CDMA1xRTT_无线资源管理

NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 7
BTS 资源管理, Cont.
• RC4_Preferred (AdvancedSector MO)
— 如果设为 True, 对于支持RC4的手机, 基站将会分配其 前向RC4. — 解决 Walsh code 的阻塞问题. — 与RC3相比，需要更多的功率. RC4 卷积编码率为 ½ （相对于RC3 的¼）
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 9
BTS 资源管理, Cont.
• MaxDataFchResources ( AdvancedSector MO)
– This attribute works in conjunction with MaxDataResources to control the number of 3G data resources on fundamental traffic channels vs. those on the supplemental channels. MaxDataFchResources defines the percentage of MaxDataResources that can be allocated on fundamental channels. For example, if MaxDataResources is 60 percent and MaxDataFchResources is 40 percent, then maximum percentage of 3G data resources on fundamental channels would be 60% * 40% = 24%. The fundamental channels offer higher total number of users at lower data rates vs. the supplemental channels which offer lower total number of users at higher data rates.
• NBSS12： RC自动判定算法 New！
• XCEM 资源管理
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 1
1xRTT载波配置与资源分配
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 2
• Note: MaxDataResources + MaxVoiceResources can total greater than 100%. If
each parameter is 100, resources are given on first-come, first-serve basis. Used for Mixed_and_RRM only.
– – – –
RC4_Preferred, Voice & Data parameter MaxDataResources, Voice & Data parameter MaxVoiceResources, Voice & Data parameter MaxDataFCHResources. Data parameter
Notes
MaxVoiceResources/MaxDataResou rces ignored; 100/0 used MaxVoiceResources/MaxDataResou rces ignored; 100/0 used MaxVoiceResources/MaxDataResou rces ignored; 0/100 used. MaxVoiceResources/MaxDataResou rces ignored; 100/100 used MaxVoiceResources/MaxDataResou rces datafill are used
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 5
BTS 资源管理
• CRM & CRP 分配参数
— BTSCallProcessing MO
– PREV, MINPREV, Voice & Data parameter
— AdvancedFrequencyAssignment (AFA) MO – RadioConfigState, Voice & Data parameter – EnableHSReverseSchFeature, Data parameter — AdvancedSector MO
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 6
BTS 资源管理, Cont.
• RadioConfigState (AFA MO)
— 规定载波的能力. CRM 和 CRP基于此决定呼叫的RC. 由CFDS控制. — 必须与 PilotDatabase MO (PDB Table) 中的 Cell Capability设置相一致，以便 于SBS 的多载波业务管理和软切换.
速率也不需匹配. 不能组合使用前向 EVRC和反向 B13K . 如果前向 使用RC4，则反向必须使用 RC3. 前向使用 RC5,则反向需使用 RC4. RC >= 3 需要 ESEL & XCEM支持. 不支持 B8K RC3.
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 4
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 8
BTS 资源管理, Cont.
• MaxVoiceResources (AdvancedSector MO)
—When RadioConfigState is set to “Mixed_and_RRM”, the MaxVoiceResources attribute allows the operator to define an upper limit on the percentage of BTS resources (forward link power and walsh codes) used on certain calls. These calls consist of 2G voice, 2G circuitswitched data, and 3G voice calls on a fundamental traffic channel. This parameter is independent of its sister parameter MaxDataResources.
1xRTT 载波配置
• Radio Configurations (RC)
– 1xRTT 目前支持5 种Radio Configurations, RC1 到 RC5.
• 载波配置
– Nortel Networks‘ 的1xRTT 产品支持载波的独立配置, 如 IS95-only, Voice-only, Data-only, and Mixed.
1xRTT 无线资源管理
北电网络（中国）无线工程部 August, 2005
NORTEL NETWORKS CONFIDENTIAL
内容
• 1xRTT载波配置与资源分配
• 无线资源管理（RRM）
– 话音与数据的资源分配 – 数据呼叫接受机制 – SCH Burst建立机制 – 无线资源管理与QOS – 无线资源管理参数的优化
• CellCapability (PilotDatabase MO)
– This parameter stores the radio configuration state of the BTS corresponding to the PDBTable entry on a per sector basis. It is defined to assist the SBS in determining carriers for MCTA sites and during soft handoff. This parameter does not actually affect how the sector operates. It is important to ensure that this parameter is set to the same value defined in the AdvancedFA MO of the BTS.
资源分配
• 无线资源由 BTS控制.
— BTS 基于 Call Resource Pool (CRP) 和 Call Resource Manager (CRM)分配资源. RC的选择 由系统参数和手机的业务申请决定.
• SBS 资源由 RMU/CAU控制
— 话音资源: 基于 MTX Tables (SBSINV, etc.) 中的 参数和 IVSN feature. — 数据资源: 基于 MTX Tables (SBSINV, etc.), 数据 到来的速率, 以及 BSM MOs (ESBSShelf, etc.)
— 如果手机的 P_REV < 6, BTS 会忽略该参数，分配其 RC 1 或 2.
— 由CFDS控制.
•
EnableHSReverseSchFeature (AFA MO)
— 如果设为 True, 反向会允许使用CELLFEAT 表中所规 定的最高速率. 如果设为 False, 反向只允许使用基速 率.
NORTEL NETWORKS CONFIDENTIAL
IS2000 Carrier Configuration - 3
wk.baidu.com
Radio Configurations
Configuration RC1 RC2 Fwd FCH Base Rate 9600 bps (EVRC) 14400 bps (B13K) Rvs FCH Base Rate 9600 bps (EVRC) 14400 bps (B13K)
Datafill
Voice_2G Voice_2G_3G Data_3G Mixed Mixed_and_RRM.
Description
Only 2G voice calls (RC1, RC2) allowed Only voice calls allowed (All RC’s) Only 3G data calls allowed (RC >= 3) All voice & data calls allowed (all RC’s) All voice & data calls allowed (all RC’s)
• MaxDataResources (AdvancedSector MO)
—When RadioConfigState is set to “Mixed_and_RRM”, the MaxDataResources attribute allows the operator to define an upper limit on the percentage of BTS resources (forward link power and walsh codes) used on 3G data calls. These data calls could exist on fundamental or supplemental traffic channels. However the amount of data traffic on the fundamental channel can be more finely tuned with the MaxDataFchResources attribute. MaxDataResources is independent of its sister parameter, MaxVoiceResources.
RC3
RC4 RC5
9600 bps (EVRC)
9600 bps (EVRC) 14400 bps (B13K)
9600 bps (EVRC)
14400 bps (B13K) Not Applicable (3x)
• Note: 前向与反向 FCH 的基速率必须匹配，但 RCs 不需匹配. SCH
