雾化器启动维护保养说明书

START UP AND MAINTENANCE INSTRUCTIONS FOR

SHATOMIZER :

喷雾器

启动及维护手册

TABLE OF CONTENTS目录

1 START UP OF SHATOMIZER 启动喷雾器

1.1Installation cold state / first start up 冷状态安装/首次启动

1.2Start up after standstill 停止后再启动

1.3Action temporary standstill 暂停启动

1.4Withdrawing shatomizer from use 使用状态中撤下喷雾器

1.5Replacing shatomiser 喷雾器的更换

2 SETTINGS 装置配备

2.1 Electrical cabinet: 电气柜

2.1.1 Vibro Check稳定性检查

2.2 Mechanical cabinet: 机械柜

2.2.1 Oil-air lubrication unit 油气润滑单元

2.2.2 pressure monitoring device primary cooling 压力监控装置初始冷

却

2.2.3 Heating element 加热装置

2.2.4 Pressure reducing valve 减压阀

2.2.5 Manual temperature control valve on secondary cooling circuit第二

阶段冷却循环手动温控阀

3 MAINTENANCE 维护

3.1 Maintenance维护

3.1.1 Shatomizer / Spray-disc 喷雾器/喷雾盘

3.1.2 Mechanical cabinet 机械柜

3.1.2.1 General 概述

3.1.2.2 Secondary water filter 二次水过滤

3.1.2.3 Filter in reducing valve secondary water 二次水过滤减压阀

中的过滤器

3.1.2.4 Temperature-controlled valve in secondary water pipe 二次

水循环管中的温控阀

3.1.2.5 Oil-lubrication unit 注油单元

3.1.2.6 Cooling air fan for shaft 传动轴空气冷却风扇

3.1.2.7 Cooling pumps for primary cooling system 基本冷却系统冷却泵

3.2 Data sheets 相关数据

3.2.1 Intervention report shatomizer 喷雾器干预报告

3.2.2 Shatomizer filing card 喷雾器存档实用卡片

1 START UP OF SHATOMIZER

1 喷雾器启动

1.1 INSTALLATION COLD STATE / FIRST START UP:

1.1冷状态安装/首次启动

1) Place shatomizer in wait position placed closest to the shaft

将喷雾器放置在离传动轴最近的地方

2) Cover in hoist. 置于起重机下方

3) Connect couplings on shatomizer in following order: 按以下顺序联接各部件

- Connect steel lifting cable 联接起吊钢丝绳

- Power plug 电源电缆插头

- Control plug 控制电缆插头

- Cooling water in 冷却水进水

- Cooling water out 冷却水回水

- Lime milk / and water 石灰乳/和水

- Sealing air 密封空气

- Removal of closing coupling oil lubrication and place on the holder

Provided 卸除油润滑装置隔离联接器，放在底座上

- Installation of oil lubrication coupling 安装油润滑装置联接器。

4) Remove closing cover on the shaft. 移除传动轴的隔离罩

5) Place shatomizer in shaft 将喷雾器置于传动轴上

6) Connect all couplings on cover in the same order as described above,

with the exception of the steel cable. 同样按照以上顺序联接除钢帘线以外

的盖罩的所有部件。

7) reset Vibro Check in electrical cabinet 在电气柜中复位震动仪。

8) Place switch electrical cabinet to manual 将电气柜开关设置为手动

9) Give release cooling air fan 打开空气冷却扇

10) Place switch electrical cabinet on local auto 将电气柜开关设置为本地自动

11) Give release PU 释放PU

-If the temperature of the primary water is less than 28°C, the

heating starts to operate Switching operation ON – 28°C – 32°C –OFF

如果初始水温低于28°C,加运行热开始

（28°C开 32°C关）

-When the temperature of the bearings has reached 20°C, the

compressed air valve of the lubrication unit opens, this is protected via

the program. Further operations are not possible until this temperature

has been reached.如果轴承的温度达到20°C，润滑单元气压阀启

动，这是程序设置的保护程序。如果未达到这个温度，将不会进
