英文原文：Mineral product monorail reduction gear synopsis1what is reducerReducer is a dynamic communication agencies, the use of gear speed converters, motor rotational speed reducer to the Rotary to be few, and have greater torque institutions.1.1 The reducer role1.1.1 velocity at the same time increase the output torque, torque output ratio by motor output by slowdown, but the attention should be paid to exceed the rated torque reducer. 1.1.2the speed at the same time reduce the inertia load, the inertia of deceleration than reduced to the square. We can look at the General Motors has a value of inertia.1.2 The type of reducerGeneral helical gear reducer has reducer (including parallel shaft helical gear reducer, a worm reducer, bevel gear reducer, etc.), planetary gear reducer, Cycloid reducer, a worm reducer, a planetary friction CVT mechanical machines.1.3 Common reducer1.3.1worm reducer is the main characteristics of a reverse self-locking function, can be larger than a slowdown, input shaft and output shaft axis is not the same, nor in the same plane. But generally larger, transmission efficiency is not high, the accuracy is not high.1.3.2 Harmonic Drive reducer is controllable using flexible components to transfer elastic deformation and dynamic movement, not volume, high precision, but the disadvantage is that flexible wheel limited life, impatient shocks, rigidity and pieces of metal relatively poor. Not too high speed input.1.3.3 planetary reducer its comparative advantage is compact structure, the return gap small, high precision, and have a long life span rated output torque can be done great. However, a price slightly expensive, the requirements of parts before assembly ：Rolling cleaning with gasoline, kerosene other parts cleaning. All parts and cabinet not allowed to have any impurities exist. Gear box and the inner wall (Worm), unprocessed surface has not been coated twice erosion-resistant oil paint box has the outer surface coated primer and paint color (color requested by host).Parts coated with a face wash after lubricants.2 the requirements of installation and adjustment2.1Rolling installationRolling bearing inner ring should be installed at the shaft shoulder close to gap must not pass 0.05 mm thick Cypriot feet.2.2Bearing axial clearanceOf the clearance can not be adjusted bearings (such as deep groove ball bearings), axial clearance of 0.25 to 0.4 mm; the clearance adjustable bearing axial clearance numerical table. Click Tapered Roller Bearings axial clearance; angular contact ball bearing axial clearance.2.3Gear (Worm) meshing tooth space availableCypriot side foot of lead or pressure. Will be lead wire on the alveolar, and then turning gear and squash lead wire, measuring two teeth side was crushed lead wire thickness and the size of which is adjacent teeth.2.4 Tooth contact dot cylinder gear tooth contact Dot 2-10-4; bevel gear tooth contact Dot 2-11-4; Gearing contact Dot 2-12-4.3 seal requirements3.1 Box partition between the surface does not allow any pads filled, but can be coated or water glass sealant to ensure that the seal;3.2Assembly, the bolt tightening box, before using 0.05 mm Cypriot-foot inspection Covers Block with me and between the sealing surface;3.3Shaft seal should stretch to smear grease. The seal should be installed in strict accordance with the requirements.4 lubrication requirements4.1 Rationally determine the types of lubricants and greases and grades4.2 Bearing lubrication fat, grease filled in the general Fatliquor space can be 1 / 2 to 2 / 3.4.3 Lubricants should be regularly replaced, the new reducer used for the first time, the operation of oil-7 ~ 14 days, according to the situation can be after every 3 to 6 months for first oil.5 the test requirements5.1 Empty operation: at rated speed is, anti-running 1 to 2 hours;5.2 Load test: at rated speed, rated load operation, the oil temperature balance to date. OnO, bearing the gear reducer, requested the pool temperature is not more than 35 Ctemperature rise no more than 40 C O ; the worm reducer, requested the pool temperature not more than 60C O , bearing temperature of not more than 50 C O .6 packaging and transportation requirements6.1 Protruding shaft and its annex should Oiler packaging;6.2 Handling, lifting may not use screw rings and lug all of the above technical requirements are not necessarily listed, and sometimes also by other projects, mainly by the specific design requirements.7 Technical requirements7.1 Assembly, all parts cleaning with kerosene, gasoline Rolling cleansing, while the existence of any debris. Oil is not painted wall corrosion coatings twice;7.2 Backlash with lead wire mesh test of not less than 0.16 mm, lead wire Backlash may not exceed the smallest of the four times;7.3 Used Tu-color dot test. Tooth high point of contact by not less than 40% of contact spots on teeth not less than 50 per cent. Can be used when necessary, grinding or scraping after grinding to improve contacts;7.4 Bearing axial clearance should be adjusted: φ40 0.05 - 0.1 mm, φ55 0.08 - 0.15 mm;7.5 Test reducer subdivision surface, the contact surface and seal, oil spills are not allowed. Split-Tu allowed to paint or water glass seal and allow the use of any filler;7.6 Engine lubricants to the contents N100 provisions height.8 GEAR INTRODUCTION8.1 Abstract:The important position of the wheel gear can't falter in traditional machine and modern machines.The wheel gear mainly install the direction that delivers the dint at the principal axis box. The passing to process to make them can is divided into many model numbers, used for many situations respectively.8.2 Key words: Wheel gearIn the force analysis of spur gears, the forces are assumed to act in a single plane. We shall study gears in which the forces have three dimensions. The reason for this, in the case of helical gears, is that the teeth are not parallel to the axis of rotation. And in the case of bevel gears, the rotational axes are not parallel to each other. There are also other reasons, as we shall learn.Helical gears are used to transmit motion between parallel shafts. The helix angle is the same on each gear, but one gear must have a right-hand helix and the other a left-hand helix. The shape of the tooth is an involutes helicoids. If a piece of paper cut in the shape of a parallelogram is wrapped around a cylinder, the angular edge of the paper becomes a helix. If we unwind this paper, each point on the angular edge generates an involutes curve. The surface obtained when every point on the edge generates an involutes is called an involutes helicoids.The initial contact of spur-gear teeth is a line extending all the way across the face of the tooth. The initial contact of helical gear teeth is a point, which changes into a line as the teeth come into more engagement. In spur gears the line of contact is parallel to the axis of the rotation; in helical gears, the line is diagonal across the face of the tooth. It is this gradual of the teeth and the smooth transfer of load from one tooth to another, which give helical gears the ability to transmit heavy loads at high speeds. Helical gears subject the shaft bearings to both radial and thrust loads. When the thrust loads become high or are objectionable for other reasons, it may be desirable to use double helical gears. A double helical gear (herringbone) is equivalent to two helical gears of opposite hand, mounted side by side on the same shaft. They develop opposite thrust reactions and thus cancel out the thrust load. When two or more single helical gears are mounted on the same shaft, the hand of the gears should be selected so as to produce the minimum thrust load.Crossed-helical, or spiral, gears are those in which the shaft centerlines are neither parallel nor intersecting. The teeth of crossed-helical fears have point contact with each other, which changes to line contact as the gears wear in. For this reason they will carry out very small loads and are mainly for instrumental applications, and are definitely not recommended for use in the transmission of power. There is on difference between a crossed helical gear and a helical gear until they are mounted in mesh with each other. They are manufactured in the same way. A pair of meshed crossed helical gears usually have the same hand; that is, a right-hand driver goes with a right-hand driven. In the design of crossed-helical gears, the minimum sliding velocity is obtained when the helix angle are equal. However, when the helix angle is not equal, the gear with the larger helix angle should be used as the driver if both gears have the same hand.Worm gears are similar to crossed helical gears. The pinion or worm has a small numberof teeth, usually one to four, and since they completely wrap around the pitch cylinder theyare called threads. Its mating gear is called a worm gear, which is not a true helical gear. A worm and worm gear are used to provide a high angular-velocity reduction between nonintersecting shafts which are usually at right angle. The worm gear is not a helical gear because its face is made concave to fit the curvature of the worm in order to provide line contact instead of point contact. However, a disadvantage of worm gearing is the high sliding velocities across the teeth, the same as with crossed helical gears.Worm gearing are either single or double enveloping. A single-enveloping gearing is one in which the gear wraps around or partially encloses the worm.. A gearing in which each element partially encloses the other is, of course, a double-enveloping worm gearing. The important difference between the two is that area contact exists between the teeth of double-enveloping gears while only line contact between those of single-enveloping gears. The worm and worm gear of a set have the same hand of helix as for crossed helical gears, but the helix angles are usually quite different. The helix angle on the worm is generally quite large, and that on the gear very small. Because of this, it is usual to specify the lead angle on the worm, which is the complement of the worm helix angle, and the helix angleon the gear; the two angles are equal for a 90-deg. Shaft angle.中文译文：1 什么是减速器减速器是一种动力传达机构，利用齿轮的速度转换器，将马达的回转数减速到所要的回转数，并得到较大转矩的机构。
