石油钻机

OIL DRILLING RIG

石油钻机

公司可提供钻井深度2000-12000米之间的钻机与修井机，有车载、橇装、整托等运输形式；并可根据用户需求，提供适应陆地、

SKID-MOUNTED DRILLING RIG

橇装钻机

4000米(1000HP)系列钻机型号及参数

TECHNICAL P ARAMETERS

技术参数

The design meets GB/T 23505 Petroleum Drilling and Workover Rigs, and the main supporting parts conform to API specifications

Reasonable overall layout, safe and fast demolition, complying with highway transport requirements

Features explosion-proof, leak-proof, anti-corrosion, moisture-proof, cold resistant, high temperature resistant and sand prevention

Mechanical drive, electromechanical drive, and electric drive are available The mast is front opening K type, featuring low installation and integral lifting The substructure is in parallelogram structure and uses drawworks power for lifting, which is safe and fast

设计符合国标GB/T▲23505《石油钻机和修井机》，主要配套部件符合API 规范 总体布局合理，拆迁安全快速，符合高速公路运输要求 产品具有防爆、防漏、防腐、防潮、防寒、耐高温、防沙等性能 采用机械驱动、机电复合驱动、电驱动等型式。 井架采用前开口K 型，低位安装，整体起升

底座采用平行四边形结构，利用绞车动力起升，安全、快捷

9000米(3000HP)系列钻机型号及参数

7000米(2000HP)系列钻机型号及参数

12000米(6000HP)系列钻机型号及参数

TECHNICAL P ARAMETERS

技术参数

TRUCK-MOUNTED DRILLING RIG

车载钻机

整机结构合理，集装化程度高，占地面积小

动力传动系统采用国际名牌发动机和液力机械传动箱；电、气、液路系统集中控制，主要元件采用国际知名品牌元件

采用重载8×6、10×8、12×8、14×8、14×12驱动底盘，配备液压助力转向系统，具有良好的通过性、

越野性和稳定性

绞车和转盘可选用电驱动方式；主刹车采用带式刹车或液压盘式刹车；辅助刹车采用气动水冷推盘式刹车或水刹车型式

转盘传动箱可实现正倒档，适应正反扣钻杆旋转作业，配备反扭矩释放装置以保证钻杆变形能安全释放 井架采用前开口、双节套装前倾式桅形井架，或直立双节套装井架，液压起放及伸缩

可配备铁钻工、排管机械手、动力猫道，减少平台操作工人（选配）

Reasonable structure, a high degree of containerization, and a small footprint.

The power transmission system adopts a world famous engine and a hydrodynamic-mechanical

transmission case. The electric circuit, air course and fluid path systems are under centralized control.

The main components are world famous brands.

It utilizes a heavy-duty 8×6, 10×8, 12×8, 14×8, 14×12 drive template and is equipped with a hydraulic assisted power steering system to ensure excellent trafficability, cross-country performance and stability. Electric drive is optional for winches and turntables. The main brake is a band brake or a hydraulic disc brake. The auxiliary brake is a pneumatic water-cooled push-tray brake or hydromatic brake. The turntable transmission box can achieve forward and reverse gear and is suitable for rotation operation of the right and left hand thread drill rod. A reactive torque release device is equipped to ensure the safe release of drill rod deformation.

The derrick is a front opening, double-section outfitted, forward leaning mast derrick or upright double-section outfitted derrick, which is hydraulically lifted and stretched.

Iron roughneck, rack pipe robots and power catwalks are optional to reduce platform operators.

TECHNICAL P ARAMETERS

技术参数
