小麦播种机参数

三立2BXF系列小麦播种机

Sanli 2BXF series wheat planter

1.三立2BX系列播种机，适用于平原和丘陵地区的条播小麦。

Sanli 2BX series planter is suitable for drilling wheat on plains and hilly areas.

2.该小麦播种机与小四轮拖拉机配套使用，采用后置双轴三点悬挂，利用液压升降，排种装置由地轮驱动，使用方便。

The wheat seeder with small-size 4-wheel tractors, adopts rear biaxial three-point suspension, using hydraulic lifting, metering device by wheel drive, easy to use.

3.轻型双圆盘开沟器，能在桔杆还田的土壤中顺利开沟、播种。

Lightweight double disc opener, can furrow and seed smoothly in the soil of straw counters-field.

4.在秸秆还田的地块中作业，还可将尖铲式开沟器换为圆盘开沟器。

Using in the straw returning to field,pointed shovel type opener also can be replaced by the disc opener.

5.播种深浅可调，播量大小可调。

Sowing depth is adjustable, sowing quantity size is also adjustable.

6.杆式传动轴完全代替了链轮组构造，避免了掉链、折链的麻烦，更能及时准确地保证您的耕作顺利，使用寿命更长。

Rod shaft is completely replace the chain structure, avoid the trouble off the chain, chain, can more timely and accurately to ensure your work smoothly, longer service life.

7.该小麦播种机一次作业可完成平地、开沟、播种、镇压、覆土、打竖等多项作业。

The wheat planter can complete the ground, furrowing and seeding, repression, turns the soil, shaft, etc.

8.圆盘开沟器采用弹簧浮动机构，可有效的避免因单盘受阻而整体漏播。

Disc opener the spring floating mechanism, can effectively avoid overall leak seeding were stuck in a single disc.

9.自主专利种量调节表，调节种量更方便、精确。

Independent patent quantity adjustment table, adjust the volume of a more convenient and accurate.

10.主机架采用加厚型方管，加强型设计，整体结构更加坚固、耐用。

The main frame with square tube, enhanced design, the overall structure is more firm

and durable.

11.尖铲式开沟器（耧腿）底部副板开槽设计，播种均匀。后期植株通风、透光效果好，抗倒伏能力强。

Sharp shovel type opener (Lou legs), vice board at the bottom of the slot design, planting evenly. The late plant ventilation, pervious to light effect is good, strong resistance to lodging.

型号Model2BXF-7 2BXF-9 2BXF-12

外形尺寸

Dimensions

长×宽×高(mm)

L×W×H(mm)

1800X1950X1400 1800X2150X1400 1800X2400X1400

重量(公斤)Weight

（kg)

235 275 315

配套动力Matched

(kw)

(马力) Horsepower

8.8-13

12~18马力HP

8.8-13

15~25马力HP

11-13

20~25马力HP

播种行数Planting

Rows

7 9 12

基本行距(mm) Basic Line Distance(mm)220(可调)

(adjustable)

160(可调)

(adjustable)

160(可调)

(adjustable)

最大播种量

(公斤/亩)Maximum Rate(kg/mu)

30

(可调)

(adjustable)

30

(可调)

(adjustable)

30

(可调)

(adjustable)

播种深度Sowing

Depth

20-50mm 20-50mm 20-50mm
