monster turbine airlinks说明书使用说明：
1、按键功能：
S1开关机按键、接听挂端电话。
S2音量递减按键，按一次减小一级。
S3音量递增按键，按一次增加一级。
2、充电：
１、本产品使用锂离子聚合物电池，首次使用请先充电两小时以上。
２、充电时红灯亮，充满电时红灭，大约１-2小时。
３、充电时不能使用本产品。
3、配对：
首先确认您的手机是否有蓝牙功能，长按S1键到红、蓝灯同时快速闪烁二次，发出“嘚”声，而后红、蓝灯交替闪烁，耳机再次发出“嘚”声。
使用手机中的蓝牙功能搜索蓝牙设备，您能找到Z-W61,选择该设备连接。
输入蓝牙配对码0000,进行配对，耳机发出一声提示音，而后蓝灯每四秒闪烁一次，配对成功。
若3分钟没找到设备配对，耳机自动关机。
4、使用说明：
１、开机：长按S1键，红、蓝灯同时快速闪烁二次，发出“嘚”声，（约1秒、，而后红灯每三秒闪烁一次，搜索、连接已配对设备，连接成功后，蓝灯每5秒连续闪烁两次，进入待机工作状
态。
若5分钟没连接上已配对设备，耳机自动关机。
２、接听电话：耳机听到来电提示音，按S1键一次接听电话，耳机发出一声提示音，通话中红、蓝灯快速闪烁；也可按手机上接听键接听电话，耳机发出一声提示音，通话中红、蓝灯快速闪烁。
3、拨出电话：在待机工作状态，按S1键一次，可以拨出最后一次通话的电话。
在待机工作状态，按手机的拨出电话方式，输入号码拨打电话。
4、结束通话：在通话中，要结束通话，按S1键一次结束通话，耳机发出一声提示音。
在通话中，对方挂断电话，耳机发出一声提示音。
自动结束通话。
在通话中，按手机挂断键一次，耳机发出一声提示音。
自动结束通话。
5、音量增加/减小：通话中按S3/S2键，可以增加和减小音量，长按连续增加和减小音量，到最大、最小音量时，耳机发出“bi\bi”提示音。
6、关机：长按S1键４秒，红、蓝灯同时快速闪烁二次，耳机发出“嘚”声提示音，关机。
在耳机远离接收范围，5分中后自动关机。
7、电量不足：在工作状态时，红灯连续快速闪烁时，耳机发出急促的提示音，表示电量不足，最多维持60秒，请及时充电。
