如何检测DIN6926质量？
如何检测DIN6926质量？DIN6926，有的人说，从来没有见过，还有的人说根本就不知道是什么东西，其实它在我们的日常生活和工作中的应用是非常广泛的，大到工程，机械上，小到自行车，电子产品。
如果你不知道，只能说明大家对它的了解不多，今天小编就带您去了解一下吧！一、DIN6926：生产制造工具DIN6926是紧固件的通用说法。
螺栓的原理是利用物体的斜面圆形旋转和摩擦力的物理学和数学原理，循序渐进地紧固器物机件的工具。
DIN6926在日常生活当中和工业生产制造当中，是少不了的，螺栓也被称为工业之米。
可见螺栓的运用之广泛。
DIN6926的运用范围有：电子产品，机械产品，数码产品，电力设备，机电机械产品。
船舶，车辆，水利工程，甚至化学实验上也有用到螺栓。
反正是超多地方都有用到DIN6926的。
特如数码产品上面用到的精密螺栓。
DVD，照相机、眼镜、钟表、电子等使用的微型螺栓；电视、电气制品、乐器、家具等之一般螺栓；至于工程、建筑、桥梁则使用大型螺栓、螺帽；交通器具、飞机、电车、汽车等则为大小螺栓并用。
螺栓在工业上负有重要任务，只要地球上存在着工业，则螺栓之功能永远重要。
二、DIN6926的检测检测分为人工和机器两中。
人工是最原始也是使用最为普遍的一致检测方式。
为了尽量减少不良品的流出，一般生产企业人员通过目视的方式对待包装或者发货的产品进行检验，以排除不良品（不良包括牙伤、混料、生锈等）。
DIN6926，DIN980，DIN981，DIN982另一种方式为机器全自动检测，主要是磁粉探伤。
磁粉探伤是利用DIN6926缺陷处的漏磁场与磁粉的相互作用，针对螺栓可能存在的缺陷（如裂纹，夹渣，混料等）磁导率和钢铁磁导率的差异，磁化后这些材料不连续处的磁场将发生崎变，形成部分磁通泄漏处工件表面产生了漏磁场，从而吸引磁粉形成缺陷处的磁粉堆积——磁痕，在适当的光照条件下，显现出缺陷位置和形状，对这些磁粉的堆积加以观察和解释，已达到剔除不良品的目的。
