Type 8605Control electronics

Cable plug version

Proportional Valve

with Control Electronics

The valve Type 6223 can be used for the con-trol of larger ﬂ ow quantities. Low hysteresis, high reproducibility and good response sen-sitivity guarantee good positioning behaviour. The valve closes tight. The push-over coil is easy to replace.

Digital control electronics DIN-rail version

Cable plug Universal controller

Approvals

UR, CSA, CGA/AGA

Further versions on request

Ordering chart for accessories

Cable plug Type 2508 according to DIN EN 175301-803 Form A

The delivery of a cable plug includes the ﬂ at seal and ﬁ xing screw

Electronic Control Type 8605

Please see separate Datasheet

Dimensions [mm]

Oriﬁ ce A B C E G H I

10.0G 3/8 or G 1/285.5 3.720.050.037.738.0

13.0G 1/2 or G 3/4106.2 3.324.058.044.550.5

20.0G 3/4 or G 1147.67.035.080.066.066.0

In case of special application conditions,

please consult for advice.

Subject to alteration.
