Telephone:86-577-66811122Fax:86-577-66811866
Email:export@ /
1.Characteristics:
The TOP-300rotary die cutting machine the latest products for the label converting and finishing process.Modular designs with many functions optional,Inkjet press,flexographic UV,Varnishing,Cold stamping,Die cutting,Slitting,Sheeting.etc.The machine shows great effort in humanity design and friendly operating.
2.Main technical parameter:
Max Speed300RPM（65M/MIN）
Accuracy of Cutting±0.1mm
0mm××290mm(L(L××W)
Max Die Cutting Area350mm
Paper Width80mm---300mm
Max Unwinding Dia.φ700mm(about2000Meters）
Max Rewinding Dia.φ700mm(about2000Meters）
Magnetic Cylinder120Teeth1/8（Standard）
Length of Die Cutting50mm~350mm
MOTOR Power8KW
UV POWER(KW)Inkjet:4.8Cold stamping:7.0
Overall Diameter（L×W×H）2900mm×1200mm×1500mm
weight2500KG
3.Price:
4.Standard configuration:
A:Web guiding system.
B:Tension control system
C:120teeth/381mm magnetic cylinder.
D:Servo motors
E:HMI Touch screen operating system
F:Waste matrix mandrels.
5.Optional Unit:
A:Single Inkjet nozzle+UV:
B:Flexographic UV(with Cold stamping unit):
C:Laminating:
Telephone:86-577-66811122Fax:86-577-66811866
Email:export@ /
D:Rotary die cutting unit
E:Slitting unit:
F:Sheeting&paper collecting table:
6.Delivery time:30days
7.Payment terms:T/T.30%deposit in advance,and70%balance payment before shipment
8.Following photo for your reference
pany profile:
Located in Economic&Technology Development Zone of Rui'an,Wenzhou,which beside to the harbor and airport,Rhyguan Machinery specialized in the R&D and manufacture of Label converting and finishing equipment.
Facing the increasing fierce competitions both domestic and abroad,insist with the mission "Technology Innovation,Quality Oriented",we strive to develop the updated machinery comply with the printing workshop and the international market.As the IOS9001quality system and CE qualified,every part and component we use in each machine is top-brand with high quality guaranteed,every set of machine will delivery out with warranty policy after test passed,even technical guiding and technician support.
