润普专业电话录音系统使用说明书
PowerRec 数字录音系统 4_使用
PowerRec®数字录音系统 4.0PowerRec®数字录音系统用户手册发布版本 4.0Website: Technical support: xxx@ Sales: xxx@版权根据《中华人民共和国著作权法》和《中华人民共和国计算机软件保护条例》等法律条款，杭州三汇软件有限公司享有该软件的发表权、复制权、发行权、出租权和信息网络传播权。
任何单位或个人若没有得到杭州三汇软件有限公司明确的书面准许(授权),不得对该软件进行署名、发表、修改、使用、复制和传播。
更改为提高软件执行性能，可操作性或稳定性而做的更改，杭州三汇软件有限公司将继续提供服务。
任何杭州三汇软件有限公司关于此产品的重新发布声明都将是准确的，但是杭州三汇软件有限公司对侵权行为将不承担任何义务。
商标PowerRec® 归杭州三汇软件有限公司所有。
Windows 和windows NT/98SE/2000/XP归微软公司所有。
其它商标或注册商标归相关公司所有。
杭州三汇软件有限公司中国浙江省杭州市文二路385号汽轮大厦10楼文档目录I、介绍-----------------------------------------------------------------------------------------------5i、PowerRec 数字录音系统 4.0 录音方案简介----------------------------------------------5A、模拟线高阻复接录音-------------------------------------------------------------------5B、现场语音采集录音---------------------------------------------------------------------5C、数字中继监听录音---------------------------------------------------------------------6 II、关于本手册------------------------------------------------------------------------------------7 III、PowerRec 数字录音系统的使用---------------------------------------------------------8i、PowerRec 数字录音系统–服务器---------------------------------------------------------8A、硬件配置--------------------------------------------------------------------------------8B、程序注册-------------------------------------------------------------------------------10C、权限管理-------------------------------------------------------------------------------11a、权限设置主界面------------------------------------------------------------------11b、权限管理程序的菜单-------------------------------------------------------------111、文件菜单--------------------------------------------------------------------112、数据菜单--------------------------------------------------------------------122.1更改密码--------------------------------------------------------------122.2新增公司--------------------------------------------------------------132.3新增部门--------------------------------------------------------------132.4新增账户--------------------------------------------------------------142.5新增权限组------------------------------------------------------------142.6编辑--------------------------------------------------------------------152.7删除--------------------------------------------------------------------152.8更新--------------------------------------------------------------------153、视图菜单--------------------------------------------------------------------154、窗口菜单--------------------------------------------------------------------16c、工具栏介绍-----------------------------------------------------------------------17D、卸载PowerRec数字录音系统------------------------------------------------------18ii、PowerRec 数字录音系统–录音监控-----------------------------------------------------19A、监控管理------------------------------------------------------------------------------19B、录音监控------------------------------------------------------------------------------21a、界面功能概述--------------------------------------------------------------------21b、文件列表视图主界面------------------------------------------------------------24c、日志浏览视图主界面------------------------------------------------------------25d、菜单命令说明--------------------------------------------------------------------251、文件菜单--------------------------------------------------------------------251.1 登入-------------------------------------------------------------------261.2 登出-------------------------------------------------------------------261.3 更改监控服务器-----------------------------------------------------261.4 查看日志-------------------------------------------------------------261.5 查询-------------------------------------------------------------------271.6 删除-------------------------------------------------------------------301.7 备份-------------------------------------------------------------------301.8 转录-------------------------------------------------------------------311.9 发送到----------------------------------------------------------------321.10 通话清单------------------------------------------------------------321.11 话量统计------------------------------------------------------------332、设置菜单--------------------------------------------------------------------342.1 系统属性-------------------------------------------------------------352.2 录音卡属性-----------------------------------------------------------362.3 通道属性设置-------------------------------------------------------362.4 工作路径-------------------------------------------------------------372.5 备份设备-------------------------------------------------------------382.6 文档分类-------------------------------------------------------------392.7 断线告警-------------------------------------------------------------402.8 服务器时间与本机时间同步----------------------------------------402.9 更改密码-------------------------------------------------------------403、视图菜单-------------------------------------------------------------------40e、工具栏介绍-----------------------------------------------------------------------42C、日志管理-------------------------------------------------------------------------------43D、硬件配置------------------------------------------------------------------------------45E、卸载PowerRec数字录音系统---------------------------------------------------------45F、注册表简介----------------------------------------------------------------------------45 I V、常见问题(FAQ) --------------------------------------------------------------------------------46I、介绍欢迎使用PowerRec 数字录音系统 4.0PowerRec 数字录音系统 4.0 具有安装设置简单化，操作使用人性化，配置管理智能化，输入输出多样化的特点。
通话录音的配置及使用说明
通话录音的配置及使用说明版本:<1.1>发布日期:<2018-5-11>目录目录 (1)1介绍...............................................................................................................错误！未定义书签。
1.1概述 (2)1.2适用型号 (2)1.3目标受众 (2)2录音框架介绍 (3)2.1通话录音方案架构 (3)3通话录音功能模块介绍 (4)3.1本地录音 (4)3.2服务器录音 (4)3.3服务停止/播放 (5)4通话录音功能使用介绍 (6)4.1本地录音 (6)4.2服务器录音 (7)11介绍1.1概述话机在通话过程中，可以启用录音服务保存通话录音。
配置有两种方式保存录音：1)将rtp数据存储成指定格式文件保存在本地。
2)将录音的rtp数据传送给服务器，在服务器上保存成文件格式。
1.2适用型号本文档适用于Fanvil X3S、X4、X5S、X6、X7、X7C、X210、X210i、XU系列等型号1.3目标受众此文档是针对那些想了解录音功能是如何改进的公司内部研发或者测试人员。
22录音框架介绍2.1通话录音方案架构创建本地stream，和要录音的stream进行混音处理，本地的stream只接收。
通过本地stream，可以本地绑定端口，接收stream上经过混音处理的rtp数据，再讲rtp数据写入本地文件保存或发送给服务器保存。
33通话录音功能模块介绍3.1本地录音本地录音只有挂载U盘才可以支持录音，获取到U盘挂载点后对U盘可用容量进行检查，创建文件保存rtp数据，文件名以“Record_当前系统时间”命名。
如果开启本地录音文件大小限制，录音文件达到限制值且U盘有可用容量会创建新的录音文件继续保存rtp 数据。
录音过程中可暂停、恢复通话录音。
TMPRO 880专业音频会议系统产品说明书
THE CLEAR CHOICE FOR PROFESSIONAL AUDIO CONFERENCING CONVERGE TM PRO 880APPLICATIONSConference RoomsBoardroomsCourtroomsDistance Learning FacilitiesConvention Centers and HotelsTraining RoomsTelemedicine FacilitiesHouses of WorshipCONVERGE TM PRO 880 ADVANTAGESAdvanced Conferencing Feature Set+Next-generation Acoustical Echo Cancellation> Full bandwidth (20Hz to 22Khz) echo cancellation> Improved duplex performance> Push-to-talk microphone compatibility+Next-generation Noise Cancellation> Adaptive modeling to room ambient noise condition+Increased resolution on Microphone Preamp stage> 0-56 dB in 7 dB increments+Pre-AEC routing for Sound Reinforcement Applications> Maximum of 4 millisecond processing delay+Management Improvements> Integrated Ethernet and USB connections> SNMP and HTML remote management agents> Event scheduler> Diagnostic console+Simplified Configuration Software> Drag & drop A/V and channel objects> Selectable views—unit, matrix, channel+Expanded Serial Command ListSuperior Audio Performance+Next-generation Distributed Echo Cancellation®on every mic input+First-mic priority delivers clear audio to the far end+20 Hz-22 kHz bandwidth for full-range audio response+ALC & AGC keep participants’ audio balanced and consistentConfiguration Flexibility+Scalable – link multiple Converge Pro units (880, 840T, 8I, TH20) for extensive microphonecoverage and up to 16 phone lines+Enhanced expansion bus, featuring 12 mix-minus audio buses for routing between units+Eight mic gating groups (four internal & four global) allow separation of mics intoindividual mixer gating groups for greater configuration flexibility+32 presets can be executed on-the-fly without disturbing other ongoing preset operations+255 Macros for customized audio control/configuration with single command execution Professional Conferencing SystemPROFESSIONAL CONFERENCINGDATA SHEET < CONVERGE TM PRO|880>SPECIFICATIONSCONVERGE PRO 880DATA SHEET <>CLEARONE LOCATIONS>CONVERGE PRO 880 BACK PANELAudio PerformanceConditions: Unless otherwise specified, allmeasurements are performed with a 20 Hz to 22 kHz BW limit (no weighting)Frequency Response: 20 Hz to 22 kHz ±1dB Noise (EIN): -126 dBu, 20 kHz BW, max gain,Rs=150 ΩTHD+N: <0.02%Dynamic Range: 100 dB (non A-weighted)Crosstalk <-91 dB re 20 dBu @ 20 kHz channelto channel Auto Mixer ParametersNumber of Open Microphones (NOM)PA Adaptive Mode First Mic Priority Mode Last Mic ModeMaximum # of Mics Mode Ambient LevelGate Threshold Adjust Off Attenuation Adjust Hold Time Decay RateMatrix Mixing Parameters 36x36 matrix 12 analog in/out12 expansion bus in/out8 assignable processing blocks in/out 4 assignable fader blocks in/out Assignable Processing Blocks Filters:All pass Low pass High pass Low shelving High shelving Parametric EQ Notch CD Horn Crossovers:BesselButterworth Linkwitz-Riley CompressorDelay; adjustable up to 250 msAssignable Fader Blocks Gain/MuteMicrophone Input Configuration Input Gain Adjust Mic or Line LevelPhantom Power on/off Echo Cancellation on/off Noise Cancellation on/off Filters:All Pass Low Pass High Pass Notch PEQMute on/offChairman Override on/off AGC on/offAutomatic Level Control on/off Auto Gate/Manual gate Adaptive Ambient on/off Pre AEC channelMic/Line Inputs 1-8Push-on mini-terminal block, balanced,bridgingImpedance: < 5 KΩNominal Level: adjustable -56 dBu to 0 dBu (7dB step coarse gain adjustment)Maximum Level: -65 dBu to +20 dBuEcho Cancellation: 130 ms tail time (works with 12 dB of room gain)Noise Cancellation: 6–15 dB attenuation Phantom Power: 24 V , selectable Line Inputs 9-12Push-on mini-terminal block, balanced,bridgingImpedance: < 5 KΩNominal Level: 0 dBu Maximum Level: 20 dBuOutputs 1-12Push-on mini-terminal block, balanced Impedance: < 50 ΩNominal Level: 0 dBu Maximum Level: 20 dBuExpansion Bus In/Out Proprietary Network RJ-45 (2), 1.9 MbpsCategory 5 twisted-pair cable, 200’ maximum cable length between any two Converge Pro devicesEthernetAutoswitching with Quality of Connection (QoC)10/100 Mbps Ethernet Network Port 10/100 Mbps Ethernet PC Port RJ-45 ConnectorsRS-232Serial Command Protocol Only (Console software not supported on RS- 232 port)DB-9 female9,600/19,200/38,400/57,600/115,200 baud rate; 8 bits,1 stop bit, no parityHardware flow control on (default)/off USBVersion 2.0 Compatible T ype: B-connectorControl/Status Ports DB-25 female A/B (2)Inputs A/B: active low (pull to ground)Outputs A/B: open collector, 40 VDC max, 40mA each+3.3 VDC pins (2) (300 mA over-current protected)Configuration & Administration Software Converge™ Console Power Input Range Auto-Adjusting100–240 VAC; 50/60 Hz Power Consumption 30 W T ypicalDimensions (L x D x H)17.25” x 10.25” x 1.75”43.8 x 26 x 4.5 cmWeight7.5 lbs/3.3375 kg unit weight 12 lbs/5.4kg shipping weightOperating T emperature14° F/-10 °C to 122° F/50° C ambient unit temperature Approvals & ComplianceAES48-2005: AES standard oninterconnections — Grounding and EMC practices — Shields of connectors in audio equipment containing active circuitry (self certified)U.S.A. & Canada CSA safety listed EU CountriesRoHS compliant WEEE compliantSee product manual for additional details Optional AccessoriesConverge Pro 880Converge Pro 880T Converge Pro 840T Converge Pro 8i Converge Pro TH20Converge SR 1212T abletop ControllerButton Microphone – Omni-Directional Button Microphone – Uni-Directional Delta MicrophoneT abletop Microphone – Uni-Directional JBL Wall-Mount SpeakersPart Number910-151-880 Converge Pro 880 – 8-channel AEC Microphone Mixer Headquarters:Salt Lake City, UT USA 5225 Wiley Post Way Suite 500Salt Lake City, UT 84116 Tel:801-975-7200T oll Free: 800-945-7730 Fax:801-977-0087******************Latin America Tel:801-974-3621*******************EMEATel: 44 (0) 1189 036 053*******************APACTel:801-303-3388 *******************Other product names may be registered trademarks of their respective owners who do not necessarily endorse ClearOne or ClearOne’s products. All rights reserved. Information in this document subject to change without notice . © 2007 ClearOne Communications Inc. 802-151-880 Revision 1.7 January 2008.。
润普RH脱机电话录音盒系统方案
中国网通北京分公司电话录音系统及电话录音仪项目；
天津地铁热线呼叫中心系统； 贵州省凯里市长热线项目； 内蒙古赤峰公安局三警合一呼叫中心项目； 北京崇文区职介中心电话语音查询系统项目； 诺基亚通信有限公司厂房设施服务中心电话系统项目； 北京七区电话局数字自动外呼系统项目；
典型客户
平安集团产险、信保、银行电话录音系统全国项目； 民信集团全国嵌入式网络版电话录音系统项目； 双胞胎集团全国嵌入式网络版电话录音系统项目； 北京第一车网电话业务呼叫中心项目； 青海西宁三警合一呼叫中心工程； 秦皇岛城管大队呼叫中心项目； 洛阳12319服务热线项目；
中国长江三峡工程开发总公司电话录音设备采购项目；
国家电网公司电话录音设备采购项目； 中华慈善总会高端数码录音电话采购项目； 北京奥组委电话录音设备采购项目； 中国工商银行陕西省分行录音电话采购项目； 中信银行总行润普高端数码录音电话采购项目； 中国国际航空公司超长数码录音电话采购项目；
典型客户
广州出入境边防检查总站数码录音电话采购项目； 中国农业发展银行高端数码录音电话采购项目； 上海机场（集团）有限公司数码录音电话采购项目； 四川长虹南北两地大型电话录音系统项目； 北大青鸟所有网点电话录音系统项目 民生银行北京42网点营业厅大客户电话录音系统项目； 山西省电力公司电话录音系统项目；
帐号密码为：admin
脱机电话录音盒系统-通道状态
脱机电话录音盒系统-系统管理
脱机电话录音盒系统-录音查询
脱机电话录音盒系统-录音查询
脱机电话录音盒系统-录音设置
脱机电话录音盒系统-用户管理
脱机电话录音盒系统-集中备份
脱机电话录音盒系统-集中备份
脱机电话录音盒系统-集中备份状态
脱机电话录音盒系统-集中备份统计
录音操作说明书
J公司相关产品简介一：录音系统选配该计费软件可实现录到分机或直线计费电话交换机自动计费系统简介本软件适用于各种类型的集团电话/程控交换机为您提供出色的电话系统监控与话费管理。
FOR:AVAYA,阿尔卡特,贝尔,爱立信,富士通,哈里斯,华为,岩通,JSY,L G,LUCENT,敏迪,NEC,日通工,北电,OKI,松下,飞利浦,三星,西门子,大矽谷,TECOM,TONNET,东芝,维想,亿泰,中联,申瓯,通利……系统特殊功能:�系统支持简体,繁体,英文的Win9X/2000/NT/2003/XP。
�系统内置200多种交换机/集团电话机型,也可自定义新机型。
�支持IP网关IP网络电话交换机计费。
�支持相同交换机双串口计费。
�系统支持多路由计费不同的路由按不同的资费标准计费。
�系统已含多个长途局资费：中国电信、联通、网通、铁通IP及其它IP的最新资费;系统可自定义资费及优惠方案。
�支持LAN网络操作,设置与查询,实现数据共享。
�查询报表可导出TXT文文件,系统内含13种报表输出样式。
�酒店入住结帐及押金管理功能齐全支持多操作员操作可生成酒店管理系统需要的话单文件。
�产品出口四十多个国家与地区质量值得信赖。
本手册所有提及之商标与名称皆属本公司所有。
在此不担保本手册无任何疏忽或错误，亦不排除会再更新发行。
手册若有任何内容修改，恕不另行通知。
产品板卡上的任何贴纸请勿自撕毁，否则会影响到产品保修期限的认定标准。
感谢您购买并使用电话商务录音系统在使用本产品前请仔细阅读下面的许可协议许可协议：同意本许可协议的所有条款是获得本产品许可的必要条件。
如果您不同意此协议的所有条款，请在三天内将产品退还软件代理商。
您对软件的使用表明您同意接受本协议中条款的约束。
1．授予您使用权限。
您可以为了备份的目的而复制光盘中的软件。
2．除已按上述第一条被授权外不可以复制、修改、逆向工程、分解或重组该产品的全部或部分不可向他人销售、租借、许可转让分发全部或部分本产品或本协议授予的权利。
润普 RP-BOX10D 数码录音电话使用说明书电子版
RP-BOX系列录音电话RP Digital Recorder数码录音电话使用说明书润普音讯（北京）科技发展有限公司RIPE Audio-Communication (Beijing) Technology Development Co., Ltd.欢迎使用RP-BOX系列数码录音电话，本产品采用数码录音，能够实时、清晰地录制通话语音、来电留言和本地录音，掉电语音数据不丢失，录音时长可达10小时，特设置两级密码保护，确保语音数据的安全性和保密性。
提供USB接口与PC机相连，通过专用的PC机管理软件可以播放、保存录制的语音信息，语音文件可转换为WA V文件，也可以作为普通文件进行COPY、E-MAIL等。
本产品还具有来电显示等多种电话功能。
包装盒内所含附件：录音电话机、电源适配器、USB连接线、录音电话说明书、软件安装光盘。
润普音讯(北京)科技发展有限公司目录一、产品安装 (1)1、安装步骤 (1)2、按键图 (1)3、液晶图 (1)二、电话功能 (2)1、末码重拨 (2)2、静音 (2)3、闪断 (2)4、忙音/静音检测挂机 (2)5、时钟及日期设置 (2)6、来电显示 (2)7、新来电号码提示 (2)8、振铃次数设置 (2)9、和弦铃声设置 (3)10、闪断时间设置 (3)三、录音功能 (4)1、通话录音 (4)2、应答留言 (4)3、现场录音 (4)4、主人留言 (4)5、录音播放 (4)6、录音查询 (5)7、录音删除 (5)四、密码功能 (6)1、密码设置 (6)2、密码修改 (6)3、密码取消 (6)五、系统设置 (7)六、电池备份及馈电电话功能 (7)七、USB接口 (7)八、产品类比 (8)九、产品保修卡 (9)一、产品安装1、安装步骤本机的安装非常简单，用户只要将手柄线、电话线、外接电源线（9V DC）插好，本机就可正常工作了。
本机备有充电电路，用户只需装入四节5号充电电池，这样即使外接电源停电，本机可正常工作。
润普专业电话录音系统、电话录音卡使用说明书和开发手册
电话录音软件使用说明和开发手册2003年5月1日目录系统简介 (3)一、基本功能 (3)二、技术参数 (5)三、典型行业客户列表 (5)系统安装 (6)一、硬件安装 (6)1.1微机 (6)1.2应用环境 (6)1.3硬件结构、安装 (7)二、软件安装 (7)软件操作 (9)一、系统启动 (9)二、基本操作 (10)2.1主窗口说明 (10)2.2模块功能 (11)编程接口 (23)函数说明 (24)VC环境 (28)C++Builder环境 (28)VB环境 (30)DELPHI环境 (32)PB环境 (33)VFP环境 (35)其他编程语言 (36)系统简介RL系列系列电话录音系统，是本公司凭借多年来在语音技术方面的专业经验，使用最新数字电子技术，辅以现今为止最先进的电脑及Windows软件所设计完成的一套整合性系统，它可以同时对多路电话通话进行录音、监听和查询。
系统可选读写光盘作为备份，容量大，可靠性高。
RL系列系列电话录音系统可广泛的应用于商业电话录音，电力调度录音，热线服务电话录音，投诉电话录音，关键岗位电话录音，传呼台录音，金融证券录音，公安报警录音,安全部门的监听电话，航空、铁路、交通运输调度录音及各行业的生产调度录音。
一、基本功能1.流行的Windows 98/ME/2000/XP操作环境。
B接口，符合USB 1.1标准，系统为外置式设备，不占用主机资源，即插即用。
3.从USB端口供电，不需外接电源。
4.可热插拔。
5.容量(线数)随意调整。
用户可根据需要接入多个USB电话录音设备。
可通过USB接口卡随意扩展。
6.支持中文、繁体、英文等各种字体的操作系统。
7.录音对通话双方没有任何影响。
8.可以根据任意给定的条件对录音、备份资料进行快速、简洁的回放查听。
9.多个用户可以在多台电脑使用声卡对录音资料根据任意给定条件进行回放查听与备份。
10.系统具有自动同步双备份功能。
也可以通过系统手工备份到您想要保存的目录或磁带转录。
录音系统使用说明书
二、技术参数
接口方式：模拟中继 录音输入阻抗 直流>= 470K 欧姆 交流（1000HZ 时）>=10K 欧姆 隔离阻抗脚直流均：>= 470K 欧姆 录音模块直流阻抗： >1M 隔离耐压：>=500VDC 录音格式：LAW、ADPCM，GSM 格式的 WINDOWS WAV 文件 数据速率：64 KBPS /32 KBPS /13.6 KBPS 全通道信噪比：>= 42 dB 频响：300~3400HZ 放音输出功率 >= 0.5 W 全通道失真：< 5% 音量调整：-20db ~ +20db 硬盘容量 (20 G 最多可存放 3500 小时)
10. 所有谈话内容录为 wav 格式，可以在任意 WINDOWS 电脑中播放。 11. 可以设置任意多个盘（可以是硬盘、分区或网络映射盘）自动循环录音。 12. 录音启动方式灵活，具有压控、键控、声控三种启动方式。 13. 录音起始时间可以灵活设置，可以是一段时间内录音，也可以是每天 24 小时录 音。 14. 提供不同的压缩率，满足不同用户的需要，20G 的硬盘最多可以保存 3500 多个 小时。 15. 线路适用于电话外线、分机内线、无线对讲机的音频输出线等。 16. 当系统的硬盘将满时，系统将自动清除最先录音的资料，以保证系统可以常年 不间断运行。 17. 方向判别。可以判别出呼叫方向，如呼入还是呼出。 18. 系统具有强大的操作员权限管理功能，除设定每个操作员的权限外，还可以设 置每个操作员可操作的通道。 19. 内置有区号表，可以记录每一次通话的地区。
电话录音系统
操作手册
电话录音系统 . 操作手册
目
录
系统简介 .....................................................................................2 一、基本功能 ..............................................................................2 二、技术参数 ..............................................................................3 系统安装 .....................................................................................4 一、硬件安装 ..............................................................................4 1、1 微机 ..............................................................................4 1、2 PCI 接口录音卡安装 .............................................................4 二、软件安装 ..............................................................................6 2、1 板卡驱动安装 ....................................................................6 2、2 录音系统软件的安装 ............................................................7 软件操作 .....................................................................................8 一、 系统登陆 ............................................................................8 1、1 登陆 ..............................................................................8 1、2 主窗口说明 ......................................................................9 二、 功能操作 .......................................................................... 10 2、1 管理 ............................................................................ 11 1) 查听 ............................................................ 11 2）操作员（权限设置） .............................................. 13 3）日志管理 ........................................................ 14 4）号码薄 .......................................... 错误！未定义书签。 5）区号表 .......................................................... 15 2．2 设 置 ........................................................................... 15 1) 系统设置 ........................................................ 15 2) 通道参数 ........................................................ 16 3) 免录音号码 ...................................................... 18 4) 硬件设置 ........................................................ 19 5) 录音目录 ........................................................ 20 6) 清除策略 ........................................................ 20 7) 备份策略 ........................................................ 21 8) 留言参数 ........................................................ 21 2、3 查 看 ........................................................................... 22 2、4 操作员 ......................................................................... 23 2、5 工 具 ........................................................................... 23 1) 数据备份 ........................................................ 23 2、6 帮 助 ........................................................................... 24
OPSSON U5 GSM GPRS 数字移动电话 说明书
4.8.3 PUK2 码 ....................................... 15 4.8.4 手机密码 ...................................... 15 5 功能菜单 ......................................... 16 5.1 欧博信乐园 ...................................... 16 5.2 相机 ............................................ 16 5.2.1 相册 .......................................... 16 5.2.2 相机设置 ...................................... 16 5.2.3 照片设置 ...................................... 17 5.2.4 白平衡 ........................................ 17 5.2.5 情境模式 ...................................... 17 5.2.6 特效设置 ...................................... 17 5.2.7 自拍 .......................................... 17 5.2.8 存储位置 ...................................... 17 5.2.9 恢复默认值 .................................... 17 5.3 网络服务 ........................................ 17 5.3.1 数据帐户 ...................................... 17 5.3.2 网际网络服务 .................................. 17 5.4.1 快速查找 ...................................... 18 5.4.2 来电组群 ...................................... 19 5.4.3 编辑 .......................................... 19 5.4.4 电话簿设置： .................................. 20 5.5.1 短信 .......................................... 20 5.5.1.1 写短信 ...................................... 20 5.5.1.2 收件箱 ...................................... 21 5.5.1.3 草稿箱： .................................... 21 5.5.1.4 发件箱 ...................................... 21 5.5.1.5 模版 ........................................ 22 5.5.1.6 短信签名 .................................... 22 5.5.1.7 短信搜索 .................................... 22 5.5.1.8 短信设置 .................................... 22 5.5.2 彩信 .......................................... 23
TUBE PREAMP 530 现代汽车音频系统用户手册说明书
professional quality tube sounds in a modern, exceptionally compact 19" rack-mountable package (1 rack space). The two main channels Clean and Lead feature dedicated voicing sections, gain pots and volume controls for precision sound shaping and fine-tuning. The Gain Lo/Hi switch converts the Clean channel to a Crunch channel and, in the Lead channel, the sound spectrum encompasses everything from Heavy Crunch to Ultra Gain. With a 4-band voicing section featuring two midrange bandwidths and ahandy feature is the Defeat function, which bypasses the preamp and routes the guitar signal directly to the output. This feature enables you to connect two preamps in series and this option enlarges the tonal spectrum. The variable Stereo Line Out and a frequency compensated Line O ut give you a wide range of application options, for instance you can patch the preamp signal directly to a mixing console or recording devicewhich is equipped with an impressive array of high-tech features that deliver a wide range of devastating sounds, come highly recommended. The integrated 2 x 1, 5 Watt stereo poweramp is suitable for three different applications:1, practicing with stereo headphones,2. practising with hi-fi stereo speakers, and3, practicing with a conventional guitar speaker cabinet.This preamp is defined by the effort and materials that went into it: intelligent design features, superior craftsmanship, impeccable finishing and quality components. However keep in mind, that a few precautions will radically extend tube life (see handling and care guidness).The entire-Team would like to thank you for your faith in ourproduct; we hope you derive a great deal of joy and satisfaction fromPLEASE NOTE: Read the O perator's Manual carefully and thoroughly, especially the Handling and Care section as well as the guidelines in bold-face type. Avoid operating errors and potential damage to the preamp by heeding the guidelines and cautionary remarks in this manual. The footnotes also cover a few convenient pointers and interesting tips on several functions. These are listed on side 3 of the manual.Gain settings depend on what type of pickups are installed in your guitar. The recommended setting for humbuckers or active pickups lies between the 10 and 1 o ’clock positions and 12 to 3 o ’clock for single coils for a pure clean response.For a crisp glassy tone, set the Bright switch to the On position. This setting boosts the treble response of muddy pickups.To get an idea of this preamp's capabilities in the Clean-Mode, we suggest you set thetone control pots Bass (5), Middle (6) and Treble (7) to the 12 o'clock position.To get Crunch or heavy Rhythm sounds, set this control between the 10 and 1 o ´clock ´s position (depending on the type of pick-up) and leave the Gain Boost (15) pusbuttonin the Off-position. All functions that can be accessed via footswitch can also be switched via the ENGL MIDI Switcher Z- 11. Simply connect the two 1/4" stereo jacks (22) and (23) to the stereo inputs of the Switcher via two cables equipped with 1/4" stereo plugs. You can control switching functions via the buttons on the Switcher. The respective functions (e, g. Lead, Hi -Gain,Contour active, Defeat off) are saved to the desired MIDI program locations. The ENGL MIDI Footswitch Z-12 is ideal for activating MIDI programs. When used in conjunction with the ENGL MIDI Switcher Z-11, this durable footswitch does not require a separateAC power pack. The requisite power is routed via the MIDI cable.To get an idea of this preamp's Lead sounds, we suggest you set the tone control pots Bass (9), Lo Mid (10), Hi Mid (11) and Treble (12) to the 12 o'clock position. The Treble control is important when operating the preamp in combination with a poweramp that does not feature a Presence control: Set the Treble pot between the 7 and 12 o ´clocksposition it suppresses the gritty upper frequencies. The integrated miniature stereo poweramp delivers maximum output of 2 x 1. 5 Watts at 4 ohms. However, you can connect diverse systems with impedances of 4, 8 and 16 ohms as well as headphones with 200 ohms. To the achieve the desired audio result, it is essential that the Selector switch (24) located on the rear panel is set to the proper position. The volume level of the poweramp is determined by the volume level settings for the two channels and the setting of the LINE LEVEL control (29). If the LINE LEVEL pot is turned up fairly high, then the setting for the two volume controls (7) and (14) must be reduced substantially so that the poweramp is not saturated!PLEASE ENSURE YOU HEED THE FOLLOWING: If you are using the amp to drive just one speaker cabinet, connect only one stereo channel via a 1/4" stereo plug. A mono 1/4" plug will short-circuit the poweramp's second channel. If you operate the amp under these conditions at high volumes for a longer period of time, this may destroythe amp or other components!The LINE outputs (25) and (26) provide signals that emulate the response of a 412 guitar cabinet, The signal level is nominally identical to the level at the LINE outputs (27) and (28).However in practice, the level deviates slightly due to frequency compensation. When the preamp is active, the output level of the LINE outputs depends on the following factors:the input level (Gain), the Volume control settings for the respective channels, and in some measure, the voicing section control settings. This is why we recommend that you dial in the desired sound via the front panel control features, set a desired FX level (if you have connected a processor) and then use the LINE LEVEL pot (29) to dial in a suitable level.The following is another conceivable practical application: Patch the outputs (27) and (28) to a stereo poweramp (e.g. ENGL 830/50) to drive two cabinets (e.g. ENGL 412G or S)and the two frequency compensated LINE outputs to the PA mixing console. The emulated 412 signal can be used for the FOH sytem so you do not have to mic your guitar cabinets.The filter stages, integrated LINE amp and the headphones amp can also be used for external application, depending on how you route the signals. Use the two FX LOOP RETURN jacks (30) and (31) as signal inputs. The preamp signal is interrupted when a1/4" jack is inserted. (refer to the Signal Routing Plan).BASSBottom end voicing control for theLead Channel.LO MIDLo Mid-range voicing control (at 500 Hz)for the Lead Channel.LEAD GAINGain control for the Lead channel, controls theamount of distortion in the Lead mode.CAUTION: Extremely high gain and volumelevels in the Lead mode can produce strongfeedback. Avoid feedback squeals, they leadto hearing loss and damaged speakers!TREBLEUpper range voicing control for theClean Channel.7CLEAN VOLUMEVolume control for the Clean channel.BASSBottom end voicing control for theClean Channel.MIDDLEMid-range voicing control for theClean Channel.BRIGHTAlters the EQ by boosting the upper treblerange; (above 2 kHz).Front1INPUTUnbalanced 1/4" (main) input jack.CLEAN GAINHI MIDHi Mid-range voicing control (above 1 kHz)for the Lead Channel.TREBLEUpper range voicing control for theLead Channel.CONTOURPress this button to alter the mid-EQ. When thebutton is pressed, mids between 300 & 500 Hzand mids between 1 & 2 kHz are boostedslightly; the red LED indicates Contour active.This function can also be activated via afootswitch connected to jack (23). Once afootpedal is connected, the channel selectorpushbutton is deactivated.LEAD VOLUMEVolume control for the Lead channel.14GAIN LO / HIThis button increases the gain levels for bothchannels. When you activate it, the Cleanchannel responds more like a Crunch channel,and the Lead channel delivers a hi-gain leadsound. You can also activate this function viafootswitch (Jack 22), the Gain Boost pushbuttonis then no longer functional. The LEDilluminates to indicate Hi-Gain mode is active.CLEAN / LEADChannel selector pushbutton for Clean andLead modes, red LED indicate Lead mode;This function can also be activated via afootswitch connected to jack 22. Once a foot-pedal is connected, the channel selector push-button is deactivated.PREAMP DEFEATThis feature bypasses the preamp when thebutton is depressed. In this case the guitarsignal is routed to the Instrument Outputjack (32) .You can also activate this function viafootswitch (at Jack 23), the Preamp Defeatpushbutton is then no longer functional.The LED above the button illuminates toindicate the preamp is bypassed.POWERAC power on/off.19STEREO HEAD PHONES1/4" stereo output designed for stereoheadphones. you can also connecthi-fi speakers or guitar cabinets. When youconnect a conventional guitar cabinet set theselector switch (24) to ,,Routed to GuitarCabinet."CAUTION! Ensure You Heed The Following:Always use a 1/4 stereo plug. If you use amono plug, it may short-circuit and destroythe poweramp!Rear Planel20AC SocketConnect AC cord here.CAUTION: Ensure you use an intact ACcord with an insulated plug only! Beforeyou power the amp up, ensure the voltagevalue printed beside the AC socketcorresponds to the available current.21AC Fuse BoxContains mains fuse (rear chamber) andspare fuse (front chamber).NOTE: Ensure replacement fuses bearidentical ratings (refer to the table)!22FOOTSWITCH:CLEAN/LEAD; GAIN LO/HI1/4" stereo jack for connecting a dualfootswitch (e.g. ENGL Z-11) or a MIDI-switching system (e.g. ENGL Z-11).The following functions can be executed:1.Channel switching Clean - Lead(mono terminal)2.Gain Lo - Hi (stereo terminal).23FOOTSWITCH:PREAMP DEFEAT; CONTOUR1/4" stereo jack for connecting a dualfootswitch (e.g. ENGL Z-11) or a MIDI-switching system (e.g. ENGL Z-11).The following functions can be executed:1.Preamp Defeat / Bypass(mono terminal).2.Contour switching (stereo terminal).24HEADPHONES OUTPUT:A) Routed To Headphones Or HiFi Cab.B) Routed To Guitar Cab.Rear panel selector switch for front panelheadphones jack. Set the switch to the leftposition A) when you connect stereoheadphones or hi-fi speakers and to theright position B) when you connect aguitar cabinet to ensure proper frequencycompensation for the respective systems.FREQUENCY COMPENSATED LINEOUTPUT: RIGHTLine Out for the preamp's right frequencycompensated signal (1/4" unbalanced jack).This signal can be patched directly to amixing console or a recording device.FREQUENCY COMPENSATED LINEOUTPUT: LEFTLine Out for the preamp's left frequencycompensated signal (1/4" unbalanced jack).This signal can be patched directly to amixing console or a recording device.LINE OUTPUT: RIGHTLine Out for the preamp's right channel(1/4" unbalanced jack).This signal can be routed to a powerampor a FX device via a shielded cable.LINE OUTPUT: LEFTLine Out for the preamp's left channel(1/4" unbalanced jack).This signal can be routed to a powerampor a FX device via a shielded cable.LINE LEVELThis control feature determines the level ofthe LINE outputs 25, 26, 27 and 28. Theinstrument output (32) signal can also beamplified to 15 dB if required.29FX LOOP RETURN: RIGHTSignal input right stereo channel for theFX Loop. Connect this input to a signalprocessor’s right output/send jack via ashielded cable with 1/4" plugs.30FX LOOP RETURN: LEFTSignal input left stereo channel for theFX Loop. Connect this input to a signalprocessor’s left output/send jack via ashielded cable with 1/4" plugs.31INSTRUMENT OUTPUTFX LOOP SENDOutput for patching the preamp signal to apoweramp input or the input of a anotherpreamp or signal processor/FX device.Ensure you use a short shielded cable forthis signal circuit.AUXILIARY INPUTSupplentary preamp input. This circuit is routedin series with the input located on the frontpanel and is used for patching the setup to a19" rack. The front panel input has priority. Inother words, when you insert a plug into thefront panel jack (1), the signal routed in via theAux. Input (33) is interrupted.33The INSTRUMENT OUTPUT (32) delivers a signal similar to the one generated by a guitar'spickups when the preamp is active (PREAMP DEFEAT switch Off), i.e. a high-ohm signal at about the same level as a guitar signal. This feature is relevant when you want to establish the same conditions via a bypass circuit (guitar signal to the INSTRUMENT OUTPUT) for further signal processing, for instance by an FX device, another Preamp connected in series or a poweramp.You can connect a signal processor between the INSTRUMENT OUTPUT (32) and the FX LOOP RETURN jacks (30) and (31) or directly between the LINE OUTPUTS (27) and (28) and a stereo poweramp's inputs. There is a substantial difference between these two applications:When you connect the Processor to the FX LOOP, the send signal is identical to the guitar signal when the preamp is in defeat mode and the preamp signal when the defeat mode is off. The send level only is influenced by the settings of the volume controls in this case.The level of the master output signal routed to the LINE outputs can be increased via the LINE LEVEL (29) pot.However, when you connect the Processor between the LINE outputs and the poweramp,the input (Send) signal to the FX device can be increased via the LINE LEVEL (29) pot and you have two Send signals (left, right) available. This option is recommended for low impedance (0 dB)FX devices that are not equipped with a variable input.Technical DataCaution: Replace fuses only with others of the same rating!INSTRUMENT: -10 dB max. 0 dB LINE OUT: -10 dB max.15 dB Output level (0 dB => 1Veff)Tubes:approx.4 kgV1 => ECC83/12AX7 FirstQuality V2 => ECC83/12AX7 selected Dimensions:Weight:19", 1 rack spaces, depth: 260 mm INPUT: -20 dB max. -3 dB Input level(0 dB => 1Veff) 2 x 1,5 Watts at 4 OhmsHeadphones poweramp:Power Consumption: approx. 16 Watts max.Fuses100 & 120 Volts 400 mAM 500 mATAC Mains: external:internal:230 Volts 200 mAM 250 mATM => medium, T => slowchanged!Internal Signal-path:INSTRUMENTHandling and CareProtect the preamp from mechanical knocks (tubes!).Let the preamp cool down before you transport it (approx. 10 minutes).Tubes need about 20 seconds to warm up after you switch the power on.Avoid storing the preamp in damp or dusty rooms, they are hard on jacks, switches and potentiometers.criteria) to avoid microfonic properties, undesireable noise and feedback.W e r e s e r v e t h e r i g h t t o m a k e u n a n n o u n c e d t e c h n i c a l u p g r a d e s !ENGL Ger ätebau GmbH, Germany; Internet: Text, design, grafics and layout by Horst Langer。
PPR80 数字录音机使用手册说明书
Open the SD card door,push the card fully until it clicks. Being careful about the direction you insert it.
Close the Card door . * If the card door cannot be completely closed, remove the card ,check its direction and then insert it again.
Do not use the unit in extreme hot, cold, dusty or high humidity. Do not use or keep the unit in following places.
In a high humid area, such as a bathroom or hypogeum. In an area exposed to direct sunlight ( e.g. inside car where it becomes extreme hot ). Near sources with strong magnetism, such as a television, speaker or magnet. In trembly places, such as on the car dashboard or shaky shelf.
HOLD 25
13 Stereo/Mono SELECTOR 26
Battery compartment 27
Battery Installation
It will never affect files stored in the unit to replace batteries . If you shut down the unit with normal operation , it will keep the date and time by previous setting .
CDX8000-RD4(P) 电话录音仪说明书
电话录音仪说明书版本：Version2.1型号：CDX8000-RD4(P)佛山市容讯科技有限公司目录目录 (2)1 前言 (4)1.1 浏览器兼容性说明 (4)1.2 文档内容 (4)1.3 文档变更 (5)2 产品介绍 (6)2.1 产品概述 (6)2.1.1 4路模拟录音盒外观 (6)2.2 主要特性 (7)2.3 主要功能 (7)2.4 主要参数 (8)3 硬件安装 (9)3.1 组网应用 (9)3.2 硬件接口 (10)3.3 产品安装 (10)4 系统管理 (13)4.1 登录 (13)4.2 导航树 (14)4.3 运行信息 (15)4.3.1 实时告警 (15)4.3.2 历史告警 (15)4.3.3 工作状态 (16)4.3.4 录音统计 (18)4.4 录音管理 (18)4.4.1 通道设置 (18)4.4.2 通道设置 (20)4.4.3 免录名单 (21)4.4.4 实时监听 (21)4.4.5 录音查询 (22)4.4.6 备份录音查询 (24)4.5 系统管理 (26)4.5.1 设备信息 (26)4.5.2 网络参数 (26)4.5.3 IP配置 (28)4.5.4 FTP配置 (28)4.5.5 WIFI配置 (29)4.5.6 时间设置 (29)4.5.7 导入/导出配置 (29)4.5.8 设备管理 (30)4.5.9 PING 测试 (31)4.5.10 帐号管理 (31)4.5.11 邮件告警 (32)4.5.12 web访问权限 (33)4.5.13 Web操作日志 (33)4.5.14 系统升级 (33)1 前言1.1浏览器兼容性说明可通过任何浏览器登陆到录音仪的web端，当进行播放，下载录音等操作时，由于要安装插件，部分浏览器兼容性不是很好，导致操作失败。
请使用下列浏览器来操作。
1.2文档内容1.3文档变更2 产品介绍2.1产品概述CDX8000-RD系列嵌入式电话录音仪是新一代录音设备，设备自带Linux系统，无需另外电脑，就可实现电话录音，不受计算机病毒的影响。
MDR电话录音系统操作手册
M D R电话录音系统操作手册This manuscript was revised by the office on December 10, 2020.二、基本操作2．1主窗口说明主界面一说明：1.两个图都是录音系统的主界面，他们之间可以自由切换。
主界面一为大图标显示，主界面二为列表方式显示，可以即时显示每个通道的状态。
2.主界面的最上方是菜单条，紧接着是快捷按钮。
菜单条与快捷按钮可以实现相同的功能，不过快捷按钮更方便些。
屏幕中间的大区域为每个通道的状态显示。
屏幕的右方与下方为用户与系统的状态显示。
3.当系统主界面启动后，录音系统即处于工作状态。
4.监听：本系统提供即时监听功能，用户用鼠标双击某一线路的图标，即可监听此线路，再次双击此线路则取消监听。
同一时刻只能监听一个通道。
5.通道状态图标说明：断线录音空闲监听录音摘机不可用留言空闲主界面二2.2模块功能主画面上方有录音系统的功能菜单，通过本菜单可以对录音系统进行全部操作。
包括：日常操作查询统计录音设置参数设置帮助1.日常操作1)登录：用户输入用户名与密码后，可以实现登录，不同的用户可以有不同的权限。
2)注销：用户完成操作后，可以注销此用户，这样其他用户要操作本系统时必须登录。
3)界面切换：切换主界面中各线路状态的显示方式，详细见主界面一与主界面二。
4)退出：关闭录音系统。
2.查询统计1）录音查询本功能是录音系统最常用的功能，在这里，用户可以完成录音文件的查听、备份、除、注释、打印等功能。
说明：查询：用户必须先查询出录音文件，然后才可以对文件进行放音，注释，备份、删除等操作。
1. 查询条件时间：可以设置查询的开始与结束时间，默认为当天。
电话号码：此号码为用户拨入或拨出的电话号码，*代表全部，5039*表示以5039开始的所有的电话号码。
*5039*表示包含5039的所有的电话号码。
备注：根据用户设置的备注信息进行查询。
电话分类：根据电话分类（可在电话本中设置分类）进行查询。
纯声55录音专业数字混音功放使用说明书
PROFES SIONAL KARAOKESound 55Pure R ecord in gINPUTS.BASSMUSIC b #AUT/S V.C.MULTIPLEXb5b4b3b2b1#1#2#3#4#5AUT/SV.C.S.BASSDVDKODAUXUSBNEXT RECORDER &PLAYERBACK PLAY/PAUSE STOP REC DELEMPPROFESSIONAL DIGITAL MIXING AMPLIFIER WITH RECORDER Pure Sound 55R e c o r d i n gLOW LOWLOWLOWLOW OWNER'S MANUALPROFESSIONAL DIGITAL ECHO MIXING AMPLIFIERWITH KARAOKE RECORDERThank you for your purchase of our new full concept amplifier.Please read this manual thoroughly before making connections and turning on the power.Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new amplifier.Please retain this manual for future reference.CHARACTERISTICSHigh Precision Dual Echo SystemThe set has two complete,independent,and advanced digital echo processing circuits.When two singers with different compasses sing simultaneously,Digital echo will offer different echo effects to fit the timbres of the singers.This system fully develops the feature of True Stereo Echo Karaoke.Sound Range Beautified SystemThe two microphones respectively offer the function of adjusting echo effects.In addition,Echo tone offers the function of beautifying the sound range of the singer,making perfect sound range and ending sound.This system help the singer enjoy enormously the delight of singing and express emotions.Singing With Great EaseWith the super output power of each channel,high currency capacity of the power filter circuit,the set offers solid power,high-quality timbres,making clear,smooth, and sound-surround music.In addition,with the advanced Echo and Music Mixed Circuit System,the set offers high sensitivity of the echo effect,clearness of the sound.The lowest signal noise ratio guarantees natural,clear sound effects.These systems help the singer sing with great ease.Protective FunctionThe set is equipped with advanced Channel Heatsink-Blow System and Overheat Protecting,which guarantee the lowest noise ratio.In addition,the set is equipped with Overload Protection,and Short-circuit Protection.These systems offer protective functions.Multi-ApplicationsThe set offers2systems Echo Mixing microphone inputs and1Direct Tone Circuit microphone input for professional DJ/KJ.Besides,the set is equipped with Video Switching,and Multiplex(Auto singing mate/Vocal cancel)function.Above all,the set is equipped with unique Super Bass frequency extension mode selection,which produces different frequency effects matched to the music broadcasted.The unit offers the newest USB karaoke recording matched with MP3format to have more fun when recording your own singing.The multi-function set offers family entertainment and fits commercial Karaoke or various Karaoke occasions.CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,DO NOT REMOVE COVER (OR BACK).NO USER-SERVICEABLE PARTS INSIDE,REFERSERVICING TO QUALIFIED SERVICE PERSONNEL.CAUTIONDO NOT OPEN!RISK OF ELECTRIC SHOCK ,The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing)instructions in the literature accompanying the appliance.The lightning flash with arrowhead symbol,within an equilateral triangle,is intended to alert you to the presence of uninsulated "dangerous voltage "within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.Explanation of Graphical SymbolsWARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK.DO NOT TO RAIN OR MOISTURE.EXPOSE THIS UNIT please record the serial number of this unit in the space below.Serial No.:Retain this Owner's Manual in a safe place for future reference.The serial number is located on the rear of the unit.1Read instructions-All the safety and operating instructions should be read before the unit is operated.2Retain Instructions -The safety and operating instructions should be retained for future reference.3Heed Warnings-All warnings on the units and in the operating instructions should be adhered to.4Follow Instructions -All operations and other instructions should be followed.5Water and Moisture-The unit should not be used near water-for example,near a bathtub,washbowl,kitchen sink,laundry tub,in a wet basement,or near a swimming pool,etc.6Carts and Stands -The unit should be used only with a cart or stand that is recommended by the manufacturer.6A A unit and card combination should be movedwith care.Quick stops,excessive force,and uneven surfaces may cause the unit and cart combination to overturn.7Grounding or Polarization-Precautions should be taken so that the grounding or polarization is not defeated.8Ventilation -The unit should be situated so that its location or position does not interfere with its proper ventilation.For example,the unit should not be situated on a bed,sofa,rug,or similar surface,that may block the ventilation openings;or placed in a built-in installation,such as a bookcase or cabinet that may impede the flow of air through the ventil-ation openings.9Heat-The unit should be situated away from heat sources such as radiators,stoves,or other appliances that produces heat.10Power Sources -The unit should be connected to a powersupply only of the type described in the operating instruc-tions or as marked on the unit.11Power Cord Protection -Power supply cords should berouted so that they are not likely to be walked on or pinched by items placed upon or against them,paying particular att-ention to cor ds at plugs,convenience receptacles,and the point where they exit the unit.12Cleaning-The unit should be cleaned only as recommendedby the manufacturer.13Nonuse Periods-The power cord of the unit should be unplu-gged from the outlet when left unused for a long period oftime.14Object and liquid Entry-Care should be taken so that objectsdo not fall into and liquids are not spilled into the inside of the unit.15Damage Requiring Service -The unit should be serviced byqualified service personnel when:A.The power supply cord or the plug has been damaged;orB.Objects have fallen,or liquid has been spilled into theunit;orC.The unit has been exposed to rain;orD.The unit does not appear to operate normally or exhibitsa marked change in performance.E.The unit has been dropped,or the cabinet damaged.16Servicing -The user should not attempt to service the unitbeyond those means described in the operating instructions.All other servicing should be referred to qualified service personnel.17Power Lines -An outdoor antenna should be located awayfrom power lines.IMPORTANTModel:Sound Pure 55R ec or d in gINPUTS.BASSMUSIC b #AUT/S V.C.MULTIPLEXb5b4b3b2b1#1#2#3#4#5AUT/SV.C.S.BASSDVDKODAUXUSBNEXT RECORDER &PLAYERBACK PLAY/PAUSE STOP REC DELEMPPROFESSIONAL DIGITAL MIXING AMPLIFIER WITH RECORDER 23456789101112131415161718192021241.Microphone input jacks2.Input signal attenuators3.Auto-gain level indicators4.Microphone volume control5.Balance control6.Bass adjust7.Mid-range adjust 8.Treble adjustB port (Matched with MP3format)30.Play/Pause 31.Stop 32.Record 33.Next34.Back(Previous)35.Circulate Broadcast 36.Delete9.Echo volume control 11.Echo treble control 12.Repeat length control 13.Delay time control 14.Music volume control 15.Balance control 16.Bass adjust17.Mid-range adjust 18.Treble adjustFUNCTION CONTROL 19.Remote control sensor 22.Key control button25.Key DisplayMICROPHONESMUSICECHO10.Echo bass control 26.Microphone master volume control 27.Music master volume control MASTER VOLUME20.Input source selector 23.Auto singing-mate switch 24.Vocal cancel switch 222325262728.Power ON/OFF switch POWER CONTROL KARAOKE RECORDING28293031323334353621.Super Bass Switch 1LOW LOW LOWLOWLOW3.SPEAKER SYSTEMS TERMINAL1.Do not let the bare speaker wires touch each other or any other metal part as this could damage this unit and /or speakers.2.Make sure that the polarity of the speaker wires is correct.that is :+and-marking are observed.Ifthese wires are reversed,the sound will be unnatural and will lack bass.3.When one speaker system is used,speakers with an impedance of 4to 8ohms should be connected for used as main amplifier output terminals.Be careful when using two pairs speaker system at the same time,since use of speakers with animpedance of less than 8ohms will lead to damage,should use speakers with an impedance of 8ohms to 16ohms.2.AC POWER FUSE HOLDERUse T4A fuse.5.MUSIC OUTPUT TERMINALThis terminal outputs music sound only from the amplifier.without music tone adjust,and not through master volume control.6.MIC SIGNAL OUTPUTThis terminal outputs microphones'sound only from the amplifier with mike tone adjust.But not through master Mic volume control.Before plug-in the power supply,be sure to pick the voltage of 230V 50Hz or 115V 60Hz correctly.1.AC POWER SUPPLY1023456781111294.HEATSINKING BLOWER OUTLETAir vents front and rear must not be obstructed.WATTS 600POWERMUSIC INPUT VOLTAGE T.H. D./115V AC 230V 0.05%RIGHT LEFTSound Pure 55R ec or d in gLEFT RIGHTKODKODDO NOT REMOVE COVER (OR BACK),NO USER-SERVICEABLE PARTS INSIDE,REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.CAUTIONC A UT I O N :A IR V EN TS F R O N T A ND RE A R M UST NO T B E O BS T R U C T E D8.SOUND-EFFECT DEVICE INPUT/OUTPUTUse this terminal when connecting external sound effect devices such as graphic equalizer,power amplifier.9.MUSIC SOURCE INPUTThe terminal use to connect sound source,such as DVD CDG KOD AUX etc.The original setting is on DVD position.11.REAR MIC INPUT JACKSThese jacks are also for connecting microphones.The MIC A is connected to the same circuit as the MIC 1jack on the front panel.And the MIC B is connected to the same circuit as the MIC 2jack on the front panel.12.DUAL VOLTAGE SELECTOR10.VIDEO INPUT/OUT JACKSConnect input jack with the video output of DVD CDG KOD or AUX etc.And connect output jack with the video input of the monitor/TV.Before turn on power switch,be sure the AC voltage selector is seted to the appropriate AC voltage according to your area.7.MIX OUTPUT TERMINALThis terminal outputs music through music tone adjust and microphone's sound with echo effect,through master volume control.The terminal can be used to connect MP3recorder or power amplifier.1.PLAY/PAUSEPress the button to enter into play/pause mode.Press STOP button,this function will be cancelled automatically.(In recording mode,when recording is finished,and then the current recording will be kept in USB record folder.Press PLAY/PAUSE button to access to the play record folder.Press "BACK"button,the current recording will be played.)press STOP button 2.STOPIn play mode,the set stops playing.In recording mode,the set stops record function and keeps the current recording.3.RECRecording button.Press the button to record the selection.When recording,the master music and master mic volume of the set does not function to the recording volume,please adjust the music and microphone volume by the music volume and the separately microphone volume to get suitable volume for recording.4.NEXTThe next selection.5.BACKThe previous selection.6.PLAY-MODEPress the button,the selection is circulated.Press and hold for 3seconds,the whole folder is circulated.7.DELEDelete button.Press the button to delete the current selection in play.ORIGINAL SETTING FUNCTIONThe set is built with original setting function.When playing,the whole folder is circulated.INDICATOR1.Play/Pause indicatorIn play mode,the indicator illuminates steadily.In recording mode,the indicator flickers.2.Play-mode indicatorThe indicator illuminates when the selection circulated,the indicator unilluminated when the whole folder circulated.HOW TO OPERATE THE RECORDING 1.Press "MUSIC INPUT"button to get the music source from DVD or KOD or AUX.2.Press "REC"button to record the selection.3.Press "STOP"the recording function stops and the current recording is kept in USB.4.Press "MUSIC INPUT"button to access to USB.5.Press "PLAY"button to access to the play record folder in USB.6.Press"BACK"button,the current recording will be played.KEY/BUTTON DESCRIPTIONWATTS 600POWERMUSIC INPUT VOLTAGE T.H. D./115V AC 230V 0.05%RIGHT LEFTSound Pure 55R ec or d in gLEFT RIGHTKODKODREMOVE COVER (OR BACK),DO NOT NO USER-SERVICEABLE PARTS INSIDE,REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.CAUTIONC AU T I ON :A IR V EN TSF R O N T A N DR E AR M U ST NO T B E O B S TR U C T E DTV/MONITORMAIN SPEAKER(A)MAIN SPEAKER(B)L R L R AUXILIARYWIRED/WIRELESS MICROPHONEKODDVD/CDGSOUND EFFECTORACTIVE SUB-WOOFERPOWER AMPLIFIERPOWER AMPLIFIERGRAPHIC EQUALIZERDo not power on the unit until all the connections are completed.When the pin plug cords are employed,always connect the "White"plug to the left channel and "Red"plug to the right channel.This helps to avoid reversed connections.Insert the plugs firmly,poor contact will result no sounds or noise.Speaker Impedance:A or B one Speaker system 4-8ohmA +B dual Speaker system 8-16ohmRECORDERorSpecifications and features are subject to changed without notice.Audio output max.600W Mic input sensitivity15mV External devices sensitivity250mV Signal /Noise ratio (with IHF A Fiter )90dB T.H.D.(1kHz.AUX 150mV INPUT )0.1%Frequency Response 25Hz 20KHz Mic.Tone adjustment80Hz 15dB 3.5KHz 5dB 12KHz 15dB Echo tone adjustment 80Hz 15dB 12KHz 15dB Power source AC115V /60Hz AC230V /50Hz Net Weight33Lbs.Dimension (WxHxD)430x155x355mmMute switchKey controlInput source selectAuto singing-mate switchMicrophone master volume control Music volume control Super Bass switchMUTE INPUT SELECTDVD KOD AUXMICMUSICb#AUT/S MULTIPLEXV.C.SUPER BASSK E Y C O N T R O LV O L C O N T R O LVocal cancel /switchKeep the microphone apart approx.5to10cm from your mouth.To make the clean voice sound,leave the proper space betweenmicrophone head and your hold position on microphone.Do not cover the lower wind screen of the microphone,which mayinterrupt the audio sound and may cause howling.Keep apartapprox.5~10cmLeave theproper spaceMartin Roland is constantly striving to maintain the highest quality and standards.As a result of these efforts,modifications may be made to this product without notice.PROFES SIONAL KARAOKE。
Polycom SoundStation IP 5000 IP会议电话说明书
Audio features • Loudspeaker
-- Frequency: 250 – 7,000 HZak volume
84 dB at 1/2 meter distance • Voice activity detection • Comfort noise fill • DTMF tone generation / DTMF event
• Robust interoperability – compatible with a broad array of SIP call platforms to maximize voice quality and feature availability while simplifying management and administration
Benefits
• Unparalleled clarity – Polycom HD Voice makes your conference calls sound amazingly clear and life-like
• More productive conference calls – Patented Polycom Acoustic Clarity™ technology delivers the best conference phone experience with no compromises
and call history (missed, placed, and received) • Customizable call progress tones • Wav file support for call progress tones • Unicode UTF-8 character support. Multilingual user interface encompassing Simplified Chinese, Danish, Dutch, English (Canada / US / UK), French, German, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish
电话商务录音系统使用说明书
第一章简介本公司将先进语音技术同大容量磁盘存储技术相结合推出性能优异的新一代多路电话商务录音管理系统是对电话双方通话过程进行实行自动录音和实时监听功能的软硬件集成系统。
能对多路电话同时进行超长时间录音显示记录主叫号码、被叫号码及通话时长等通话信息并保存于电脑系统管理人员可以对任意正在通话的通道进行实时监听而通话不受任何影响。
录音采用国际通用语音处理及压缩技术符合CCITT标准将话音信号经取样数字化压缩后存储在计算机磁盘中。
放音则是通过对磁盘上的语音数据进行解压后通过外接音箱(耳机)播放。
是生产调度、服务热、110、火警、防讯报警、银行委托、证卷行业等领域不可缺少的工具。
产品已布及国家和地区：美国、港澳台地区新加坡马来西亚印度尼西亚等东南亚国家南美诸国中东地区以及西亚地区出口品质值得信赖。
产品通过CE/FCC认证.系统基本功能：●支持Windows 98/NT/2000/XP/2003操作环境。
●提供USB接口2路PCI接口单卡4路8路16路数字30B+D（30路）。
●可实时监听每一条线路的通话内容。
●支持三种录音模式自动录音(压控)声控可手动录音(键控)。
●可以对所有的拨入、拨出未接电话进行清单列表、打印、支持条件查询及添加通话备注。
●支持直线交换机的内线分机接入同时录音。
●系统支持自动备份可将语音文件自动备刻录到DVD支持自动循环录音。
●系统附带来电客户信息管理系统可识别来电身份及自定义来电座席弹屏。
●录音起始时间可以灵活设置可以是一段时间内录音也可以是每天24小时录音。
●用户可在特殊号码表里自定义不录音的电话号码如拨打95555,163上网录音系统不启动录音）。
●系统具有完整的操作日志可以记录对系统的所有操作。
●支持每个用户对某些线路拥有操作的权限可设定不同等级的密码保护除了系统管理员使用最高级的密码外还有用户密码、录音文档查询密码等多种保护措施。
●线路适用于普通电话外线、分机内线、ISDN引出的模拟线、无线对讲机的音频输出线等。
RA-2000多通道数字电话录音系统说明书
RA-2000多通道数字多通道数字录音录音录音系统系统一、 系统概述RA-2000多通道数字录音系统采用最新的数字语音处理技术，结合先进的计算机硬件，实现了大容量、高品质且安全、稳定的多路电话录音。
与传统的磁带录音系统相比，RA-2000具有语音不失真、易保存、查询快及便于操作等优点，而且还具有许多磁带录音系统所没有的功能，其性能价格比远超出磁带录音系统。
二、 应用范围RA-2000多通道数字录音系统应用非常广泛，如电力、铁路、石油、企业等行业的指挥调度部门，机场、港口、公安、安全、军事等要害部门的录音和监听，金融行业授权指令的实时录音，无线寻呼台、电信局、服务行业的服务、售票窗口、应急电话受理的录音和监听，并且还应用在各种客户服务中心、投诉中心等，为了解及时查询和发现事故原因以及提供准确可靠的原始录音记录，发挥了巨大作用。
三、 主要功能＊ 录音功能- 摘机自动录音。
挂机或断线时自动停止录音。
- 录音资料保存为标准的PCM 格式或ADPCM 格式（压缩格式）文件。
可转换为Windows 下的WA V 格式文件。
＊ 放音功能- 可选择任一条录音记录由扬声器播放。
- 可对放音进行控制，如快进、快退、暂停、重放等。
- 经转换的WA V 文件可在任何带声霸卡的计算机上播放。
＊ 网络查询- 可通过网络，查听系统内所有的录音记录。
- 即时播放录音内容。
＊ 远程查询- 可通过电话拨通系统的查询通道，查听系统内所有的录音记录。
- 查询时，系统提供提示语音帮助用户操作。
＊ 系统管理- 系统本身以及查询通道均设密码保护。
用户只能在其权限内操作。
-提供完整的通话记录方便用户查看。
-自动监视硬盘剩余容量。
当剩余容量小于指定的最小保留容量值时，系统提示用户进行转存或删除。
四、技术特点分层结构：基于C/S模式的分布结构，层次清晰，易于维护。
可将服务器和客户端运行在不同的计算机上通过网络连接，也可运行在同一台机器上；并行操作：录音和通话记录检索或记录放音可同时进行；数据快速检索：系统语音用数据库方式来管理，快速而高效，并能实现复杂的通话记录快速检索。
