directx_jun10在VS2010下的配置

directx_jun10在VS2010下的配置

1、打开VS2010，新建控制台应用程序项目dx,如图：

2、右击dx,选择属性：

分别在VC++目录中的可执行文件、包含目录和库目录中添加（其中D:\Program Files (x86)\dxsdk_JUN10为安装dxsdk_jun10的安装路径）：

可执行文件：

D:\Program Files (x86)\dxsdk_JUN10\Utilities/Bin/x86;

包含目录：

D:\Program Files (x86)\dxsdk_JUN10\Include;

库目录：

D:\Program Files (x86)\dxsdk_JUN10\Lib/x86;

3、选择连接器中的输入：

正确链接所需要的lib文件，在”附加依赖项“那里添加：

d3dx9d.lib;

d3dx10d.lib;

d3d9.lib;

winmm.lib;

如果仍有链接问题，可能还缺少其他的lib文件，注意添加。4、实例验证

右击源文件，添加新建项dx.cpp：

将实例黏贴到dx.cpp中，F5运行即可：

#include

#include

usingnamespace std;

// Overload the "<<" operators so that we can use cout to // output D3DXVECTOR3 objects.

ostream&operator<<(ostream& os, D3DXVECTOR3&v)

{

os <<"("<< v.x <<", "<< v.y <<", "<< v.z <<")";

return os;

}

int main()

{

// Using constructor, D3DXVECTOR3(FLOAT x, FLOAT y, FLOAT z);

D3DXVECTOR3 u(1.0f, 2.0f, 3.0f);

// Using constructor, D3DXVECTOR3(CONST FLOAT *);

float x[3] = {-2.0f, 1.0f, -3.0f};

D3DXVECTOR3 v(x);

// Using constructor, D3DXVECTOR3() {};

D3DXVECTOR3 a, b, c, d, e;

// Vector addition: D3DXVECTOR3 operator +

a = u + v;

// Vector subtraction: D3DXVECTOR3 operator -

b = u - v;

// Scalar multiplication: D3DXVECTOR3 operator*

c = u * 10;

// ||u||

float L = D3DXVec3Length(&u);

//d = u / ||u||

D3DXVec3Normalize(&d, &u);

// s = u dotv

float s = D3DXVec3Dot(&u, &v);

// e = u xv

D3DXVec3Cross(&e, &u, &v);

cout <<"u = "<< u << endl;

cout <<"v = "<< v << endl;

cout <<"a = u + v = "<< a << endl;

cout <<"b = u - v = "<< b << endl;

cout <<"c = u * 10 = "<< c << endl;

cout <<"d = u / ||u|| = "<< d << endl;

cout <<"e = u x v = "<< e << endl;

cout <<"L = ||u|| = "<< L << endl;

cout <<"s = u.v = "<< s << endl;

return 0;

}

运行结果：

配置完成！
