imx6q BSP移植详细学习笔记

合集下载

基于IMX6Q+TSI721的RapidIO硬件设计与实现

基于IMX6Q+TSI721的RapidIO硬件设计与实现作者：***来源：《计算机与网络》2021年第13期为了使ARM架构的CPU能通过PCIE总线连接到RapidIO系统中，利用NXP公司的IMX6Q处理器PCIE接口和RapidIO桥芯片Tsi721的硬件特性，在Linux操作系统下开发该芯片的驱动程序，实现了PCIE总线网络和RapidIO总线网络的无缝对接。

通过实际测试，验证了工作的正确性。

RapidIO总线是当前广泛应用的一种嵌入式系统内部互联架构，具有高带宽、低延迟，支持多处理器等特征，比千兆以太网提供更高的传输速率，比PCIE更适合组建平行通信网络。

本设计采用了FREESCALE公司的i.MX6Q芯片作为核心CPU，它是基于ARMCortex-A9架构，40nm工艺制程，最高运行频率可达1.2GHz，具备PCIE2.0接口，可以进行功能扩展，凭借IMX6Q的此功能，选择美国IDT公司生产的PCIE转RapidIO桥接芯片Tsi721与之无缝对接，来实现RapidIO总线功能。

为将SerialRapidIO总线更好地应用到ARM处理器系统中，本文提出了一种基于IMX6Q+TSI721的解决方案。

RapidIO协议架构RapidIO是一个开放的标准，宗旨是为嵌入式系统开发可靠的、高性能、基于包交换的互连技术。

主要用于系统内部互连，支持芯片到芯片、板到板间的通信。

为了满足灵活性和可扩展性的要求，RapidIO分为3个层次：逻辑层、传输层及物理层。

如图1所示。

CPU硬件设计ARM嵌入式Rapidio通信平台硬件由IMX6Q+TSI721芯片组成，IMX6Q集成1路PCIE 接口，外接TSI721桥接芯片，扩展Rapidio总线接口，外接DDR3存储器。

其中FLASH用于存储Bootloader、操作系统内核、文件系统，在IMX6Q内运行Linux操作系统，Linux操作系统集成协议栈，通过BSP与硬件进行通信，图2是硬件平台架构示意图。

IMX6开发板使用教程资料

D-CHIP i.MX6 开发板安装Android系统方法详细教程一、烧写系统●将i.MX6开发板通讯OTG与电脑的USB口连接；开发板OTG与电脑主机的USB口连接●将核心板上的2PIN拨码开关调为1:OFF，2:OFF。

核心板的2PIN拨码开关设置为全部关闭●在鼎芯科技下载的Android包对应的系统版本中运行相应的MfgTool2对系统进行系统烧写。

运行MfgTool2.exe程序未给i.MX6开发板通电时，软件为识别到设备的接入，显示为No Device Connected.给i.MX6开发板通电后，软件将会识别到设备的接入，并提示HID-compliant device.点击“Start”按钮，执行系统的烧写在软件对开发板烧写过程中，由于数据复制到eMMC存储芯片过程，系统将提示磁盘格式化提示，直接“取消”或者不予理会。

一直等到完成烧写并提示“Done”后，点击“Stop”退出软件，至此，系统已经烧写成功。

●完成烧写工作后，断开电源，并将核心板的2PIN拨码开关恢复原来状态1：ON，2：OFF将核心板的2PIN拨码开关设置为1：ON ；2：OFF状态●接入显示设备（LVDS显示屏）7寸LVDS屏幕（本屏幕作为产品选配件，需要额外购买）通过2x15排针将显示屏接入LVDS0接口接好的开发板显示屏（有木有一种帅帅的感觉?）●将i.MX6开发板的COM口与PC机电脑通讯COM口连接，用以和putty.exe进行数据交互。

开发板COM口连接PC机通讯COM口●运行putty.exe（通过网上百度搜索下载即可），实现通讯数据交互。

运行putty.exe程序在putty.exe主界面的“会话”窗口中设置如上图，“串行口”设置为您PC机COM口的端口号，“速度”处为152000，设置好以后直接按“打开”按钮进入数据侦听界面。

给i.MX6开发板接入电源，设备启动，PuTTY显示从COM口上传的数据信息，i.MX6开发板启动进入系统。
