7.2 Measurement of Velocity
7.3 Measurement of Acceleration
7.4 Vibration test
7.1 Overview
Measurement of velocity and acceleration for vehicle, train, ship, plane, etc,and that of their moving attitude Rotational velocity for output shaft speed of engine and generator Velocity of rolled plate, strip, bar, tubing material Measurement of vibration for large devices and engineering
Average velocity method
Correlation velocity measurement
Strong anti-interference
ability and make the measurement under complex interference conditions .
and magnitude of changes in velocity.物体运动时单 位时间内的速度增量,m/s2
Rotational Velocity:物体运动时单位时间内的转 数,r/min Angular Velocity:物体单位时间内转过的角度, rad/s
Chapter Seven Measurement of velocity, acceleration and vibration
Contents
7.1 Overview
7.2 Measurement of Velocity
7.3 Measurement of Acceleration
7.4 Vibration test
7.2 Measurement of Velocity
From motion form: measurement of linear velocity( 线速度) and angular velocity(角速度) From reference: measurement of absolute velocity(绝 对速度) and relative velocity(相对速度)
7.2 Measurement of Velocity
Instantaneous velocity, on the other hand, describes the motion of a body at one particular moment in time. From accessible means: measurement of direct velocity(直接速度)and indirect one(间接速度)
From numerical feature: measurement of average velocity(平均速度) and instantaneous velocity(瞬时 速度) The average velocity of an object is the total displacement during some extended period of time, divided by that period of time.
