中英文翻译传感器重点

传感器的基础知识Basic knowledge of transducersA transducer is a device which converts the quantity being measured into an optical,mechanical, or-more commonly-electrical signal. The energy-conversion process that takesplace is referred to as transduction. Transducers are classified according to the transduction principle involved and the form of themeasured. Thus a resistance transducer for measuring displacement is classified as aresistance displacement transducer. Other classification examples are pressure bellows, force diaphragm, pressure flapper-nozzle, and so on.1. Transducer ElementsAlthough there are exception ,most transducers consist of a sensing element and a conversionor control element. For example, diaphragms,bellows,strain tubes and rings, bourdon tubes,and cantilevers are sensing elements which respond to changes in pressure or force and convert these physical quantities into a displacement. This displacement may then be used tochange an electrical parameter such as voltage, resistance, capacitance, or inductance. Such combination of mechanical and electrical elements form electromechanical transducing devices or transducers. Similar combination can be made for other energy input such as thermal. Photo, magnetic and chemical,giving thermoelectric, photoelectric,electromaanetic,and electrochemical respectively.2. Transducer SensitivityThe relationship between the measured and the transducer output signal is usually obtained bycalibration tests and is referred to as the transducer sensitivity Kl=output-signal increment /measured increment. In practice, the transducer sensitivity is usually known, and, bymeasuring the output signal, the input quantity is determined from input = output-signal increment / Kl.3. Characteristics of an Ideal TransducerThe high transducer should exhibit the following characteristics.a high fidelity-the transducer output waveform shape be a faithfulreproduction of the measured; there should be minimum distortion. b There should be minimum interference with the quantity being measured; the presence of the transducer should not alter the measured in any way.c Size. The transducer must be capable of being placed exactly where it is needed.d There should be a linear relationship between the measured and the transducer signal.e The transducer should have minimum sensitivity to external effects, pressure transducers,for example,are often subjected to external effects such vibration and temperaturefThe natural frequency of the transducer should be well separated from the frequency and harmonics of the measurand.4. Electrical TransducersElectrical transducers exhibit many of the ideal characteristics. In addition they offer high sensitivity as well as promoting the possible of remote indication or mesdurement.Electrical transducers can be divided into two distinct groups:a variable-control-parameter types,which include:i resistanceii capacitanceiii inductanceiv mutual-inductance typesThese transducers all rely on external excitation voltage for their operation.b self-generating types,which includei electromagneticii photoemissiveiv piezo-electric typesThese all themselves produce an output voltage in response to the measurand input and their effects are reversible. For example, a piezo-electric transducer normally produces an output voltage in response to the deformation of a crystalline material; however, if an alternating voltage is applied across the material, the transducer exhibits thereversible effect by deforming or vibrating at the frequency of the alternating voltage.5. Resistance TransducersResistance transducers may be divided into two groups, as follows: i Those which experience a large resistance change, measured by using potential-divider methods. Potentiometers are in this group.ii Those which experience a small resistance change, measured by bridge-circuit methods. Examples of this group include strain gauges and resistance thermometers.5.1 PotentiometersA linear wire-wound potentiometer consists of a number of turns resistance wire wound around a non-conducting former, together with a wiping contact which travels over the barwires. The construction principles are shown in figure which indicate that the wiper displacement can be rotary, translational, or a combination of both to give a helical-type motion. The excitation voltage may be either a.c. or d.c. and the output voltage isproportional to the input motion, provided the measuring device has a resistance which is much greater than the potentiometer resistance. Such potentiometers suffer from the linked problem of resolution and electrical noise.Resolution is defined as the smallest detectable change in input and is dependent on the cross-sectional area of the windings and the area of the sliding contact. The output voltage is thus a serials of steps as the contact moves from one wire to next.Electrical noise may be generated by variation in contact resistance, by mechanical went due to contact friction, and by contact vibration transmitted from the sensing element. In addition,the motion being measured may experience significant mechanical loading by the inertia and friction of the moving parts of the potentiometer. The wear on the contacting surface limits the life of a potentiometer to a finite number of full strokes or rotations usually referred to in the manufacture's specification as the `number of cycles of life expectancy', a typical value being 20M 1000000 cycles.The output voltage VO of the unload potentiometer circuit is determinedas follows. Let resistance RI= xi/xt *Rt where xi二 input displacement, xt= maximum possible displacement,Rt total resistance of the potentiometer. Then output voltage VO= VRl/(Rl+( Rt-Rl=V*Rl/Rt=V*xi/xt*Rt/Rt=V*xi/xt. This shows that there is a straight-line relationship between output voltage and input displacement for the unloaded potentiometer.It would seen that high sensitivity could be achieved simply by increasing the excitation voltage V . however, the maximum value of V is determined by themaximum power dissipation P of the fine wires of the potentiometer winding and is given by V=(PRt1/2 .5.2 Resistance Strain GaugesResistance strain gauges are transducers which exhibit a change in electrical resistance in response to mechanical strain. They may be of the bonded or unbonded variety .a bonded strain gaugesUsing an adhesive, these gauges are bonded, or cemented, directly on to the surface of the body or structure which is being examined.Examples of bonded gauges arei fine wire gauges cemented to paper backingii photo-etched grids of conducting foil on an epoxy-resin backing iii a single semiconductor filament mounted on an epoxy-resin backing with copper or niekelleads.Resistance gauges can be made up as single elements to measuring strain in one direction only,or a combination of elements such as rosettes will permit simultaneous measurements in more than one directionb unbonded strain gaugesAtypical unbonded-strain-gauge arrangement shows fine resistance wires stretched around supports in such a way that the deflection of the cantilever spring system changes the tension in the wires and thus alters the resistance of wire.Such an arrangement may be found incommercially available force, load, or pressure transducers.5.3 Resistance Temperature TransducersThe materials for these can be divided into two main groups:a metals such as platinum, copper, tungsten, and nickel which exhibitand increase in resistance as the temperature rises; they have a positive temperature coefficient of resistance.b semiconductors, such as thermistors which use oxides of manganese,cobalt, chromium, or nickel. These exhibit large non-linear resistance changes with temperature variation and normally have a negative temperature coefficient of resistance.a metal resistance temperature transducersThese depend, for many practical purpose and within a narrow temperature range, upon the relationship RI=RO*[1+a*(b1-62] where a coefficient of resistance in 'C-band RO resistance in ohms at the reference temperature b0=00C at the reference temperature range 0C The international practical temperature scale is based on the platinum resistance thermometer,which covers the temperature range -259.35 0C to 630.5 'C.b thermistor resistance temperature transducersThermistors are temperature-sensitive resistors which exhibit large non-liner resistance changes with temperature variation. In general, they have a negative temperature coefficient.For small temperature increments the variation in resistance is reasonably linear; but, if large temperature changes are experienced, special linearizing techniques are used in the measuring circuits to produce a linear relationship of resistance against temperature. Thermistors are normally made in the form of semiconductor discs enclosed in glass vitreous enamel. Since they can be made as small as lmm,quite rapid response times are possible.5.4 Photoconductive CellsThe photoconductive cell , uses a light-sensitive semiconductor material. The resistance between the metal electrodes decrease as the intensity of the light striking thesemiconductor increases. Common semiconductor materials used for photo-conductive cells are cadmium sulphide, lead sulphide, and copper-doped germanium.The useful range of frequencies is determined by material used. Cadmium sulphide is mainly suitable for visible tight, whereas lead sulphide has its peak response in the infra-red region and is, therefore, most suitable for flame-failure detection and temperature measurement.5.5 Photoemissive CellsWhen light strikes the cathode of the photoemissive cell are given sufficient energy to arrive the cathode. The positive anode attracts these electrons, producing a current which flows through resistor R and resulting in an output voltageV Photoelectrically generated voltage V=Ip.Rl Where Ip=photoelectric current(A,and photoelectric currentlp=Kt.B Where Kt=sensitivity (A/im,and B=illumination input (lumen Although the output voltage does give a good indication of the magnitude of illumination, the cells are more often used for counting or control purpose, where the light striking the cathode can be interrupted.6. Capacitive TransducersThe capacitance can thus made to vary by changing either the relative permittivity, the effective area, or the distance separating the plates. The characteristic curves indicate that variations of area and relative permittivity give a linear relationship only over a small range of spacings. Thus the sensitivity is high for small values of d. Unlike the potentionmeter, the variable-distance capacitive transducer has an infinite resolution making it most suitable for measuring small increments of displacement or quantities which may be changed to produce a displacement7.Inductive TransducersThe inductance can thus be made to vary by changing the reluctance of the inductive circuit.Measuring techniques used with capacitive and inductive transducers:a A.C. excited bridges using differential capacitors inductors.b A.C. potentiometer circuits for dynamic measurements.c D.C, circuits to give a voltage proportional to velocity for a capacitor.d Frequency-modulation methods, where the change of C or L varies the frequency of an oscillation circuit.Important features of capacitive and inductive transducers are as follows: i resolution infiniteii accuracy+一 0.1% of full scale is quotediii displacement ranges 25-10-6 in to 10-3miv rise time less than 50us possibleTypical measurands are displacement, pressure, vibration, sound, and liquid level.8. Linear Variable-differential Ttransforcner9, Piezo-electric Transducers10, Electromagnetic Transducers11, Thermoelectric Transducers12,photoelectric Cells13,Mechanical Transducers and Sensing Elements传感器的基础知识传感器是一种把被测量转换为光的、机械的或者更平常的电信号的装置。
