叼纸牙
常用模切词汇
模切----Die cutting
刀具---tool
平刀---Flatbed die
圆刀---Rotary die
精度---precision
公差---tolerance
圆刀模切---Rotary die cutting
平刀模切---Flatbed die cutting
激光模切---Laser die cutting
刀座---station
冲压---stamping
印刷---printing
喷漆---painting
镀金属(法)---metallization
数码装饰(法)---digital decoration
碾压,层压---laminate
分切---slit
装配---Assembly
嵌缝材料---Joint material
保护膜---Protective Film
粘结胶带---Bonding Adhesive Tape
单面胶带---single-sided adhesive tape
双面胶带---Double-coated Adhesive Tape
防尘网---Dustproof Mesh
泡棉---Foam
金属箔膜---Metal foil film
空间填补---Space Filling
网孔冲压---Mesh Stamping
按键板---Key Plate
金属冲压件---Metal Punching Part
塑胶薄膜类---Plastic Film
低粘性保护膜---Low-adhesive protective film 静电---static
厚度---thickness
密度---density
定制---customize
基材---carrier
硬度---rigidity
透明色---transparent color
Glassine liner-----格钠辛底纸
paper liner----纸离型膜Ployester liner-----PET离型膜Vacume die--真空刀
Strip bar---剥刀
Nip roller--胶辊
Relaese tab---小耳朵
Die cut----模切
Flatbed die---平刀
Rotary Die---圆刀
Kiss cutting--半切
Through cutting--全切
ID slug---内框废料
Waste matrix---外框废料
Thermal bonding film-----热溶胶Polyester film----PET 膜Release liner---离型模
Fine-tuning----微调
Bi-level die----双层刀
Stee rule die----平板刀
Etch Die----蚀刻刀
Male/femal die----公母模Engraving die----雕刻模
Seek Pin---套位针
Tension---张力
Torque---扭力
Slitting----分切
Rewind----收料
Unwind----放料。
