基于12864的菜单设计

编写者:董新凯2011.7.20 仅供交流#include <hidef.h> /* for EnableInterrupts macro */#include "derivative.h" /* include peripheral declarations */#include "init.h"#define UINT8 unsigned char#define UINT16 unsigned int#define D_RS PTCD_PTCD4#define D_RW PTFD_PTFD4#define D_E PTCD_PTCD0#define D_L PTCD_PTCD1 //左右半屏选择#define D_R PTCD_PTCD2#define D_REST PTFD_PTFD5 //复位选择#define LED1 PTCD_PTCD5#define LED2 PTCD_PTCD6#define LED3 PTCD_PTCD7#define LED4 PTFD_PTFD6#define LED5 PTFD_PTFD3/******************菜单填充**************/# define FillType_Fill 0x01 //填充黑色# define FillType_Clear 0x00 //填充白色const UINT8 zimo[][32]={/*-- 文字: 菜0 --*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x04,0x04,0x44,0xC4,0x4F,0x44,0x44,0xC4,0x24,0x24,0x2F,0xB4,0x24,0x04,0x04,0x00, 0x40,0x44,0x24,0x24,0x15,0x0C,0x04,0xFE,0x04,0x0C,0x15,0x24,0x24,0x44,0x40,0x00, },/*-- 文字: 单 1 --*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x00,0x00,0xF8,0x49,0x4A,0x4C,0x48,0xF8,0x48,0x4C,0x4A,0x49,0xF8,0x00,0x00,0x00, 0x10,0x10,0x13,0x12,0x12,0x12,0x12,0xFF,0x12,0x12,0x12,0x12,0x13,0x10,0x10,0x00, },/*-- 文字: 一2--*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x80,0x00, 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00, },/*-- 文字: 二3--*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x00,0x00,0x08,0x08,0x08,0x08,0x08,0x08,0x08,0x08,0x08,0x08,0x08,0x00,0x00,0x00, 0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x10,0x00, },/*-- 文字: 三4--*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x00,0x04,0x84,0x84,0x84,0x84,0x84,0x84,0x84,0x84,0x84,0x84,0x84,0x04,0x00,0x00, 0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x20,0x00, },/*-- 文字: 四5--*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x00,0xFC,0x04,0x04,0x04,0xFC,0x04,0x04,0x04,0xFC,0x04,0x04,0x04,0xFC,0x00,0x00, 0x00,0x7F,0x28,0x24,0x23,0x20,0x20,0x20,0x20,0x21,0x22,0x22,0x22,0x7F,0x00,0x00, },/*-- 文字: 是6--*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x00,0x00,0x00,0x7F,0x49,0x49,0x49,0x49,0x49,0x49,0x49,0x7F,0x00,0x00,0x00,0x00, 0x81,0x41,0x21,0x1D,0x21,0x41,0x81,0xFF,0x89,0x89,0x89,0x89,0x89,0x81,0x81,0x00, },/*-- 文字: 否7--*//*-- 新宋体12; 此字体下对应的点阵为：宽x高=16x16 --*/{0x00,0x02,0x82,0x82,0x42,0x22,0x12,0xFA,0x06,0x22,0x22,0x42,0x42,0x82,0x00,0x00, 0x01,0x01,0x00,0xFC,0x44,0x44,0x44,0x45,0x44,0x44,0x44,0xFC,0x00,0x00,0x01,0x00, }};/******************************************/UINT8 Menu_word[][4]={{0,1,2},{0,1,3},{0,1,4},{0,1,5}} ;struct MenuItem{ //菜单结构UINT8 MenuCount;//菜单项所在层的菜单项数目UINT8 *DisplayString;//显示的名称void (*subs)(void);//所指向的功能函数UINT8 Local_x;UINT8 Local_y;//菜单的横纵起始坐标struct MenuItem *ChildrenMenu;//所指向的子菜单struct MenuItem *ParentMenu;//所指向的父菜单struct MenuItem *This;//Thi s指针指向本项菜单1行地址};/*****************************************/struct MenuItem MainMenu[4];struct MenuItem ChildMenu1[3];struct MenuItem ChildMenu2[3];struct MenuItem ChildMenu3[3];struct MenuItem ChildMenu4[3];struct MenuItem SubChildMenu1;struct MenuItem SubChildMenu2;struct MenuItem SubChildMenu3;/**********************************************************/ struct MenuItem *Menu_point=MainMenu;UINT8 key_number=0;UINT8 key_number_store=0;/**********************************************************/ void _12864_busycheck(void);void _12864_wr_cmd(UINT8 cmd);void _12864_clear_dot(UINT8 x,UINT8 y);void delay(UINT16 time){UINT16 i;for(i=0;i<time;i++);}/****************菜单初始化******************/ void MainMenu_init(void){MainMenu[0].MenuCount=4;MainMenu[0].DisplayString=&Menu_word[0][0];MainMenu[0].subs=NULL;MainMenu[0].Local_x=5;MainMenu[0].Local_y=16;MainMenu[0].ChildrenMenu=ChildMenu1;MainMenu[0].ParentMenu=NULL;MainMenu[0].This=MainMenu;MainMenu[1].MenuCount=4;MainMenu[1].DisplayString=&Menu_word[1][0];MainMenu[1].subs=NULL;MainMenu[1].Local_x=5;MainMenu[1].Local_y=16;MainMenu[1].ChildrenMenu=ChildMenu2;MainMenu[1].ParentMenu=NULL;MainMenu[1].This=MainMenu;MainMenu[2].MenuCount=4;MainMenu[2].DisplayString=&Menu_word[2][0];MainMenu[2].subs=NULL;MainMenu[2].Local_x=5;MainMenu[2].Local_y=16;MainMenu[2].ChildrenMenu=ChildMenu3;MainMenu[2].ParentMenu=NULL;MainMenu[2].This=MainMenu;MainMenu[3].MenuCount=4;MainMenu[3].DisplayString=&Menu_word[3][0];MainMenu[3].subs=NULL;MainMenu[3].Local_x=5;MainMenu[3].Local_y=16;MainMenu[3].ChildrenMenu=ChildMenu4;MainMenu[3].ParentMenu=NULL;MainMenu[3].This=MainMenu;}void ChildMenu1_init(void){ChildMenu1[0].MenuCount=3;ChildMenu1[0].DisplayString=&Menu_word[0][0];ChildMenu1[0].subs=NULL;ChildMenu1[0].Local_x=43;ChildMenu1[0].Local_y=0;ChildMenu1[0].ChildrenMenu=&SubChildMenu1;ChildMenu1[0].ParentMenu=MainMenu;ChildMenu1[0].This=ChildMenu1;ChildMenu1[1].MenuCount=3;ChildMenu1[1].DisplayString=&Menu_word[1][0];ChildMenu1[1].subs=NULL;ChildMenu1[1].Local_x=43;ChildMenu1[1].Local_y=0;ChildMenu1[1].ChildrenMenu=&SubChildMenu2;ChildMenu1[1].ParentMenu=MainMenu;ChildMenu1[1].This=ChildMenu1;ChildMenu1[2].MenuCount=3;ChildMenu1[2].DisplayString=&Menu_word[2][0];ChildMenu1[2].subs=NULL;ChildMenu1[2].Local_x=43;ChildMenu1[2].Local_y=0;ChildMenu1[2].ChildrenMenu=&SubChildMenu3;ChildMenu1[2].ParentMenu=MainMenu;ChildMenu1[2].This=ChildMenu1;}void ChildMenu2_init(void){ChildMenu2[0].MenuCount=3;ChildMenu2[0].DisplayString=&Menu_word[0][0];ChildMenu2[0].subs=NULL;ChildMenu2[0].Local_x=43;ChildMenu2[0].Local_y=16;ChildMenu2[0].ChildrenMenu=&SubChildMenu1;ChildMenu2[0].ParentMenu=MainMenu;ChildMenu2[0].This=ChildMenu2;ChildMenu2[1].MenuCount=3;ChildMenu2[1].DisplayString=&Menu_word[1][0];ChildMenu2[1].subs=NULL;ChildMenu2[1].Local_x=43;ChildMenu2[1].Local_y=16;ChildMenu2[1].ChildrenMenu=&SubChildMenu2;ChildMenu2[1].ParentMenu=MainMenu;ChildMenu2[1].This=ChildMenu2;ChildMenu2[2].MenuCount=3;ChildMenu2[2].DisplayString=&Menu_word[2][0];ChildMenu2[2].subs=NULL;ChildMenu2[2].Local_x=43;ChildMenu2[2].Local_y=16;ChildMenu2[2].ChildrenMenu=&SubChildMenu3;ChildMenu2[2].ParentMenu=MainMenu;ChildMenu2[2].This=ChildMenu2;}void ChildMenu3_init(void){ChildMenu3[0].MenuCount=3;ChildMenu3[0].DisplayString=&Menu_word[0][0];ChildMenu3[0].subs=NULL;ChildMenu3[0].Local_x=43;ChildMenu3[0].Local_y=0;ChildMenu3[0].ChildrenMenu=&SubChildMenu1;ChildMenu3[0].ParentMenu=MainMenu;ChildMenu3[0].This=ChildMenu3;ChildMenu3[1].MenuCount=3;ChildMenu3[1].DisplayString=&Menu_word[1][0];ChildMenu3[1].subs=NULL;ChildMenu3[1].Local_x=43;ChildMenu3[1].Local_y=0;ChildMenu3[1].ChildrenMenu=&SubChildMenu2;ChildMenu3[1].ParentMenu=MainMenu;ChildMenu3[1].This=ChildMenu3;ChildMenu3[2].MenuCount=3;ChildMenu3[2].DisplayString=&Menu_word[2][0];ChildMenu3[2].subs=NULL;ChildMenu3[2].Local_x=43;ChildMenu3[2].Local_y=0;ChildMenu3[2].ChildrenMenu=&SubChildMenu3;ChildMenu3[2].ParentMenu=MainMenu;ChildMenu3[2].This=ChildMenu3;}void ChildMenu4_init(void){ChildMenu4[0].MenuCount=3;ChildMenu4[0].DisplayString=&Menu_word[0][0];ChildMenu4[0].subs=NULL;ChildMenu4[0].Local_x=43;ChildMenu4[0].Local_y=16;ChildMenu4[0].ChildrenMenu=&SubChildMenu1;ChildMenu4[0].ParentMenu=MainMenu;ChildMenu4[0].This=ChildMenu4;ChildMenu4[1].MenuCount=3;ChildMenu4[1].DisplayString=&Menu_word[1][0];ChildMenu4[1].subs=NULL;ChildMenu4[1].Local_x=43;ChildMenu4[1].Local_y=16;ChildMenu4[1].ChildrenMenu=&SubChildMenu2;ChildMenu4[1].ParentMenu=MainMenu;ChildMenu4[1].This=ChildMenu4;ChildMenu4[2].MenuCount=3;ChildMenu4[2].DisplayString=&Menu_word[2][0];ChildMenu4[2].subs=NULL;ChildMenu4[2].Local_x=43;ChildMenu4[2].Local_y=16;ChildMenu4[2].ChildrenMenu=&SubChildMenu3;ChildMenu4[2].ParentMenu=MainMenu;ChildMenu4[2].This=ChildMenu4;}void SubChildMenu1_init(void){SubChildMenu1.MenuCount=1;SubChildMenu1.DisplayString=&Menu_word[0][0];SubChildMenu1.subs=NULL;SubChildMenu1.Local_x=79;SubChildMenu1.Local_y=0;SubChildMenu1.ChildrenMenu=NULL;SubChildMenu1.ParentMenu=ChildMenu1;SubChildMenu1.This=&SubChildMenu1;SubChildMenu2.MenuCount=1;SubChildMenu2.DisplayString=&Menu_word[0][0];SubChildMenu2.subs=NULL;SubChildMenu2.Local_x=79;SubChildMenu2.Local_y=16;SubChildMenu2.ChildrenMenu=NULL;SubChildMenu2.ParentMenu=ChildMenu1;SubChildMenu2.This=&SubChildMenu2;SubChildMenu3.MenuCount=1;SubChildMenu3.DisplayString=&Menu_word[0][0];SubChildMenu3.subs=NULL;SubChildMenu3.Local_x=79;SubChildMenu3.Local_y=32;SubChildMenu3.ChildrenMenu=NULL;SubChildMenu3.ParentMenu=ChildMenu1;SubChildMenu3.This=&SubChildMenu3;}/*****************键盘*******************/ UINT8 keyscan(void){UINT8 i,j,temp;PTFD|=0x07; //PTF xxxx x111for(i=0;i<3;i++){PTFD &= ~(1<<i);temp=0x04;for(j=0;j<3;j++){if(!(PTGD&temp)){delay(10);if(!(PTGD&temp)){return (i*3+j+1);}}temp <<= 1;}PTFD|=0x07;}return 0;}/****************读状态*******************/ UINT8 _12864_rd_stat(void){UINT8 volatile temp;PTBDD=0X00;D_RS=0;D_RW=1;D_E=1;delay(1);temp=PTBD;delay(1);D_E=0;return temp;}/*******************读数据******************/UINT8 _12864_rd_data(UINT8 page,UINT8 colum,UINT8 D_LorR) {UINT8 volatile data;_12864_busycheck();if(D_LorR){D_L=0;D_R=1;}else{D_L=1;D_R=0;}_12864_wr_cmd(0xb8+page);_12864_wr_cmd(0x40+colum);PTBDD=0X00;D_RS=1;D_RW=1;D_E=1;delay(5);data=PTBD;delay(10);D_E=0;return data;}/*******************忙检测**********************/void _12864_busycheck(void){PTBDD=0x00;D_RS=0;D_RW=1;D_E=1;while(_12864_rd_stat()==0x80);D_E=0;}/****************写指令********************/void _12864_wr_cmd(UINT8 cmd){_12864_busycheck();PTBDD=0XFF;D_RS=0;D_RW=0;D_E=1;delay(10);PTBD=cmd;delay(10);D_E=0;}/*****************写数据*****************/void _12864_wr_data(UINT8 page,UINT8 colum,UINT8 D_LorR,UINT8 data) {_12864_busycheck();if(D_LorR){D_L=0;D_R=1;}else{D_L=1;D_R=0;}_12864_wr_cmd(0xb8+page);_12864_wr_cmd(0x40+colum);PTBDD=0XFF;D_RS=1;D_RW=0;D_E=1;delay(5);PTBD=data;delay(10);D_E=0;}void _12864_wr_data_notclear(UINT8 page,UINT8 colum,UINT8 D_LorR,UINT8 data) {UINT8 temp;_12864_busycheck();if(D_LorR){D_L=0;D_R=1;}else{D_L=1;D_R=0;}(void)_12864_rd_data(page,colum,D_LorR);temp=_12864_rd_data(page,colum,D_LorR);data=data|temp;_12864_wr_cmd(0xb8+page);_12864_wr_cmd(0x40+colum);PTBDD=0XFF;D_RS=1;D_RW=0;D_E=1;delay(5);PTBD=data;delay(10);D_E=0;}/*****************清屏********************/void _12864_clear_lcdall(void){UINT8 i,j;for(i=0;i<8;i++){for(j=0;j<64;j++){_12864_wr_data(i,j,0,0x00);_12864_wr_data(i,j,1,0x00);}}}void _12864_clear_lcd(UINT8 xbegin,UINT8 ybegin,UINT8 xend,UINT8 yend) {UINT8 x,y,pages,pagee,D_LorR,temp;if(xbegin>=xend){temp=xbegin;xbegin=xend;xend=temp;}if(ybegin>=yend){temp=ybegin;ybegin=yend;yend=temp;}if(xend>127)xend=127;if(yend>63)yend=63;pages=ybegin>>3;pagee=yend>>3;for(x=pages;x<=pagee;x++){for(y=xbegin;y<=xend;y++){if(y>63){D_LorR=1;_12864_wr_data(x,y-64,D_LorR,0x00);}else{D_LorR=0;_12864_wr_data(x,y,D_LorR,0x00);}}}}/*****************清除一个点******************/void _12864_clear_dot(UINT8 x,UINT8 y){UINT8 page,row;UINT8 data;if(x<=63){page=y/8;row=y%8;(void)_12864_rd_data(page,x,0);data=_12864_rd_data(page,x,0);data=data&(~(0x01<<row));_12864_wr_data(page,x,0,data);}else{page=y/8;row=y%8;(void)_12864_rd_data(page,x-64,1);data=_12864_rd_data(page,x-64,1);data=data&(~(0x01<<row));_12864_wr_data(page,x-64,1,data);}}/**********************画一个点*********************/ void _12864_write_dot(UINT8 x,UINT8 y){UINT8 page,row;volatile UINT8 data;if(x<=63){page=y/8;row=y%8;delay(5);(void)_12864_rd_data(page,x,0);data=_12864_rd_data(page,x,0);data=data|(0x01<<row);_12864_wr_data(page,x,0,data);}else{page=y/8;row=y%8;delay(5);(void)_12864_rd_data(page,x-64,1);data=_12864_rd_data(page,x-64,1);data=data|(0x01<<row);_12864_wr_data(page,x-64,1,data);}}/*****************初始化*********************/void _12864_init(void){D_REST=1;D_L=1;D_R=1;_12864_wr_cmd(0xc0);_12864_wr_cmd(0x3f);}/******************io封装*****************/void io_keyscan(void){PTGPE=0x1c;PTFDD=0xff;}void io_12864(void){PTBDD=0XFF;PTCDD_PTCDD0=1;PTCDD_PTCDD1=1;PTCDD_PTCDD2=1;PTCDD_PTCDD4=1;PTFDD_PTFDD4=1;PTFDD_PTFDD5=1;}/******************画线函数****************/void _12864_glibline(UINT8 x1,UINT8 y1,UINT8 x2,UINT8 y2) {int dx,dy,sub;dx=x2-x1;dy=y2-y1;if(dx>=0){if(dy>=0){if(dx>=dy)//1/8{sub=2*dy-dx;while(x1<x2){_12864_write_dot(x1,y1);if(sub>0){y1+=1;sub+=(dy-dx)*2;}else{sub+=2*dy;}x1+=1;}}else //2/8{sub=2*dx-dy;while(y1<y2){_12864_write_dot(x1,y1);if(sub>0){x1+=1;sub+=(dx-dy)*2;}else{sub+=2*dx;}y1+=1;}}}else{dy=-dy;if(dx>=dy){sub=2*dy-dx;while(x1<x2){_12864_write_dot(x1,y1);if(sub>0){y1-=1;sub+=(dy-dx)*2;}else{sub+=2*dy;}x1+=1;}}else{sub=2*dx-dy;while(y1>y2){_12864_write_dot(x1,y1);if(sub>0){x1+=1;sub+=(dx-dy)*2;}else{sub+=dx*2;}y1-=1;}}}}else{dx=-dx;if(dy>0){if(dx>dy){sub=2*dy-dx;while(x1>x2){_12864_write_dot(x1,y1);if(sub>0){y1+=1;sub+=(dy-dx)*2;}else{sub+=2*dy;}x1-=1;}}else{sub=2*dx-dy;while(y1<y2){_12864_write_dot(x1,y1);if(sub>0){x1-=1;sub+=(dx-dy)*2;}else{sub+=dx*2;}y1+=1;}}}else{dy=-dy;if(dx>dy){sub=2*dy-dx;while(x1>x2){_12864_write_dot(x1,y1);if(sub>0){y1-=1;sub+=(dy-dx)*2;}else{sub+=dy*2;}}}else{sub=2*dx-dy;while(y1>y2){_12864_write_dot(x1,y1);if(sub>0){x1-=1;sub+=(dx-dy)*2;}else{sub+=2*dx;}y1-=1;}}}}}/********************写16*16点阵的汉字函数*********************///参数page汉字开始的页数，colum汉字开始的列数//字符代码编号//CorN是否是带擦除的写入方式1为不擦除，0为擦除void write_word_16_16(UINT8 page,UINT8 colum,UINT8 word_num,UINT8 CorN,UINT8 filltype){UINT8 i,D_LorR,colum_temp;if(filltype==FillType_Fill){if(CorN==1){for(i=0;i<8;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data_notclear(page,colum_temp,D_LorR,zimo[word_num][i]);}for(i=16;i<24;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data_notclear(page+1,colum_temp,D_LorR,zimo[word_num][i]);}for(i=8;i<16;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data_notclear(page,colum_temp,D_LorR,zimo[word_num][i]);}for(i=24;i<32;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data_notclear(page+1,colum_temp,D_LorR,zimo[word_num][i]);}}else{for(i=0;i<8;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data(page,colum_temp,D_LorR,zimo[word_num][i]);}for(i=16;i<24;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data(page+1,colum_temp,D_LorR,zimo[word_num][i]);}for(i=8;i<16;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data(page,colum_temp,D_LorR,zimo[word_num][i]);}for(i=24;i<32;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data(page+1,colum_temp,D_LorR,zimo[word_num][i]);}}}else{if(CorN==1){for(i=0;i<8;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data_notclear(page,colum_temp,D_LorR,~zimo[word_num][i]);}for(i=16;i<24;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data_notclear(page+1,colum_temp,D_LorR,~zimo[word_num][i]);}for(i=8;i<16;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data_notclear(page,colum_temp,D_LorR,~zimo[word_num][i]);}for(i=24;i<32;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data_notclear(page+1,colum_temp,D_LorR,~zimo[word_num][i]);}}else{for(i=0;i<8;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data(page,colum_temp,D_LorR,~zimo[word_num][i]);}for(i=16;i<24;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data(page+1,colum_temp,D_LorR,~zimo[word_num][i]);}for(i=8;i<16;i++){D_LorR=0;colum_temp=colum+i;if((colum+i)>63){colum_temp=colum-64+i;D_LorR=1;}_12864_wr_data(page,colum_temp,D_LorR,~zimo[word_num][i]);}for(i=24;i<32;i++){D_LorR=0;colum_temp=colum+i-16;if((colum+i-16)>63){colum_temp=colum-64+i-16;D_LorR=1;}_12864_wr_data(page+1,colum_temp,D_LorR,~zimo[word_num][i]);}}}}/********************编写16*16点阵字符串显示函数******************************/ //参数string是字符编号数组的首地址void write_string_16_16(UINT8 page,UINT8 colum,UINT8 *string,UINT8 number,UINT8 CorN,UINT8 filltype){UINT8 i;for(i=0;i<number;i++){write_word_16_16(page,colum+(i<<4),*(string+i),CorN,filltype);}}/****************************************************************************** ******//*************************填充函数****************************/void fill_rectangle(UINT8 xbegin,UINT8 ybegin,UINT8 xend,UINT8 yend){UINT8 x;for(x=xbegin;x<=xend;x++){_12864_glibline(x,ybegin,x,yend);}}/*******************菜单函数*******************///功能:编译出一个菜单可视化图形界面//具有填充,反相功能//struct MenuItem//{ //菜单结构// UINT8 MenuCount;//菜单项所在层的菜单项数目// UINT8 *DisplayString;//显示的名称// void (*subs)(void);//所指向的功能函数// struct MenuItem *ChildrenMenu;//所指向的子菜单// struct MenuItem *ParentMenu;//所指向的父菜单//};void MenuBox(UINT8 xbegin,UINT8 ybegin)/*Xbegin 方框左上角横坐标Ybegin 方框左上角纵坐标Xend 方框右下角横坐标Y end 方框右下角纵坐标*/{UINT8 page,num,xend,yend;struct MenuItem *Menu_point_temp;Menu_point_temp=Menu_point;xend=xbegin+16*3;yend=ybegin+Menu_point->MenuCount*16-1;if(yend>63)yend=63;Menu_point=Menu_point->This;//指向本项菜单的首位地址page=ybegin>>3;_12864_clear_lcd(xbegin,ybegin,xend,yend);_12864_glibline(xbegin,ybegin,xend,ybegin);_12864_glibline(xbegin,ybegin,xbegin,yend);_12864_glibline(xbegin,yend,xend,yend);_12864_glibline(xend,ybegin,xend,yend);for(num=0;num<Menu_point->MenuCount;num++){if(page>7)continue;if(Menu_point==Menu_point_temp){if(key_number!=0){write_string_16_16(page,xbegin,Menu_point->DisplayString,3,1,0);}else{write_string_16_16(page,xbegin,Menu_point->DisplayString,3,1,1);}}else{write_string_16_16(page,xbegin,Menu_point->DisplayString,3,1,1);}Menu_point++;page+=2;}Menu_point=Menu_point_temp;}/******************主函数*******************/void main(void){PLL_init(16);io_12864();io_keyscan();_12864_init();_12864_clear_lcdall();MainMenu_init();ChildMenu1_init();ChildMenu2_init();ChildMenu3_init();ChildMenu4_init();SubChildMenu1_init();/* _12864_glibline(0,0,0,63);_12864_glibline(0,0,63,0);_12864_glibline(63,0,63,63);_12864_glibline(0,63,63,63);write_word_16_16(1,60,1,0,0); */MenuBox(Menu_point->Local_x,Menu_point->Local_y);// MenuBox(65,16);// write_string_16_16(0,40,Menu_point->DisplayString,3,0,0);// write_string_16_16(2,40,&Menu_word[0][0],3,0,0);for(;;){switch(keyscan()){case 1: //DOWM下翻页key_number++;if(key_number>Menu_point->MenuCount){key_number=1;Menu_point=Menu_point->This;}Menu_point=Menu_point->This+key_number-1;MenuBox(Menu_point->Local_x,Menu_point->Local_y);break;case 6:key_number--;if(key_number==0){key_number=Menu_point->MenuCount;}Menu_point=Menu_point->This+key_number-1;MenuBox(Menu_point->Local_x,Menu_point->Local_y);break;case 5://enterif(Menu_point->ChildrenMenu!=NULL){Menu_point=Menu_point->ChildrenMenu;key_number_store=key_number;key_number=0;MenuBox(Menu_point->Local_x,Menu_point->Local_y);}else if(Menu_point->subs!=NULL){(*Menu_point->subs)();}break;case 9://escif(Menu_point->ParentMenu!=NULL){_12864_clear_lcd(Menu_point->Local_x,Menu_point->Local_y,(Menu_point->Local_x+16*3),(Menu_point->Local_y+16*Menu_point->MenuCount-1));key_number=key_number_store;Menu_point=Menu_point->ParentMenu+key_number-1;MenuBox(Menu_point->Local_x,Menu_point->Local_y);}break;}}}。
