PHOTO-2000μ微光照度计和微光照度计价格

PHOTO-2000μ微光照度计和微光照度计价格PHOTO-2000μ微光照度计标题：PHOTO-2000μ微光照度计主要用于10-3lx以下的微弱光测试。

国际领先的微光检测技术，微光探测能力可达10-8lx。

技术特性：1、测量微光照度，国际领先的微光检测技术；2、测量范围：1.0×10-6lx～2.000lx 或1.0×10-8lx~100mlx；3、精度等级：一级；4、多量程自动切换；5、国家一级（CLASS B）探头修正水平；6、用户可通过键盘定标，校零；7、RS-232/RS-485串行通讯。

...厂家：南北仪器市场价格：优惠价格：百度搜索联系UV2000Z紫外红斑效应辐照度计标题：UV2000Z紫外红斑效应辐照度计产品简介：太阳光和某些光源中的紫外线会导致人体皮肤出现红斑和色等沉积，严重的还会导致皮肤癌，UV2000红斑效应紫外辐照度计主要用于太阳光紫外指数（UVI）、红斑效应紫外辐照度（μ W/cm2）、标准红斑剂量（SED）的测量和光源与灯具的紫外辐射安全性评测，满足CIE和ISO关于人体皮肤对紫外红斑效应响应的有关标准要求。

技术特性：1、测量范围：0.1μW/cm2～2×105μW/cm2自动量程；2、四档十倍关系量程自动切换；3、精度等级：一级；4、四位半A/D转换精度，五位数码管显示；5、用户可通过键盘定标、校零；6、探头相对光谱灵敏度曲线符合皮肤红斑效应响应标准曲线CIE1987 M-D curve Ser(λ)，测试精度高，稳定性曲线；7、配有 ...厂家：南北仪器市场价格：优惠价格：百度搜索联系UV-2000袖珍式紫外辐照度计标题：UV-2000袖珍式紫外辐照度计UV-2000 袖珍式紫外辐照度计(也称紫外照度计、UV能量计、UV照度计)专为紫外辐射照度测试而设计，满足各项国际和国内标准。
