gmp-北京光华路SOHO大厦建筑设计文本

gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Perspective
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
New Design Proposal – Inside View
Guanghualu SOHO 2 1st Revision
gmp International GmbH
THE CANYON
Construction Concept Schlaich Bergermann and Partners SBP
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2
floors + access
F1
gmp International GmbH
THE CANYON
Guanghualu SOHO 2
Perspective
gmp International GmbH
百度文库
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Guanghualu SOHO 2 1st Revision
New Design Proposal – Structure Roof - References
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Perspective
THE CANYON
multiple access – public space continues within the building Guanghualu SOHO 2 access gmp International GmbH
THE CANYON
multiple access to shopping areas Guanghualu SOHO 2 access gmp International GmbH
gmp International GmbH
Guanghualu SOHO 2 1st Revision
Glass Roof References
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Sunlight Reflection
Schemes + Units
F2
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
F3
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
B1
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units F1
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Guanghualu SOHO 2 1st Revision
gmp International GmbH
THE CANYON
Shopping
Offices
Total shopping area shared mechanics basement Total shopping area above ground Total rentable area Efficiency
gmp International GmbH
THE CANYON
Guanghualu SOHO 2
1st
Revision
New Design Proposal – Structure Roof / lowered Green Roof
gmp International GmbH
THE CANYON
THE CANYON
viewlines Guanghualu SOHO 2 orientation gmp International GmbH
Guanghualu SOHO 2
siteplan
gmp International GmbH
Guanghualu SOHO 2
birdview
gmp International GmbH
Schemes + Units
F4
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
66.491 sqm 1.171 sqm
Total floor area Shared core area out of shopping floors mechanics above ground
74.644 sqm 905 sqm 1.000 sqm 1.329 sqm 61.313 sqm 79 %
gmp International GmbH
THE CANYON
Layout efficiency
-Targeted efficiency should be 55 to 60% (Retail), 70-75% (Offices). In your current proposal, retail efficiency = 53% -Retail al F4 should "swing out" instead than set back in order to increase the retail area and visibility.
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
distribution of units – shopping
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
THE CANYON
"Canyon"
-Glass roof: technical and cost feasibility. Please provide references. -Sunlight reflected on the glass roof could be a problem for the residential building on the north side. -Is noise within the canyon an issue? Other examples you provided of roofed public spaces mostly regarded pure office buildings. Retail might have different requirements/problems (i.e. temporal events, etc.). Interfererence retail/office have to be considered.
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Comparison F1
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Comparison F2
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
THE CANYON
multiple access to office areas via office lobbies at F2 Guanghualu SOHO 2 access gmp International GmbH
Guanghualu SOHO 2
Inside “The Canyon”
gmp International GmbH
THE CANYON
maximum volume + sunlight contour Guanghualu SOHO 2 form gmp International GmbH
THE CANYON
public spaces Guanghualu SOHO 2 form gmp International GmbH
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Comparison F3
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Comparison F4
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Schemes + Units
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
- 1.000sqm
Terraces
./.
- 1.000sqm
Guanghualu SOHO 2 1st Revision
Calculation
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
distribution of units – office
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Sunlight Reflection
gmp International GmbH
THE CANYON
Guanghualu SOHO 2 1st Revision
Sunlight Reflection
54.009 sqm shared mechanics basement 38.890 sqm Total area of office units 57 % Efficiency
GFA Design Options
130.558 sqm
Set Back F1/F2
- 800 sqm
Setback Top Floors
Guanghualu SOHO 2
1st Revision
德国gmp国际建筑设计有限公司 gmp International GmbH
THE CANYON
Introduction / Overview 1st round
Guanghualu SOHO 2 1st Revision
Perspective
