压链机--英文使用说明-更改打印设置后的效果

FCZ R

Hand(power)hydraulic Master Pin Press Installation,operation,and maintenance manual

type LCZ5B

type LCZ6B

type LCZ10B

type LCZ15B

Thanks for purchasing the FCZ R hand(power)Hydraulic Master Pin Press.

Before use,please read these instructions completely

We at Fuda machinery co.ltd would Iike to thank you for purchasing the FCZ hand(power)；lydraulic Master Pin Press To get the most out of vour investment，we encourage you to take a moment to read through the Operator’S manual We have been manufacturing hand(power)Hydraulic Master Pin Press since2002．during this time we llave experienced many different scenarios．Our product support team would be happy to lend assistance or share any ricks of the trade We can always be reached by caIling check our web site for tips also．

LIMITED WARRANTY

1.Fu Da Machinery Co Ltd warrants that all new rnachines are free of aIl material and manufacturer defects．The Machine warranty covers all pans and workmanship for a period of one year from the original date of invoice．

Should defects in any material or workmanship be discovered during the warranty period，the purchaset should notify the factory or the nearest FCZ representative as soon as possible．Fu Da Machinery CoLtd．will

have the option to repair or replace the defective part or machine Freight to and from the factory shall be the responsibility,of the customer

2.To expedite repairs，please provide the model，the serial number,the date of purchase，and the invoice number with the returned machine．

3 Warranty shall be void in the following circumstances：

DA MAGE CAUSED BY OPERATOR ABUSE oR NEGLECT

OAMAGE CAUSED BY THIRD PARTIES．

DAMAGE CAUSED DURING SHIPPING. DANIAGECAUSEDBYOPERATIONSBEYOND RATED CAPACITIES． DAMAGECAUSEDBYANYMODlFICATIONSTOTHE

MANUFACTURE S ORlGlNAL DESIGN．

4 Fu Da Machinery Co Ltd Co.Ltd liabil ity on any claim，whether in contract，tort(including negligence)or otherwise,for any loss or damage arising out Of,connected with，or resulting from the mannfacture．sale．delivery，resale，repair,replacement or use of any product shall jn no case exceed the price allocated to the product or part there of,which gives rise to the claim，except as specifically provided in the warranty provisions In no event shall the Fu Da Machinery Co．Ltd be liable for special indirect or consequential damages or any damages resulting from loss oflife or damage to property other

than the property'that iS tile subject of this warranty.

5 The foregoing warranties shall constitute Fu Da Machinery Co Ltd

sole liability and the purchaser s sole remedy and are in 1ieu or alI other warmnties and conditions written or verbal，statulot'y,express or implled All returned items，whether for repairs or warrant must be pre—approved by Fu Da Machinery Co Ltd.will fax the shipper a claim number and shipping instructions.ltems returned without Drior authorization wjII not be accepled

6.This manual describes the genetal operation of the FCZ Hand(Power) Hydraulic Master Pin Press As the new owner of this product，we strongly urge you and any other operators to read and Ullderstand the intbrmation in this manual.

7.The customer shall ensure that only people thoroughly trained in safe work Procedures ope rate this machine．Sate working ocedut~s are requi red when operating rotating machine tools The misuse of this machine could result in SeVere injury or death．

WARNING!

Misuse can cause serious injuries ever deatM

Rotating machine parts can cause serious injuries，even death!

1.INSTALLATION AND AND ADJUSTMENT

1.1MACHINEANDADJUNCTS (4)

1.2INSTALLATIONANDADJUSTMENT (4)

2 SAFETY

2.1SAFETY

PRECAUTIONS (5)

2.2MACHINE

SAFETY (5)

3 SETUPAND OPERATION

3.1 PREPARATlON (5)

3.2 HINGEROLLKNoCKFDDOWN (5)

3.3 HINGEROLL SETUP (6)

4．REPAIR AND MAINTENANCE

4.1OILCANANDMACHINEBOLSTER (7)

4.2POWEROILPUMP (7)

4.3HANDOILPUMP (7)

5 MALFUNCTIONS AND SOLUTION (7)

6 STANDARD AND SPEClFICAT0N (8)
