空客飞机AMM,IPC,TSM手册使用

On A/C 007-099, POST SB 53-4098; 对于 007-099飞机, 已执行服务通告SB 53-4098
Removal / Installation 拆卸/安装
FIN
程序的结构组成
M M E L C D L M P D
T E M C M L
A I P C
P I P C
X X X X
JIC GIC CCC
TLMC Time Limits MPD Section 9
NTM
NonDestructive Testing Manual
Structural Repair Manual
ATA Ref.
CMM
Component Maintenance Manual
© AIRBUS CHINA LTD. All rights reserved. Confidential and proprietary document. This document and all information contained herein is the sole property of AIRBUS CHINA LTD. No intellectual property rights are granted by the delivery of this document or the disclosure of its content. This document shall not be reproduced or disclosed to a third party without the express written consent of AIRBUS CHINA LTD. This document and its content shall not be used for any purpose other than that for which it is supplied.
AIRBUS, its logo, A300, A310, A318, A319, A320, A321, A330, A340, A350, A380, A400M are registered trademarks.
Technical Data Support & Services
Presented by
AMM – Breakdown 内容划分
Manual Front Matter page (手册首页) Highlights (only AirN@v) 更改重点 (只在AirN@v 中) Chapter 00 – Introduction (章节00 - 手册介绍) Fleet No. / MSN cross ref table (FSN / MSN 交叉索引表) SB list (SB 清单) COC list (COC 清单)
Tool Drawing Status工具图纸状态 Y --> TEI 参见TEI P --> Contact Vendor 与厂家联系 C --> Refer to CMM 参考 CMM S --> Standard tool 标准工具 etc…
AMM and associated manuals AMM 及相关手册
D&O - Component location 部件位置
10JS1 R/I
Click to see The figure
2JS1 Cross ref. to Removal/installation 9JS1
EFFECTIVITY 有效性
On A/C 007-099, PRE SB 53-4098; 对于007-099飞机, 未执 行服务通告SB 53-4098
Technical Data Support & Services
Presented by
Name
JobTitle
AMM 及相关手册 AMM & Associated Products
AMM – General 飞机维护手册 – 概述
WHEN YOU WORK ON AIRCRAFT USE THE AMM 当在飞机上工作时使用 AMM
28 - 21 - 51
Component (unit) level, breakdown allocated by Manufacturer 部件, 由飞机制造商划分 Sub-sub-system level, breakdown allocated by Manufacturer 次级分系统, 由飞机制造商划分 Sub-system level, breakdown allocated by ATA 100 Spec. 分系统 按 ATA 100 规范划分 Chapter level, breakdown allocated by ATA 100 Spec. 章 按 ATA 100 规范划分
D/R
A/T I/C C/P AR PB 501 PB 601 PB 701 PB 801
Keyword – Page Block (PB) 关键字 – 页段 (PB)之间的关系
Table of Contents (TOC)
Description & Operation (PB 001) 系 The purpose of the D & O is to explain: 统描述& 系统描述&工作部分是为了解释 : 工作 (PB 001)
- the component location - the system/component description - the power supply (if applicable) - the interfaces with other systems (if applicable) - the operation/control & indicating - the BITE test. - 部件位置 - 系统及部件描述. - 供电 (如适用) - 与其他系统的交连 (如适用) - 系统工作/控制& 指示 - BITE 测试. This part contains the necessary data to understand the functioning of a system. 本部分内容有助于了解系统的功能.
D&O
PB 001 PB 201
S
PB 301
Any Removal or Installation or Deactivation or Reactivation
R/I
PB 401
拆卸/安装, 或失效/ 恢复使用
Any Adjustment or Test: 调节/测试: Any Inspection or Check 检查/检验: Any Cleaning or Painting: 清洁/喷漆: Any Approved Repair: 批准的修理:
The statements made herein do not constitute an offer. They are based on the mentioned assumptions and are expressed in good faith. Where the supporting grounds for these statements are not shown, AIRBUS CHINA LTD. will be pleased to explain the basis thereof.
PPIPC CML
Consumable Material List Material Number ATA Ref. CSN / ATA Reference FIN
Power Plant
IPC
Illustrated Parts Catalog
NSRM
Nacelle
SRM
TSM
SJC
Standard Job Cards
TEM
TOOL PN 工具件号 OVERHAUL 部件翻修
Tool & Equipment Manual
TEI
Tool & Equipment Index
TED
Tool/Equipment Drawing
CMM
Component Maintenance Manual 部件翻修手册
SES
Support Equipment Summary
SCHEDULED MAINTENANCE PROCEDURES
NON-SCHEDULED MAINTENANCE PROCEDURES
例行维护程序
非例行维护程序
FM CDL
MRB MPD
MEL
TSM
AMM – General 维护手册 –概述
The AMM provides detailed information required to maintain the aircraft at line or in the hangar. AMM 维护手册提供航线和定检维护时所需的详细技术信息 This does not include workshop information which is contained in the CMM. 车间附件修理的技术信息不在AMM 而在 CMM 中.
The AMM is structured into ATA chapters and further into sub-systems and units as required. AMM维护手册按需要划分成ATA章节, 分系统和主题(部件)
Reference breakdown example: 例如:
CLM
Component Location Manual
TEM
Tool & Equipment Manual
MMEL CDL
Configuration Deviation List (m) ATA MMEL/CDL Ref. Ref.
MPD
Maintenance Planning Document
AWM
Maintenance Procedures 维护程序
AMM – SB List 服务通告清单
AMM – SB List 服务通告清单
AMM – SB List 服务通告清单
Keyword – Page Block (PB) 关键字 – 页段 (PB)之间的关系
Description & Operation 系统描述&工作 Any Standard Maintenance Practices: e.g. pressurizing, jacking, energizing... 任何标准施工: 如: 增压, 顶飞机, 通电 Any task related to Service, e.g. replenishment, lubricating... 勤务工作:如: 加油, 润滑...
SHOP MAINTENANCE 车间维护===> CMM / ACMM / EIPC
Tools/Equipment & Associated Documentation工具/设备及相关文件
MAINTENANCE 飞机维护
AMM
Aircraft Maintenance Manual
wenku.baidu.comTEB
Tool Equipment Bulletin
TEM TEI SES
TSM
Trouble Shooting Manual
Deactivation/Reactivation index <--- MMEL/CDL (失效/恢复使用程序 <--- MMEL/CDL)
At each chapter level you will find 在各章节包括
TOC ( + Highlights on PDF) 手册内容目录 ( +更改内容重点PDF 手册) D&O MP Description and Operation 系统描述&工作
Name
JobTitle
零备件资料介绍 SPARE DATA FAMILIARIZATION
Generalities 概述
LINE MAINTENANCE 航线维护===> AIPC /PIPC
AIPC ==> AIRFRAME ILLUSTRATED PARTS CATALOG 飞机图解零件清册 PIPC ==> POWER PLANT ILLUSTRATED PARTS CATALOG 发动机图解零件清册
