S系列双吸中开泵样本

Assembly and Disassembly
1. Assemble impeller, shaft sleeve, shaft sleeve nuts, packing sleeve, packing rings, packing gland,
block water ring in order on the pump shaft. Afterwards cross the suction seal ring, and then the bearing
The pump shaft is supported by two single radial ball bearing. The bearing fitted on the ends of the pump casing is installed in the bearing body and is lubricated by Ca-base grease. The double suction seal ring is used to reduce the leaking water from the pressure water house which would flow back to the suction water house.
安装
Installation………….………………………………………………………………………………⑷
启动、停止和动行
Starting, Stopping and Running ..………….……………………………………………………⑸
泵用轴承
The Bearing of Pump ……………………………………………………………………………⑺
外形尺寸图
The Drawing for the Outline Dimensions….……………………………………………………⒃
安装尺寸图
The Drawing for the Installation Dimensions ……………………………. .……………………⒄
1
概述
S 系列和 Sh 系列泵是单级、双吸卧式中开式离心泵。供输送清水及物理化学性质类似于水的液体。改 变泵结构及材质可用于输送多泥砂水和各类腐蚀性液体。输送液体温度不得超过 80℃。适合工厂、矿山、化 工、石油、城市、电站、农田排灌和各种水利工程。
water supply in factories, mines, chemical industry, petroleum, cities, hydropower stations, various
conservancy projects and irrigation in farms etc.
The rotating direction of Series S is clockwise, when viewed from the motor end.
are use to pump clean water or similar liquids in physical and chemical properties. It can handle heavy
sand and mud water or various corrosive after changing the pump construction and materials. The temperature of the pumped liquid should not be exceeded 80℃. And the pumps are mainly suitable for
Construction Description
The suction and discharge of the pump are both under the centerline of the pump shaft, they are vertical to the shaft centerline and go to horizontal direction. You need not dismount the motor and the outlet and inlet pipes for repairing.
可能发生的故障及其消除方法
Possible Malfunctions and Solutions………….…………………………………………………⑻
泵结构图
Construction Drawing of Pump …………………………………………………………………⑽
泵性能表
Performance Table of Pump ….……………….…………………………………………………⑾
名义直径(mm) <50
50～120 120～260 260～500 500～800 800～1250
跳动量(mm)
0.03
0.04
0.05
0.06
0.08
0.10
3．将转子部件装在泵体上，用轴套螺母调整叶轮的轴向位置到泵体流道的中间加以固定。 4．装上填料，放好中开面纸垫，盖上泵盖，打紧定位锥销后，拧紧泵盖螺母，最后装上填料压盖。但 不要将填料压得太紧，填料过紧会使轴套发热，耗费功率较大；也不要压得太松，过松会使液体渗漏大，水 泵效率降低。 5．装配完后，用手转动转子，无卡擦、轻滑均匀即可。 6．拆卸可按上述装配顺序相反进行。
机。
泵主要零件有：泵体、泵盖、叶轮、轴、双吸密封环、轴套、轴承等。除泵轴材料为优质碳素钢外，其
余主要零件为铸铁制成。根据用户需要，泵材质也可选用其它材质，如 ZG25、1Cr18Ni9、316 和 316L 等。 泵体与泵盖构成叶轮的工作室，在进、出水法兰上设有安装真空表和压力表的管螺孔，进出水法兰的下
S 系列泵从电机端看为顺时针方向旋转。 Sh 系列泵从电机端看为逆时针方向旋转。 泵型号意义：300S—58A
300—泵进口直径（毫米） S—单级双吸离心泵 58—泵扬程（米） A—叶轮外径被第一次切割，流量扬程等性能参数将降低。
Summary
Series S and Series Sh pumps are single stage, double suction and axially split centrifugal pump and
部设有放水的管螺孔。
叶轮经过静平衡校验，用轴套和两侧的轴套螺母固定，其轴向位置可通过轴套螺母进行调整，叶轮的轴
向力利用其叶片的对称布置、两面进水达到平衡。
2
泵轴由两个单列向心球轴承支承，轴承装在泵体两端的轴承体内，用钙基黄油润滑。双吸密封环用以减 少水泵压水室的水漏回吸水室。
泵通过弹性联轴器与电动机直接传动。必要时亦可用柴油机传动。 轴封为填料密封，为了防止空气进入泵内和冷却润滑密封腔，在填料之间装有填料环，水泵工作时少量 高压水通过泵盖中开面上的梯形凹槽流入填料腔，起水封作用。 轴封根据用户需要，亦可采用机械密封。
The pump is driven by the motor through the flexible coupling. It also can be driven by diesel engine if it is necessary.
The shaft seal is packing seal. The packing ring is installed between the packing in order to prevent air leaking into the pump and cooling lubrication sealing, and while the pump working, there is a little high pressure water going through into packing cavity by the groove on the horizontally split face of the pump cover, function as water seal .
The impeller have been done static balance test. It is fixed on the shaft by the shaft sleeves and the shaft sleeve nuts, which axial position can be adjusted by the sleeve nuts. The symmetrical distribution of the impeller to balance the axial force of the impeller.
Main parts of pump: pump casing, pump cover, impeller, shaft, double suction seal ring, shaft sleeve, bearing etc. They are made of cast iron except the shaft material being made of fine carbon steel. We can according to user’ s requirement to adopt the other material, such as ZG25, 1Cr18Ni9, 316, 316L etc.
part andwenku.baidu.comcoupling.
2. Respectively inspect the radial jumping value of the excircle of the impeller seal ring position and the
目录
CONTENTS
概述
Summary ……………...……………………………………………………………………………⑴
结构说明
Construction Description …………………………………………………………………………⑵
装配与拆卸
Assembly and Disassembly ………………………………………………………………………⑶
S – Single-stage double-suction split case centrifugal pump
58 – Head 58m
A – Impeller cut via the first time
结构说明
本型泵的进口与出口均在水泵轴心线下方，与轴线垂直呈水平方向，检修时无需拆卸进出水管路及电动
The rotating direction of Series Sh is counterclockwise, when viewed from the motor end.
The model of pump represents the meaning : 300S – 58A
300 – Diameter of suction (mm)
The impeller working house is composed of pump casing and pump cover. The threaded holes for installing the vacuum meter and pressure meter are separately located at the suction flange and the discharge flange. At the bottom of the suction or discharge flange there is a threaded hole for drain .
The mechanical seal depend on user’ s requirements.
装配与拆卸
1．装配转子部件：依次将叶轮、轴套、轴套螺母、填料套、填料环、填料压盖、挡水圈、轴承部件装 在轴上，并套上双吸密封环，然后装上联轴器。
3
2．分别检查转子部件上叶轮的密封环外圆、轴套外圆，其径向跳动应不超过下表的规定。
