申请CCC强制认证产品描述

内部载流部件的材料，镀层和尺寸是否相同(Whether different model types within this application are using theinternalcurrent-carrying partsof the samematerial,coatingand dimension):
申请CCC强制认证产品描述
(低压电器类)
Product Description ForChinaCompulsory Certification
(Low-voltage Products)
申请编号(Application No.)
申请人(Applicant)
地址(Applicant’s Address)
工厂编号(Factory’s Code)
生产厂(Factory)
地址(Factory’s Address)
产品名称(Name of Product)
转换开关电器(CB级)(TSE(Class CB))
型号(Model)
申请单位（印章）
Applicant’s seal here
企业自我声明1
(Applicant Declaration 1)
(通常指连接硬线的能力Capability for connecting with hardline)
最大导线截面(Max. cross-sectional area):，连接至接线端子最多根数(maxi. Number of wires):;
最小导线截面(Min. cross-sectional area):，连接至接线端子最多根数(min number of wires):
3)任何内配手操机构，其材料和物理特性是否相同:
(Whether different model types within this application are using any internal manual operator of the same material and physical characteristic):□是□否
Herein we solemnly declare: all the modes and trademarks of the above-applied product are strictly complied with the relevant laws, stipulations and governmental regulations. We will bear all the law liability in case of infringement of the modes and trademarks of other manufactures.
本企业在此郑重声明:本次申请中，我单位向指定检测机构提供的型号/规格为
的(产品名称)是由
(生产厂名称)于(生产厂地址)
完成最终装配和出厂检验。
本企业对提以上情况的真实性负责，否则由此引起任何事情由本企业将承担全部责任。
Herein we solemnly declare that the final assemble and routine tests of ________________ (product name) under ____________ (model type and specification) _______________ within this application are done by _______________ (factory name) in _________________________________ (factory address).We guarantee the truth of the above declaration; otherwise we are willing to assume any possible consequences.
b)对于热磁脱扣器，其确定电流额定值的脱扣元件的尺寸和材料(For TMTU, difference in different rating trip units' dimensions and sizes is acceptable);
注:a)接线端尺寸，只要电气间隙和爬电距离不减少(Difference in wireterminals' dimensions is acceptable, as long as electrical clearance and creepage distance are not reduced);
(7)外壳防护等级(IP):
(8)电磁兼容设备发射等级(Emission class of EMC equipment):□A级;□B级
(9)电源电压偏差和频率偏差(Voltage supply deviation and frequency supply deviation):
(10)触头转换时间(Contact transfer time):
转换动作时间(Operating transfer time):
返回转换时间(Return transfer time):
断电时间(包括延时时间)范围(Off time range(including time-delay)):
(11)接线端子连接导线能力(Terminals’wiring capability):
包括产品的主要组成部件,操作方式,安装方式,接线方式等，还包括以下内容:
For the main parts of the product, operation mode, installation mode and connection mode, etc., and the following information should be also submitted:
We are liable for the authenticity of all the documentation we submit for CCC approval. We will keep you informed in case of product changes by submitting product change report; otherwise we will bear responsibilities for all the consequences arising therefore.
6)除下面的a)、b)和c)中的差异，过电流脱扣装置的基本结构是否相同(Whether different model types within this application are usingthe overcurrent trip unit of the same basical structure, except the difference below):□是□否
2.主要技术参数(Main technical Parameter):
(1)使用类别(Utilization Category):
(2)额定冲击耐受电压Uimp:
(3)额定绝缘电压Ui:
(4)约定发热电流Ith:
(5)额定短路接通能力Icm (峰值Peak Value):
(6)额定短路分断能力Icn:
□是;□否
2)主触头的尺寸、材料、结构和连接方法是否相同
(Whether different model types within this application are using the main contacts of the same dimension, material, structure and connection type):□是□否
4)模压和绝缘材料是否相同(Whether different model types within this application are usingthe samemoldingmaterial and isolation material):□是□否
5)灭弧装置的的工作原理、材料和结构是否相同
注册商标(Trade Mark):
本企业在此郑重声明:上述申证产品所使用的型号和商标保证严格遵守国家有关法律法规和政府部门的有关规定。如有乱用、冒用其他企业产品的型号和商标导致侵权行为，本企业将对其后果承担全部法律责任。
本企业对提供所有与认证有关资料的真实性负责。如果本企业获证的产品有所变更，将及时提交产品变更报告，否则由此引起任何事情由本企业将承担全部责任。
1)产品型号及名称(Product’s Mode and Name):
转换控制器型号规格(Type/Model of TSE controller):
2)额定工作电压Ue:
3)额定工作电流Ie:
4)极数(Pole):
5)产品是否适用于隔离(Whether it is applicable for isolation):是(Yes);否(No)
(Whether different model types within this application are using the arc control device of the same operational principle, material and structure):□是□否
申证企业负责人(签名):
Applicant’s principal(signature)
日期(Date):
(企业盖章)
(Applicant’s seal here)
产品描述
(Product Description)
1.产品构成的描述及结构特点(结构概要说明):
Product’s composing and construction characteristics (brief description of the construction):
