的张紧度，以防肘板在工作时脱落。
3. Before adjusting discharge door, release strain spring, and then adjust spring
in order to prevent drop of ancon plate.
五、使用须知
V. Notes for use
二、主要技术性能
II. Main technical performances
进料口尺寸（宽×长） Size of feed inlet (width × length) 调整范围 Adjusted range 最大进料粒度 Maximum feed granularity 偏心轴转速 Rotate speed of eccentric shaft 处理能力 Treatment capacity 设备重量（不含电动机） Weight of equipment (excluding motor) 外形尺寸（长×宽×高） Dimensions (length × width × height)
increase. 3. Generally, temperature rise o bearing shall not exceed 35℃ and
(III) Maintenance and use:
1、设备运转正常后，方可开始投料。
2、待破碎物料均匀地加入破碎腔内，应避免侧面加料以防负荷不均
或单边突增。
3、在正常工作情况下，轴承温升不应超过35℃.最高温度不得超过
70℃，否则应立即停车，查明原因加以清除。
4、 停车前首先停止加料，待破碎腔内物料排空后，方可关闭电动
调整横梁与机架侧墙电焊钢连接，当排料口调小时，首先放松拉杆 弹簧和拉紧螺丝，然后用扳手旋转止动螺钉，使止动螺钉向前顶起垫片 组，再插入新增加的垫片，直至所要求的排料口尺寸时，先退回止动螺 钉，使垫片组由动颚部件自重压紧，再旋紧拉紧螺母并紧固定。最后适 当旋紧拉杆弹簧，反之则由小变大（抽掉垫片）。
Adjusting beam is welded to side wall of bracket. When the discharge door is adjusted smaller, release tie spring and tightens screw, rotate retention screw to make gasket up, insert new gasket to achieve required size of discharge door, turn back retention screw to make jaw press closely the gaskets, rotate nut staybolt and fix it and at last, rotate tie spring tight. Conversely, from small size to large one (draw gasket out).
四、安装说明 IV. Installation
本机由制造厂装配后整机供应的，用户收到产品后就检查，以便消
除在运输过程中可能产生的弊病。 The equipment after assembly is provided by manufacturer and check
shall be carried out as soon as receiving product in order to avoid possible troubles during transportation.
2、基础的重量，大致可取为机器重量的5-10倍，地基的深度要大于
该处土地冻结的深度，关于机器的安装及地脚螺栓的位置，可参阅基础
图。
2. Weight of base can be determined at 5-10 times of that of equipment and the depth of base shall be more than that of local frozen earth. Refer to the Base figure for locations of installing equipment and foundation bolt. 3、在调整排料口前，应先松开拉紧弹簧，待调整好后，再适当调整弹簧
为了确保破碎机正常运转，充分发挥应有的性 能，望各使用单位在设备投入运行之前，首先熟悉 本说明书，并按说明书内容进行操作。
In order to guarantee normal running of the crusher and complete exertion of due performances, this instruction shall be well understood before the equipment is put into running and the operation shall conform to the instructions.
5. Clean ore or other things in crushing chamber.
(II) Start crusher
1. Start under normal driving conditions.
2. Start only under no load.
3. Stop and get rid of hidden trouble when abnormal thing occurs.
1000×1200mm 195—265mm 850mm 210r/min 197—214m3/h 51t 3480×2876×3330mm
电动机 Motor
型号 size 功率 power 转速 rotation speed
Y315M3-8 110KW 740r/min
三、结构简述
III. Structure 本机主要由机架、动颚、偏心轴、颚板、肘板等零部件组成。电动 机通过三角皮带传动偏心轴旋转，使动颚按照已调好的轨迹进行运动， 从而将破碎腔内物料予以破碎。 The equipment consists of bracket, jaw, eccentric shaft, jaw plate and ancon plate etc. Eccentric shaft is driven to rotate by motor and jaw runs on adjusted track to crush materials in crushing chamber. 机架为整体铸钢结构，机架前壁上装有楔形螺栓紧固的固定颚板。
5、检查破碎腔内有无矿石或其它杂物，如有时应清除干净。 （二）破碎机的启动：
1、经检查确认设备传动部分情况正常方可启动。 2、本机只允许无负荷情况下启动。 3、启动后，如发现不正常情况时，应立即停车查明原因，排除隐患 方可再启动。 （三）维护和使用：
4. Cancel unsecured protection devices.
一、用途 I. Application:
本破碎机用于粗碎、中碎抗压强度极限不超过245MPa的各种岩石或矿
石。
The crusher is applicable for the rough and medium crushing of rocks and ores that have a compressive strength not more than 245MPa.
在破碎机左右的机架内侧壁上装有边护板，以保护机架内侧壁的磨损。 The bracket is welded by steel plate. On the front arm of bracket, jaw plate is fixed by wedge-shaped bolt. Edge protection plate is equipped on inside wall of bracket to prevent abrasion.
1、由于本机工作时振动较大，故建议将机器装在混凝土基础上，为 减少振动、噪音和吸振以免机器工作时振动影响建筑基础，最好在破碎 机和混凝土基础中间垫以硬木垫板、夹布橡胶带或其它缓冲材料。
1. It is suggested to install the equipment on concrete base to decrease vibration, noise and absorption of shock in order to avoid impact on building base. Adding ironwood, rubber belt or other buffer materials may as well.
支承作用外，在外来不能破碎的异物，进入破碎腔内时，破碎机负荷物 增加的情况下，起保险作用，既自身断裂，从而保护其它机件不被损 伤。
The other end of ancon plate is supported on adjusting beam. Besides supporting jaw, the ancon plate plays the role of insurance during load increase caused by the uncrushed material’s entry into crushing chamber. It will be broken to protect other pieces from damage.
动颚为一成型铸钢件，正面装有活动颚板，其上部借偏心轴与滚柱轴
承悬挂在机架上、下部支承在肘板上，并与肘板成滚动接触，在偏心轴
两端装有飞轮和槽轮。
The moving jaw is a shaped casting with a kinetic jaw plate on the face. The
upper part of jaw is hung on upper and lower parts of bracket and supported on
ancon plate by eccentric shaft and roller bearing. There equipped flywheel and
grooved pulley at both ends of eccentric shaft. 肘板的另一端支承于调整横梁上并与其成滚动接触。肘板除 对动颚起
(一)启动前的准备工作：
(I) Preparations before
start
1、为仔细检查轴承的润滑情况是否良好，轴承内及肘板的联接处是
否有足够的润滑脂。
2、仔细检查所有的紧固是否紧固。
3、传动皮带是否良好，发现皮带有破损现象，应及时更换，当皮带
和皮带轮上有油污时，应用干净抹布将其擦净。
1. Check lubrication of bearings and guarantee adequate lubricant inside bearings and on joint of ancon.
2. Check carefully all tightness. 3. Change the abraded belt and clean the oil stain on belt and belt pulley with clean duster cloth. 4、防护装置是否良好，如发现不安全现象，应立即消除之。
机。
5、在破碎时，如因破碎腔内物料阻塞而造成停车，应立即关闭电动
机，必须将物料清除后，方可再行起动。
6、颚板一端磨损后，方可调头使用。
（四）Байду номын сангаас滑：
1、经常注意和及时做好摩擦面的润滑工作，可保证设备的正常运转
和延长设备使用寿命。 1. Feeding equipment after normal running. 2. Material shall be fed evenly in order to prevent side load or side weight
3. Before adjusting discharge door, release strain spring, and then adjust spring
in order to prevent drop of ancon plate.
五、使用须知
V. Notes for use
二、主要技术性能
II. Main technical performances
进料口尺寸（宽×长） Size of feed inlet (width × length) 调整范围 Adjusted range 最大进料粒度 Maximum feed granularity 偏心轴转速 Rotate speed of eccentric shaft 处理能力 Treatment capacity 设备重量（不含电动机） Weight of equipment (excluding motor) 外形尺寸（长×宽×高） Dimensions (length × width × height)
increase. 3. Generally, temperature rise o bearing shall not exceed 35℃ and
(III) Maintenance and use:
1、设备运转正常后，方可开始投料。
2、待破碎物料均匀地加入破碎腔内，应避免侧面加料以防负荷不均
或单边突增。
3、在正常工作情况下，轴承温升不应超过35℃.最高温度不得超过
70℃，否则应立即停车，查明原因加以清除。
4、 停车前首先停止加料，待破碎腔内物料排空后，方可关闭电动
调整横梁与机架侧墙电焊钢连接，当排料口调小时，首先放松拉杆 弹簧和拉紧螺丝，然后用扳手旋转止动螺钉，使止动螺钉向前顶起垫片 组，再插入新增加的垫片，直至所要求的排料口尺寸时，先退回止动螺 钉，使垫片组由动颚部件自重压紧，再旋紧拉紧螺母并紧固定。最后适 当旋紧拉杆弹簧，反之则由小变大（抽掉垫片）。
Adjusting beam is welded to side wall of bracket. When the discharge door is adjusted smaller, release tie spring and tightens screw, rotate retention screw to make gasket up, insert new gasket to achieve required size of discharge door, turn back retention screw to make jaw press closely the gaskets, rotate nut staybolt and fix it and at last, rotate tie spring tight. Conversely, from small size to large one (draw gasket out).
四、安装说明 IV. Installation
本机由制造厂装配后整机供应的，用户收到产品后就检查，以便消
除在运输过程中可能产生的弊病。 The equipment after assembly is provided by manufacturer and check
shall be carried out as soon as receiving product in order to avoid possible troubles during transportation.
2、基础的重量，大致可取为机器重量的5-10倍，地基的深度要大于
该处土地冻结的深度，关于机器的安装及地脚螺栓的位置，可参阅基础
图。
2. Weight of base can be determined at 5-10 times of that of equipment and the depth of base shall be more than that of local frozen earth. Refer to the Base figure for locations of installing equipment and foundation bolt. 3、在调整排料口前，应先松开拉紧弹簧，待调整好后，再适当调整弹簧
为了确保破碎机正常运转，充分发挥应有的性 能，望各使用单位在设备投入运行之前，首先熟悉 本说明书，并按说明书内容进行操作。
In order to guarantee normal running of the crusher and complete exertion of due performances, this instruction shall be well understood before the equipment is put into running and the operation shall conform to the instructions.
5. Clean ore or other things in crushing chamber.
(II) Start crusher
1. Start under normal driving conditions.
2. Start only under no load.
3. Stop and get rid of hidden trouble when abnormal thing occurs.
1000×1200mm 195—265mm 850mm 210r/min 197—214m3/h 51t 3480×2876×3330mm
电动机 Motor
型号 size 功率 power 转速 rotation speed
Y315M3-8 110KW 740r/min
三、结构简述
III. Structure 本机主要由机架、动颚、偏心轴、颚板、肘板等零部件组成。电动 机通过三角皮带传动偏心轴旋转，使动颚按照已调好的轨迹进行运动， 从而将破碎腔内物料予以破碎。 The equipment consists of bracket, jaw, eccentric shaft, jaw plate and ancon plate etc. Eccentric shaft is driven to rotate by motor and jaw runs on adjusted track to crush materials in crushing chamber. 机架为整体铸钢结构，机架前壁上装有楔形螺栓紧固的固定颚板。
5、检查破碎腔内有无矿石或其它杂物，如有时应清除干净。 （二）破碎机的启动：
1、经检查确认设备传动部分情况正常方可启动。 2、本机只允许无负荷情况下启动。 3、启动后，如发现不正常情况时，应立即停车查明原因，排除隐患 方可再启动。 （三）维护和使用：
4. Cancel unsecured protection devices.
一、用途 I. Application:
本破碎机用于粗碎、中碎抗压强度极限不超过245MPa的各种岩石或矿
石。
The crusher is applicable for the rough and medium crushing of rocks and ores that have a compressive strength not more than 245MPa.
在破碎机左右的机架内侧壁上装有边护板，以保护机架内侧壁的磨损。 The bracket is welded by steel plate. On the front arm of bracket, jaw plate is fixed by wedge-shaped bolt. Edge protection plate is equipped on inside wall of bracket to prevent abrasion.
1、由于本机工作时振动较大，故建议将机器装在混凝土基础上，为 减少振动、噪音和吸振以免机器工作时振动影响建筑基础，最好在破碎 机和混凝土基础中间垫以硬木垫板、夹布橡胶带或其它缓冲材料。
1. It is suggested to install the equipment on concrete base to decrease vibration, noise and absorption of shock in order to avoid impact on building base. Adding ironwood, rubber belt or other buffer materials may as well.
支承作用外，在外来不能破碎的异物，进入破碎腔内时，破碎机负荷物 增加的情况下，起保险作用，既自身断裂，从而保护其它机件不被损 伤。
The other end of ancon plate is supported on adjusting beam. Besides supporting jaw, the ancon plate plays the role of insurance during load increase caused by the uncrushed material’s entry into crushing chamber. It will be broken to protect other pieces from damage.
动颚为一成型铸钢件，正面装有活动颚板，其上部借偏心轴与滚柱轴
承悬挂在机架上、下部支承在肘板上，并与肘板成滚动接触，在偏心轴
两端装有飞轮和槽轮。
The moving jaw is a shaped casting with a kinetic jaw plate on the face. The
upper part of jaw is hung on upper and lower parts of bracket and supported on
ancon plate by eccentric shaft and roller bearing. There equipped flywheel and
grooved pulley at both ends of eccentric shaft. 肘板的另一端支承于调整横梁上并与其成滚动接触。肘板除 对动颚起
(一)启动前的准备工作：
(I) Preparations before
start
1、为仔细检查轴承的润滑情况是否良好，轴承内及肘板的联接处是
否有足够的润滑脂。
2、仔细检查所有的紧固是否紧固。
3、传动皮带是否良好，发现皮带有破损现象，应及时更换，当皮带
和皮带轮上有油污时，应用干净抹布将其擦净。
1. Check lubrication of bearings and guarantee adequate lubricant inside bearings and on joint of ancon.
2. Check carefully all tightness. 3. Change the abraded belt and clean the oil stain on belt and belt pulley with clean duster cloth. 4、防护装置是否良好，如发现不安全现象，应立即消除之。
机。
5、在破碎时，如因破碎腔内物料阻塞而造成停车，应立即关闭电动
机，必须将物料清除后，方可再行起动。
6、颚板一端磨损后，方可调头使用。
（四）Байду номын сангаас滑：
1、经常注意和及时做好摩擦面的润滑工作，可保证设备的正常运转
和延长设备使用寿命。 1. Feeding equipment after normal running. 2. Material shall be fed evenly in order to prevent side load or side weight
