A RESEARCH ON DATA PROCESSING MODEL OF GPS DAM

DEFORMATION MONITORING NETWORK

Abstract: Considering the particularity of the GPS dam deformation monitoring network, a data processing model based on the station orthogonal coordinate system for three-dimension GPS dam deformation monitoring network, was put forward. Also, a mathematical model of using the clustering analysis method in fuzzy mathematics to test the relative stability of quasi-stable points(or datum marks) was successfully brought forward. The adjustment method during the course of data processing was quasi-stable adjustment. At last, a software system of three-dimension GPS dam deformation monitoring network was designed and opened up with the help of Visual Basic Language. With three periods o'bservation data from the GPS deformation monitoring network of a dam, an adjustment calculation was done by the software.The calculation result shows that the mathematical models can be more suitable for the data processing in GPS dam deformation monitoring network.

Key words: GPS, Dam deformation monitoring, Quasi-stable adjustment, Clustering analysis 1.Introduction

WGS-84 coordinate system is generally used in GPS. But local or independent coordinate systems are usually chosen in dam deformation monitoring networks for their small areas. During the course of past data processing, the adjustment under WGS-84 coordinate system for

independent networks or networks with several fixed points is often firstly made. Then, the transformation from WGS-84 coordinate system to

local(or independent) coordinate systems is done. For GPS deformation monitoring networks with repetitive observation data, the obvious change of datum marks coordinates under the two different coordinate systems can be brought by the tiny deformation of datum marks among different periods of observation. And the greater error can be made during the coordinate transformation. If a local Gauss coordinate system is chosen, the projection distortions can also be produced by the transformation itself. For the reasons above, the station orthogonal coordinate system is chosen as the reference coordinate system for data processing of GPS dam deformation networks. And the mathematical model is put forward and deduced.

2.Data processing model based on the station orthogonal coordinate system for three-dimension GPS deformation monitoring networks

2.1 Coordinate system

The station orthogonal coordinate system is a left-hand coordinate system. Its origin is set at one of the GPS monitoring points. The E(X) axis points at the meridian passing the origin. It is on the tangent plane of the origin. And the right north is taken as forward direction. The H(Z) axis is on the
