数控走心机工件加工完成图如下：
上图中的工件在数控走心机中的编程如下：$1
M500
T0101
M8
M10
G4X0.2
M7S2000F0.02
M5
M11
G4X0.2
G300X-1.5Z110.0T0101
G150Z0
G4X0.2
M10
G4X0.2
G0Z-2.0
G1X-1.5F0.02
G0X60.0Z-2.0
M51
G99 G18
T0202
G97 S1500 M03
G0 X40.
G0 Z0.
X17.2
G1 X-0.8 F0.02
Z-0.2
G99 F0.03
G0 X6.088
Z-0.236
G1 X7.6 Z0.519 F0.02
Z6.08
X13.426
X14.35 Z6.542
Z12.216
X14.438 Z12.241
X16.522 Z13.283
G0 X40. M05
M01
G98 G19
T0909
M50
M23 S3=3500
G0 X30.
G0 Y5.651
G0 C0.
G0 X38.37 Y5.651
C-139.785
Z2.337
X15.714
G1 X11.714 H0. F500.
X11.714 Z2.349 H0. F544.
X11.714 Y5.649 Z2.438 H0. F498. X11.714 Y5.642 Z2.527 H0. F499. X11.714 Y5.632 Z2.616 H0. F501. X11.714 Y5.617 Z2.704 H0. F499. X11.714 Y5.599 Z2.792 H0. F502. X11.714 Y5.577 Z2.878 H0. F496. X11.714 Y5.551 Z2.964 H0. F502.
X11.714 Y5.521 Z3.048 H0. F499. X11.714 Y5.487 Z3.131 H0. F501. X11.71 Y5.45 Z3.212 H0. F498. X11.71 Y5.409 Z3.292 H0. F503. X11.71 Y5.364 Z3.37 H0. F503. X11.71 Y5.317 Z3.445 H0. F495. X11.71 Y5.265 Z3.518 H0. F501. X11.706 Y5.211 Z3.589 H0. F499. X11.706 Y5.154 Z3.658 H0. F500. X11.706 Y5.093 Z3.724 H0. F502. X11.702 Y5.03 Z3.787 H0. F498. X11.702 Y4.963 Z3.847 H0. F503. X11.702 Y4.895 Z3.904 H0. F496. X11.698 Y4.823 Z3.958 H0. F503. X11.698 Y4.75 Z4.009 H0. F498. X11.698 Y4.674 Z4.056 H0. F500. X11.694 Y4.596 Z4.1 H0. F501. X11.694 Y4.516 Z4.141 H0. F503. X11.694 Y4.435 Z4.178 H0. F498. X11.69 Y4.352 Z4.211 H0. F499. X11.69 Y4.267 Z4.24 H0. F502. X11.69 Y4.182 Z4.266 H0. F497. X11.686 Y4.095 Z4.288 H0. F502. X11.686 Y4.007 Z4.306 H0. F502. X11.682 Y3.919 Z4.32 H0. F498. X11.682 Y3.83 Z4.33 H0. F501. X11.678 Y3.741 Z4.335 H0. F498. X11.678 Y3.651 Z4.338 H0. F503. X11.546 Y3.6 H1.032 F2489.
X11.422 Y3.544 H1.003 F2414.
X11.298 Y3.487 H1.011 F2414.
X11.174 Y3.428 H1.019 F2415.
X11.052 Y3.367 H1.026 F2415.
X10.932 Y3.306 H1.034 F2414.
X10.814 Y3.242 H1.041 F2414.
X10.696 Y3.177 H1.049 F2414.
X10.58 Y3.11 H1.056 F2415.
X10.466 Y3.042 H1.064 F2414.
X10.35 Y2.971 H1.1 F2414.
X10.27 Y2.92 H0.778 F2414.
X10.192 Y2.867 H0.781 F2415.
X10.114 Y2.815 H0.785 F2414.
X10.036 Y2.761 H0.789 F2415.
X9.962 Y2.707 H0.792 F2414.
X9.814 Y2.596 H0.799 F2414. X9.742 Y2.54 H0.791 F2415. X9.674 Y2.484 H0.782 F2414. X9.606 Y2.428 H0.785 F2414. X9.54 Y2.371 H0.788 F2414. X9.476 Y2.313 H0.791 F2414. X9.412 Y2.255 H0.794 F2414. X9.35 Y2.196 H0.797 F2414. X9.29 Y2.137 H0.799 F2414. X9.23 Y2.074 H0.829 F2415. X9.168 Y2.01 H0.859 F2414. X9.108 Y1.944 H0.862 F2415. X9.052 Y1.878 H0.864 F2414. X8.996 Y1.811 H0.867 F2414. X8.942 Y1.743 H0.87 F2415. X8.89 Y1.675 H0.872 F2414. X8.84 Y1.607 H0.875 F2414. X8.794 Y1.541 H0.833 F2415. X8.752 Y1.478 H0.791 F2415. X8.712 Y1.415 H0.793 F2414. X8.674 Y1.351 H0.795 F2415. X8.636 Y1.287 H0.796 F2414. X8.602 Y1.223 H0.798 F2414. X8.568 Y1.158 H0.8 F2415.
X8.536 Y1.093 H0.8 F2414.
X8.508 Y1.028 H0.799 F2414. X8.48 Y0.963 H0.795 F2414. X8.454 Y0.898 H0.797 F2414. X8.43 Y0.832 H0.798 F2415. X8.408 Y0.767 H0.799 F2414. X8.388 Y0.7 H0.8 F2415.
X8.368 Y0.634 H0.8 F2414.
X8.352 Y0.568 H0.802 F2414. X8.336 Y0.501 H0.8 F2415.
X8.324 Y0.435 H0.801 F2414. X8.312 Y0.368 H0.8 F2415.
X8.302 Y0.301 H0.801 F2415. X8.296 Y0.234 H0.802 F2414. X8.29 Y0.168 H0.801 F2414. X8.286 Y0.101 H0.802 F2414. X8.286 Y0.034 H0.802 F2414. X8.286 Y-0.035 H0.819 F2415. X8.286 Y-0.105 H0.837 F2414.
