性。
XC90还配备了先进的四驱系统，以确保在各种路况下都能提供稳定的驾驶性能。
第四部分：内部空间和舒适性XC90提供了宽敞的内部空间，为乘客提供了舒适的乘坐体验。
座椅采用高品质材料制成，提供了良好的支撑和舒适度。
此外，XC90还配备了先进的空调系统和音响系统，以提供更加愉悦的驾乘体验。
第五部分：维护和保养为了确保车辆的正常运行和延长使用寿命，定期的维护和保养是必不可少的。
根据2007年沃尔沃XC90的说明书，建议按照规定的里程和时间间隔进行保养，包括更换机油、检查刹车系统和轮胎磨损等。
此外，定期清洁和保养车辆的外部和内部也是非常重要的。
结论：2007年沃尔沃XC90是一款卓越的豪华SUV，具有出色的性能和安全性能。
它的外观时尚大气，内部空间宽敞舒适。
无论是驾驶性能还是乘坐舒适度，XC90都能满足您的需求。
同时，定期的维护和保养将确保车辆的正常运行和延长使用寿命。
如果您是一位追求品质和安全的车主，2007年沃尔沃XC90将是您的理想选择。
沃尔沃说明书
沃尔沃物流信息服务平台软件需求规格说明书变更记录目录1概述 ............................................................................. ....................................................................... 4 1.1 1.21.3 22.1编写目的 ............................................................................. ...................................................... 4 系统目标 ............................................................................. ...................................................... 4 术语定义 ............................................................................. ...................................................... 7 物流信息服务平台 ............................................................................. .. (9)首页 ............................................................................. ...................................................... 9 物流需求发布 ............................................................................. .................................... 10 物流解决方案 ............................................................................. .................................... 10 物流企业园区 ............................................................................. .................................... 11 物流联盟论坛 ............................................................................. .................................... 12 物流效率测算 ............................................................................. .................................... 12 新闻维护 ............................................................................. ............................................ 14 物流项目发布 ............................................................................. .................................... 14 论坛维护 ............................................................................. ............................................ 15 物流运营数据分析系统维护 ............................................................................. ............ 16 数据字典 ............................................................................. ............................................ 17 网站用户管理 ............................................................................. .................................... 17 平台系统管理 ............................................................................. (21)需求说明 ............................................................................. ............................................................... 9 2.1.1 2.1.22.1.3 2.1.4 2.1.5 2.1.6 2.2 2.2.1 2.2.2 2.2.3 2.2.4 2.2.5 2.2.6 2.2.7物流信息服务平台管理系统 ............................................................................. .. (14)3 4 5 6性能要求 ............................................................................. ............................................................. 23 可维护性, 可扩展性 ............................................................................. .......................................... 24 安全性 ............................................................................. ................................................................. 25 设计约束 ............................................................................. ............................................................. 26 6.1.1 6.1.2 语言约束 ............................................................................. ............................................ 26 系统模型约束 ............................................................................. (26)7 8 9界面要求 ............................................................................. ............................................................. 27 验收标准 ............................................................................. ............................................................. 29 附件 ............................................................................. (30)1 概述1.1 编写目的本文档是北京软通动力科技有限公司（以下简称软通）在沃尔沃（中国）投资有限公司（以下简称沃尔沃）的物流信息服务平台合同基础上编制的。
沃尔沃汽车使用手册说明书
RACE Newsletter09/04/2018CAR:NEW : FLASH_0675 VOLVO BOSCH EDC17CP22/CP48/CP68 CANATTENTION!In order to run the writing procedure with the serial protocol flash_0675 it is necessary to perform first the PATCH UNLOCK with the New Trasdata - plugin 158 / 681 / 743.Please check the specific manual.VOLVO C30 Mk2/C70/S40/V50 Mk2/V40 Mk2-3 2.0L 16V D3 110kW EDC17CP22/CP48VOLVO C30 Mk2/V60 2.4L 20V D5 132kW EDC17CP22/CP48VOLVO C70/ S60 Mk2/V60/XC60 2.0L 20V D3 120kW EDC17CP22/CP48VOLVO S60 Mk2/XC70 Mk3/S80Mk3/V60/V70 Mk3/XC60/XC70 Mk3 2.4L 20V D5 158kW EDC17CP22/CP48VOLVO S80 Mk2/V70 Mk3/XC60 2.4L 20V D5 151kW EDC17CP22VOLVO V50 Mk2 2.0L 20V D5 130kW EDC17CP22VOLVO V70 Mk3 2.4L 20V D5 130kW EDC17CP22VOLVO X C60 2.4L 20V D4 120-129kW EDC17CP22VOLVO X C70 Mk3/XC60/ XC70 Mk3/XC90/V60 2.4L 20V D5 120kW EDC17CP22/CP48/CP68VOLVO S60 Mk2/V60/V70 Mk3 2.0L 20V D3 100kW EDC17CP48VOLVO S80 Mk3/V60/V70 Mk3/XC70 Mk3 2.0L 16V D4 120kW EDC17CP48VOLVO S80 Mk3 2.4L 20V D4 120kW EDC17CP48VOLVO V40 Mk3 2.0L 16V D4 130kW EDC17CP48VOLVO V60 2.4L 20V D6 HYBRID 158kW EDC17CP48 VOLVO X C60 2.0L 20V D5 100kW EDC17CP48VOLVO X C60/XC70 Mk3 2.4L 20V D4 133kW EDC17CP48VOLVO X C60 2.4L 20V D4 140kW EDC17CP68VOLVO X C70 Mk3 2.4L 20V D5 133kW EDC17CP68VOLVO X C70 Mk3 2.4L 20V D5 162kW EDC17CP68NEW : FLASH_0676 MERCEDES DELPHI CRD3.E/P CANATTENTION!In order to run the writing procedure with the serial protocol flash_0676 it is necessary to perform first the PATCH UNLOCK with the New Trasdata - plugin 935.Please check the specific manual.MERCEDES A CLASS W176 A200 2.2L 16V CDI 100kW CRD3.E/PMERCEDES A CLASS W176 A220 2.2L 16V CDI 130kW CRD3.E/PMERCEDES B CLASS W246 B200 2.2L 16V CDI 100kW CRD3.E/PMERCEDES C CLASS W205 C220 2.2L 16V CDI 100-120-125kW CRD3.E/PMERCEDES C CLASS W205 C250 2.2L 16V CDI 152kW CRD3.E/PMERCEDES CLA CLASS C117 CLA200 2.2L 16V CDI 100kW CRD3.E/PMERCEDES CLA CLASS C117 CLA220 2.2L 16V CDI 130kW CRD3.E/PMERCEDES GLA CLASS X156 GLA200 2.2L 16V CDI 100kW CRD3.E/PMERCEDES GLA CLASS X156 GLA220 2.2L 16V CDI 130kW CRD3.E/PMERCEDES SPRINTER W906 316-516 2.2L CDI 105-120kW CRD3.E/PTRUCK:NEW: FLASH_0677 CUMMINS – TEREX ATLAS TRUCK CM570 CANTEREX TRUCKS TA300 10.8L QSM 276kW CM570TRACTOR:NEW: FLASH_0674 CUMMINS – TIGERCAT TRACTOR CM2250 CANTIGERCAT FELLER BUNCHERS 724E 6.7L QSB 164kW CM2250SW : 3.0.186 DLL : 1.0.197 FW: 12.09 build 0002 MOTOROLA MPC500 CPUs:ADD : 01 - MOTOROLA MPC500BOSCH EDC7C1 MPC555/MPC556 INTERNATIONAL DieselNEW - plugin 1037 – INTERNATIONAL BUS 3100 4.8L 110kW EDC7C1 STMICROELECTRONICS CPUs:ADD : 02 - STMICROELECTRONICS ST10BOSCH DCU15 ST10C167 DAF AdBlue DCUNEW - plugin 1032 – FENDT 300 VARIO 313 4.4L 99kWINFINEON TRICORE CPUs:ADD : 03 - INFINEON TRICORE NO PSW CANLINEBOSCH REXROTH SRC 9-34 TC1796 AGCO GEARBOX CVTNEW – plugin 951 – AGCO GEARBOX CVTBOSCH ME17.9.71 TC1724 PSA PetrolNEW – plugin 1035 – PEUGEOT 206 1.6L 16V 82kW ME17.9.71BOSCH ME17.2.4/BMS-MP TC1791/TC1793 BMW MOTORRAD PetrolNEW – plugin 1057 – BMW MOTORRAD S SERIES S 1000 R my2017 1.0L 121kW ME17.2.4BMW MOTORRAD S SERIES S 1000 RR my2017 1.0L 146kW ME17.2.4BMW MOTORRAD S SERIES S 1000 XR my2017 1.0L 121kW ME17.2.4BMW MOTORRAD F SERIES F 800 R/GT my2017 1.0L 66kW ME17.2.4BMW MOTORRAD R SERIES R 1200 GS my2017 1.0L 92kW ME17.2.4BOSCH MEVD17.8.4 TC1797 BMW PetrolNEW – plugin 1065 – BMW 3 SERIES F30/F31/F35 320i 2.0L L4 16V TURBO 135kW MEVD17.8.4BMW 5 SERIES F10/F11/F18 520i 2.0L L4 16V TURBO 135kW MEVD17.8.4BMW 5 SERIES F10/F11/F18 525i 2.0L L4 16V TURBO 160kW MEVD17.8.4ADD : 04 - INFINEON TRICORE BOSCH MEDC17 TPROT2/4/7BOSCH MED17.0.7 TC1782 FORD PetrolNEW – plugin 1064 – FORD FIESTA 7 1.0L 12V Ecoboost 74kW MED17.0.7ADD: 23 - INFINEON TRICORE BOSCH MEDC17 GPT VAGBOSCH ME17.5.22 TC1724 VAG PetrolNEW – plugin 1039 – VOLKSWAGEN GOLF 7 1.6L 8V MPI 81kW ME17.5.22VOLKSWAGEN GRAN LAVIDA 1.6L 8V MPI 81kW ME17.5.22VOLKSWAGEN POLO 5 (6R, 6C) 1.6L 8V MPI 81kW ME17.5.22VOLKSWAGEN TOURAN 1.6L 8V MPI 81kW ME17.5.22SKODA OCTAVIA (5E) 1.6L 8V MPI 81kW ME17.5.22ADD: 28 - INFINEON TRICORE BOSCH MEDC17 GPT FORDBOSCH EDC17CP05 TC1797 FORD DieselNEW – plugin 1042 – FORD F250 6.7L V8 32V TD SUPERDUTY 287kW EDC17CP05FORD F350 6.7L V8 32V TD SUPERDUTY 224kW EDC17CP05FORD F250/F350 6.7L V8 32V TD SUPERDUTY 298kW EDC17CP05FORD F250/F350 6.7L V8 32V TD SUPERDUTY 328kW EDC17CP05Important: F34NTA15 flat cable is required to operate in GPT modeNEW: 61 - INFINEON TRICORE BOSCH EDC17 TPROT13 VM MOTORIBOSCH EDC17C49 TC1797 AEBI-SCHMIDT DieselNEW – plugin 1070 – AEBI-SCHMIDT MT750 4.5L V6 115kW EDC17C49ADD: 46 - INFINEON TRICORE CONTINENTAL ACM_MCM MEB TRUCK CAN LINETEMIC ACM2.1/AT25256 TC1796 ACM MERCEDES TRUCKNEW – plugin 1029 – ACM MERCEDES TRUCKWARNING: in order to communicate with this ECU ACM2.1/AT25256 using the plugin 1029 it is required the new cable F34NTA20F34NTA20ADD: 46 - INFINEON TRICORE CONTINENTAL ACM_MCM MEB TRUCK CAN LINECONTINENTAL-SIEMENS-VDO HDEP MCM2.1 TC1797 MERCEDES TRUCK E6 DieselNEW – plugin 1030 – MERCEDES TRUCK EURO6PONSEE FORWARDERS EURO6CLAAS JAGUAR EURO6FENDT KATANA 65 EURO6WARNING: in order to communicate with this ECU HDEP MCM2.1 using the plugin 1030 it is required the new cable F34NTA19F34NTA19ADD: 50 - INFINEON TRICORE SIEMENS SSM VAGCONTINENTAL-SIEMENS-VDO Simos18.X TC1791_384/TC1793_384 VAG PetrolNEW – plugin 830 –AUDI A1 (8X) 1.8L 16V TFSI 141kW SIMOS18.XAUDI A3 (8V) 1.8L 16V TFSI 132kW SIMOS18.XAUDI A3 (8V) 2.0L 16V TFSI 162kW SIMOS18.XAUDI A4 (B8-B9) 2.0L 16V TFSI 132-140-165-185kW SIMOS18.XAUDI A5 (8F/8T) 2.0L 16V TFSI 165kW SIMOS18.XAUDI A6 (C7) 1.8L 16V TFSI 140kW SIMOS18.XAUDI A6 (C7) 2.0L 16V TFSI 183-185kW SIMOS18.XAUDI A7 (4G) 1.8L 16V TFSI 140kW SIMOS18.XAUDI A7 (4G) 2.0L 16V TFSI 140-162-183-185kW SIMOS18.XAUDI Q3 (8U) 2.0L 16V TFSI 132-162kW SIMOS18.XAUDI Q5 (8RB) 2.0L 16V TFSI 132-162kW SIMOS18.XAUDI Q7 (4M) 2.0L 16V TFSI 185kW SIMOS18.XAUDI S1 (8X) 2.0L 16V TFSI 170kW SIMOS18.XAUDI S3 (8V) 2.0L 16V TFSI 205-210-220kW SIMOS18.XAUDI TT (FV) 1.8L 16V TFSI 132kW SIMOS18.XAUDI TT (FV) 2.0L 16V TFSI 161-169-210-228kW SIMOS18.XSEAT LEON (5F) 1.8L 16V TSI-TFSI 132kW SIMOS18.XSEAT LEON (5F) 2.0L 16V TSI CUPRA 195kW SIMOS18.XSKODA OCTAVIA (5E) 1.8L 16V TSI-TFSI 132kW SIMOS18.XSKODA OCTAVIA (5E) 2.0L 16V TSI RS-GTI 162-169kW SIMOS18.XSKODA SUPERB (3V) 1.8L 16V TSI-TFSI 132kW SIMOS18.XVOLKSWAGEN EOS (1F8) 2.0L 16V TFSI 162kW SIMOS18.XVOLKSWAGEN BEETLE (A5)/JETTA 6-7 1.8L 16V TFSI 125kW SIMOS18.XVOLKSWAGEN BEETLE (A5)/JETTA 6 2.0L 16V TFSI 154-155-162kW SIMOS18.XVOLKSWAGEN GOLF 7 1.8L 16V TFSI 132kW SIMOS18.XVOLKSWAGEN GOLF 7 2.0L 16V TFSI 162-205kW SIMOS18.XVOLKSWAGEN GOLF 7 2.0L 16V GTI 155-162-169-194kW SIMOS18.XVOLKSWAGEN GOLF 7 2.0L 16V R 213-220kW SIMOS18.XVOLKSWAGEN LAMANDO 1.8L 16V TSI 132kW SIMOS18.XVOLKSWAGEN LAMANDO 2.0L 16V TFSI 161kW SIMOS18.XVOLKSWAGEN PASSAT (B7-B8-B9) 1.8L 16V TFSI 125-132kW SIMOS18.XVOLKSWAGEN PASSAT (B8-B9) 2.0L 16V TFSI 162kW SIMOS18.XVOLKSWAGEN POLO (6C) 1.8L 16V TSI-GTI 141kW SIMOS18.XVOLKSWAGEN SCIROCCO 3 2.0L 16V TFSI-GTS-WRC 132-162kW SIMOS18.XVOLKSWAGEN TOURAN 1.8L 16V TSI 132kW SIMOS18.XPORSCHE MACAN (95B) 2.0L 16V TFSI 185kW SIMOS18.XCONTINENTAL-SIEMENS-VDO Simos12.X TC1797 VAG PetrolNEW – plugin 1067 –AUDI A3 (8V-8P) 1.8L 16V FSI-TFSI 162kW SIMOS12.XAUDI A4 (B8) 1.8L 16V TFSI 125kW SIMOS12.XAUDI A4 (B8) 2.0L 16V TFSI 165kW SIMOS12.XAUDI A5 (8F/8T) 1.8L 16V TFSI 106-125-130kW SIMOS12.XAUDI A5 (8F/8T) 2.0L 16V TFSI 165-169kW SIMOS12.XAUDI A7 (4G) 2.0L 16V TFSI 165kW SIMOS12.XAUDI Q5 (8RB) 2.0L 16V TFSI 132-165-169kW SIMOS12.XAUDI S3 (8P) 2.0L 16V TFSI 205-210-220kW SIMOS12.XAUDI TT (8J) 1.8L 16V FSI 162kW SIMOS12.XAUDI TT (FV) 1.8L 16V TSI 162kW SIMOS12.XAUDI TT (8J) 2.0L 16V TFSI 210-228kW SIMOS12.XImportant: F34NTA18 flat cable is required to operate in SSM modeMOTOROLA MPC55XX CPUs:ADD : 06 - MOTOROLA MPC55XX JTAGCONTINENTAL-SIEMENS-VDO CM2250 MPC5566 PETERBILT DieselNEW – plugin 1028 – PETERBILT 386 15.0L ISX15 298kW CM2250ADD : 43 - MOTOROLA MPC55XX BAMCONTINENTAL-SIEMENS-VDO MPC5534 ACM VOLVONEW – plugin 1041 – VOLVO WHEEL LOADERS ACMRENESAS SH7050 CPUs:ADD : 07 - RENESAS SH7050DELPHI DCM3.7AP SH72543R CASE/DOOSAN/NEW HOLLAND DieselNEW - plugin 1034 – CASE FARMALL 55 C CVT 2.2L 39.5kW DCM3.7APMITSUBISHI MH7XXX/MH8XXX CPUs:ADD : 08 – MITSUBISHI MH7XXX/8XXXMITSUBISHI F8T86571 MH8115F YAMAHA PetrolNEW – plugin 1033 – YAMAHA ATV WOLVERINE X4 0.85L 50kW F8T86571MITSUBISHI E6T32xxx MH8102F MITSUBISHI PetrolNEW – plugin 1038 – MITSUBISHI PAJERO V60 3.5L V6 24V 150kW E6T32xxxMITSUBISHI 33920-98J80 MH8115F SUZUKI PetrolNEW – plugin 1040 – SUZUKI MARINE DF 300 3.6L V6 220kW 33920-98J80NEC CPUs:ADD : 36 - NEC NBDDENSO 270536-6941 NEC 76F0040GD TOYOTA PetrolNEW - plugin 1031 – TOYOTA RAV4 (A2) 2.0L 16V 4L 110kW 270536-6941DENSO 275036-7581 NEC 76F0085 TOYOTA PetrolNEW - plugin 1068 – TOYOTA HILUX/VIGO (AN120-AN130) 2.7L 16V L4 VVT-i DOHC FLEX 120kW 275036-7581 FREESCALE ST MPC56XX SPC56X CPUs:ADD : 37 – FREESCALE ST MPC56XX SPC56XCONTINENTAL-SIEMENS-VDO CM2350 MPC5674F GENERIC CUMMINS ENGINE DieselNEW – plugin 638 – GENERIC CUMMINS ENGINE CM2350AGENERIC CUMMINS ENGINE CM2350BDelphi DCM6.2AP MPC5674F HYUNDAI DieselNEW – plugin 1024 – HYUNDAI i20 Mk2 1.1L 12V CRDi 55kW DCM6.2APKIA RIO/K2 (YB) 1.1L 12V CRDi 55kW DCM6.2APADD : 44 – FREESCALE MPC56XX BAMDelphi DCM6.2AP MPC5674F HYUNDAI DieselNEW - plugin 1063 – HYUNDAI i20 Mk2 1.1L CRDi 55kW DCK6.2APKIA RIO/K2 (YB) 1.1L 12V CRDi 55kW DCM6.2APNEW PLUG-IN LISTPLGID ECU Brand ECU Model Brand Connection Type Micro Flash Ext Category638 Continental-Siemens-VDO CM2350Generic CumminsEngine37 - FREESCALE/STMPC56XX/SPC56X JTAG MPC5674F TRUCK830 Continental SIMOS18.x VAG 50 - INFINEON TRICORE SIEMENSSSM VAG TC1791_384/TC1793_384 CAR951 BOSCH REXROTH SRC 9-34 GEARBOXCVT AGCO03 - INFINEON TRICORE NO PSWCANLINE TC1796 M58BW032FB TRACTOR1024 Delphi DCM6.2AP Hyundai 37 - FREESCALE/STMPC56XX/SPC56X JTAG MPC5674F CAR1028 Continental-Siemens-VDO CM2250 Peterbilt 06 - MOTOROLA MPC5500 JTAG MPC5566 TRUCK1029 Temic ACM2.1/AT25256 MEB Truck 46 - INFINEON TRICORE TEMIC MCMACM MERCEDES OBD TC1796 TRUCK1030 Continental-Siemens-VDO HDEP MCM2.1 MEB Truck46 - INFINEON TRICORE TEMIC MCMACM MERCEDES OBD TC1797 TRUCK1031 Denso 275036-6941 Toyota 36 - NEC NBD 76F0040GD CAR 1032 Bosch DCU15 DAF 02 - STMICROELECTRONICS ST10 ST10C167 AM29F400BT TRUCK 1033 Mitsubishi F8T86571 Yamaha 08 - MITSUBISHI MH7XXX/MH8XXX MH8115F BIKE1034 Delphi DCM3.7AP Case/Doosan/NewHolland 07 - RENESAS SH7050 SH72543RTRUCKTRACTOR1035 Bosch ME17.9.71 PSA 03 - INFINEON TRICORE NO PSWCANLINE TC1724 CAR1037 Bosch EDC7C1 International 01 - MOTOROLA MPC500 MPC555/MPC556 TRUCK 1038 Mitsubishi E6T32xxx Mitsubishi 08 - MITSUBISHI MH7XXX/MH8XXX MH8102F CAR1039 Bosch ME17.5.22 VAG 23 - INFINEON TRICORE BOSCHMEDC17 GPT VAG TC1724 CAR1040 Mitsubishi 33920-98J80 Suzuki 08 - MITSUBISHI MH7XXX/MH8XXX MH8102F MARINE1041 Continental-Siemens-VDO ACM Volvo 43 - MOTOROLA MPC55XX BAM MPC5534 TRUCK1042 Bosch EDC17CP05 Ford 28 - INFINEON TRICORE BOSCHMEDC17 GPT FORD TC1797 CAR1057 BOSCH ME17.2.4/BMS-MP BMW 03 - INFINEON TRICORE NO PSWCANLINE TC1791/TC1793 BIKE1063 Delphi DCM6.2AP Hyundai 44 - FREESCALE MPC56XX BAM MPC5674F CAR1064 Bosch MED17.0.7 Ford 04 - INFINEON TRICORE BOSCHMEDC17 TPROT2/4/7 TC1782 CAR1065 Bosch MEVD17.8.4 BMW 03 - INFINEON TRICORE NO PSWCANLINE TC1797 CAR1067 Continental SIMOS12.x VAG 50 - INFINEON TRICORE SIEMENSSSM VAG TC1797 CAR1068 Denso 275036-7581 Toyota 36 - NEC NBD 76F0085 CAR1070 BOSCH EDC17C49 AEBI SCMIDT 61 – INFINEON TRICORE BOSCHEDC17 TPROT13 VM MOTORI TC1797 TRUCKDIMSPORT S.r.l.。
沃尔沃柴油发电机组说明书
All specifications and design are subject to change without noticeOverall Dimensions & Weights - Open SetLength (L) = 3420mm [132in]Width (W) = 1140mm [45in]Height (H) = 2020mm [80in]Dry Weight (inc oil) = 3657kg [8101lb]Operating Weight = 4241kg [9349lb]989492904000 Hz 8000 Hz 10593101Typical Open Generator Sound Pressure Level at 1m, Free Field (dB)125 Hz 400Key Features:● Water cooled Volvo diesel engine with ECU/CANBus ● Single bearing CGT Stamford alternator ● Radiator with pressure cap and drain point ● Fully guarded engine-driven fan● Fully welded steel skid base with lifting points ● Integral fuel tank with filler cap and gauge ● Heavy duty rubber anti-vibration mountings ● 24V starter batteries and connecting cables● Separate engine-driven battery charging alternator● Spin on oil and fuel filters and dry type air filter element ● Industrial silencer (15dBA reduction) supplied loose ● Auto Start control system with digital instrumentation ● Main line circuit breaker ● Factory Test Certificate● Operation & Maintenance Manual● Wide range of optional extra features available440/254416/2405753206081054400350220/1274001002000 Hz 10063 Hz Overall dBA400320438350250 Hz 500 Hz 1000 Hz Definition of Ratings & Reference ConditionsPrime Power (PRP) is the nominal output continuously available, where the average load (variable) does not exceed 70% of the prime power rating. 10% overload is available for a maximum of 1 hour in 12 hours of operation.Standby Power (LTP ) is the maximum output available, for up to 500 hours per year, where the average load does not exceed 70% of the standby power rating. No overload is available.Standard Reference Conditions: air inlet temperature 25°C (77°F), barometric pressure 100kPa, [110m (361ft) altitude], 30% relative humidity.Note: The above ratings may be subject to derate at different operating conditions. Please see the Derate Guidelines on the Broadcrown website.All power ratings and reference conditions in accordance with ISO 8528-1 and ISO 3046-1.1149240/138320438350527320438Technical DataMay 2013Generator Model: VolvoTAD 1352GE CGT Stamford HCI 444BCV 350-60 T3/FVoltage 480/277400kWe kVA Amps 43835060 HzEmissionsEPA Tier III Flex CompliantPower FactorCos Φ = 0.83-Phase350320kWe kVA 438RatingsPrime Power (PRP)Standby Power (LTP)HL WSI Units[US Units]Engine Speed r/min [rpm]Gross Power kWm [bhp]363487395530Fan Power kWm [bhp]1925.51925.5Net PowerkWm [bhp]344461376504Emissions Certification Altitude Capabilitym[ft.]1000330010003300Cylinders / TypeAspiration / Charge CoolingGoverning / Engine Management Bore / Stroke mm [in.]Cubic Capacity litres [cu.in.]BMEPkPa [psi]18942752061299Fuel Consumption at 100% Power litres/h [gal/h]87.223.096.325.4Fuel Consumption at 75% Power litres/h [gal/h]66.717.672.919.3Fuel Consumption at 50% Power litres/h [gal/h]46.412.349.513.1Total fuel flowlitres/h [gal/h]Standard Fuel Tank Capacitylitres [gal]Engine Air Flowm³/s [cfm]0.4339180.433918Maximum Air Intake Restriction (used filter)kPa [inWG]Exhaust Gas Flowm³/s [cfm] 1.0452214 1.1282391Exhaust Gas Temperature°C [°F]470878535995Maximum Exhaust Back Pressure kPa [inWG]Typical Exhaust Pipe Diameter mm [in.]Radiator Cooling Air Flowm³/s [cfm]Max Restriction to Cooling Air Flow Pa [inWG]Max Radiator Air-On Temperature °C [°F]Maximum Coolant Temperature °C [°F]Coolant Capacity - Engine Only litres [gal]Total Coolant Capacitylitres [gal]Total Oil Capacity incl Filterslitres [gal]Typical Oil Pressure at Rated SpeedkPa [psi]Typical Oil Consumption (>250hrs Operation)litres/h [pt/h]Heat Rejection to Engine Cooling Water kW [btu/min]164933517710075Heat Rejection to Charge CoolerkW [btu/min]834724874952Heat Radiated From Engine (Typical)kW[btu/min]84559512Electrical System Voltage Battery TypeBattery Capacity SAE CCASI Units[US Units]ManufacturerModel (may vary with voltage)Operating Temperature °C[°F]40[104]27[81]Coupling / No. of Bearings Phase / Poles / Winding Type Power Factor ExcitationInsulation System AVR TypeVoltage RegulationAll specifications and design are subject to change without noticeElectronic Governor / ECU / CANBusTurbocharged / Air to Air6 cyl / Inline / 4-stroke Direct / Single Bearing Alternator55131810F u e l A i r71118831205AS 440± 1.0%Self exited StandbyPrimeG e n e r a lEngine & Cooling SystemVolvo TAD 1352GE1800BCV 350-60 T3/F5.16 /6.22773131 / 15812.78P e r f o r m a n c eT3/FMay 2013G e n e r a l D a t a84412StandbyE x h a u s tC o o l i n g T h e r m a l O i lE l e c V 201029.540Class H 3-Phase / 4-Pole / Winding 311445A0.22 (series) 656Cos Φ = 0.8HCI 444 E HCI 444 ECummins Generator Technologies - Stamford240.48PrimeCGT Stamford HCI 4442165.336140911.21162946.710200[ ] [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ [ ] ]] ]] ] ] ] ] ]]]] ]] ] ] ] ] ] ] ]] ] ]]] ] ] ]] [ ] ] [ [ ][ ]][ [ ] [ ][ ] ][ ] [ ][STANDARD CONTROL SYSTEM BC 7310 Digital Auto StartThe standard control system for this model is BC 7310 (photo), based on the DeepSea Electronics DSE7310 Digital Auto Start controller.This provides for the manual and automatic remote start of the generator, togetherwith full CANBus implementation for the control and protection of the engine via theECU. LCD digital display of :▪ Coolant temperature with high temperature alarm and shutdown▪ Oil pressure with low pressure alarm and shutdown▪ Oil temperature, engine operating hours, battery charge volts and amps▪ Volts, with Under/Over Volts protection▪ Amps, with Over Current protection▪ Frequency, kW, kVA, Power FactorAlso featuring :▪ Full RS485 Telemetry implementation▪ Automatic cool-down timer function▪ Emergency Stop button▪ Ample auxiliary inputs/outputs for optional features▪ Optional (shown) - battery charger and door mounted illuminated switch.CONTROL SYSTEM OPTIONSThe BC 7320 control system (just the DSE7320 module is shown here) has an identical featureset to the BC 7310 but with the addition of full AMF functionality with integrated mainsmonitoring.Finally, BC 8610 & BC 8620 control systems provide the same features asBC 7310 & BC 7320 respectively, plus :▪ BC 8610 - Set-to-Set Synchronisation▪ BC 8620 - Single Set-to-Mains Supply Synchronisation withintegrated mains monitoringFor Multi Set-to-Mains synchronisation, each set requires BC 8610 with theaddition of one mains monitoring panel BC 8660 (not illustrated).See the Synchronisation Guidelines for further details.All designs and specifications subject to change without noticeLxWxHdB(A) at 1m [3ft]dB(A) at 7m [23ft]IntegralBunded5200[204]x 1740[68]x2200[86]2400[5291]7868985[260]895[236]OptionalOPTIONAL ACOUSTIC ENCLOSURE Canopy 5[ Indicative weight of canopy additional to open setTypical SPL is a mean level, measured in free field conditions, with no contributory background noise.KEY OPTIONS (Open Set)Dimensions mm [in]Additional Weight kg [lbs]*Typical Sound Pressure Levelat Standby Power Fuel Tank Capacity Litres [US gal]Single Point LiftThe optional acoustic enclosure for this model is Canopy 5R , suitable for operation in harsh outdoor environmments whilst providing excellent security and acoustic performance. The steel canopy is of fully welded construction with a two-pack polyurethane egg-shell finish in RAL9001 white. The baseframe is finished in RAL9005 satin finish black.Acoustically, the canopy is designed to meet the requirements ofEU Legislation 2000/14/EC, achieved by extensive use of rock wool andperforated zintec steel lining, together with efficient management of cooling air. Exhaust noise is minimised by a unique high performance exhaust silencer, mounted within the baseframe.A steel fuel tank with filler, gauge and accessory points, is integrated within the baseframe. Alernatively, a bund with separate fuel tank can be provided where this is required.Other key features include :- Side-opening doors with retainers for good service access - Control panel viewing window - External service access panels- Heavy duty locks on all doors for total security - Weather cap on exhaust discharge- Emergency Stop button relocated to canopy exterior - Lifting and holding down points on baseframe - Optional single roof lifting point.Engine & Cooling :- Oil and coolants drains extended to edge of baseframe - Manual lub oil drain pump - Coolant heater- Medium duty air cleaner - Exhaust manifold guardsFuel System :- Baseframe with integral bund and drop-in fuel tank - Fuel filter/separator- Low fuel level switch (single point)- Fuel level switch (four point)- Manual fuel transfer pump- Pumped/gravity fuel transfer system Alternator :- Anti-condensation heater - Quadrature droop kit - Alternative AVR- Thermistor probes and controlsExhaust System :- Residential silencer - Critical silencer- Flange/connection kitPlease refer to Broadcrown Sales Department for full details of these and other optionsAll designs and specifications subject to change without notice。
Volvo 货车系列产品说明书
Important NotesChassis DimensionsCab Height: +328 mm for CAB-HSLP, -262 mm for CAB-LDAY, -262 mm for CAB-LSLP, +16 mm for CAB-SLP.Front Axle to Back of Cab: +431 mm for CAB-HSLP and CAB-SLP, -69 mm for CAB-LDAY, +425 mm for CAB-LSLP.D-measure includes a front clearance of 50 mm and for rigid trucks also a subframe of 100 mm.Height can vary ± 20 mm for leaf and ± 10 mm for air suspension. All dimensions are for unladen chassis and any tag axles down.Rear overhang used for vehicle weight calculation is the maximum rear overhang (N Max.) for selected wheelbase.Chassis weight includes oil, water, AdBlue, 0 litres fuel and without driver. Kerb weight can vary ± 3%.Turning diameters are theoretically calculated.Legal weights can differ from country to country.For more detailed weight information, including optional equipment weights, ask your Volvo sales contact to enter your specification into the Volvo Weight Information system (WIS).Do NOT use this drawing for bodybuilding. Refer to Volvo BodybuilderChassis Dimensions [mm]WB Wheelbase370039004300A Overall Chassis Length8615 8915 9565 D Center of rear axle to front of body 3135 3335 3735 N Rear Overhang (Min.) 825 825 825 NRear Overhang (Max.)202521252375T Theoretical Wheelbase4385 4585 4985 Y Center of Gravity for Payload (Min.) -285 -271 -245 Y Center of Gravity for Payload (Max.) -285 -271 -245 W Body Length (Min.) 6451 6771 7411 W Body Length (Max.) 6451 6771 7411Chassis Weights [kg]Front Axle 5260 5270 5310 Rear Bogie 4110 4140 4185 Kerb Weight9370 9410 9495 Payload (including body, driver, fuel, etc.) 13630 13590 13505Turning Diameter [mm]Turning Circle Diameter Kerb to Kerb 16400 1710018400Turning Circle Diameter Wall to Wall 17800 18500 19800Plated Weights [kg]PlatedDesignGross Vehicle Weight23000 35000 Gross Combination Weight 42500 60000 Front Axle 6500 9000 Rear Bogie 16500 26000■ Standard Equipment □ Optional EquipmentFor more detailed information about cab and powertrain equipment, please refer to separate specification sheets.For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS).□ TIPP-PRE Tipper preparation ■ UNIFORM Basic uniform vehicleCore components ■ CHH-XXHI Chassis Height (extra extra high) approx. 1158-1189mm(depending on tyre selection)■ RADD-G2 Rear air suspension-high clearance■ FMX-DAY5 Day cab □ FMX-LDA5 Low day cab □ FMX-LSL5 Low sleeper cab □ FMX-SLP5 Sleeper cab■ EU5SCR-M Eu5 SCR Selective Catalytic Reduction ( mandatory ) ■ D13C460 Engine, 13C litre, 460hp, 2300nm □ D13K460 Eu6 13 litre engine 460hp/2300nm/345kW □ D13K540 Eu6 13 litre engine 540hp/2600nm/397kW■ EBR-VEB+ Volvo Engine Brake + (VEB+) ■ AT2612 Volvo I-shift-12 speed automatic transmission (2600nm) □ PT2606 Powertronic 6 speed transmission (2600nm) □ ASO-C Crawler gears □ ASO-ULC Ultra low crawler gears■ RTH2610B Volvo RTH2610B hub reduction rear axles4 planet gears per hubAxle rating: 26,000 kg 115 tonne train weight (Application approved)Packages ■ INFODF Information Platform with Dynafleet Support □ INFOMED Information Platform-Medium □ INFONDF Information Platform with Navigation & Dynafleet Support Chassis ■ FST-PAR3 3 leaf parabolic front springs (stiffer than normal) □ FAL10.0 Front axle load 10 tonnes ■ FAL9.0 Front axle load 9.0 tonnes ■ FSTAB Front stabilizer, normal stiffness ■ RAL26 Rear suspension load rating: 26,000 kg ■ RSTAB3 Heavy duty rear stabiliser bar ■ PSP-FIX Power steering pump with fixed displacement □ PSP-VAR Power steering pump with variable displacement ■ EBS-MED Electronic Brake System (EBS) containsABS, Traction control, Hill start aid Diff lock control, Brake assistWheel brake monitoring, EBS status□ AUXPARK Auxiliary parking brake ■ FST8080 Frame section thickness 8mm □ FIL-EEEF Liner (inner) from end of engine to end of frame ■ FIL-TXEB Liner (inner) - trans x-mem to end of bogie ■ BBOX-L Battery box mounted on LHS chassis rail ■ 2BATT225 2x225 Ah batteries □ BATTAMP Battery amperage indicator (in the DID) ■ MSWI-C Isolation toggle switch LHS of chassis □ MSWI-R Isolation switch on key fob (press door lock twice to isolate) ■ R415A66 RHS 415 litre alloy fuel tank w/o step Min volume 415l Max volume 415l ■ ADB064 AdBlue tank 64 litres ■ FCAP-L Fuel tank cap with lock■ ESH-REAR Horizontal muffler with low rear facing outlet□ EXST-SSP Stainless steel exhaust stack■ TL-LED LED tail lightsRims and Tyres ■ RT-STEEL 10 stud steel disc rims □ SPWT-D Spare rim & tyre equal to drive □ SPWT-F Spare rim & tyre equal to steer □ SWCP-T2 Transport mounted spare wheel □ JACK-20T Jack, 20 tonnes■ TOOL-BAS Basic tools □ TOOLKIT Tool kit complete□ INFLAHOS Tyre inflation hose (18 metres)Powertrain equipment ■ TRAP-HD Heavy Duty Transmission Internals ■ DRM-BE Drive Mode - Balanced Economy □ DRM-E Drive Mode - Economy □ PVT-MAP Preview Topography Information (by a high resolutioncommercial topography map)■ CRUIS-E Extended cruise control (additional fuel saving functions)□ AMSO-AUT Manual gear shift in automatic mode. □ AVO-ENH AMT Vocational option - enhanced □ APF-ENH Enhanced I-shift PTO functions ■ CS43B-O Volvo 430mm single plate clutch □ TC-HWO Transmission Oil Cooler■ TC-MAOH2 High performance transmission cooler■ 2COM1080 High volume air compressor□ 2COM1100 Air compressor. 1100 litres/minute (Eu6) ■ AIRIN-HI High air intake, roofline position □ AIRIN-LO Low air intake, rear of cab position ■ ACL1ST-S Air cleaner with two stage filter element □ 24A110BL Alternator - 110 Amp (Eu6) □ 24A150BL Alternator - 150 Amp (Eu6) □ 24A180BL Alternator - 180 Amp (Eu6) ■ 24AL150B Alternator - 150 Amp□ FUEFE2LW Dual fuel filter, engine mounted with water separator-large □ PTER-100 PTO engine rear mounted with flange DIN100/ISO7646 □ PTER-DIN Power Take Off / splined shaft groove (female) DIN5462. □ PTER1400 Rear engine mounted power-take-off with flange SAE 1410 □ HPE-F101 F1-101 Hydraulic pump rear engine mounted □ HPE-F41 F1-41 Hydraulic pump rear engine mounted □ HPE-F51 F1-51 Hydraulic pump rear engine mounted □ HPE-F61 F1-61 Hydraulic pump rear engine mounted □ HPE-F81 F1-81 Hydraulic pump rear engine mounted □ HPE-T53 F2-53/53 twin flow hyd pump rear engine mounted □ HPE-T70 F2-70/53 twin flow hyd pump rear engine mounted □ HPE-V45 V1-45 variable pump rear engine mounted □ HPE-V75 V1-75 variable pump rear engine mounted □ PTPT-D PTO DIN / Powertronic □ PTPT-F PTO flange conn / Powertronic □ PTR-D Low speed PTO with DIN connection □ PTR-DH High speed PTO with DIN connection □ PTR-DM Medium speed PTO with DIN connection □ PTR-F Rear PTO trans.flange 100% speed □ PTRD-D PTO with 2 DIN connections rear + 1 DIN connection front □ PTRD-D1 PTO with 1 DIN + 1 flange connection rear + 1 DIN connectionfront□ PTRD-D2 PTO with 2 flange connection rears + 1 DIN connection front □ HPG-F101 F1-101 hydraulic pump gearbox mounted □ HPG-F41 F1-41 hydraulic pump gearbox mounted■ Standard Equipment □ Optional EquipmentFor more detailed information about cab and powertrain equipment, please refer to separate specification sheets.For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS). □ HPG-F81 F1-81 hydraulic pump gearbox mounted□ DRC-AMIIDPF regeneration- auto initialise/manual on demand/manual inhibit□ DRC-AUTO DPF regeneration- fully automatic (in motion) □ ACCLF-D Acceleration Limiting Feature - Disabled □ ACCLF-E Acceleration Limiting Feature - Enabled■ ESP-BAS1 ESP package (tractor/trailer combinations with ABS/EBS OrRigids with standard COG)□ RSENS-W Rain sensor to activate wipers □ CU-ECC Climate controlled air conditioning ■ CU-MCC Manual controlled air conditioning □ IMMOBIL Engine immobiliser □ ALARM-B Anti-theft alarm (cab) ■ ISUNS-DS Interior side sunvisor - driver's door □ ISUNF-B Interior front sunvisor - standard □ ISUNF-MD Interior front sunvisor - with mirror (driver's side) □ ISUNF-RE Interior sunvisor - front (electric) ■ ISUNF-RM Interior sunvisor - front (manual) □ ADFS 2 din slots in front shelf■ BUPALARM Reverse alarm □ LOADIND Load indicator, electronic controlled suspension (SUSPL-EC) □ REMC-MF Multifunction wireless remote control ■ FIREX25A Fire extinguisher 2.5 kg■ WRITEPAD Storable steering wheel fit clip board ■ DST-CF5 Fully adjustable driver's comfort seatAir suspension, heated, integrated safety belt□ SBD-RED Red safety belts, pass. & driver seats■ SBPRE-DS Drivers seat belt pretensioner■ PST-BAS1 Basic passenger's seat □ PST-CF5 Fully adjustable passenger comfort seatAir suspension, heated, safety belt□ SBPRE-PS Passenger seatbelt pretensioner□ ARMRE-BB Armrests both sides - driver's & passenger's seat ■ ARMRE-DB Armrests both sides - driver's seat ■ ARU-BAS Seat armrest upholstery - basic■ FMAT-RUB Floor mats - rubber □ LBK70 Lower bunk 700mm wide □ MATL-FI Spring Mattress Lower Bunk - Firm (100kg +) □ MATL-SF Mattress lower bunk - semi firm□ OLMAT-BA Mattress overlay - basic □ SAFE Safe box at bed-end □ ETSB-F Engine tunnel storage box □ ETSB-FR Engine tunnel storage box & rear cab wall □ ETSB-R Rear cab wall storage □ REF-ICPK Refrigerator prep kit (on engine tunnel) □ BOTH-D Bottle holder in driving area ■ INLI-BAS Interior night lights ■ RH-ER Roof hatch-electric (metal emergency exit) □ RH-MTR Roof hatch-manual (tinted glass & rear opening)□ SWIND-PS Cab passenger side aux. window■ AWIND-RF Cab rear window- fitted □ VANMIR Vanity mirror Cab exterior■ DGLAS-H Hardened door glass □ DGLAS-L Laminated door glass■ LOCK-REM Central door locking with remote control■ BUMP-HD Bumper - heavy duty□ AUXFS Auxiliary folding side step■ GUARD-EH Guard plate for cooling pipes and oil sump■ BUGNET Insect net in front of radiator■ CTILTP-E Electrical cab tilt pump□ FCABS-A Front cab suspension-air bellows■ FCABS-M Front cab suspension-mechanical spring□ RCABS-A Rear cab suspension-air bellows■ RCABS-M Rear cab suspension-mechanical spring■ MIRCFCPXElectrically heated & operated convex glass mirrors with front monitoring camera on passenger side.□ AMIR-F20 Close view mirror ■ SUNV-H Exterior sunvisor□ GUARD-W Windscreen stoneguard ■ HL-BASIC Standard head lamps □ HL-LED LED headlights□ HL-CLEAN Head lamp cleaning system ■ HLP-ST Headlamp protection-steel □ HLP-ST2 Headlamp protection-steel/wire mesh (non ADR compliant) ■ DRL-LED V-shaped LED daytime running light ■ IDLAMP-A Identification lamps-amber□ BEACON-P Beacon light wire preparation □ SPOTP-F Aux spotlamp preparation, 280W maximum □ ANT-CBR Antenna for CB radio, single antenna Superstructure □ SRWL-2RW 2 white rear chassis mounted working lamps □ SRWL-PK Wiring prep for chassis mounted reverse/working lamps-3position switch□ SWL-2FW 2 white side working lamps (forward facing) □ SWL-2RW 2 white side working lamps (rearward facing) □ SWL-4W 4 white side working lamps □ SWL-PK Wiring prep for chassis-mounted working lamps-2 positionswitch□ WL-CHPK Chassis mounted working lamp prep kit □ WLC-H2W 2 x H3/70W high mounted work lamps with white lens. □ WLC-PKH Prep kit for high mounted work lamps. □ WLC-PKL Prep kit for low mounted work lamps.□ WLC-PKLH Prep kit for low and high mounted work lamps.□ ECBB-HIG Body builder module - cab module ■ ECBB-MED Body builder module - cab module ■ BBCHAS3 Body builder chassis electrical interface, 3 x 7 pin connectors □ HBA-SB Holes for body attachments ■ AESW2 2 flexible switches (AUX1 and AUX2).□ AESW2PK 2 flexible switches (AUX1 & AUX2) + additional 4 flexibleswitches■ AUXSW-4 Wiring prep. for 4 extra bodybuilder switches (switches notincluded)Delivery services ■ TGW-4GWL Telematics Gateway with 4G/LTE & WLAN □ FMS-PK Fleet management system gateway □ DRUT2 "My Truck" smartphone app. 2 year prepaid■ Standard Equipment □ Optional EquipmentFor more detailed information about cab and powertrain equipment, please refer to separate specification sheets.For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS).。
Volvo 车辆配置手册说明书
Important NotesChassis DimensionsCab Height: +39 mm for CAB-CRW.Front Axle to Back of Cab: +1258 mm for CAB-CRW, +280 mm for CAB-SSLP. D-measure includes a front clearance of 50 mm and for rigid trucks also a subframe of 120 mm.Height can vary ± 20 mm for leaf and ± 10 mm for air suspension.All dimensions are for unladen chassis and any tag axles down. Chassis height used: CHH-MED.Weight and dimensions are based upon the following tyres:Chassis weight includes oil, water, AdBlue, 0 litres fuel and without driver. Kerb weight can vary ± 3%.Turning diameters are theoretically calculated.Legal weights can differ from country to country.For more detailed weight information, including optional equipment weights, ask your Volvo sales contact to enter your specification into the Volvo WeightChassis Dimensions [mm]WB Wheelbase3250 3500 3800 4100 4400 4700 5000 5300 5600 5900 6200 6500A Overall Chassis Length6545 6975 7425 7955 8425 8915 9435 9915 10425 10835 11430 11730 D Center of rear axle to front of body 2662 2912 3212 3512 3812 4112 4412 4712 5012 5312 5612 5912 N Rear Overhang (Min.) 1515 1685 1615 1515 1615 1615 1615 1615 1615 1615 1615 1615 NRear Overhang (Max.)19752155230525352705289531153295 3505 3615 3910 3910Y Center of Gravity for Payload (Min.) 550 594 645 699 751 802 855 905 958 1007 1060 1105 Y Center of Gravity for Payload (Max.) 748 807 877 950 1021 1092 1164 1234 1305 1374 1447 1512 W Body Length (Min.) 3829 4210 4669 5124 5581 6041 6497 6957 7414 7876 8330 8800 W Body Length (Max.) 4224 4637 5134 5627 6121 6619 7114 7613 8109 8610 9103 9614Chassis Weights [kg]Front Axle 3150 3150 3160 3155 3155 3160 3160 3170 3170 3180 3180 3200 Rear Axle 1335 1365 1400 1425 1445 1470 1495 1530 1550 1570 1595 1615 Kerb Weight4485 4515 4560 4580 4600 4630 4655 4700 4720 4750 4775 4815 Payload (including body, driver, fuel, etc.) 11515 11485 11440 11420 11400 11370 11345 11300 11280 11250 11225 11185Turning Diameter [mm]Turning Circle Diameter Kerb to Kerb 11600 12400 13300 14200 15100 16000 16900 1780018700 19600 20500 21400 Turning Circle Diameter Wall to Wall 1290013700 1460015500 16400 17300 18200 19100 20000 20900 21800 22700Plated Weights [kg]DesignGross Vehicle Weight16000 Gross Combination Weight 21000 Front Axle 5800 Rear Axle 10900■ Standard Equipment □ Optional EquipmentFor more detailed information about cab and powertrain equipment, please refer to separate specification sheets.For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS).□ GARB-PRE Garbage vehicle preparation ■ UNIFORM Basic platform vehicleCore components □ CHH-HIGH Chassis height high - approx. 1000 mm above ground level ■ CHH-MED Chassis height medium - approx. 900 mm above ground level ■ RAD-L80 Rear leaf suspension, 1 axle - 1 driven (80 mm wide leafs) □ CAB-CRW Crew cab □ CAB-DAY Day cab □ CAB-SSLP Comfort cab ■ EU6SCR Euro 6 emission level with Selective Catalytic Reduction(SCR), particle filter and Exhaust Gas Recirculation (EGR)■ D8K250 Six cylinder diesel engine, 7.7 litre Euro 6 SCR + EGR (DieselParticulate Filter), 250 hp, 950 Nm□ D8K280 Six cylinder diesel engine, 7.7 litre Euro 6 SCR + EGR (DieselParticulate Filter), 280 hp, 1050 Nm□ AL306 Automatic 6-speed Allison gearbox, max input torque 1695 Nm □ ATO1056 I-Sync, Automated manual 6 speed gearbox, 1070 Nm ■ ZTO1006 Overdrive 6 speed manual ZF gearbox, 1050 Nm □ EBR-CEB Engine compression and exhaust brake ■ EBR-EPG Engine brake with Exhaust pressure governor, EPG■ RSS1125A Rear single reduction solo axle - axle load 11 tonnes, GCW 25tonnes□ RSS1132A Rear single reduction solo axle - axle load 11 tonnes, GCW32.5 tonnesPackages □ DRIVEFL Driver convenience package FL □ VISIFL Visibility package FL - Optimizing the drivers field of visionaround the cab□ AIRFLOW Airflow package FL - Includes adjustable roof spoiler, sidedeflector and sun visor□ AUDIODAB Audio System DAB ■ AUDIOPD Audio Preparation DAB kit, incl. DAB-amplifier Chassis ■ FST-PAR Front parabolic leaf suspension (normal stiffness) □ FST-PAR3 Two-leaf front parabolic suspension (stiffer than normal) ■ FAL5.8 Front axle load 5.8 tonnes □ FAL6.3 Front axle load 6.3 tonnes ■ RAL10.9 Rear axle load 10.9 tonnes ■ RSTAB1 Rear stabilizer with normal stiffness □ EBS-MED EBS (Electronic Brake System) medium package ■ EBS-STD EBS (Electronic Brake System) standard package■ RST-PAR1 Rear parabolic leaf suspension□ RST-PAR3 Three leaf parabolic rear suspension, stiffer than normal□ RST-PAR4 Short four leaf parabolic rear suspension with normal stiffness ■ FST7070 Frame section thickness - web 7.0 mm / flange 7.0 mm □ FST8080 Frame section thickness - web 8.0 mm / flange 8.0 mm ■ 2BATT170 Batteries 2x170 Ah □ ADR2 ADR adaptation, 1 switch in dashboard, 1 outside on back ofcab■ R80P Right 80 litre plastic diesel tank Min volume 80l Max volume 430l ■ UL-FUEL Without left diesel tank Min volume 80l Max volume 215l □ ADTP-L AdBlue tank on left hand side ■ ADTP-R AdBlue tank on right hand side ■ WHC-FIX1 One fixed wheel chock□ TOWMBRH High mounted towing member, in centre of frame□ C-RO40AG Towing coupling Rockinger 400 G-145■ TOWF-NO1 One front towing device □ TOWF-NO2 Two front towing devices□ TOWR-ONE One rear towing device in frame end cross member□ TREL15 15 pol electrical trailer connector (ADR certified)□ TBC-EC Trailer brake connection, European Community□ RUP-FIX2 Fixed rear underrun protection, EC approved■ RFEND-T Transport mounted one-piece rear fenders□ 2024GSR General safety regulations 2024Rims and tyres □ RT-AL Brushed aluminium rims with std holes (long stud fixing) on allaxles□ RT-ALDP Dura-Bright polished aluminium rims with std holes (long studfixing) on all axles■ RT-STEEL Steel rims on all axles ■ SPWT-F Spare wheel with tyre equal to front wheel □ SWCP-LF Spare wheel carrier on left side in front of rear axle □ SWCP-R Spare wheel carrier transport mounted behind rear axle, onright-hand side (FH, FM)/below frame (FL,□ SWCP-T Spare wheel transport mounted on top of frame ■ SWCP-TP Spare wheel carrier transport mounted with the spare wheel ontop of the frame rails□ JACK-10T Jack, 10 tonnes ■ JACK-8T Jack, 8 tonnes□ GAUGE-TP Tyre pressure gaugePowertrain equipment ■ CS39A-O Single plate clutch, plate diameter 395 mm □ RET-TPT Retarder for hydraulic gearbox □ TC-HWO Oil cooler for hydraulic transmissions – water/oil■ 1COMP500 Single cylinder air compressor 360 cc / 500 l/min □ 2COM1080 Dual cylinder air compressor 720 cc / 1080 l/min ■ AIRIN-HI High air intake □ AIRIN-RL Low air intake, chassis mounted behind cab on left hand side ■ ACL1ST Air cleaner with one filter element □ ACL1ST-S Air cleaner with additional filter element ■ 24AL110B Alternator 110 Ampere □ 24AL130B Alternator 130 Ampere □ CCV-C Closed crankcase ventilation ■ CCV-OX Open crankcase ventilation with oil separator and amaintenance free gas centrifuge■ EST-AID Engine start pre-heating element □ PTER-100 Rear engine mounted clutch independent power-take-off withflange connection (DIN 100 / ISO 7646)□ PTER-DIN Rear engine mounted clutch independent PTO with splinedshaft groove (female) for a close coupled pump (DIN 5462 / ISO 7653)□ PTER1400 Rear engine mounted clutch independent power-take-off withflange connection (SAE 1410 / ISO 7647)□ PR-HF4S PTO transmission, Hydrocar, flange connection, side mounted □ PR-HF4SH PTO transmission, Hydrocar, flange connection, side mounted,high speed□ PR-HF6S PTO transmission, Hydrocar, flange connection, side mounted □ PR-HP4S PTO transmission, Hydrocar, pump connection, side mounted □ PR-HP4SH PTO transmission, Hydrocar, pump connection, side mounted,high speed□ PR-HP6S PTO transmission, Hydrocar, pump connection, side mounted □ PTR-FH1 Rear gearbox mounted Hydrocar S81 PTO with flangeconnection (DIN 90 / ISO 7646) for propeller shaft (800 Nm)connection (DIN 90 / ISO 7646) for propeller shaft (430 Nm)□ PTR-FH5 Rear gearbox mounted Hydrocar S88 PTO with flangeconnection (DIN 90 / ISO 7646) for propeller shaft (450 Nm)□ PTR-PH1 Rear gearbox mounted Hydrocar S81 PTO with connection(DIN 5462 / ISO 7653) for pump (800 Nm)□ PTR-PH2 Rear gearbox mounted Hydrocar S84 PTO with connection(DIN 5462 / ISO 7653) for pump (430 Nm)□ PTR-PH4 Rear gearbox mounted Hydrocar S88 PTO with connection(DIN 5462 / ISO 7653) for pump (450 Nm)□ PTR-PK Electrical and solenoid prep kit for gearbox PTO□ PTR-ZF2 Rear gearbox mounted ZF PTO with flange connection (DIN100 / ISO 7646) for prop shaft (410 Nm)□ PTR-ZF3 Rear gearbox mounted ZF PTO with connection (DIN 5462 /ISO 7653) for pump (410 Nm)□ PTR-ZF4 Rear gearbox mounted ZF PTO with flange connection (DIN100 / ISO 7646) for prop shaft (320 Nm)□ PTR-ZF5 Rear gearbox mounted ZF PTO with connection (DIN 5462 /ISO 7653) for pump (320 Nm)□ PTR-ZF6 Rear gearbox mounted ZF PTO with flange connection (DIN100 / ISO 7646) for prop shaft (270 Nm)□ HPG-F101 Gearbox mounted hydraulic pump F1-101, fixed displacement,single flow□ HPG-F41 Gearbox mounted hydraulic pump F1-41, fixed displacement,single flow□ HPG-F51 Gearbox mounted hydraulic pump F1-51, fixed displacement,single flow□ HPG-F61 Gearbox mounted hydraulic pump F1-61, fixed displacement,single flow□ HPG-F81 Gearbox mounted hydraulic pump F1-81, fixed displacement,single flow□ ETC Electronic throttle control - dash mounted switch for PTOspeed controlCab interior■ TAS-DIG4 Gen 4 one day digital tachograph, EC approved (GNSS &DSRC, EU 2020/1054)□ SPDU-R Dual speed limiter for rear refuse body stepsCab exterior□ SUNV-B Exterior transparent dark grey front sun visor■ SUNV-PK Exterior front sun visor installation preparation kit (fasteners)□ AD-SIDES Short cab side air deflectors□ BEACON-P Prepared for roof beacons□ BEACONA2 2 amber beacon, roof mounted warning lampsSuperstructure preparations□ FBA-BTF Front body attachments for flexible body□ FBA-BTSF Front body attachments for semi-flexible body□ RBA-T2 Rear body attachments for helper frame□ TAILPREP Tail lift preparation kitServices□ TGW-4G Telematics gateway with 4G modem■ WVTA Whole Vehicle Type Approved■ Standard Equipment □ Optional EquipmentFor more detailed information about cab and powertrain equipment, please refer to separate specification sheets.For all possible options and combinations of options please consult your Volvo sales contact who can create a specification to match your requirements using the Volvo Sales Support system (VSS).。
沃尔沃汽车Showmode使用手册说明书
VOLVO CAR SHOWMODEUser manualCritical informationThe technical data, information and illustrations in this manual have been carefully compiled and corresponds to the products status at the time of printing this manual. The manufacturer reserves the right to improve or modify the product, specifications and documentation at any time without prior notice.Several Technical Journals has been issued to prevent permanent damages to vehicles due to continuous usage of Showmode in the showroom vehicles. These issues are continuously reported back to Volvo R&D for update of the Showmode software. In order to avoid any risk for damaging the vehicles, always refer to VIDA for latest Showmode related Technical Journals and ideally follow the instructions there: TJ EN-GB 32009, TJ EN-US 34206.Under no circumstances will the manufacturer of the Showmode components be held responsible for errors or damages resulting from wrong use or from misinterpretation.Read the whole manual, including the manual that comes with thepower supply unit, before connecting or using the system. Connectingor using the products in a wrong way may damage the products or thecar.Failure to follow the safety instructions can result in personal injury,property damage or impact the functionality of the Showmode system.For improved protection, it is strongly recommended to connect themains power of the power supply unit to a residual-current device andto check with the Electrical Safety Authority in the country where theShowmode device is being used to ensure compliance with localregulations.It is important to connect the 12 V clamps with good electricalconnection, otherwise the connectors will get hot and may causeburns. It might also deform the plastic in the connectors.Connect the clamps with as large electrical surface as possiblebetween the connector and the terminal to improve the currenttransmission and reduce heat generation.You should be able to touch the 12 V clamps after 1 hours use of theShowmode, without it being unpleasant to touch them. Use gloves ifthe clamps feel too hot.After connecting and starting the Showmode system in a car it is amust to make sure that the engine cannot be started and that theparking brake cannot be disengaged before leaving the Showmodeenabled in the car. Make sure the car key is stored away from the car asKeyless drive keys would enable engine start.The Showmode system consists both hardware and software.The hardware has been tested and found to comply with applicable CEstandards and has been marked with the CE sign.The software is developed by Volvo Cars and has been tested on manyvehicles but not all combinations possible.It is important that the person who connects the system into any carhas appropriate training and skills in working with the car and itsdemonstration.WarrantyThe hardware components have a 1-year warranty issued by the seller, Brigo AB, Mölndal, Sweden. Claims for warranty shall include the serial numbers of the components and the purchase date or ordering number.The software is developed by Volvo Car Corporation; updates will be made available for download at https:///showmode as they are compiled.System overviewThe Volvo Car Showmode is a system that enables demonstration of manyfunctions in the car without having the car key present. The system consists of acontroller and a power supply unit that has been specially developed for thispurpose.NB! Both components are needed to activate the system.ControllerThe controller is plugged into the OBD connector in the car and starts automatically. The two status LED lights are used to check operation and for troubleshooting.There is also an USB cable provided in the Showmode kit, to allow you toconnect the controller to a computer when a software update is required(see page 11, Software updates).Power supplyThe default power supply unit in the kit is Primepower Showmode Charger12/50A. This PSU works throughout input voltage of 100 to 240V, with orwithout the car battery connected to the car.All power supplies below have been tested to work with Showmode and to work with high continuous load.Primepower Showmode Charger12/50APrimepower PSU 12/30APower supply cable available for different standards.Input voltage 100-240V.CE and UL marked.Fan cooled with silent fan.Can be used with battery disconnected or connected. Available up on request for 230/240V markets.Input voltage 230/240V.CE marked.Silent.Waterproof.Must be used with battery connected in the car.Connect and startup1.Make sure there is no visual damage on the power supply housing or thebattery and mains cables. Do not use if there is damage.2.For the Primepower Showmode Charger 12/50A, make sure the DIPswitch connector is set to 010 (14.2V with battery detection active).3.Ensure that the car has the latest software status. I.e Pre Delivery Status.4.Open the hood and place the power supply unit beside the engine. Choose a location where aircan flow around the unit and the hood can be closed.Sometimes the power supply does not fit under the hood. Then the power supply shall beplaced under the car.5.Route the mains cable down to the floor inside the engine compartment. Normally this is bestdone on the right hand side of the car down towards the drive shaft of the front right wheel.6.Connect the red wire to battery positive and black (or blue) to chassis.Consult the car user manual if you are unsure.The clamps should be connected with as large electrical surface aspossible between the connector and the terminal to improve the currenttransmission and reduce heat generation.7.Connect the mains power and check the power supply unit indicators.The Primepower 12/30 shall be set to AGM or POWER SUPPLY mode before the batteryclamps are connected.If the charger has started the charging the setting is locked. Disconnect the battery clamps and change the mode, reconnect the clamps to start the unit.8.Prepare the car for Showmode;- Turn of the wipers.- Switch the running lights to automatic.- Ensure the car key is not in the car.Connect the Showmode controller to the OBD connector under thedashboard, the car will wake up within 10-20 seconds.9.Hide the controller under the dash. Use a cable tie to secure thecontroller under the dash (this prevent the controller from being “lost”).Hide the cable as much as possible.10.The error and information messages and warning triangle that appear in the driver display (DIM)can be removed from the display by pressing on the OK-button (READ button) on the steering wheel (see picture below). The warning triangle (RED or YELLOW) may remain in the display and it is normal when using the Showmode.Locking the car while in Showmode (SPA carsonly)To lock the car from the outside using the car key when in Showmode, follow thesteps described below:1.Make sure that the Showmode is running.2.Open the driver door as well as the side window fully (to be able to reach in to the car from theoutside later).3.Press and hold the Hazard button for about 10 seconds and release button when the displayshows Showmode information. The Showmode will restartin a couple of seconds.4.Go out of the car, close the door and lock the car with the key, while start up sequence of theShowmode is running in the driver display. Make sure to put the key away from the car before next step.5.Without opening the door, you can now access the OK-button on the steering wheel andremove error messages by pressing the OK-button and abort the Hazard warning lights bypressing the Hazard button.6.Close the side window (without opening the door).The car will now be in Showmode while remaining locked. In this mode the centerstack display will automatically toggle between the main menu and the navigation screen every five seconds.When the car is unlocked the normal Showmode functionality is restored.Disconnect Showmode (SPA cars only)When disconnecting Showmode completely from the car it is necessary tocomplete the checklist below.Not doing so may result in error codes being stored in the ECU’s of the car orsome components to continue to be on. Error codes must be reset beforedelivering the car to an end customer.•Switch the running lights to “0”.•Press the “Hazard” button and keep it pressed for more than 15 seconds until“Shutting down”is shown on the display. Showmode controller is now deactivated.•Unplug the OBD connector and remove the controller from the car.•Unplug the power supply unit mains supply and then the battery connectors.•Remove the power supply unit from the car before starting the engine.To activate Showmode after completing step 2 the controller must first be disconnected from the car and then reinstalled again.TroubleshootingFollow the checklist below if Showmode fails to start;1.Make sure the power supply is connected before plugging in theShowmode controller. The controller checks the car voltage during start-up and does not start if it is not connected to the charger or if the poweris too low.2.The car must be completely turned off before inserting the Showmode controller.3.Observe the LED’s on the controller during start-up and verify to the list below;a)Connect / reconnect the controller in the OBD port of the car.b)Pre start-up phaseLED A: Indicating the software version, binary notation, short green flash = 0, long greenflash = 1, followed by red flashes to indicate the last version digit. Version 5.4 is indicatedwith green flashes as short + long + short + long, followed by four red flashes.c)Car initialization phaseLED A: Flashing blue, checking if car is based on SPA/CMA platform. LED continues to flashuntil car start-up sequence is finished.LED B: Flashing blue, checking if car is based on EuCD/C1MCA platform (older cars). LEDcontinues to flash until car start-up sequence is finished.d)Car start finishedLED A and LED B, three green flashes, start-up sequence has finished.e)Showmode activeLED A or LED B is flashing every five seconds (battery voltage is ok).Low voltage, 12V batteryIf LED A and B is flashing blue every 20 seconds after pre start-up phase this indicates low voltage. The controller will continue to check the battery voltage every 30 minutes and will start Showmode as soon as the voltage is ok (above 12.5V).If Showmode has started and battery voltage becomes low this is first indicated by LED A and B flashing red every five seconds during the first minute. If the voltage is still low the controller shuts down Showmode, LED A and B flashes blue and restart is tried after 30 minutes.Low voltage, High voltage batteryIf the high voltage battery voltage drops below 250V the controller will shut down Showmode and will not try to restart automatically. This state is indicated by continuous flashing on both LED A and B, the colour of the flash is green for software V3 and red for software V4 and higher.Wrong modeIf the car is already in Active or Driving mode (by using the car key) when the controller is installed the controller will enter a waiting mode. The LED A or B will flash with green to indicate power is ok but will not enter the initialization phase (with blue flashing).Software updatesAs new cars are launched the software in the Showmode controller will needupdating to support them. Software updates for the Showmode controller areavailable for download as they become available. It is important that the latestsoftware is downloaded and installed in the controller to avoid error messages inthe car.You can activate e-mail notifications to receive an e-mail when new software is available.For more information; go to https:///showmode.Check software version on controllerThe controller indicates the software version with the LED’s during start-up of the controller.This can be checked by powering the controller using the USB cable and connecting it to your computer without pressing the programming button or when installing it into the car.LED A: Green flashes showing the version (see Troubleshooting 3b)Updating the softwareTo update the software, you need a personal computer, a micro USB cable (included in the kit) and the downloaded software file.Follow the instructions below;1.Download the latest software from https:///showmode, store the downloadedfile at a location you can remember, lik e the desktop or in “My documents”.2.Connect the Showmode controller to your computer using a USB cable and keep thePROGRAM button on the controller pressed while doing so.3.The controller shall be detected as a USB flash drive if step 2 was successful. If not, justdisconnect, press the programming button and reconnect again.4.Open the detected USB drive and delete the firmware.bin file that is stored on it.5.Copy the downloaded software file to the controller USB drive.6.Disconnect the USB cable, the programming is finished.7.Check the installed software version using the instruction provided earlier in this manual.Power supply unit informationThe power consumption in idle Showmode is between 15 to 23 Amperedepending on car model and extra equipment. Some functions use a lot morewhile being demonstrated. The power needed is supplied from the power supplyunit and the car battery working together.The power supply unit becomes hot during use (60C / 140F). This isnormal and within unit specifications.The unit has a modified charging program that handles recharging thecar battery while Showmode is running and shall not be replaced byother charging devices.About ShowmodeThe Showmode system has been developed as a joint effort by Volvo Cars and Brigo AB.The software and overall functionality is provided by Volvo Cars.The hardware and logistics is provided by Brigo AB, Mölndal, Sweden.More information about the system is available at the Showmode website hosted by Brigo AB at https:///showmode.。
2023款沃尔沃汽车使用手册说明书
A Concise Guide to Your New Model Year 2023 VolvoWith Google built-in and moreTable of ContentsClick on any topic to jump to that page; use the Home iconon the lower left of each page to return hereKey Google Services 3Interacting with the Infotainment Systemwith Google built-in 4 Driver Profile Setup 5 Basic Navigation: Center Display 8 Pairing Your Car with the Volvo Cars App 11 Adding, Changing, and Deleting Profiles in the Car 15 Pairing and Deleting Keys 18 Screen Lock 19 Hands-Free, Foot-Activated Tailgate 20 Charging a Twin Engine Plug-In Hybrid 21 One-Pedal Drive 22 Recharge Plug-In Hybrid Drive Modes 23Key Google ServicesAn Active Google Account Will Enable Access to Key FeaturesSigning into your own Google account provides a personalized experience, such as directions to work or home, saved Google Maps destinations, and Google Map search history. This makes trip planning very easy. The system will still function without being signed in with Google.We recommend you set up a Google account, if you don’t already have one. You can do that here .Google AssistantAllows driver to control in-car functions and muchmore by voice.Google PlayAllows drivers to easily download apps and have themappear within the car center touchscreen.Google, Google Play, and Google Maps are trademarks of Google LLC. Google services are included in the 4-year Digital Services package.Interacting with the Infotainment Systemwith Google built-inInteracting with the new Infotainment system is easy and as familiar as using your smartphone• Google Assistant supports natural speech. Simply say “Hey Google” or “OK Google” and state your command – anything from navigation to most things that can be answered by the internet.• Google can also control some in-car features, such as climate settings, heated seats and steering wheel.• Our new navigation system, Google Maps, is based on the Google Maps app for smartphones, now adapted for in-car usage. Mapsare always up to date and cached in the car while driving. The routeto your destination is pre-cached in case of limited connectivity, and the system will assist you with Real Time Traffic Information, automatic rerouting, and voice control. When logged in with your Google account, saved favorites such as home, work, and recent destinations are sharedbetween smartphone and car.Driver Profile SetupC D Once in Profiles, selectComplete Profile Setup .Follow prompts to set up Volvo ID and complete step one.1. Link Volvo IDComplete Profile Setup Completing the Driver Profile is the first step in customizing the car settings to set you up for a more intuitive driving experience. We recommend each driver create their own profile in the car.Before you can set up Driver Profiles, you will need both your Volvo ID and your Google account login.If you don’t yet have a Volvo ID, your Volvo Retailer Sales Consultant can help you to create it, or you can do it yourself by downloading the Volvo Cars app with which you can create a Volvo ID login and password. You also can do it by clicking here and following the steps.*iPhone user only, no action needed for Android users.D 2. Pair PhoneMake sure the code displayed in the vehicle matches the onedisplayed on your phone and confirm.Once pairing is completed, g o to the phone’s Bluetooth settings*• Press (i) by your car’s model name• Enable Show Notifications and Sync Contacts for access to text messages and phone contacts in the car.Google Assistant, Google Play and Google Maps are trademarks of Google LLC.C A short tutorial on Google Assistant is available here , and you are able to turn on personal results for access to your calendar and contacts.A short tutorial on Drive Profile Setup is available here .3. Google Sign-InFollow prompts to sign in and view tutorials, turnon personal results and select Google Play apps,then your profile is complete!Basic Navigation: Center DisplayHome ViewHome view is displayedwhen the screen is activated.It consists of four tiles.You can choose which appswill be shown in Home view tiles.An app that is selected from Appview starts in the respective tilein Home view.The tiles are dynamic and showthe last-used apps, such asnavigation, media, phone, etc.Tap an app to expand it or swipefrom the left in the tile to viewadditional apps.Note, when the vehicle is moving:• Certain applications (e.g.the Owner’s Manual) maybe deactivated.• Certain messages(e.g. those generatedby apps) will be shortened.Status BarCurrent vehicle activities are shown at the top of the screenin the status bar: information such as active user profile,network and Bluetooth connection status, and the clock.Notifications ViewPull the tab down to access Notifications view, which shows missed calls, vehicle information, and provides access to User Profiles. To leave, tap outside of Notifications, press the Home button, or swipe upwards.User ProfilesTo access User Profiles, swipedown on the Home Screen toreach notifications.Select (tap) the profile in use(upper left corner).Only the profile that is signed-inwill appear. A new car will defaultto the name “Owner” as the primaryand only profile.On the Profiles screen you canupdate or delete an existing profile,or add a new one.Many driver personal preferencesettings can be saved in differentuser profiles, including screens,mirrors, front seat, navigation,audio and media system,language and voice control.App ViewApp view provides access to the vehicle’s preinstalledand downloaded apps. From App view, you can downloadand install additional apps and access the Owner’s Manual.Tap an app to open it in full-screen mode.Camera ViewCamera view starts automatically when gear selectorposition R is used. It shows the Park Assist Cameras,and separate views for each of the four cameras:rear, front, left and right.Camera view closes automatically when the vehiclereaches a certain speed or can be closed manuallyby tapping or the Home button.Settings ViewSelecting Settings view allows you to make changes thatinclude system units of measurement, system language,door lock and unlock settings, and resetting user data.Climate ViewButtons for App view, Camera view, Settings view, and the most common climate settings are at the bottom of the center display. Tap the blue or red arrow to adjust the temperature when left and right side temperature is synchronized. Tap the temperature button to open Climate view and additional settings options. Tap the Home button to close Climate view.The Volvo Cars app pairing process is completed in the car. Please make sure you are signed into your driver profile in the car and have all car keys with you. Don’t have a driver profile yet? Please follow the instructions on page 5.Pairing Your Car with the Volvo Cars AppDownload the Volvo Cars app by visiting the appropriate app store. Available for iOS 8 or higher and Android 4.0 or higher.Next, create your Volvo ID. If you already created your Volvo ID, go directly to Sign In .Sign In Create Volvo ID1. Download the Volvo Cars app and Sign InThe Volvo Cars app pairing process is completed in the vehicle.2. Within Car: Share Car DataThe Volvo Cars app pairing process is completed in the vehicle.3. Within Car: Pairing app Part 1CThe Volvo Cars app pairing process is completed in the vehicle.Open app while sitting in your vehicle. If you are new to the Volvo Cars app, press Add your car .Press Next on the center touch-screen. Verify the numbers on screen match the numbers in the Volvo Cars app. Pairing complete.4. Within Car: Pairing App Part 2A short tutorial on Volvo Cars app pairing is available here .Add your carAdding, Changing, and DeletingProfiles in the CarTo add, change or delete a Driver Profile, please follow the steps below. Access Profiles & ChangeAdd ProfileDelete ProfileLog into the profile you want to delete.By deleting a profile, all settings associatedwith that profile will be deleted.Pairing your key fob into your driver profile will ensure that your personal settings for seat, climate, audio, and navigation will auto-matically adjust each time you enter the car with the paired fob.Follow these easy steps on the center touchscreen to pair or remove a key fob in your profile.Pairing and Deleting KeysAccess ProfilesWith your Driver Profile set up, you can easily lock the screen when someone outside your household will be driving your car (e.g. a valet). This protects your personal information, past destinations, and apps.Screen LockAccess Screen LockHands-Free, Foot-Activated Tailgate Both hands full? You can open or close the tailgate with a single footkick movement under the rear bumper.Pro tip: Aim for the center left parking sensor or the first “V” of the “Volvo” lettering for best results.The ‘kick’ should be smooth during the inward and outward motion – no waving or holding your foot in place as this won’t activate the sensor to open /close the tailgate.Immediately after the kick, take a step back to ensure that the tailgate will open or close.A short tutorial on the foot-activated tailgate is available here.Charging a Recharge Plug-In HybridRecharge Plug-In HybridVolvo Twin Engine Plug-in Hybrid vehicles feature the “Three Layer” 18.8 kWh high-voltage battery. That means you can do longer fully electric journeys with zero tailpipe emissions on a single charge.The Charging CableThe standard dual-voltage (110V & 220V) charging cable has two connectors – one side plugs into the vehicle using an industry-standard J1772 connector. The other connector has a special adaptor that allows it to plug into either a 110V or a 220V wall outlet.Using a 110V outlet, you can expect to charge the battery in 10 to 15 hours. Using a 220V outlet or a commercial charging station, you can charge the battery in 5 to 8 hours.Two-Step Regenerative Braking SystemThe regenerative braking system recovers and transmits energy back into the high-voltage battery, either to recharge it or for immediate use. You can press the “Hold” button on the center display to keep the current battery charge for later use, or the “Charge” button for the gasolineengine to charge the battery up to 90 percent.In Recharge Plug-In Hybrid vehicles, one pedaldrive gives you intuitive, seamless control ofthe car’s acceleration and braking just by usingthe accelerator pedal. Press the pedal for instantacceleration, and release it to instantly reducespeed or to brake the car to standstill (on Rechargewith Google built-in). This adds to more relaxeddriving, more fun, and an enhanced feeling ofcontrol – especially in stop-and-go city traffic.Brake energy regeneration also adds to a longerrange – every time you release the pedal, electricenergy is generated and fed back to the car’sbattery. The level of regenerative brake forceis determined by moving the shifter between “D” mode and “B” mode. In “B” mode the car has a high level of brake energy regeneration, and it activates one pedal drive. One pedal drive can also be controlled via Google Assistant. In “D” mode one pedal drive is turned off, and it provides a lower level of energy regeneration. When driving in one pedal drive you can activate “Creep” mode –“Creep On” to allow you to continue driving at low speeds without the car coming to a complete stop, such as in precision parking situations. “Creep” mode can easily be turned on or off via the settings menu in the center display or simply by using a voice command with the help of Google Assistant:“Hey Google, turn on/off creep mode.”One-Pedal DriveRecharge Plug-In Hybrid Drive ModesThe drive mode settings in our Plug-In Hybrid are different from thosein our gasoline engine cars. The drive mode settings allow the driverto choose different settings for the engine via the center display.Hybrid Mode (Default) utilizes the electric motor and gasoline engine, either individually or in parallel. Their operation is optimized for performance, fuel consumption, and comfort. The engineand automatic gearbox are programmed for maximum comfort.This is the default mode when the engine is started.Pure Electric Mode prioritizes electric operation and low energy consumption. It helps to maximize driving on the hybrid battery.The dynamic performance is reduced, and air-conditioning is partly disengaged but can be activated manually. This mode sets a maximum speed of 87 mph using only electric propulsion. (When Hybrid Mode is active, the car’s maximum speed is 78 mph on electric propulsion only.) Power Mode combines the gasoline engine and the electric motorto ensure the strongest performance, sporty characteristics, and quick response.Launching from a stop, this mode takes advantage of the electric motor’s instant maximum torque while the combustion engine gets up to speed. eAWD (All-Wheel Drive) Mode provides constant all-wheel driveon demand. Used primarily at low speeds and in slippery conditions, it activates all-wheel drive to improve traction. You can select this mode when needed, or choose to save energy for later. There is always enough power to use AWD mode, even when the battery is depleted. Off-Road Mode (XC90 & XC60 only) can be set at speeds below approximately 12 mph to maximize traction and control on poor roads. Above 25 mph Off-Road mode is disconnected and will notbe connected automatically again, even if speed is reduced. In this mode, Hill Descent Control is automatically activated, steering is set to comfort mode, the Electronic Stability Control is set to Traction/ Sport, and the Stop/Start function is deactivated.。
2021年版Volvo XC90说明书
Volvo XC90A Higher Grade Of LuxuryWe created the XC90 to meet your highest expectations of Swedish luxury. It’s a highly personal expression that evokes a strong sense of elegant refinement. Each detail is carefully selected to give you and your passengers a sophisticated and invigorating experience. A car that meets your expectations of a dynamic luxury drive with refined comfort and sophisticated design. And when it comes to intelligent luxury imbued with distinctive style and fresh thinking, the XC90 Inscription is in a class ofits own – just like you.XC90’s plug-in hybrid technology means you get an uncompromising driving experience with excellent fuel economy and low CO₂ emissions all at the same time.That’s why this solution is as important today as it is in our future.The XC90 epitomises our proud heritage of human-centric design. The highly sophisticated XC90 Inscription expresses the essence of contemporary luxury inits Swedish craftsmanship.Select your power. Choose between five drive modes that allow you to tailor the car’s behaviour to your mood and find the perfect setting for the road you’re on. The large9-inch center display further adds to your sense of being in control.Note: Above images used are only for illustration purposes.City Safety - Collision Avoidance & Mitigation with IntersectionSupport Pedestrian, Cyclist & Large Animal DetectionBlind Spot Information System (BLIS) with Steer Assist Lane Keeping Aid (LKA)Oncoming Lane MitigationCross Traffic Alert (CTA) with Auto BrakeRun-off Road Mitigation with Road Edge DetectionPark Assist Pilot, Parallel Parking & Perpendicular Parking Front & Rear Collision Warning & Mitigation SupportINTELLISAFE – SAFET Y ASSISTANCENote: City Safety and Accessories video footage used are for illustration purposes. The video footage shows a general car model. Actual functionality andspecifications may vary.Product Walk AroundVideo GalleryVIDEO GALLERYS : StandardB5 : B5 Inscription PlusT8 : Recharge T8 Inscription PlusNote: Model specifications and colours may differ from those shown in leaflet. Please check with your dealer for more information.707 Crystal White, Pearl723 Denim Blue, Metallic717 Onyx Black, Metallic727 Pebble Grey, Metallic** The electric range is the certified data based on driving cycles and regulations. This is not a range that can be expectedduring typical driving.Note: Prices quoted are exclusive of insurance and HP Endorsement. Prices quoted are subject to change without priornotice. Model specifications and colours may differ from those shown in leaflet. For further details, please refer to yournearest authorised dealer. * Terms and conditions apply. Effective Date: 15 February 2022.COLOURSVolvo XC90Years Unlimited MileageWarranty On New Car *Years or 160,000kmWarranty On PHEV Battery *58VOLVO CAR MALAYSIA SDN BHD (482430-K) • Authorised Dealers:• KUALA LUMPUR • FEDERAL AUTO CARS (Federal Highway 03-2260 1411) • SISMA AUTO (Jalan Bukit Bintang 03-2166 5155) • SELANGOR • FEDERAL AUTO CARS (Glenmarie 03-5569 4880) • INGRESS SWEDE AUTOMOBILE (Mutiara Damansara 03-7732 9666) • SIME DARBY SWEDISH AUTO (Ara Damansara 03-7623 3200) • PENANG • FEDERAL AUTO CARS (Jalan Sungai Pinang 04-281 7300) • WESTERN CIRCLE (Juru 04-508 0888) • PERAK • iROLL IPOH (Jalan Raja Permaisuri Bainun 05-246 1618) •MELAKA • SEONG HOE MOTORS (Melaka 06-282 2653)• JOHOR • AJ PREMIUM MOTORS (Batu Pahat 07-431 2222) • PEKIN AUTO (Johor Bahru 07-562 6011) • SABAH • SEBANGGA MITSINBO(Kota Kinabalu 088-309 888) • SARAWAK • FOTROENDE AUTOMOBILE (Kuching 082-572 009)。
沃尔沃XC90汽车使用手册说明书
VOLVO XC90 Owners Manual WEB EDITIONDEAR VOLVO OWNERTHANK YOU FOR CHOOSING VOLVOWe hope you will enjoy many years of driving pleasure in your Volvo. The car has been designed for the safety and comfort of you and your passengers. Volvo is one of the safest cars in the world. Your Volvo has also been designed to satisfy all current safety and environmental requirements.In order to increase your enjoyment of the car, we recommend that you familiarise yourself with the equipment, instructionsand maintenance information contained in this owner's manual.G 000000Environmental care is one of Volvo Car Corpo-ration's core values which influence all opera-tions. We also believe that our customers share our consideration for the environment.Your Volvo complies with strict international Fuel consumptionVolvo cars have competitive fuel consumption in each of their respective classes. Lower fuel consumption generally results in lower emis-sion of the greenhouse gas, carbon dioxide.many cases the exhaust emissions are well below the applicable standards.Clean air in the passenger compartment A passenger compartment filter prevents dust and pollen from entering the passenger com-Volvo workshop immediately.Red symbol。
沃尔沃汽车产品说明书
Q U I C K G U I D E恭喜您拥有全新沃尔沃汽车！本文件夹包含您的汽车中最常用的功能。
《车主手册》与其它手册中包含安全说明及所有警告信息、重要说明和提示文本。
下列符号表示：在概览图像中指出不同的部件。
分步说明。
阅读《车主手册》尤为重要。
最后一页包含必须阅读的警告信息、重要说明和提示文本。
选装件用星号（*）标记。
《车主手册》可分为印刷版手册以及通过车辆屏幕、网页以及移动应用程序显示的数字版手册。
移动应用程序包含整本《车主手册》及说明影片，并具有多个文本和插图搜索路径。
移动应用程序可从苹果应用商店 (App Store) 或谷歌市场 (Google play) 下载至移动设备。
另外，更多有关您的汽车的信息，请登录 温度系统控制器大灯开关组合仪表板Infotainment 系统电话互联网外部声音设备中控台中的按钮菜单系统的设置维修中心/预订保养ECO*调节座椅调节方向盘电动尾门*03 您的驾驶环境重新添加燃油车辆维护储物区域AUX/USB 端口和 12 V 插座04 汽车中的功能05 提示起动/停止功能*行人保护系统*02 汽车中的驾驶员支持系统遥控钥匙Keyless*锁止系统起动和关闭发动机驻车制动器雨刮器轮胎压力监测*01 起动和驾驶遥控钥匙如何工作？01解锁车门和尾门并解除警报。
该功能可在MY CAR（我的汽车）中进行设定。
锁止车门和尾门并启用警报。
安全取车照明期间。
按一下可解锁尾门，长按一下可打开电动尾门*。
信息*。
紧急功能。
遥控钥匙可存储车门后视镜和电动驾驶员座椅*等设置–请参阅《车主手册》。
遥控钥匙指示灯*表示什么信息？01绿色常亮：车辆锁止。
黄色常亮：车辆解锁。
红色常亮：警报器自车辆锁止后触发。
两个指示灯交替闪烁红光：警报器在不到5分钟前触发。
如何操作Keyless*锁止系统？遥控钥匙可一直放在（例如）口袋这些位置。
锁止并激活警报器–触摸一个外部车门把手的后部区域。
解锁和解除警报–以平常的方式握住一个车门把手并打开车门，或轻按尾门的橡胶按钮。
沃尔沃yv1fs63c使用说明书
沃尔沃yv1fs63c使用说明书沃尔沃(Volvo)是瑞典的一个汽车品牌，属于豪华汽车品牌，旗下的产品主要有沃尔沃汽车、沃尔沃摩托车共享平台、沃尔沃共享汽车平台等。
作为一个注重环保的企业，沃尔沃一直坚持以人为本，致力于成为为每一个家庭带来健康安全生活的豪华品牌。
如今这款Yv1fs63c 已经上市了,Yv1fs63c这个名字来源于它的英文名称是Yv1 Motors (安全防护)+FS63c (安全）的组合体。
为了给大家介绍这款Yv1fs63c到底是怎么用上它的时候。
请看这本说明书，这是一本有关车辆安全防护及控制设备的使用说明书。
一、概述Yv1 Motors安全防护是沃尔沃针对儿童和年轻家庭车辆（不包括全轮驱动车辆）推出的新型防护系统，该系统由安装在儿童座椅或儿童踏板上的传感器、照明装置和儿童锁组成，旨在保护儿童和年轻家庭及驾驶员的安全。
该系统主要用于监测儿童和年轻家庭车辆的交通状况、儿童交通安全、驾驶员操作危险情况及预防儿童交通事故等。
该系统与儿童安全座椅（或儿童锁）相连，能够在必要时候，通过遥控开关为儿童自动解锁。
该系统具有更好的保护功能，如在雨天、雾天驾驶的时候能够保护儿童乘车不受危险状况的影响。
该系统采用电子控制系统，提供良好的保护效果。
二、使用说明Yv1 Motors的正确使用方法如下：a、启动车辆，进入“全开”模式，打开大灯开关，当大灯亮起时，向右滑动到左侧踏板，然后关闭大灯开关，同时按下方向盘上的“ON”键，接着将方向盘从左侧向左转动，直到方向盘转向正确。
b、当转向角度达到最大或与最小转弯角之间时，再次向右旋转方向盘，直到方向盘转动正确。
d、方向盘从左上方向左转动，直到方向盘转向正确。
e、重新调节方向盘转向角度即可完成开车体验。
f、完成上述操作后，请按下“ON”键，车辆将自动关闭。
三、注意事项请勿将Yv1fs63c放置在不平整或不平的路面上，应避免与其它车辆碰撞；如果您的车辆在静止状态下移动时，请确保Yv1fs63c处于静止的状态下；如果您想让他工作时不影响其他车辆的正常行驶，请使用自带或租赁设备来保证安全；YVR模式无法提供持续的服务，请在使用车辆前确认您是否处于开启状态（包括在停车或启动车辆中);为确保安全驾驶，请勿让YVR 模式使用超过48小时进行充电。
沃尔沃汽车使用手册说明书
w e b e d i t i o n q u i c k g u i d eVälkommen!本快速指南为您介绍新 Xc90 twin engine 汽车的一系列功能。
中央显示屏上的车主手册中包含有关您沃尔沃车辆的全面信息。
手套箱中收藏了含重要且实用信息的车主手册摘录。
车主手册还可以应用程序的形式在智能手机和平板电脑上查看，以及在 网站上查看。
支持页面对于大多数市场可用，并包含有关您的 Xc90 twin engine 汽车的进一步信息和帮助。
选装件用星号（*）标记。
01. 入门指南您可在此处找到可帮助您熟悉您的沃尔沃车辆中的一些基本功能的信息。
除其他内容外，您还可阅读有关遥控钥匙、车辆的三个显示屏以及如何起动和关闭发动机的内容。
此外，您还可了解如何控制与调节座椅以及空调控制的相关信息。
02. 混合动力相关信息除其他信息以外，您还会在此处找到有关如何开始和结束混合动力蓄电池充电的信息。
03. 驾驶和驾驶员支持系统您会在此处找到有关车内驾驶模式以及诸如巡航控制系统、自动泊车辅助系统 (PAP)*、盲点信息 (bliS)* 和 city Safety 等不同驾驶员支持功能的信息。
04. 仪表与控制器您在此处可找到有关如何控制灯光和雨刮器以及如何使用行车电脑和语音控制的信息。
05. 联网、娱乐与支持从您的沃尔沃车辆中，您就可以与外面的世界互联，获得信息、娱乐和支持功能。
本节包含有关如何将手机连接至您的沃尔沃车辆、连接至互联网以及如何使用应用程序的信息。
06. 特殊文本请务必阅读警告、重要及注意事项。
按一下可锁止车门和尾门并布设警报1。
长按一下可同时关闭全景天窗* 和所有侧窗。
按一下可解锁车门和尾门并解除警报。
长按一下可同时开启所有侧窗。
按一下仅解锁尾门并解除警报。
长按一下可开启或关闭电动*尾门。
遥控钥匙按钮1特定市场选项。
紧急功能用于在紧急情况下引起注意。
长按一下至少 3 秒钟或在 3 秒钟内按下两次可启用方向指示灯和喇叭。
沃尔沃发电机的说明书
沃尔沃发电机的说明书尊敬的用户，感谢您选择沃尔沃发电机。
本文将为您提供关于沃尔沃发电机的详细说明，以便您更好地了解和使用该产品。
一、产品介绍沃尔沃发电机是一款高性能、高效能的发电设备，采用先进的发动机技术和可靠的发电机组件，旨在为用户提供稳定、可靠的电力输出。
1.1 技术特点沃尔沃发电机的核心技术包括但不限于以下方面：- 先进的燃油喷射系统，确保燃油利用率高效，减少能源浪费。
- 高性能发动机，具有出色的功率输出和稳定性能。
- 智能化控制系统，可实时监测和管理发电机的运行状态，提供安全可靠的电力保障。
- 多层次的安全保护装置，有效预防过载、过热、短路等异常情况的发生。
1.2 产品优势沃尔沃发电机在市场上具有显著的竞争优势：- 高效能：采用先进技术和优质材料制造，提高燃油利用率和能源转换效率。
- 环保节能：符合国家环保要求，减少废气排放，降低对环境的影响。
- 安全可靠：全面考虑用户需求，确保发电机的稳定性和可靠性，保障电力供应的连续性。
- 易操作：智能化控制系统使用户操作简单便捷，提供用户友好的界面和人机交互体验。
二、使用说明请在使用之前仔细阅读以下内容，并按照说明操作，确保发电机的正常运行和使用安全。
2.1 安装- 在选择安装位置时，应确保发电机有足够的空间，并保证周围通风良好，远离易燃物品，以防发生事故。
- 安装前请查看发电机的连接线路，并确保连接正确牢固，避免安装过程中出现短路或电流泄漏的问题。
2.2 操作- 如需启动发电机，请确保燃油供应充足、电池电量足够，并按照操作手册中的步骤进行操作。
- 正常使用过程中，应定期检查油量、冷却液、电池电量等，确保各项参数在正常范围内。
- 如遇到异常情况，请立即停止使用并联系售后服务，切勿私自拆卸或修理，以免造成更大损失。
三、维护保养定期维护和保养可以延长发电机的使用寿命和保证其良好性能。
以下是一些常见的维护保养注意事项：3.1 清洁定期清洁发电机的外部表面，避免灰尘和污垢积聚。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
沃尔沃物流信息服务平台软件需求规格说明书变更记录目录1概述 ............................................................................. ....................................................................... 4 1.1 1.21.3 22.1编写目的 ............................................................................. ...................................................... 4 系统目标 ............................................................................. ...................................................... 4 术语定义 ............................................................................. ...................................................... 7 物流信息服务平台 ............................................................................. .. (9)首页 ............................................................................. ...................................................... 9 物流需求发布 ............................................................................. .................................... 10 物流解决方案 ............................................................................. .................................... 10 物流企业园区 ............................................................................. .................................... 11 物流联盟论坛 ............................................................................. .................................... 12 物流效率测算 ............................................................................. .................................... 12 新闻维护 ............................................................................. ............................................ 14 物流项目发布 ............................................................................. .................................... 14 论坛维护 ............................................................................. ............................................ 15 物流运营数据分析系统维护 ............................................................................. ............ 16 数据字典 ............................................................................. ............................................ 17 网站用户管理 ............................................................................. .................................... 17 平台系统管理 ............................................................................. (21)需求说明 ............................................................................. ............................................................... 9 2.1.1 2.1.22.1.3 2.1.4 2.1.5 2.1.6 2.2 2.2.1 2.2.2 2.2.3 2.2.4 2.2.5 2.2.6 2.2.7物流信息服务平台管理系统 ............................................................................. .. (14)3 4 5 6性能要求 ............................................................................. ............................................................. 23 可维护性, 可扩展性 ............................................................................. .......................................... 24 安全性 ............................................................................. ................................................................. 25 设计约束 ............................................................................. ............................................................. 26 6.1.1 6.1.2 语言约束 ............................................................................. ............................................ 26 系统模型约束 ............................................................................. (26)7 8 9界面要求 ............................................................................. ............................................................. 27 验收标准 ............................................................................. ............................................................. 29 附件 ............................................................................. (30)1 概述1.1 编写目的本文档是北京软通动力科技有限公司（以下简称软通）在沃尔沃（中国）投资有限公司（以下简称沃尔沃）的物流信息服务平台合同基础上编制的。
本文档的编写为下阶段的设计、开发提供依据，为项目组成员对需求的详尽理解，以及在开发开发过程中的协同工作提供强有力的保证。
同时本文档也作为项目评审验收的依据之一。
1.2 系统目标本平台为物流需求企业和物流服务企业提供了各种需求、货源、车源信息。
为物流需求企业提供完整的解决方案、为物流服务企业提供需求信息等增值服务，在促进沃尔沃用户供需交互的同时达到宣传和推销沃尔沃卡车的目的，最终使沃尔沃卡车在中国地区的销量能够显著增长。
鉴于上述目标，本平台由两个子平台组成，即物流信息服务平台（以下简称服务平台）和物流信息服务平台管理系统（以下简称管理系统）。
服务平台的用户主要是物流企业以及有物流需求的非物流企业，所完成的目标为：首页支持的功能应包括：用户注册与登录，订阅电子期刊，过桥费查询，给沃尔沃留言；首页所发布内容包括：物流企业介绍、成功案例展示、物流需求发布、最新消息、解决方案展示、运力合作展示。
2. 物流需求项目发布:? 物流需求项目发布平台为物流需求企业提供大型物流项目发布的平台，为物流服务企业提供更多的商机。
用户可以在平台上发布和查询需求项目信息，以及进行之后的方案征集活动。
